ALINCO, INC.
Service Manual
Service ManualService Manual
Service Manual
DJ-V57
www.ALINCO.ru

SPECIFICATIONS DJ-V57
SPECIFICATIONS DJ-V57SPECIFICATIONS DJ-V57
SPECIFICATIONS DJ-V57
<GRNERAL>
136
.
000
～
173
.
995
MHz
*
144
.
000
～
145
.
995
MHz
400
.
000
～
479
.
995
MHz
*
430
.
000
～
439
.
995
MHz
136
.
000
～
173
.
995
MHz
400
.
000
～
511
.
995
MHz
Mode
F3E(FM)
Channel steps
5
、
10
、
12
.
5
、
15
、
20
、
25
&
30
kHz
Memory channels
200 channels, 2 CALL channel
Antenna connector
50Ω(unbalanced)
Frequency stability
±2.5ppm
Microphone impedance
2k ohm nominal
7.2V (Ni-MH battery)
7
～
16
V
(
external DC IN
)
-
10
℃
～
+
60
℃
(
external DC IN
)
+
14
°F
～
+
140
°F
(
external DC IN
)
*Guaranteed range per specifications
<TRANSMITTER>
VHF Output power
approx. 5W
approx. 4.5W (with battery)
approx. 5W (external DC IN)
Modulation system
Variable reactance frequency modulation
WFM Max. frequency deviation
±5kHz
NFM Max. frequency deviation
±2.5kHz
Spurious emission
-60dB or less
<RECEIVER>
Receive system
Double conversion superheterodyne
Intermediate frequencies
38.85MHz(1st) / 450kHz (2nd)
VHF Sensitivity (12dB SINAD)
-14dBu (center range)
UHF Sensitivity (12dB SINAD)
-12dBu (center range)
Selectivity
-6dB: 12kHz or more / -60dB: 35kHz or less
Audio output power
500mW (at 8ohm, MAX)
UHF Output power
Power supply
Usable temperature range
TX Frequency range
RX Frequency range

DJ-V57 CIRCUIT DESCRIPTION
[Reception]
1. RX Metho : Double Conversion Super Hetero yne
1st IF: 38.85 MHz
2n IF: 450 KHz
2. Front En
[VHF]
The signal input from antenna passes through the low pass filter, an then it is
amplifie at RF amplifier Q117. The amplifie signal is le to ban pass filter
an ban switch D132, then input to the mixer Q120.
[UHF]
The signal input from antenna passes through the high pass filter an low pass
filter, an then it is amplifie at RF amplifier Q123. The amplifie signal is le
to ban pass filter an ban switch D132, then input to the mixer Q120.
3. Mixer
The input signal to the mixer Q120 an the 1st local signal are a e or
subtracte at the mixer Q120, an the crystal filter XF101 selects the signal of
38.85 MHz, then it is amplifie at the 1st IF amplifier Q121 after the a jacent
signal is eliminate . The 1st local signal from VCO output is supplie to the
base of mixer Q120 passing through the buffer amplifier Q116.
4. IF
The signal amplifie at the 1st IF amplifier Q121 is supplie to pin 16 of IC105
for emo ulation. Also the signal of 12.8 MHz from X101 multiplie by three at
Q115, an then it is le to pin 1 of IC105. Two input signals are mixe in the
mixer circuit insi e of IC105 an converte into the 2n IF signal of 450 kHz.
The 2n IF signal output from pin 3 of IC105 is supplie to pin 5 of IC105 after
eliminating the a jacent signal at the ceramic filter CF101 in WFM mo e, or at
the ceramic filter CF102 in NFM mo e. The input 2n IF signal to pin 5 of
IC105 is emo ulate at the limiter amplifier an qua rature etection circuit
insi e of IC105, then output from pin 9 of IC105 as an AF signal.

5. Squelch
The AF signal from pin 9 of IC105 is input to pin 8 of IC105. The input signal
is output from pin 14 of IC105 passing through the noise filter amplifier an
rectifier circuits insi e of IC105. The rectifie signal is input to the A/D port
pin 82 of microcomputer IC109. Ju ging the signal, the microcomputer controls
ON/OFF of the au io output.
6. Au io
The AF signal from pin 9 of IC105 is amplifie at Q119, an then it is input to
pin 6 of IC106 passing through the active high pass filter Q118. The volume of
au io signal is a juste at the D/A converter IC106. The au io signal is input
to pin 2 of au io power amplifier IC104 an output from pin 6 to rive a
speaker.
7. VCO
[VHF]
VCO in VHF ban consists of the Colpitts oscillator. D106, D112, L112 an
L115 etermine the oscillating frequency, an the signal is oscillate at the
transistor Q103. L115 is passe at shift transistor Q107 when transmitting.
The oscillate signal is supplie to pin 16 of PLL-IC102 passing through the
buffer amplifier Q114.
[UHF]
VCO in VHF ban consists of the Colpitts oscillator. D119, D124, L127 an
L129 etermine the oscillating frequency, an the signal is oscillate at the
transistor Q108. L129 is passe at shift transistor Q111 when transmitting.
The oscillate signal is supplie to pin 16 of PLL-IC102 passing through the
buffer amplifier Q114.
8. PLL
PLL-IC102 is use to control the oscillating frequency of VCO. IC102 is
controlle by the serial control signal sent from the microcomputer IC109. The
12.8MHz for reference frequency of IC102 oscillates in the TCXO X101.
IC102 compares the frequency gaine by ivi ing the signal input to pin 16 of
IC102 by the control signal from IC109 with the frequency gaine by ivi ing
the reference frequency of 12.8 MHz. When the phase ifference is foun as a

result of phase comparison, the pulse signal is output from the charge pump
output of pin 21 of IC102, then the signal is converte into the DC voltage at
the low pass filter an a e to the catho e si e of VCO vari-cap to make the
phases equal. In result the stabilize oscillation can be one at the esire
frequency.
[Transmission]
1. Microphone Amplifier
The microphone amplifier IC110 has four operational amplifiers. The voice is
converte into the electric signal through the microphone, an then supplie to
IC110. The input signal is amplifie an pre-emphasize to be output.
The signal output from microphone amplifier is a juste the maximum
frequency eviation at D/A converter IC106. The a juste signal is a e to
the catho e of D111 of VHF or D123 of UHF VCO for eviation to change the
capacity of the oscillation circuit resulting the FM eviation.
2. Power Amplifier
The oscillate signal at VCO is amplifie at pre- river amplifier IC101, river
amplifier Q105 an power amplifier Q101. The power-amplifie signal is
supplie to the antenna through the uplexer after the harmonics are rejecte
enough at the low pass filter.

Parts List DJ-V57
MAIN Unit
Ref.No. Parts No. Parts Name
C101 CU3559 GRM155B30J105KE18D
C102 CU3535 GRM155B11H102KA01D
C103 CU3523 GRM1552C1H101JZ01D
C104 CU3535 GRM155B11H102KA01D
C105 CU3554 GRM155B11A104KA01D
C106 CU3535 GRM155B11H102KA01D
C107 CU3535 GRM155B11H102KA01D
C108 CU0124 GRM21BB30J226ME38L
C109 CU3504 GRM1553C1H3R0CZ01D
C110 CU3513 GRM1552C1H150JZ01D
C111 CU3535 GRM155B11H102KA01D
C112 CU3515 GRM1552C1H220JZ01D
C113 CU3511 GRM1552C1H100JZ01D
C114 CU3514 GRM1552C1H180JZ01D
C115 CU3559 GRM155B30J105KE18D
C116 NC
C117 CU3517 GRM1552C1H330JZ01D
C118 CU3516 GRM1552C1H270JZ01D
C119 NC
C120 CU3513 GRM1552C1H150JZ01D
C121 CU3516 GRM1552C1H270JZ01D
C122 CU3515 GRM1552C1H220JZ01D
C123 CU3502 GRM1554C1H1R0CZ01D
C124 CU3502 GRM1554C1H1R0CZ01D
C125 CU3518 GRM1552C1H390JZ01D
C126 CU3518 GRM1552C1H390JZ01D
C127 CU3017 C1608CH1H330JT-NS
C128 NC
C129 NC
C130 CU3535 GRM155B11H102KA01D
C131 CU3502 GRM1554C1H1R0CZ01D
C132 CU3501 GRM1554C1HR50CZ01D
C133 CU3535 GRM155B11H102KA01D
C134 CU3514 GRM1552C1H180JZ01D
C135 CU3513 GRM1552C1H150JZ01D
C136 CU3511 GRM1552C1H100JZ01D
C137 CU3547 GRM155B11C103KA01D
C138 CU3535 GRM155B11H102KA01D
C139 CU3527 GRM1552C1E221JA01D
C140 CU3535 GRM155B11H102KA01D
C141 CU3502 GRM1554C1H1R0CZ01D
C142 CU3502 GRM1554C1H1R0CZ01D
C143 CU3502 GRM1554C1H1R0CZ01D
C144 CU3547 GRM155B11C103KA01D
C145 CU3514 GRM1552C1H180JZ01D
C146 CU3535 GRM155B11H102KA01D
C147 CU3148 GRM188B31E105KA75D
C148 CU3547 GRM155B11C103KA01D
C149 CU3535 GRM155B11H102KA01D
C150 CU3527 GRM1552C1E221JA01D
C151 CU3515 GRM1552C1H220JZ01D
C152 CU3527 GRM1552C1E221JA01D
C153 CU3535 GRM155B11H102KA01D
C154 CU3535 GRM155B11H102KA01D
C155 CU3535 GRM155B11H102KA01D
C156 CU0119 GRM21BB30J106KE18L
C157 CU3547 GRM155B11C103KA01D
C158 CU3535 GRM155B11H102KA01D
C159 CU3535 GRM155B11H102KA01D
1

C160 CU3547 GRM155B11C103KA01D
C161 CU3535 GRM155B11H102KA01D
C162 CU3535 GRM155B11H102KA01D
C163 CS0396 TMCP1D104MTRF
C164 CU3527 GRM1552C1E221JA01D
C165 CU3535 GRM155B11H102KA01D
C166 CU3531 GRM155B11H471KA01D
C167 CU3508 GRM1552C1H7R0DZ01D
C168 CU3523 GRM1552C1H101JZ01D
C169 CU3554 GRM155B11A104KA01D
C170 CU3554 GRM155B11A104KA01D
C171 CU3535 GRM155B11H102KA01D
C172 CU3009 C1608CH1H080DT-NS
C173 CU3007 C1608CH1H060DT/S
C174 CU3013 C1608CH1H150JT/S
C175 NC
C176
CU3531
GRM155B11H471KA01D
C177
CU3507
GRM1552C1H6R0DZ01D
C178 CU3509 GRM1552C1H8R0DZ01D
C179 CU3535 GRM155B11H102KA01D
C180 CU3143 GRM188B30J475KE18D
C181 CU3554 GRM155B11A104KA01D
C182 CU3531 GRM155B11H471KA01D
C183 CU3518 GRM1552C1H390JZ01D
C184 CU3507 GRM1552C1H6R0DZ01D
C185 CU3502 GRM1554C1H1R0CZ01D
C186 CU3511 GRM1552C1H100JZ01D
C187 CU3512 GRM1552C1H120JZ01D
C188 CU3501 GRM1554C1HR50CZ01D
C189 CU3531 GRM155B11H471KA01D
C190 CU3507 GRM1552C1H6R0DZ01D
C191 CU3506 GRM1552C1H5R0CZ01D
C192 CU3518 GRM1552C1H390JZ01D
C193 CU3535 GRM155B11H102KA01D
C194 CU3554 GRM155B11A104KA01D
C195 CU3501 GRM1554C1HR50CZ01D
C196 CU3535 GRM155B11H102KA01D
C197 CU3507 GRM1552C1H6R0DZ01D
C198 CU3501 GRM1554C1HR50CZ01D
C199 CU3501 GRM1554C1HR50CZ01D
C200 CU3535 GRM155B11H102KA01D
C201 CS0396 TMCP1D104MTRF
C202 CU3523 GRM1552C1H101JZ01D
C203 CU3523 GRM1552C1H101JZ01D
C204 CU3502 GRM1554C1H1R0CZ01D
C205 CU3535 GRM155B11H102KA01D
C206 CU3511 GRM1552C1H100JZ01D
C207 CU3556 GRM155B10J224KE01E
C208 CU3531 GRM155B11H471KA01D
C209 CS0397 TMCP1C105MTRF
C210 CU3506 GRM1552C1H5R0CZ01D
C211 CU3535 GRM155B11H102KA01D
C212 CU3535 GRM155B11H102KA01D
C213 CU3531 GRM155B11H471KA01D
C214 CS0396 TMCP1D104MTRF
C215 CU3554 GRM155B11A104KA01D
C216 CU3535 GRM155B11H102KA01D
C217 CU3507 GRM1552C1H6R0DZ01D
C218 CU3523 GRM1552C1H101JZ01D
C219 CU3535 GRM155B11H102KA01D
C220 CU3507 GRM1552C1H6R0DZ01D
C221 NC
2

C222 CU3547 GRM155B11C103KA01D
C223 CU3508 GRM1552C1H7R0DZ01D
C224 CU3521 GRM1552C1H680JZ01D
C225 CU3535 GRM155B11H102KA01D
C226 CU3575 GRM1554C1H1R5BZ01D
C227 CU3503 GRM1554C1H2R0CZ01D
C228 CU3502 GRM1554C1H1R0CZ01D
C229 CU3502 GRM1554C1H1R0CZ01D
C230 CU3511 GRM1552C1H100JZ01D
C231 CU3521 GRM1552C1H680JZ01D
C232 NC
C233 CU3521 GRM1552C1H680JZ01D
C234 NC
C235 CU3517 GRM1552C1H330JZ01D
C236 CU3505 GRM1552C1H4R0CZ01D
C237 CU3535 GRM155B11H102KA01D
C238 NC
C239 CU3535 GRM155B11H102KA01D
C240 CU3547 GRM155B11C103KA01D
C241 CU3535 GRM155B11H102KA01D
C242 NC
C243 CU3519 GRM1552C1H470JZ01D
C244 CU3535 GRM155B11H102KA01D
C245 CU3523 GRM1552C1H101JZ01D
C246 CU3523 GRM1552C1H101JZ01D
C247 CU3523 GRM1552C1H101JZ01D
C248 CU3547 GRM155B11C103KA01D
C249 CU3517 GRM1552C1H330JZ01D
C250 CU3535 GRM155B11H102KA01D
C251 CU3535 GRM155B11H102KA01D
C252 CU3554 GRM155B11A104KA01D
C253 CU3554 GRM155B11A104KA01D
C255 CU3539 GRM155B11H222KA01D
C256 CU3539 GRM155B11H222KA01D
C257 CU3547 GRM155B11C103KA01D
C258 CU3554 GRM155B11A104KA01D
C260 CU3547 GRM155B11C103KA01D
C261 CU3547 GRM155B11C103KA01D
C262 CU3547 GRM155B11C103KA01D
C263 CU3535 GRM155B11H102KA01D
C264 CU3517 GRM1552C1H330JZ01D
C265 CU3547 GRM155B11C103KA01D
C266 CU3148 GRM188B31E105KA75D
C267 CU3554 GRM155B11A104KA01D
C268 CU3523 GRM1552C1H101JZ01D
C269 CU3501 GRM1554C1HR50CZ01D
C270 CU3501 GRM1554C1HR50CZ01D
C271 CU3575 GRM1554C1H1R5BZ01D
C272 CE0463 10CE100BSS
C273 CU3507 GRM1552C1H6R0DZ01D
C274 CU3547 GRM155B11C103KA01D
C275 NC
C276 CU3503 GRM1554C1H2R0CZ01D
C277 CU3502 GRM1554C1H1R0CZ01D
C278 CU3535 GRM155B11H102KA01D
C279 NC
C280 CU3509 GRM1552C1H8R0DZ01D
C281 CU3575 GRM1554C1H1R5BZ01D
C282 CU3523 GRM1552C1H101JZ01D
C283 CU3535 GRM155B11H102KA01D
C284 CU3547 GRM155B11C103KA01D
C285 CU3547 GRM155B11C103KA01D
3

C286 CU3535 GRM155B11H102KA01D
C287 CU3535 GRM155B11H102KA01D
C288 NC
C289 CU3531 GRM155B11H471KA01D
C290 CU3554 GRM155B11A104KA01D
C291 CU3554 GRM155B11A104KA01D
C292 NC
C293 CU3519 GRM1552C1H470JZ01D
C294 CS0397 TMCP1C105MTRF
C295 CU3531 GRM155B11H471KA01D
C296 CU3510 GRM1552C1H9R0DZ01D
C297 CU3509 GRM1552C1H8R0DZ01D
C298 CU3509 GRM1552C1H8R0DZ01D
C299 CU3509 GRM1552C1H8R0DZ01D
C300 CE0436 16CE47BSS
C301 CU3535 GRM155B11H102KA01D
C302 CU3535 GRM155B11H102KA01D
C303 CU3535 GRM155B11H102KA01D
C304 CU3531 GRM155B11H471KA01D
C305 CU3527 GRM1552C1E221JA01D
C306 CU3554 GRM155B11A104KA01D
C307 CU0124 GRM21BB30J226ME38L
C308 CU3547 GRM155B11C103KA01D
C309 CU3535 GRM155B11H102KA01D
C310 CU3531 GRM155B11H471KA01D
C311 CU3554 GRM155B11A104KA01D
C312 CU3554 GRM155B11A104KA01D
C313 CU3554 GRM155B11A104KA01D
C314 CU3527 GRM1552C1E221JA01D
C315 CU3535 GRM155B11H102KA01D
C316 CU3535 GRM155B11H102KA01D
C317 CU3535 GRM155B11H102KA01D
C318 CU3138 GRM188B31C225KE14D
C319 CU3554 GRM155B11A104KA01D
C320 CU3554 GRM155B11A104KA01D
C321 CU3535 GRM155B11H102KA01D
C322 CU3554 GRM155B11A104KA01D
C323 CU3535 GRM155B11H102KA01D
C324 CU3535 GRM155B11H102KA01D
C325 CU3554 GRM155B11A104KA01D
C326 CU3554 GRM155B11A104KA01D
C327 CU0124 GRM21BB30J226ME38L
C328 CU3138 GRM188B31C225KE14D
C329 CU3535 GRM155B11H102KA01D
C330 CS0439 TMCMA0J476MTRF
C331 CU3535 GRM155B11H102KA01D
C332 CU3535 GRM155B11H102KA01D
C333 CU3535 GRM155B11H102KA01D
C334 CU3554 GRM155B11A104KA01D
C335 CU3559 GRM155B30J105KE18D
C336 CU3535 GRM155B11H102KA01D
C339 CU3535 GRM155B11H102KA01D
C340 CU0119 GRM21BB30J106KE18L
C341 CU3535 GRM155B11H102KA01D
C342 CU3547 GRM155B11C103KA01D
C343 CU3547 GRM155B11C103KA01D
C344 CU3559 GRM155B30J105KE18D
C345 CU3138 GRM188B31C225KE14D
C346 CU3148 GRM188B31E105KA75D
C347 CU3535 GRM155B11H102KA01D
C348 CU3554 GRM155B11A104KA01D
C349 CU3148 GRM188B31E105KA75D
4

C350 CU3535 GRM155B11H102KA01D
C351 CU3535 GRM155B11H102KA01D
C352 CU3554 GRM155B11A104KA01D
C353 CU0119 GRM21BB30J106KE18L
C354 CU3535 GRM155B11H102KA01D
C355 CU0119 GRM21BB30J106KE18L
C356 CU3535 GRM155B11H102KA01D
C357 CU3547 GRM155B11C103KA01D
C358 NC
C359 CU3553 GRM155B11A473KA01D
C360 CU3553 GRM155B11A473KA01D
C361 CU3527 GRM1552C1E221JA01D
C362 CU3545 GRM155B11E682KA01D
C363 CU3554 GRM155B11A104KA01D
C364 CU3559 GRM155B30J105KE18D
C365 CU3523 GRM1552C1H101JZ01D
C366 CU3539 GRM155B11H222KA01D
C367 CU3554 GRM155B11A104KA01D
C368 CU3535 GRM155B11H102KA01D
C369 CS0439 TMCMA0J476MTRF
C370 NC
C371 CU3514 GRM1552C1H180JZ01D
C372 CU3535 GRM155B11H102KA01D
C373 CU3541 GRM155B11H332KA01D
C374 CU3554 GRM155B11A104KA01D
C375 CU3547 GRM155B11C103KA01D
C376 CU3148 GRM188B31E105KA75D
C377 CU3535 GRM155B11H102KA01D
C378 CU3513 GRM1552C1H150JZ01D
C379 CU3535 GRM155B11H102KA01D
C380 CU3553 GRM155B11A473KA01D
C381 CU3543 GRM155B11E472KA01D
C382 CU3535 GRM155B11H102KA01D
C383 CU3148 GRM188B31E105KA75D
C384 CU3535 GRM155B11H102KA01D
C385 CU3554 GRM155B11A104KA01D
C386 CU3533 GRM155B11H681KA01D
C387 CU3523 GRM1552C1H101JZ01D
C388 CU3535 GRM155B11H102KA01D
C389 CU3559 GRM155B30J105KE18D
C390 CU3148 GRM188B31E105KA75D
C391 CU3535 GRM155B11H102KA01D
C392 CU3559 GRM155B30J105KE18D
C393 CU3554 GRM155B11A104KA01D
C394 CU3541 GRM155B11H332KA01D
C395 CU3535 GRM155B11H102KA01D
C396 CU0119 GRM21BB30J106KE18L
C397 CU3535 GRM155B11H102KA01D
C398 CU3535 GRM155B11H102KA01D
C399 CU3535 GRM155B11H102KA01D
C400 CU3553 GRM155B11A473KA01D
C401 CU3559 GRM155B30J105KE18D
C402 NC
C403 CU3535 GRM155B11H102KA01D
C404 CU3547 GRM155B11C103KA01D
C405 CU3535 GRM155B11H102KA01D
C406 CU3527 GRM1552C1E221JA01D
C407 CU3535 GRM155B11H102KA01D
C408 CE0436 16CE47BSS
C409 CU3535 GRM155B11H102KA01D
C410 CU3547 GRM155B11C103KA01D
C411 CU3547 GRM155B11C103KA01D
5

C412 CU3554 GRM155B11A104KA01D
C414 CU3523 GRM1552C1H101JZ01D
C415 CU3535 GRM155B11H102KA01D
C416 CU3554 GRM155B11A104KA01D
C417 CU0119 GRM21BB30J106KE18L
C418 CU3554 GRM155B11A104KA01D
C419 CU3535 GRM155B11H102KA01D
C421 NC
C422 CU3507 GRM1552C1H6R0DZ01D
C423
CU3508
GRM1552C1H7R0DZ01D
C424
CU3507
GRM1552C1H6R0DZ01D
C425
CU3535
GRM155B11H102KA01D
C426
NC
C427 NC
C428 CU3535 GRM155B11H102KA01D
C429 CU3143 GRM188B30J475KE18D
CF101 XC0075 CFUKG450KE4A-R0
CF102 XC0074 CFUKG450KG1A-R0
D101 XD0419 1SS400 TE61
D102 XD0326 1SV307(TPH3,F)
D103 XD0422 HSC277TRF-E
D104 XD0339 1SV308(TPH3,F)
D106 XD0421 1SV323(TPH3,F)
D107 XD0422 HSC277TRF-E
D108 XD0433 RB715WTL
D109 XD0422 HSC277TRF-E
D110 XD0422 HSC277TRF-E
D111 XD0422 HSC277TRF-E
D112 XD0421 1SV323(TPH3,F)
D113 XD0451 015AZ3.0-X(TPL3,F)
D114 XD0326 1SV307(TPH3,F)
D116 XD0503 JDP2S04E(TPH3,F)
D117 XD0339 1SV308(TPH3,F)
D118 XD0503 JDP2S04E(TPH3,F)
D119 XD0454 1SV305(TPH3,F)
D120 XD0497 1SS364(TE85L,F)
D121 XD0433 RB715WTL
D122 XD0422 HSC277TRF-E
D123 XD0422 HSC277TRF-E
D124 XD0454 1SV305(TPH3,F)
D125 XD0339 1SV308(TPH3,F)
D126 XD0339 1SV308(TPH3,F)
D127 XD0498 1SV329(TPH3,F)
D128 XD0339 1SV308(TPH3,F)
D129 XD0421 1SV323(TPH3,F)
D130 XD0421 1SV323(TPH3,F)
D131 XD0421 1SV323(TPH3,F)
D132 XD0497 1SS364(TE85L,F)
D133 XD0486 1SV331(TPH3,F)
D134 XD0486 1SV331(TPH3,F)
D135 XD0486 1SV331(TPH3,F)
D136 XD0486 1SV331(TPH3,F)
D137 XD0497 1SS364(TE85L,F)
D138 XD0497 1SS364(TE85L,F)
D139 XL0097 SML-521MUWT86
D140 XL0128 SML-D12M8WT86
D141 XL0128 SML-D12M8WT86
D142 XD0418 RB521S-30TE61
D143 XD0424 S3JB-T
D144 XD0338 1SS362(TE85L,F)
D145 XL0128 SML-D12M8WT86
D146 XL0128 SML-D12M8WT86
6

D147 XD0419 1SS400 TE61
D148 XD0338 1SS362(TE85L,F)
D149 XL0128 SML-D12M8WT86
D150 XL0128 SML-D12M8WT86
D151 XD0418 RB521S-30TE61
D152 XD0499 CMS01(TE12L,Q)
D153 XD0418 RB521S-30TE61
D154 XD0499 CMS01(TE12L,Q)
D155 XD0338 1SS362(TE85L,F)
D156 XD0503 JDP2S04E(TPH3,F)
FB101 QB0057 MPZ1608S101AT/A
FB102 QB0057 MPZ1608S101AT/A
FB103 QB0057 MPZ1608S101AT/A
FB104 QB0057 MPZ1608S101AT/A
FB106 QB0065 FBMH1608HM151-T
IC101 XA0968 UPC2710TB-E3
IC102 XA1410 AK1542-L
IC103 XA1103 LM2904PWR-JF (G4)
IC104 XA0210 NJM2070M-TE1-#ZMZB
IC105 XA1391 NJM2591V-TE1
IC106 XA1411 R2A20178NP#W0
IC107 XA0617 TC75S56FU(TE85L,F)
IC108 XA1119 XC6202P502MR
IC109 XA1496 R5F2L3ACANFP#U1
IC110 XA1106 LM2902PWR (G4)
IC111 XA1103 LM2904PWR-JF (G4)
IC112 XA1106 LM2902PWR (G4)
IC113 XA1120 S-80845CLNB-B66T2G
IC114 XA1413 R1EX24064ATAS0A#S0
JK101 UJ0060 HSJ1594-010150
JK102 UJ0061 LD-0208-1.3
L101 QS402006 0.40-2.0-6TLﾃｰﾋﾟﾝｸﾞ
L102 QS401405 0.40-1.4-5TLﾃｰﾋﾟﾝｸﾞ
L103 QS402006 0.40-2.0-6TLﾃｰﾋﾟﾝｸﾞ
L104 QS401405 0.40-1.4-5TLﾃｰﾋﾟﾝｸﾞ
L105 QS501403 0.50-1.4-3TL ﾃｰﾋﾟﾝｸﾞ
L106 QC0812 MLG1005SR10J-T/A
L107 QC0762 C1608CB-56NJ
L108 QC0762 C1608CB-56NJ
L109 QC0779 C1608H-10NJ
L110 QS402006 0.40-2.0-6TLﾃｰﾋﾟﾝｸﾞ
L111 QC0902 C2012C1R0J
L112 QC0956 C1608CB-62NG
L113 QS402006 0.40-2.0-6TLﾃｰﾋﾟﾝｸﾞ
L114 QC0812 MLG1005SR10J-T/A
L115 QC0786 C1608H-39NJ
L116 QC0736 LK10052R2K-T
L117 QC0816 MLG1005SR22J-T/A
L119 QS401405 0.40-1.4-5TLﾃｰﾋﾟﾝｸﾞ
L120 QS401405 0.40-1.4-5TLﾃｰﾋﾟﾝｸﾞ
L121 QS401205 E2-0.40-1.2-5TR
L122 QS501402 0.50-1.4-2TLﾃｰﾋﾟﾝｸﾞ
L123 QC0808 MLG1005S47NJ-T/A
L124 QS401405 0.40-1.4-5TLﾃｰﾋﾟﾝｸﾞ
L125 QC0773 C1608CB-R47J
L126 QS401405 0.40-1.4-5TLﾃｰﾋﾟﾝｸﾞ
L127 QC0778 C1608H-8N2J
L129 QC0774 C1608H-2N7K
L130 QC0812 MLG1005SR10J-T/A
L132 QC0816 MLG1005SR22J-T/A
L133 QC0816 MLG1005SR22J-T/A
L134 QC0875 C2012H68NH
7

L135 QC0816 MLG1005SR22J-T/A
L136 QC0875 C2012H68NH
L137 QC0875 C2012H68NH
L138 QC0874 C2012H56NH
L139 QC0816 MLG1005SR22J-T/A
L140 QC0773 C1608CB-R47J
L141 QC0955 C1608H-15NG
L142 QC0955 C1608H-15NG
L143 QC0955 C1608H-15NG
L144 QC0782 C1608H-18NJ
L145 QC0780 C1608H-12NJ
L146 QC0762 C1608CB-56NJ
L147 QC0965 LB2012T220K
L148 QC0779 C1608H-10NJ
LCD101 EL0059 L5-0353TRM
MIC101 EY0017 OB-27P44 (ROHS)ﾀｲｵｳ
Q101 XT0210 2SC6026MFV-GR(TPL3)
Q102 XE0090 SSM3J15FV(TPL3,Z)
Q103 XT0180 2SC5066FT-Y(T5L,F)
Q104 XU0237 RN47A4JE(TE85L,F)
Q105 XE0094 RD01MUS2-T113
Q106 XE0100 RD07MUS2B-T112
Q107 XU0210 RN1107MFV(TPL3)
Q108 XT0180 2SC5066FT-Y(T5L,F)
Q109 XE0090 SSM3J15FV(TPL3,Z)
Q110 XU0210 RN1107MFV(TPL3)
Q111 XU0210 RN1107MFV(TPL3)
Q112 XU0237 RN47A4JE(TE85L,F)
Q113 XT0180 2SC5066FT-Y(T5L,F)
Q114 XT0180 2SC5066FT-Y(T5L,F)
Q115 XT0213 2SC5659 T2L P
Q116 XT0180 2SC5066FT-Y(T5L,F)
Q117 XE0053 3SK293(TE85L,F)
Q118 XT0210 2SC6026MFV-GR(TPL3)
Q119 XT0210 2SC6026MFV-GR(TPL3)
Q120 XT0180 2SC5066FT-Y(T5L,F)
Q121 XT0213 2SC5659 T2L P
Q122 XE0090 SSM3J15FV(TPL3,Z)
Q123 XE0053 3SK293(TE85L,F)
Q124 XE0090 SSM3J15FV(TPL3,Z)
Q125 XT0241 TPCP8602(TE85L,F)
Q126 XU0237 RN47A4JE(TE85L,F)
Q127 XT0214 HN2C01FE-GR(T5L,F)
Q128 XU0220 RN2111MFV(TPL3)
Q129 XT0212 2SA1955FV-A (TPL3)
Q130 XE0090 SSM3J15FV(TPL3,Z)
Q131 XT0212 2SA1955FV-A (TPL3)
Q132 XU0237 RN47A4JE(TE85L,F)
Q133 XT0241 TPCP8602(TE85L,F)
Q134 XU0210 RN1107MFV(TPL3)
Q135 XT0212 2SA1955FV-A (TPL3)
Q136 XU0211 RN2107MFV(TPL3)
Q137 XT0214 HN2C01FE-GR(T5L,F)
Q138 XU0213 RN1111MFV(TPL3)
Q139 XU0210 RN1107MFV(TPL3)
Q140 XU0211 RN2107MFV(TPL3)
Q141 XU0211 RN2107MFV(TPL3)
Q142 XU0212 RN2115MFV (TPL3)
Q143 XU0211 RN2107MFV(TPL3)
Q144 XU0210 RN1107MFV(TPL3)
Q145 XU0210 RN1107MFV(TPL3)
Q146 XU0220 RN2111MFV(TPL3)
8

Q147 XU0210 RN1107MFV(TPL3)
Q148 XT0241 TPCP8602(TE85L,F)
Q149 XT0210 2SC6026MFV-GR(TPL3)
Q150 XU0213 RN1111MFV(TPL3)
Q151 XU0210 RN1107MFV(TPL3)
Q152 XU0213 RN1111MFV(TPL3)
Q153 XU0210 RN1107MFV(TPL3)
Q154 XU0210 RN1107MFV(TPL3)
R101 RK3542 RK73B1ETTP222J
R102 RK3534 RK73B1ETTP471J
R103 RK3526 RK73B1ETTP101J
R104 RK3522 RK73B1ETTP470J
R105 RK3550 RK73B1ETTP103J
R106 NC
R107 RK3530 RK73B1ETTP221J
R108 RK3554 RK73B1ETTP223J
R109 RK3030 RK73B1JTTD221J
R110 RK3552 RK73B1ETTP153J
R111 RK3574 RK73B1ETTP105J
R112 RK3562 RK73B1ETTP104J
R113 RK3526 RK73B1ETTP101J
R114 RK3550 RK73B1ETTP103J
R115 RK3018 RK73B1JTTD220J
R116 RK3530 RK73B1ETTP221J
R117 RK3530 RK73B1ETTP221J
R118 RK3550 RK73B1ETTP103J
R119 RK3550 RK73B1ETTP103J
R120 RK3560 RK73B1ETTP683J
R121 RK3556 RK73B1ETTP333J
R122 RK3526 RK73B1ETTP101J
R123 RK3537 RK73B1ETTP821J
R124 RK3562 RK73B1ETTP104J
R125 RK3562 RK73B1ETTP104J
R126 RK3532 RK73B1ETTP331J
R127 RK3562 RK73B1ETTP104J
R128 RK3538 RK73B1ETTP102J
R130 RK3550 RK73B1ETTP103J
R131 RK3566 RK73B1ETTP224J
R132 RK3558 RK73B1ETTP473J
R133 RK3526 RK73B1ETTP101J
R134 RK3534 RK73B1ETTP471J
R135 RK3546 RK73B1ETTP472J
R136 RK3526 RK73B1ETTP101J
R137 RK3554 RK73B1ETTP223J
R138 NC
R140 RK3550 RK73B1ETTP103J
R141 RK3558 RK73B1ETTP473J
R142 RK3552 RK73B1ETTP153J
R143 RK3550 RK73B1ETTP103J
R144 RK3563 RK73B1ETTP124J
R145 RK3544 RK73B1ETTP332J
R146 RK3550 RK73B1ETTP103J
R147 RK3550 RK73B1ETTP103J
R148 RK3544 RK73B1ETTP332J
R149 RK3556 RK73B1ETTP333J
R150 RK3532 RK73B1ETTP331J
R151 RK3550 RK73B1ETTP103J
R152 RK3534 RK73B1ETTP471J
R153 RK3530 RK73B1ETTP221J
R154 RK3562 RK73B1ETTP104J
R155 RK3562 RK73B1ETTP104J
R156 RK3526 RK73B1ETTP101J
9

R157 RK3542 RK73B1ETTP222J
R158 RK3550 RK73B1ETTP103J
R159 RK3552 RK73B1ETTP153J
R160 RK3534 RK73B1ETTP471J
R161 RK3546 RK73B1ETTP472J
R162 RK3550 RK73B1ETTP103J
R163 RK3562 RK73B1ETTP104J
R164 RK3562 RK73B1ETTP104J
R165 RK3566 RK73B1ETTP224J
R166 RK3542 RK73B1ETTP222J
R167 RK3538 RK73B1ETTP102J
R168 RK3562 RK73B1ETTP104J
R169 RK3530 RK73B1ETTP221J
R170 RK3566 RK73B1ETTP224J
R171 RK3530 RK73B1ETTP221J
R172 RK3526 RK73B1ETTP101J
R173 RK3562 RK73B1ETTP104J
R174 RK3522 RK73B1ETTP470J
R175 RK3562 RK73B1ETTP104J
R176 RK3562 RK73B1ETTP104J
R177 RK3538 RK73B1ETTP102J
R178 RK3526 RK73B1ETTP101J
R179 RK3556 RK73B1ETTP333J
R180 RK3562 RK73B1ETTP104J
R181 RK3546 RK73B1ETTP472J
R182 RK3570 RK73B1ETTP474J
R183 RK3526 RK73B1ETTP101J
R184 RK3526 RK73B1ETTP101J
R185 RK3570 RK73B1ETTP474J
R186 RK3546 RK73B1ETTP472J
R187 RK3501 RK73Z1ETTP
R188 RK3543 RK73B1ETTP272J
R189 RK3562 RK73B1ETTP104J
R190 RK3537 RK73B1ETTP821J
R191 RK3566 RK73B1ETTP224J
R192 RK3550 RK73B1ETTP103J
R193 RK3546 RK73B1ETTP472J
R194 RK3546 RK73B1ETTP472J
R195 RK3534 RK73B1ETTP471J
R196 RK3538 RK73B1ETTP102J
R197 RK3562 RK73B1ETTP104J
R198 RK3538 RK73B1ETTP102J
R199 RK3546 RK73B1ETTP472J
R200 RK3574 RK73B1ETTP105J
R201 RK3550 RK73B1ETTP103J
R202 RK3570 RK73B1ETTP474J
R203 RK3550 RK73B1ETTP103J
R204 RK3514 RK73B1ETTP100J
R205 RK3550 RK73B1ETTP103J
R206 RK3526 RK73B1ETTP101J
R207 RK3538 RK73B1ETTP102J
R208 RK3532 RK73B1ETTP331J
R209 RK3574 RK73B1ETTP105J
R210 RK3562 RK73B1ETTP104J
R211 RK3564 RK73B1ETTP154J
R212 RK3522 RK73B1ETTP470J
R213 RK3562 RK73B1ETTP104J
R214 RK3562 RK73B1ETTP104J
R215 RK3562 RK73B1ETTP104J
R216 RK3538 RK73B1ETTP102J
R217 RK3558 RK73B1ETTP473J
R218 RK3562 RK73B1ETTP104J
10

R219 RK3562 RK73B1ETTP104J
R220 RK3574 RK73B1ETTP105J
R221 RK3554 RK73B1ETTP223J
R222 RK3553 RK73B1ETTP183J
R223 RK3526 RK73B1ETTP101J
R224 RK3526 RK73B1ETTP101J
R225 RK3564 RK73B1ETTP154J
R226 RK3574 RK73B1ETTP105J
R227 RK3554 RK73B1ETTP223J
R228 RK3550 RK73B1ETTP103J
R229 RK3562 RK73B1ETTP104J
R230 RK3550 RK73B1ETTP103J
R231 RK3558 RK73B1ETTP473J
R232 RK3542 RK73B1ETTP222J
R233 RK3536 RK73B1ETTP681J
R234 RK3532 RK73B1ETTP331J
R235 RK3546 RK73B1ETTP472J
R236 RK3562 RK73B1ETTP104J
R237 NC
R238 NC
R239 RK3542 RK73B1ETTP222J
R240 RK3552 RK73B1ETTP153J
R241 RK3546 RK73B1ETTP472J
R242 RK3546 RK73B1ETTP472J
R243 RK3546 RK73B1ETTP472J
R244 RK3546 RK73B1ETTP472J
R245 RK3546 RK73B1ETTP472J
R246 RK3546 RK73B1ETTP472J
R247 RK3550 RK73B1ETTP103J
R248 RK3550 RK73B1ETTP103J
R249 RK3562 RK73B1ETTP104J
R250 RK3562 RK73B1ETTP104J
R251 RK3562 RK73B1ETTP104J
R252 RK3562 RK73B1ETTP104J
R253 RK3558 RK73B1ETTP473J
R254 NC
R255 RK3552 RK73B1ETTP153J
R256 RK3538 RK73B1ETTP102J
R257 RK3562 RK73B1ETTP104J
R258 RK3526 RK73B1ETTP101J
R259 RK3536 RK73B1ETTP681J
R260 RK3562 RK73B1ETTP104J
R261 RK3550 RK73B1ETTP103J
R264 RK3566 RK73B1ETTP224J
R265 RK3563 RK73B1ETTP124J
R266 RK3548 RK73B1ETTP682J
R267 RK3552 RK73B1ETTP153J
R268 RK3550 RK73B1ETTP103J
R269 RK3501 RK73Z1ETTP
R270 RK3538 RK73B1ETTP102J
R271 RK3550 RK73B1ETTP103J
R272 RK3548 RK73B1ETTP682J
R273 RK3542 RK73B1ETTP222J
R274 RK3538 RK73B1ETTP102J
R275 RK3560 RK73B1ETTP683J
R276 NC
R277 RK1018 ERJ8GEYJ101V
R278 RK3552 RK73B1ETTP153J
R279 RK3562 RK73B1ETTP104J
R280 RK3554 RK73B1ETTP223J
R281 RK3559 RK73B1ETTP563J
R282 RK3558 RK73B1ETTP473J
11

R283 RK3566 RK73B1ETTP224J
R284 RK3562 RK73B1ETTP104J
R285 RK3562 RK73B1ETTP104J
R286 RK3550 RK73B1ETTP103J
R287 RK3550 RK73B1ETTP103J
R288 RK3550 RK73B1ETTP103J
R289 RK3558 RK73B1ETTP473J
R290 RK3558 RK73B1ETTP473J
R291 RK3558 RK73B1ETTP473J
R292 RK3550 RK73B1ETTP103J
R293 RK3562 RK73B1ETTP104J
R294 RK3562 RK73B1ETTP104J
R295 RK3550 RK73B1ETTP103J
R296 RK3554 RK73B1ETTP223J
R297 RK3554 RK73B1ETTP223J
R298 RK3550 RK73B1ETTP103J
R299 RK3558 RK73B1ETTP473J
R300 RK3574 RK73B1ETTP105J
R301 RK3550 RK73B1ETTP103J
R302 RK3556 RK73B1ETTP333J
R303 RK3566 RK73B1ETTP224J
R304 RK3570 RK73B1ETTP474J
R306 RK3550 RK73B1ETTP103J
R307 RK3546 RK73B1ETTP472J
R308 RK3566 RK73B1ETTP224J
R309 RK3568 RK73B1ETTP334J
R310 RK3574 RK73B1ETTP105J
R311 RK3550 RK73B1ETTP103J
R312 RK3550 RK73B1ETTP103J
R313 RK3556 RK73B1ETTP333J
R314 RK3556 RK73B1ETTP333J
R315 RK3536 RK73B1ETTP681J
R316 RK3562 RK73B1ETTP104J
R317 RK3550 RK73B1ETTP103J
R318 RK3017 RK73B1JTTD180J
R319 RK3566 RK73B1ETTP224J
R320 RK3558 RK73B1ETTP473J
R321 RK3562 RK73B1ETTP104J
R322 RK3546 RK73B1ETTP472J
R323 RK3550 RK73B1ETTP103J
R324 RK3558 RK73B1ETTP473J
R325 RK3558 RK73B1ETTP473J
R326 RK3552 RK73B1ETTP153J
R327 RK3562 RK73B1ETTP104J
R328 RK3016 RK73B1JTTD150J
R329 RK3537 RK73B1ETTP821J
R330 RK3562 RK73B1ETTP104J
R331 RK3550 RK73B1ETTP103J
R332 RK3546 RK73B1ETTP472J
R333 RK3562 RK73B1ETTP104J
R334 RK3550 RK73B1ETTP103J
R335 RK3570 RK73B1ETTP474J
R336 RK3552 RK73B1ETTP153J
R337 RK3567 RK73B1ETTP274J
R338 RK3537 RK73B1ETTP821J
R339 RK3550 RK73B1ETTP103J
R340 RK3574 RK73B1ETTP105J
R341 NC
R342 RK3566 RK73B1ETTP224J
R343 NC
R344 RK3538 RK73B1ETTP102J
R345 RK3538 RK73B1ETTP102J
12

R347 RK3554 RK73B1ETTP223J
R348 RK3550 RK73B1ETTP103J
R349 RK3550 RK73B1ETTP103J
R350 RK3550 RK73B1ETTP103J
R351 RK3546 RK73B1ETTP472J
R353 NC
R354 RK3546 RK73B1ETTP472J
R355 RK3546 RK73B1ETTP472J
R356 RK3546 RK73B1ETTP472J
R357 RK3546 RK73B1ETTP472J
R358 NC
R359 RK3555 RK73B1ETTP273J
R361 RK3532 RK73B1ETTP331J
R362 RK3530 RK73B1ETTP221J
R363 RK3501 RK73Z1ETTP
R364 RK3550 RK73B1ETTP103J
R365 RK3550 RK73B1ETTP103J
R366 NC
R368 RK3544 RK73B1ETTP332J
R369 RK3562 RK73B1ETTP104J
R370 NC
R371 RK3501 RK73Z1ETTP
R373 RK3574 RK73B1ETTP105J
R374 NC
R375 NC
R377 RK3526 RK73B1ETTP101J
R378 RK3554 RK73B1ETTP223J
R379 RK3554 RK73B1ETTP223J
R380 RK3562 RK73B1ETTP104J
R381 RK0107 ERJ6GEY0R00V
SW101 UU0041 EVQP4203M
SW102 UU0041 EVQP4203M
SW103 UU0041 EVQP4203M
TH101 XS0052 NTCG104LH104JT/A
X101 XQ0194 NT3225SA 12.800MHZ
X102 XK0014 CDBKB450KCAY70-R0
X103 XQ0233 DSX530GA 8.192MHZ
XF0085 XF0085 DSF753SBF 38.85MHZ
FM0265A HEAT SINK
DG0046 LCD LIGHT DJ170
FG0418 LCD RUB CONE
ST0089 LCD HOLDER
TL0033 REFLECTIVE SHEET
TS0193 VCO CASE DJS57
MACLH2GG #30AH1-025-H1
UP0660 INTEGRATED DJS57
13

Mechanical Unit
Ref.No. Parts No. Parts Name
AA0083 M6 WATERPROOF
AF0003Z XQN2+C3FN
AF0018Z XQN2+C4FJK
AF0030 XQN2+A6FN(58364-0001
AN0012Z ﾀﾞｲﾔﾙﾅｯﾄ ｸﾛﾆｯｹﾙ
AN0033 BASE NUT
AN0034 M6 NUT BR/B.N
AP0039 ﾅﾍﾞP2+20ﾃﾂ 3BBC
AX0004Z PT 3P 2X8 3BBC
DP0210 LCD PANEL
ES0034 40-8BB-17
FG0392 WATERPROOF CAP
FG0416 BASE RUBBER
FG0417 DC CAP
FG0419 WATERPROOF RUBBER
FG0420A POWER KEY V17
FG0421 PTT RUBBER
FG0424 O RING DJ170
FG0426 MIC RUBBER DJ170
FG0427 ON AIR RUBBER
FG0422 KEY RUBBER
FG0472 CUSHION EDH34
FG0503 JACK RUBBER DJS57
FK0002 MIC SPACER DJP82
FM0263 GROUND DJ170
FM0264Z JACK BASE
FP0254 REAR COVER DJ170
FP0255 LOCK LEVER DJV17
FP0264 BLIND SEAL DJ170
FP0265 S-NTF1026J 5.8X3.0PH
FP0266 INSULATION SHEET
KZ0240 FRONT CASE ASSY
MACL07AA #30A02-070-02
MRCL07AA #30R02-070-02
NK0081 KNOB
SD0111A BATTERY TERMINAL
SP0013 LECTRA #7800
SS0103A CHASSIS
UE0502A SMA CONNECTOR
UP0535 BATT PANEL BOARD
UR0027 RH70N97E20 16.2F
YX0039 LCD TAPE DJS45
Packing Unit
BB0009Y HAND STRAP
BH0017 BELT CLIP
EA0114A ANTENNA
EG0063 EBP66
EDC160 NI-MH CHARGER SET
www.ALINCO.ru

ALINCO, INC.
MAIN - Side A
DJV57 PC Board View
