Amada Homefurnishing AMFS12 User manual

Floating Shelf Instruction Manual V2.0
Model: AMFS12/AMFS12B/AMFS12M
Thank you for choosing this AMADA product! At AMADA we strive to provide
you with the best quality products and services in the industry. Should you have
any issues, please don't hesitate to contact at
[email protected] (US/CA)

• Check package contents against supplied parts and hardware list to assure that all
components were received undamaged. Do not use damaged or defective parts. lf you
require replacement parts, please contact amada customer service at
[email protected].
• Carefully read all instructions before attempting installation. If you do not understand the
instructions or have any concerns or questions, please contact customer service at
[email protected].
• Not all parts and hardware included will be used.
• Do not use this product for any purpose that is not explicitly specified in this manual. Do
not exceed weight capacity. We cannot be liable for damage or injury caused by improper
mounting, incorrect assembly or inappropriate use. Thank you for your understanding.
IMPORTANT SAFETY INFORMATION
Tools Needed (Not lncluded)
Stud Finder Pencil Phillips
Screwdriver
Level Drill 5/64 in.(2mm)
Wood Drill
15/64 in.(6mm)
Concrete Drill
Supplied Parts and Hardware
Wall Anchor
M13x42mm
x12
F
CAUTION!
This wall anchor [F] is
for drywall ONLY. DO
NOT use them in
concrete / brick / wood
studs wall.
CAUTION!
This wall anchor [G] is
for concrete or brick
walls ONLY. DO NOT
use them in drywall or
wood studs.
x12
G
Wall Anchor
M4x30mm
Hammer
Long Lag Screw
M4x50mm
(C) x12
Short Lag Screw
M4x30mm
(D) x12
Screw
M4x15mm
(E) x18
(A) x3
(B) x6
01 02 03 04 05 06

Before installation, please identify your wall type.
For wood stud installation, follow the step 1A.
For drywall installation, follow the step 1B.
For solid concrete and concrete block walls installation, follow the step 1C
Step 1 Secure Metal Brackets to Wall
Step 1A For Wood Stud
For wood stud mounting, wall
anchors [F] and [G] are not
necessary.
WARNING:
XX
F G
01 02 03 04 05 06

C
D
[Not Included] (For wood stud only!)
[Optional]
2 in.(50mm)
For Lag Screw [C]
ø5/64 in.(ø2mm)
Step 1B For Drywall
Note:
The anchor [F] is used for
drywall only.
01 02 03 04 05 06
F

Step 1C For Solid Concrete and Concrete Block Walls
F
D
01 02 03 04 05 06

G
15/64 in.(ø6mm)
2 11/64 in.(55mm)
01 02 03 04 05 06

C
Step 2 Secure the Floating Shelf to Wall
G
E
01 02 03 04 05 06

Thank you again for
choosing this AMADA product!
All of us at AMADA do appreciate your product purchase. We hope that you
are as happy with your product as we are designing and manufacturing it for
you. We strive to provide you with the best quality products and services in
the industry. Should you have any issues, please don't hesitate to contact us
at [email protected] (US/CA)
