AllisCom LHR10 User manual

ALLIS COMMUNICATIONS Page 1 of 8 LHR10&LSS10 Specifications Rev. 1.0 08/2018
ALLISCOM
IoT LoRa Sensor/Receiver
Temperature/Humidity/PM2.5/PM10
Model : LHR10 (Receiver) ; LSS10 (Sensor)
Features: - Low Power Consumption
- Highly Reliability
- Good Connectivity
- Long Distance 1~10KM
- Multiple of LoRa Compatibility
- Battery Inside
- Light & Compact Design
- Ease of Installation
-Use with Allis Communications 4G Wireless Router/
Gateway (MG700)

ALLIS COMMUNICATIONS
TOPOLOGY OF
Page 2 of 8 LHR10&LSS10 S
pecifications Rev.
TOPOLOGY OF
HARDWARE
CONNECTION
pecifications Rev.
1.0 08/2018
CONNECTION

ALLIS COMMUNICATIONS Page 3 of 8 LHR10&LSS10 Specifications Rev. 1.0 08/2018
1. Electrical Specifications:
Device
Hardware Specifications
LHR10
LSS10
Controller ATmega328/P
Operating Voltage
USB power In 4.5~5.2V--LHR10
12V cable in -- LSS10
LoRa® Chipset SX1276
LoRa® MCU STM32L151,128 KB flash
Frequency 902 - 928 MHz
Transmitting Power 902-928 MHz @ 20 dBm
Transmitting Distance 1 ~ 10 KM @ 0.81 Kbps
Receiving Sensitivity -132 dBm @ 0.81 Kbps
LSS10
PM2.5/ PM10 Sensor
Operating Principle Laser Scattering
Detection1,2 PM2.5 and PM10
Output unit1,2 PM2.5 in μg/m3 and PM10 in μg/m3
Concentration Range 0 μg/m3 to 1,000 μg/m3
Accuracy (at 25°C±5°C)
0 μg/m3 to 100 μg/m3: ±15 μg/m3
100 μg/m3 to 1000 μg/m3: ±15 %
Operating time 20,000 hrs
Laser Class Laser Class 1: IEC/EN 60825-1: 650 nm
ESD ±4 kV contact, ±8 kV air per IEC 61000-4-2
Fast Transient Burst ±0.5 kV per IEC61000-4-4
Radiated Emissions
40 dB 30 MHz to 230 MHz
47 dB 230 MHz to 1000 MHz
Conducted Emissions 0.15 MHz to 30 MHz in compliance with CISPR 14

ALLIS COMMUNICATIONS Page 4 of 8 LHR10&LSS10 Specifications Rev. 1.0 08/2018
LSS10
Humidity / Temperature Sensor
Chipset HDC1080 (Texas Instruments)
Accuracy Relative Humidity Accuracy ±2% (typical)
Temperature Accuracy ±0.2°C (typical)
Recommended
Operating Conditions
Temperature -40 ~ 125 °C
Humidity -20 ~ 70 °C
Human-body model (HBM), per ANSI/ESDA/JEDEC JS-001:±2000V
Charged-device model (CDM), per JEDEC specification JESD22- V C101:±500V
Operating Temperature -10 ~ 50°C
Storage Temperature - 30 to 65°C
Humidity 5 ~ 95% (Non-condensing)
Power Consumption 0.6 Watt — Normal Operation
3 Watt — Battery Charging
Battery 1000mA @ 4V ( 4Watt)
Work Time @Battery only 8 Hours approx.
2. Mechanical Specifications:
LHR10 (LoRa Receiver)
Item Description
Dimension 59.05(L) × 54.92(W)x 24.88mm(H) (Metal Box with ear)
Connector RJ45, Micro-USB, LoRa Antenna

ALLIS COMMUNICATIONS Page 5 of 8 LHR10&LSS10 Specifications Rev. 1.0 08/2018
LSS10 (LoRa Sensor)
Item Description
Dimension 72.62(L) × 45.7(W)x 41.2mm(H) (Metal Box)
Connector Micro-USB, LoRa Antenna

ALLIS COMMUNICATIONS
3. Installation:
3.1 LED Indication
LHR10
(Receiver)
Device Item
LED
LHR10
1 B
luetooth (BT)
2 LoRa
3 Power
LSS10
1 Power
2 LoRa
3 CHG
4 PM2.5
/PM10
5 T.H.1
6 T.H.2
Page 6 of 8 LHR10&LSS10 S
pecifications Rev.
(Receiver)
LSS10
(Sensor)
LED
Description
luetooth (BT)
BT Module Normal
LoRa Module Normal
Power ON
Power ON
Send Data
Battery Charging
/PM10
PM.2.5
/PM10 Module Normal
Temperature and Humidity
Module Normal
External Temperature and
Humidity
pecifications Rev.
1.0 08/2018
(Sensor)
Description
/PM10 Module Normal
Module Normal
Humidity
Module Normal

ALLIS COMMUNICATIONS
3.2 Physical Connection
Step1.
Plug the LAN cable to
Step2. Press the pair
button
Step3. Press the pair button of LSS10 and
Step4.
LHR10 and LSS10 pairing
Fig.1 LHR10
Cable plug
Fig.3 LHR10 and LSS10
Pair
Page 7 of 8 LHR10&LSS10 S
pecifications Rev.
Plug the LAN cable to
LHR10 (Receiver) Fig. 1 and switch on
LSS10
button
of LHR10 and hold. The LoRa blue
LED
Step3. Press the pair button of LSS10 and
hold until the LHR10
blue LED
LHR10 and LSS10 pairing
succeeded
Cable plug
-in
Fig. 2 LSS10 Switch
Pair
Button pressed Fig.4 LHR10
LoRa Blue
pecifications Rev.
1.0 08/2018
LSS10
(Receiver) Fig. 2
LED
will blink. Fig.3
blue LED
solid on. Fig.4
Fig. 2 LSS10 Switch
On
LoRa Blue
LED Solid On

ALLIS COMMUNICATIONS Page 8 of 8 LHR10&LSS10 Specifications Rev. 1.0 08/2018
4. Demonstration of LoRa Sensor Data on Web View
(Example captured from Alliscom's Grafana Server)
(2) days of big data
(7) days of big data
(30) days of big data
