Allen-Bradley PowerFlex 20-COMM-P User manual

PowerFlex 20-COMM-P Profibus Adapter
FRN 1.xxx
User Manual

Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and
operation of this equipment before you install, configure, operate, or maintain this product. Users are required to
familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws,
and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required
to be carried out by suitably trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the
use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or
software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation,
Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Labels may also be on or inside the equipment to provide specific precautions.
Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT
Identifies information that is critical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Summary of Changes
The information below summarizes the changes made to this manual since
its last release (November 2001):
Description of Changes Page
Reformatted document from half size (5.5 x 8.5 in.) to full size (8.5 x 11 in.) Throughout
manual
Added information about Connected Components Workbench software configuration
toll for drives and connected peripherals.
Revised the ‘DPI Ports and Internal Interface Cables’ figure, and the ‘Mounting and
Grounding the Adapter’ figure to show PowerFlex 700H/S Frames 9 and larger.
2-4 and 2-5
In the ‘Applying Power’ section in Chapter 2, added new subsections ‘Start-Up Status
Indications’ and ‘Configuring and Verifying Key Drive Parameters’.
2-8 and 2-9
In Chapter 3, added new section ‘Updating the Adapter Firmware’. 3-6
In the section ‘Using Reference/Feedback’ in Chapter 5, added the following new
subsections:
•‘PowerFlex 70/700/700H, and PowerFlex 700L Drives with 700 Control’
•‘PowerFlex 700S and PowerFlex 700L Drives with 700S Control’
•‘PowerFlex Digital DC Drives’
5-5
5-6
5-6
In the section ‘Using Datalinks’ in Chapter 5, added the new subsection ‘Datalink
Scaling’. 5-7
Revised Appendix C to include the following new sections:
•‘PowerFlex 70/700/700H, and 700L (with 700 Control) Drives’
•‘PowerFlex 700S (Phase II Control) and 700L (with 700S Control) Drives’
•‘PowerFlex Digital DC Drives’
C-1
C-3
C-5

soc-ii Summary of Changes
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P

PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Table of Contents
Preface About This Manual
Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-1
Rockwell Automation Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-2
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-2
Chapter 1 Getting Started
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Compatible Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Required Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Chapter 2 Installing the Adapter
Preparing for an Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Commissioning the Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Setting the Node Address Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Connecting the Adapter to the Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Connecting the Adapter to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Node Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Applying Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Chapter 3 Configuring the Adapter
Configuration Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Using the PowerFlex 7-Class HIM to Access Parameters . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Setting the Node Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Setting the I/O Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Setting a Fault Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Resetting the Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Viewing the Adapter Status Using Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Updating the Adapter Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Chapter 4 Configuring the Profibus Scanner
Example Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
SST Profibus Configuration Software Tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Installing the 20-COMM-P GSD File Into Software Tool Library. . . . . . . . . . . . . . . . . . 4-2
Configuring the SST-PFB-SLC Profibus Scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
GSD Diagnostic Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

ii Table of Contents
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Chapter 5 Using the I/O
About I/O Messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Understanding the I/O Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Using Logic Command/Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Using Reference/Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Using Datalinks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
SLC Controller Example Ladder Logic Program Information . . . . . . . . . . . . . . . . . . . . . 5-8
SLC Ladder Logic Example Main Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
SLC Ladder Logic Example Station 1 Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
SLC Ladder Logic Example Station 2 Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Chapter 6 Using Explicit Messaging
About Explicit Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Performing Explicit Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Parameter Protocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
SLC Ladder Example Station 1 Parameter Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
SLC Ladder Example Station 2 Parameter Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Chapter 7 Troubleshooting
Understanding the Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
PORT Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
MOD Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
NET A Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Viewing Adapter Diagnostic Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Viewing and Clearing Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Appendix A Specifications
Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Mechanical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Appendix B Adapter Parameters
About Parameter Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Parameter List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Appendix C Logic Command/Status Words
PowerFlex 70/700/700H, and 700L (with 700 Control) Drives . . . . . . . . . . . . . . . . . . . . C-1
PowerFlex 700S (Phase II Control) and 700L (with 700S Control) Drives . . . . . . . . . . . C-3
PowerFlex Digital DC Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5
Glossary
Index

PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Preface
About This Manual
This manual provides information about the adapter and using it with
PowerFlex 7-Class (Architecture-Class) drives. The adapter can be used
with other products that support a DPI™ adapter. See the documentation for
your product for specific information about how it works with the adapter.
Conventions Used in This
Manual
The following conventions are used throughout this manual:
•Parameter names are shown in the format Parameter xx - [*]. The xx
represents the parameter number. The * represents the parameter name
—for example Parameter 01 - [DPI Port].
•Menu commands are shown in bold type face and follow the format
Menu > Command. For example, if you read ‘Select File > Open’, you
should click the File menu and then click the Open command.
•The firmware revision number (FRN) is displayed as FRN X.xxx, where
‘X’ is the major revision number and ‘xxx’ is the minor revision number.
Topic Page
Conventions Used in This Manual P-1
Rockwell Automation Support P-2
Additional Resources P-2

P-2 About This Manual
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Rockwell Automation
Support
Rockwell Automation offers support services worldwide, with over 75 sales
and support offices, over 500 authorized distributors, and over 250
authorized systems integrators located throughout the United States alone.
In addition, Rockwell Automation representatives are in every major
country in the world.
Local Product Support
Contact your local Rockwell Automation, Inc. representative for:
•Sales and order support
•Product technical training
•Warranty support
•Support service agreements
Technical Product Assistance
For technical assistance, please review the information in Chapter 7,
Troubleshooting, first. If you still have problems, then access the
Allen-Bradley Technical Support website at www.ab.com/support/abdrives
or contact Rockwell Automation.
Additional Resources These documents contain additional information concerning related
products from Rockwell Automation.
Resource Description
PowerFlex 7-Class DPI (Drive Peripheral Interface) Network Communication Adapter Installation
Instructions, publication 20COMM-IN004
Information on installing PowerFlex® 20-COMM-x Network
Communication Adapters.
Connected Components Workbench website http://www.ab.com/support/abdrives/webupdate/
software.html, and online help (1)
Information on the Connected Components Workbench
software tool—and includes a link for free software download.
DriveExplorer website http://www.ab.com/drives/driveexplorer, and online help (1) Information on using the DriveExplorer™ software tool.
DriveExecutive website http://www.ab.com/drives/drivetools, and online help (1) Information on using the DriveExecutive™ software tool.
PowerFlex 20-HIM-A3/-A5/-C3S/-C5S HIM Quick Reference, publication 20HIM-QR001 Information on using PowerFlex 20-HIM-A3, 20-HIM-A5,
20-HIM-C3S, and 20-HIM-C5S HIMs.
PowerFlex 20-HIM-A6/C6S HIM (Human Interface Module) User Manual, publication 20HIM-UM001 Information on installing and using PowerFlex 20-HIM-A6 and
20-HIM-C6S HIMs.
PowerFlex 70 User Manual, publication 20A-UM001
PowerFlex 70/700 Reference Manual, publication PFLEX-RM001
PowerFlex 70 Enhanced Control and 700 Vector Control Reference Manual, publication PFLEX-RM004
Information on installing and programming PowerFlex 70
standard control and enhanced control drives.
PowerFlex 700 Series A User Manual, publication 20B-UM001
PowerFlex 700 Series B User Manual, publication 20B-UM002
PowerFlex 70/700 Reference Manual, publication PFLEX-RM001
PowerFlex 70 Enhanced Control and 700 Vector Control Reference Manual, publication PFLEX-RM004
Information on installing and programming PowerFlex 700
standard control and vector control Series A drives, and
PowerFlex 700 vector control Series B drives.
PowerFlex 700H Installation Instructions, publication PFLEX-IN006
PowerFlex 700H Programming Manual, publication 20C-PM001
Information on installing and programming PowerFlex 700H
drives.

About This Manual P-3
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Documentation can be obtained online at http://
literature.rockwellautomation.com. To order paper copies of technical
documentation, contact your local Rockwell Automation distributor or sales
representative.
To find your local Rockwell Automation distributor or sales representative,
visit http://www.rockwellautomation.com/locations.
For information such as firmware updates or answers to drive-related
questions, go to the Drives Service & Support website at http://
www.ab.com/support/abdrives and click on the Downloads or
Knowledgebase link.
PowerFlex 700S w/Phase I Control Installation Manual (Frames 1…6), publication 20D-IN024
PowerFlex 700S w/Phase I Control Installation Manual (Frames 9 and 10), publication PFLEX-IN006
PowerFlex 700S w/Phase I Control User Manual (All Frame Sizes), publication 20D-UM001
PowerFlex 700S w/Phase I Control Reference Manual, publication PFLEX-RM002
PowerFlex 700S w/Phase II Control Installation Manual (Frames 1…6), publication 20D-IN024
PowerFlex 700S w/Phase II Control Installation Manual (Frames 9…14), publication PFLEX-IN006
PowerFlex 700S w/Phase II Control Programming Manual (All Frame Sizes), publication 20D-PM001
PowerFlex 700S w/Phase II Control Reference Manual, publication PFLEX-RM003
Information on installing and programming PowerFlex 700S
drives.
PowerFlex 700L User Manual, publication 20L-UM001 Information on installing and programming PowerFlex 700L
Liquid-Cooled AC drives.
PowerFlex Digital DC Drive User Manual, publication 20P-UM001 Information on installing and programming PowerFlex Digital
DC drives.
Profibus Installation Guideline at http://www.profibus.com/ Information on the planning, installation, and techniques used
to implement a Profibus network.
Profibus Standard at http://www.profibus.com/ Information on Profibus standards and specifications.
SLC 500 Modular Hardware Style Installation and Operation Manual, publication 1747-6.21 Information on installing and operating the SLC 500 controller.
SLC 500 Instruction Set, publication 1747-RM001 Information on status file functions and instructions for ladder
logic programs.
(1) The online help is installed with the software.
Resource Description

P-4 About This Manual
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Notes:

PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Chapter 1
Getting Started
The adapter is intended for installation into a PowerFlex 7-Class drive and
is used for network communication.
Components
Topic Page
Components 1-1
Features 1-2
Compatible Products 1-2
Required Equipment 1-3
Safety Precautions 1-5
Quick Start 1-6
Item Part Description
➊Status Indicators Three status indicators that indicate the status of the DPI, adapter,
and network connection. See Chapter 7, Troubleshooting.
➋DPI Connector A 20-pin, single-row shrouded male header. An Internal Interface
cable is connected to this connector and a connector on the drive.
➌Profibus Connector A 9-pin, female D-sub connector to connect to the network.
➍Node Address
Switches
Switches to set the node address. See Setting the Node Address
Switches on page 2-2.
➊
➌
➋
➍

1-2 Getting Started
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Features The features of the adapter include the following:
•Typical mounting in a PowerFlex 7-Class drive.
•Captive screws to secure and ground the adapter to the drive.
•Compatibility with various configuration tools to configure the adapter
and connected host drive, including the following tools:
–PowerFlex HIM (Human Interface Module) on the drive, if available
–Connected Components Workbench software, version 1.02 or later
–DriveExplorer software, version 2.01 or later
–DriveExecutive software, version 3.01 or later
•Switches to set a node address before applying power to the PowerFlex
drive. Or, you can disable the switches and use an adapter parameter to
set the node address.
•Status indicators that report the status of the drive communications, the
adapter, and network. They are visible when the drive cover is open or
closed.
•Parameter-configured I/O (Logic Command/Reference and up to four
pairs of Datalinks) to accommodate application requirements.
•Explicit Messaging support using the PROFIDRIVE Parameter Protocol.
•User-defined fault actions to determine how the adapter and connected
PowerFlex drive respond to the following:
–I/O messaging communication disruptions (Comm Flt Action)
–Controllers in idle mode (Idle Flt Action)
•Access to any PowerFlex drive and its connected peripherals on the
network to which the adapter is connected.
Compatible Products At the time of publication, the adapter is compatible with the following
products:
•PowerFlex 70 drives with standard or enhanced control
•PowerFlex 700 drives with standard or vector control
•PowerFlex 700H drives
•PowerFlex 700S drives with Phase I or Phase II control
•PowerFlex 700L drives with 700 vector control or 700S control
•PowerFlex Digital DC drives
•SMC™ Flex smart motor controllers
•SMC-50 smart motor controllers

Getting Started 1-3
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Required Equipment Some of the equipment that is required for use with the adapter is shipped
with the adapter, but some you must supply yourself.
Equipment Shipped with the Adapter
When you unpack the adapter, verify that the package includes the
following:
User-Supplied Equipment
To install and configure the adapter, you must supply the following:
❑One 20-COMM-P adapter
❑One 2.54 cm (1 in.) long and one 15.24 cm (6 in.) long Internal
Interface cable (only one cable is needed to connect the adapter to the
drive; for which cable to use, see Figure 2.2 on page 2-4)
❑GSD file on digital media
❑One PowerFlex 7-Class DPI (Drive Peripheral Interface) Network
Communication Adapter Installation Instructions, publication
20COMM-IN004
❑A small flathead screwdriver
❑Profibus network cable
❑One 9-pin, male D-Sub Profibus connector [Note: Profibus connectors
are available from a variety of sources and in various sizes. As such,
there may be mechanical limitations that prohibit the use of some
connectors. Phoenix Subcon Plus M1 (Part # 2761826) or ERNI
Profibus vertical (Node Part # 103658 and Termination Part # 103659),
are recommended for use with PowerFlex 7-Class drives.]
❑Drive and adapter configuration tool, such as the following:
– PowerFlex 20-HIM-xx HIM
– Connected Components Workbench software, version 1.02 or later
Connected Components Workbench is the recommended
stand-alone software tool for use with PowerFlex drives. You can
obtain a free copy by:
•Internet download at http://www.ab.com/support/abdrives/
webupdate/software.html
•Requesting a DVD at http://www.ab.com/onecontact/controllers/
micro800/
Your local distributor may also have copies of the DVD available.
Connected Components Workbench software cannot be used to
configure SCANport-based drives or Bulletin 160 drives.

1-4 Getting Started
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
– DriveExplorer software, version 2.01 or later
This software tool has been discontinued and is now available as
freeware at http://www.ab.com/support/abdrives/webupdate/
software.html. There are no plans to provide future updates to this
tool and the download is being provided ‘as-is’ for users that lost
their DriveExplorer CD, or need to configure legacy products not
supported by Connected Components Workbench software.
– DriveExecutive software, version 3.01 or later
A Lite version of DriveExecutive software ships with RSLogix
5000, RSNetWorx MD, FactoryTalk AssetCentre, and
ItelliCENTER software. All other versions are purchasable items:
•9303-4DTE01ENE Drive Executive software
•9303-4DTS01ENE DriveTools SP Suite (includes
DriveExecutive and DriveObserver software)
•9303-4DTE2S01ENE DriveExecutive software upgrade to
DriveTools SP Suite (adds DriveObserver software)
DriveExecutive software updates (patches, and so forth) can be
obtained at http://www.ab.com/support/abdrives/webupdate/
software.html. It is highly recommended that you periodically check
for and install the latest update.
❑1203-USB Serial Converter or 1203-SSS Serial Converter with
firmware revision 3.001 or later
❑Profibus configuration software
❑Controller configuration software

Getting Started 1-5
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Safety Precautions Please read the following safety precautions carefully.
!
ATTENTION: Risk of injury or death exists. The PowerFlex
drive can contain high voltages that can cause injury or death.
Remove all power from the PowerFlex drive, and then verify
power has been discharged before installing or removing the
adapter.
!
ATTENTION: Risk of injury or equipment damage exists. Only
personnel familiar with drive and power products and the
associated machinery should plan or implement the installation,
start up, configuration, and subsequent maintenance of the
product using an adapter. Failure to comply can result in injury
and/or equipment damage.
!
ATTENTION: Risk of equipment damage exists. The adapter
contains electrostatic discharge (ESD) sensitive parts that can be
damaged if you do not follow ESD control procedures. Static
control precautions are required when handling the adapter. If
you are unfamiliar with static control procedures, see Guarding
Against Electrostatic Damage, publication 8000-4.5.2.
!
ATTENTION: Risk of injury or equipment damage exists. If the
adapter is transmitting control I/O to the drive, the drive can fault
when you reset the adapter. Determine how your drive responds
before resetting an adapter.
!
ATTENTION: Risk of injury or equipment damage exists.
Parameters 9 - [Comm Flt Action] and 10 - [Idle Flt Action]
let you determine the action of the adapter and connected drive if
I/O communication is disrupted or the controller is idle. By
default, these parameters fault the drive. You can set these
parameters so that the drive continues to run, however, take
precautions to verify that the settings of these parameters do not
create a risk of injury or equipment damage. When
commissioning the drive, verify that your system responds
correctly to various situations (for example, a disconnected cable
or a faulted controller).
!
ATTENTION: Risk of injury or equipment damage exists.
When a system is configured for the first time, there can be
unintended or incorrect machine motion. Disconnect the motor
from the machine or process during initial system testing.
!
ATTENTION: Risk of injury or equipment damage exists. The
examples in this publication are intended solely for purposes of
example. There are many variables and requirements with any
application. Rockwell Automation does not assume responsibility
or liability (to include intellectual property liability) for actual
use of the examples shown in this publication.

1-6 Getting Started
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Quick Start This section is provided to help experienced users quickly start using the
adapter. If you are unsure how to complete a step, refer to the referenced
chapter.
Step Action See
1 Review the safety precautions for the adapter. Throughout This Manual
2 Verify that the PowerFlex drive is properly installed. Drive User Manual
3 Install the adapter.
a. Verify that the PowerFlex drive is not powered.
b. Connect the adapter to the drive with the Internal Interface
cable.
c. Use the captive screws to secure and ground the adapter to
the drive.
d. Connect the adapter to the network with a Profibus cable.
PowerFlex 7-Class DPI
Network Communication
Adapter Installation
Instructions, publication
20COMM-IN004, and
Chapter 2,
Installing the Adapter
4 Apply power to the adapter.
a. Verify that the adapter is installed correctly
The adapter receives power from the drive.
b. Apply power to the drive.
The status indicators should be green. If they flash red, there
is a problem. See Chapter 7, Troubleshooting.
c. Configure and verify key drive parameters.
Chapter 2,
Installing the Adapter
5 Configure the adapter for your application.
Set adapter parameters for the following functions as required
by your application:
•Node address
•I/O configuration
•Fault actions
Chapter 3,
Configuring the Adapter
6 Apply power to the Profibus master and other devices on the
network.
Verify that the master and network are installed properly and
functioning in accordance with Profibus standards.
—
7 Configure the scanner to communicate with the adapter.
Use a network tool for Profibus to configure the master on the
network to recognize the adapter and drive.
Chapter 4,
Configuring the Profibus
Scanner
8 Create a ladder logic program.
Use a controller configuration tool to create a ladder logic
program that enables you to do the following:
•Control the connected drive, via the adapter, by using I/O.
•Monitor or configure the drive using explicit messages.
Chapter 5,
Using the I/O
Chapter 6,
Using Explicit Messaging

PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Chapter 2
Installing the Adapter
This chapter provides instructions for installing the adapter in a PowerFlex
7-Class drive.
Preparing for an Installation Before installing the adapter, verify that you have all required equipment.
See Required Equipment on page 1-3.
Commissioning the Adapter To commission the adapter, you must set a unique node address on the
network. See Setting the Node Address Switches on page 2-2 or Setting the
Node Address on page 3-3 for details.
Important: New settings for some adapter parameters are recognized only
when power is applied to the adapter or it is reset. After you
change parameter settings, cycle power or reset the adapter.
Topic Page
Preparing for an Installation 2-1
Commissioning the Adapter 2-1
Setting the Node Address Switches 2-2
Connecting the Adapter to the Drive 2-3
Connecting the Adapter to the Network 2-6
Node Termination 2-7
Applying Power 2-8
!
ATTENTION: Risk of equipment damage exists. The adapter
contains electrostatic discharge (ESD) sensitive parts that can be
damaged if you do not follow ESD control procedures. Static
control precautions are required when handling the adapter. If you
are unfamiliar with static control procedures, see Guarding
Against Electrostatic Damage, publication 8000-4.5.2.

2-2 Installing the Adapter
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Setting the Node Address
Switches
Set the adapter node address switches (Figure 2.1) by rotating the switches
to the desired value for each digit.
Important: Each node on the Profibus network must have a unique address.
Set the node address before power is applied because the
adapter uses the node address it detects when it first receives
power. To change a node address, you must set the new value
and then remove and reapply power to (or reset) the adapter.
Figure 2.1 Setting Adapter Node Address Switches
The Node Address switch settings can be verified by viewing Parameter 04
- [P-DP Addr Actual] or Diagnostic Device Item numbers 27 and 28
(page 7-4) with any of the following drive configuration tools:
•PowerFlex HIM
•Connected Components Workbench software, version 1.02 or later
•DriveExplorer software, version 2.01 or later
•DriveExecutive software, version 3.01 or later
Setting Description
0…99 The node address used by the adapter if the Node Address switches are enabled.
The default switch setting is 05.
Important: If the Node Address switches are set to ‘00’, the adapter uses the value
stored in Parameter 03 - [P-DP Addr Cfg] for the node address. See Setting the Node
Address on page 3-3.
2
1
0
9
8
3
4
5
6
7
2
1
0
9
8
3
4
5
6
7
S2
(Tens Digit)
S3
(Ones Digit)

Installing the Adapter 2-3
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Connecting the Adapter to
the Drive
1. Remove power from the drive.
2. Use static control precautions.
3. Remove or open the drive cover.
4. Connect the Internal Interface cable to the DPI port on the drive and
then to the DPI connector on the adapter (see Figure 2.2).
5. Secure and ground the adapter to the drive (see Figure 2.3) by doing the
following:
–On a PowerFlex 70 drive, fold the Internal Interface cable behind the
adapter and mount the adapter on the drive using the four captive
screws.
–On a PowerFlex 700, PowerFlex 700H, or PowerFlex 700S drive,
mount the adapter on the drive using the four captive screws.
Important: Tighten all screws to properly ground the adapter.
Recommended torque is 0.9 N•m (8.0 lb•in).
!
ATTENTION: Risk of injury or death exists. The PowerFlex
drive may contain high voltages that can cause injury or death.
Remove power from the drive, and then verify power has been
discharged before installing or removing the adapter.

2-4 Installing the Adapter
PowerFlex 20-COMM-P Profibus Adapter User Manual
Publication 20COMM-UM006B-EN-P
Figure 2.2 DPI Ports and Internal Interface Cables
➋
➌
➍
➊
X1
X2
➍
20-COMM-P Adapter
PowerFlex 700 Frames 0 and 1
PowerFlex 700S Frames 0 and 1
PowerFlex 70 - All Frames
PowerFlex 700 Frames 2 and Larger
PowerFlex 700S Frames 2 through 6
HIM panel opens for
access to the DPI
interface. To open
panel, remove screws
on left side of the HIM
panel and swing open.
PowerFlex 700H Frames 9 and Larger
PowerFlex 700S Frames 9 and Larger
Item Description
➊15.24 cm (6 in.) Internal Interface cable
➋DPI Connector
➌Profibus connector
➍2.54 cm (1 in.) Internal Interface cable
