AM TECH SRP-IV User manual

U
Us se er r’ ’s s M Ma an nu ua al l
S
SR RP P- -I IV V
http://www.amteq.co.kr

SRP-IV
- 2 -
Record of Revisions
Revision Version Date DESCRIPTION
1.00
1.10
26-Jan-2008
30-Mar-2009
Preliminary
Changing Power Spec.
Upgrade printing speed

SRP-IV
- 3 -
Table of Contents
INTRODUCTION
1. Specifications & Features
TechnicalInformation
Product Features
2. The name of parts and Accessories
3. Installation & Usage
3.1 Paper Loading
3.2 Supplying Power to Printer
3.3 Interface cable connection
3.4 How to do self test
4. Printer Status
5. Troubleshooting
6. Cleaning
7. Warning
8. Contact to your retailer

SRP-IV
- 4 -
INTRODUCTION
All rights reserved. Total or partial reproduction of this manual in whatever form, whether by
printed or electronic means, is forbidden. While guaranteeing that the information contained in it
has been carefully checked, AM TECH CO., LTD. and other entities utilized in the realization of
this manual bear no regarding any errors found in it or suggestions on how it could be improved
are appreciated. Since products are subject to continuous check and improvement, AM TECH
Co., LTD. reserves the right to make changed in information contained in this manual without
prior notification.
Copyright 2006 AM TECH CO., LTD.ⓒ– KOREA
1. Specifications & Features
1.1Technical Specifications
Item Description
Printer Method Direct Line Thermal Printing
Printing width 72mm
Resolution 8dots/mm(203dpi)
Printing Speed 100mm/ sec (Max.150mm)*1
Operating Voltage DC 24V 2A(Option : 12V 2A)
Size of the Buffer 64kb
Graphic(logo) Available
Barcode JAN13, EAN8, UPC-A, UPC Code39, Code 128
Interface RS232C
Baud Rate 115200
Power Adaptor
Input : 100~250V, AC 50~60 Hz,
Output: 24V 2A
Paper Width 79.5mm±0.5
Paper Diameter Ø55
Dimensions (W)138 X (L)188 X (H)107mm
MSR ISO I,II,III Track
Weight About 680g
Operation emperature 5 ~ 40℃
Storage Temperature 20℃~ 80℃
Storage Humidity 20% ~ 80%
Head Life Approximately 50km
*1 There is also case that the printing speed will not follow as specification under condition.

SRP-IV
- 5 -
1.2 Product Features
This Printer is a suitable for large volume tasks. Really simple paper loading, just drop-in and
printing out.
.
¾High Resolution
This printer boosts printing precise characters and clear image at high resolution of
8dots/mm.
¾Easy Paper Loading
Paper roll can be loaded easily and replaced quickly by clamshell design.
¾Very Silent printing
This printer prints silently through the direct thermal printing method
¾Compact & Light Weight
This printer is designed as a newly developed compact light weight (680g) printer,

SRP-IV
- 6 -
2. The name of parts and accessories
(Serial Cable, 9pin-9pin) (24V 2A Power adaptor)
Top Cover
Feed Button
Error LED
Power LED
Power Button
Open Knob
Power port
Serial Port
MSR
Receipt Slot (with Tear Bar)

SRP-IV
- 7 -
3. Installation & Usage
3.1 Paper Loading
Push ‘both knobs’ of cover upward to open and put the paper roll into the printer and, close
cover. Make sure that the paper cutting direction is correct like picture ④
CAUTION:
1) Don’t touch the print head. It can be very hot after printing continuously for a long time.
2) Make sure that the paper direction is correct
Correct Wrong
The recommended the diameter of paper roll is 55mm (Max. 60mm)
○
1○
2
○
3
○
4

SRP-IV
- 8 -
3.2 Supplying Power to Printer
Insert ‘Power supply connector’ into the ‘power port’ (red circle)
3.3 Interface Cable Connection
Prepare dedicated Serial cable. Insert ‘9 pin end’ into ‘Serial port’ (red circle). Connect the other
end of the cable to the device to be connected
3.4 How to do Self test
The self test lets you know if your printer is operating properly. It checks the control circuits,
printer mechanisms, print quality, and ROM version.
Running the self test
1. Make sure the printer is ‘off’ and the printer covers are closed properly.
2. Make sure a paper roll has been installed properly
3. Press and hold ‘feed button’ and then turn on the power.
The self test receipt shows the printer settings.

SRP-IV
- 9 -
4. Printer Status
◎Power LED
Status Description
Power LED is “On” Power light is “Green LED “and Printer is ready to work
Power LED is ”Off” Power Supplier is not connected with printer or Power
switch is off.
◎Error LED
Status Description
ERROR LED is “On” Paper is not loaded properly or no paper.
Printer top cover is not closed properly.
◎MSR reading
Status Description
ERROR LED flashes one time and
buzzers one time
Card reading is Good
ERROR LED flashed two times
and buzzers two times
Card reading is Bad
5. Troubleshooting
This chapter gives solutions to some printer questions you may have.
◎The lights on the control panel do not come on.
Make sure that the power supply cables are correctly plugged into the printer, the power unit,
and to the power outlet.
◎The ERROR light is “ON”
1) Make sure that the printer top cover is properly closed. If the ERROR light is still “ON”
although printer top cover is closed properly, contact a qualified service person.
2) The paper roll is not installed. Install a new paper roll.

SRP-IV
- 10 -
6. Cleaning
If the interior of printer is mess the printing quality can be bad. In such case please follow the
instruction below to clean the printer. Before cleaning the printer, disconnect the power supply
and make sure that the printer is off.
1) How to clean the print head
Wipe print head with a small cloth which moistened with alcohol (Take care not to touch
the heated line of the print head)
2) How to clean the paper sensor
Use air-spray to blow dust on paper sensor
7. Warning
A. Do not operate the printer near water or liquid. The printer has been exposed to
water or liquid.
B. Only use approved accessories. It may cause fire or damage on printers.
C. Use the type of electrical power supply indicated on the printer label, if in doubt,
do not use.
D. When deciding where to place the printer, make sure it is positioned where it will
not be damaged.
E. Do not introduce foreign object of any kind into the printer as they could cause
a short circuit and could jeopardize printer, with the exception of the scheduled maint
enance procedures specifically indicated in the user manual.
8. Contact to your retailer
- Liquid has seeped inside of the printer
- The printer has been exposed to rain or water.
- The printer is not functioning normally despite the fact the all instructions
in the user manual have been followed.
- The printer has been dropped and its outer casing damaged.
- Printer performance is poor.
- The printer is not functioning.
