Alpine Blackbird PMD-B200P User manual

PMD-B 200 P
Quick Reference Guide
Kurzreferenz
Guide de référence rapide
Guida rapida
Guía de referencia rápida
Beknopte handleiding
Snabbreferensguide
Lynguide
Краткий справочник

EN-1
How to Mount My Blackbird
WARNING Improper installation may make the navigation system fall from the cradle while driving.
Ensure all locks and knobs are tight. Do not install the navigation system while driving.
Find a spot suitable for the navigation system. Ensure that both the
suction cup and windshield area are clean. Stick the suction cup against
the windshield. Turn the knob to lock it in position.
Turn the knob counterclockwise to adjust up/down position. Turn
clockwise to set the position.
Turn the knob clockwise to adjust right/left position. Turn
counterclockwise to set the position.
THE DEVICE SHOULD NOT BE INSTALLED SO THAT IT OBSTRUCTS THE
DRIVER’S VIEW.
Slide the navigation system into the cradle until it clicks.
Plug in the cigarette lighter charger.
Note:The cradle consists of 2 separate parts that must be assembled before mounting.
1
2
3
4
5
CAUTION Remove the navigation system when you are away from the vehicle to prevent theft.
How to Remove My Blackbird
1
2
Press and hold the cradle’s eject button.
Grasp the navigation system behind the antenna and slide up and out of
the cradle.
NOTE: Local regulations may prohibit the placement of any object on windows or the dash. See your authorised
ALPINE dealer for other installation options.
2
3
4
2
1

EN-2
Blackbird
1 - SD/MMC Card Slot
2 - Power Button
3 - Headphone Jack
4 - Volume Control
5 - Remote and Ambient Light
Sensor
6 - Navigation Menu Button
7 - Map Zoom Out
8 - Center Key (Phone Key)
9 - Music
10 - Destination
11 - Map Zoom In
12 - Battery Charging Status
Indicator
13 - Current Vehicle Position Icon
14 - Reset Button
15 - Cradle Connector
16 - External GPS Antenna
Connector
17 - Mini USB Connector
1 2 3 4
5 6
7
8
9
10
11
12 13
14 15 16 17

EN-3
Map Functions
Below is an overview of dierent buttons and icons on the map display. For more
detailed information about this screen, please see the Owner’s Manual.
Next Street Name
Next Manoeuvre
Arrow
Distance to next
Manoeuvre
Trip Information
Trac Information
Map Orientation
Battery Status
Indicator
GPS Status Bar
Map Scale Bar
Current Street Name
Navigation Menu – Press this icon
to access the navigation menu.
Current Vehicle Position – Press this icon
to return to the map from any screen.
Voice Prompt Repeat Button – Repeats
the last voice prompt command.

EN-4
Navigation Menu
From the Map or any screen, touch the Navigation Menu to access the following menus:
Destination
Set and save
destinations using any
of six dierent input
methods (Address,
Home, History, POI,
Favourites, Coordinate).
Edit
Edit Favourites,
Personal POI, Saved
Routes and Track Logs.
Multimedia
Listen to Music and
watch Pictures
stored on your
SD or MMC card.
Route
Get route information, see
the turn list, edit the route,
change methods as well
as load, save, delete and
simulate the route.
Phone
Access your Bluetooth-
enabled mobile phone.
Settings
Allows you to customise
various characteristics of
your navigation system’s
look and feel.

EN-5
Go to a Destination
The following example briey describes how to input a destination in the Blackbird
Navigation System.
12
Select Destination from
Navigation Menu .
Or press Destination
button.
Select a destination input
method. (Address is
selected.)
To change the country
press the button with the
countryname. Select a
country from the list.
3
4Press the button <City
Name> to type in the
destination. Press OK to
access the list to select a
matching entry.

EN-6
5Type in the street name.
Press OK to access the list
to select a matching entry.
Enter a house number.
Press OK to access the
conrmation screen.
6Press Go to initialise route
calculation and start
navigation.
7

EN-7
Docking with IVA-W 205 R and IVA-W 505 R
1Open IVA-W
205 R / IVA-W 505 R head
unit monitor.
Insert Blackbird into the unit with the
screen facing up and the navigation
wheel on the left.
Press Blackbird rmly into place.
2
3
CLOSE
1
2
Additional On-Screen Button
When Blackbird is docked, an additional on-screen button allows you to
conveniently access additional system features.
Touching this
button will give you
access to the A/V Head
Unit’s display control.
