Alvin Heritage HWE150 User manual

Heritage™ H-Frame Easel
Assembly Instructions
Parts List:
To Assemble
Unwrap and lay out all parts.
Some hardware may have loosened during transportation.
For best results, we suggest that you tighten the four Allen
bolts in sides of main easel frame, as shown in Figure 1,
and tighten the two Phillips screws in the back of canvas
support assembly, as shown in Figure 2.
1
2
For HWE150
Main Easel Frame
Canvas Support Assembly
Top bracket
Figure 1
Figure 2

©2008 ALVIN & COMPANY, INC. • P.O. Box 188, Windsor, CT 06095-0722
Phone: [phone] • Toll-Free: 800-444-2584 • Fax: [phone] • Toll-Free Fax: [phone]
www.alvinco.com
LIT-A8011-2 4/08
Lay main easel frame flat on floor with brass height
adjustment track facing up.
Carefully slide canvas support assembly from below into
slots and tracks in main frame, as shown in Figure 3.
Pull spring-loaded height-adjustment ring and set in the
third track position for the time being.
Loosen the two angle adjustment knobs and slowly lift
frame into the vertical position, as shown in Figure 4.
Tighten knobs when desired angle is reached.
Slide top bracket down over main vertical track and
secure with brass thumbscrew at desired height, as
shown in Figure 4.
Your easel is now ready to use. Enjoy!
3
4
1
2
3
Loosen brass thumbscrew on back of main vertical track.
Pull spring-loaded height-adjustment ring to release
locking mechanism from brass track. Slide canvas
support assembly up or down until desired height
is reached.
Retighten brass thumbscrew.
Please save these instructions for future reference.
To Adjust Height
5
6
Figure 3
Figure 4
7
Angle
Adjustment
Knobs
Height Adjustment Ring
Brass
Thumbscrew
Brass
Thumbscrew
Angle
Adjustment
Knobs
