Microphone input electronically balanced, discrete input configuration
Frequency response 10Hz to 55kHz, + /-3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Gain range 0dB to 60dB (MIC)
SNR (Signal to Noise Ratio) 115dB
Line input electronically balanced
Frequency response 10Hz to 55kHz, +/-3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Sensitivity range +15dBu to- 45dBu
Line input Balanced/unbalanced
Frequency response 10Hz to 55kHz, +/-3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Microphone input 1.4kOhm
Channel Insert return 2.5kOhm
All other inputs 10kOhm or greater
Tape out 1kOhm
All other output 120Ohm
Hi shelving +/- 15dB @12kHz
Mid bell (mono) +/- 15dB @100Hz to 8kHz
Hi Mid (stereo) +/- 15dB @ 3kHz
Mid low (stereo) +/- 15dB @500Hz
Low shelving +/- 15dB @80Hz
Low Cut filter 75Hz, 18dB/oct.
A/D and D/A converters 24 bit
DSP resolution 24 bit
Hall, Room, Vocal & Plate REVERBS
Mono & Stereo DELAY (max DELAY TIME 650ms)
Chorus, Flanger & Reverb MODULATIONS
REVERB+DELAY,REVERB+CHORUS,
REVERB+FLANGER combinations
Presets 256
16-position PRESET Selector
16-position VARIATION selector
PEAK LED
MUTE SWITCH with LED indicator
Fader 0 dB, channels muted: -100dBr (ref.:+4dBu)
Fader 0dB, all input channels assigned and set to
UNITY gain: -90dBr (ref.:+4dBu)
+22dBu balanced XLR,
+22dBu unbalanced, 1/4" jacks
AUX Returns gain range -Ќto +15dB
AUX Sends max out +22dBu
USA/Canada 100-120V~, 60Hz
Europe 210- 240V~, 50Hz
U.K./Australia 240V~, 50Hz
Power Consumption 70 watts
100-120V~ : T800mAL
210-240V~ : T500mAL
Main connection Standard IEC receptacle
Max output
Main Mix Section
Main voltage
Fuse
Power supply
DSP Section
Type of effects
Controls
Noise (Bus noise)
Mono input channels
Stereo input
channels
Impedances
Equalization
. Specificatio
