ALTAI B5
WIRELESS PTP/PTMP BRIDGE
QUICK SETUP GUIDE
Version 1.0
Date: October, 2013

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
1. Unpack
After receiving the equipment please locate the following items in your box as shown
on the picture below:
2. Switch on
Connect ODU and IDU with STP/FTP cable.
The total cable length between LAN (behind IDU) and ODU should not be
longer than 100 meters.
ODU:
IDU:
Console port Grounding clamp/damping
system window
DO NOT BLOCK!
ALWAYS LOOKS DOWN!
Service cable
RJ-45 connector
Figure 2. Ind
oor Unit
Figure 1. Outdoor Unit
Figure 2. Iutdoor Unit

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
When ODU module has one or several N-type
connectors for external antenna.
If other IDUs used, please study
their installation instructions in
Technical User Manual.
Cable preparation:
Step 1.
Peel STP service cable
and prepare “RJ-45”
connector parts.
Use RJ-45 connector
without grounding here
(RJ-45 connector with
grounding should be
used for connecting
service cable to IDU).
Step 2.
Stick rubber filler –5 on
the Part 4, previously
having removed
protective white layer
from rubber filler -5.
Insert Part 2 inside part 4
up to the stop. Part 2
must be entirely within
Part 4.

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Step 3.
Put connector parts on
the STP service cable as
shown.
Attach RJ-45 connector
without grounding to the
STP service cable
according to the “RJ-45”
soldering scheme
(below in this section)
and crimp the
connector using a crimp
tool.
Please tightly
crimp the RJ-45
connector. Not
crimped or badly
crimped
connector
damages the unit
when assembled
into it which is not
considered as a
warranty case.
Step 4.
Put Part 4 on the
attached in the previous
step RJ-45 connector.
Step 5.
Screw Part 2 on Part 4.
This fixes the “RJ-45”
connector on the cable.
Check that the
connector is properly
fixed on the cable.

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Step 6.
Assemble the connector
to the unit.
Step 7.
Fix the connector by
screwing Part 3.
Now the connector is
hermetically attached
to the unit. No
additional sealing
needed.
Figure 3. RJ-45 cable connector soldering scheme
Power on
Plug the power cord into the IDU Power supply connector and to the Power supply
socket (220V 50 Hz or 110V 60 Hz depending on the country of residence).

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Accessing the Unit:
To access the unit via console:
1. Using Altai Console Cable please connect the unit’s console port (see Fig. 1) to
the
COM-port of your PC/Laptop.
In order to accomplish the steps described in this
section your PC/Laptop must be equipped with a
COM-port
2. Locate the power cord in the package
3. Plug the power cord into the IDU power supply connector and to the power
supply socket
(220V 50 Hz or 110V 60 Hz depending on the country of residence)
4. Green power indicator on the IDU must light up
5. Power your PC/Laptop on
Following step’s screenshots are taken from Microsoft
Windows XP. You can also perform this procedure in
Microsoft Windows 98/NT/2003
6. Run HyperTerminal. See Figure 4
Figure 4. Locate HyperTerminal
7. Indicate connection name (e.g. “IWR Lab Test”) and specify the COM-port name
to which the unit is connected. See Figure 5

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Figure 5. Select the port
8. Specify port parameters exactly as shown on Figure 6
Figure 6. Port parameters
9. If you connected everything properly, selected the right port and made its
configuration right,
After pressing enter on the white blank screen (after step 8) you should see
WANFleX OS prompt as shown on Figure 7

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Figure 7. WANFleX OS prompt
10. Your device has a factory configuration. Default login is altai, default password is
wag. Once this is done, you will see CLI (Command Line Interface). See Figure 8
Figure 8. “Login” screen
11. In order for your unit to be accessible from your LAN/PC/Laptop via Ethernet, you
should configure eth0 interface IP-address so the unit would allocate in the
desired LAN (or accessible from your PC/Laptop Ethernet adapter). You can
change this IP-address via “ifc eth0” command as shown on figure 9. After
changing the IP-address, save the configuration using “co sa” command. In the
example given the IP-address being assigned to eth0 interface is 9.1.8.1 with
mask length 24 (255.255.255.0). In order to check whether your changes were
correct, use “co sh ifc” command which shows configuration for all interfaces of
the unit. Do not forget to save your configuration using “co sa” (config save)
command.
Figure 9. Changing IP-address on eth0 interface

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
12. If all your settings are correct you can connect the unit to your LAN using UTP
cable with RJ-45 connectors (Ethernet port of the unit is located on IDU).
To access the unit via Ethernet:
If your PC/Laptop does not have a COM-port or you want to plug the unit to the LAN
switch you can configure it using Telnet protocol.
The default IP-address assigned to the eth0 interface of the unit is 192.168.1.20 with
255.255.255.0 mask.
If you connect the unit directly to the LAN/PC/Laptop you should either change the
IP-address on the Ethernet adaptor or create an alias IP-address which would be
located in 192.168.1.0/24 network.
Connect the unit to LAN/PC/Laptop using UTP cable with RJ-45 connectors.
The procedure is the following:
1. Open the Control Panel in Windows. See Figure 10
Figure 10. Open Control Panel
2. Open “Network connections” icon. See Figure 11
Figure 11. “Network connections”

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
3. In “Network connections” folder right mouse button click on the LAN connection
and click “Properties”. See Figure 12
Figure 12. LAN Connection properties
4. Choose “Internet protocol (TCP/IP)” and click “Properties”. See Figure 13.
5.
Figure 13. Internet Protocol Properties
5. If you want to connect to the unit using PC/Laptop you can just change an IP-
address on the Ethernet adaptor to some address from 192.168.1.0/24 network
(e.g. change “IP-address” field to “192.168.1.23” and “Subnet mask” to
“255.255.255.0”). After that click OK and move to step 7. See Figure 14

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Figure 14. Change IP-address
6. If you are in a LAN and you do not want to change your primary IP-address so
you could keep LAN connectivity, you can assign an alias. In order to do that,
press “Advanced…” button (Figure 14). In “Advanced TCP/IP Settings” click
“Add” and put alias IP-address and mask (e.g. “192.168.1.2” and “255.255.255.0”
correspondingly). See Figure 15. Click OK in all windows opened in the described
procedure.
Figure 15. Create alias

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
7. Run “Telnet” utility using “Start->Run” and type “telnet IP-address” where IP-
address is the unit’s IP-address (by default: 192.168.1.20).
3. Configure
To configure via web page:
To connect to the device via Web-browser type: http://<device IP-address> (by
default: http://192.168.1.20).
You can also make an SSL-secured connection: https://<device IP-address> (by
default: https://192.168.1.20).
For complete Web-interface configuration and user guide please see B5 Wireless
Bridge Configuration Manual.
To configure via command line:
For simplest configuration in
bridge mode type:
mint <RF IFNAME> start (ex. mint
rf4.0 start)
switch group 1 add eth0 rf4.0
switch group 1 start
switch admin-group 1
switch start
Check connectivity
Type command: mint map
If there are active nodes in the command output then you have the connection:
To change IP on Ethernet interface:
Type: ifc eth0 <IP address>/<Net
Mask> #This will add IP address as a
new alias.
Type: ifc eth0 <IP address>/<Net
Mask> -alias #This will delete IP
address.

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Figure 16. Mint Map
On the picture there is one active node “TEST1Client”.
4. Diagnose
Diagnose tools:
Mint map.
Check Color indication with Signal levels and Bitrates.
Interface name
Neighbor
node ID Neighbor
node name Neighbor
node MAC Cost of
routes to
neighbor
Signal level (in db)
abouve the noise
threshold for currant
bitrate (From/To)
Neighbor node
type
Node’s type
MAC and name of
current node
Receive/
Transmit
bitrates
Network logical number Noise threshold
(in dbm)
Node’s ID
Number of
errors
Number of
retries
Common color
Yellow color
Yellow color with
red background
Figure 17. Mint Map
Color indication of «mint map»command output:
Common color identifies neighbor nodes that have acceptable characteristics of a
link to the current node.
Yellow color identifies neighbor nodes that potentially may have problems with
sustainability and quality of a link to the current node. In this case link quality can be
improved through the change of certain parameters (for example, lowering bitrates).
Yellow color with red background identifies neighbor nodes that have unsatisfactory
characteristics of a link to the current node. For example, neighbor nodes that have
low characteristics of a link on the lowest possible bitrate or have errors are marked
this way. In this case link quality can be improved by such actions as antenna
alignment, cable connectivity testing and so on.
Muffer utility
Type: muffer stat
Muffer can be used for statistics gathering for estimating link load intensity and per
client.

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Figure 18. Muffer Stat
The following decisions can be made by analyzing the outputted parameters:
If the number of repeated packets is comparable with total number of packets that
means that you might have an interference source on the selected frequency. For
normally operating link the percentage of repeated packets should not exceed 10%.
It is extremely important to obtain a permanent zero value for the average number
of repeats per packet. If the value is not zero that means that the link is NOT working
properly and requires further improvement
If total percentage of repeated packets and the percentage of packets that were
repeated at least once are close to each other that might mean that you have got
a permanent source of interference. Otherwise, it means that a strong interference
source appears from time to time breaking your signal
Concerning the fact that statistics module outputs the information for each MAC-
address separately, you can reveal the problem for some specific unit on the
wireless network
Load meter.
Type: loadm –l <IFNAME> (for example, loadm –l rf4.0)
Load meter is a tool to perform the channel load monitoring. It allows estimating the
load of a system interfaces specified by interface parameter.

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
Figure 19. Load Meter
Useful commands that should be remembered:
“help” –lists all available commands in the unit
“config show” (or “co sh” for short) – shows unit’s current configuration
“config save” (or “co sa” for short) – saves unit’s current configuration
“restart y” –immediate unit reboot. Reboot lasts for 20-30 seconds (approximately)
and during this time you will not be able to control it over Telnet. “restart XX” can be
used for a postponed reboot so the unit will be rebooted in XX seconds (this is very
helpful when there is a risk of loosing a remote unit while performing risky
manipulations with configuration). “restart 0” cancels postponed reboot.
“quit” –closes current telnet session

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
5. Outdoor
Mounting kit (MOUNT-KIT-85).
Grounding
Antenna should be placed on the mast on the level that is at least 1 meter lower than
a mast’s top. In this case it is of big probability that the lightning strikes the mast and
not the antenna. The mast is to be grounded on the grounding contour according to
your local standards. When the lightning strikes the antenna, the current goes through
the coaxial cable which grounds ODU clamp with the mast –the mast is grounded
via the grounding contour. The direct lightning strike to the STP service cable (ODU-
IDU) is partially terminated on the grounded IDU case. Partial termination means that
the direct lightning strike will probably destroy an STP cable. The service cable pickups

Altai Technologies Ltd. All rights reserved
B5 Quick Installation Guide
TPS13-010_rev1.0
from the electromagnetic impulses are terminated on the IDU case by the winding
shield, and further –on the IDU grounding. IDU is grounded via a three-conductor
power cord and a plug containing a ground. The data & power wires pickups are
terminated via IDU protection scheme (three-conductor power cord and a plug
containing a ground).
Antenna pole, tower, ODU and lightning arrestor should be connected to
the first common grounding contour. Cable thickness should be no less
than 10AWG using corrosion-steady connectors. It is highly recommended
to entrust grounding contour development to the skilled personnel.
A special attention should be paid if antenna used is not DC-shorted. In this case
additional lightning arrestor should be used between the antenna and ODU.
Suggested grounding diagram is shown on the picture below.
Figure 20. Grounding
