AlphaGen DCX2000 36VDC Portable Generator
Operation Manual
Effective: June 2014

Safety Notes
Review the drawings and illustrations contained in this manual before proceeding. If there are any questions regarding
the safe installation or operation of the system, contact Alpha Technologies or the nearest Alpha representative. Save this
document for future reference.
To reduce the risk of injury or death and to ensure the continued safe operation of this product, the following symbols have
been placed throughout this manual. Where these symbols appear, use extra care and attention.
The following sections contain important safety information that must be followed during the installation and maintenance
of the equipment and batteries. Read all of the instructions before installing or operating the equipment, and save this
manual for future reference.
There may be multiple warnings associated with the call out. Example:
ATTENTION provides specic regulatory/code requirements that may affect the placement of equipment and /or
installation procedures.
ATTENTION:
NOTICE provides additional information to help complete a specic task or procedure.
NOTICE:
ELECTRICAL HAZARD WARNING provides electrical safety information to PREVENT
INJURY OR DEATH to the technician or user.
WARNING! ELECTRICAL HAZARD
FUMES HAZARD WARNING provides fumes safety information to PREVENT INJURY OR
DEATH to the technician or user.
WARNING! FUMES HAZARD
FIRE HAZARD WARNING provides ammability safety information to PREVENT INJURY OR
DEATH to the technician or user.
WARNING! FIRE HAZARD
This WARNING provides safety information for both Electrical AND Fire Hazards
WARNING! ELECTRICAL & FIRE HAZARD
CAUTION provides safety information intended to PREVENT DAMAGE to material or equipment.
CAUTION!

3041-135-B0-001 Rev. A1 (06/2014)
AlphaGen DCX2000
36VDC Portable Generator
Operation Manual
041-135-B0-001, Rev. A1
Effective Date: June 2014
Copyright 2013
Alpha Technologies, Inc.
Contacting Alpha Technologies: www.alpha.com
or
For general product information and customer service (7 AM to 5 PM, Pacic Time), call
1-800-863-3930
For complete technical support, call
1-800-863-3364
7 AM to 5 PM, Pacic Time or 24/7 emergency support
To report errors in this document, send email to:T[email protected]
member of The Group
TM
Alpha denies responsibility for any damage or injury involving its enclosures, power supplies, generators,
batteries or other hardware, manufactured by Alpha or members of the Alpha Group, when used for an
unintended purpose, installed or operated in an unapproved manner, or improperly maintained.
NOTICE:
Photographs and drawings in this manual are for illustrative purposes only and might not exactly match your
installation.
NOTICE:
Review this manual before proceeding. If there are questions regarding the safe installation or operation of
this product, please contact Alpha Technologies or your nearest Alpha representative.
NOTICE:

4041-135-B0-001 Rev. A1 (06/2014)
Table of Contents
DCX2000 Portable Generator Safety Notes......................................................................................................... 6
1.0 Introduction............................................................................................................................................... 7
1.1 DCX2000 Generator Components ............................................................................................... 7
2.0 Operation.................................................................................................................................................. 9
2.1 Oil Level ........................................................................................................................................ 9
2.2 Fuel Level ................................................................................................................................... 10
2.3 Air Cleaner .................................................................................................................................. 11
2.4 Power System Connections........................................................................................................ 12
2.4.1 Y-Style Connection........................................................................................................... 12
2.4.2 Ring Lug Style Connection .............................................................................................. 13
2.4.3 Alligator Clamp Style Connection..................................................................................... 14
2.5 Start-Up....................................................................................................................................... 15
2.6 Operation at High Altitude ........................................................................................................... 16
2.7 Operation at Extreme Temperatures........................................................................................... 16
2.8 Engine Shutdown........................................................................................................................ 16
2.9 Output, Alarm and Oil LEDs........................................................................................................ 17
3.0 Servicing................................................................................................................................................. 18
3.1 Emission Control System............................................................................................................ 18
3.2 Maintenance Schedule ............................................................................................................... 20
3.3 Changing Oil ............................................................................................................................... 21
3.4 Air Cleaner Service ..................................................................................................................... 22
3.5 Spark Plug Maintenance............................................................................................................. 23
3.6 Spark Arrestor Maintenance ....................................................................................................... 24
4.0 Transport and Storage Instructions ........................................................................................................ 25
4.1 Transporting the Generator......................................................................................................... 25
4.2 Exercising the Generator ............................................................................................................ 25
4.3 Short Term Storage..................................................................................................................... 25
4.4 Long Term Storage ..................................................................................................................... 26
5.0 Troubleshooting ...................................................................................................................................... 27
6.0 Specications.......................................................................................................................................... 28
7.0 Warranty Information .............................................................................................................................. 29
7.1 California Emissions Control Warranty Statement...................................................................... 29
7.2 Emission Control System Warranty ............................................................................................ 30

5041-135-B0-001 Rev. A1 (06/2014)
Figures & Tables
Fig. 1-1, DCX2000 Generator Components ......................................................................................................... 7
Fig. 1-2, Engine Serial Number ............................................................................................................................ 8
Fig. 2-1, Oil Level ................................................................................................................................................. 9
Fig. 2-2, Checking Fuel Level............................................................................................................................. 10
Fig. 2-3, Checking Air Cleaner............................................................................................................................ 11
Fig. 2-4, Y-Style Connection............................................................................................................................... 12
Fig. 2-5, Ring Lug Style Connection................................................................................................................... 13
Fig. 2-6, Alligator Clamp Style Connection ......................................................................................................... 14
Fig. 2-7, Start-Up................................................................................................................................................ 15
Fig. 2-8, Recommended Oil By Temperature ..................................................................................................... 16
Fig. 2-9, Fuel Valve ON/OFF Positions .............................................................................................................. 16
Fig. 2-10, Control Panel...................................................................................................................................... 17
Fig. 3-1, Air Quality Index Label ......................................................................................................................... 19
Fig. 3-2, Changing Oil......................................................................................................................................... 21
Fig. 3-3, Air Cleaner Assembly ........................................................................................................................... 22
Fig. 3-4, Spark Plug Maintenance ...................................................................................................................... 23
Fig. 3-5, Accessing the Spark Arrestor ............................................................................................................... 24
Fig. 4-1, Starter Grip........................................................................................................................................... 26
Fig. 5-1, Replace Spark Plug.............................................................................................................................. 27
Table 2-1, LED States......................................................................................................................................... 17
Table 3-1, Maintenance Schedule ...................................................................................................................... 20

6041-135-B0-001 Rev. A1 (06/2014)
DCX2000 Portable Generator Safety Notes
The manufacturer cannot anticipate every circumstance that may involve a hazard, therefore, these warnings are not
comprehensive.
• Engine exhaust contains carbon monoxide gas, which can be deadly in closed or poorly
ventilated areas.
WARNING! FUMES HAZARD
• Generator must be properly grounded.
• Do not place or operate the generator in standing water, or expose it to a forced spray of
water.
• Ensure cables do not cross hot surfaces or sharp edges. Inspect cables before and after
each use.
WARNING! ELECTRICAL HAZARD
• Never operate the generator near combustible materials.
• Never refuel the generator in the vicinity of open ames of heat sources. Do not smoke near
the generator.
• Do not refuel the generator while engine is running. Allow generator to cool before refueling.
• Fuel spillage cleanup is the responsibility of the operator and should comply with local codes
and regulations.
• For re safety, the generator must be properly connected, maintained, and in compliance
with applicable codes and regulations.
• Drain oil and empty the fuel tank before transporting. Fuel can leak from the ller cap if the
generator is tilted.
WARNING! FIRE HAZARD
• Prior to each use, inspect the generator for leaks and damage. Immediately repair or replace any
damaged parts.
• The generator must be operated on level ground, not to exceed 15° slant.
• Use only vendor-authorized repair parts.
CAUTION!

7041-135-B0-001 Rev. A1 (06/2014)
1.0 Introduction
The Alphagen DCX2000 portable DC generator supplies DC voltage to a power supply battery bus when
commercial AC power is not available. The generator is designed to be temporarily connected to the DC bus
of a standard Alpha 36V uninterruptable power supply (UPS). Upon loss of commercial AC power, the existing
batteries immediately supply the power supply inverters. After some interval of battery discharge, an operator
deploys the portable generator at the site to supply power to the DC bus.
1.1 DCX2000 Generator Components
Fig. 1-1, DCX2000 Generator Components
Spark Plug Access Cover
Gas Cap
Control Panel
Starter Grip
Choke Lever
Exhaust Grill
Maintenance
Panel
Fuel
Valve
Fuel Primer
Spark Arrestor
OUTPUT BREAKER
LCD Display
V: 40.3V I: 00.0A
P:0000W
Oil: OK ALM:
Time: 004H 27M
Ground Stud
DC OUTPUT
OUTPUT
ALARM
OIL
ENGINE
ON
OFF
ON
OFF

8041-135-B0-001 Rev. A1 (06/2014)
1.0 Introduction, continued
1.1 DCX2000 Generator Components, continued
The engine serial number is stamped on the engine block (remove maintenance panel).
Fig. 1-2, Engine Serial Number
11085603
Serial Number

9041-135-B0-001 Rev. A1 (06/2014)
2.1 Oil Level
Power OFF the generator engine and place on a level surface before servicing.
WARNING! ELECTRICAL HAZARD
• Using non-detergent oil or 2-stroke engine oil will shorten service life and void the warranty. Use only
high-detergent, premium quality, 4-stroke engine oil, certied to meet U.S. automobile manufacturer’s
requirements for API Service Classication SG/SF/SJ/SL/SM/SN. Use synthetic SAE 15W-40
viscosity oil unless operating at ambient temperatures below 32°F (0°C). For temperatures below
32°F, use synthetic SAE 0W-40 viscosity oil.
• Change the oil in a new engine within 4-6 hours of operation to clean any contamination or
manufacturing debris.
• Running the engine with low oil can cause serious damage.
• The Low Oil Alarm System will automatically stop the engine before the oil level falls below a safe
limit. To avoid an unexpected shutdown, inspect the oil level regularly.
CAUTION!
Tools Required:
#2 Philips Head Screwdriver
Oil Drain Pipe
Procedure:
1. Remove the maintenance cover.
2. Using the slots in the oil drain pipe, remove the dipstick, wipe with a clean rag and reinsert, screw
down until tight.
3. Remove the dipstick to check the oil level.
4. If the oil level is below the lower level of the dipstick, rell to the top of the upper level marking. Do not
overll.
5. Reinsert the dipstick and screw down until tight.
2.0 Operation
Fig. 2-1, Checking Oil Level
L
L/2
Dipstick
Oil Fill Hole
Minimum
Oil Level
Maximum
Oil Level

10 041-135-B0-001 Rev. A1 (06/2014)
2.0 Operation, continued
2.2 Fuel Level
Gasoline is extremely ammable and can be explosive. Refuel in a well-ventilated area
with the engine OFF. Keep all smoking materials, sparks, and other sources of combustion
away from the generator during refueling.
The area must be free of spilled fuel before starting the engine. Avoid repeated or
prolonged contact with skin or exposure to vapor. KEEP OUT OF REACH OF CHILDREN.
WARNING! FIRE & FUMES HAZARD
Only use regular unleaded gasoline with the DCX2000 Generator. The fuel tank has a capacity of 1.7
gallons (6.5 Liters).
Procedure:
1. If the fuel level is low, rell to the top of the fuel strainer.
2. After refueling, tighten the fuel cap securely.
Do not use an alternate fuel blend that contains more than 10% ethanol. Do not use gasoline
containing methanol. An octane rating of 87 or higher is recommended. Fuel system damage or engine
performance problems resulting from the use of fuels that contain an improper alcohol blend are not
covered under warranty.
CAUTION!
Fig. 2-2, Checking Fuel Level
Fuel Cap

11041-135-B0-001 Rev. A1 (06/2014)
2.0 Operation, continued
2.3 Air Cleaner
Never run the engine without the air cleaner element in place. Rapid engine wear will result from
contaminants entering through the carburetor into the engine.
CAUTION!
Tools Required:
#2 Philips Head Screwdriver
Procedure:
1. Remove the maintenance cover.
2. Remove the three screws from the air cleaner. Remove the cover to check the element. Clean or
replace as necessary (see Section 3.4, Air Cleaner Service for details).
3. Replace the air cleaner element and cover. Tighten the screw.
4. Replace the maintenance cover and tighten the screw.
Fig. 2-3, Checking Air Cleaner
Captive Screw
Maintenance
Cover
Air Cleaner
Cover
Air Cleaner
Element
Air Cleaner
Case

12 041-135-B0-001 Rev. A1 (06/2014)
2.4 Power System Connections
2.4.1 Y-Style Connection
Fig. 2-4, Y-Style Connection
2
1
3
F us e
ALM/
RDY
RST
FLASH = MIN ALM
OUTPUT 1
~
N
OUTPUT 2
SOLID = MAJ ALM
STRG A
STRG B
STRG C
STRG D
TPR
ENV
Rx/Tx PWR
E
T
H
A
/
B
C
/
D
C
O
M
REG
DS
ACT
LNK
BLUE = WARN
RED = OUT
GRN = OK
ON
OFF
O
I
i
~
N
OUTPUT
ALARM
TEST
BATTERY
TEMP
LRI
BATTERY
INPUT
BATTERY
BREAKER
Y-Style
Battery Pack
Adapter Cable
P/N 874-946-22
Generator Output Cable
50' P/N 876-011-21
30' P/N 876-011-20
2.0 Operation, continued

13041-135-B0-001 Rev. A1 (06/2014)
Fig. 2-5, Ring Lug Style Connection
2.4 Power System Connections, continued
2.4.2 Ring Lug Style Connection
2.0 Operation, continued
2
1
3
F us e
ALM/
RDY
RST
FLASH = MIN ALM
OUTPUT 1
~
N
OUTPUT 2
SOLID = MAJ ALM
STRG A
STRG B
STRG C
STRG D
TPR
ENV
Rx/Tx PWR
E
T
H
A
/
B
C
/
D
C
O
M
REG
DS
ACT
LNK
BLUE = WARN
RED = OUT
GRN = OK
ON
OFF
O
I
i
~
N
OUTPUT
ALARM
TEST
BATTERY
TEMP
LRI
BATTERY
INPUT
BATTERY
BREAKER
Ring Lug Style
Battery Pack Adapter Cable
P/N 874-946-21
Cable lugs connect directly
to the battery terminals
Generator Output Cable
50' P/N 876-011-21
30' P/N 876-011-20

14 041-135-B0-001 Rev. A1 (06/2014)
2.4 Power System Connections, continued
2.4.3 Alligator Clamp Style Connection
2.0 Operation, continued
RED
BLACK
2
1
3
F us e
Fig. 2-6, Alligator Clamp Style Connection
Alligator Clamp Style
Battery Pack Adapter Cable
P/N 874-946-20
Ensure clamps lay at against
batteries, facing inward
ALM/
RDY
RST
FLASH = MIN ALM
OUTPUT 1
~
N
OUTPUT 2
SOLID = MAJ ALM
STRG A
STRG B
STRG C
STRG D
TPR
ENV
Rx/Tx PWR
E
T
H
A
/
B
C
/
D
C
O
M
REG
DS
ACT
LNK
BLUE = WARN
RED = OUT
GRN = OK
ON
OFF
O
I
i
~
N
OUTPUT
ALARM
TEST
BATTERY
TEMP
LRI
BATTERY
INPUT
BATTERY
BREAKER
Generator Output Cable
50' P/N 876-011-21
30' P/N 876-011-20

15041-135-B0-001 Rev. A1 (06/2014)
2.5 Start-Up
Before starting the engine, verify the output circuit breaker is in the OFF position.
Procedure:
1. Connect output cable to the generator’s DC output connection and the power supply.
2. Turn the fuel valve to the ON position. If the fuel tank was just lled, pump the fuel primer bulb 7 times
to get fuel to the carburetor.
3. Turn the engine switch ON.
4. Move the choke lever to the START position.
5. Pull the starter grip lightly until resistance is felt, then pull briskly out.
6. Move the choke lever to the RUN position after the engine warms up.
7. Turn the output circuit breaker ON.
8. Verify an output voltage of 39.5V on the display.
Slowly return starter grip to position; do not allow it to snap back. Do not allow the rope to rub against
generator body while retracting.
CAUTION!
Substantial overloading that continuously lights the overload LED (red) may damage the generator.
Marginal overloading that temporarily lights the overload LED (red) may shorten the service life of the
generator.
CAUTION!
2.0 Operation, continued
Fig. 2-7, Start-Up
Fuel Primer
Choke Lever
DCX
2000
36V DC GENERATOR
ALPHA
START RUN

16 041-135-B0-001 Rev. A1 (06/2014)
2.0 Operation, continued
2.6 Operation at High Altitude
The standard carburetor air-fuel mixture will be excessively rich at high altitudes. This will decrease
performance and increase fuel consumption.
High altitude performance can be improved by installing a smaller diameter main fuel jet in the carburetor.
If you always operate the generator at altitudes higher than 5000 feet (1500 m) above sea level, have an
authorized Alpha Service Center install a high altitude main jet.
Even with suitable carburetor jetting, engine horsepower will decrease approximately 3.5% for each 1000
feet (305 m) increase in altitude. The affect of altitude on the horsepower will be greater than this if no
carburetor modication is made.
Have any carburetor modications reversed before operating at lower altitudes. Operation of the
generator at an altitude lower than the carburetor is jetted for may result in reduced performance,
overheating, and serious engine damage caused by an excessively lean air/fuel mixture.
CAUTION!
2.7 Operation at Extreme Temperatures
High temperatures adversely affect generator operation.
Generator performance will decrease 1% for each 10°F
(5.5°C) increase in temperature above 85°F (29°C). The
normal operating range of this generator is 5° to 104°F (-15°
to 40°C). Although the generator can operate at 5°F (-15°C)
it will be necessary to use a lower viscosity engine oil such
as SAE 0W-40. Even with 0W-40 oil, the engine will be
more difcult to start.
When operating the generator below 5°F (-15°C), the unit may be difcult to start. In temperatures above
104°F (40°C), the output power will be derated.
CAUTION!
2.8 Engine Shutdown
To stop the engine in an emergency, push the engine switch on the control panel to the OFF position.
In an emergency, push the engine switch to the off position. This will stop the engine with or without a load.
However, repeatedly stopping the generator without disconnecting all loads may damage the generator or power
supply.
CAUTION!
Normal Shutdown Procedure:
1. Turn the Output Breaker OFF.
2. Disconnect load.
3. Push the engine switch to the OFF position.
4. Turn the fuel valve to the OFF position.
Recommended Oil
SAE 0W-40 SAE 15W-40
0° F 32° F 113° F
(-18° C) (0° C) (45° C)
Fig. 2-8, Recommended Oil By Temperature
Fig. 2-9, Fuel Valve ON/OFF Positions

17041-135-B0-001 Rev. A1 (06/2014)
2.0 Operation, continued
2.9 Output, Alarm and Oil LEDs
Before connecting or reconnecting a power supply to the generator, check that it is in good condition and that its
electrical rating does not exceed that of the generator.
CAUTION!
Use Fig. 2-10 and Table 2-1 to understand the different LED states of the generator.
Fig. 2-10, Control Panel
(data values shown for illustration purposes only)
OUTPUT BREAKER
LCD Display
V: 40.3V I: 00.0A
P:0000W
Oil: OK ALM:
Time: 004H 27M
Ground Stud
DC OUTPUT
OUTPUT
ALARM
OIL
ENGINE
ON
OFF
State LED State LCD Display Text Output State Corrective Action
Normal Operation
V = Voltage (V)
I = Current (A)
P = Power (W)
Oil = “_OK”
ALM = no display
Time = Hour; Min
Engine Running
Output ON
Overload ALM = “OL” Engine Running
Disconnect the power supply
and investigate the cause of the
overload; manual reset* (the
output LED turns green)
Module Overheat ALM = “OH” Engine Running Manual reset*
Critical Low Oil
Shutdown
Oil = “LO_” Engine OFF
Output OFF Replenish oil; manual reset
Overspeed
Shutdown N/A Engine OFF Output OFF
Generator needs servicing;
Contact Alpha for service
information.
Table 2-1, LED States
OUTPUT
ALARM
OIL
OIL
ALARM
ALARM
(ashes during
overload)
*To manually reset the generator, stop the engine and disconnect all electrical connections. Follow instructions in Section 2.5 for startup.

18 041-135-B0-001 Rev. A1 (06/2014)
3.0 Servicing
The maintenance schedule (Section 3.2, Maintenance Schedule) maintains the generator in peak operating
condition. The oil should be changed between the rst 4 to 6 hours of operation to remove any manufacturing
debris or contamination.
The exhaust contains poisonous carbon monoxide gas. Shut off the engine before performing
any maintenance. If you must run the engine, make sure the area is well ventilated.
WARNING! FUMES HAZARD
Use genuine Alpha parts. The use of replacement parts not of equivalent quality may damage the generator.
When repairing or replacing components of the emission control system, only use parts known to comply with EPA
standards.
CAUTION!
3.1 Emission Control System
Emission Source
Exhaust gas contains carbon monoxide, nitrogen oxides (NOx), and hydrocarbons. Controlling the
emissions of NOx and hydrocarbons is very important, as they are a major contributor to air pollution.
Carbon monoxide is a poisonous gas. The emission of fuel vapors is also a source of pollution. The Alpha
generator engine utilizes a precise air-fuel ratio and emission control system to reduce the emissions of
carbon monoxide, NOx, hydrocarbons, and evaporative fuel emissions.
Regulation
This engine has been designed to meet current Environmental Protection Agency (EPA) and the California
Air Resources Board (CARB) clean air standards. The regulations dictate that the manufacturer provides
operation and maintenance standards regarding the emission control system. Tune up specications
are provided in Section 6.0, Specications. Adherence to the following instructions will help ensure the
engine meets the emission control standards.
Modication
Modication of the emission control system may lead to increased emissions and will void the warranty
statement. Modication is dened as the following:
• Disassembling or modifying the function or parts of the intake, fuel, or exhaust system.
• Modifying or destroying the speed governing function of the generator.
Engine Faults
Any of the following faults must be repaired immediately. Consult with Alpha technical support for diagnosis
and repair. The following engine faults may affect emission:
• Hard starting or shut down after starting.
• Unstable idle speed.
• Shut down or backre after applying an electrical load.
• Backre.
• Black smoke and/or excessive fuel consumption.

19041-135-B0-001 Rev. A1 (06/2014)
3.0 Servicing, continued
3.1 Emission Control System, continued
Replacement Parts and Accessories
The parts making up the emission control system have been specically approved and certied by
the regulatory agencies. Replacement parts supplied by Alpha have been manufactured to the same
production standard as the original parts. The use of replacement parts or accessories which are not
designed by Alpha may affect the engine emission performance. The manufacturers of replacement parts
and accessories have the responsibility to guarantee that their replacement products will not adversely
affect emission performance.
Maintenance
Maintain the generator according to the maintenance schedule in Section 4.2, Maintenance Schedule.
Service items more frequently when used in dusty areas, or under conditions of high load, temperature,
and humidity.
Air Quality Index
CARB requires that an air quality index label be attached to every certied engine showing the engine
emission information for the emission duration period. The label is provided for the user to compare
the emission performance of different engines. The lower the air index, the better the engine emission
performance. The description of durability is helpful for the user to learn the engine emission duration
period and the service life of emission control system. Refer to the warranty section of this Owner’s Manual
for more information.
The air quality index label is designed to be permanently afxed to the generator and removal should not
be attempted.
The generator has an engine that has been approved by the California Air Resources Board. Other than
the tune up procedures specied in the maintenance section, no additional maintenance is required.
The emission control system has the following components:
1. Fuel System: The fuel tank, cap, indicator and hoses are specially designed and constructed to not
allow fuel vapors to permeate and be released to the atmosphere.
2. A carbon activated canister collects gasoline vapors from the fuel tank and returns them to the
combustion chamber for burning.
3. A catalyst is built into the mufer to further treat the engine exhaust.
4. A secondary air injection valve adds combustion air to ignite unburned fuel in the exhaust.
Contact Alpha to obtain the correct replacement parts and service on this system.
Fig. 3-1, Air Quality Index Label
EMISSION CONTROL INFORMATION
YONGKANG XINGGUANG ELECTRICAL MANUFACTURE CO., LTD.
THIS ENGINE IS CERTIFIED TO OPERATE ON UNEADED GASOLINE. THIS ENGINE MEETS U.S.
EPA CALIFORNIA AND EVP EMISSION. REGULATIONS FOR SMALL OFF-ROAD ENGINES
FOR 2012 MODEL YEAR. ENGINE FAMILY: CYKXS.1251XG DISPLACEMENT: 125 CC EVAP
ECS CM CARB EVAP FAMILY: CM EPA EVAP FAMILY: CXKXPNHEQOO1 LUBRICANT
REQUIREMENTS: SF15W-40 EXH ECS: TWC+PAIR EMISSIONS COMPLIANCE PERIOD: 125 HOURS
THE AIR INDEX OF THIS ENGINE IS 3
MOST CLEAN LEAST CLEAN
0246810
DATE OF MANUFACTURE:
2012 01 02 03 04 05 06 07 08 09 10 11 12

20 041-135-B0-001 Rev. A1 (06/2014)
3.2 Maintenance Schedule
Item Maintenance
Procedure
Regular Service period. Perform at every indicated month or operating hour
interval, whichever occurs rst.*
Each Use
1st Month
or
4 to 6 Hours
Every 3 Months
or
50 Hours
Every 6 Months
or
100 Hours
Once per Year
or
300 Hours
Engine Oil Check x
Change x x
Air Cleaner Check x
Clean x**
Spark Plug Clean / Adjust x
Spark Arrester Clean x
Fuel Filter Check x
Replace x**
Valve Clearance Check / Adjust x***
Fuel Tank
and Strainer Clean x**
Fuel Line Check Every 2 years (Replace as necessary)***
*Log hours of operation to determine proper maintenance.
**Service more frequently when used in dusty areas.
***These items should be serviced by an authorized dealer or qualied personnel.
Service Period for Oil Changes Temperature
Normal - 100 hr 77°F (25°C)
95 hr 86°F (30°C)
85 hr 95°F (35°C)
70 hr 104°F (40°C)
Table 3-1, Maintenance Schedule
3.0 Servicing, continued
