Contents
Operating
Instructions
WARNING
WARNING 5
CAUTION 5
PRECAUTIONS 6
Discs Playable on This Unit 7
Getting Started
Accessory List 11
Location of Controls 11
Turning Power On or Off 11
InsertinglEjecting aDisc 12
Adjusting the Monitor Viewing Angle 12
Adjusting the Volume 12
Lowering Volume Quickly 12
How to view the Display 12
Soft button operation 12
Recalling the Source 12
Displaying the Numeric Keypad Input
Screen 13
Selecting the Display Style 14
Radio
Listening to the Radio 14
Presetting Stations Manually 15
Presetting Stations Automatically 15
Tuning to Preset Stations 15
Changing the Display
(HD Radio mode only)
15
Receiving aMulticast
(HD Radio mode only)
15
CDIMP3IWMAJAAC
Playback 16
Repeat Play 17
M.I.X. (Random Play) 17
Selecting Folders
(concerning
MP3IWMN AAC) 17
About MP3IWMN AAC 17
ENGLISH
DVDNideo CD
Playing aDisc 19
To display the DVD mode screen 19
If amenu screen appears 20
Displaying the Top Menu Screen
21
Displaying the Menu Screen 21
Displaying the Menu Operation Mode
Screen
21
Searching by Program 21
Searching by Playlist 21
Stopping Playback (PRE STOP) 21
Stopping Playback 21
Fast-forwardinglFast-reversing 22
Finding the Beginnings
of Chaptersffracksl
Files 22
Playing Still Frames (Pausing) 22
Forward/reverse frame-by-frame Playback 22
Slow Motion Playback 22
Selecting Program (SKIP) 22
Selecting Playlist (SKIP) 23
Selecting Folders
23
Repeat Playback 23
Searching
by Title/Group/PrograrnlPlaylisti
Folder Number 24
Searching Directly by Chapter, Track or File
Number 24
Switching the Angle 24
Scroll to Move the Page Forward or Back 24
Switching the Audio Tracks
25
Switching the Subtitles
(Subtitle Language)
25
Switching from the disc menu 25
Displaying the Disc Status for
DVDNideo CD 25
About DivX®
25
Other Useful Features
Adjusting the Audio 26
Search Function 27
Rear Entertainment Function 28
Switching Display Modes
28
i-EN
Contents
Operating
Instructions
WARNING
WARNING 5
CAUTION 5
PRECAUTIONS 6
Discs Playable on This Unit 7
Getting Started
Accessory List 11
Location of Controls 11
Turning Power On or Off 11
InsertinglEjecting aDisc 12
Adjusting the Monitor Viewing Angle 12
Adjusting the Volume 12
Lowering Volume Quickly 12
How to view the Display 12
Soft button operation 12
Recalling the Source 12
Displaying the Numeric Keypad Input
Screen 13
Selecting the Display Style 14
Radio
Listening to the Radio 14
Presetting Stations Manually 15
Presetting Stations Automatically 15
Tuning to Preset Stations 15
Changing the Display
(HD Radio mode only)
15
Receiving aMulticast
(HD Radio mode only)
15
CDIMP3IWMAJAAC
Playback 16
Repeat Play 17
M.I.X. (Random Play) 17
Selecting Folders
(concerning
MP3IWMN AAC) 17
About MP3IWMN AAC 17
ENGLISH
DVDNideo CD
Playing aDisc 19
To display the DVD mode screen 19
If amenu screen appears 20
Displaying the Top Menu Screen
21
Displaying the Menu Screen 21
Displaying the Menu Operation Mode
Screen
21
Searching by Program 21
Searching by Playlist 21
Stopping Playback (PRE STOP) 21
Stopping Playback 21
Fast-forwardinglFast-reversing 22
Finding the Beginnings
of Chaptersffracksl
Files 22
Playing Still Frames (Pausing) 22
Forward/reverse frame-by-frame Playback 22
Slow Motion Playback 22
Selecting Program (SKIP) 22
Selecting Playlist (SKIP) 23
Selecting Folders
23
Repeat Playback 23
Searching
by Title/Group/PrograrnlPlaylisti
Folder Number 24
Searching Directly by Chapter, Track or File
Number 24
Switching the Angle 24
Scroll to Move the Page Forward or Back 24
Switching the Audio Tracks
25
Switching the Subtitles
(Subtitle Language)
25
Switching from the disc menu 25
Displaying the Disc Status for
DVDNideo CD 25
About DivX®
25
Other Useful Features
Adjusting the Audio 26
Search Function 27
Rear Entertainment Function 28
Switching Display Modes
28
i-EN

Switching the Visual Source Only
(Simultaneous Function) 28
Canceling the Simultaneous Function 28
Blackout Mode On and Off 28
Setup
DVD Setup Operation 29
Changing the language setting 30
Setting
of the Menu Language 30
Setting
of the Audio Language 30
Setting
of the Subtitle Language 30
Changing the Country Code Setting 30
Setting the Rating Level (Parental Lock)
31
Changing the Digital Output Setting 31
Setting the Downmix Mode 33
Setting the TV Screen Mode 33
Setting
of the Bonus Code 33
Setting
of the DVD-Audio Playback
Mode 33
Playing MP3IWMAIAAC Data
(FILE PLAY MODE) 33
Setting the compressed File Playback
Data 34
Displaying DivX® Disc Information 34
Setting the Video
CD Play Mode 34
Digital SEEK Setting
(HD Radio mode only) 34
Display Setup Operation 34
Setting the Brightness
of the
Backlighting 35
Adjusting the Minimum Level
of
Backlight 35
Switching Background Textures 35
Setting Automatic Background Textures 35
Switching the Font Back Display Color
35
Adjusting the Touch Panel 35
General Setup Operation 36
Displaying the Time 36
Setting the Time 36
Setting Daylight Saving Time 36
Demonstration Function 36
Sound (Beep) Guide Function 36
Setting the Scroll 37
Adjusting the Dimmer
of Button Lighting at
Night 37
2-EN
System Setup Operation 37
Setting the External Device Interrupt
Mode 38
Setting the Interrupt Icon Display 38
Switching the function
of the remote
sensor 38
Setting the Rear Camera Input 38
Setting the Navigation Mode 38
Setting the Navigation Interruption 38
Setting the AUX Mode 38
Adjusting the External Input Audio
Level 39
Switching the Visual Input Signal
System 39
Setting the Picture Output 39
Setting the Bluetooth Connection
(BLUETOOTH IN) 39
Setting the USB Adapter to ON/OFF 39
Setting the VISUAL Soft Button 39
Setting the OPTION Button on the Unit 39
Setting the Digital Output 39
Setting the AUX+ Mode 39
Adjusting the AUX+ Audio Level 39
L.L.c. Setting Operation 40
Picture Quality Darkness Adjustment Function
(L.L.C.) 40
Selecting the VISUAL EQ Mode
(Maker's setting)
40
Adjusting Brightness 40
Adjusting Color of Picture 40
Adjusting Tint of Picture 40
Adjusting Image Contrast 41
Adjusting Picture Quality 41
Storing VISUAL EQ 41
Downloading the BACKGROUND data ........41
SIRIUS Setup Operation 42
Setting the announcement individually for aSong/
Artist/Sports Team
42
Setting ON/OFF of all Songs/Artists
Interruption 42
Setting the sports team announcement
type 42
Setting the Sports Team Display
.43
Switching the Visual Source Only
(Simultaneous Function) 28
Canceling the Simultaneous Function 28
Blackout Mode On and Off 28
Setup
DVD Setup Operation 29
Changing the language setting 30
Setting
of the Menu Language 30
Setting
of the Audio Language 30
Setting
of the Subtitle Language 30
Changing the Country Code Setting 30
Setting the Rating Level (Parental Lock)
31
Changing the Digital Output Setting 31
Setting the Downmix Mode 33
Setting the TV Screen Mode 33
Setting
of the Bonus Code 33
Setting
of the DVD-Audio Playback
Mode 33
Playing MP3IWMAIAAC Data
(FILE PLAY MODE) 33
Setting the compressed File Playback
Data 34
Displaying DivX® Disc Information 34
Setting the Video
CD Play Mode 34
Digital SEEK Setting
(HD Radio mode only) 34
Display Setup Operation 34
Setting the Brightness
of the
Backlighting 35
Adjusting the Minimum Level
of
Backlight 35
Switching Background Textures 35
Setting Automatic Background Textures 35
Switching the Font Back Display Color
35
Adjusting the Touch Panel 35
General Setup Operation 36
Displaying the Time 36
Setting the Time 36
Setting Daylight Saving Time 36
Demonstration Function 36
Sound (Beep) Guide Function 36
Setting the Scroll 37
Adjusting the Dimmer
of Button Lighting at
Night 37
2-EN
System Setup Operation 37
Setting the External Device Interrupt
Mode 38
Setting the Interrupt Icon Display 38
Switching the function
of the remote
sensor 38
Setting the Rear Camera Input 38
Setting the Navigation Mode 38
Setting the Navigation Interruption 38
Setting the AUX Mode 38
Adjusting the External Input Audio
Level 39
Switching the Visual Input Signal
System 39
Setting the Picture Output 39
Setting the Bluetooth Connection
(BLUETOOTH IN) 39
Setting the USB Adapter to ON/OFF 39
Setting the VISUAL Soft Button 39
Setting the OPTION Button on the Unit 39
Setting the Digital Output 39
Setting the AUX+ Mode 39
Adjusting the AUX+ Audio Level 39
L.L.c. Setting Operation 40
Picture Quality Darkness Adjustment Function
(L.L.C.) 40
Selecting the VISUAL EQ Mode
(Maker's setting)
40
Adjusting Brightness 40
Adjusting Color of Picture 40
Adjusting Tint of Picture 40
Adjusting Image Contrast 41
Adjusting Picture Quality 41
Storing VISUAL EQ 41
Downloading the BACKGROUND data ........41
SIRIUS Setup Operation 42
Setting the announcement individually for aSong/
Artist/Sports Team
42
Setting ON/OFF of all Songs/Artists
Interruption 42
Setting the sports team announcement
type 42
Setting the Sports Team Display
.43

External Audio Processor (Optional)
Adjustment Procedure for Dolby Surround 44
Setting the A.PROCESSOR 44
Storing Settings in the Memory 50
Calling up the Preset Memory 50
IMPRINT Operation (Optional)
Changing MultEQ mode 50
Adjusting Sound Setting in Manual Mode
51
Equalizer Presets (F-EQ) 51
Setting the Response Slope for the High Range
Speaker
(TW SETUP) 51
Setting the MX Level
(MEDIA XPANDER)
51
Adjusting the Parametric Equalizer Curve
(P-EQ) 52
Adjusting the Graphic Equalizer Curve
(G-EQ) 52
Setting the Time Correction Unit
(T.CORR PARAMETER) 52
Adjusting the Time Correction
(T. CORR) 52
Adjusting the Crossover Settings
(X-OVER) 53
Storing Settings in the Memory 53
Calling up the Preset Memory 54
Setting the Subwoofer 54
Adjusting the Subwoofer Level 54
Setting the Subwoofer System 54
Setting the Subwoofer Phase 54
Setting the Subwoofer Channel 54
About Time Correction 54
About the Crossover 55
About IMPRINT 56
Navigation System (Optional)
Switching the Navigation Screen
(Optional) 57
Portable Navigation System Operation
(Optional) 57
Auxiliary Device (Optional)
Operating Auxiliary Devices (Optional) 58
Changer (Optional)
Controlling CD Changer (Optional) 59
Multi-Changer Selection (Optional) 60
USB Adapter Operation (Optional)
Controlling USB (Optional) 60
SAT Radio Receiver (Optional)
Receiving Channels with the SAT Receiver
(Optional)
61
Tuning in to Categorized Programs 61
Changing the Display 61
Checking the SAT Radio ill Number 62
Storing Channel Presets 62
Receiving Stored Channels 62
Search Function (XM mode) 62
Search Function (SIRIUS mode) 63
Selecting the Channel directly 63
Setting the SIRIUS (SIRIUS mode only) 63
Receiving Weather
or Traffic information from
SAT Radio 63
Storing the desired Song/Artist
(SIRIUS mode only) 63
Storing favorite Sports Teams
(SIRIUS mode only) 64
Receiving the stored information
(SIRIUS mode only) 64
Offset Playback Function
(SIRIUS mode only) 64
USB Memory (Optional)
BANK Function (USB memory only) 65
Playback 65
Repeat Play
65
Random Play Shuffle (M.LX.) 66
Searching for adesired Song
'" 66
Searching by artist name 66
Selecting Playlist!Artist!Album/Genre/
Composer 66
Select the desired Folder (Folder up/down) 67
Creating the playlist from the Artist!Album
information
of the current song 67
About
MP3IWMNAAC File of USB
Memory 67
iPod@ (Optional)
Playback 67
Searching for adesired Song 68
Searching by artist name 68
Direct Search Function 69
Selecting Playlist!Artist!Album/Genre/Composer/
Category 69
Random Play Shuffle (M.LX.) 70
Repeat Play 70
3-EN
External Audio Processor (Optional)
Adjustment Procedure for Dolby Surround 44
Setting the A.PROCESSOR 44
Storing Settings in the Memory 50
Calling up the Preset Memory 50
IMPRINT Operation (Optional)
Changing MultEQ mode 50
Adjusting Sound Setting in Manual Mode
51
Equalizer Presets (F-EQ) 51
Setting the Response Slope for the High Range
Speaker
(TW SETUP) 51
Setting the MX Level
(MEDIA XPANDER)
51
Adjusting the Parametric Equalizer Curve
(P-EQ) 52
Adjusting the Graphic Equalizer Curve
(G-EQ) 52
Setting the Time Correction Unit
(T.CORR PARAMETER) 52
Adjusting the Time Correction
(T. CORR) 52
Adjusting the Crossover Settings
(X-OVER) 53
Storing Settings in the Memory 53
Calling up the Preset Memory 54
Setting the Subwoofer 54
Adjusting the Subwoofer Level 54
Setting the Subwoofer System 54
Setting the Subwoofer Phase 54
Setting the Subwoofer Channel 54
About Time Correction 54
About the Crossover 55
About IMPRINT 56
Navigation System (Optional)
Switching the Navigation Screen
(Optional) 57
Portable Navigation System Operation
(Optional) 57
Auxiliary Device (Optional)
Operating Auxiliary Devices (Optional) 58
Changer (Optional)
Controlling CD Changer (Optional) 59
Multi-Changer Selection (Optional) 60
USB Adapter Operation (Optional)
Controlling USB (Optional) 60
SAT Radio Receiver (Optional)
Receiving Channels with the SAT Receiver
(Optional)
61
Tuning in to Categorized Programs 61
Changing the Display 61
Checking the SAT Radio ill Number 62
Storing Channel Presets 62
Receiving Stored Channels 62
Search Function (XM mode) 62
Search Function (SIRIUS mode) 63
Selecting the Channel directly 63
Setting the SIRIUS (SIRIUS mode only) 63
Receiving Weather
or Traffic information from
SAT Radio 63
Storing the desired Song/Artist
(SIRIUS mode only) 63
Storing favorite Sports Teams
(SIRIUS mode only) 64
Receiving the stored information
(SIRIUS mode only) 64
Offset Playback Function
(SIRIUS mode only) 64
USB Memory (Optional)
BANK Function (USB memory only) 65
Playback 65
Repeat Play
65
Random Play Shuffle (M.LX.) 66
Searching for adesired Song
'" 66
Searching by artist name 66
Selecting Playlist!Artist!Album/Genre/
Composer 66
Select the desired Folder (Folder up/down) 67
Creating the playlist from the Artist!Album
information
of the current song 67
About
MP3IWMNAAC File of USB
Memory 67
iPod@ (Optional)
Playback 67
Searching for adesired Song 68
Searching by artist name 68
Direct Search Function 69
Selecting Playlist!Artist!Album/Genre/Composer/
Category 69
Random Play Shuffle (M.LX.) 70
Repeat Play 70
3-EN

Remote Control
Controls on Remote Control 70
When Using the Remote Control 72
Battery Replacement 72
Information
About DVDs 73
Terminology 73
List
of Language Codes 75
List
of Country Codes 76
In Case
of Difficulty 78
Specifications 82
Installation and Connections
Warning 83
Caution 83
Precautions 83
Installation 84
Connections 87
System Example 90
LIMITED WARRANTY
4-EN
Remote Control
Controls on Remote Control 70
When Using the Remote Control 72
Battery Replacement 72
Information
About DVDs 73
Terminology 73
List
of Language Codes 75
List
of Country Codes 76
In Case
of Difficulty 78
Specifications 82
Installation and Connections
Warning 83
Caution 83
Precautions 83
Installation 84
Connections 87
System Example 90
LIMITED WARRANTY
4-EN

Operating Instructions
WARNING
& WARNING
This symbol means important instructions.
Failure
to heed them can result in serious injury
or death.
INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER
CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE IS
STOPPED AND THE EMERGENCY BRAKE IS APPLIED.
It is dangerous (and illegal in many states) for the driver to watch
TVfVideo while driving avehicle. Installing this product
incorrectly enables the driver
to watch TVfVideo while driving.
This may cause adistraction, preventing the driver from looking
ahead, thus causing an accident. The driver orother people could be
severely injured.
DO NOT WATCH VIDEO WHILE DRIVING.
Watching the video may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR
ATIENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.
Any function that requires your prolonged attention should only be
performed after coming to acomplete stop. Always stop the vehicle
in asafe location before performing these functions. Failure to do
so may result in an accident.
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL
HEAR OUTSIDE NOISES WHILE DRIVING.
Excessive volume levels that obscure sounds such as emergency
vehicle sirens or road warning signals (train crossings, etc.) can be
dangerous and may result in an accident. LISTENING
AT LOUD
VOLUME LEVELS IN ACAR
MAY ALSO CAUSE HEARING
DAMAGE.
MINIMIZE DISPLAY VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident. fire or electric shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in fire, etc.
KEEP SMALL OBJECTS SUCH AS BATIERIES OUT OF THE
REACH OF CHILDREN.
Swallowing them may result in serious injury. If swallowed,
consult aphysician immediately.
USE THE CORRECT AMPERE RATING WHEN REPLACING
FUSES.
Failure to do so may result in fire or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result in fire.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in fire,
electric shock or other injury.
DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN
INSERTION SLOTS OR GAPS.
Doing so may result in personal injury or damage to the product.
& CAUTION
This symbol means important instructions.
Failure to heed them can result in injury or
material property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it
to your authorized Alpine dealer or the nearest
Alpine Service Center for repairing.
KEEP FINGERS AWAY WHILE THE MOTORIZED FRONT
PANEL OR MOVING MONITOR IS IN MOTION.
Failure to do so may result in personal injury or damage to the
product.
DO NOT MIX NEW BATIERIES WITH OLD BATTERIES.
INSERT WITH THE CORRECT BATIERY POLARITY.
When inserting the batteries, be sure to observe proper polarity (+
and -) as instructed. Rupture or chemical leakage from the battery
may cause fire or personal injury.
5-EN
Operating Instructions
WARNING
& WARNING
This symbol means important instructions.
Failure
to heed them can result in serious injury
or death.
INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER
CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE IS
STOPPED AND THE EMERGENCY BRAKE IS APPLIED.
It is dangerous (and illegal in many states) for the driver to watch
TVfVideo while driving avehicle. Installing this product
incorrectly enables the driver
to watch TVfVideo while driving.
This may cause adistraction, preventing the driver from looking
ahead, thus causing an accident. The driver orother people could be
severely injured.
DO NOT WATCH VIDEO WHILE DRIVING.
Watching the video may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR
ATIENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.
Any function that requires your prolonged attention should only be
performed after coming to acomplete stop. Always stop the vehicle
in asafe location before performing these functions. Failure to do
so may result in an accident.
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL
HEAR OUTSIDE NOISES WHILE DRIVING.
Excessive volume levels that obscure sounds such as emergency
vehicle sirens or road warning signals (train crossings, etc.) can be
dangerous and may result in an accident. LISTENING
AT LOUD
VOLUME LEVELS IN ACAR
MAY ALSO CAUSE HEARING
DAMAGE.
MINIMIZE DISPLAY VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident. fire or electric shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in fire, etc.
KEEP SMALL OBJECTS SUCH AS BATIERIES OUT OF THE
REACH OF CHILDREN.
Swallowing them may result in serious injury. If swallowed,
consult aphysician immediately.
USE THE CORRECT AMPERE RATING WHEN REPLACING
FUSES.
Failure to do so may result in fire or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result in fire.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in fire,
electric shock or other injury.
DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN
INSERTION SLOTS OR GAPS.
Doing so may result in personal injury or damage to the product.
& CAUTION
This symbol means important instructions.
Failure to heed them can result in injury or
material property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it
to your authorized Alpine dealer or the nearest
Alpine Service Center for repairing.
KEEP FINGERS AWAY WHILE THE MOTORIZED FRONT
PANEL OR MOVING MONITOR IS IN MOTION.
Failure to do so may result in personal injury or damage to the
product.
DO NOT MIX NEW BATIERIES WITH OLD BATTERIES.
INSERT WITH THE CORRECT BATIERY POLARITY.
When inserting the batteries, be sure to observe proper polarity (+
and -) as instructed. Rupture or chemical leakage from the battery
may cause fire or personal injury.
5-EN

New Discs
To prevent the CD from jamming, "DISC ERROR" is displayed if
discs with irregular surfaces are inserted or if discs are inserted
incorrectly. When anew disc is ejected immediately after initial
loading, use your finger to feel around the inside of the center hole
and outside edge of the disc. If you feel any small bumps or
irregularities, this could inhibit proper loading of the disc. To
remove the bumps, rub the inside edge of the hole and outside edge
of the disc with aballpoint pen or other such instrument, then insert
the disc again.
~ PRECAUTIONS
Product Cleaning
Use asoft dry cloth for periodic cleaning of the product. For more
severe stains, please dampen the cloth with water only. Anything
else has the chance'of dissolving the paint or damaging the plastic.
Temperature
Be sure the temperature inside the vehicle is between +4SoC
(+1 13°F) and O°C (+32°F) before turning your unit on.
Moisture Condensation
You may notice the disc playback sound wavering due to
condensation. If this happens, remove the disc from the player and
wait about an hour for the moisture to evaporate.
~ce""HOI'
Bumps
CenterH~1e
'--_ /New Disc
... ~~ -:~' ,..,..."
~._.~r.':::.-
- - "' .............
Outside
(Bumps)
Damaged Disc
Do not attempt to play cracked, warped, or damaged discs. Playing
abad disc could severely damage the playback mechanism.
Maintenance
If you have problems, do not attempt to repair the unit yourself.
Return it to your Alpine dealer or the nearest Alpine Service
Station for servicing.
Never Attempt the Following
Do not grip or pull out the disc while it is being pulled back into the
player by the automatic reloading mechanism.
Do not attempt to insert adisc into the unit when the unit power is
off.
Inserting Discs
Your player accepts only one disc at atime for playback. Do not
attempt to load more than one disc.
Make sure the label side is facing up when you insert the disc,
"DISC ERROR" will be displayed on your player if you insert a
disc incorrectly. If "DISC ERROR" continues to be displayed even
though the disc has been inserted correctly, push the RESET switch
with apointed object such as aballpoint pen.
Playing adisc while driving on avery bumpy road may result in
skips, but this will not scratch the disc or damage the player.
Irregular Shaped Discs
Be sure to use round shaped discs only for this unit and never use
any special shaped discs.
Use of special shaped discs may cause damage to the mechanism.
6-EN
Installation location
Make sure the IVA-WSOS will not be installed in alocation
subjected to:
•Direct sun and heat
•High humidity and water
•Excessive dust
•Excessive vibrations
Correct Handling
Do not drop the disc while handling. Hold the disc so you will not
leave fingerprints on the surface. Do not affix tape, paper, or
gummed labels to the disc. Do not write on the disc.
CORRECT
?f
~
-~
INCORRECT CORRECT
X0
~ ~
<---
Disc Cleaning
Fingerprints, dust, or soil on the surface of the disc could cause the
DVD player to skip. For routine cleaning, wipe the playing surface
with aclean, soft cloth from the center of the disc to the outer edge.
If the surface is heavily soiled, dampen aclean, soft cloth in a
solution of mild neutral detergent before cleaning the disc.
New Discs
To prevent the CD from jamming, "DISC ERROR" is displayed if
discs with irregular surfaces are inserted or if discs are inserted
incorrectly. When anew disc is ejected immediately after initial
loading, use your finger to feel around the inside of the center hole
and outside edge of the disc. If you feel any small bumps or
irregularities, this could inhibit proper loading of the disc. To
remove the bumps, rub the inside edge of the hole and outside edge
of the disc with aballpoint pen or other such instrument, then insert
the disc again.
~ PRECAUTIONS
Product Cleaning
Use asoft dry cloth for periodic cleaning of the product. For more
severe stains, please dampen the cloth with water only. Anything
else has the chance'of dissolving the paint or damaging the plastic.
Temperature
Be sure the temperature inside the vehicle is between +4SoC
(+1 13°F) and O°C (+32°F) before turning your unit on.
Moisture Condensation
You may notice the disc playback sound wavering due to
condensation. If this happens, remove the disc from the player and
wait about an hour for the moisture to evaporate.
~ce""HOI'
Bumps
CenterH~1e
'--_ /New Disc
... ~~ -:~' ,..,..."
~._.~r.':::.-
- - "' .............
Outside
(Bumps)
Damaged Disc
Do not attempt to play cracked, warped, or damaged discs. Playing
abad disc could severely damage the playback mechanism.
Maintenance
If you have problems, do not attempt to repair the unit yourself.
Return it to your Alpine dealer or the nearest Alpine Service
Station for servicing.
Never Attempt the Following
Do not grip or pull out the disc while it is being pulled back into the
player by the automatic reloading mechanism.
Do not attempt to insert adisc into the unit when the unit power is
off.
Inserting Discs
Your player accepts only one disc at atime for playback. Do not
attempt to load more than one disc.
Make sure the label side is facing up when you insert the disc,
"DISC ERROR" will be displayed on your player if you insert a
disc incorrectly. If "DISC ERROR" continues to be displayed even
though the disc has been inserted correctly, push the RESET switch
with apointed object such as aballpoint pen.
Playing adisc while driving on avery bumpy road may result in
skips, but this will not scratch the disc or damage the player.
Irregular Shaped Discs
Be sure to use round shaped discs only for this unit and never use
any special shaped discs.
Use of special shaped discs may cause damage to the mechanism.
6-EN
Installation location
Make sure the IVA-WSOS will not be installed in alocation
subjected to:
•Direct sun and heat
•High humidity and water
•Excessive dust
•Excessive vibrations
Correct Handling
Do not drop the disc while handling. Hold the disc so you will not
leave fingerprints on the surface. Do not affix tape, paper, or
gummed labels to the disc. Do not write on the disc.
CORRECT
?f
~
-~
INCORRECT CORRECT
X0
~ ~
<---
Disc Cleaning
Fingerprints, dust, or soil on the surface of the disc could cause the
DVD player to skip. For routine cleaning, wipe the playing surface
with aclean, soft cloth from the center of the disc to the outer edge.
If the surface is heavily soiled, dampen aclean, soft cloth in a
solution of mild neutral detergent before cleaning the disc.

Alpine products equipped with the Ai-NET bus, connected to the
IVA-W505, can be operated from the IVA-W505. Depending on the
products connected, the functions and displays will vary. For
details, consult your Alpine dealer.
•After turning the system off, aslight ghost
of the image will
remain temporarily. This is an effect peculiar to LCD technology
and is normal.
•In cold temperature conditions, the screen may lose contrast
temporarily. After ashort warm-up period, it will return to
normal.
Mark (logo) Recorded Content Disc size
AM?
12 cm*
DVD Video Audio +Video
VIDEO
8cm
EM?
12 cm*
DVD Audio Audio +Video
AUDIO
8cm
cOJD~~
12 cm
IDIGITAL vlDeol
Video CD Audio +Video
£
8cm
VIDEO CD
ill]o~@
12cm
DIGrrAL AUDIO
Music CD Audio
(ill0§@
8cm
DIGITAL AUIIIO (CD single)
ITEXT I
12 cm
DivX®
..
Audio +Video
8cm
Playable Discs
The discs listed below can be played on this unit.
Discs Playable on This Unit
~.
'.~---' .......•.....
.y .•
f" e", ./~
~"'- ... :." "
Disc Stabilizer
Transparent
Sheet
Operation of some of the functions of this unit is very complex.
Because
of this, it was deemed necessary to place these functions
into aspecial screen. This will restrict operation
of these functions
to times when the vehicle is parked. This ensures the focus of the
driver's attention will be on the road and not on the IVA-W505.
This has been done for the safety
of the driver and passengers.
Audio Processor Adjustments cannot be made
if the car is moving.
The car must be parked and the parking brake must be engaged for
the procedure described in the Owner's Manual to be valid. The
warning
"CAN'T OPERATE WHILE DRIVING" will be
displayed
if any attempts are made to perform these operations
while driving.
Disc Accessories
There are various accessories available on the market for protecting
the disc surface and improving sound quality. However, most
of
them will influence the thickness and/or diameter of the disc. Using
such accessories can cause operational problems.
We recommend
not using these accessories on discs played in Alpine DVD players.
•The IVA-W505 draws minimal current even when its power switch is
turned
off./fthe switched power (ignition) lead of the IVA-W505 is
connecteddirectly to the positive (+) post of the vehicle's battery. the
battery may be discharged.
An
SPST (Single-Pole. Single-Throw) switch (sold separately) can be
added to simplify this procedure. Then. you can simply place it in the
OFF position when you leave the vehicle. Turn the SPST switch back
ON before using the IVA-W505. For connecting the SPST switch.
refer to the "Connection Diagram
of SPST Switch (Sold Separately)"
(page 86).
If the power (ignition) lead is unswitched. it must be
disconnectedfrom the battery post should the vehicle be left unused
for an extendedperiod of time.
*Two-layer DVD disc compatible
The formatted discs listed below can be played on this unit.
CD-RI DVD-RI DVD+RI
CD-RW DVD-RW DVD+RW
CD Format 0
MPS Format ("mpS") 0 0 0
WMA Format ("wma") 0 0 0
AAC Format ("aac". "m4a") 00 0
DVD Video Format 0 0
DVD-VR Format 0
DivX Format ("avi", "divx") 000
Video CD Format 0
•Discs that are not finalized cannot be played back.
7-EN
Alpine products equipped with the Ai-NET bus, connected to the
IVA-W505, can be operated from the IVA-W505. Depending on the
products connected, the functions and displays will vary. For
details, consult your Alpine dealer.
•After turning the system off, aslight ghost
of the image will
remain temporarily. This is an effect peculiar to LCD technology
and is normal.
•In cold temperature conditions, the screen may lose contrast
temporarily. After ashort warm-up period, it will return to
normal.
Mark (logo) Recorded Content Disc size
AM?
12 cm*
DVD Video Audio +Video
VIDEO
8cm
EM?
12 cm*
DVD Audio Audio +Video
AUDIO
8cm
cOJD~~
12 cm
IDIGITAL vlDeol
Video CD Audio +Video
£
8cm
VIDEO CD
ill]o~@
12cm
DIGrrAL AUDIO
Music CD Audio
(ill0§@
8cm
DIGITAL AUIIIO (CD single)
ITEXT I
12 cm
DivX®
..
Audio +Video
8cm
Playable Discs
The discs listed below can be played on this unit.
Discs Playable on This Unit
~.
'.~---' .......•.....
.y .•
f" e", ./~
~"'- ... :." "
Disc Stabilizer
Transparent
Sheet
Operation of some of the functions of this unit is very complex.
Because
of this, it was deemed necessary to place these functions
into aspecial screen. This will restrict operation
of these functions
to times when the vehicle is parked. This ensures the focus of the
driver's attention will be on the road and not on the IVA-W505.
This has been done for the safety
of the driver and passengers.
Audio Processor Adjustments cannot be made
if the car is moving.
The car must be parked and the parking brake must be engaged for
the procedure described in the Owner's Manual to be valid. The
warning
"CAN'T OPERATE WHILE DRIVING" will be
displayed
if any attempts are made to perform these operations
while driving.
Disc Accessories
There are various accessories available on the market for protecting
the disc surface and improving sound quality. However, most
of
them will influence the thickness and/or diameter of the disc. Using
such accessories can cause operational problems.
We recommend
not using these accessories on discs played in Alpine DVD players.
•The IVA-W505 draws minimal current even when its power switch is
turned
off./fthe switched power (ignition) lead of the IVA-W505 is
connecteddirectly to the positive (+) post of the vehicle's battery. the
battery may be discharged.
An
SPST (Single-Pole. Single-Throw) switch (sold separately) can be
added to simplify this procedure. Then. you can simply place it in the
OFF position when you leave the vehicle. Turn the SPST switch back
ON before using the IVA-W505. For connecting the SPST switch.
refer to the "Connection Diagram
of SPST Switch (Sold Separately)"
(page 86).
If the power (ignition) lead is unswitched. it must be
disconnectedfrom the battery post should the vehicle be left unused
for an extendedperiod of time.
*Two-layer DVD disc compatible
The formatted discs listed below can be played on this unit.
CD-RI DVD-RI DVD+RI
CD-RW DVD-RW DVD+RW
CD Format 0
MPS Format ("mpS") 0 0 0
WMA Format ("wma") 0 0 0
AAC Format ("aac". "m4a") 00 0
DVD Video Format 0 0
DVD-VR Format 0
DivX Format ("avi", "divx") 000
Video CD Format 0
•Discs that are not finalized cannot be played back.
7-EN

Discs that cannot be played
DVD-ROMs, DVD-RAMs, CD-ROMs (excluding MP3IWMN
AAC files), photo CDs, etc.
DualDlsc
This unit is not compatible with DualDisc.
Using aDualDisc may cause unit malfunction, and may cause disc
damage when the disc
is inserted/ejected.
DVD region number (playable region number)
This DVD player will play back any disc whose region number is I
(or All). DVDs with aregion number other than those listed below,
cannot be played on this DVD player.
Video CDs
This DVD head unit is compatible with playback control (PBC)
compatible Video CDs (version 2.0).
"PBC"
is afunction by which you can use menu screens recorded
on the disc to find the scene you want to watch and view various
types
of information in dialog style.
Using compact discs (CD/CD-R/CD-RW)
Ifyou use unspecified compact discs, correct performance cannot
be guaranteed.
You can play CD-Rs (CD-Recordables)/CD-RWs (CD-
ReWritables) which have been recorded only on audio devices.
You can also play CD-Rs/CD-RWs containing MP3IWMNAAC
formatted audio files.
oSome of the following discs may not play on this unit:
Flawed discs, discs with fingerprints, discs exposed to extreme
temperatures
or sunlight (e.g .• left in the car or this unit), discs
recorded under unstable conditions, discs on which arecording
failed or are-recording was attempted, copy-protected CDs
which do not conform to the audio
CD industry standard.
Use discs with
MP3IWMNAAC files written in aformat
compliant with this unit. For details, see pages
17 and 18.
To customers using CD-RlCD-RW
oIf aCD-RlCD-RW cannot be played back, make sure the last
recording session was closed (finalized).
oFinalize the CD-RlCD-RW if necessary, and attempt playback
again.
8-EN
Tips for making your own CDs
The IVA-W505 plays DVD Video, DVD Audio, Video CD, Audio
CD and has abuilt in MP3IWMN AAC decoder.
The following information
is designed to help you create your own
music CDs (either Audio
CD or MP3IWMNAAC encoded CD-RI
RW files).
What is the difference between an Audio and MP3IWMAlAAC
CD?
An Audio CD is the same format as the commercial CDs you buy
in the store (also known as CD-DA). MP3 (MPEG-I Audio Layer
3)IWMA (Windows Media Audio)/AAC (Advanced Audio
Coding)
is adata file that uses acompression scheme to reduce the
size
of the music file*.
Hybrid Audio CD and Data (MP3/WMAlAAC) CD-R/RW
discs:
The IVA-W505 can read either sector on the disc. Choose CD-DA
to play the
CD audio section or MP3IWMA/AAC to play the MP3/
WMAIAAC section*.
Multisession CD-R/RW:
Once arecording has been stopped, this is considered one session.
If the disc is not closed (finalized), additional data may be added.
Once this additional data has been recorded, this becomes a
"multisession" CD. The IVA-W505 can only read multisession
DATA Formatted discs (MP3IWMNAAC files -Not Audio CD
files).
Properly formatted MP3IWMAlAAC Discs:
Use IS09660 formatting to insure proper playback. You may use
standard ISO naming Level I(8.3 DOS standard), Level 2(32
characters) or Joliet (Windows
or Macintosh long filenames) file
naming conventions*.
*Please consult the Owner's manual for additional information.
On handling compact discs (CO/CD-R/CD-RW)
oDo not touch the surface.
•Do not expose the disc to direct sunlight.
•Do not affix stickers or labels.
oClean the disc when it is dusty.
oMake sure that the disc is smooth and flat.
oDo not use commercially available disc accessories.
Do not leave the disc in the car or the unit for along time.
Never expose the disc to direct sunlight.
Heat and humidity may damage the disc and you may not be
able to play it again.
Discs that cannot be played
DVD-ROMs, DVD-RAMs, CD-ROMs (excluding MP3IWMN
AAC files), photo CDs, etc.
DualDlsc
This unit is not compatible with DualDisc.
Using aDualDisc may cause unit malfunction, and may cause disc
damage when the disc
is inserted/ejected.
DVD region number (playable region number)
This DVD player will play back any disc whose region number is I
(or All). DVDs with aregion number other than those listed below,
cannot be played on this DVD player.
Video CDs
This DVD head unit is compatible with playback control (PBC)
compatible Video CDs (version 2.0).
"PBC"
is afunction by which you can use menu screens recorded
on the disc to find the scene you want to watch and view various
types
of information in dialog style.
Using compact discs (CD/CD-R/CD-RW)
Ifyou use unspecified compact discs, correct performance cannot
be guaranteed.
You can play CD-Rs (CD-Recordables)/CD-RWs (CD-
ReWritables) which have been recorded only on audio devices.
You can also play CD-Rs/CD-RWs containing MP3IWMNAAC
formatted audio files.
oSome of the following discs may not play on this unit:
Flawed discs, discs with fingerprints, discs exposed to extreme
temperatures
or sunlight (e.g .• left in the car or this unit), discs
recorded under unstable conditions, discs on which arecording
failed or are-recording was attempted, copy-protected CDs
which do not conform to the audio
CD industry standard.
Use discs with
MP3IWMNAAC files written in aformat
compliant with this unit. For details, see pages
17 and 18.
To customers using CD-RlCD-RW
oIf aCD-RlCD-RW cannot be played back, make sure the last
recording session was closed (finalized).
oFinalize the CD-RlCD-RW if necessary, and attempt playback
again.
8-EN
Tips for making your own CDs
The IVA-W505 plays DVD Video, DVD Audio, Video CD, Audio
CD and has abuilt in MP3IWMN AAC decoder.
The following information
is designed to help you create your own
music CDs (either Audio
CD or MP3IWMNAAC encoded CD-RI
RW files).
What is the difference between an Audio and MP3IWMAlAAC
CD?
An Audio CD is the same format as the commercial CDs you buy
in the store (also known as CD-DA). MP3 (MPEG-I Audio Layer
3)IWMA (Windows Media Audio)/AAC (Advanced Audio
Coding)
is adata file that uses acompression scheme to reduce the
size
of the music file*.
Hybrid Audio CD and Data (MP3/WMAlAAC) CD-R/RW
discs:
The IVA-W505 can read either sector on the disc. Choose CD-DA
to play the
CD audio section or MP3IWMA/AAC to play the MP3/
WMAIAAC section*.
Multisession CD-R/RW:
Once arecording has been stopped, this is considered one session.
If the disc is not closed (finalized), additional data may be added.
Once this additional data has been recorded, this becomes a
"multisession" CD. The IVA-W505 can only read multisession
DATA Formatted discs (MP3IWMNAAC files -Not Audio CD
files).
Properly formatted MP3IWMAlAAC Discs:
Use IS09660 formatting to insure proper playback. You may use
standard ISO naming Level I(8.3 DOS standard), Level 2(32
characters) or Joliet (Windows
or Macintosh long filenames) file
naming conventions*.
*Please consult the Owner's manual for additional information.
On handling compact discs (CO/CD-R/CD-RW)
oDo not touch the surface.
•Do not expose the disc to direct sunlight.
•Do not affix stickers or labels.
oClean the disc when it is dusty.
oMake sure that the disc is smooth and flat.
oDo not use commercially available disc accessories.
Do not leave the disc in the car or the unit for along time.
Never expose the disc to direct sunlight.
Heat and humidity may damage the disc and you may not be
able to play it again.

Using DVD·Rs/DVD-RWs/DVD+Rs/DVD+RWs
•This unit is compatible with discs recorded in the standard
DVD-Video and DVD-VR (DVD-RlDVD-RW only) formats.
•Note that discs not finalized (processed to enable to play on
playback-only DVD players) cannot
be played on this DVD
player.
•Some discs may not play back, depending on the recording
device and disc format.
•Discs or files utilizing copy protection, may not be playable.
Some recording systems may not properly format copied files to
enable proper playback.
•In the following cases, the disc may not play on this unit:
discs recorded by certain DVD recorders, certain irregular discs,
flawed discs, dirty discs, when the pickup lens
of this DVD
player
is dirty, or when moisture condensation has occurred
inside the unit.
•Be sure to follow all cautions included with your DVD-Rsl
DVD-RWslDVD+Rs/DVD+RWs discs.
• Do not put stickers, seals, or tape on the label side of DVD-Rsl
DVD-RWsIDVD+RsIDVD+RW
s.
•Compared to the regular discs, DVD-RsIDVD-RWs/DVD+RsI
DVD+RWs are more affected by heat, moisture, and direct
sunlight.
If left in acar, etc., damage may occur and it might not
play on this unit.
•The operable temperature range for disc playback is as follows:
DVD-RlDVD-RW: -25 -+70°C
DVD+RlDVD+RW: +5 -+55°C
Disc terminology
ntle
If titles are programmed for the DVD, these are the largest units of
division of the information recorded on the disc.
Chapter
Each Title may also be divided into smaller divisions, called
chapters. These can be specific scenes
or musical selections.
Protecting the USB connector
•Only an iPod, USB memory or Portable audio player can be
connected to the USB connector on this unit. Correct
performance using other USB products cannot be guaranteed.
• If the USB connector is used, be sure to use only the supplied
connector cable with the unit. AUSB hub is not supported.
•Depending on the connected USB memory device, the unit may
not function or some functions may not be performed.
•The audio file format that can be played back on the unit is
MP31
WMNAAC.
•Artist/song name, etc., can be displayed, however characters
may not be correctly displayed.
LhCAUTION
Alpine accepts no responsibility for lost data. etc .. even ifdata. etc ..
is lost while using this product.
On Handling USB Memory
•This unit can control amemory storage device that supports the
USB Mass Storage Class (MSC) protocol. Playable audio file
formats are MP3, WMA and AAC.
•USB memory function
is not guaranteed. Use USB memory
according to the terms
of agreement. Read the USB memory
Owner's Manual thoroughly.
•Avoid usage or storage in the following locations:
Anywhere in the car exposed to direct sunlight or high
temperatures.
Anywhere the possibility
of high humidity or corrosive
substances are present.
•Fix the USB memory in alocation where driver operation will
not be hindered.
•USB memory may not function correctly at high or low
temperature.
•Use only certified USB memory. Note that even certified USB
memory, may not function correctly depending on its type or
state.
•Depending on the settings
of the USB memory type, memory
state or encoding software, the unit may not play back ordisplay
properly.
•Files protected by DRM (Digital Rights Management), cannot be
played back on this unit. These include AAC formatted files
purchased from the iTunes Store and WMA or other files with
some form of copyright protection.
•USB memory may take time to start playback.
If there is a
particular file other than audio in the USB memory, it may take
considerable time before the file
is played back or searched.
•The unit can play back "mp3", "wma" or "m4a" file extensions.
•Do not add the above extensions to afile other than audio data.
This non-audio data will not be recognized. The resulting
playback may contain noise that can damage speakers and/or
amplifiers.
•It is recommended to back up important data on apersonal
computer.
•Do not remove the USB device while playback
is in progress.
Change SOURCE to something other than USB, then remove the
USB device to prevent possible damage to its memory.
On Handling Portable audio player
•The unit can control aPortable audio player with the USB
interface. Playable audio file formats are MP3 and WMA.
•Portable audio player function is not guaranteed. Use Portable
audio player according to the terms
of agreement. Read the
Portable audio player Owner's Manual thoroughly.
•Avoid usage or storage in the following locations:
Anywhere
in the car exposed to direct sunlight or high
temperatures.
Anywhere the possibility of high humidity or corrosive
substances are present.
•Fix the Portable audio player in alocation where driver operation
will not be hindered.
•Portable audio player may not function correctly at high
or low
temperature.
•Depending on the settings
of the Portable audio player type,
memory state or encoding software, the unit may not play back
or display properly.
9-EN
Using DVD·Rs/DVD-RWs/DVD+Rs/DVD+RWs
•This unit is compatible with discs recorded in the standard
DVD-Video and DVD-VR (DVD-RlDVD-RW only) formats.
•Note that discs not finalized (processed to enable to play on
playback-only DVD players) cannot
be played on this DVD
player.
•Some discs may not play back, depending on the recording
device and disc format.
•Discs or files utilizing copy protection, may not be playable.
Some recording systems may not properly format copied files to
enable proper playback.
•In the following cases, the disc may not play on this unit:
discs recorded by certain DVD recorders, certain irregular discs,
flawed discs, dirty discs, when the pickup lens
of this DVD
player
is dirty, or when moisture condensation has occurred
inside the unit.
•Be sure to follow all cautions included with your DVD-Rsl
DVD-RWslDVD+Rs/DVD+RWs discs.
• Do not put stickers, seals, or tape on the label side of DVD-Rsl
DVD-RWsIDVD+RsIDVD+RW
s.
•Compared to the regular discs, DVD-RsIDVD-RWs/DVD+RsI
DVD+RWs are more affected by heat, moisture, and direct
sunlight.
If left in acar, etc., damage may occur and it might not
play on this unit.
•The operable temperature range for disc playback is as follows:
DVD-RlDVD-RW: -25 -+70°C
DVD+RlDVD+RW: +5 -+55°C
Disc terminology
ntle
If titles are programmed for the DVD, these are the largest units of
division of the information recorded on the disc.
Chapter
Each Title may also be divided into smaller divisions, called
chapters. These can be specific scenes
or musical selections.
Protecting the USB connector
•Only an iPod, USB memory or Portable audio player can be
connected to the USB connector on this unit. Correct
performance using other USB products cannot be guaranteed.
• If the USB connector is used, be sure to use only the supplied
connector cable with the unit. AUSB hub is not supported.
•Depending on the connected USB memory device, the unit may
not function or some functions may not be performed.
•The audio file format that can be played back on the unit is
MP31
WMNAAC.
•Artist/song name, etc., can be displayed, however characters
may not be correctly displayed.
LhCAUTION
Alpine accepts no responsibility for lost data. etc .. even ifdata. etc ..
is lost while using this product.
On Handling USB Memory
•This unit can control amemory storage device that supports the
USB Mass Storage Class (MSC) protocol. Playable audio file
formats are MP3, WMA and AAC.
•USB memory function
is not guaranteed. Use USB memory
according to the terms
of agreement. Read the USB memory
Owner's Manual thoroughly.
•Avoid usage or storage in the following locations:
Anywhere in the car exposed to direct sunlight or high
temperatures.
Anywhere the possibility
of high humidity or corrosive
substances are present.
•Fix the USB memory in alocation where driver operation will
not be hindered.
•USB memory may not function correctly at high or low
temperature.
•Use only certified USB memory. Note that even certified USB
memory, may not function correctly depending on its type or
state.
•Depending on the settings
of the USB memory type, memory
state or encoding software, the unit may not play back ordisplay
properly.
•Files protected by DRM (Digital Rights Management), cannot be
played back on this unit. These include AAC formatted files
purchased from the iTunes Store and WMA or other files with
some form of copyright protection.
•USB memory may take time to start playback.
If there is a
particular file other than audio in the USB memory, it may take
considerable time before the file
is played back or searched.
•The unit can play back "mp3", "wma" or "m4a" file extensions.
•Do not add the above extensions to afile other than audio data.
This non-audio data will not be recognized. The resulting
playback may contain noise that can damage speakers and/or
amplifiers.
•It is recommended to back up important data on apersonal
computer.
•Do not remove the USB device while playback
is in progress.
Change SOURCE to something other than USB, then remove the
USB device to prevent possible damage to its memory.
On Handling Portable audio player
•The unit can control aPortable audio player with the USB
interface. Playable audio file formats are MP3 and WMA.
•Portable audio player function is not guaranteed. Use Portable
audio player according to the terms
of agreement. Read the
Portable audio player Owner's Manual thoroughly.
•Avoid usage or storage in the following locations:
Anywhere
in the car exposed to direct sunlight or high
temperatures.
Anywhere the possibility of high humidity or corrosive
substances are present.
•Fix the Portable audio player in alocation where driver operation
will not be hindered.
•Portable audio player may not function correctly at high
or low
temperature.
•Depending on the settings
of the Portable audio player type,
memory state or encoding software, the unit may not play back
or display properly.
9-EN

o If the Portable audio player has an MSC/MTP setting, set to
MTP.
oAPortable audio player in which data is stored by USB Mass
Storage may not be playable on the unit.
oDepending on the Portable audio player settings, USB Mass
Storage may be supported. For setting, refer to the
Owner's
Manual of the player.
oThe unit can play back MP3IWMA files synchronized by
Windows Media Player (Ver.
10 or II), and are then forwarded
to the player. The
"mp3" or "wma" extensions are playable.
o If data is not synchronized by Windows Media Player and is
forwarded in another way, the unit may not be able to correctly
play back the files.
o WMDRM 10 is supported by the unit.
oAfile that is copy-protected (copyright protection) cannot be
played back.
o It is recommended to back up important data on apersonal
computer.
•Do not remove the USB device while playback is in progress.
Change SOURCE to something other than USB, then remove the
USB device to prevent possible damage to its memory.
lO-EN
•This product incorporates copyright protection technology that
is protected by U.S. patents and other intellectual property
rights. Use
of this copyright protection technology must be
authorized by Macrovision, and is intendedfor home andother
limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering
or disassembly is prohibited.
•Manufactured under licensefrom Dolby Laboratories. Dolby
and the double·D symbolare trademarks of Dolby
Laboratories.
oManufactured under license under U.S. Patent #'s: 5,451,942;
5,956,674; 5,974,380; 5,978,762; 6,487,535 &other U.S.
and
worldwide patents issued &pending. DTS and DTS 2.0 +
Digital Out are registered trademarks and the DTS logos and
Symbolare trademarks of DTS, Inc. ©1996-2007DTS, Inc.
All Rights Reserved.
oWindows Media and the Windows logo are trademarks, or
registered trademarks of Microsoft Corporation in the United
States and/orother countries.
oiPod is atrademark of Apple Inc., registered in the U.S. and
othercountries.
•HD
Radio™ and the HD Radio Ready logo are proprietary
trademarks
of iBiquity Digital Corp.
•
"MPEG Layer-3 audio coding technology licensedfrom
Fraunhofer
liS and Thomson."
•"Supply
of this productonly conveys alicense for private, non-
commercial use
and does not convey alicense nor imply any
right to use this productin any commercial (i.e. revenue-
generation) real time broadcasting (terrestrial, satellite, cable
and/or any other media), broadcasting/streaming via internet,
intranets and/orother networks or in otherelectronic content
distribution systems, such as pay-audio oraudio-on-demand
applications.
An independentlicense for such use is required.
For details, please visit http://www.mp3licensing.com..
•Audyssey MultEQ
XT is aregistered trademark of Audyssey
Laboratories
Inc ..
• LL.C. (Linear Luminance Control) uses technology provided
by !Apical Limited,
U.K.
o If the Portable audio player has an MSC/MTP setting, set to
MTP.
oAPortable audio player in which data is stored by USB Mass
Storage may not be playable on the unit.
oDepending on the Portable audio player settings, USB Mass
Storage may be supported. For setting, refer to the
Owner's
Manual of the player.
oThe unit can play back MP3IWMA files synchronized by
Windows Media Player (Ver.
10 or II), and are then forwarded
to the player. The
"mp3" or "wma" extensions are playable.
o If data is not synchronized by Windows Media Player and is
forwarded in another way, the unit may not be able to correctly
play back the files.
o WMDRM 10 is supported by the unit.
oAfile that is copy-protected (copyright protection) cannot be
played back.
o It is recommended to back up important data on apersonal
computer.
•Do not remove the USB device while playback is in progress.
Change SOURCE to something other than USB, then remove the
USB device to prevent possible damage to its memory.
lO-EN
•This product incorporates copyright protection technology that
is protected by U.S. patents and other intellectual property
rights. Use
of this copyright protection technology must be
authorized by Macrovision, and is intendedfor home andother
limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering
or disassembly is prohibited.
•Manufactured under licensefrom Dolby Laboratories. Dolby
and the double·D symbolare trademarks of Dolby
Laboratories.
oManufactured under license under U.S. Patent #'s: 5,451,942;
5,956,674; 5,974,380; 5,978,762; 6,487,535 &other U.S.
and
worldwide patents issued &pending. DTS and DTS 2.0 +
Digital Out are registered trademarks and the DTS logos and
Symbolare trademarks of DTS, Inc. ©1996-2007DTS, Inc.
All Rights Reserved.
oWindows Media and the Windows logo are trademarks, or
registered trademarks of Microsoft Corporation in the United
States and/orother countries.
oiPod is atrademark of Apple Inc., registered in the U.S. and
othercountries.
•HD
Radio™ and the HD Radio Ready logo are proprietary
trademarks
of iBiquity Digital Corp.
•
"MPEG Layer-3 audio coding technology licensedfrom
Fraunhofer
liS and Thomson."
•"Supply
of this productonly conveys alicense for private, non-
commercial use
and does not convey alicense nor imply any
right to use this productin any commercial (i.e. revenue-
generation) real time broadcasting (terrestrial, satellite, cable
and/or any other media), broadcasting/streaming via internet,
intranets and/orother networks or in otherelectronic content
distribution systems, such as pay-audio oraudio-on-demand
applications.
An independentlicense for such use is required.
For details, please visit http://www.mp3licensing.com..
•Audyssey MultEQ
XT is aregistered trademark of Audyssey
Laboratories
Inc ..
• LL.C. (Linear Luminance Control) uses technology provided
by !Apical Limited,
U.K.

Getting Started
Accessory List
•Head unit 1
•Power cable 1
•Mounting sleeve 1
•Bracket key 2
•Flush Head Screw (M5x8) 6
•Screw (M5x8) 8
•Remote control 1
•Battery (CR2025) 1
•Face plate 1
•Mounting Position Seal 2
•Slot Securing Screw (M2 x 4)* 2
•Pre OUT Cable 1
•AUX I/O Cable 1
• AV extension cable 1
•USB extension cable 1
•USB 30P cable 1
•Owner's Manual 1set
* To customers who do not use an optional portable navigation:
Ifnecessary, secure the slot panel with this screw.
Optional Remote Control Interface Box
This unit is operable using the vehicle's secondary radio controls.
An Alpine Remote Control Interface Box (optional)
is required. For
details, contact your Alpine dealer.
Location of Controls
G) Remote Sensor
Point the supplied remote control transmitter towards the
remote sensor within arange of 2meters.
®V / /\. button
Press to adjust the volume.
@MUTE button
Lowers the volume by 20 dB instantly. Press the button
again to cancel.
@*(OPTION) button
Press to recall the setting which is set in "Setting the VISUAL
Soft Button" (page 39).
If "V. SEL" is set, the VISUAL SETUP screen will be recalled.
If "SAT" is set, the weather channel or traffic channel will be
recalled (when the XM or SIRIUS Receiver Box is
connected).
If "TEL" is set, the TEL Bluetooth screen will be recalled
(when the optional Bluetooth Box is connected).
@IMPRINT/AUDIO button
Press to recall the IMPRINT operation screen. (When the
optional IMPRINT audio processor (PXA-H100) is
connected).
Pressing and holding for at least 2seconds will recall the
AUDIO SETUP screen.
@ SOURCEI<!> button
Turns the power on. Press and hold for at least 2seconds to
turn the power off.
Recalls the SOURCE selection screen.
(j) OPEN button
Recalls the EJECTfTlLT screen.
If the disc does not eject after touching [EJECT) of DISC,
press and hold OPEN for at least 3seconds.
@RESET switch
Be sure to press the RESET switch when using the unit for
the first time, after installing the CD changer, after changing
the car battery, etc.
Turn off the unit power, press RESET with aballpoint pen or
similar pointed object.
®DOCK indicator
Lights when aportable navigation device is inserted into the
unit.
About the button descriptions used in this Owner's
Manual
•The buttonsfound on the face of the unit are expressed in bold
(e.g. SOURCEIcJ). The buttonsfound on the touch-screen
display are shown in bold within brackets, [ ]
(e.g. [SOURCE]).
•This Owner's Manual explains mainly thefunction
of soft
buttons, when asoft button
and aunit button have the same
function.
Turning Power On or Off
Some ofthis unit's functions cannot be performed while the vehicle is in
motion. Be sure to stop your vehicle in asafe location and apply the
parking brake, before attempting these operations.
1Press SOURCEI<!> to turn on the unit.
•The unit can be turned on by pressing any button.
2Press and hold SOURCEI<!> for at least 2seconds to
turn off the unit.
•Some operation of the unit cannot beperformed while the vehicle is
in motion. In this case, be sure tofirst stop yourvehicle andapply the
parking brake, then perform the operation.
•The IVA-W505 is aprecision device. With gentle handling, its unique
capabilities can be enjoyed
for along time.
ii-EN
Getting Started
Accessory List
•Head unit 1
•Power cable 1
•Mounting sleeve 1
•Bracket key 2
•Flush Head Screw (M5x8) 6
•Screw (M5x8) 8
•Remote control 1
•Battery (CR2025) 1
•Face plate 1
•Mounting Position Seal 2
•Slot Securing Screw (M2 x 4)* 2
•Pre OUT Cable 1
•AUX I/O Cable 1
• AV extension cable 1
•USB extension cable 1
•USB 30P cable 1
•Owner's Manual 1set
* To customers who do not use an optional portable navigation:
Ifnecessary, secure the slot panel with this screw.
Optional Remote Control Interface Box
This unit is operable using the vehicle's secondary radio controls.
An Alpine Remote Control Interface Box (optional)
is required. For
details, contact your Alpine dealer.
Location of Controls
G) Remote Sensor
Point the supplied remote control transmitter towards the
remote sensor within arange of 2meters.
®V / /\. button
Press to adjust the volume.
@MUTE button
Lowers the volume by 20 dB instantly. Press the button
again to cancel.
@*(OPTION) button
Press to recall the setting which is set in "Setting the VISUAL
Soft Button" (page 39).
If "V. SEL" is set, the VISUAL SETUP screen will be recalled.
If "SAT" is set, the weather channel or traffic channel will be
recalled (when the XM or SIRIUS Receiver Box is
connected).
If "TEL" is set, the TEL Bluetooth screen will be recalled
(when the optional Bluetooth Box is connected).
@IMPRINT/AUDIO button
Press to recall the IMPRINT operation screen. (When the
optional IMPRINT audio processor (PXA-H100) is
connected).
Pressing and holding for at least 2seconds will recall the
AUDIO SETUP screen.
@ SOURCEI<!> button
Turns the power on. Press and hold for at least 2seconds to
turn the power off.
Recalls the SOURCE selection screen.
(j) OPEN button
Recalls the EJECTfTlLT screen.
If the disc does not eject after touching [EJECT) of DISC,
press and hold OPEN for at least 3seconds.
@RESET switch
Be sure to press the RESET switch when using the unit for
the first time, after installing the CD changer, after changing
the car battery, etc.
Turn off the unit power, press RESET with aballpoint pen or
similar pointed object.
®DOCK indicator
Lights when aportable navigation device is inserted into the
unit.
About the button descriptions used in this Owner's
Manual
•The buttonsfound on the face of the unit are expressed in bold
(e.g. SOURCEIcJ). The buttonsfound on the touch-screen
display are shown in bold within brackets, [ ]
(e.g. [SOURCE]).
•This Owner's Manual explains mainly thefunction
of soft
buttons, when asoft button
and aunit button have the same
function.
Turning Power On or Off
Some ofthis unit's functions cannot be performed while the vehicle is in
motion. Be sure to stop your vehicle in asafe location and apply the
parking brake, before attempting these operations.
1Press SOURCEI<!> to turn on the unit.
•The unit can be turned on by pressing any button.
2Press and hold SOURCEI<!> for at least 2seconds to
turn off the unit.
•Some operation of the unit cannot beperformed while the vehicle is
in motion. In this case, be sure tofirst stop yourvehicle andapply the
parking brake, then perform the operation.
•The IVA-W505 is aprecision device. With gentle handling, its unique
capabilities can be enjoyed
for along time.
ii-EN

Inserting/Ejecting a Disc
1Press OPEN on the unit.
The display changes to the EJECTfTlLT screen.
2Insert adisc:
Touch [OPEN] on the EJECTfTlLT screen.
The movable monitor will open, then insert adisc into the
disc slot. Inserting adisc will close the monitor
automatically.
Eject the disc:
Touch [EJECT] of DISC on the EJECTfTlLT screen.
The movable monitor will open. Then the disc
is ejected.
3Touch [CLOSE] on the EJECTmLT screen.
The movable monitor will close.
oTouching [~J returns to the earlier main source screen.
oDo not apply shock to the movable monitor when it is open as it may
result
in malfunction of the unit.
oThe monitormay be dim during low temperature and immediately
after turning on the power. The brightness will return to normal as
time elapses.
oThe monitor will stop at the set tilt angle when closing.
CAUTION
Keep hands (or any other object) awayfrom the monitor while it
is opening
or closing to avoid damage or injury. The back of the
movable monitor will get very warm under
nonnal operating
conditions. This is not amalfunction. Do not touch.
Adjusting the Monitor Viewing Angle
Adjust the monitor's angle for better visibility.
1Press OPEN on the unit.
The display changes to the EJECTfTlLT screen.
2Touch [oA] or [~] of TILT to adjust the desired
monitor angle.
The monitor angle can be adjusted in 5stages.
3Touch [~] to return to the previous screen.
o If the monitor touches an obstacle while the angle is being adjusted,
it will stop immediately.
oThe screen color will vary when viewedat certain angles. Adjust the
screen angle
for the best viewing position.
o If the voltage of the vehicle's battery poweris low. the screen may
blink when the screen angle is changed. This is
nonnal and nota
malfunction.
oTouching and holding [~J for at least 2seconds will change to the
main source screen.
12-EN
Adjusting the Volume
Adjust the volume by pressing V or /'\.
Volume decreases/increases continuously by pressing and
holding Vor
/'\.
Volume: 0 - 35
Lowering Volume Quickly
Activating the Audio Mute function will instantly lower the volume
level
by 20 dB.
Press MUTE to activate the MUTE mode.
The audio level will decrease by about 20 dB.
Pressing MUTE again will bring the audio back to its
previous level.
How to view the Display
o Be sure to touch the button lightly with the pad of yourfinger on the
display to protect the display.
o If you touch abutton and there is no reaction, remove yourfinger
from the display.
and try again.
About the button descriptions usedIn this Owner's Manual
oSoft buttons, onesfound in the display, are shown in bold
enclosed in brackets, [J(e.g. [SOURCE]).
oWhenever asoft button and aheadunit button have the same
function, the explanations in this Owner's Manual will describe
the function
of the soft button.
Here is an example explanation for the Radio mode display on how to
recall asource.
1Touch [SOURCE] on the main screen.
The SOURCE selection screen is displayed.
Displayexample for SOURCE selection screen
0a9
SOURCE VISUAL SETUP
SOURCE
SEL.
ESC
ill'
RADIO
D!SC USB AUOIO
-""-"
,-
rJ
~
12:34
:1ll'JlniI'Jcf1
=' RSE
CD Changes to VISUAL selection screen.
Set to VISUAL
in "Setting the VISUAL Soft Button"
(on page 39).
® Changes to SETUP selection screen.
@ Changes to main source screen.
@ Displays source modes that can be selected
(The kind of source modes that are displayed varies
depending on connection and setting).
Inserting/Ejecting a Disc
1Press OPEN on the unit.
The display changes to the EJECTfTlLT screen.
2Insert adisc:
Touch [OPEN] on the EJECTfTlLT screen.
The movable monitor will open, then insert adisc into the
disc slot. Inserting adisc will close the monitor
automatically.
Eject the disc:
Touch [EJECT] of DISC on the EJECTfTlLT screen.
The movable monitor will open. Then the disc
is ejected.
3Touch [CLOSE] on the EJECTmLT screen.
The movable monitor will close.
oTouching [~J returns to the earlier main source screen.
oDo not apply shock to the movable monitor when it is open as it may
result
in malfunction of the unit.
oThe monitormay be dim during low temperature and immediately
after turning on the power. The brightness will return to normal as
time elapses.
oThe monitor will stop at the set tilt angle when closing.
CAUTION
Keep hands (or any other object) awayfrom the monitor while it
is opening
or closing to avoid damage or injury. The back of the
movable monitor will get very warm under
nonnal operating
conditions. This is not amalfunction. Do not touch.
Adjusting the Monitor Viewing Angle
Adjust the monitor's angle for better visibility.
1Press OPEN on the unit.
The display changes to the EJECTfTlLT screen.
2Touch [oA] or [~] of TILT to adjust the desired
monitor angle.
The monitor angle can be adjusted in 5stages.
3Touch [~] to return to the previous screen.
o If the monitor touches an obstacle while the angle is being adjusted,
it will stop immediately.
oThe screen color will vary when viewedat certain angles. Adjust the
screen angle
for the best viewing position.
o If the voltage of the vehicle's battery poweris low. the screen may
blink when the screen angle is changed. This is
nonnal and nota
malfunction.
oTouching and holding [~J for at least 2seconds will change to the
main source screen.
12-EN
Adjusting the Volume
Adjust the volume by pressing V or /'\.
Volume decreases/increases continuously by pressing and
holding Vor
/'\.
Volume: 0 - 35
Lowering Volume Quickly
Activating the Audio Mute function will instantly lower the volume
level
by 20 dB.
Press MUTE to activate the MUTE mode.
The audio level will decrease by about 20 dB.
Pressing MUTE again will bring the audio back to its
previous level.
How to view the Display
o Be sure to touch the button lightly with the pad of yourfinger on the
display to protect the display.
o If you touch abutton and there is no reaction, remove yourfinger
from the display.
and try again.
About the button descriptions usedIn this Owner's Manual
oSoft buttons, onesfound in the display, are shown in bold
enclosed in brackets, [J(e.g. [SOURCE]).
oWhenever asoft button and aheadunit button have the same
function, the explanations in this Owner's Manual will describe
the function
of the soft button.
Here is an example explanation for the Radio mode display on how to
recall asource.
1Touch [SOURCE] on the main screen.
The SOURCE selection screen is displayed.
Displayexample for SOURCE selection screen
0a9
SOURCE VISUAL SETUP
SOURCE
SEL.
ESC
ill'
RADIO
D!SC USB AUOIO
-""-"
,-
rJ
~
12:34
:1ll'JlniI'Jcf1
=' RSE
CD Changes to VISUAL selection screen.
Set to VISUAL
in "Setting the VISUAL Soft Button"
(on page 39).
® Changes to SETUP selection screen.
@ Changes to main source screen.
@ Displays source modes that can be selected
(The kind of source modes that are displayed varies
depending on connection and setting).

@Returns to the previous screen.
®Changes to the REAR selection screen when "Setting
the Picture Output" (page 39) is set to ON.
@The information about the current source.
e.g.
The DISC image, Track NO. and Track time will be
displayed in DISC mode.
2Touch [RADIO].
The screen changes to the Radio mode main display.
Display example for FM Radio main screen
(j) Changes to the SOURCE selection screen (to Step 1
screen)
®Displays the source name, such as radio band, etc.,
that is selected
®Changes the display style, refer to "Selecting the
Display Style" (on
page 14).
@Display time and volume level
@Function Guide:
The function guide display varies depending on each
source.
The contents of the function guide change by touching
[P1/21* or [P1/31* on the function guide, and many other
operations can be performed.
*Display may vary depending on the connected devices.
3Touch [SOURCE] on the main source screen to
change to another source screen, and select the
desired source from the SOURCE selection screen.
•After5seconds of each operation in the visual mode, the screen
changes to the visual screen only.
To display the main source screen. touch the display panel. then
touch [ESC] on the screen. The SOURCE selection screen appears
by touching [SOURCE] on the changed main source screen.
The numeric keypad input screen
is displayed when the DVD mode is
selected for searching atitle or chapter. Itcan also be used for entering a
country code or password for DVD setup. and for selecting achannel
number
in the SAT Radio mode etc.
1Touch [10KEY] on the main source screen.
2Touch the desired numeric key.
Displayexample for numeric keypad
7
CD Operation buttons of this area can be used while
displaying the numeric keypad input screen.
@> Input screen area
®Closes numeric keypad input screen
@All input numbers will be deleted
@Previous number will be deleted
®Input number is confirmed
(j) Numeric keypad
®The numeric keypad input screen closes when the area
is touched while displayed.
3Touch [ENT] to confirm your entry.
13-EN
@Returns to the previous screen.
®Changes to the REAR selection screen when "Setting
the Picture Output" (page 39) is set to ON.
@The information about the current source.
e.g.
The DISC image, Track NO. and Track time will be
displayed in DISC mode.
2Touch [RADIO].
The screen changes to the Radio mode main display.
Display example for FM Radio main screen
(j) Changes to the SOURCE selection screen (to Step 1
screen)
®Displays the source name, such as radio band, etc.,
that is selected
®Changes the display style, refer to "Selecting the
Display Style" (on
page 14).
@Display time and volume level
@Function Guide:
The function guide display varies depending on each
source.
The contents of the function guide change by touching
[P1/21* or [P1/31* on the function guide, and many other
operations can be performed.
*Display may vary depending on the connected devices.
3Touch [SOURCE] on the main source screen to
change to another source screen, and select the
desired source from the SOURCE selection screen.
•After5seconds of each operation in the visual mode, the screen
changes to the visual screen only.
To display the main source screen. touch the display panel. then
touch [ESC] on the screen. The SOURCE selection screen appears
by touching [SOURCE] on the changed main source screen.
The numeric keypad input screen
is displayed when the DVD mode is
selected for searching atitle or chapter. Itcan also be used for entering a
country code or password for DVD setup. and for selecting achannel
number
in the SAT Radio mode etc.
1Touch [10KEY] on the main source screen.
2Touch the desired numeric key.
Displayexample for numeric keypad
7
CD Operation buttons of this area can be used while
displaying the numeric keypad input screen.
@> Input screen area
®Closes numeric keypad input screen
@All input numbers will be deleted
@Previous number will be deleted
®Input number is confirmed
(j) Numeric keypad
®The numeric keypad input screen closes when the area
is touched while displayed.
3Touch [ENT] to confirm your entry.
13-EN

You can change the style of display by touching [Style) in nonnal mode
of every source.
Style I(Initial) HStyle 2
Displayexample for IPod main screen
3
CD Changes to the L.L .C. adjustment screen (Only for
visual source) directly, refer to
page 40.
@Changes to the Bass*}, Treble*} and Subwoofer,.2 Level
adjustment screen directly.
When an optional external audio processor with the
MEDIA XPANDER function is connected to this unit and
Defeat is set to
OFF, MEDIA XPANDER level may be also
adjusted directly.
• If the optional IMPRINTaudio processor (PXA-Hl00) is
connected, MultEQ must also be set to
OFF to adjust the
MEDIA XPANDER directly.
*1 Adjustment cannot be performed when DEFEATis set to ON.
,.2 Adjustment cannot be performed when SUBWOOFER is set to OFF
(page 26).
®Displays the next 5songs' name (Only for the USB
AUDIO and iPod mode).
<Style 2>
@Displays the image of the current source.
• If the playing song contains artwork, the artwork can be
displayed in @(Only for USB AUDIO,.] and iPod..-l mode).
,.] USB memory is connected by using USB connector and only JPEG
or BMP (565formatted only) pictures that are smaller than 80 KB
can be displayed.
..-I iPod is connected by using the USB connector.
14-EN
Radio
Displayexample for FM Radio main screen
5
CD [SOURCE] button: Refer to page 12
@[VISUAL] button: Displays the VISUAL selection screen
®[SETUP] button: Displays the SETUP selection screen
@[Style] button: Refer to page 14
@[DX SEEK]* button: Displays the tuning mode selection
list.
@Displays the preset number/frequency
This unit cannot receive HD Radio signals (digital terrestrial radio).
In order to activate the digital radio functions described below, an
optional HD Radio Tuner module must be connected through the Ai-
NET bus.
Listening to the Radio
1Touch [SOURCE] on the main source screen.
The SOURCE selection screen is displayed.
Receiving Analog Radio:
2Touch [RADIO].
The radio mode is activated and the display changes to the
Radio Mode screen.
Receiving HD Radio (if TUA-T500HD is connected):
2Touch [HD RADIO].
The digital radio mode is activated and the display changes
to the HD Radio Tuner Mode screen.
3Touch [BAND] to select the desired radio band.
Each press changes the bands as follows:
FM-1 ~ FM-2 ~ AM ~ FM-1
4Touch [DX SEEK]* to choose the tuning mode.
DX SEEK Local SEEK MANUAL
1 .... 1 I~I 1 .... 1 I~I I~I ' .. I
•There are two modes you can select for auto tuning. OX and
Local:
-OX(Distance) mode;
Both strong and weak stations will be tuned in.
-Local mode;
Only strong stations will be tuned
in.
The initial setting is ox.
*The button displays the current tuning mode.
You can change the style of display by touching [Style) in nonnal mode
of every source.
Style I(Initial) HStyle 2
Displayexample for IPod main screen
3
CD Changes to the L.L .C. adjustment screen (Only for
visual source) directly, refer to
page 40.
@Changes to the Bass*}, Treble*} and Subwoofer,.2 Level
adjustment screen directly.
When an optional external audio processor with the
MEDIA XPANDER function is connected to this unit and
Defeat is set to
OFF, MEDIA XPANDER level may be also
adjusted directly.
• If the optional IMPRINTaudio processor (PXA-Hl00) is
connected, MultEQ must also be set to
OFF to adjust the
MEDIA XPANDER directly.
*1 Adjustment cannot be performed when DEFEATis set to ON.
,.2 Adjustment cannot be performed when SUBWOOFER is set to OFF
(page 26).
®Displays the next 5songs' name (Only for the USB
AUDIO and iPod mode).
<Style 2>
@Displays the image of the current source.
• If the playing song contains artwork, the artwork can be
displayed in @(Only for USB AUDIO,.] and iPod..-l mode).
,.] USB memory is connected by using USB connector and only JPEG
or BMP (565formatted only) pictures that are smaller than 80 KB
can be displayed.
..-I iPod is connected by using the USB connector.
14-EN
Radio
Displayexample for FM Radio main screen
5
CD [SOURCE] button: Refer to page 12
@[VISUAL] button: Displays the VISUAL selection screen
®[SETUP] button: Displays the SETUP selection screen
@[Style] button: Refer to page 14
@[DX SEEK]* button: Displays the tuning mode selection
list.
@Displays the preset number/frequency
This unit cannot receive HD Radio signals (digital terrestrial radio).
In order to activate the digital radio functions described below, an
optional HD Radio Tuner module must be connected through the Ai-
NET bus.
Listening to the Radio
1Touch [SOURCE] on the main source screen.
The SOURCE selection screen is displayed.
Receiving Analog Radio:
2Touch [RADIO].
The radio mode is activated and the display changes to the
Radio Mode screen.
Receiving HD Radio (if TUA-T500HD is connected):
2Touch [HD RADIO].
The digital radio mode is activated and the display changes
to the HD Radio Tuner Mode screen.
3Touch [BAND] to select the desired radio band.
Each press changes the bands as follows:
FM-1 ~ FM-2 ~ AM ~ FM-1
4Touch [DX SEEK]* to choose the tuning mode.
DX SEEK Local SEEK MANUAL
1 .... 1 I~I 1 .... 1 I~I I~I ' .. I
•There are two modes you can select for auto tuning. OX and
Local:
-OX(Distance) mode;
Both strong and weak stations will be tuned in.
-Local mode;
Only strong stations will be tuned
in.
The initial setting is ox.
*The button displays the current tuning mode.

5Touch [ ..... ]. [~]or["]. ["]to change the
radio frequency up or down respectively.
In manual mode, touch and hold to change the frequency
continuously.
•"DIGITAL" is displayed when adigital radio station is received.
•Refer to "Digital SEEK Setting (HD Radio mode only)" on page
34.
Presetting Stations Manually
1Tune in adesired radio station you wish to store in
the preset memory by manual or automatic seek
tuning.
2Touch [P1/2]* to change the function guide.
*[P 113} is displayed in the HD Radio mode.
3Touch and hold anyone of the preset buttons
[P.SET 1] through [P.SET 6] for at least 2seconds.
The selected station is stored.
4Repeat the procedure to store up to 5other stations
onto the same band.
To use this procedure for other bands, simply select the
desired band and repeat the procedure.
Atotal of 18 stations can be stored in the preset memory
(6 stations for each band; FM1, FM2 or AM).
• If apreset memory has already been setin the same preset number, it
will be cleared
and the new station will be memorized.
Presetting Stations Automatically
The tuner can automatically seek and store 6strong stations in the
selected band in order
of signal strength.
After selecting the desired band. touch [A. MEMO].
The tuner automatically seeks and stores 6strong stations into
[P.SET 1] to [P.SET 6] in order of signal strength.
When the automatic storing has been completed, the tuner goes
to the station stored in [P.SET 1].
• If no stations are stored. the tuner will return to the original station
you were listening to before the automatic storing procedure began.
Tuning to Preset Stations
You can tune in the preset stations in memory on each band using the
preset number.
1After selecting the desired band, touch [P1/2]* to
change the function guide.
*[P 113} is displayed in the HD Radio mode.
2Touch anyone of the preset buttons [P.SET 1]
through [P.SET 6] that has astation stored to it.
The preset station is received.
Changing the Display (HD Radio mode
only)
Text information, such as Station name, Song title, Artist, etc., is
displayed while receiving adigital radio station.
Touch [INFO.] on the HD Radio Tuner mode main
screen.
Each time you touch this button, the display changes as shown
below.
Short Station Name *J
Song IiIle *2
- - - - - - - - - - ~ Long Station Name *J
Artist *2
----------
Album *2
*1 Displays Short Station Name /Long Station Name in the Station
Information Service Data.
~ Displays Song title /Artist/Album in the main program Service
Data.
Receiving a Multicast (HD Radio mode
only)
Multicasting is the ability to broadcast multiple program streams over a
single FM frequency. This increases the amount and diversity
of content
choices. Amaximum
of eight multicast station channels can be selected
on this unit.
When aradio station multicast
is received, the "MULTICAST'
indicator lights.
1Touch [ 0] in the HD Radio Tuner mode.
The program list is displayed.
2Touch [.] of the desired program type.
The selected program is received.
3Touch [T] or [...]of PROGRAM on the function
guide.
The sub channel of the received radio station is changed.
i5-EN
5Touch [ ..... ]. [~]or["]. ["]to change the
radio frequency up or down respectively.
In manual mode, touch and hold to change the frequency
continuously.
•"DIGITAL" is displayed when adigital radio station is received.
•Refer to "Digital SEEK Setting (HD Radio mode only)" on page
34.
Presetting Stations Manually
1Tune in adesired radio station you wish to store in
the preset memory by manual or automatic seek
tuning.
2Touch [P1/2]* to change the function guide.
*[P 113} is displayed in the HD Radio mode.
3Touch and hold anyone of the preset buttons
[P.SET 1] through [P.SET 6] for at least 2seconds.
The selected station is stored.
4Repeat the procedure to store up to 5other stations
onto the same band.
To use this procedure for other bands, simply select the
desired band and repeat the procedure.
Atotal of 18 stations can be stored in the preset memory
(6 stations for each band; FM1, FM2 or AM).
• If apreset memory has already been setin the same preset number, it
will be cleared
and the new station will be memorized.
Presetting Stations Automatically
The tuner can automatically seek and store 6strong stations in the
selected band in order
of signal strength.
After selecting the desired band. touch [A. MEMO].
The tuner automatically seeks and stores 6strong stations into
[P.SET 1] to [P.SET 6] in order of signal strength.
When the automatic storing has been completed, the tuner goes
to the station stored in [P.SET 1].
• If no stations are stored. the tuner will return to the original station
you were listening to before the automatic storing procedure began.
Tuning to Preset Stations
You can tune in the preset stations in memory on each band using the
preset number.
1After selecting the desired band, touch [P1/2]* to
change the function guide.
*[P 113} is displayed in the HD Radio mode.
2Touch anyone of the preset buttons [P.SET 1]
through [P.SET 6] that has astation stored to it.
The preset station is received.
Changing the Display (HD Radio mode
only)
Text information, such as Station name, Song title, Artist, etc., is
displayed while receiving adigital radio station.
Touch [INFO.] on the HD Radio Tuner mode main
screen.
Each time you touch this button, the display changes as shown
below.
Short Station Name *J
Song IiIle *2
- - - - - - - - - - ~ Long Station Name *J
Artist *2
----------
Album *2
*1 Displays Short Station Name /Long Station Name in the Station
Information Service Data.
~ Displays Song title /Artist/Album in the main program Service
Data.
Receiving a Multicast (HD Radio mode
only)
Multicasting is the ability to broadcast multiple program streams over a
single FM frequency. This increases the amount and diversity
of content
choices. Amaximum
of eight multicast station channels can be selected
on this unit.
When aradio station multicast
is received, the "MULTICAST'
indicator lights.
1Touch [ 0] in the HD Radio Tuner mode.
The program list is displayed.
2Touch [.] of the desired program type.
The selected program is received.
3Touch [T] or [...]of PROGRAM on the function
guide.
The sub channel of the received radio station is changed.
i5-EN

CD/MP3/WMA/AAC
Displayexample for MP3IWMAlAAC main screen
5
CD [SOURCE] button: Refer to page 12
@[VISUAL] button: Displays the VISUAL selection screen
@[SETUP) button: Displays the SETUP selection screen
@[Style] button: Refer to page 14
® [0] button: Refer to page 27
@CD:
Displays the Track text*} /Disc text*}.
• If there is neither Track nor Disc name information. "NO TEXT" will
be displayed.
MP3IWMAJAAC:
After displaying the file name
in the upper line, the track
name
is displayed if there is 103 tag information.
After displaying the folder name
in the lower line, the album
name/artist name are displayed if there is
103 tag
information.
@CD:
Displays the disc number*2/track number/elapsed time.
MP3IWMAJAAC:
Displays the disc number*3/folder number/track number/
elapsed playback time.
*} Displayed when aCD text disc is inserted.
~ Displayed when aCD changer is connected.
~ Displayed when an MP3 compatible CD changer is connected.
16-EN
Playback
1Touch [SOURCE] on the main source screen.
The SOURCE selection screen is displayed.
2Touch [DISC].
The display shows the DISC mode screen.
When aCD/MP3IWMA/AAC is inserted into the DISC SLOT
of the IVA-W505, with the label side facing up, the unit starts
to play the CD/MP3/WMNAAC.
3Touch [10+1I] or [~] to select the desired track
(file).
Returning to the beginning of the currenttrack(file):
Touch [10+1I).
Fast reverse:
Touch and hold [10+1I).
Advancingto the beginning of the nexttrack (file) :
Touch[~).
Fast forward :
Touch and hold [~).
To pause playback
Touch [./11) .
Touching [./11) again will resume playback.
Inserting/Ejecting aDisc
Refer to "Inserting/Ejecting aDisc" (page 12).
•The IVA-W505 model includes abuilt-in MP3IWMAlAAC unit. You
can play CD-ROMs. CD-Rs. and CD-RWs containing MP3IWMAI
AAC files on this unit. Use theformat compliant with this unit.
For further information about playing or storing MP3IWMAlAAC
files. refer to pages
/7 and 18before using the unit.
•
WMAformatfiles that are protected by DRM (Digital Rights
Management).
AAC formatfiles that have been purchasedfrom
iTunes Music Store andfiles that are copy-protected (copyright
protection) cannot be played back on this unit.
•The unit can play discs containing both audio data
and MP3IWMAI
AAC data.
•The track display
for CD audio data playback is the track numbers
recorded on the disc.
•Three-inch
(8 cm) CDs can be used.
•"Playing MP3IWMAlAAC Data (FILE PLAY MODE)" is mentioned
on page
33.
• If an MP3IWMAlAAC disc with manyfiles andfolders is played. it
takes alittle longer than normal to start playback.
•Touch
[OJ to activate the search mode. For operations. refer to
"Search Function" on page 27.
However, the search modefunction does not work in the CD changer
mode.
•The playback time may not be correctly displayed when aVBR
(Variable Bit Rate) recordedfile is played back.
CD/MP3/WMA/AAC
Displayexample for MP3IWMAlAAC main screen
5
CD [SOURCE] button: Refer to page 12
@[VISUAL] button: Displays the VISUAL selection screen
@[SETUP) button: Displays the SETUP selection screen
@[Style] button: Refer to page 14
® [0] button: Refer to page 27
@CD:
Displays the Track text*} /Disc text*}.
• If there is neither Track nor Disc name information. "NO TEXT" will
be displayed.
MP3IWMAJAAC:
After displaying the file name
in the upper line, the track
name
is displayed if there is 103 tag information.
After displaying the folder name
in the lower line, the album
name/artist name are displayed if there is
103 tag
information.
@CD:
Displays the disc number*2/track number/elapsed time.
MP3IWMAJAAC:
Displays the disc number*3/folder number/track number/
elapsed playback time.
*} Displayed when aCD text disc is inserted.
~ Displayed when aCD changer is connected.
~ Displayed when an MP3 compatible CD changer is connected.
16-EN
Playback
1Touch [SOURCE] on the main source screen.
The SOURCE selection screen is displayed.
2Touch [DISC].
The display shows the DISC mode screen.
When aCD/MP3IWMA/AAC is inserted into the DISC SLOT
of the IVA-W505, with the label side facing up, the unit starts
to play the CD/MP3/WMNAAC.
3Touch [10+1I] or [~] to select the desired track
(file).
Returning to the beginning of the currenttrack(file):
Touch [10+1I).
Fast reverse:
Touch and hold [10+1I).
Advancingto the beginning of the nexttrack (file) :
Touch[~).
Fast forward :
Touch and hold [~).
To pause playback
Touch [./11) .
Touching [./11) again will resume playback.
Inserting/Ejecting aDisc
Refer to "Inserting/Ejecting aDisc" (page 12).
•The IVA-W505 model includes abuilt-in MP3IWMAlAAC unit. You
can play CD-ROMs. CD-Rs. and CD-RWs containing MP3IWMAI
AAC files on this unit. Use theformat compliant with this unit.
For further information about playing or storing MP3IWMAlAAC
files. refer to pages
/7 and 18before using the unit.
•
WMAformatfiles that are protected by DRM (Digital Rights
Management).
AAC formatfiles that have been purchasedfrom
iTunes Music Store andfiles that are copy-protected (copyright
protection) cannot be played back on this unit.
•The unit can play discs containing both audio data
and MP3IWMAI
AAC data.
•The track display
for CD audio data playback is the track numbers
recorded on the disc.
•Three-inch
(8 cm) CDs can be used.
•"Playing MP3IWMAlAAC Data (FILE PLAY MODE)" is mentioned
on page
33.
• If an MP3IWMAlAAC disc with manyfiles andfolders is played. it
takes alittle longer than normal to start playback.
•Touch
[OJ to activate the search mode. For operations. refer to
"Search Function" on page 27.
However, the search modefunction does not work in the CD changer
mode.
•The playback time may not be correctly displayed when aVBR
(Variable Bit Rate) recordedfile is played back.

Repeat Play
Touch ['::)] to play back repeatedly the track currently
being played.
The track (file) will be played repeatedly.
Touch
['::)] again and select OFF to deactivate Repeat play.
CD:
RPT ~ RPT DISC*) -t (off) ~ RPT
MP3N/MA/AAC:
1Touch [P1/2j*3 to change the function guide.
2Touch ['::») and select the desired Repeat play.
RPT ~ RPT FLDR*2 ~ RPT DISC*) ~ (off) ~ RPT
*) If aCD Changer oran MP3 compatible CD changer is connected
and the RPT DISCmode is selected, the unit repeatedly plays back
all tracks (files) on the disc selected.
~ Onlyfiles in afolder are repeatedly played back.
~ Display may vary depending on the connected devices.
M.I.X. (Random Play)
Touch [cal during playback.
The tracks (files) on the disc will be played back in a random
sequence.
To cancel M.I.X. play, touch [ca).
CD: M.I.X. ~ M.I.X. ALL*) ~ (off) ~ M.I.X.
MP3N/MA/AAC:
1Touch [P1J2j*4 to change the function guide.
2Touch [ca] and select the desired M.I.X. play.
M.I.X. FLDR*3
~ M.I.X.*2 ~ (off) ~ M.I.X. FLDR*3
*) If aCD Changerequipped with the M.I.X. ALLfunction is connected,
M.I.X.
ALL will also be selectable.
In this mode, the tracks on all the CDs in the current magazine will
be included in the random playback sequence.
~ If an MP3 compatible CD changer is connected, allfiles in adisc are
playedback in random sequence,
and playback shifts to the next disc.
~ Onlyfiles in afolder are played back in random sequence in the
M.I.X. FLDR mode.
~ Display may vary depending on the connected devices.
•
If the search mode (page 27) is activated, the M.l.X. play mode will
be canceled.
Selecting Folders (concerning MP3/
WMA/AAC)
Touch FOLDER ["'] or [... ]to select the folder.
About MP3/WMA/AAC
CAUTION
Exceptfor private use, duplicating audio data (including MP31
WMAlAAC data) or distributing, transferring,
or copying it,
whether for free or for afee, without permission of the copyright
holder is strictly prohibited by the Copyright
Act and by
international treaty.
What Is MP3?
MP3, whose official name is "MPEG-1, 2, 2.5 Audio Layer 3", is a
compression standard prescribed by the
ISO, the International
Standardization Organization and
MPEG which is ajoint activity
institution of the IEC.
MP3 files contain compressed audio data, MP3 encoding is
capable of compressing audio data at extremely high ratios,
reducing the size of music files to as much as one-tenth their
original size. This is achieved while still maintaining near CD
quality. The MP3 format realizes such high compression ratios
by eliminating the sounds that are either inaudible to the human
ear or masked by other sounds.
What Is AAC?
MC is the abbreviation for "Advanced Audio Coding", and is a
basic format of audio compression used by MPEG2 or MPEG4.
What Is WMA?
WMA, or "Windows Media™ Audio," is compressed audio data.
WMA
is similar to MP3 audio data and can achieve CD quality
sound with small file sizes.
Method for creating MP3IWMAlAAC flies
Audio data is compressed using software with MP3N/MNMC
codecs. For details on creating MP3/WMNAAC files, refer to the
user's manual for that software,
MP3/WMNMC files that are playable on this device have the
file extensions.
MP3: "mp3"
WMA: "wma" (ver. 7.1, 8 . 9, 9.1 and 9.2 are supported)
MC: "m4a"
WMA
is not supported for the following files, Windows Media
Audio Professional, Windows Media Audio 9Voice or Windows
Media Audio 9
Pro Lossless.
There are many different versions of the AAC format. Confirm
that the software being used conforms
to the acceptable
formats listed above.
It's possible that the format may be
unplayable even though the extension is valid.
Playback of MC files encoded by iTunes is supported.
Supportedplayback sampling rates and bit rates
MP3
Sampling rates:
48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,
16 kHz. 12 kHz, 11.025 kHz, 8kHz
Bit rates:
32 -320 kbps
WMA
Sampling rates:
48 kHz, 44.1 kHz, 32 kHz
Bit rates:
48 -192 kbps
AAC
Sampling rates:
48 kHz. 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,
16 kHz, 12 kHz, 11.025 kHz, 8kHz
Bit rates:
16 -320 kbps
This device may not play back correctly depending on sampling
rates.
17-EN
Repeat Play
Touch ['::)] to play back repeatedly the track currently
being played.
The track (file) will be played repeatedly.
Touch
['::)] again and select OFF to deactivate Repeat play.
CD:
RPT ~ RPT DISC*) -t (off) ~ RPT
MP3N/MA/AAC:
1Touch [P1/2j*3 to change the function guide.
2Touch ['::») and select the desired Repeat play.
RPT ~ RPT FLDR*2 ~ RPT DISC*) ~ (off) ~ RPT
*) If aCD Changer oran MP3 compatible CD changer is connected
and the RPT DISCmode is selected, the unit repeatedly plays back
all tracks (files) on the disc selected.
~ Onlyfiles in afolder are repeatedly played back.
~ Display may vary depending on the connected devices.
M.I.X. (Random Play)
Touch [cal during playback.
The tracks (files) on the disc will be played back in a random
sequence.
To cancel M.I.X. play, touch [ca).
CD: M.I.X. ~ M.I.X. ALL*) ~ (off) ~ M.I.X.
MP3N/MA/AAC:
1Touch [P1J2j*4 to change the function guide.
2Touch [ca] and select the desired M.I.X. play.
M.I.X. FLDR*3
~ M.I.X.*2 ~ (off) ~ M.I.X. FLDR*3
*) If aCD Changerequipped with the M.I.X. ALLfunction is connected,
M.I.X.
ALL will also be selectable.
In this mode, the tracks on all the CDs in the current magazine will
be included in the random playback sequence.
~ If an MP3 compatible CD changer is connected, allfiles in adisc are
playedback in random sequence,
and playback shifts to the next disc.
~ Onlyfiles in afolder are played back in random sequence in the
M.I.X. FLDR mode.
~ Display may vary depending on the connected devices.
•
If the search mode (page 27) is activated, the M.l.X. play mode will
be canceled.
Selecting Folders (concerning MP3/
WMA/AAC)
Touch FOLDER ["'] or [... ]to select the folder.
About MP3/WMA/AAC
CAUTION
Exceptfor private use, duplicating audio data (including MP31
WMAlAAC data) or distributing, transferring,
or copying it,
whether for free or for afee, without permission of the copyright
holder is strictly prohibited by the Copyright
Act and by
international treaty.
What Is MP3?
MP3, whose official name is "MPEG-1, 2, 2.5 Audio Layer 3", is a
compression standard prescribed by the
ISO, the International
Standardization Organization and
MPEG which is ajoint activity
institution of the IEC.
MP3 files contain compressed audio data, MP3 encoding is
capable of compressing audio data at extremely high ratios,
reducing the size of music files to as much as one-tenth their
original size. This is achieved while still maintaining near CD
quality. The MP3 format realizes such high compression ratios
by eliminating the sounds that are either inaudible to the human
ear or masked by other sounds.
What Is AAC?
MC is the abbreviation for "Advanced Audio Coding", and is a
basic format of audio compression used by MPEG2 or MPEG4.
What Is WMA?
WMA, or "Windows Media™ Audio," is compressed audio data.
WMA
is similar to MP3 audio data and can achieve CD quality
sound with small file sizes.
Method for creating MP3IWMAlAAC flies
Audio data is compressed using software with MP3N/MNMC
codecs. For details on creating MP3/WMNAAC files, refer to the
user's manual for that software,
MP3/WMNMC files that are playable on this device have the
file extensions.
MP3: "mp3"
WMA: "wma" (ver. 7.1, 8 . 9, 9.1 and 9.2 are supported)
MC: "m4a"
WMA
is not supported for the following files, Windows Media
Audio Professional, Windows Media Audio 9Voice or Windows
Media Audio 9
Pro Lossless.
There are many different versions of the AAC format. Confirm
that the software being used conforms
to the acceptable
formats listed above.
It's possible that the format may be
unplayable even though the extension is valid.
Playback of MC files encoded by iTunes is supported.
Supportedplayback sampling rates and bit rates
MP3
Sampling rates:
48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,
16 kHz. 12 kHz, 11.025 kHz, 8kHz
Bit rates:
32 -320 kbps
WMA
Sampling rates:
48 kHz, 44.1 kHz, 32 kHz
Bit rates:
48 -192 kbps
AAC
Sampling rates:
48 kHz. 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,
16 kHz, 12 kHz, 11.025 kHz, 8kHz
Bit rates:
16 -320 kbps
This device may not play back correctly depending on sampling
rates.
17-EN

ID3 tagsIWMA tags
If tag data is in an MP3N/MA/AAC file, this device can display
the title (track title), artist name, and album name
ID3tagN/MA
tag data (maximum 128 characters).
This device can only display single-byte alphanumeric
characters and the underscore. For non-supported characters,
"NO SUPPORT" is displayed.
The number of characters may be limited, or not correctly
displayed, depending on the tag information.
Playing back MP3IWMAlAAC
MP3N/MNAAC files are prepared, then written to aCD-R,
CD-RW (DVD-R/DVD-RW) using CD-R writing software. Adisc
can hold
up to 1024 files/256 folders (including Root Folders),
and the maximum number of folders is 255. Playback may not
be performed
if adisc exceeds the limitations described above.
Media supported
The media that this device can play back are CD-ROMs, CD-Rs,
and CD-RWs, DVD-Rs and DVD-RWs.
Corresponding File Systems
This device supports discs formatted with IS09660 Level 1or
Level
2.
Under the IS09660 standard, there are some restrictions to
remember.
The maximum nested folder depth is 8(including the root
directory). The number of characters for afolder/file name is
limited.
Valid characters for folder/file names are letters A-Z (all caps),
numbers 0-9, and '_' (underscore).
This device can play back discs in Joliet, Romeo, etc., and other
standards that conform
to IS09660. However, sometimes the file
names, folder names, etc., are not displayed correctly.
Formats supported
This device supports CD-ROM XA, Mixed Mode CD, Enhanced
CD (CD-Extra) and Multi-Session.
This device cannot correctly play back discs recorded with
Track At Once or packet writing.
Order of files
Files are played back in the order that the writing software writes
them to the disc. Therefore, the playback order may not be
what's expected. Verity the writing order
in the software's
documentation. The playback order of the folders and files is as
follows. (The following numbers may differ from actually
displayed numbers.)
18-EN
®
®
III D
Folder MP3IWMAJAAC File
Terminology
Bit rate
This is the "sound" compression rate specified for encoding. The
higher the bit rate, the higher the sound quality, but also the larger
thefiles.
Sampling rate
This value shows how many times per second the data is sampled
(recorded). For example, music CDs use asampling rate
of 44.1 kHz,
so the sound is sampled (recorded) 44,100 times
per second. The
higher the sampling rate, the higher the sound quality, but also the
larger the volume
of data.
Encoding
Convening music CDs, WAVE (AlFF)files, and othersoundfilesinto
the specifiedaudio compressionformat.
Tag
Song information such as track titles, anist names, album names,
etc., written into MP3/WMA/AACfiles.
Root folder
The rootfolder (or root directory) is found at the top of thefile
system. The rootfolder contains allfolders
and files. It is created
automatically
for all burneddiscs.
ID3 tagsIWMA tags
If tag data is in an MP3N/MA/AAC file, this device can display
the title (track title), artist name, and album name
ID3tagN/MA
tag data (maximum 128 characters).
This device can only display single-byte alphanumeric
characters and the underscore. For non-supported characters,
"NO SUPPORT" is displayed.
The number of characters may be limited, or not correctly
displayed, depending on the tag information.
Playing back MP3IWMAlAAC
MP3N/MNAAC files are prepared, then written to aCD-R,
CD-RW (DVD-R/DVD-RW) using CD-R writing software. Adisc
can hold
up to 1024 files/256 folders (including Root Folders),
and the maximum number of folders is 255. Playback may not
be performed
if adisc exceeds the limitations described above.
Media supported
The media that this device can play back are CD-ROMs, CD-Rs,
and CD-RWs, DVD-Rs and DVD-RWs.
Corresponding File Systems
This device supports discs formatted with IS09660 Level 1or
Level
2.
Under the IS09660 standard, there are some restrictions to
remember.
The maximum nested folder depth is 8(including the root
directory). The number of characters for afolder/file name is
limited.
Valid characters for folder/file names are letters A-Z (all caps),
numbers 0-9, and '_' (underscore).
This device can play back discs in Joliet, Romeo, etc., and other
standards that conform
to IS09660. However, sometimes the file
names, folder names, etc., are not displayed correctly.
Formats supported
This device supports CD-ROM XA, Mixed Mode CD, Enhanced
CD (CD-Extra) and Multi-Session.
This device cannot correctly play back discs recorded with
Track At Once or packet writing.
Order of files
Files are played back in the order that the writing software writes
them to the disc. Therefore, the playback order may not be
what's expected. Verity the writing order
in the software's
documentation. The playback order of the folders and files is as
follows. (The following numbers may differ from actually
displayed numbers.)
18-EN
®
®
III D
Folder MP3IWMAJAAC File
Terminology
Bit rate
This is the "sound" compression rate specified for encoding. The
higher the bit rate, the higher the sound quality, but also the larger
thefiles.
Sampling rate
This value shows how many times per second the data is sampled
(recorded). For example, music CDs use asampling rate
of 44.1 kHz,
so the sound is sampled (recorded) 44,100 times
per second. The
higher the sampling rate, the higher the sound quality, but also the
larger the volume
of data.
Encoding
Convening music CDs, WAVE (AlFF)files, and othersoundfilesinto
the specifiedaudio compressionformat.
Tag
Song information such as track titles, anist names, album names,
etc., written into MP3/WMA/AACfiles.
Root folder
The rootfolder (or root directory) is found at the top of thefile
system. The rootfolder contains allfolders
and files. It is created
automatically
for all burneddiscs.
