Alto C2K-13 Quick start guide

C2K-13
230V
Polisher
(Schuko)
Section II
Parts and Service Manual
(70210A)
CLARKE TECHNOLOGY Operator's Manual - C2K-13 230V Page - 59 -

CLARKE TECHNOLOGY Operator's Manual - C2K-13 230V Page - 5 -
WARNING: Use only brushes and accessories supplied by the manufacturer.
ACCESSORIES
Thefollowingaccessoriesareavailable.
1. Polishing and waxing brushes.
2. Brushes with natural or synthetic bristles for
scrubbing.
3. Synthetic pad holders.
4. Synthetic pads for polishing, scrubbing,
stripping and spray buffing.
5. Brushes with metal or wood backs and with
holes to let the solution flow through.
6. Solution tank.
Brushes and Accessories
Brush, Union Mix 52343A
Scrubbing Brush Polypropylene 51702A
CarpetBrush 51496B
Perma Grip Drive Pad Asm. 66101A
Super Grip Drive Pad Asm. 37006A
White Pads (5) 976031
Red Pads (5) 976032
Blue Pads (5) 976034
Brown Pads (5) 976035
Solution Tank Asm. 50026A
MachineSpecifications
Model:C2K-13 01236A
Motor(HP) 1/3
Brush/Pad(rpm) 145
NomianlBrush/PadDiameter 13" (33 cm)
Height 44" (112 cm)
Width 13" (33 cm)
Length 15" (38 cm)
Machineweight 46 lbs. (20.87 kg)
Shippingweight 56 lbs. (25.40 kg)
CordLength 50' (15.2 m)

CLARKETECHNOLOGY
C2K-13
Assembly Drawing 3/02
1
2
345643
9
7
8
10
11
46
40
1
10
13
41
38
22
21
19
20
18
17
16
14
15
26
26
3711 42
25
24
123
27
25
22 28
32
24 23 1
33
34
35
36
12
39
49
50
51
53
54
55
54
30
44
31
29
44
43
56
45
47
63
57
62
61 58
59
60
64
65
Page -60 - CLARKE TECHNOLOGY Operator's Manual - C2K-13 230V

Ref. Part No. Description Qty.
1 85383A Screw, 10-32 x 3/410
2 50779A Handle, Front 1
3 50798A Lever, Switch 2
4 50820A Spring, Extension 2
5 50806A Button, Interlock 1
6 40109A Switch 2
7 50799A Interlock, Main 1
8 50821A Spring, Compression 1
9 50780A Handle, Rear 1
10 920722 Nut, 10-32 ESNA 7
11 962957 Screw 2
12u962727 Screw 2
13 10092A Cord, Interconnect 1
14 461404 Cam, Locking (included in 47) 1
15 925592 Roll Pin, ¼ (included in 47) 1
16 441301 Bolt, Locking Cam
(includedin 47) 1
17 980349 Washer, Wear Cam 1
18 50975A Arm Link, RH 1
19 50781A Clamp, Handle 1
20 50976A Arm Link, LH 1
21 980645 Washer, Flat 3/81
22 920342 Nut, 3/8-16 ESNA 2
23 87035A Washer, Fender #10 SS 2
24 50793A Wheel, 5" 2
25 87050A Washer, 5/8Nylon 2
26 50794A Bushing, Nylon 2
27 80087A Screw, 3/8 -16 x 6 1
28 57165A Plug,Button 1
29 407302 Ring, Retaining 1
30 403516 Pinion, Motor 1
31 408203 Spacer, Bearing 1
32 50974A Frame, Main 1
33 50971A Shield, Brush 1
34 50972A Bumper 1
35 980652 Washer, Lock 5/16 4
36 85817A Screw, 5/16-18 x 2 4
37 50796A Bushing, Cord 1
38 50795A Tube, Handle 1
39 32396A Cover, Motor 1
40 50797A Relief, Strain (included w/41) 1
41 50931A Cord Assembly (includes 40) 1
42 441401 Cam Assembly (incl. 14, 15 & 16) (1)
43 403519 Gear, Drive 1
44 902657 Bearing 1
45 980645 Washer, 3/8Flat 1
46 82100A Lock nut (not illustrated) 1
47 980666 Washer, 3/8Ext Star 1
49 40152A Motor 1
50 77378A Label, Clarke Technology 1
51 915028 Key, 1/8x 5/8Woodruff 1
52 51523A Strain Relief (not illustrated) 1
53 407712 Shaft, Intermediate 1
54 980361 Washer, Thrust 2
55 403520 Gear 1
56 413401 Gasket, Gear Unit 1
57 404206 Housing, Gear 1
58 407604 Seal, Oil 2
59 406604 Plate, Brush Drive 1
60 962668 Screw, 10-24 x 3/84
61 962241 Screw, 10-24 x ½ 6
62 980982 Washer, #10 Plain 6
63 920268 Nut, 3/8-24 LH Hex 1
64 962823 Screw, ¼-20 x ½ 4
65 920110 Nut, 5/16-18 ESNA 4
CLARKETECHNOLOGY
C2K-13
Assembly Drawing Parts List 3/02
CLARKE TECHNOLOGY Operator's Manual - C2K-13 230V Page - 61 -
NOTE: uindicates a
change has taken place
since last publication of
this manual

Page -62 - CLARKE TECHNOLOGY Operator's Manual - C2K-13 230V
CLARKETECHNOLOGY
C2K-13
Wiring Diagram 230V 5/00
WARNING: All electrical repairs must be performed by qualified personnel only.
