Aluratek AWS10F Operating and maintenance manual

Copyright © 2019 Aluratek, Inc. All Rights Reserved.
aluratek.com
Instructional Manual
WiFi Digital Photo Frame with Touchscreen LCD Display

04
06
07
07
08
09
09
12
14
18
20
21
23
25
Table of Contents
Frame Features .............................................................................................................
Frame Control Close-up ................................................................................................
Package Contents .........................................................................................................
Getting Started ..............................................................................................................
Operating Instructions
Connecting to a Wireless Network...............................................................................
Link your frame to your Facebook, Twitter, Aluratek Smart Frame app or Computer...
Facebook..............................................................................................................
Twitter...................................................................................................................
Aluratek Smart Frame app....................................................................................
Transfer Pictures Directly From Your Computer To The Frame ............................
Main Menu Function
Main Menu ................................................................................................................
Album Function
Album Settings ..........................................................................................................
System Function
System Settings ........................................................................................................
Alarm Function
How To Set Alarm .....................................................................................................

26
27
28
Table of Contents
Technical Support ..........................................................................................................
Radio and TV Interference Statement ...........................................................................
Warranty ........................................................................................................................

1
2
8” / 10” IPS LCD
Touchscreen
Frame
SD/SDHC Card Slot
Power Adapter Port
USB 2.0 Ports
3
4
6
7
8
9
10
11
A
B
Connect a USB hard drive, USB flash drive or SD/SDHC card to easily access
and share your favorite pictures, music, or videos.
Transfer and store files quickly and easily from your personal computer to the
frame's 16GB built-in memory with hi-speed USB 2.0.
12
13
Menu Button
Directional Keypad
Power Button
Wall Mount Hole
Speakers
Security Lock
Frame Stand
Wall / VESA Mount
5
4
3
2
1
9
5
10
11
A
B
12
67813
Frame Features: 8” / 10” Frame
4

1
2
8” / 10” IPS LCD
Touchscreen
Frame
SD/SDHC Card Slot
Power Adapter Port
USB 2.0 Ports
3
4
6
7
8
9
10
11
A
B
Connect a USB hard drive, USB flash drive or SD/SDHC card to easily access
and share your favorite pictures, music, or videos.
Transfer and store files quickly and easily from your personal computer to the
frame's 16GB built-in memory with hi-speed USB 2.0.
12
13
Menu Button
Directional Keypad
Power Button
Wall Mount Hole
Speakers
Security Lock
Frame Stand
Wall / VESA Mount
5
4
3
2
1
9
5
10
11
A
B
12
67813
5

1
2
17.3” / 15.6” IPS LCD
Touchscreen
Frame
Power Button
Wall Mount
Speakers
3
4
6
7
8
9
10
11
A
B
Connect a USB hard drive, USB flash drive or SD/SDHC card to easily access
and share your favorite pictures, music, or videos.
Transfer and store files quickly and easily from your personal computer to the
frame's 16GB built-in memory with hi-speed USB 2.0.
12
SD/SDHC Card Slot
Headphone Jack
Power Adapter
Mini USB Port
USB 2.0 Port
Security Lock
Frame Stand
5
2
1AB
8
6
9 11 12
7
10
4
35
Frame Features: 15.6” / 17.3” Frame
6

1
2
17.3” / 15.6” IPS LCD
Touchscreen
Frame
Power Button
Wall Mount
Speakers
3
4
6
7
8
9
10
11
A
B
Connect a USB hard drive, USB flash drive or SD/SDHC card to easily access
and share your favorite pictures, music, or videos.
Transfer and store files quickly and easily from your personal computer to the
frame's 16GB built-in memory with hi-speed USB 2.0.
12
SD/SDHC Card Slot
Headphone Jack
Power Adapter
Mini USB Port
USB 2.0 Port
Security Lock
Frame Stand
5
2
1AB
8
6
9 11 12
7
10
4
35
7

8
1 - Power On / O󰀨
2- Menu
(a) Press to return to previous screen
(b) Press & hold to return to Main Menu
3 - ►║ Play / Pause
(a) Press to select option on Main Menu
(b) Press to pause slideshow, music or video
4 - |◄◄ Up Arrow
(a) Press to navigate UP when selecting options
(b) Press to select Previous le (Photo & Music mode)
(c) Press & hold to Fast Forward
5 - ►►| Down Arrow
(a) Press to navigate DOWN when selecting options
(b) Press to select Next le (Photo & Music mode)
(c) Press & hold to Scan Backward
6- Left Arrow
(a) Press to navigate LEFT when selecting options
(b) Press & hold to lower volume
7- Right Arrow
(a) Press to navigate RIGHT when selection options
(b) Press & hold to increase volume
MENU
1
2
4
3
7
5
6
8” / 10” Frame Control Close-Up

Getting Started
• Screw in the frame stand
• Plug in the power adapter
9
Package Contents
Your order has been carefully packaged and inspected. The following accessories should
be included in your package. Please inspect the contents of the package to ensure that
you have received all items and that nothing has been damaged. If you discover a problem,
please contact us immediately for assistance.
• USB 2.0 Cable
• Power Adapter
• Frame Stand
• Instructional Manual
• Quick Start Guide

10
Operating Instructions
Step 1: Power On
- Connect your WiFi Frame to an AC outlet. The photo frame will power on
Step 2: Connect to your WiFi
1. Select the WiFi connection utilizing the photo frame touch screen display.
(if required, enter the WiFi password)
2. “Connected” will appear below your selected WiFi network.
3. Press the arrow in the upper right corner to move to the next step
Step 3: Download the ‘Aluratek Smart Frame” APP to your Smartphone / Tablet
1. Go to the App store on your Apple or Anroid device and search for
“Aluratek Smart Frame” then install and open. (Image 1 & 2)
NOTE: Make certain you download “Aluratek Smart Frame” and not
“Aluratek WIFI Frame”
2. Tap “Complete” on the device info screen

Operating Instructions
11
Image 1 Image 2

12
Operating Instructions
Step 4: Creating Your Account in the APP
1. Open the “Aluratek Smart Frame” APP (Allow notications if prompted)
2. Select “Sign Up” (Image 3)
3. Create “Username” “Password” (write this down as you will need it later)
4. Enter your email address then press the “right arrow icon” next to the email
address you entered (Image 4 & 5)
5. Check your email for the verication code and enter it in the “Verify Code” eld then
click “Submit”.

Operating Instructions
13
Image 3 Image 4 Image 5

14
Operating Instructions
Step 5: Bind Your Frame
1. Make sure you are signed in within the APP
2. Select “Devices” within the APP
3. Click the “+” next to My Devices (Image 6)
4. Enter a device Name that will help you identify this particular frame.
For example “Kitchen123”.
5. Create a unique email address name for your frame so you can email pictures/ videos.
Tip: Make it unique using 6 or more characters including letters, numbers, and
symbols. For example, Alexkitchen@wiframe.com (Image 7)
6. Enter your frame ID - this is found on your WiFi frame by selecting “Settings” the
“Device info”. See “Frame ID:” xxxxxx at the top of the screen. (Image 8)
7. Enter your unique “Frame ID” into the eld o n the app. Your frame will notify you that
a
request has been sent to allow a user to bind to it. Touch “Accept” to bind.
8. On your digital frame go to “Settings” the “User Management” to see “Pending User
Request” and touch “Accept”.
9. Your phone and frame are now connected!

Operating Instructions
15
Image 6 Image 7 Image 8

16
Operating Instructions
Step 6: Enjoy Your Photos!
1. On the main screen on your photo frame - select the photos in the
upper left box
2. Use the menu on the left to select the source for your photos
typically, that is “ALL”
3. Tap a photo in the right column to start enjoying your photos.

17
Operating Instructions
Send Pictures from your Smartphone / Tablet to the frame using the
Aluratek Smart Frame APP *****
1. Select the photo or video icon within the APP to take a live
photo / video. If prompted to access the camera, please “Allow”
access.
2. Select the “Files” icon to send a photo or video previously saved
to your smartphone / tablet. Select the les you would like to
send then click done.
3. Under “Push Device” Select the frame that you ould like to send
the les to.
4. Select the right arrow (send mail) icon to send.
NOTE: You can send up to 9 photos at a time to speed up the
photo delivery to the frame.

18
Operating Instructions
Step 2: Link your frame to your Facebook, Twitter or Aluratek Smart Frame App
Facebook
How to link the frame to you Facebook account so that you can send pictures to the frame
via Facebook.
1. Open Facebook app or go
to Facebook from your
browser and login to your
Facebook account if you
are not logged in already
2. Search for “Aluratek WiFi
Frame”

19
Operating Instructions
Facebook
3. Send a message with your frame ID to bind
the frame. For example, if your frame ID is
123456, please send “bd123456”

20
Operating Instructions
Facebook
4. You will see the binding message,
“Successful Binding!” once the
binding is completed
5. You can now send pictures to your
frame by just attaching a picture and
send via message.
