Altec Vision NU-VIEW 1024 User manual

1 May/2003
Copyright 2003 Alltek Vision, LLC. All rights reserved.
USER’S MANUAL

2 May/2003
TableofContents
1. Introduction
1-1. Features ………………………………………3
1-2. Package Contents …………………………….3
1-3. Location of Controls (Box Set) ………………4
1-4. Location of Controls (Remote) ………………4
2. Set Up
2-1. Installing Stand ………………………………..5
2-2. Installing Batteries ……………………………5
2-3. Connecting TV Antenna/Cable ………………6
2-4. Connecting Video Out To Monitor …………...6
2-5. Connecting Video Input From PC ……………7
2-6. Connecting Audio Line Out ……………….….7
2-7. Connecting Power Supply …………………….8
2-8. Connecting Audio/Video Equipment …………8
3. Operation
3-1. Selecting Input Source …………………….…..9
3-2. Programming Channel Memory ………………10
3-3. Watching TV Programs ……………………….11
3-4. Convenient Remote Functions ………………..12
3-5. Selecting Stereo/SAP Broadcasts ……………..13
3-6. Adjusting the Picture ………………………….14

3 May/2003
1.Introduction
Congratulations! You have purchased the Nu-View1024 TV Tuner Box to
enhance your multimedia PC. We will guide you through all of the features,
installation and operation. This manual will help you use the many exciting and useful
features to make your TV viewing more enjoyable than ever before.
1-1. Features
! Watch live broadcast TV or cable TV on your CRT or LCD monitor
! Built with cable ready TV tuner with 125 channels and automatic channel scan
! Auto Channel memory to set up channels
! MTS option that supports multiple audio programs (Stereo, Dual, Mono or SAP)
! Video source selection for TV, composite or S-Video inputs
! External Video Source (composite and S-Video) supports NTSC, PAL and
SECAM
! Can connect game console, Camcorder ,VTR , VCD/DVD player for viewing on
your monitor
! Full function remote control
1-2. Package Contents
! Nu-View TV Tuner BOX
! Stand
! Source cable (AV & Composite Input)
! Video input from PC cable
! Video out to LCD Monitor cable
! Stereo Audio cable
! Remote controller
! Batteries
! DC 12V power adapter
! User’s manual

4 May/2003
1-3. Location of Controls (Box Set)
1-4. Location of Controls(Remote)
Front view Rear view
Source change button
Channel Return button
Add channel button
CATV system change for NTSC only
Mute button
Volume ＋/－button
Channel ▲/▼button
Channel Number buttons
Channel program button
Erase channel button
TV/CATV button
Function button
Power button
Status On Screen Display
MTS button for NTSC only
N
on function
N
on function
N
on function
N
on function

5 May/2003
2.SetUp
2-1.Installing Stand
2-2.Installing Batteries
1. Place the Remote Control with the face down. Press down on the ridged area of the
battery cover and slide it off.
2. Place two “AAA” size batteries, matching the + and – sign on each battery to the +
and – sign of the battery compartment. Then, place the battery cover until the lock.
Notes
! Aim the Remote Control directly at the Nu-View from a distance of no more than
7m and the wider the angle within 90, and be sure there is no obstruction between
the Remote Control and Nu-View.
! If the unit does not operate properly, the batteries might be exhausted. Replace
them with new ones.
! To avoid damage from possible batteries leakage, remove the batteries if you do
not use for a long time.
N
u-View box
Stand
Place the stand until the lock

6 May/2003
2-3. Connecting TV Antenna/Cable
You can use either an indoor or outdoor antenna to VHF and/or UHF channels.
You can receive Cable TV by connecting a cable supplied by your local cable
company.
2-4. Connecting Video Out To Monitor
300 ohm twin-lead cable
Antenna adapter
OR
75 ohm coaxial cable
VHF, UHF or
Cable TV
TV signal input
Rear view
Rear view
Video out Video out to LCD Monitor cable(12cm)
LCD Monitor
15pin Female type
D-SUB connector
9pin Male type Mini
Din connector

7 May/2003
2-5. Connecting Video Input From PC
2-6. Connecting Audio Line Out
Rear view
Video input Video input from PC cable(100cm)
PC
15pin Male type
D-SUB connector
8pin Male type Mini Din
connector
Rear view
Audio out
Stereo Audio cable(180cm) Speaker
3.5φAudio connector

8 May/2003
2-7. Connecting Power Supply
2-8. Connecting Audio/Video Equipment
Rear view
DC 12V Input
AC/DC Adaptor
Power source
Output: 12V DC 500mA
4pin Female type Mini Din connector for S-Video input
RCA connector for Video input
Audio input connector
V8/DV
Front view
AV Source Input
or VCD/DVD, Game
Source cable(10cm)
8pin Male type Mini Din
connector

9 May/2003
3.Operation
3-1. Selecting Input Source
1. Press Power button to turn on the Nu-View.
2. When you press Source button, the TV/CATV,AV,S-Video, and PC input source
will be automatically changed by loop as Figure.3-1.
Front view
Source
Power
PC Mode
TV Mode
AV Mode
S-Video Mode
Figure.3-1

10 May/2003
3-2. Programming Channel Memory
TV/CableTVfunction
1. Press Power button to turn on the Nu-View. If power has been turned on, press
Source button to select TV mode. (Ref. 3-1. Selecting Input Source)
2. Each time you press TV/CATV button, TV or Cable TV mode will be selected in
order. If you selected Cable TV, you press System button each time, the STD, HRC,
IRC mode will be selected in order.
ChannelProgramfunction
1. Press Scan button to start channel programming. The TV will automatically cycle
through all the TV or Cable TV channels depending on the mode selected, and
store active channels in the channel memory.
2. When channel programming is complete, press CH▲or ▼button to make sure
the channel programming has been done properly.
Add/Erasefunction
1. Select the channel you want to erase using the CH▲or ▼button, or select the
channel you want to add using the Channel Number button.
2. Press DEL or INS:
! To erase the channel: Press DEL button indicating that the channel has been
erased from the memory.
! To add the channel: Press INS button indicating that the channel has been
memorized.
Front view
Power
Source
CH▲▼
Scan
TV/CATV
System
Insert
Delete
CH Number

11 May/2003
3-3. Watching TV Programs
1. Press Power button to turn on the Nu-View. If power has been turned on, press
Source button to select TV mode.
2. Select a channel in one of the following two ways.
! To scan the memorized channels in numerical sequence
Press CH ▲ to select the next higher channel.
Press CH ▼ to select the next lower channel.
! To select a channel directly
Press the Channel Number buttons (0-9, 100)
Example: To select channel 7, press “7”.
To select channel 12, press “1” , “2”.
To select channel 120, press “100”, “2”, “0”.
3. Press Vol + /- to adjust the volume.
To increase the volume, press +.
To decrease the volume, press -.
WatchingVideoInput
The Source button is used to view the signals coming from other devices like
VCD/DVD Players to display. Ref.3-1. Selecting Input Source.
Note:
The Vol+/- button on the Function key function as the adjust button while any of the
Function displays (Brightness, Contrast, Color, V-Shift, H-Shift) are on the screen.
Ref. 3-6. Adjusting the Picture
Front view
Power
Source
CH▲▼
Vo l + / -
CH Number

12 May/2003
3-4. Convenient Remote Functions
To display on-screen information
! On AV mode: Press OSD button to display the AV on-screen .
! On S-Video mode: Press OSD button to display the S-Video on-screen .
! On TV mode: Press OSD button to display the Channel number, System, MTS,
Volume on-screen information.
!
To mute the sound
Press Mute button to mute the sound. The word “MUTE” will be displayed on
the screen. To restore the sound, press Mute button again, and the “MUTE” will
disappear.
To change quickly between two channel
1. Select the first channel you want to view.
2. Select the other channel with the Channel Number buttons or CH▲, CH▼.
3. Press Recall button. The previous channel will return.
Each time you press Recall button, the TV will switch back and forth between
the two channel.
Front view
CH▲▼
Mute
CH Number
OSD
Recall

13 May/2003
3-5. Selecting Stereo/SAP Broadcasts
The MTS(Multi-channel TV Sound) feature allows you to improve your TV viewing
with high fidelity stereo sound. MTS also provides for an extra channel, SAP(Second
Audio Program), used to transmit a second language or other audio information.
To use MTS function
When you press MTS button, the Stereo, SAP, Dual, Mono mode will be
automatically changed by loop as Figure.3-5.
“MTS” does not function in Video mode (AV mode, S-Video mode).
MTS
Stereo Mode
SAP Mode
Dual Mode
Mono Mode
Figure 3-5

14 May/2003
3-6. Adjusting the Picture
You can adjust the picture quality(Brightness, Contrast, Color, V-Shift, H-Shift) to
suit your taste.
To adjust the picture quality
1. When you press Function button, Brightness, Contrast, Color, V-Shift, H-Shift
mode will be automatically changed by loop as Figure.3-6.
2. Press Vol+ or Vol- button to adjust the level.
Example: Brightness adjustment mode display.
Function
Brightness mode
Contrast mode
Color mode
V-Shift mode
Vo l + / -
H-Shift mode
Figure 3-6

15 May/2003
17568 E. Rowland Street
City of Industry, CA 91748
T: 1.888.229.NUTV(6888)
T: 1.626.839.3788
F: 1.626.839.3787
www.alltekvision.com
Copyright © Alltek Vision, LLC 2003. All rights reserved.
