AWM970Quick Reference Guide
AM/FM Tuner Controls
STATION STORE BUTTONS:
Press & hold to store current channel playing. Momentarily
press to recall stored channel. NOTE: you can store up to 30
channels (6 channels per band FM1, FM2, FM3, AM1, AM2).
TUNE/TRACK: Rotate
COUNTER CLOCKWISE
to TUNE DOWN in
frequency. Rotate
CLOCKWISE to TUNE
UP in frequency. Rotate
and hold to scan to next
strongest station.
AS/PS: Press to
SCAN through
currently stored
presets. Press &
hold to STORE
strongest broad-
cast stations in
your area.
MUTE: Press to
MUTE audio.
AM/FM: Press to directly access TUNER
MODE. Press to select between two
AM BANDS (AM1 & AM2) & three FM
BANDS (FM1, FM2, & FM3).
VOL: Rotate CLOCK-
WISE to INCREASE
VOLUME. Rotate
COUNTER CLOCK-
WISE to DECREASE
VOLUME.
AS/PS:
SCAN through
currently stored
strongest broad-
cast stations in
your area.
AM/FM:
VOL:
WISE to INCREASE
VOLUME. Rotate
COUNTER CLOCK-
WISE to DECREASE
VOLUME.
Basic Operation
Power On/Off:
Push to turn
ON or OFF.
SPEAKER OUTPUT:
Press any speaker
button (SPEAKER A,
SPEAKER B, or
SPEAKER C) to control
corresponding speaker
output from the stereo.
Red light above each
button will illuminate
when selected speaker
is turned on.
MUTE: Press to
MUTE audio.
T/F CLOCK: Press to
display CLOCK.
AUDIO: With each
press of the button
choose from the
following AUDIO
ADJUSTMENT
options: VOLUME,
BASS, TREBLE,
BALANCE (left to
right), & FADER
(front to back).
HEADPHONE: Insert
headphone jack.
AUX A/V IN: Insert
3.5mm audio/video jack.
CD/DVD/USB Player Controls
PLAY/PAUSE:
Press to PLAY or
PAUSE current
audio or video.
INTRO SCAN: Press to
play each track for 10
seconds in sequential
order. Press again to
SELECT desired play.
RPT: Press to REPEAT
current playing track.
Press to release
function.
RDM: Press to
play each track in
RANDOM order.
Press again for
NORMAL play.
STOP: Press to
SUSPEND disc play.
Press PLAY/PAUSE
to RESUME disc play.
TUNE/TRACK: Rotate
CLOCKWISE to tune
to NEXT TRACK or
CHAPTER/TITLE.
Rotate COUNTER
CLOCKWISE to tune to
PREVIOUS TRACK or
CHAPTER/TITLE. In CD
MODE, rotate and hold
to FAST FORWARD
or REWIND current
play. In DVD MODE,
rotate and hold to enter
FAST FORWARD/RW.
Momentarily turn to
step through x2, x4,
x8, x20. Press PLAY
to resume.
MUTE: Press to
MUTE audio.
VOL: Rotate CLOCK-
WISE to INCREASE
VOLUME. Rotate
COUNTER CLOCK-
WISE to DECREASE
VOLUME.
EJECT: Press to
EJECT CD or DVD.
LANG: Press
to select AUDIO
LANGUAGE
when in DVD
MODE.
DVD/USB:
Press to select
DVD/USB mode.
MENU: Press
to access main
DVD MENU.
USB: Plug in
USB device

Clock/Alarm Settings
T/F CLOCK: Press to display current time.
Press & hold to enter CLOCK SETTING
MODE. Rotate TUN/TRK encoder knob
to adjust the HOUR. Press T/F again and
rotate TUN/TRK encoder knob to adjust
the MINUTES. Once desired time has been
selected, the time will set after 5 seconds.
©Copyright 2009 ASA, LLC QRGAWM970 - 309 REV2
EJECT: Press to EJECT DVD.
MUTE: Press to MUTE audio.
PLAY/PAUSE: Press to PLAY or PAUSE current audio.
TITLE: Press to enter TITLE MENU. Use the DIRECTIONAL
ARROWS to choose menu item. Press ENTER to select.
ZOOM: Press to ZOOM in on current picture.
Press repeatedly to change MAGNIFICATION LEVEL of current picture.
ANGLE: Press to select different visual angle if stored on DVD.
LANG: Press to select AUDIO LANGUAGE.
ENTER: Press to select menu option.
DIRECTIONAL ARROWS: Press to move
cursor to desired MENU ITEM. Press ENTER
to select desired MENU ITEM.
STOP: Press once SUSPEND disc play.
Press PLAY/PAUSE to RESUME disc play.
Press twice to completely stop disc play.
CHAPTER SKIP: Press to skip to NEXT or PREVIOUS chapter.
FAST FORWARD/REWIND: Press to FAST FORWARD or REWIND
current play. Continue to press to enhance the speed.
Press PLAY/PAUSE to resume current play.
GOTO: Press to view CHAPTER, TRACK, & TIME. Press again to clear.
DISPLAY: Press to DISPLAY current playback information on the screen.
SETUP: Press to enter SETUP MENU.
SUBTITLES: Press to select CLOSED CAPTIONING.
Continue to press to select AUDIO LANGUAGE.
DVD Remote Controls
MENU: Press to access main DVD MENU.
T/F: Press to display CLOCK.
SOURCE: Press to select for PLAYBACK.
RPT: Press to REPEAT current CHAPTER. Press again to release function.
iPod Controls
TUNE/TRACK: Rotate
to select NEXT or
PREVIOUS track in
current playlist for
desired play.
MENU: Press
to enter PLAYLIST.
Use FOLDER UP/
DOWN to navigate
through list. Press
ENTER to select.
This also returns you
to the previous menu.
MUTE: Press to
MUTE audio.
VOL: Rotate CLOCK-
WISE to INCREASE
VOLUME. Rotate
COUNTER CLOCK-
WISE to DECREASE
VOLUME.
AUX: Press to
enter iPod Mode.
PLAY/PAUSE:
Press to PLAY or
PAUSE current audio.
RPT: Press to
REPEAT current
playing track. Press
again to REPEAT all
tracks. Press again
to release function.
RDM: Press to play each
track on selected album
in RANDOM order. Press
again to play all albums
in RANDOM order. Press
again to release function.
FOLDER UP/DOWN:
After pressing SEARCH press
UP/DOWN to navigate through
various playlists. Press ENTER
to make selection.
TUNE/TRACK: Rotate UP or DOWN
to adjust HOUR and MINUTES once in
CLOCK MODE or ALARM SETTING MODE.
ALARM: Press ALARM SET to cycle
trough SLEEP TIMER MODE. Press and
hold to enter ALARM SETTING MODE.
Rotate TUN/TRK encoder knob to adjust
the HOUR. Press ALARM SET again and
rotate TUN/TRK encoder knob to adjust
the MINUTES. Once desired time has been
selected, press ALARM ON/OFF to turn
ALARM MODE ON or OFF.
TUNE/TRACK: Rotate
and hold CLOCKWISE
to FAST FORWARD.
Turn and hold COUN-
TER CLOCKWISE to
RE-WIND. Release
knob and press
PLAY/PAUSE to
resume normal play.
ENTER: Press to select
desired PLAYLIST,
ARTIST, ALBUM,
SONG LIST, or GENRE.
MENU:
to enter PLAYLIST.
Use FOLDER UP/
DOWN to navigate
through list. Press
ENTER to select.
This also returns you
to the previous menu.
VOL:
WISE to INCREASE
VOLUME. Rotate
COUNTER CLOCK-
WISE to DECREASE
VOLUME.
AUX:
enter iPod Mode.
