AlphaTecRacing Dashboard Formula User manual

Instruction
Dashboard Formula
AlphaTecRacing

Mounting material
2m USB-C textile cable
Mounting plate
Thumbscrews for
each wheelbase necessary
Mounting screws for
Fanatec
Mounting screws for
Simucube, VRS, Simagic
Mounting screws for
Moza R5,R9,R16,21;
Asetek SimSports

I Product information
Features
> Dashboard for SimRacing
> Realistic Formula 1 design
> Aluminum housing
> Supports all popular wheelbases
> Intended for use with SimHub
Technical drawing
Wheelbase
> Simucube etc.
> Fanatec
> Moza R5&9
> Moza R16&21
Hole spacing
> 103–92mm (Oblong hole)
> 56mm
> 124mm
> 84mm

II Mounting
1. For mounting on your personal Wheelbase, take a close
look at the following schematics.
Fanatec
Simucube, VRS, Simagic, etc.

1. For your Moza or Asetec Wheelbase you will need you
need the screws and spacers included in the bags.
Moza R5 & R9
Moza R16 & R21
Asetec SimSports

2. Now screw your dashboard to the bracket using the
thumbscrews. You can easily adjust the height of the
dashboard by hand at any time using the by hand at any
time.
3. Connect your dashboard and the PC with the USB-C cable
and now follow the part „Software installation“.
Fixing dashboard

III Software installation
1. Install the freeware SimHub: www.simhubdash.com.
2. Install the VoCore display driver from
www.simhubdash.com/devices-driver-installation/.
Select the „VOCORE LCD“ (Windows 10/11 Vocore Screen
(Touch version) drivers)
3. Start the SimHub program and select „AlphaTecRacing
- Dashboard Formula“ under „Devices“ and „add new
Device“.

4. Under the following link you will find LED and display
presets that automatically adapt to your vehicle
to further personalize your dashboard and use all
functions: www.alphatecracing.com/pages/downloads
Follow the steps below to install the additional
presets:
a. Go to the website mentioned above, where you
already found this guide, and download the
„SimHub ATR-plugin“ file.
b. Make sure that the SimHub program is closed.
c. Run the „SimHub ATR-plugin.exe“ file after
downloading it. You will be guided through the
installation by a new window. Make sure that
the installation path is the same as your Sim-
Hub installation path (by default C://Progam
Files (x86)\SimHub is selected).
d. After starting SimHub, you can now see the
new dashboard designs under your „Device“,
„AlphaTecRacing Dashboard Formula“ under
„Display Dashboard“ (see next page).
e. Additionally check the box „Save/Restore last
dashboard used by game/car“, so that SimHub
automatically selects the dashboard which
you used for the game last time. So you
have to use our dashboard sets for iRacing,
ACC, F1 etc. only have to select them once and
start the game. After that it works by itself.

V Disposal of the device
When you no longer need the AlphaTecRacing Dashboard Formula or it no longer functions,
you must dispose of it properly to avoid environmental pollution and health risks. Please
do not throw the device into the household waste. According to the EU Directive 2012/19/
EU on waste electrical and electronic equipment, you must return the product to a special
collection point or to an electronics retailer near you. The crossed-out wheeled garbage
can symbol on the product indicates that it should not be disposed of with other household
waste. By disposing of the device properly, valuable raw materials can be reused and
recovered. It also protects the environment from pollutants that can be released when
waste electrical and electronic equipment is improperly handled. Please learn about and
comply with the specific recycling programs and regulations in your region or country to
ensure that the device is disposed of properly.
VI Warranty details
The AlphaTecRacing Dashboard Formula is covered by a 2-year warranty from the date of
purchase. The warranty covers repair and replacement of parts that are defective due to
manufacturing or material defects. Please note that the warranty does not cover damage due
to misuse, dropping, abuse, water or fire damage, or natural wear and tear. In addition,
damage caused by unauthorized attempts to repair or modify the unit is not covered under
warranty. If you are eligible for warranty service, please contact our Customer Service
Department. We will review your request and provide you with instructions for returning
the product and processing the warranty claim. Please note that return shipping costs
must be paid by the customer. To make your warranty claim, we will need a copy of your
sales receipt and a detailed description of the problem, including a serial number of the
product if available. We reserve the right to repair the defective product or replace it
with a new or refurbished product. This warranty gives you specific legal rights, which
may vary depending on the country or region in which you live. However, this warranty
does not affect your statutory rights and is construed in accordance with the relevant
laws and regulations.
IV Safety instructions
- Avoiding moisture: Avoid using the device in humid environments or near water, as this
may cause short circuits or electric shocks.
- Use of authorized cables and accessories: Use only authorized cables and accessories
recommended for the device. Unauthorized cables and accessories may cause damage to
the device.
- Disconnecting devices when not in use: Disconnect the device from the computer when not
in use to save power and avoid possible damage from power surges.
- Protect from dust and dirt: Protect the device from dust and dirt to prolong the life
of the device and not affect its operation.
- Avoid shock or impact: Avoid dropping or bumping the device to prevent possible damage.
- Follow the manufacturer‘s instructions: Always follow the manufacturer‘s instructions
for using the device to ensure safe and effective use.

Company address
AlphaTecRacing
Thorben Günther
Ernst-Lehmann-Str. 20
39106 Magdeburg
Germany
URL: https://alphatecracing.com/
VII Contact and help
Please contact the following email address if you need further assistance:
- [email protected]
VIII Device specifications
- AlphaTecRacing - Dashboard Formula
- P.N.: 3.23.3.43
- Housing material: Aluminum alloy
- Color: Black anodized
- Input power: 5V 500mA (USB)
- Exclusively for use with PC
- Dimensions 129mm x 82mm x 17,5mm
- Weight: 220g
