User Manual
Model: MA5000
®
™

2
support.alteclansing.com
Table of Contents
Welcome 03
Features 03
What’s in the box 04
Compatibility 04
At a Glance 05
IR Remote 06
Setting up your inAir 5000 07
Setting up with the inAir Guide app 07
Setting up with a browser 12
Push button setup (WPS) 18
Audio Playback 20
AirPlay 20
Aux input for external devices 21
Play audio from iPad, iPhone, iPod touch
through USB connection 22
Resetting your inAir 5000 23
Firmware updates 24
inAir Guide app 24
Ethernet wired to Mac/PC 25
LED indicator chart 27
Troubleshooting 28
RECOMMENDED
RECOMMENDED

3
support.alteclansing.com
Welcome
Congratulations on your purchase of
the inAir™ 5000. Altec Lansing’s 75
years of audio engineering excellence
promises amazing sound clarity, lower
bass response and a wider sound field
to please even the most discerning
music enthusiasts.
Now with AirPlay® technology, you can
stream your music wirelessly from your
Mac/PC computer or iOS device to
your inAir 5000. Place an inAir 5000
in the living room, bedroom, kitchen or
anywhere you wish. All you need is a
Wi-Fi network to get started.
Setting up the inAir 5000 is easy with the free inAir Guide iOS App.
Download the inAir Guide app, follow the prompts, and your home will be
filled with music in minutes.
• Wirelessly stream music from your iPad, iPhone and iPod touch devices
(iOS 4.2 or later)
• Wirelessly stream music from your iPad, iPhone, or iPod touch device
(iOS 4.2 or later)
• Use your USB cable for audio playback or charging compatible devices
• Play audio directly through AUX
• Enjoy the convenient IR remote to play, pause, rewind and advance
Features

4
support.alteclansing.com
What’s in the box
Compatibility
Quick Connect Guide &
Safety & Warranty
AirPlay
inAir 5000 works with iOS 4.2 and iTunes 10.1 (Mac and PC), iPad 2, iPad,
iPhone 4S, iPhone 4, iPhone 3GS, iPod touch (4th, 3rd and 2nd generation).
USB charging
inAir 5000 works to charge iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G,
iPhone, iPod touch (4th, 3rd, 2nd, and 1st generations), iPod classic and iPod
nano (6th, 5th, 4th, 3rd and 2nd generation).
IR remote control
AC power adaptor & cord
Ethernet cable

5
support.alteclansing.com
At a glance
1. Mode LED (Aux, USB, & AirPlay)
2. Status LED (see LED chart, pg 26)
3. Mute LED (toggle between mute on/mute off)
Front view
1. Power Switch
2. AC
3. iPod/iPhone
4. Ethernet
5. Wi-Fi Connect
6. Reset
Rear view
1
1
2
2
3
354 6

6
support.alteclansing.com
At a glance continued...
1. DIM mode
2. AUX button
3. AUX connection
4. Headphone
connection
1. Volume up
2. Volume down
3. Mute
Side view left Side view right
1. Play/Pause
2. FWD/RWD
3. Volume +/-
Using your remote
for the first time:
remove plastic tab
Replacing your
remote battery
Battery:
CR2032, 3V
IR remote control
11
1
22
2
33
3
4

7
support.alteclansing.com
inAir 5000 Setup using the inAir
Guide app
• Make sure you have a Wi-Fi network in your home.
• A current iOS device running iOS® 4.2 or later. (iPad, iPhone, or iPod touch)
• Download and install the free inAir Guide app for your iOS device
(available at the App Store).
• Have your Wi-Fi network name and password ready for reference.
• The contents of your inAir 5000 package should be handy.
• If you don’t have an iOS device, see Wi-Fi setup (pg. 12)
• Attach your iOS device to the inAir 5000 with your Apple USB cable.
• Connect your inAir 5000 to power with the supplied AC adapter.
• Flip up the master power switch, located on the back of your device to
power on the inAir 5000. The Status LED will begin to flash blue.
1. Before we begin
2. Connect your devices
RECOMMENDED

8
support.alteclansing.com
Using the inAir Guide app continued...
• Please wait 20-30 seconds for the
inAir 5000 to power on.
• When the Status LED begins to flash
purple, launch the app.
• Press SETUP to continue.
NOTE: If your device is not detected, make sure your USB cable
is securely attached and that your inAir 5000 is powered on.
3. Using the app
• Give your inAir 5000 a custom name
or select one from the predefined list.
Creating a unique name is helpful if
you plan on adding multiple devices in
your home.
• Press NEXT
• You will receive a confirmation that you
have successfully named your inAir 5000.
• Press NEXT
NOTE: To change your device name after setup, just connect
your USB cable between the inAir 5000 and your iOS device
and launch the inAir Guide app. Enter Settings and select
Device Name.
4. Naming your inAir 5000

9
support.alteclansing.com
Using the inAir Guide app continued...
• Choose your Wi-Fi network from the
available list. This will set the Wi-Fi
network on your inAir 5000.
• Enter the password if needed.
• Press NEXT
NOTE: To change your Wi-Fi Settings after setup, just connect
your USB cable between the inAir 5000 and your iOS device
and launch the inAir Guide app. Enter Settings, select ‘Wi-Fi
Networks’ and choose your new home network.
5. Connecting to your Wi-Fi Network
• Enter your email address so that we can
inform you about firmware updates.
• The “Send me info” slider lets you
opt-in to upcoming info about Altec
Lansing products and promotions.
• Press NEXT to continue.
NOTE: If you decide to bypass “Email”, you can enter this
information later in Settings.
6. Firmware update notifications

10
support.alteclansing.com
• Congratulations. Your inAir 5000 is now
ready to stream music wirelessly!
• You can now disconnect the USB cable.
• To close the inAir Guide app, press the
home button on your iOS device.
7. Device is ready
Using the inAir Guide app continued...
• Launch the music application on your
iPad, iPhone, or iPod touch.
• You can also launch iTunes from your Mac
or PC to play music.
• Look for the AirPlay icon to select
your inAir 5000.
NOTE: If the AirPlay icon does not appear, try quitting the
music application and re-launching. Make sure your iOS device
is connected to the same Wi-Fi network as your inAir 5000.
8. Play music

11
support.alteclansing.com
Using the inAir Guide app continued...
• In iTunes, go to preferences and select ‘devices’.
• Select the check box for ‘allow iTunes audio control from remote speakers’.
NOTE: This feature allows your IR Remote to be fully functional with your inAir 5000.
7. Configure iTunes to allow audio control

12
support.alteclansing.com
inAir 5000 Setup using a browser
• Make sure you have a Wi-Fi network in your home.
• You will need a Wi-Fi enabled device with an internet browser.
This can be your Mac/ PC computer, iPad, iPhone, or iPod touch.
• Make sure iTunes (10.1 or later) is running on your computer.
• Have your Wi-Fi network name and password ready for reference.
• The contents of your inAir 5000 package should be handy.
NOTE: This setup is for Wi-Fi setup using an internet browser. For iOS app setup, that works with
your iPad, iPhone, or iPod touch, please use our free inAir Guide app available at the App Store.
• Disconnect any Ethernet or power cable on your inAir 5000.
• Reconnect the power cable to your inAir 5000 and flip the master
power switch to ON. The Status LED will begin to flash blue.
1. Before we begin
2. Connect your devices
press and hold

13
support.alteclansing.com
• Wait for the Status LED on to start flashing purple. This will take
approximately 20-30 seconds.
• Press the “Wi-Fi Connect” button on the back of your device.
The LED will begin to flash orange.
• Go to your computer’s* Wi-Fi settings and select “inAir-Setup”. You will
be temporarily disconnected from your home network.
• The Status LED will change to solid blue. This confirms that you have
connected to the “inAir-Setup” successfully.
*Mac/PC computer, iPad, iPhone, or iPod touch.
2. Connect your devices continued...
Browser setup continued...

14
support.alteclansing.com
Browser setup continued...
• Launch your preferred browser.
• Type http://192.168.1.12 into the address bar and press Enter/Go.
• Wait for the “inAir-Setup” home page to load.
3. Enter the inAir-Setup home page
• Create a unique name or select one from the drop down list to
name your inAir 5000.
• Press APPLY.
• You will receive a confirmation that your device has been
named successfully.
NOTE: If you have multiple inAir 5000 speakers, it is recommended that you create a unique name for
each device to help with discoverability.
4. Name your device

15
support.alteclansing.com
Browser setup continued...
• Select your home network from the available list.
• Enter your password.
• Press the JOIN button. While the device is trying to connect to the
Wi-Fi network the status LED will flash purple. Once a connection has
been established, the status LED will turn solid blue.
NOTE: If your Wi-Fi network does not appear as in the available list, try refreshing your browser. If the
status LED continues to flash purple after 15 seconds or more, there is a problem connecting to your
home network. Usually this is caused by an incorrect password.
Follow these easy steps.
• Press the “Wi-Fi Connect” button, located on the back of your device.
• Wait for LED to start flashing orange.
• Starting from Step 2, go to your system’s Wi-Fi setting and select “inAir Setup”.
• Repeat the steps as instructed.
• Make sure to check the Wi-Fi Settings of your Mac/PC or iOS device, and re-select your home network.
5. Choose your home Wi-Fi network

16
support.alteclansing.com
Browser setup continued...
• Launch the music application on your iPad, iPhone, or iPod touch.
• You can also launch iTunes from your Mac or PC to play music.
• From iTunes, look for the AirPlay icon at the bottom right of
the application’s window to select your speaker.
NOTE: if the AirPlay icon does not appear try quitting then re-launching the iTunes or iOS application.
6. Play music

17
support.alteclansing.com
Browser setup continued...
• In iTunes, go to preferences and select ‘devices’.
• Select the check box for ‘allow iTunes audio control from remote speakers’.
NOTE: This feature allows your IR Remote to be fully functional with your inAir 5000.
7. Configure iTunes to allow audio control

18
support.alteclansing.com
Push Button Setup
• Push the ‘WPS’ button on your router.
• Press and hold the ‘Wi-Fi Connect’ button, located on the back of your
inAir 5000, for 5+ seconds.
• The Status LED will turn blue and begin to flash rapidly.
• Wait for the status LED to turn to solid blue. This will confirm that the
inAir 5000 has successfully connected to your router.
NOTE: Setting up your inAir 5000 by this method will automatically generate a default name. For
example, “inAir 5000 12346”. You can use the inAir Guide app, available on the App Store, or enter
“Wi-Fi Setup” to change your device name.
1. Setup
press and hold
WPS

19
support.alteclansing.com
Push Button Setup continued...
• Launch the music application on your iPad, iPhone, or iPod touch.
• You can also launch iTunes from your Mac or PC to play music.
• Look for the AirPlay icon to select your inAir 5000.
2. Play music
