Altronix RESERV ReServ5WP User manual

Rev. 092816 More than just power.TM
ReServ5WP
Outdoor Video Surveillance UPS
Installation Guide

- 2 - ReServ5WP
Overview:
ReServ5WP Video Surveillance UPS unit is designed to provide power for 24VAC and 12VDC cameras during
normal or power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs.
Specifications:
Agency Listings:
UL 60950-1 UL/CUL Listed for Information
Technology Equipment.
UL 60950-22 Information Technology Equipment -
Safety - Part 22: Equipment to be
Installed Outdoors
Input:
• 115VAC 60Hz, 3.5A.
Output:
• 4 individually PTC protected outputs
configured as follows:
- Two (2) Class 2 Rated PTC protected
24VAC outputs. PTCs rated @ 2.5A.
- Two (2) PTC protected 12VDC outputs.
PTCs rated @ 2.5A.
• Total supply current:
- 24VAC @ 4A max (96W).
- 12VDC @ 1A (12W).
Total output not to exceed 100W.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
Battery Backup (cont’d):
• Automatic switchover to stand-by battery when
AC fails.
Supervision:
• AC fail and low battery supervision
(form “C” contacts).
Visual and Audio Indicators:
• AC/DC power LED indicators.
Visual Indicators:
• Individual power output LED indicators.
• Low voltage input and Shutdown LED indicators.
Additional Features:
• True sine wave regulated AC outputs and
regulated DC outputs.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates
costly labor.
Enclosure Dimensions:
• NEMA4 / IP66 Rated enclosure accommodates up
to two (2) 12VDC/12AH batteries.
17.53” x 15.3” x 6.67”
(445.3mm x 388.6mm x 169.4mm)
Installation Instructions:
This installation should be made by qualified service personnel and should conform to the National Electrical
Code and all local codes. This product contains no serviceable parts.
1. Remove back plate inside the enclosure by removing four (4) mounting screws and ground lug.
Do not discard hardware.
2. Mark and drill desired knockouts on the enclosure to facilitate wiring.
Note: It is required to use UL Listed outdoor rated conduit hubs with a minimum outdoor rating of NEMA4X.
3. Secure back plate and ground lug inside the enclosure with four (4) mounting screws (Fig. 1, pg. 4).
4. Mount unit in the desired location with the appropriate fasteners utilizing the holes on the flanges (pg. 8).
Secure enclosure to earth ground.
Note: This product needs to be secured to the building/pole before operation.
5. Connect AC power mains to the terminals marked [L] and [N] (Fig. 1, pg. 4).
Use 18 AWG or larger for all power connections (Battery, output) (Fig. 1, pg. 4).
Use 18 AWG to 22 AWG for power-limited circuits (AC Fail/Low Battery reporting) (Fig. 1, pg. 4).
Note: A readily accessible disconnect device shall be incorporated in the building installation wiring.
6. The LEDs on the power supply board will illuminate when AC power is present.
7. Measure output voltage before connecting cameras/devices to outputs.
This helps avoiding potential damage.
8. Connecting devices:
Connect 12VDC devices to the terminals marked [P 1-2, N 1-2] (Fig. 1, pg. 4).
Connect 24VAC devices to the terminals marked [15-16] (Fig. 1, pg. 4).
9. Connect batteries to the terminals marked [+ BAT –] (Fig. 1, pg. 4).
Use two (2) 12VDC batteries connected in series for 24VDC operation (battery leads included).
Use batteries - Casil CA12120 (12V/12AH) or UL recognized BAZR2 batteries of appropriate raing.
10. Connect appropriate signaling notification devices to AC FAIL & BAT FAIL (Fig. 1, pg. 4) supervisory
relay outputs.
11. The power LEDs on the unit for Outputs 1-2 and 15-16 will illuminate when AC power is present (Fig. 1, pg. 4).
Note: If any of the power LEDs are not illuminated, the cause may be due to the following:
a. AC mains and battery fail.
b. One (1) or more power output PTCs are tripped due to a short circuit or overload condition.
c. Unit damaged/defective.

ReServ5WP - 3 -
To reset the PTC:
1. Temporarily remove wiring from output with tripped PTC (Fig. 1, pg. 4).
2. Eliminate the trouble condition (short circuit or overload).
3. Allow 1 minute for PTC to cool off (reset).
4. Re-attach wiring to the output (Fig. 1, pg. 4).
5. Power LEDs will illuminate indicating power has been restored to outputs (Fig. 1, pg. 4).
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or mois-
ture. This installation should be made by qualified service personnel and should conform to the
National Electrical Code and all local codes.
LED Diagnostics:
Power Supply Board
Red (DC) Green (AC1) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC. Stand-by battery supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
ReServ Board
LED LED State Unit Status
Output LEDs ON – Normal operating condition.
– OFF Loss of 24VAC and/or 12VDC output power.
Low Battery ON – Stand-by batteries are low.
– OFF Normal operating condition.
Shutdown ON – Loss of 24VAC and/or 12VDC output power.
Discharged stand-by battery.
– OFF Normal operating condition.
Audio Signal Diagnostics:
ReServ Unit
Audio Signal Unit Status
Single Periodic Beep AC Fail.
Double Periodic Beep Low Battery or No Battery.
Terminal Identification:
Power Supply Board
Terminal Legend Function/Description
L, G, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral.
– DC + 24VDC output.
AC FAIL
NO, C, NC
Form “C” dry contacts used to instantaneously signal the loss AC to local
annunciation devices.
With AC present terminals marked NO and C are open, NC and C are closed.
When loss of AC occurs, terminals marked NO and C are closed, NC and C are open.
BAT FAIL
NO, C, NC
Form “C” dry contacts used to signal low battery voltage or loss of battery voltage.
Under normal conditions terminals marked NO and C are open, NC and C are closed.
During a trouble condition terminals marked NO and C are closed, and NC and C are open.
+ BAT – Stand-by battery connections. Maximum charge current 0.7A.
ReServ Board
Terminal Legend Function/Description
Input – 24VDC + 24VDC input from power supply board.
N, P 1-2 12VDC outputs. N = Negative, P = Positive (Fig. 1, pg. 4).
N, P 15-16 24VAC outputs.

- 4 - ReServ5WP
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the
user to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that
may be of sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside. Refer servicing to qualified
service personnel.
Fig. 1 - ReServ5WP
Ground Lug
CAUTION: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteires according to the instructions.
12VDC Rechargeable Battery
(order separately)
Note: Two (2) 12VDC rechargeable batteries
connected in series required.
Supervised - Non power-limited
Unswitched
115VAC
60Hz, 3.5A
power mains
(non power-limited)
L G N
+ BAT -- -- DC +
NC C NO NC C NO
power-
limited
Non power-limited
24VAC
Outputs
(4A max.)
12VDC
Outputs
(1A max.)
P
N
LOW BATTERY
SHUTDOWN
Input
--- 24VDC +
15 161 2
Green Lead

ReServ5WP - 5 -
Wall Mount Installation
1- Place unit at desired location and secure with mounting
screws (not included) (Fig. 2, pg. 5).
Fig. 2
Pole Mounting Using Optional Pole Mount Kit PMK2 (not included):
Note: In order to properly mount ReServ5WP on a pole using Altronix PMK2, additional holes need to be
drilled in the enclosure’s flanges, so the distance between those holes is 10”.
This installation should be made by qualified service personnel. This product contains no serviceable parts.
PMK2 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP2 enclosures.
Brackets are designed for use with the Wormgear Quick Release Straps (two included).
1. Thread one (1) wormgear quick release strap through the slots on the back of a mounting bracket (Fig. 3, pg. 5).
2. Once the desired height of the top Pole Mount bracket is achieved, tighten the straps down by sliding open
end of the strap through the locking mechanism on the strap, then tighten the screw with
flat head screwdriver or 5/16” hex socket driver (Fig. 4, pg. 5 and Fig. 6, pg. 5).
3. Attach the bottom bracket to the enclosure by inserting bolts through the flange of the enclosure and into the
bracket, tightening bolts with a 7/16” hex socket (Fig. 5, pg. 5).
4. Thread the second wormgear quick release strap through the slots on the back of the bottom mounting bracket
(Fig. 3, pg. 5).
5. Mount enclosure onto the top bracket by inserting bolts through flange of the enclosure and into the bracket,
tightening bolts with a 7/16” hex socket (Fig. 5, pg. 5).
6. Tighten the straps of the bottom bracket down by sliding the open end of the strap through the locking
mechanism on the strap, then tighten screw with flat head screwdriver or 5/16” hex socket driver
(Fig. 3, pg. 5).
7. Clip excess straps.
Fig. 3 Fig. 4 Fig. 5
Fig. 6
Fig. 7
2” to 8”(50.8mm to 203.2mm)
diameter round pole
Fig. 7a
5” (127mm) square pole

- 6 - ReServ5WP
Notes:

ReServ5WP - 7 -
Notes:

- 8 - ReServ5WP
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty | Made in U.S.A.
IIReServ5WP G09R MEMBER
NEMA4/IP66 rated enclosure.
Enclosure Dimensions (H x W x D approximate):
17.53” x 15.3” x 6.67” (445.3mm x 388.6mm x 169.4mm)
FRONT VIEW COVER REMOVEDRIGHT SIDE VIEWFRONT VIEW
END VIEW
SECTION A-A
AA
316 STAINLESS STEEL
PADLOCK LATCH ATTACHED
WITH RIVETS. Ø.375 PADLOCK EYE
17.36”
441 mm
12.00”
304.8mm
6.41”
162.8mm
10-32 X .250
BRASS INSERT
4 PLCS.
14.54” (369.3mm)
16.74”
425.2mm
0.125” (3.2mm)
14.25”
362mm
14.00” (355.6mm)
12.23” (310.6mm)
17.53”
445.3mm
16.00”
406.4mm
1.67”
42.4mm
5.00”
127mm
16.73”
425mm
15.3”
388.6mm
6.67”
169.4mm
4.94”
125.5mm
5.77”
146.6mm
0.75”
19.1mm
MOUNTING PLATE
Ø.32” (8.1mm)
WALL MOUNTING HOLE X 4
