Altronix TROVE Trove1C1 User manual

SIGNALING
Rev. TCDVI011117
Trove1C1
- Trove1 enclosure with Altronix/CDVI backplane (TC1)
TC1
- Altronix/CDVI backplane only
Trove2CV2
- Trove2 enclosure with Altronix/CDVI backplane (TCV2)
TCV2
- Altronix/CDVI backplane only
Trove3CV3
- Trove3 enclosure with Altronix/CDVI backplane (TCV3)
TCV3
- Altronix/CDVI backplane only
Installation Guide
All registered trademarks are property of their respective owners. More than just power.™
Installing Company: _____________________ Service Rep. Name: __________________________________________
Address: ________________________________________________________ Phone #: _________________________
Access & Power Integration

- 2 - Trove / CDVI
Overview:
Trove1C1, Trove2CV2 and Trove3CV3 accommodate various combinations of CDVI boards with or without Altronix power supplies and
accessories for access control systems.
Specifications:
• 16 Gauge backplane and enclosure with ample knockouts for convenient access.
Agency Listings:
• UL 294 - 6th edition: Line Security I, Destructive Attack I, Endurance IV, Stand-by Power II*.
* Stand-by Power Level I if no battery is supplied.
• This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.
• CE European Conformity.
Installation Instructions for Trove1, Trove2, Trove3:
1. Remove backplane from enclosure prior to mounting (do not discard hardware).
2. Trove1C1 (Pg. 8):
Mark and predrill holes on the wall to line up with the top two keyholes in the enclosure. Install two upper fasteners and screws in
the wall with the screw heads protruding. Place the enclosure’s upper keyholes over the two upper screws; level and secure.
Mark the position of the lower two holes. Remove the enclosure. Drill the lower holes and install the two fasteners.
Place the enclosure’s upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws.
Trove2CV2 and Trove3CV3 (Pg. 10 and Pg. 12):
Mark and predrill holes on the wall to line up with the top three keyholes in the enclosure.
Install three upper fasteners and screws in the wall with the screw heads protruding.
Place the enclosure’s upper keyholes over the three upper screws; level and secure.
Mark the position of the lower three holes. Remove the enclosure. Drill the lower
holes and install the three fasteners. Place the enclosure’s upper keyholes over the
three upper screws. Install the three lower screws and make sure to tighten all screws.
3. Mount included UL Listed tamper switch(es) (Altronix Model TS112 or equivalent)
in desired location, opposite hinge. Slide the tamper switch bracket onto the edge of
the enclosure approximately 2” from the right side (Fig. 1, pg. 2).
Connect tamper switch wiring to the Access Control Panel input or the appropriate
UL Listed reporting device. To activate alarm signal open the door of the enclosure.
4. Mount Altronix/CDVI modules to TC1, TCV2 or TCV3 backplane, refer to pages 3, 4, 5.
Fig. 1
Trove1C1
Trove1 enclosure with
TC1 Altronix/CDVI backplane
• Includes: tamper switch, cam lock,
and mounting hardware.
Enclosure Dimensions (H x W x D):
18” x 14.5” x 4.625”
(457mm x 368mm x 118mm).
TC1
Altronix/CDVI backplane only
• Includes mounting hardware.
Dimensions (H x W x D):
16.625” x 12.5” x 0.3125”
(422.3mm x 317.5mm x 7.9mm).
TC1 accommodates a combination
of the following:
Altronix Modules:
• One (1) AL400ULXB2, AL600ULXB,
AL1012ULXB, AL1024ULXB2,
eFlow4NB, eFlow6NB, eFlow102NB or
eFlow104NB.
• One (1) ACM4(CB), MOM5, PD4UL(CB),
PD8UL(CB), PDS8(CB), VR6.
CDVI Modules:
• Four (4) A22K/A22NB/ADH10 modules.
Trove2CV2
Trove2 enclosure with
TCV2 Altronix/CDVI backplane
• Includes: tamper switch, cam lock,
and mounting hardware.
Enclosure Dimensions (H x W x D):
27.25” x 21.75” x 6.5”
(692.15mm x 552.5mm x 165.1mm).
TCV2
Altronix/CDVI backplane only
• Includes mounting hardware.
Dimensions (H x W x D):
25.375” x 19.375” x 0.3125”
(644.5mm x 482.6mm x 7.9mm).
TCV2 accommodates a combination
of the following:
Altronix Modules:
• Two (2) AL400ULXB2, AL600ULXB,
AL1012ULXB, AL1024ULXB2,
eFlow4NB, eFlow6NB, eFlow102NB or
eFlow104NB.
• One (1) ACM8(CB), or two (2) MOM5,
PD4UL(CB), PD8UL(CB), PDS8(CB),
VR6.
CDVI Modules:
• Five (5) A22K/A22NB/ADH10 modules.
Trove3CV3
Trove3 enclosure with
TCV3 Altronix/CDVI backplane
• Includes: two (2) tamper switches, cam
lock, and mounting hardware.
Enclosure Dimensions (H x W x D):
36.12” x 30.125” x 7.06”
(917.5mm x 768.1mm x 179.3mm).
TCV3
Altronix/CDVI backplane only
• Includes mounting hardware.
Dimensions (H x W x D):
34” x 28” x 0.3125”
(863.6mm x 711.2mm x 7.9mm).
TCV3 accommodates a combination
of the following:
Altronix Modules:
• Up to four (4) AL400ULXB2,
AL600ULXB, AL1012ULXB,
AL1024ULXB2, eFlow4NB, eFlow6NB,
eFlow102NB or eFlow104NB.
• Up to four (4) ACM8(CB), MOM5,
PD4UL(CB), PD8UL(CB), PDS8(CB),
VR6.
CDVI Modules:
• Ten (10) A22K/A22NB/ADH10 modules.
Tamper Switch
(provided)
To Access Control Panel or
UL Listed Reporting Device
Edge of
Enclosure
Enclosure

Trove / CDVI - 3 -
Spacer
CDVI - A22K/A22NB/ADH10
Access Controller
Backplane
Fig. 2b
TC1: Configuration of Altronix Power Supply
and/or Sub-Assembly Boards and CDVI Modules
1. Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers or Altronix Sub-Assembly boards
(Fig. 2, pg. 3). Fasten metal spacers in the correct locations to provide proper grounding, see below (Fig. 2, pg. 3).
2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 2a, pg. 3).
3. Mount appropriate CDVI A22K/A22NB/ADH10 modules into the correct positions (Fig. 2, pg. 3) by postioning spacers over
appropriate holes on the backplane and depress down on board to secure spacer to the backplane (Fig. 2, 2b, 2c, pg. 3).
Note: CDVI A22K/A22NB/ADH10 modules have one (1) RJ45 jack each.
Please make sure that they are mounted correctly, as shown in Fig. 2 below.
4. Fasten TC1 backplane to Trove1 enclosure utilizing pan head screws (provided).
Fig. 2 - Trove1C1/TC1 Configurations
Plastic Spacer
pre-mounted into
CDVI Atrium modules
Insert into
TC1/TCV2/TCV3 backplane
Fig. 2c
Altronix
Power
Supply
Altronix
Sub-
Assembly
Metal
Spacer
Placement
RJ45 Jack RJ45 Jack RJ45 Jack
RJ45 JackRJ45 JackRJ45 Jack
CDVI
A22K/A22NB/ADH10
CDVI
A22K/A22NB/ADH10
CDVI
A22K/A22NB/ADH10
CDVI
A22K/A22NB/ADH10
CDVI
A22K/A22NB/ADH10
CDVI
A22K/A22NB/ADH10
Pem
Spacer
Altronix
Power Supply or
Sub-Assembly
Backplane
Pan Head
Screw
Fig. 2a

- 4 - Trove / CDVI
Altronix
Power Supply
Altronix
Power Supply or
Sub-Assembly
Altronix
Sub-Assembly
Metal Spacer Placement
Metal Spacer Placement
RJ45 Jack RJ45 Jack
RJ45 Jack
RJ45 Jack
RJ45 Jack
CDVI - A22K/A22NB/ADH10
CDVI - A22K/A22NB/ADH10
CDVI - A22K/A22NB/ADH10
CDVI - A22K/A22NB/ADH10CDVI - A22K/A22NB/ADH10
TCV2: Configuration of Altronix Power Supply
and/or Sub-Assembly Boards and CDVI Modules
1. Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers or Altronix Sub-Assembly boards
(Fig. 3, pg. 4). Fasten metal spacers in the correct locations to provide proper grounding, see below (Fig. 3, pg. 4).
Note: Altronix sub-assembly position can accommodate either one (1) ACM8/ACM8CB or two (2) PD4UL/PD4ULCB,
PD8UL/PD8ULCB or MOM5.
2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 3a, pg. 4).
3. Mount appropriate CDVI A22K/A22NB/ADH10 modules into the correct positions (Fig. 3, pg. 4). by positioning spacers over
appropriate holes on the backplane and depress down on board to secure spacer to the backplane (Fig. 3, 3b, 3c, pg. 4).
Note: CDVI A22K/A22NB/ADH10 modules have one (1) RJ45 jack each. Please make sure that they are mounted correctly, as shown
in Fig. 3 below.
4. Fasten TCV2 backplane to Trove2 enclosure utilizing pan head screws (provided).
Fig. 3 - Trove2CV2/TCV2 Configurations
Spacer
CDVI - A22K/A22NB/ADH10
Access Controller
Backplane
Fig. 3b
Plastic Spacer
pre-mounted into
CDVI Atrium modules
Insert into
TC1/TCV2/TCV3 backplane
Fig. 3c
Pem
Spacer
Altronix
Power Supply or
Sub-Assembly
Backplane
Pan Head
Screw
Fig. 3a

Trove / CDVI - 5 -
Altronix
Power Supply
Metal
Spacer
Placement
Altronix
Power Supply
Metal
Spacer
Placement
Altronix
Sub-Assembly
Altronix
Sub-Assembly
Altronix
Sub-Assembly
Altronix
Sub-Assembly
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
CDVI - A22K/A22NB/ADH10
RJ45 Jack
TCV3: Configuration of Altronix Power Supply
and/or Sub-Assembly Boards and CDVI Modules
1. Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers or Altronix Sub-Assembly boards
(Fig. 4, pg. 5). Fasten metal spacers in the correct locations to provide proper grounding, see below (Fig. 4, pg. 5).
Note: Altronix sub-assembly positions can accommodate two (2) PD4UL/PD4ULCB, PD8UL/PD8ULCB or MOM5.
2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 4a, pg. 5).
3. Mount appropriate CDVI A22K/A22NB/ADH10 modules into the correct positions (Fig. 4, pg. 5). by positioning spacers over
appropriate holes on the backplane and depress down on board to secure spacer to the backplane (Fig. 4, 4b, 4c, pg. 5).
Note: CDVI A22K/A22NB/ADH10 modules have one (1) RJ45 jack each. Please make sure that they are mounted correctly, as shown
in Fig. 4 below.
4. TCV3 backplane installation: refer to note below drawing and Fig. 4d, pg. 5.
5. Fasten TCV3 backplane to Trove3 enclosure utilizing pan head screws (provided).
Fig. 4 - Trove3CV3/TCV3 Configurations
Spacer
CDVI - A22K/A22NB/ADH10
Access Controller
Backplane
Fig. 4b
Plastic Spacer
pre-mounted into
CDVI Atrium modules
Insert into
TC1/TCV2/TCV3 backplane
Back of
Backplane
Rubber
Bumper
Cutout
Fig. 4c
Fig. 4d
Pem
Spacer
Altronix
Power Supply or
Sub-Assembly
Backplane
Pan Head
Screw
Fig. 4a
Note: TCV3 bumper installation.
Prior to mounting TCV3 install rubber bumpers
(included) to the back of backplane, one (1) on
top and one (1) on bottom, approximately 1”
from the cutouts (Fig. 4d, pg. 5).
Bumpers are pre-installed in Trove3CV3

- 6 - Trove / CDVI
Notes:

Trove / CDVI - 7 -
TC1 Dimensions
16.625” x 12.5” x 0.3125” (422.3mm x 317.5mm x 7.9mm)
6.25” (158.75mm)
16.625” (422.3mm)
15.65” (397.5mm)
12.5” (317.5mm)
8.15” (207mm)
0.5” (12.7mm)
0.5” (12.7mm)

- 8 - Trove / CDVI
4.5” (114.3mm) 4.5” (114.3mm) 2.75”
(69.9mm)
1.115” (28.3mm)
1.36” (34.5mm)
1.25” (31.8mm) 1.25” (31.8mm)
1.5” (38.1mm)
8.5” (215.9mm)6.5” (165.1mm)
1.5” (38.1mm)
8.5” (215.9mm)6.5” (165.1mm)
4.5” (114.3mm)
13.0” (330.2mm)
0.6” (15.2mm)
14.5” (321.3mm)
1.45” (36.8mm)
7.25” (184.2mm)
1.95” (49.5mm)
1.1” (27.9mm)
0.6” (15.2mm)
0.57” (14.5mm)
18.0” (457.2mm)
1.25” (31.8mm)
Trove1C1 Enclosure Dimensions (H x W x D):
18” x 14.5” x 4.625” (457mm x 368mm x 118mm)

Trove / CDVI - 9 -
TCV2 Dimensions
25.375” x 19.375” x 0.3125” (644.5mm x 482.6mm x 7.9mm).
2.2” (55.9mm) 2.2” (55.9mm)
19.375” (492.1mm)
12.625” (320.7mm)
8.5” (215.9mm)
16.25” (412.8mm)
1.0” (25.4mm)
1.0” (25.4mm)
9.2” (233.7mm) 9.2” (233.7mm)
7.5” (190.5mm) 7.5” (190.5mm)
25.375” (644.6mm)
0.45” (11.4mm)0.45” (11.4mm)
0.156”
( 3.96mm)

- 10 - Trove / CDVI
6.75” (171.5mm)8.25” (209.5mm)
8.00” (203.2mm)
2.00” (50.8mm)
2.00” (50.8mm)
1.25” (31.8mm)
1.25” (31.8mm)
5.25” (133.4mm) 5.25” (133.4mm)7.00” (177.8mm)
1.25” (31.8mm)
6.25” (158.8mm) 19.80” (502.9mm)
1.00” (25.4mm)
27” (685.8mm)
1.5”
(38.1mm)
2.00” (50.8mm) 2.00” (50.8mm)
3.5”(88.9mm) 3.5”(88.9mm)
21.50” (546.1mm)
5.25” (133.35mm) 5.25” (133.35mm)
6.25” (158.8mm)
1.25”
(31.8mm)
0.85” (21.6mm)
0.5625” (14.3mm)
2.415” (61.3mm)
0.685” (17.4mm)
1.77”
(45mm)
0.885” (22.5mm)
1.125” (28.3mm)
Knockouts
2.00” (50.8mm) 2.00” (50.8mm)
Trove2CV2 Enclosure Dimensions (H x W x D):
27.25” x 21.75” x 6.5” (692.15mm x 552.5mm x 165.1mm)

Trove / CDVI - 11 -
TCV3 Dimensions
34” x 28” x 0.3125” (863.6mm x 711.2mm x 7.9mm)
0.45” (11.4mm)
2.5” (63.5mm)
2” (50.8mm)
13.5”
(342.9mm)
13.5”
(342.9mm)
13.5” (342.9mm)
25” (635mm)
0.156”
( 3.96mm)
1.0” (25.4mm)
1.0” (25.4mm)
34” (863.6mm)
28” (711.2mm)

- 12 - Trove / CDVI
Trove3CV3 Enclosure Dimensions (H x W x D approximate):
36.12” x 30.125” x 7.06” (917.5mm x 768.1mm x 179.3mm)
G
G
2”
(50.8mm)
8.75” (222.3mm) 8.75” (222.3mm)
8.62” (219mm)
7.06” (179.3mm)
1.25” (31.8mm)
1.25” (31.8mm)
2.00” (50.8mm) 7.12” (222.3mm) 9.5” (241.3mm) 9.5” (241.3mm)
30.12” (768.1mm)
14.01” (355.9mm) 14.01” (355.9mm)
1.25” (31.8mm) 1.55” (39.4mm)
1.78” (45.2mm)
1.25” (31.8mm)
1.07”
(27.2mm)
1.10” (27.9mm)
2” (50.8mm)
10.75” (273.1mm)10.75” (273.1mm) 10.62” (269.8mm)
2.00” (50.8mm)10.75” (273.1mm)10.75” (273.1mm) 10.62” (269.8mm)
36.12” (917.5mm) 33.63” (854.2mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
web site: www.altronix.com | e-mail: [email protected] | Made in U.S.A.
IITrove / CDVI K04S
MEMBER
