Alpha ARES Pro 150 User guide

Floor standing, high water content
condensing boilers
Installation and Servicing
Instructions
Leave these instructions with the
Building Manager
ARES Pro 150
ARES Pro 230
ARES Pro 300
ARES Pro 348
ARES Pro 400
ARES Pro 500
ARES Pro 600

Attention: this manual contains instructions for the exclusive use of the professionally
qualified installer and/or maintenance technician in compliance with current legislation.
The user is NOT qualified to intervene on the boiler.
The manufacturer will not be held liable in case of damage to persons, animals or objects
re-sulting from failure to comply with the instructions contained in the manuals supplied
with the boiler.
INDEX
1 General Informations..........................................................4
1.1 Symbols used in the manual........................................................4
1.2 Compliant use of the appliance...................................................4
1.3 Information to be provided to the user .....................................4
1.4 Safety warnings .............................................................................5
1.5 Regulations for installation..........................................................6
1.6 Installation.....................................................................................6
1.7 Water treatment ............................................................................7
1.8 General warnings..........................................................................8
2 Technical characteristics and dimensions.................................9
2.1 View of main parts........................................................................9
2.2 Dimensions..................................................................................10
2.2.1 Dimensions to insert in the boiler room .................................11
2.2.2 View of internal access...............................................................12
2.3 Water side pressure drops diagram ..........................................13
2.3.1 Primary circuit pump determination.......................................13
2.4 Operating data / general characteristics ..................................14
2.5 Technical parameters for combination boilers (in
compliance with Regulation 813/2013) ...................................15
3 Instructions for installatione ............................................19
3.1 General warnings........................................................................19
3.2 Packaging.....................................................................................20
3.2.1 Handling ......................................................................................20
3.3 Positioning the heating control unit.........................................21
3.4 Flue exhaust manifold connection ...........................................22
3.5 Connection..................................................................................23
3.6 Filling and emptying the system...............................................25
3.7 Electrical connections ................................................................25
3.8 First ignition................................................................................30
3.9 Measurement of combustion eciency during installation..31
3.9.1 Activation of the calibration function......................................31
3.9.2 Probes positioning......................................................................32
3.10 Checking burner pressure adjustment.....................................32
4 Inspections and maintenance............................................ 37
4.1 Inspection and maintenance instructions ...............................37
4.3 Adaptation to the use of other gas............................................40
4.4 Programming operating parameters........................................41
4.5 Practical connection diagram ...................................................44
4.6 Release and reset error codes ....................................................46
The company Alpha Heating Innovation (registered office - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS) declares
that the design, manufacturing and after-sales assistance processes comply with the requirements of standard UNI EN ISO 9001:2008.
For further details on the product CE marking, request a copy of the Declaration of Conformity from the manufacturer, specifying the appliance
model and the language of the country.

General information
4
1.2 COMPLIANT USE OF THE APPLIANCE
e ARES PRO appliance was built based on the current technical level and recognised technical safety rules.
Nevertheless, following improper use the safety and life of the user or other people may be exposed to danger, i.e. damage
to the appliance or other objects.
e appliance is designed for operation in hot water circulating heating systems.
Any other use is considered improper.
Alpha Heating Innovation will not be held liable for any damage resulting from improper use.
Any use in accordance with the envisioned purposes includes the strict observance of the instructions in this manual.
1.3 INFORMATION TO BE PROVIDED TO THE USER
e user must be instructed in the use and operation of his/her heating system, in particular:
- Deliver these instructions to the user, as well as the other documents relative to the appliance contained in the packaging in
an envelope. e user must keep this documentation safe so that it is available for future consultation.
- Inform the user of the importance of aeration vents and the ue exhaust system, highlighting how essential they are and how
it is strictly forbidden to change them.
- Inform the user on how to control the water pressure in the system as well as the operations required to restore it.
- Inform the user on how to correctly regulate the temperature, control units/thermostats and radiators in order to save energy.
- Remember it is compulsory to carry out regular maintenance on the system once a year and a combustion analysis every two
years (as per national legislation).
- If the appliance is sold or transferred to another owner or if the owner moves, leaving the appliance behind, always ensure the
manual accompanies the appliance so that it may be consulted by the new owner and/or installer.
e manufacturer will not be held liable in the case of damage to people, animals or property due to the failure to observe the instructions
contained in this manual.
1GENERAL INFORMATION
1.1 SIMBOLS USED IN THE MANUAL
When reading this manual, pay special attention to the parts marked with these symbols:
DANGER!
Serious danger to
safety and life
ATTENTION!
Possible dangerous
situation for the product
and the environment
NOTE!
Tips
for the user
DANGER!
Danger of burns!
OBLIGATION!
wear gloves
protective

General information
5
1.4 SAFETY WARNINGS
ATTENTION!
e appliance must not be used by people with reduced physical, mental and sensorial capabilities, without experience and
knowledge. ese people must be duly instructed and supervised during manoeuvring operations.
ATTENTION!
Installation, adjustment and maintenance of the appliance must be carried out by professionally authorised company, in
compliance with regulations and provisions in force, as incorrect installation can cause damage to people, animals and
property, for which the manufacturer will not be held liable.
DANGER!
Maintenance or repair work on the boiler must be carried out by professionally authorised company; it is advisable to
sign a maintenance contract.
Poor or irregular maintenance can compromise the operational safety of the appliance and cause damage to people, animals
and property for which the manufacturer will not be held liable.
Changes to parts connected to the appliance
Do not make changes to the following elements:
- to the boiler
- to the gas, air, water and power supply lines
- to the ue pipe, safety valve and exhaust pipe
- to the constructive elements that aect the operational safety of the appliance.
ATTENTION!
To tighten or loosen the screw-attached ttings, use suitable wrenches only.
Improper use and/or unsuitable tools can cause damage (for ex. water and gas leaks).
ATTENTION!
Instructions for appliances running on propane gas
Make sure that the gas tank has been deaerated prior to installing the appliance.
For a thorough deaeration of the tank contact the liquid gas supplier and in any case professionally authorised company, in
accordance with the law.
Ignition problems can arise if the tank is not thoroughly deaerated.
In this case contact the liquid gas tank supplier.
Smell of gas
In case of the smell of gas observe the following safety instructions:
- do not use electric switches
- do not smoke
- do not use the telephone
- shut o the gas cut-o valve
- aerate the room where the gas leak occurred
- notify the gas supply company or a company specialised in the installation and maintenance of heating systems.
Explosive and easily ammable substances
Do not use or deposit explosive or easily ammable materials (for ex. petrol, paints, paper) in the room where the appliance is
installed.
ATTENTION!
e heating unit must be installed so as to avoid, under the envisioned operating conditions, the liquid contained in it from
freezing and avoid exposing the command and control parts to temperatures below -15°C and over +40°C.
e heating unit must be protected from climatic/environmental variations by:
- insulating the hydraulic and condensation exhaust pipes
- adopting specic anti-freeze products in the hydraulic system.

General information
6
1.5 REGULATIONS FOR INSTALLATION
e appliance must be installed in accordance with the instructions
contained in this manual.
Installation must be carried out by a professionally authorised company,
who is in charge of enforcing observance of all local and/or national
laws published in the Ocial Gazette, as well as all applicable
technical regulations.
It is necessary to observe the standards, regulations and requirements
for installation provided below, constituting a rough and non-exhaustive
list, in order to follow the evolution of the "state of the art". We
would like to underline that updating the list of standards is the
responsibility of the technicians authorised to carry out installation.
Also observe the standards regarding the heating control unit,
construction regulations and requirements on combustion heating in
the country of installation.
e appliance must be installed, commissioned and subject to
maintenance in accordance with the current "state of the art". is also
applies to the hydraulic system, the ue exhaust system, the installation
room and the electrical system.
Failure to observe the above regulations will void
the warranty.
Attention!
If the new boiler is installed in an old system
without having flushed the system, as indicated in the
previous paragraph, any residues present in the
circuit could accumulate in the generator,
generating clogging.
Otherwise, if ARES Pro is being installed on a new system:
it is advisable to wash it thoroughly in any case, using products that are
suitable for the entire system, and install a Y-strainer with two cut-o
valves on the return pipe to the boiler, so that it can be cleaned as needed.
is lter will protect the boiler from sediments coming from the
heating system.
In both cases it is necessary to keep the head losses localised in the
primary circuit, for the correct sizing of the pump.
1.6 INSTALLATION
When the appliance is installed on existing systems, make sure that:
- e ue is suitable for condensation appliances, for the temperatures
of the combustion products, calculated and built in accordance with
regulations in force. at is it a straight as possible, water-tight and
insulated and does not have any obstructions or constrictions.
- e ue is equipped with an attachment to evacuate the condensation.
- e heating control unit is equipped with a pipe for the evacuation
of the condensation produced by the boiler.
- e electrical system is built in accordance with specic regulations
and by professionally authorised company.
- e ow rate, head and direction of ow of the circulation pumps is
appropriate.
- e fuel feed line and any existing tanks are set up in accordance with
regulations in force.
- e expansion vessels ensure complete absorption of the dilation of
the uid contained in the system.
- Slurry and build-up have been cleaned out of the system.
Important!
e National Standard prescribes water treatment
in case of new installation or renovation of heating
systems and replacement of heat generators.
If ARES Pro is being installed on existing Systems:
If it is possible to schedule the replacement, it is necessary to wash
the system preventively, with alkaline dispersants. Washing must be
carried out four weeks prior to replacement, with a system operating
between 35°C - 40°C. e installation of a lter is always recommended
and, above 350 kW, it is necessary (ref. National Standard).

General information
7
1.7 WATER TREATMENT
Feed water treatment prevents problems and main-
tains the functionality and eciency of the generator
over time.
the ideal pH value of water in heating systems must
be included:
VALUE MIN MAX
PH 6,5 8
HARDNESS (°fr) 9 15
To minimise corrosion, it is crucial to use a corrosion
inhibitor; in order for it to work properly, the metal
surfaces must be clean.
ATTENTION!
Any damage to the boiler caused by the formation
of fouling or by corrosive water will not be covered
by the warranty.
ATTENTION!
e heating only models are NOT suitable for the pro-
duction of water for human consumption according
to Ministerial Decree D.M. 174/2004.

General information
8
1.8 GENERAL WARNINGS
e instruction book is an integral and essential part of the product and
must be kept safe by the individual in charge of the system.
Read the warnings contained in the manual carefully, as they provide
important instructions regarding installation, user and maintenance
safety.
Keep the manual safe for future consultation.
e appliance must be installed and maintained in accordance
with regulations in force, pursuant to the instructions of the
manufacturer, the state of the art and by an authorised company, in
accordance with the law.
Professionally authorised company means company with specic
technical skills in the sector of heating system parts for civil use, hot
water production for domestic use and maintenance. is company
must have the authorisations required by legislation in force.
Incorrect installation or poor maintenance can cause injury to persons
and animals and damage to objects, for which the manufacturer is
not liable.
Before carrying out any cleaning or maintenance operations, cut the
appliance o from the power mains by acting on the switch on the
system and/or using the cut-o devices.
Do not obstruct the intake/exhaust pipe terminals.
In case of breakdown and/or poor operation of the appliance, switch it
o, and do not attempt in any way to repair it or intervene directly. Only
contact companies that has been authorised in accordance with the law.
Any repairs to the products must be carried out by authorised company
only, using original spare parts only. Failure to observe the above can
jeopardise the safety of the appliance and will void the warranty.
e guarantee the eciency of the appliance and its correct operation
it is essential for authorised company to carry out annual maintenance.
If the appliance is put out of use for downtime, any part that is
susceptible to posing a potential source of danger must be made safe.
Before re-commissioning an appliance that has been put out of use,
proceed to washing the domestic hot water production system, making
water ow through it for the amount of time required to change the
water completely.
If the appliance is sold or transferred to another owner or if the
owner moves, leaving the appliance behind, always ensure the manual
accompanies the appliance so that it may be consulted by the new
owner and/or installer.
All appliances with optionals or kits (including electric) must only use
original spare parts.
e appliance must only be employed for its expressly foreseen use.
Any other use must be considered improper and therefore dangerous.

Technical characteristics and dimensions
9
2TECHNICAL CHARACTE
RISTICS AND DIMEN
SIONS
2.1 VIEW OF MAIN PARTS
S
R
G
*53 18
54
27
60
56
57
14
58
32
S.cond
59
3
19
61
62
28
10-1
1
63
64
M
55
5
33
S.cond
59
S
32
58
14
57
56
R
27
M
18
60
19
3
61
62
G
28
10-11
53
63
64 54
55
5
33
Key:
N° S.E. Description
3VG Gas valve
5 Burner
10 TL Limit ermostat Probe
11 SR Flow sensore
14 Boiler drain valve
18 VM Fan
19 PF Flue gas pressure switch
27 E. RIL. Detection electrode
28 E. ACC. Ignition electrode
32 Inlet ue inspection
33 Panel board
53 PGmin
PGmax
Gas pressure switch (min. *ARES PRO 150)
(min. ARES PRO 230 - 300)
(min. / max ARES PRO 348 ÷ 600)
54 Visual inspection glass
55 Door insulation
56 Stainless steel vertical smoke pipes with internal
aluminium
57 Technical water tank
58 SL Level sensor
59 Condensate collection pan
60 Combustion chamber
61 Air/gas mixer
62 T.ACC Igniters
63 PFmin Min. smoke pressure switch
64 Connection for air vent.
G Gas inlet
M Heating system ow
R Heating system return
Scond Condensate drain DN 32
S.E. = WIRING DIAGRAM KEY
ARES PRO 150 ARES PRO 230 - 300 - 400 - 500 - 600

Technical characteristics and dimensions
10
H1
H
H3
H2
L1
L4
L2
A
G
M
S
Sm
H4
H5
H6
H7
R
L3
L5
2.2 DIMENSIONS
SIDE VIEW SIDE VIEWFRONT VIEW
REAR VIEW TOP VIEW
ARES
PRO
DIMENSIONS [mm]
Depth Width Height
P P1 P2 L L1 L2 L3 L4 L5 H H1 H2 H3 H4 H5 H6 H7
150 944 788 156 666 120 81 228,5 228,5 457 1809 65,6 1467 323,5 770 554,5 1579 1679
230 1092 954 141 846 120 43 277 277 554 1917 65,6 1557 356 800 604,5 1697 1768
300 1181 1036 144 910 100 200 297 297 594 1946 65,6 1618 353 825 600,5 1741 1796
348 1276 1152 124 996 100 200 338 338 676 2130 65,6 1712 390 853 664 1794 1974
400 1276 1152 124 996 100 200 338 338 676 2130 65,6 1712 390 853 664 1794 1974
500 1276 1152 124 996 100 200 338 338 676 2130 65,6 1712 390 853 664 1794 1974
600 1398 1256 142 1096 200 220 386 386 772 2206 65,6 1753 390 900 673 1863 2052
NOTE:
For the dimensions of the
connections, see the dedicated
chapter

Technical characteristics and dimensions
11
2.2.1 DIMENSIONS TO INSERT THE BOILER IN THE
BOILER ROOM
FRONT VIEW SIDE VIEW
P(P1+P2)
L
Lc
Lp
< 150
Example of Corridor Width (Lc) calculation required to handle the
boiler SPK 150:
L = Boiler Width
P = Boiler Depth
Lc = Corridor Width
Lp = Door Width
666
Lc = 900 x 944 = > 698 mm
ARES
PRO
BOILER DIMENSIONS WITHOUT ITS CASING [mm]
P L H
150 917 655 1785
230 1027 795 1895
300 1134 845 1910
348 1258 965 2075
400 1258 965 2075
500 1258 965 2075
600 1313 1065 2186
P

Technical characteristics and dimensions
12
Default scale for models:
ARES PRO 348 - ARES
PRO 400 - ARES PRO
500 - ARES PRO 600
Optional for models:
ARES PRO 150 - ARES
PRO 230 - ARES PRO 300
ARES PRO 150 - ARES PRO 230 - ARES PRO 300
To remove the cover,
release the 2 springs, refer to the part shown below
2.2.2 VIEW OF INTERNAL ACCESS
1
1
2
2

Technical characteristics and dimensions
13
2.3.1 PRIMARY CIRCUIT PUMP DETERMINATION
e boiler pump must have head that is able to ensure the pump's ow
rates according to the circuit's ∆t.
e pumps must be determined by the installer or
designer according to the boiler and system data.
2.3 WATER SIDE PRESSURE DROPS
DIAGRAM
Pressure drop (m/H2O)
Flow rate (m3/h)
ARES PRO
150
ARES PRO
230
ARES PRO
300
ARES PRO
348 - 400 -
500
ARES PRO
600
ARES PRO 150 230 300 348 400 500 600
Maximum ow rate in l / h (Dt=15K) 7.818 11.999 15.740 19.575 21.386 25.338 30.978
Nominal ow required in l / h (Dt=20K) 5.863 9.000 11.805 14.681 16.039 19.004 23.234
e pump is not an integral part of the boiler.
It is recommended to select a pump with a ow rate and head of
approximately 2/3 of its characteristic curve.

Technical characteristics and dimensions
14
2.4 OPERATING DATA / GENERAL CHA
RACTERISTICS
Room Temperature = 20°C
(*) Temperature detected with appliance operation ow rate 80°C / ret. 60°C
CO2 (min/max) See table ‘’NOZZLES - PRESSURE’’
Seasonal energy eciency to heat the room
2009/125 CEE (<=400Kw) ηs - see table ErP
Heat loss in stand-by ∆T 30°C - Pstb - see table ErP
Electricity consumption on standby - Psb - see table ErP
ARES PRO 150 230 300 348 400 500 600
Boiler category II2H3P
Modulation ratio 1 : 4,0 1 : 4,3 1 : 4,3 1 : 3,9 1 : 4,2 1 : 3,9 1 : 4,4
Rated heat output on P.C.I. Qn kW 140 214 280 348 380 450 550
Minimum heat output on P.C.I. Qmin kW 35 50 65 90 90 115 125
Rated useful power (Tr 60 / Tm 80 °C) Pn kW 136,36 209,29 274,54 341,42 373,01 441,95 540,32
Minimum useful power (Tr 60 / Tm 80 °C) Pn min kW 32,52 48,25 63,57 87,67 87,80 111,09 118,53
Rated useful power (Tr 30 / Tm 50 °C) Pcond kW 145,88 226,84 292,88 363,31 399,00 472,20 581,19
Minimum useful power (Tr 30 / Tm 50 °C) Pcond
min kW 36,54 54,60 70,01 99,09 97,20 124,09 135,88
Rated power performance (Tr 60 / Tm 80°C) % 97,4 97,8 98,05 98,11 98,16 98,21 98,24
Minimum power performance (Tr 60 / Tm 80°C) % 92,92 96,5 97,8 97,41 97,55 96,6 94,82
Rated power performance (Tr 30 / Tm 50°C) % 104,2 106 104,6 104,4 105 104,9 105,67
Minimum power performance (Tr 30 / Tm 50°C) % 104,4 109,2 107,7 110,1 108 107,9 108,7
Performance at 30% of the load (Tr 30°C) % 107,7 107,2 108,9 108,4 108,8 108,9 106,5
Combustion eciency at nominal load % 97,8 97,9 98,2 98,2 98,2 98,2 98,3
Combustion eciency with reduced load % 98,38 98,32 98,40 98,34 98,31 98,43 98,42
Casing heat loss with burner operating (Qmin) % 5,46 1,82 0,60 0,93 0,76 1,83 3,60
Casing heat loss with burner operating (Qn) % 0,4 0,1 0,1 0,1 0,1 0,03 0,04
Net ue gas temperature tf-ta (min)(**) °C 32,3 33,6 32 33,2 33,7 31,3 31,5
Net ue gas temperature tf-ta (max)(**) °C 44,2 42,7 36,7 35,6 35,4 35,5 34,3
Maximum permitted temperature °C 100
Maximum operating temperature °C 90
Flue gas mass ow rate (min) kg/h 57 82 106 147 147 188 204
Flue gas mass ow rate (max) kg/h 229 350 458 569 621 735 899
Excess air % 25,53
Heat loss at chimney with burner on (min) % 1,62 1,68 1,60 1,66 1,69 1,57 1,58
Heat loss at chimney with burner on (max) % 2,21 2,14 1,84 1,78 1,77 1,78 1,72
Minimum heating circuit pressure bar 0,5
Maximum heating circuit pressure bar 6
Water content l 153 210 270 340 340 340 425
Methane gas consumption G20 (pow.sup. 20 mbar) at Qn m3/h 14,80 22,63 29,61 36,80 40,18 47,58 58,15
Methane gas consumption G20 (pow.sup. 20 mbar) at Qmin m3/h 3,70 5,29 6,87 9,52 9,52 12,16 13,22
Propane gas consumption (pow. sup. 37/50 mbar) at Qn kg/h 10,87 16,61 21,73 27,01 29,50 34,93 42,69
Propane gas consumption (pow. sup. 37/50 mbar) at Qmin kg/h 2,72 3,88 5,05 9,70 6,99 8,93 8,70
Chimney base maximum pressure available Pa 100
Max condensate production kg/h 11,5 13,7 15,8 29,1 28,5 28,8 31,0
Emissions
CO at maximum heat output with 0% of O2
mg/kWh 13,73 18,05 28,08 25,27 18,25 22,46 22,1
NOx at maximum heat output with 0% of O2
mg/kWh 54 43 53 49 50 48 50
NOx Class 6
Electrical data
Power supply voltage/frequency V/Hz 230/50
Fuse on the power supply A (R) 6
Protection rating IP X4D

Technical characteristics and dimensions
15
2.5 TECHNICAL PARAMETERS FOR COMBINATION BOILERS
IN COMPLIANCE WITH REGULATION 813/2013
Eciencies in the following tables refer to the gross caloric value.
Model/s: ARES PRO 150
Condensing Boilers: YES
Low temperature boiler: NO
Boiler type B1: NO
Co-generation appliance for central heating: NO Fitted with supplementary heating system: NO
Mixed heating appliance: NO
Element Symbol Value Unit Element Symbol Valu e Unit
Nominal heat output Pn136 kW Seasonal energy eciency of central
heating ηs93 %
For central heating only and combination boilers: useful heat output For central heating only and combination boilers: useful eciency
At nominal heat output in high tempera-
ture mode (*) P4136,3 kW At nominal heat output in high tempera-
ture mode (*) η487,8 %
At 30% of nominal heat output in a low
temperature mode (**) P145,2 kW At 30% of nominal heat output in a low
temperature mode (**) η197,0 %
Auxiliary electricity consumption Other items
At full load elmax 0,190 kW Heat loss in standby Pstby 0,32 kW
At partial load elmin 0,042 kW Ignition burner energy consumption QHE 424 GJ
In standby mode PSB 0,005 kW Emissions of nitrogen oxides NOX59 (53) mg /
kWh
For mixed central heating appliances
Stated load prole Domestic hot water production eciency ηWH %
Daily electrical power consumption Qelec kWh Daily gas consumption Qfuel kWh
Contact information Alpha Heating Innovation - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS
(*) High temperature mode means 60°C on return and 80 °C on ow.
(**) Low temperature mode for condensation Boilers means 30 °C , for low temperature boilers 37 °C and for other appliances 50 °C of return
temperature.

Technical characteristics and dimensions
16
Model/s: ARES PRO 230
Condensing Boilers: YES
Low temperature boiler: NO
Boiler type B1: NO
Co-generation appliance for central heating: NO Fitted with supplementary heating system: NO
Mixed heating appliance: NO
Element Symbol Value Unit Element Symbol Valu e Unit
Nominal heat output Pn209 kW Seasonal energy eciency of central
heating ηs92 %
For central heating only and combination boilers: useful heat output For central heating only and combination boilers: useful eciency
At nominal heat output in high tempera-
ture mode (*) P4209,3 kW At nominal heat output in high tempera-
ture mode (*) η488,1 %
At 30% of nominal heat output in a low
temperature mode (**) P168,8 kW At 30% of nominal heat output in a low
temperature mode (**) η196,6 %
Auxiliary electricity consumption Other items
At full load elmax 0,195 kW Heat loss in standby Pstby 0,39 kW
At partial load elmin 0,040 kW Ignition burner energy consumption QHE 653 GJ
In standby mode PSB 0,005 kW Emissions of nitrogen oxides NOX56 (51) mg /
kWh
For mixed central heating appliances
Stated load prole Domestic hot water production eciency ηWH %
Daily electrical power consumption Qelec kWh Daily gas consumption Qfuel kWh
Contact information Alpha Heating Innovation - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS
(*) High temperature mode means 60°C on return and 80 °C on ow.
(**) Low temperature mode for condensation Boilers means 30 °C , for low temperature boilers 37 °C and for other appliances 50 °C of return
temperature.
Model/s: ARES PRO 300
Condensing Boilers: YES
Low temperature boiler: NO
Boiler type B1: NO
Co-generation appliance for central heating: NO Fitted with supplementary heating system: NO
Mixed heating appliance: NO
Element Symbol Value Unit Element Symbol Valu e Unit
Nominal heat output Pn274 kW Seasonal energy eciency of central
heating ηs94 %
For central heating only and combination boilers: useful heat output For central heating only and combination boilers: useful eciency
At nominal heat output in high tempera-
ture mode (*) P4274,5 kW At nominal heat output in high tempera-
ture mode (*) η488,3 %
At 30% of nominal heat output in a low
temperature mode (**) P191,5 kW At 30% of nominal heat output in a low
temperature mode (**) η198,1 %
Auxiliary electricity consumption Other items
At full load elmax 0,210 kW Heat loss in standby Pstby 0,34 kW
At partial load elmin 0,032 kW Ignition burner energy consumption QHE 844 GJ
In standby mode PSB 0,005 kW Emissions of nitrogen oxides NOX59 (53) mg /
kWh
For mixed central heating appliances
Stated load prole Domestic hot water production eciency ηWH %
Daily electrical power consumption Qelec kWh Daily gas consumption Qfuel kWh
Contact information Alpha Heating Innovation - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS
(*) High temperature mode means 60°C on return and 80 °C on ow.
(**) Low temperature mode for condensation Boilers means 30 °C , for low temperature boilers 37 °C and for other appliances 50 °C of return
temperature.

Technical characteristics and dimensions
17
Model/s: ARES PRO 348
Condensing Boilers: YES
Low temperature boiler: NO
Boiler type B1: NO
Co-generation appliance for central heating: NO Fitted with supplementary heating system: NO
Mixed heating appliance: NO
Element Symbol Value Unit Element Symbol Valu e Unit
Nominal heat output Pn341 kW Seasonal energy eciency of central
heating ηs93 %
For central heating only and combination boilers: useful heat output For central heating only and combination boilers: useful eciency
At nominal heat output in high tempera-
ture mode (*) P4341,4 kW At nominal heat output in high tempera-
ture mode (*) η488,4 %
At 30% of nominal heat output in a low
temperature mode (**) P1113,2 kW At 30% of nominal heat output in a low
temperature mode (**) η197,7 %
Auxiliary electricity consumption Other items
At full load elmax 0,270 kW Heat loss in standby Pstby 0,95 kW
At partial load elmin 0,036 kW Ignition burner energy consumption QHE 1054 GJ
In standby mode PSB 0,005 kW Emissions of nitrogen oxides NOX54 (49) mg /
kWh
For mixed central heating appliances
Stated load prole Domestic hot water production eciency ηWH %
Daily electrical power consumption Qelec kWh Daily gas consumption Qfuel kWh
Contact information Alpha Heating Innovation - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS
(*) High temperature mode means 60°C on return and 80 °C on ow.
(**) Low temperature mode for condensation Boilers means 30 °C , for low temperature boilers 37 °C and for other appliances 50 °C of return
temperature.
Model/s: ARES PRO 400
Condensing Boilers: YES
Low temperature boiler: NO
Boiler type B1: NO
Co-generation appliance for central heating: NO Fitted with supplementary heating system: NO
Mixed heating appliance: NO
Element Symbol Value Unit Element Symbol Valu e Unit
Nominal heat output Pn371 kW Seasonal energy eciency of central
heating ηs94 %
For central heating only and combination boilers: useful heat output For central heating only and combination boilers: useful eciency
At nominal heat output in high tempera-
ture mode (*) P4373,0 kW At nominal heat output in high tempera-
ture mode (*) η488,4 %
At 30% of nominal heat output in a low
temperature mode (**) P1124,0 kW At 30% of nominal heat output in a low
temperature mode (**) η198,0 %
Auxiliary electricity consumption Other items
At full load elmax 0,425 kW Heat loss in standby Pstby 0,95 kW
At partial load elmin 0,051 kW Ignition burner energy consumption QHE 1148 GJ
In standby mode PSB 0,005 kW Emissions of nitrogen oxides NOX55 (50) mg /
kWh
For mixed central heating appliances
Stated load prole Domestic hot water production eciency ηWH %
Daily electrical power consumption Qelec kWh Daily gas consumption Qfuel kWh
Contact information Alpha Heating Innovation - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS
(*) High temperature mode means 60°C on return and 80 °C on ow.
(**) Low temperature mode for condensation Boilers means 30 °C , for low temperature boilers 37 °C and for other appliances 50 °C of return
temperature.

Technical characteristics and dimensions
18
Model/s: ARES PRO 500
Condensing Boilers: YES
Low temperature boiler: NO
Boiler type B1: NO
Co-generation appliance for central heating: NO Fitted with supplementary heating system: NO
Mixed heating appliance: NO
Element Symbol Value Unit Element Symbol Valu e Unit
Nominal heat output Pn442 kW Seasonal energy eciency of central
heating ηs94 %
For central heating only and combination boilers: useful heat output For central heating only and combination boilers: useful eciency
At nominal heat output in high tempera-
ture mode (*) P4441,9 kW At nominal heat output in high tempera-
ture mode (*) η488,5 %
At 30% of nominal heat output in a low
temperature mode (**) P1147,1 kW At 30% of nominal heat output in a low
temperature mode (**) η198,2 %
Auxiliary electricity consumption Other items
At full load elmax 0,555 kW Heat loss in standby Pstby 0,95 kW
At partial load elmin 0,053 kW Ignition burner energy consumption QHE 1358 GJ
In standby mode PSB 0,004 kW Emissions of nitrogen oxides NOX53 (48) mg /
kWh
For mixed central heating appliances
Stated load prole Domestic hot water production eciency ηWH %
Daily electrical power consumption Qelec kWh Daily gas consumption Qfuel kWh
Contact information Alpha Heating Innovation - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS
(*) High temperature mode means 60°C on return and 80 °C on ow.
(**) Low temperature mode for condensation Boilers means 30 °C , for low temperature boilers 37 °C and for other appliances 50 °C of return
temperature.
Model/s: ARES PRO 600
Condensing Boilers: YES
Low temperature boiler: NO
Boiler type B1: NO
Co-generation appliance for central heating: NO Fitted with supplementary heating system: NO
Mixed heating appliance: NO
Element Symbol Value Unit Element Symbol Valu e Unit
Nominal heat output Pn540 kW Seasonal energy eciency of central
heating ηs92 %
For central heating only and combination boilers: useful heat output For central heating only and combination boilers: useful eciency
At nominal heat output in high tempera-
ture mode (*) P4540,3 kW At nominal heat output in high tempera-
ture mode (*) η488,5 %
At 30% of nominal heat output in a low
temperature mode (**) P1175,7 kW At 30% of nominal heat output in a low
temperature mode (**) η196,0 %
Auxiliary electricity consumption Other items
At full load elmax 0,590 kW Heat loss in standby Pstby 1,34 kW
At partial load elmin 0,088 kW Ignition burner energy consumption QHE 1694 GJ
In standby mode PSB 0,007 kW Emissions of nitrogen oxides NOX56 (50) mg /
kWh
For mixed central heating appliances
Stated load prole Domestic hot water production eciency ηWH %
Daily electrical power consumption Qelec kWh Daily gas consumption Qfuel kWh
Contact information Alpha Heating Innovation - Nepicar House - London Road - Wrotham Heath - Kent - TN15 7RS
(*) High temperature mode means 60°C on return and 80 °C on ow.
(**) Low temperature mode for condensation Boilers means 30 °C , for low temperature boilers 37 °C and for other appliances 50 °C of return
temperature.

19
Instructions for the installer
3INSTRUCTIONS FOR INSTALLATION
3.1 GENERAL WARNINGS
ATTENTION!
is boiler must only be employed for its explicitly
intended use. Any other use must be considered
improper and therefore dangerous.
is boiler is used to heat water to below boiling
temperature in atmospheric pressure.
Before connecting the boiler, have professionally
authorised company:
a) Accurately washing all of the pipes in the system
to remove any residues or sediments could stop
the boiler form running eciently,
b) Making sure the boiler is set up to operate with the
available type of fuel.
e type of fuel is stated on the packaging and
technical characteristics plate.
c) Make sure that the chimney/ue has an adequate
draught, that it is not choked, and that there are
no other exhausts for other appliances, unless the
ue is designed for multiple utilities, in accordance
with standard specications and requirements in
force.
Only once this check has been carried out can the
tting between boiler and chimney/ue be set up.
ATTENTION!
If aggressive / corrosive powders and / or vapors are
present in the installation room, the appliance must
be adequately protected and must be able to operate
independently of the room air.
ATTENTION!
Assemble the appliance in observance of the mi-
nimum required distances for installation and
maintenance.
e boiler must be connected to a heating system
and / or a domestic hot water distribution network,
compatible with its performance and power.

20
Instructions for the installer
3.2 PACKAGING
Ensure the integrity of the content.
Packaging materials (cardboard box, straps, plastic bags,
etc.) constitute a potential hazard and must be kept
out of the reach of children.
Alpha Heating Innovation will not be held liable in
case of damage caused to people, animals or property
due to failure to observe the above.
ARES
PRO
P
depth (mm)
L
width (mm)
H
height (mm) Net Weight (kg) Weight Packaging (kg)
150 1042 780 2010 347+60* 15** + 20***
230 1232 1120 2200 399+80* 43** + 30***
300 1495 1120 2393 459+90* 57** + 30***
348 1495 1120 2393 610+106* 57** + 30***
400 1495 1120 2393 610+106* 57** + 30***
500 1495 1120 2393 610+106* 57** + 30***
600 1520 1120 2500 755+120* 59** + 35***
(*) casing - (**) pallet - (***) cardboard
In the packaging, in addition to the appliance, there is an accessory
box containing:
- 5 curves + a T + a plastic cap for condensation drainage
- External probe
- Accumulation probe
- Cable exit sheet
- SHC multifunction kit module
- Condensate drain siphon pipe 1 m.
3.2.1 HANDLING
e boiler must be handled by liing it from the holes
on the upper plate or using a transpallet
OBLIGATION!
wear protective gloves
- Only transport the boiler using appropriate transport
equipment
- Protect all parts against impacts if they are to be
transported.
- Follow the transport instructions on the packaging.
