ALPHA WORKS GUR052 User manual

ALPHAWORKS
SMART CORD REEL
OPERATOR' MANUAL

1
TECHNICAL DETAILS
SAFETY PRECAUTIONS
Read carefully and understand all INSTRUCTIONS
before operating. Failure to follow the safety rules
and other basic safety precautions may result in
serious personal injury.
Save these instructions in a safe place and on hand
so that they can be read when required. Keep these
instructions to assist in future servicing.
The warnings, cautions, and instructions discussed
in this instruction manual cannot cover all possible
conditions or situations that could occur. It must be
understood by the operator that common sense
and caution are factors which cannot be built into
this product, but must be supplied by the operator.
CORD REEL SAFETY PRECAUTIONS
1. Ensure that only the qualified electrician can installs/services this cord reel. And it must not
be used by children or unskilled persons.
2. Ensure that power supply voltage does not exceed maximum voltage rating of reel.
3. Ensure that reel is properly be installed before connecting to power supply.
4. Ensure that all electrical power is removed from reel before servicing.
5. Check for frayed and broken wires before each use.
6. When pull electrical cord from the reel always grasp the electrical cord itself, not the work
device.
7. Remove power from the reel immediately when any malfunction occurs.
8. Never remove, tamper with or cut the safety devices fitted by the manufacture.
9. Do not use the reel in damp or wet conditions. Keep the work area is clean.
12.866
7.80 4-0.413
14.637
14.464
10.22
14.173 14.42
8.78
Item No.
GUR052 65 125 15
Length (ft)AWG Volt (V) Ampere (A)
12

2
INSTALLATION
1. Unpack and inspect reel for damage. Check for completeness.
2. The cord reel must be installed in premises comforming to current regulation and standards
covering systems and work environments.
3. Secure the cord reel to the wall and the ceiling according to the installation diagrams.Using
screw anchors or suitable screws which must be fitted in the holes in the brackets.
4. The appliance can also be used on the ground. The cord reels can be placed in place as
needed.
OPERATION
1. Check reel for correct operation by slowly pulling out the cord.
2. To latch the reel, slowly pull out the cord to any point, release the cord to stop.
Note：It can not exceed the back end mark when the cord is pulled out.
In the ceiling on the wall
on the ground

3
CHECKLIST BEFORE USING THE DEVICE
1. In order to power up the sockets, first click each button, and check whether the indicator
lights are working.
2. Your smart phone or tablet should have connected a 2.4G WIFI with internet.
3. The device only supports 2.4G network. Please don’t connect to a 5G network or hybrid
network.
4. Enter correct WIFI passwords. Make sure that your WIFI SSID and passwords don’t contain
special characters.
5. During pairing process, make sure that your IOS or Android device and smart socket within
the range of the router.
6. Please pay attention to the maximum power that this socket.
Retract the cord
1. Principal control: Press button 2 on the body and the cord can retracts. (pictured below).
2. Socket control:
2.1 Press both RF buttons, the cord can retract .（If the cord can't retract, need to reconnect
RF. Press the main body buttons 1 and 2 simultaneously until they flash. Press any button
at the socket end, the body light is always on to indicate a successful connection. (pictured
below)
2.2 Press any of the 3 socket buttons to control the current flow of each socket.
2
1
RF Button
Socket
Button 1 Socket
Button 2
Socket
Button 3
The indicator lights are green
while working, and the RF
indicator will flash.

4
APP CONTROL
Download Smart Life App
You can scan the QR code below to download the Smart Life App:
You can also search “Smart Life” in either App Store or Google Play to install the app.
REGISTER
If you don’t have an App account, please register an account first.
1. Tap to enter registration page, select your country code. Enter the mobile number and tap
“Obtain verification code”.
2. Then enter the verification code from the message, and enter the password, tap “Confirm” to
finish your registration.
ADD DEVICE
1. Enter the App, tap “Add Device” or “+”, then select Electrical. Engineering “Socket”.
2. Please press the WIFI button on the body for over 2 seconds and make sure the WIFI
indicator flashes quickly.

5
3. Tap to go on to network connecting. Select the Wi-Fi under which device is working, enter
password and tap “ok” to enter network connection process.
4. After connecting, you could name the device you want, then the smart device will be shown
on the home page. Rename what you want by click the icon.
5. Control retract the cord
Click on the control page, click on the retract button
motor work, cord will automatically retract, cord
retract after the motor automatically stop working,
if the cord retraction process to stop, gently pull
the wire with your hand, the motor will stop
working.
Retract Button
Working
Socket On/Off
Timing & Countdown

6
6. Control device
1. Tap to enter it’s control page, click on the button for
ON / OFF operations. Each socket can be
independently controlled and customized through
the app. And individually control each socket using
sepatate buttons. Rename what you want by click
the icon.
2. In the control page you could click on the Timing &
Countdown etc., for regularly operations.
HOW TO WORK WITH ALEXA AND GOOGLE HOME
Click and go to the “Me” page. Get the corresponding detailed operation instructions in “More
Services”.
Retract Button
Socket On/Off
Stopped
Timing & Countdown

How to connect Alexa? Clink the link.
You could get more related operations and the help of
common problems on the APP’s “Me” page. You could
also contact the seller to get a better product use
experience!
MAINTENANCE
1. Make sure the Cord is in proper working order.
2. Clean the Cord with a cloth dipped in warm water
to remove dirt or deposits and ensure correct
rewinding.
3. Do not use detergents or solvents which could
prove incompatible with cord-winder materials.
4. Dismantling of the unit by unskilled personal
could prove hazardous;the risk involved
mainly concerm the preloaded springs.
LIMITED WARRANTY
1. The manufacturer warrantees this Cord reel against defects in material and craftsmanship,-
for a period of 12 months from date of purchase.
2. Manufacturer’s liability is limited to replacement or repair of defective material within the
warranty period,when returned freight prepaid to the distributor or their designated service
depot.
3. The warranty dose not cover damage caused by accident, misuse or faulty installation.
4. The reel must be installed and maintained in compliance with the instructions.
Your risk from these exposures varies, depending on how often you do this type of work. To
reduce your exposure to these chemicals: work in a well ventilated area, and work with
approved safety equipment, such as those dust masks that are specially designed to filter out
microscopic particles.
Great Circle USA
Support Line: 1-866-493-0524
[email protected]
www.greatcircleus.com
