MiTAC PH11SI User manual

MITAC Desktop Board
PH11SI
Product Guide

2
Desktop Board Features
This chapter briefly describes the features of Desktop Board PH11SI.
Table 1 summarizes the major features of the Desktop Board.
Feature Summary
Form Factor
Thin Mini-iTX (170mm x 170mm), 6 layers
Processor
CPU Type : Intel kylake
-
Desktop platform
CPU Core : Dual Core / Quad Core
ocket : ocket LGA1151
TDP : upport up to 65W CPU types
Chipset
Chipset eries : Intel® H110 Chipset
Graphics
Integrated GFX by CPU
Graphic Core : Gen9
Graphic Memory : hared Memory
3D : DX12, OpenGL 4.3/4.4
Computing : OpenCL 2.0
Memory
Memory ocket: 260
-
pin
o
-
DIMM socket
2
Memory
Type:
DDR
4
@ 1.
2
V
, 2133MHz (
Unbuffered
Non-ECC)
Memory Channel: Dual Channel
Memory Capacity : upport total up to 16 GB
ECC upport : No
SIO Controller
IT8519E
LAN
Controller
Realtek RTL8111G, 10/100/1000 support
Audio
Controller
Codec: HD audio codec,
Realtek ALC662
AMP for internal speaker
Display
Controller
Parade DP701
Expansion slot
PCI
-
E Mini Card (Half)
x 1
, ignal: PCIe, U B2.0
for WiFi/BT module
PCI
-
E Mini Card (Full)
x 1
, ignal: PCIe, ATA3.0
for m ATA or TV card
External I O
HD
-
out
1
VGA out
1
U B3.0
4
RJ
-
45 (
with integrated status LED
s)
1
Line
-
out
1
Mic
-
in
1
DC
-
in Jack
(19V DC
;
5mm/ ID, 7.5mm/ OD)
1
Internal I O
LVD connector
1
Converter BD header
1
Light sensor header
1
U B 2.0 header
5
ATA Connector
2
ATA
Power
1
CPU Fan header
1

3
peaker header
1
ide W/LED header
1
DMIC header
1
19V 2 pin power header (Option#1)
12V 4 pin power header (Option#2)
Power
Option#1: 19V DC
-
in, 19V 2pin power header
Option#2: 12V DC-in, 12V 4pin power header
BIOS AMI BIO
Compliance
CE
FCC
T ABLE 1. M I TAC D ESKTOP B OARD PH11SI F EAT RES

4
Desktop Board Components
Figure 1 sho s the approximate location of the major components on the top side of
MiTAC Desktop Board PH11SI.
Figure 1. MiTAC Desktop Board PH11SI Components (Top)

5
T ABLE 2. M I TAC D ESKTOP B OARD PH11SI C OMPONENTS (S HOWN IN F IG RE 1)
A
Back
P
anel
C
onnectors
B
12V out for Wireless charger Module (
For MiTAC AiO)
C
12V in for Wireless charger Module
D
Fan Connector
E
SATA connector
F
Dual
-
Port USB 2.0 Header
G
Front I O header
(For MiTAC AiO)
H
SATA connector
I
SATA power connector
J
Front I O header
K
CPU FAN header
L
B
acklight power selec
t
M
LVDS connector
N
B
acklight power header
O
DIMM sockets
P
Mini
PCIE
slot (full length)
Q
Dual
-
Port USB 2.0 Header
for
TP &Card reader
header (For MiTAC AiO)
R
NFC RFID
header (For MiTAC AiO)
S
CPU socket
T
Single
-
Port USB 2.0 Header
for
WebCAM
h
eader (For MiTAC AiO)
U
Mini
PCIE
slot (half length)
V
Single USB 2.0 Header
for DMIC (For MiTAC AiO)
W
Internal speaker

6
Processor
The board supports 6th generation Intel Core processors. Other processors may be
supported in the future. This board supports processors ith a maximum attage of
65 W Thermal Design Po er (TDP).
NOTE
This board has specific requirements for providing power to the processor. Additional
power required will depend on configurations chosen by the integrator.
System Memory
NOTE
To be fully compliant with all applicable DDR SDRAM memory specifications, the board
should be populated with D MMs that support the Serial Presence Detect (SPD) data
structure. This allows the B OS to read the SPD data and program the chipset to
accurately configure memory settings for optimum performance. f non-SPD memory
is installed, the B OS will attempt to correctly configure the memory settings, but
performance and reliability may be impacted or the D MMs may not function under the
determined frequency.
The Desktop Board has t o 260-pin DDR4 SO-DIMM sockets ith gold-plated contacts.

7
Connecting to the Internal Headers and Connectors
Front panel main header
Figure 2 Front panel main header pin-out
Pin Signal Name Description Pin Signal Name Description
1 HDD_POWER_LED Pull-up resistor (750) to +5V 2 POWER_LED_MAIN [Out] Front panel LED (main color)
3 HDD_LED# [Out] Hard disk activity LED 4 POWER_LED_ALT [Out] Front panel LED (alt color)
5 GROUND Ground 6 POWER_SWITCH# [In] Power switch
7 RESET_SWITCH# [In] Reset switch 8 GROUND Ground
9 +5V_DC Power 10 KEY No pin
T ABLE 2 F RONT PANEL MAIN HEADER SIGNALS

8
Internal speaker
Figure 3 Internal speaker
Pin Signal Name
1
Front_L-
2
Front_L+
3
Front_R+
4
Front_R-
T ABLE 3 I NTERNAL HEADER SIGNALS
TP & Card reader SB
Figure 4 TP & Card reader SB pin-out
Pin Signal Pin Signal
1 5V_USB 2 5V_USB
3 Data (negative) 4 Data (negative)
5 Data (positive) 6 Data (positive)
7 Ground 8 Ground
9 Key (no pin) 10 No Connect
T ABLE 4 TP & C ARD READER SB SIGNALS

9
WebCAM header
Figure 5 WebCAM header pin-out
Pin Signal name
1
VCC
2
Data (negative)
3
Data (positive)
4
Ground
5
Key (no pin)
T ABLE 5 W EB CAM HEADER SIGNALS
Side IO SB header
Figure 6 Side IO SB header pin-out
Pin
Signal Pin Signal
1 5V_USB 2 5V_USB
3 Data (negative) 4 Data (negative)
5 Data (positive) 6 Data (positive)
7 Ground 8 Ground
9 Key (no pin) 10 No Connect
T ABLE 6 S IDE IO SB HEADER SIGNALS

10
Processor fan header
Figure 7 Processor fan header pin-out
Pin Signal
1 Ground
2 +12V
3 CPU_FAN_TACH
4 CPU_FAN_CTRL
T ABLE 7 P ROCESSOR FAN HEADER
Inverter power voltage selection header
Pins 1&2: jumper position for 12V
Pins 2&3: jumper position for 19V
Figure 8 Inverter power voltage selection
Pin Signal Name
1 12VDUAL_HDMI
2 BKLT_PWR
3 +19V_A
T ABLE 8 I NVERTER POWER VOLTAGE SELECTION HEADER
