Altronix Maximal series User manual

Maximal11E
- Power Supply 1:
12VDC @ 4A or 24VDC @ 3A.
- Power Supply 2:
12VDC @ 4A or 24VDC @ 3A.
Maximal33E
- Power Supply 1:
12VDC or 24VDC @ 6A.
- Power Supply 2:
12VDC or 24VDC @ 6A.
Maximal37E
- Power Supply 1:
24VDC @ 10A.
- Power Supply 2:
12VDC or 24VDC @ 6A.
Maximal75E
- Power Supply 1:
12VDC @ 10A.
- Power Supply 2:
24VDC @ 10A.
Maximal13E
- Power Supply 1:
12VDC or 24VDC @ 6A.
- Power Supply 2:
12VDC @ 4A or 24VDC @ 3A.
Maximal35E
- Power Supply 1:
12VDC @ 10A.
- Power Supply 2:
12VDC or 24VDC @ 6A.
Maximal55E
- Power Supply 1:
12VDC @ 10A.
- Power Supply 2:
12VDC @ 10A.
Maximal77E
- Power Supply 1:
24VDC @ 10A.
- Power Supply 2:
24VDC @ 10A.
Rev. ME102512
Series
Expandable Power Systems
Installation Guide
Models Include:
More than just power.TM
Altronix Corp.
140 58th St. Brooklyn, NY

- 2 - Maximal Expandable Power Systems
Table of Contents:
MaximalE Overview........................................................................................................ 3
MaximalE Series Configuration Chart ............................................................................ 3
MaximalE Features.......................................................................................................... 3
MaximalE Installation Instructions ................................................................................. 4
Maintenance..................................................................................................................... 4
Power Supply Board Terminal Identification ................................................................. 5
Power Supply Board Stand-by Battery Specifications.................................................... 5
Power Supply Board LED Diagnostics........................................................................... 6
Power Supply Board Output Voltage Settings................................................................ 6
MaximalE Battery Hook-up Installation Instructions ..................................................... 7
NEC Power-Limited Wiring Requirements for Maximal11E.......................................... 8
NEC Power-Limited Wiring Requirements for Maximal13E.......................................... 9
NEC Power-Limited Wiring Requirements
for Maximal33E, Maximal35E and Maximal55E.......................................................... 10
NEC Power-Limited Wiring Requirements for Maximal37E and Maximal75E........... 11
NEC Power-Limited Wiring Requirements for Maximal77E........................................ 12
Enclosure Dimensions .................................................................................................... 13

Maximal Expandable Power Systems - 3 -
MaximalE Overview:
Maximal Expandable Power System provide system designers and installers with maximum power choices and the highest
levels of versatility. They provide 12VDC, 24VDC, or 12VDC and 24VDC simultaneously via two (2) single output power
supply/chargers. Includes AC fail, low battery and battery presence monitoring. Custom enclosure facilitates up to four (4)
12VDC/12AH batteries. All interconnecting equipment must be UL Listed.
MaximalE Series Configuration Chart:
Altronix
Model
Number
Output Voltage Options
Non Power- Limited Outputs Class 2 Rated Power-Limited 115VAC 60 Hz Input Current Power Supply Board Input Fuse Rating Power Supply Board Output Fuse Rating Agency Listings and File Numbers
Power Supply 1 Power Supply 2
Maximal11E
AL400ULXB2 AL400ULXB2
--- 2 7.0A 5A/250V 15A/32V
California State
Fire
Marshal Approved
UL File # BP6714
UL 294
UL Listed for
Access Control
System Units.
General Signaling
Equipment
Evaluated to
CSA Standard
C22.2
No.205-M1983
12VDC @ 4A 12VDC @ 4A
12VDC @ 4A 24VDC @ 3A
24VDC @ 3A 24VDC @ 3A
Maximal13E
AL600ULXB AL400ULXB2
1 1 7.0A 5A/250V 15A/32V
(AL400ULXB2)
12VDC @ 6A 12VDC @ 4A
24VDC @ 6A 12VDC @ 4A
12VDC @ 6A 24VDC @ 3A
24VDC @ 6A 24VDC @ 3A
Maximal33E
AL600ULXB AL600ULXB
2--- 7.0A 5A/250V ---
12VDC @ 6A 12VDC @ 6A
12VDC @ 6A 24VDC @ 6A
24VDC @ 6A 24VDC @ 6A
Maximal35E
AL1012ULXB AL600ULXB
2--- 6.1A 5A/250V 15A/32V
(AL1012ULXB)
12VDC @ 10A 12VDC @ 6A
12VDC @ 10A 24VDC @ 6A
Maximal37E
AL1024ULXB2 AL600ULXB
2--- 7.9A
5A/250V
(AL600ULXB
and
AL1024ULXB2)
15A/32V
(AL1024ULXB2)
24VDC @ 10A 12VDC @ 6A
24VDC @ 10A 24VDC @ 6A
Maximal55E AL1012ULXB AL1012ULXB 2--- 5.2A 5A/250V 15A/32V
12VDC @ 10A 12VDC @ 10A
Maximal75E
AL1024ULXB2 AL1012ULXB
2--- 7.0A
5A/250V
(AL1012ULXB
and
AL1024ULXB2)
15A/32V
(AL1012ULXB
and
AL1024ULXB2)
24VDC @ 10A 12VDC @ 10A
Maximal77E AL1024ULXB2 AL1024ULXB2 2--- 8.8A 5A/250V 15A/32V
24VDC @ 10A 24VDC @ 10A
MaximalE Features:
Altronix Corp.
140 58th St. Brooklyn, NY
• Filtered and electronically regulated outputs
(built-in power supply).
• Built-in charger for sealed lead acid or gel type batteries.
• AL400ULXB2, AL600ULXB, and AL1012ULXB
(Power Supply Board) maximum charge current 0.7A.
AL1024ULXB2 (Power Supply Board) maximum charge
current 3.6A.
• Automatic switch over to stand-by battery when AC fails.
• Zero voltage drop when unit switches over to
battery backup (AC failure condition).
• Low battery and battery presence supervision
(form “C” contact).
• Short circuit and thermal overload protection
with auto reset.
• AC input and DC output LED indicators.
• AC fail supervision (form “C” contact).
• Enclosure accommodates up to four (4)
12VDC/12AH batteries.
• Enclosure dimensions:
26” x 19” x 6.25” (660.4mm x 482.6mm x 158.75mm)

- 4 - Maximal Expandable Power Systems
MaximalE Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes and
authorities having jurisdiction. Product is intended for indoor use only.
Power Supply Board Terminal Identification (pg. 5)
Power Supply Stand-by Battery Specifications (pg. 5)
Power Supply Board LED Diagnostics (pg. 6)
Power Supply Board Output Voltage Settings (pg. 6)
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top three keyholes in the
enclosure. Install three upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s
upper keyholes over the three upper screws, level and secure. Mark the position of the lower three holes. Remove the
enclosure. Drill the lower holes and install the three fasteners. Place the enclosure’s upper keyholes over the three
upper screws. Install the three lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 13).
2. The power supply is pre-wired to the ground (chassis). Connect main incoming ground to the provided green
grounding conductor lead. Connect unswitched AC power (115VAC 60Hz) to the terminals marked [L, N] on both
power supply boards. Use 14 AWG or larger for all power connections. (Fig. 2, pg. 7).
Keep power-limited wiring separate from non power-limited wiring. Minimum 0.25” spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing equipment.
There are no user serviceable parts inside. Refer installation and servicing to qualified service personnel.
3. Select desired DC output voltage by setting SW1 to the appropriate position, (Maximal11E, Maximal13E,
Maximal33E, Maximal35E and Maximal37E) (Fig. 1, pg. 6). Maximal55E power supplies are factory set at 12VDC.
Maximal77E power supplies are factory set at 24VDC. Maximal75E power supplies are factory set at 12VDC and
24VDC (Power Supply Board Stand-by Battery Specifications, pg. 5).
4. Measure the output voltage of the unit before connecting any devices to ensure proper operation.
Improper or high voltage will damage these devices.
5. Connect devices to be powered to the terminals marked [+ DC –] (Fig. 2, pg. 7).
6. For Access Control applications batteries are optional. When batteries are not used, a loss of AC will result in the
loss of output voltage. When the use of stand-by batteries is desired, they must be lead acid or gel type.
Connect battery to the terminals marked [+ BAT -- ] (Figs. 2-7, pgs. 7-12).
Use two (2) 12VDC batteries connected in series for 24VDC operation (battery leads included).
7. Battery and AC Supervision outputs: It is required to connect supervisory trouble reporting devices to outputs marked
[AC Fail, BAT FAIL] supervisory relay outputs marked [NC, C, NO] to appropriate visual notification devices.
Use 22 AWG to 18 AWG for AC Fail & Low/No Battery reporting (Fig. 2a, pg. 7).
8. Mount UL Listed tamper switch (Not Included) (Sentrol model 3012 or equivalent) at the top of the enclosure.
Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side (Fig. 2b, pg. 7).
Connect tamper switch wiring to the Access Control Panel input or the appropriate UL Listed reporting device.
To activate alarm signal open the door of the enclosure.
9. Please ensure that the cover is secured with the provided key lock.
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions the DC output voltage should be checked for proper voltage level
(Power Supply Stand-by Battery Specifications, pg. 5).
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage at the battery
terminals and at the board terminals marked [+ BAT -- ] to ensure that there is no break in the battery connection wires.
Note: AL400ULXB2, AL600ULXB and AL1012ULXB (Power Supply Board) maximum charge current is 0.7A.
AL1024ULXB2 (Power Supply Board) maximum charge current is 3.6A.
Expected battery life is 5 years, however it is recommended to change batteries within 4 years or less if necessary.

Maximal Expandable Power Systems - 5 -
Power Supply Board Terminal Identification:
Terminal
Legend Function/Description
L, G, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral.
+ DC – Refer to Maximal Series Configuration Chart, pg. 3.
AC FAIL
NC, C, NO
Indicates loss of AC power. To meet with UL requirements it is mandatory to connect visual notification
devices, connecting audible notification devices is optional. Relay normally energized when AC power is
present. Contact rating 1A @ 28VDC. AC or brownout fail is reported within 1 minute of event.
BAT FAIL
NC, C, NO
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized when DC
power is present. Contact rating 1A @ 28VDC. A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute.
Low battery threshold:
12VDC output threshold set @ approximately 10.5VDC.
24VDC output threshold set @ approximately 21VDC.
+ BAT - Stand-by battery connections. AL400ULXB2, AL600ULXB, and AL1012ULXB (Power Supply Board)
maximum charge current is 0.7A. AL1024ULXB2 (Power Supply Board) maximum charge current is 3.6A.
Power Supply Board Stand-by Battery Specifications
Altronix
Model Power Supply Board Battery 20 min. of Backup
4 hr. of
Backup
24 hr. of
Backup
60 hr. of
Backup
Maximal11E
Maximal13E
AL400ULXB2
(Refer to Fig. 1a, 1b on pg. 6 for
Switch [SW1] location and position)
12VDC/40AH* N/A 4A 1A 300mA
24VDC/12AH N/A 200mA N/A N/A
24VDC/40AH* N/A 3A 1A 300mA
Maximal13E
Maximal33E
Maximal35E
Maximal37E
AL600ULXB
(Refer to Fig. 1a, 1b on pg. 6 for
Switch [SW1] location and position)
12VDC/40AH* N/A 6A 1A 300mA
24VDC/12AH N/A 200mA N/A N/A
24VDC/40AH* N/A 6A 1A 300mA
Maximal35E
Maximal55E
Maximal75E
AL1012ULXB
(Factory set at 12VDC) 12VDC/12AH 10A
Battery capacity
for emergency
stand-by at least
20 mins.
N/A N/A
Maximal37E
Maximal75E
Maximal77E
AL1024ULXB2
(Factory set at 24VDC)
24VDC/12AH 8A 1.5A 200mA 100mA
24VDC/65AH* N/A 8A 1.5A 500mA
* Note: Additional battery enclosure required (Figs. 3-5, pgs, 8-10).

- 6 - Maximal Expandable Power Systems
+ DC ---
SW1
OFF - 24V
ON - 12V
ON
Fig. 1a
AL400ULXB2 / AL600ULXB Power Supply Board
Fig. 1b
Power Supply Board LED Diagnostics:
LED Power Supply Status
Red (DC) Green (AC)
ON
ON Normal operating condition.
ON
OFF Loss of AC. Stand-by battery supplying power.
OFF
ON No DC output. Short circuit or thermal overload condition.
OFF
OFF No DC output. Loss of AC. Discharged battery.
Red (Bat) Battery Status
ON Normal operating condition.
OFF Battery fail/low battery.
Power Supply Board Output Voltage Settings:
Fig. 1
ON
OFF - 24V
ON - 12V

Maximal Expandable Power Systems - 7 -
BAT FAIL
Power Supply Board
L G N
Power Supply Board
L G N
Line Neutral
Line Neutral
*12VDC operation: For 12VDC operation
only a single battery is needed.
Connect red battery lead
to terminal marked
[+ BAT] and to the
[positive (+)] terminal
of the battery. Connect
black battery lead to
terminal marked [BAT -]
and to the [negative (-)]
terminal of the battery.
Tamper Switch
115VAC
Input
60 Hz.
--- DC +
+ DC ---
NO C NC NO C NC
+ BAT ---
AC FAIL
BAT FAIL
+ DC ---
NO C NC NO C NC
+ BAT ---
AC FAIL
--- BAT +
**24VDC operation: Connect two (2) 12VDC batteries in series
Earth
Ground
12VDC Rechargeable
Battery**
(Optional)
12VDC Rechargeable
Battery**
(Optional)
12VDC Rechargeable
Battery**
(Optional)
Fig. 2
Fig. 2b
Edge of
Enclosure
to Access Control Panel
or U.L. Listed
Reporting Device
Enclosure
Sentrol
model # 3012
Tamper Switch
or equivalent
(Not Included)
Power Supply Board [DC]
Terminal Layout for:
AL1012ULXB
Power Supply Board [BAT]
Terminal Layout for:
AL1024ULXB2
Fig. 2a

- 8 - Maximal Expandable Power Systems
NEC Power-Limited Wiring Requirements for Maximal11E:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring
must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring
and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this
is shown below. Your specific application may require different conduit knockouts to be used. Any conduit knockouts may
be used. For power-limited applications, use of conduit is optional.
All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 3a).
Fig. 3
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 3a
Supervisory
Connections
(power-limited)
115VAC Input
60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
DC Output
Wiring
(power-
limited)
Battery
Connections
(non power-limited)

Maximal Expandable Power Systems - 9 -
NEC Power-Limited Wiring Requirements for Maximal13E:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring
must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring
and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this
is shown below. Your specific application may require different conduit knockouts to be used. Any conduit knockouts may
be used. For power-limited applications, use of conduit is optional.
All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 4a).
Fig. 4
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 4a
Supervisory
Connections
(power-limited)
115VAC Input
60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
DC Output
Wiring
(non
power-
limited)
Battery
Connections
(non power-limited)
DC Output
Wiring
(power-
limited)

- 10 - Maximal Expandable Power Systems
NEC Power-Limited Wiring Requirements for Maximal33E, Maximal35E, and
Maximal55E:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring
must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring
and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this
is shown below. Your specific application may require different conduit knockouts to be used. Any conduit knockouts may
be used. For power-limited applications use of conduit is optional.
All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 5a).
Fig. 5
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 5a
Supervisory
Connections
(power-limited)
115VAC Input
60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
DC Output
Wiring
(non
power-
limited)
Battery
Connections
(non power-limited)

Maximal Expandable Power Systems - 11 -
NEC Power-Limited Wiring Requirements for Maximal37E and Maximal75E:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring
must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring
and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this
is shown below. Your specific application may require different conduit knockouts to be used. Any conduit knockouts may
be used. For power-limited applications use of conduit is optional.
All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 6a).
Fig. 6
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 6a
Supervisory
Connections
(power-limited)
115VAC Input
60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
DC Output
Wiring
(non
power-
limited)
Battery
Connections
(non power-limited)

- 12 - Maximal Expandable Power Systems
NEC Power-Limited Wiring Requirements for Maximal77E:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring
must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring
and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this
is shown below. Your specific application may require different conduit knockouts to be used. Any conduit knockouts may
be used. For power-limited applications use of conduit is optional.
All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 7a).
Fig. 7
Supervisory
Connections
(power-limited)
115VAC Input
60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
DC Output
Wiring
(non
power-
limited)
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 7a
Battery
Connections
(non power-limited)

Maximal Expandable Power Systems - 13 -
Enclosure Dimensions (H x W x D approximate):
26” x 19” x 6.25” (660.4mm x 482.6mm x 158.75mm)
TOP
LEFT RIGHT
BOTTOM
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
0.85”
(21.59mm)
0.85”
(21.59mm)
1”
(25.4mm)
0.85”
(21.59mm)
1”
(25.4mm)
0.85”
(21.59mm)
8.9”
(226.06mm)
19”
(482.6mm)
19”
(482.6mm)
19”
(
482.6mm
)
2”
(50.8mm)
2”
(50.8mm)
2”
(50.8mm)
6.25”
(158.75mm)
6.25”
(158.75mm)
4”
(101.6mm)
4”
(101.6mm)
2”
(50.8mm)
4”
(101.6mm)
8.9”
(226.06mm)
8.4”
(213.36mm)
7”
(177.8mm)
7”
(177.8mm)
7”
(177.8mm)
8.4”
(213.36mm)
8.5”
(215.9mm)
8.5”
(215.9mm)
7.5”
(190.5mm)
10”
(254mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
26”
(660.4mm)
26”
(660.4mm)
7.5”
(190.5mm)
5”
(127mm)
26”
(660.4mm)

- 14 - Maximal Expandable Power Systems
Notes:

Maximal Expandable Power Systems - 15 -
Notes:

- 16 - Maximal Expandable Power Systems
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
web site: www.altronix.com, e-mail: [email protected]. Lifetime Warranty, Made in U.S.A.
IIMaximalE Series E27P
Notes:
MEMBER
