Amada Asx 18 series User manual

ASX 18 SEER

Condensing Units

•RefertoServiceManualRS6200006forinstallation,operation,andtroubleshootinginformation.

•Allsafetyinformation must be followedasprovided in the ServiceManual.

•RefertotheappropriatePartsCatalog for part number information.

•Models listed on page 3.

RT6114003r2

March2011

TECHNICAL MANUTECHNICAL MANU

TECHNICAL MANUALAL

ALAL

This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does

not assume any responsibility for property damage or personal injury due to improper service proce-

dures or services performed by an unqualified person.

®is a registered trademark of Maytag Corporation or its related companies and is used under license

PRODUCT IDENTIFICATION

The model number is used for positive identification of component parts used in manufacturing. Please use this number

whenrequestingserviceorpartsinformation.

WARNING

WARNING HIGH VOLTAGE!

Disconnect ALL power before servicing or installing this unit. Multiple power

sources may be present. Failure to do so may cause property damage, personal

injury or death.

Installation and repair of this unit

should be performed ONLY by

individuals meeting (at a minimum) the requirements of

an "entry level technician" as specified by the Air-Condi-

tioning, Heating, and Refrigeration Institute (AHRI). At-

tempting to install or repair this unit without such back-

ground may result in product damage, personal injury or

death.

Goodman will not be responsible

for any injury or property damage

arising from improper service or service procedures. If

you install or perform service on this unit, you assume

responsibility for any personal injury or property damage

which may result. Many jurisdictions require a license to

install or service heating and air conditioning equipment.

WARNING

WARNING WARNING

WARNING

ASX18361AA

PRODUCT

TYPE:

X: Condenser R-410A

Z: Heat PumpR-410A

PRODUCT

FAMILY:

S: Split System

SEER:

SEER Rating MAJOR

REVISION:

:InitialRelease

MINOR

REVISION:

: Initial Release

ELECTRICAL:

1: 208-230V/1ph/60Hz

3: 208-230v/3ph/60Hz

4: 460v/3ph/60Hz

NOMINAL

CAPACITY:

036: 3Tons

048: 4Tons

060: 5Tons

BRAND:

: Amana®

Brand

PRODUCT IDENTIFICATION

The United States Environmental Protection Agency (“EPA”) has issued various regulations re-

garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow

these regulations may harm the environment and can lead to the imposition of substantial fines.

These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.

WARNING

Do not connect or use any device

that is not design certified by

Goodman for use with this unit.

Serious property damage, personal injury, reduced unit

performance and/or hazardous conditions may result

from the use of such non-approved devices.

WARNING

WARNING To prevent the risk of property

damage, personal injury, or death,

do not store combustible materials or use gasoline or

other flammable liquids or vapors in the vicinity of this

appliance.

WARNING

The model number is used for positive identification of component parts used in manufacturing. Please use this number

whenrequestingserviceorpartsinformation.

* Indicates minor revision & is not used for order entry or inventory management

ASX180361A*

ASX180481A*

ASX180601A*

ASX180361B*

ASX180481B*

ASX180601B*

PRODUCT DESIGN

ASX18 models are available in 3 4 and 5 ton sizes and use

R-410Arefrigerant.Theyaredesignedfor 208/230voltsingle

phaseapplications.

The condenser air is pulled through the condenser coil by a

direct drive propeller fan. This condenser air is then dis-

charged out of the top of the cabinet.

These units are designed for free air discharge, so no addi-

tional resistance like duct work shall be attached.

The suction and liquid line connections on present models

areofthe sweat type for field piping withrefrigeranttypecop-

per. Front seating valves are factory installed to accept the

fieldruncopper. The total refrigerantcharge for a normal in-

stallationisfactory installed in the condensing unit.ASX units

are charged for the matching evaporator coil and a 15 foot

refrigerantlineset.

Systems should be properly sized by heat gain and loss

calculations made according to methods of the Air Condi-

tioning Contractors Association (ACCA) or equivalent. It is

the contractors responsibility to ensure the system has ad-

equate capacity to heat or cool the conditioned space.

ASX16 models use the Copeland Scroll "Ultratech" Series

compressorswhichare specifically designed for R-410Are-

frigerant. Thereare anumberofdesign characteristicswhich

are different from the traditional reciprocating and/or scroll

compressors.

"Ultratech" Series scroll compressors with Copeland®

ComfortAlert diagnostics will not have a discharge thermo-

stat, some of the early model scroll compressors required

dischargethermostats.

"Ultratech" Series scroll compressors will not have a dis-

chargethermo-stat. Some of the early modelscrollcompres-

sorsrequireddischargethermostats.DuetotheirdesignScroll

compressorsareinherentlymoretolerantof small quantities

ofliquid refrigerant.

NOTE: Eventhough the compressorsectionofa Scroll com-

pressor is more tolerant of liquid refrigerant, continued

floodback or flooded start conditions may wash oil from the

bearingsurfacescausing premature bearing failure.

"Ultratech" Series scroll compressors use "POE" or

polyolesteroil whichisNOT compatiblewithmineraloilbased

lubricants like 3GS. "POE" oil must be used if additional oil

isrequired.

WARNING

To avoid possible injury, explosion or death, practice

safe handling of refrigerants.

Operating pressures and amp draws may differ from stan-

dardreciprocatingand/orscroll compressors. This informa-

tion may be found in the "Cooling Performance Data" sec-

tion.

This unit is for outdoor installation only. Refer to minimum

figure for clearances from the sides of the unit to full walls

andother objects.

NOTE: This unit cannot be completely enclosed. At least

one side must be unrestricted.

Theseclearanceswillhelpavoidairrecirculation.Ifinstalling

two or more units at the same location, allow at least 24

inches between units. If only one side is restricted (for ex-

ample, against the outside wall of a house), the unit may be

placed as close as 8" to that one wall.

DO NOT locate the unit:

* Directlyundera vent termination fora gas appliance.

* Within 3 feet of a clothes drier vent

* Wheretherefreezingofdefrostwaterwould create

ahazard

* Where water may rise into the unit.

OK!

AA AAA

CCOK!

OK!

NOT

RECOMMENDED

AA AA

B B B

Model Type A B C AA

Residential 10" 10" 18" 20"

Light Commercial 12" 12" 18" 24"

Minimum Airflow Clearance

Model Dimensions - W x D x H

ASX180361* 35½ x 35½ x 38¼

ASX180481* 35½ x 35½ x 38¼

ASX180601* 35½ x 35½ x 38¼

CONDENSING UNIT SPECIFICATIONS

NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and

wires in accordance with all national and/or local electrical codes. Use copper wire only.

Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general

and electrical information.

ASX180361* - ASX180601*

* Up to 24' in equivalent line length

(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.

(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.

NOTES:

• Always check the S & R plate for electrical data on the unit being installed.

• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).

• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).

• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge

Procedure.

• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE

OUTDOORUNIT,NOTTHEINDOORCOIL.

ASX180361*

ASX180481*

ASX180601*

Cooling Capacity, BTUH 36,000 48,000 60,000

Compressor

R.L. Amps 16.7 21.2 25.6

L.R. Amps 82.0 96.0 118.0

Low Pressure Switch

Open 22 + / - 7 PSIG 22 + / - 7 PSIG 22 + / - 7 PSIG

Close 50 + / - 7 PSIG 50 +/ - 7 PSIG 50 +/ - 7 PSIG

High Pressure Switch

Open 610 PSIG 610 PSIG 610 PSIG

Close 420 PSIG 420 PSIG 420 PSIG

Condenser Fan Motor

Horsepower 1/3 1/3 1/3

F.L. Amps 2.8 2.8 2.8

Liquid Line, Inches O.D.* 3/8" 3/8" 3/8"

Suction Line,Inches O.D.* 7/8" 1 1/8" 1 1/8"

Refrigerant Charge 187.0 262.0 262.0

Power Supply 208/230-60-1 208/230-60-1 208/230-60-1

Minimum Circuit Ampacity(1) 23.7 29.3 34.8

Maximum OvercurrentDevice(2) 40 50 60

Electrical Conduit Size

Power Supply(Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4

Approximate Shipping Weight 270 320 330

PERFORMANCE DATA ASX180361*-LOW STAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180361A* / CA*F4961*6**+TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. Low Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67 715963677159636771

MBh 25.3 26.2 28.8 - 24.7 25.6 28.1 - 24.1 25.0 27.4 - 23.6 24.4 26.8 - 22.4 23.2 25.4 - 20.7 21.5 23.5 -

S/T 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -

Delta T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -

930 KW 1.30 1.33 1.38 - 1.41 1.45 1.50 - 1.51 1.55 1.60 - 1.60 1.63 1.69 - 1.67 1.71 1.77 - 1.73 1.77 1.84 -

AMPS 5.3 5.5 5.7 - 5.8 5.9 6.1 - 6.3 6.5 6.7 - 6.7 6.9 7.1 - 7.2 7.4 7.6 - 7.6 7.8 8.1 -

HI PR 210 226 229 - 237 255 259 - 270 290 295 - 308 331 335 - 332 357 362 - 394 423 429 -

LO PR 124 128 140 - 128 132 144 - 132 136 149 - 135 140 153 - 138 143 156 - 142 146 159 -

MBh 24.6 25.5 27.9 - 24.0 24.9 27.3 - 23.4 24.3 26.6 - 22.9 23.7 26.0 - 21.7 22.5 24.7 - 20.1 20.9 22.9 -

S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -

Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 18 13 - 20 17 13 - 19 16 12 -

70 825 KW 1.29 1.32 1.37 - 1.40 1.43 1.48 - 1.50 1.53 1.59 - 1.58 1.62 1.68 - 1.65 1.69 1.75 - 1.72 1.76 1.82 -

AMPS 5.3 5.4 5.6 - 5.7 5.9 6.1 - 6.2 6.4 6.6 - 6.7 6.8 7.1 - 7.1 7.3 7.5 - 7.6 7.7 8.0 -

HI PR 208 224 227 - 235 253 256 - 267 288 292 - 305 327 332 - 329 354 359 - 390 419 425 -

LO PR 123 127 138 - 126 130 142 - 131 135 147 - 134 138 151 - 137 141 154 - 140 145 158 -

MBh 22.7 23.5 25.8 - 22.2 23.0 25.2 - 21.6 22.4 24.6 - 21.1 21.9 24.0 - 20.1 20.8 22.8 - 18.6 19.3 21.1 -

S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -

Delta T 20 18 13 - 20 18 13 - 20 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -

720 KW 1.28 1.31 1.36 - 1.39 1.42 1.47 - 1.48 1.52 1.57 - 1.57 1.60 1.66 - 1.64 1.68 1.74 - 1.70 1.74 1.80 -

AMPS 5.2 5.4 5.5 - 5.7 5.8 6.0 - 6.2 6.3 6.5 - 6.6 6.8 7.0 - 7.1 7.2 7.5 - 7.5 7.7 7.9 -

HI PR 206 221 225 - 233 250 254 - 265 285 289 - 302 324 329 - 326 350 355 - 386 415 421 -

LO PR 122 125 137 - 125 129 141 - 129 133 146 - 133 137 150 - 135 140 153 - 139 143 156 -

MBh 25.826.528.730.825.225.928.030.124.625.327.429.424.0 24.7 26.7 28.7 22.8 23.4 25.4 27.2 21.1 21.7 23.5 25.2

S/T 0.860.770.580.380.890.800.600.390.920.820.620.400.95 0.85 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.89 0.67 0.43

DeltaT22201711222017122220171222 21 17 12 22 20 17 12 21 19 16 11

930 KW 1.30 1.33 1.38 1.43 1.41 1.45 1.50 1.55 1.51 1.55 1.60 1.66 1.60 1.63 1.69 1.75 1.67 1.71 1.77 1.83 1.73 1.77 1.84 1.90

AMPS5.35.55.75.95.85.96.16.46.36.56.76.96.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4

HI PR 210 226 229 234 237 255 259 265 270 290 295 301 308 331 335 343 332 357 362 370 394 423 429 439

LO PR 124 128 140 149 128 132 144 153 132 136 149 158 135 140 153 162 138 143 156 166 142 146 159 170

MBh 25.025.727.929.924.425.127.229.223.824.526.628.523.3 23.9 25.9 27.8 22.1 22.8 24.6 26.4 20.5 21.1 22.8 24.5

S/T 0.820.740.560.360.850.760.580.370.870.780.590.380.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41

DeltaT23211712232117122321181223 22 18 12 23 21 17 12 22 20 16 11

75 825 KW 1.29 1.32 1.37 1.42 1.40 1.43 1.48 1.54 1.50 1.53 1.59 1.64 1.58 1.62 1.68 1.74 1.65 1.69 1.75 1.82 1.72 1.76 1.82 1.88

AMPS5.35.45.65.85.75.96.16.36.26.46.66.96.7 6.8 7.1 7.4 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3

HI PR 208 224 227 232 235 253 256 262 267 288 292 298 305 327 332 339 329 354 359 367 390 419 425 435

LO PR 123 127 138 147 126 130 142 152 131 135 147 157 134 138 151 161 137 141 154 164 140 145 158 168

MBh 23.123.825.727.622.523.225.127.022.022.724.526.321.5 22.1 23.9 25.7 20.4 21.0 22.7 24.4 18.9 19.5 21.1 22.6

S/T 0.790.710.540.350.820.740.560.360.840.750.570.370.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40

DeltaT23221812242218122422181224 22 18 12 24 22 18 12 22 20 17 11

720 KW 1.28 1.31 1.36 1.40 1.39 1.42 1.47 1.52 1.48 1.52 1.57 1.63 1.57 1.60 1.66 1.72 1.64 1.68 1.74 1.80 1.70 1.74 1.80 1.87

AMPS5.25.45.55.85.75.86.06.26.26.36.56.86.6 6.8 7.0 7.3 7.1 7.2 7.5 7.8 7.5 7.7 7.9 8.2

HI PR 206 221 225 230 233 250 254 259 265 285 289 295 302 324 329 336 326 350 355 363 386 415 421 430

LO PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area isACCA (TVA) conditions

PERFORMANCE DATA ASX180361*-LOW STAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180361A* / CA*F4961*6**+TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. Low Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67 715963677159636771

MBh 26.226.828.630.625.626.228.029.925.025.527.329.224.4 24.9 26.6 28.523.223.725.327.021.521.923.425.0

S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62

DeltaT25232016252421172524211724 25 21172323211621221915

930 KW 1.30 1.33 1.38 1.43 1.41 1.45 1.50 1.55 1.51 1.55 1.60 1.66 1.60 1.63 1.69 1.75 1.67 1.71 1.77 1.83 1.73 1.77 1.84 1.90

AMPS 5.3 5.5 5.7 5.9 5.8 5.9 6.1 6.4 6.3 6.5 6.7 6.9 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4

HI PR 210 226 229 234 237 255 259 265 270 290 295 301 308 331 335 343 332 357 362 370 394 423 429 439

LO PR 124 128 140 149 128 132 144 153 132 136 149 158 135 140 153 162 138 143 156 166 142 146 159 170

MBh 25.426.027.829.724.925.427.129.024.324.826.528.323.7 24.2 25.8 27.6 22.5 23.0 24.6 26.2 20.8 21.3 22.7 24.3

S/T 0.900.850.690.510.930.880.710.530.960.900.730.550.99 0.93 0.76 0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59

DeltaT26252117262522172625221726 25 22 17 25 25 21 17 23 23 20 16

80 825 KW 1.29 1.32 1.37 1.42 1.40 1.43 1.48 1.54 1.50 1.53 1.59 1.64 1.58 1.62 1.68 1.74 1.65 1.69 1.75 1.82 1.72 1.76 1.82 1.88

AMPS5.35.45.65.85.75.96.16.36.26.46.66.96.7 6.8 7.1 7.4 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3

HI PR 208 224 227 232 235 253 256 262 267 288 292 298 305 327 332 339 329 354 359 367 390 419 425 435

LO PR 123 127 138 147 126 130 142 152 131 135 147 157 134 138 151 161 137 141 154 164 140 145 158 168

MBh 23.524.025.627.422.923.425.026.822.422.924.526.121.9 22.3 23.9 25.520.821.222.724.219.219.621.022.4

S/T 0.87 0.82 0.66 0.50 0.90 0.85 0.69 0.51 0.92 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.99 0.93 0.76 0.56 1.00 0.94 0.76 0.57

DeltaT26252217262522182625221827 26 22182625221725242016

720 KW 1.28 1.31 1.36 1.40 1.39 1.42 1.47 1.52 1.48 1.52 1.57 1.63 1.57 1.60 1.66 1.72 1.64 1.68 1.74 1.80 1.70 1.74 1.80 1.87

AMPS 5.2 5.4 5.5 5.8 5.7 5.8 6.0 6.2 6.2 6.3 6.5 6.8 6.6 6.8 7.0 7.3 7.1 7.2 7.5 7.8 7.5 7.7 7.9 8.2

HI PR 206 221 225 230 233 250 254 259 265 285 289 295 302 324 329 336 326 350 355 363 386 415 421 430

LO PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166

MBh 26.727.228.530.426.026.627.829.725.425.927.129.024.8 25.3 26.5 28.323.624.025.226.821.822.323.324.9

S/T 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.80 1.00 1.00 0.99 0.80

DeltaT26262421262625212526252125 25 25212324242122222320

930 KW 1.30 1.33 1.38 1.43 1.41 1.45 1.50 1.55 1.51 1.55 1.60 1.66 1.60 1.63 1.69 1.75 1.67 1.71 1.77 1.83 1.73 1.77 1.84 1.90

AMPS 5.3 5.5 5.7 5.9 5.8 5.9 6.1 6.4 6.3 6.5 6.7 6.9 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4

HI PR 210 226 229 234 237 255 259 265 270 290 295 301 308 331 335 343 332 357 362 370 394 423 429 439

LO PR 124 128 140 149 128 132 144 153 132 136 149 158 135 140 153 162 138 143 156 166 142 146 159 170

MBh 25.926.427.629.525.325.827.028.824.725.226.428.124.1 24.6 25.7 27.422.923.324.426.121.221.622.624.1

S/T 0.95 0.91 0.82 0.67 0.98 0.95 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77

DeltaT27272522282726222827262227 27 26222526262224242421

85 825 KW 1.29 1.32 1.37 1.42 1.40 1.43 1.48 1.54 1.50 1.53 1.59 1.64 1.58 1.62 1.68 1.74 1.65 1.69 1.75 1.82 1.72 1.76 1.82 1.88

AMPS 5.3 5.4 5.6 5.8 5.7 5.9 6.1 6.3 6.2 6.4 6.6 6.9 6.7 6.8 7.1 7.4 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3

HI PR 208 224 227 232 235 253 256 262 267 288 292 298 305 327 332 339 329 354 359 367 390 419 425 435

LO PR 123 127 138 147 126 130 142 152 131 135 147 157 134 138 151 161 137 141 154 164 140 145 158 168

MBh 23.924.425.527.223.323.824.926.622.823.224.326.022.2 22.7 23.7 25.321.121.522.524.119.619.920.922.3

S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74

Delta T 27.83 27 26 22 28 28 26 23 28 28 26 23 28 28 26 23 27 27 26 23 25 25 24 21

720 KW 1.28 1.31 1.36 1.40 1.39 1.42 1.47 1.52 1.48 1.52 1.57 1.63 1.57 1.60 1.66 1.72 1.64 1.68 1.74 1.80 1.70 1.74 1.80 1.87

AMPS 5.2 5.4 5.5 5.8 5.7 5.8 6.0 6.2 6.2 6.3 6.5 6.8 6.6 6.8 7.0 7.3 7.1 7.2 7.5 7.8 7.5 7.7 7.9 8.2

HI PR 206 221 225 230 233 250 254 259 265 285 289 295 302 324 329 336 326 350 355 363 386 415 421 430

LO PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

PERFORMANCE DATA ASX180481*-LOW STAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180481A* / CA*F4961*6**+TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. Low Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67 715963677159636771

MBh 34.6 35.8 39.3 - 33.8 35.0 38.3 - 33.0 34.2 37.4 - 32.2 33.3 36.5 - 30.5 31.7 34.7 - 28.3 29.3 32.1 -

S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.83 0.70 0.48 - 0.87 0.72 0.50 - 0.87 0.73 0.51 -

Delta T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

1325 KW 1.87 1.91 1.97 - 2.02 2.07 2.14 - 2.16 2.21 2.29 - 2.28 2.34 2.42 - 2.39 2.44 2.53 - 2.47 2.53 2.62 -

AMPS 7.2 7.4 7.6 - 7.8 8.0 8.3 - 8.5 8.7 9.0 - 9.1 9.4 9.7 - 9.7 10.0 10.3 - 10.4 10.6 11.0 -

HI PR 216 232 235 - 244 262 266 - 277 298 303 - 316 340 345 - 356 382 388 - 398 428 434 -

LO PR 121 125 137 - 125 129 141 - 129 133 146 - 133 137 149 - 135 140 152 - 139 143 156 -

MBh 33.6 34.8 38.1 - 32.8 34.0 37.2 - 32.0 33.2 36.3 - 31.2 32.4 35.5 - 29.7 30.7 33.7 - 27.5 28.5 31.2 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.64 0.45 - 0.80 0.66 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -

Delta T 19 16 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -

70 1175 KW 1.85 1.89 1.96 - 2.00 2.05 2.12 - 2.14 2.19 2.27 - 2.26 2.32 2.40 - 2.36 2.42 2.51 - 2.45 2.51 2.60 -

AMPS 7.1 7.3 7.6 - 7.7 7.9 8.2 - 8.4 8.7 9.0 - 9.0 9.3 9.6 - 9.7 9.9 10.2 - 10.3 10.5 10.9 -

HI PR 214 230 233 - 242 260 263 - 275 295 300 - 313 336 341 - 352 378 384 - 394 424 430 -

LO PR 120 124 135 - 124 128 139 - 128 132 144 - 131 136 148 - 134 138 151 - 137 142 155 -

MBh 31.0 32.1 35.2 - 30.3 31.4 34.4 - 29.5 30.6 33.5 - 28.8 29.9 32.7 - 27.4 28.4 31.1 - 25.4 26.3 28.8 -

S/T 0.70 0.58 0.40 - 0.73 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.67 0.46 - 0.80 0.67 0.46 -

Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

1025 KW 1.83 1.88 1.94 - 1.99 2.03 2.10 - 2.12 2.17 2.25 - 2.24 2.29 2.38 - 2.34 2.40 2.48 - 2.43 2.49 2.58 -

AMPS 7.1 7.2 7.5 - 7.7 7.9 8.1 - 8.4 8.6 8.9 - 9.0 9.2 9.5 - 9.6 9.8 10.1 - 10.2 10.4 10.8 -

HI PR 212 227 231 - 239 257 261 - 272 292 297 - 310 333 338 - 348 375 380 - 390 420 426 -

LO PR 119 123 134 - 123 126 138 - 127 131 143 - 130 134 147 - 133 137 149 - 136 140 153 -

MBh 35.236.239.242.034.335.438.341.133.534.537.440.132.7 33.7 36.4 39.1 31.1 32.0 34.6 37.2 28.8 29.6 32.1 34.4

S/T 0.860.770.590.380.900.800.610.390.920.820.620.400.95 0.85 0.64 0.41 0.98 0.88 0.67 0.43 0.99 0.89 0.67 0.43

DeltaT21191611212016112120161122 20 16 11 21 20 16 11 20 18 15 10

1325 KW 1.871.911.972.042.022.072.142.222.162.212.292.372.28 2.34 2.42 2.51 2.39 2.44 2.53 2.62 2.47 2.53 2.62 2.72

AMPS7.27.47.67.97.88.08.38.68.58.79.09.49.1 9.4 9.7 10.1 9.7 10.0 10.3 10.8 10.4 10.6 11.0 11.4

HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 356 382 388 396 398 428 434 444

LO PR 121 125 137 146 125 129 141 150 129 133 146 155 133 13

149 159 135 140 152 162 139 143 156 166

MBh 34.135.138.040.833.334.337.239.932.533.536.338.931.7 32.7 35.4 38.0 30.2 31.1 33.6 36.1 27.9 28.8 31.1 33.4

S/T 0.820.740.560.360.850.760.580.370.880.780.590.380.90 0.81 0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

DeltaT22201711222117122221171222 21 17 12 22 20 17 12 21 19 16 11

75 1175 KW 1.851.891.962.032.002.052.122.202.142.192.272.352.26 2.32 2.40 2.48 2.36 2.42 2.51 2.60 2.45 2.51 2.60 2.69

AMPS7.17.37.67.97.77.98.28.58.48.79.09.39.0 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.9 11.3

HI PR 214 230 233 238 242 260 263 269 275 295 300 306 313 336 341 349 352 378 384 392 394 424 430 439

LO PR 120 124 135 144 124 128 139 148 128 132 144 154 131 136 148 158 134 138 151 161 137 142 155 165

MBh 31.532.435.137.730.831.734.336.830.030.933.535.929.3 30.2 32.7 35.1 27.8 28.7 31.0 33.3 25.8 26.6 28.7 30.8

S/T 0.800.710.540.350.820.740.560.360.850.760.570.370.87 0.78 0.59 0.38 0.91 0.81 0.61 0.39 0.91 0.82 0.62 0.40

DeltaT22211712232117122321171223 21 17 12 23 21 17 12 21 19 16 11

1025 KW 1.831.881.942.011.992.032.102.182.122.172.252.332.24 2.29 2.38 2.46 2.34 2.40 2.48 2.57 2.43 2.49 2.58 2.67

AMPS7.17.27.57.87.77.98.18.48.48.68.99.29.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.8 11.2

HI PR 212 227 231 236 239 257 261 267 272 292 297 303 310 333 338 345 348 375 380 388 390 420 426 435

LO PR 119 123 134 143 123 126 138 147 127 131 143 152 130 134 147 156 133 137 149 159 136 140 153 163

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area isACCA (TVA) conditions

PERFORMANCE DATA ASX180481*-LOW STAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180481A* / CA*F4961*6**+TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. Low Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67 715963677159636771

MBh 35.836.639.141.834.935.738.240.834.134.937.239.833.3 34.0 36.3 38.831.632.334.536.929.329.932.034.2

S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.62 1.00 1.00 0.83 0.62

DeltaT24232016242320162423201623 24 20162222201620211815

1325 KW 1.87 1.91 1.97 2.04 2.02 2.07 2.14 2.22 2.16 2.21 2.29 2.37 2.28 2.34 2.42 2.51 2.39 2.44 2.53 2.62 2.47 2.53 2.62 2.72

AMPS 7.2 7.4 7.6 7.9 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.4 9.1 9.4 9.7 10.1 9.7 10.0 10.3 10.8 10.4 10.6 11.0 11.4

HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 356 382 388 396 398 428 434 444

LO PR 121 125 137 146 125 129 141 150 129 133 146 155 133 137 149 159 135 140 152 162 139 143 156 166

MBh 34.735.537.940.533.934.737.039.633.133.836.238.732.3 33.0 35.3 37.7 30.7 31.4 33.5 35.8 28.4 29.1 31.0 33.2

S/T 0.900.850.690.520.940.880.720.530.960.900.730.550.99 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 0.97 0.79 0.59

DeltaT25242016252421172524211725 24 21 17 24 24 21 16 22 22 19 15

80 1175 KW 1.851.891.962.032.002.052.122.202.142.192.272.352.26 2.32 2.40 2.48 2.36 2.42 2.51 2.60 2.45 2.51 2.60 2.69

AMPS7.17.37.67.97.77.98.28.58.48.79.09.39.0 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.9 11.3

HI PR 214 230 233 238 242 260 263 269 275 295 300 306 313 336 341 349 352 378 384 392 394 424 430 439

LO PR 120 124 135 144 124 128 139 148 128 132 144 154 131 136 148 158 134 138 151 161 137 142 155 165

MBh 32.132.835.037.431.332.034.236.530.631.233.435.729.8 30.5 32.6 34.828.329.030.933.126.226.828.730.6

S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57

DeltaT25242117252421172524211726 25 21172524211724232016

1025 KW 1.83 1.88 1.94 2.01 1.99 2.03 2.10 2.18 2.12 2.17 2.25 2.33 2.24 2.29 2.38 2.46 2.34 2.40 2.48 2.57 2.43 2.49 2.58 2.67

AMPS 7.1 7.2 7.5 7.8 7.7 7.9 8.1 8.4 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.8 11.2

HI PR 212 227 231 236 239 257 261 267 272 292 297 303 310 333 338 345 348 375 380 388 390 420 426 435

LO PR 119 123 134 143 123 126 138 147 127 131 143 152 130 134 147 156 133 137 149 159 136 140 153 163

MBh 36.437.138.941.535.636.238.040.534.735.437.139.533.9 34.5 36.2 38.632.232.834.336.629.830.431.833.9

S/T 0.99 0.96 0.87 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 0.99 0.81

DeltaT25252320252524202425242023 24 24212223232021212219

1325 KW 1.87 1.91 1.97 2.04 2.02 2.07 2.14 2.22 2.16 2.21 2.29 2.37 2.28 2.34 2.42 2.51 2.39 2.44 2.53 2.62 2.47 2.53 2.62 2.72

AMPS 7.2 7.4 7.6 7.9 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.4 9.1 9.4 9.7 10.1 9.7 10.0 10.3 10.8 10.4 10.6 11.0 11.4

HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 356 382 388 396 398 428 434 444

LO PR 121 125 137 146 125 129 141 150 129 133 146 155 133 137 149 159 135 140 152 162 139 143 156 166

MBh 35.336.037.740.334.535.236.939.333.734.436.038.432.9 33.5 35.1 37.431.231.833.335.628.929.530.933.0

S/T 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77

DeltaT26262421272625212626252126 26 25222425252123232320

85 1175 KW 1.85 1.89 1.96 2.03 2.00 2.05 2.12 2.20 2.14 2.19 2.27 2.35 2.26 2.32 2.40 2.48 2.36 2.42 2.51 2.60 2.45 2.51 2.60 2.69

AMPS 7.1 7.3 7.6 7.9 7.7 7.9 8.2 8.5 8.4 8.7 9.0 9.3 9.0 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.9 11.3

HI PR 214 230 233 238 242 260 263 269 275 295 300 306 313 336 341 349 352 378 384 392 394 424 430 439

LO PR 120 124 135 144 124 128 139 148 128 132 144 154 131 136 148 158 134 138 151 161 137 142 155 165

MBh 32.633.334.837.231.932.534.036.331.131.733.235.430.3 30.9 32.4 34.628.829.430.832.826.727.228.530.4

S/T 0.91 0.88 0.80 0.65 0.95 0.91 0.83 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.91 0.74

Delta T 26.75 26 25 22 27 27 25 22 27 27 25 22 27 27 25 22 26 26 25 22 24 24 23 20

1025 KW 1.83 1.88 1.94 2.01 1.99 2.03 2.10 2.18 2.12 2.17 2.25 2.33 2.24 2.29 2.38 2.46 2.34 2.40 2.48 2.57 2.43 2.49 2.58 2.67

AMPS 7.1 7.2 7.5 7.8 7.7 7.9 8.1 8.4 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.8 11.2

HI PR 212 227 231 236 239 257 261 267 272 292 297 303 310 333 338 345 348 375 380 388 390 420 426 435

LO PR 119 123 134 143 123 126 138 147 127 131 143 152 130 134 147 156 133 137 149 159 136 140 153 163

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

PERFORMANCE DATA ASX180601*-LOW STAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180601A* / CA*F4961*6** +TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. Low Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67 715963677159636771

MBh 42.4 43.9 48.1 - 41.4 42.9 47.0 - 40.4 41.9 45.9 - 39.4 40.8 44.7 - 37.4 38.8 42.5 - 34.7 35.9 39.4 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -

Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

1520 KW 2.43 2.49 2.57 - 2.64 2.70 2.79 - 2.82 2.89 2.99 - 2.98 3.05 3.16 - 3.12 3.19 3.31 - 3.24 3.31 3.43 -

AMPS 9.4 9.6 10.0 - 10.2 10.4 10.8 - 11.1 11.4 11.8 - 11.9 12.2 12.6 - 14.0 14.3 14.8 - 14.8 15.1 15.7 -

HI PR 226 243 247 - 248 267 271 - 291 313 317 - 331 356 361 - 372 400 406 - 430 463 469 -

LO PR 118 122 133 - 121 125 137 - 125 129 141 - 129 133 145 - 131 136 148 - 135 139 152 -

MBh 41.1 42.6 46.7 - 40.2 41.6 45.6 - 39.2 40.6 44.5 - 38.3 39.6 43.4 - 36.3 37.7 41.3 - 33.7 34.9 38.2 -

S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -

Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

70 1350 KW 2.41 2.47 2.55 - 2.61 2.68 2.77 - 2.80 2.86 2.96 - 2.95 3.03 3.13 - 3.09 3.16 3.28 - 3.21 3.28 3.40 -

AMPS 9.3 9.5 9.9 - 10.1 10.3 10.7 - 11.0 11.3 11.7 - 11.8 12.1 12.5 - 13.8 14.2 14.7 - 14.6 15.0 15.5 -

HI PR 224 241 244 - 246 264 268 - 288 309 314 - 328 352 357 - 369 397 402 - 426 458 465 -

LO PR 117 120 131 - 120 124 135 - 124 128 140 - 128 132 144 - 130 134 146 - 133 137 150 -

MBh 38.0 39.3 43.1 - 37.1 38.4 42.1 - 36.2 37.5 41.1 - 35.3 36.6 40.1 - 33.5 34.8 38.1 - 31.1 32.2 35.3 -

S/T 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.64 0.44 - 0.77 0.64 0.44 -

Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -

1180 KW 2.39 2.44 2.53 - 2.59 2.65 2.75 - 2.77 2.84 2.94 - 2.93 3.00 3.10 - 3.06 3.14 3.25 - 3.18 3.25 3.37 -

AMPS 9.2 9.4 9.8 - 10.0 10.2 10.6 - 10.9 11.2 11.6 - 11.7 12.0 12.4 - 13.7 14.0 14.5 - 14.5 14.8 15.4 -

HI PR 222 238 242 - 243 262 265 - 285 306 311 - 325 349 354 - 365 393 398 - 422 454 460 -

LO PR 116 119 130 - 119 123 134 - 123 127 138 - 126 130 142 - 129 133 145 - 132 136 149 -

MBh 43.144.348.051.542.143.346.950.341.142.345.849.140.1 41.3 44.7 47.9 38.1 39.2 42.4 45.5 35.3 36.3 39.3 42.2

S/T 0.830.740.560.360.860.770.580.370.880.790.590.380.91 0.81 0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

DeltaT22201611222016112220161122 20 17 11 22 20 16 11 20 19 15 11

1520 KW 2.432.492.572.672.642.702.792.892.822.892.993.102.98 3.05 3.16 3.28 3.12 3.19 3.31 3.43 3.24 3.31 3.43 3.56

AMPS 9.4 9.6 10.0 10.3 10.2 10.4 10.8 11.2 11.1 11.4 11.8 12.2 11.9 12.2 12.6 13.1 14.0 14.3 14.8 15.4 14.8 15.1 15.7 16.3

HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 372 400 406 415 430 463 469 480

LO PR 118 122 133 141 121 125 137 146 125 129 141 150 129 13

145 154 131 136 148 158 135 139 152 161

MBh 41.843.146.650.040.842.145.548.939.941.144.447.738.9 40.1 43.4 46.5 37.0 38.0 41.2 44.2 34.2 35.2 38.1 40.9

S/T 0.790.700.530.340.820.730.550.360.840.750.570.360.86 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39

DeltaT22211712232117122321171223 21 17 12 23 21 17 12 21 19 16 11

75 1350 KW 2.412.472.552.642.612.682.772.872.802.862.963.072.95 3.03 3.13 3.25 3.09 3.16 3.28 3.40 3.21 3.28 3.40 3.53

AMPS 9.3 9.5 9.9 10.210.110.310.711.111.011.311.712.111.8 12.1 12.5 13.0 13.8 14.2 14.7 15.3 14.6 15.0 15.5 16.1

HI PR 224 241 244 250 246 264 268 274 288 309 314 321 328 352 357 365 369 397 402 411 426 458 465 475

LO PR 117 120 131 140 120 124 135 144 124 128 140 149 128 132 144 153 130 134 146 156 133 137 150 160

MBh 38.639.743.046.237.738.842.045.136.837.941.044.035.9 37.0 40.0 42.9 34.1 35.1 38.0 40.8 31.6 32.5 35.2 37.8

S/T 0.760.680.510.330.790.700.530.340.810.720.550.350.83 0.75 0.56 0.36 0.87 0.77 0.59 0.38 0.87 0.78 0.59 0.38

DeltaT23211712232117122321171223 21 18 12 23 21 17 12 21 20 16 11

1180 KW 2.392.442.532.622.592.652.752.842.772.842.943.042.93 3.00 3.10 3.22 3.06 3.14 3.25 3.37 3.18 3.25 3.37 3.49

AMPS 9.2 9.4 9.8 10.110.010.210.611.010.911.211.612.011.7 12.0 12.4 12.9 13.7 14.0 14.5 15.1 14.5 14.8 15.4 16.0

HI PR 222 238 242 247 243 262 265 271 285 306 311 318 325 349 354 362 365 393 398 407 422 454 460 470

LO PR 116 119 130 139 119 123 134 143 123 127 138 147 126 130 142 151 129 133 145 154 132 136 149 158

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area isACCA (TVA) conditions

PERFORMANCE DATA ASX180601*-LOW STAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180601A* / CA*F4961*6** +TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. Low Stage

OutdoorAmbient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67715963677159636771

MBh 43.8 44.8 47.9 51.2 42.8 43.8 46.7 50.0 41.8 42.7 45.6 48.8 40.8 41.7 44.5 47.6 38.7 39.6 42.3 45.2 35.9 36.7 39.2 41.9

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.96 0.90 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.79 0.59

DeltaT24232016242320162423201625 23 20162323201622221915

1520 KW 2.43 2.49 2.57 2.67 2.64 2.70 2.79 2.89 2.82 2.89 2.99 3.10 2.98 3.05 3.16 3.28 3.12 3.19 3.31 3.43 3.24 3.31 3.43 3.56

AMPS 9.4 9.6 10.0 10.3 10.2 10.4 10.8 11.2 11.1 11.4 11.8 12.2 11.9 12.2 12.6 13.1 14.0 14.3 14.8 15.4 14.8 15.1 15.7 16.3

HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 372 400 406 415 430 463 469 480

LO PR 118 122 133 141 121 125 137 146 125 129 141 150 129 133 145 154 131 136 148 158 135 139 152 161

MBh 42.6 43.5 46.5 49.7 41.6 42.5 45.4 48.5 40.6 41.5 44.3 47.4 39.6 40.5 43.2 46.2 37.6 38.4 41.1 43.9 34.8 35.6 38.0 40.7

S/T 0.86 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57

DeltaT25242117252421172524211726 24 21 17 25 24 21 17 24 23 20 16

80 1350 KW 2.41 2.47 2.55 2.64 2.61 2.68 2.77 2.87 2.80 2.86 2.96 3.07 2.95 3.03 3.13 3.25 3.09 3.16 3.28 3.40 3.21 3.28 3.40 3.53

AMPS 9.3 9.5 9.9 10.2 10.1 10.3 10.7 11.1 11.0 11.3 11.7 12.1 11.8 12.1 12.5 13.0 13.8 14.2 14.7 15.3 14.6 15.0 15.5 16.1

HI PR 224 241 244 250 246 264 268 274 288 309 314 321 328 352 357 365 369 397 402 411 426 458 465 475

LO PR 117 120 131 140 120 124 135 144 124 128 140 149 128 132 144 153 130 134 146 156 133 137 150 160

MBh 39.3 40.1 42.9 45.8 38.4 39.2 41.9 44.8 37.5 38.3 40.9 43.7 36.5 37.3 39.9 42.6 34.7 35.5 37.9 40.5 32.2 32.9 35.1 37.5

S/T 0.83 0.78 0.64 0.48 0.86 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.96 0.90 0.73 0.55

DeltaT26242117262522172625221726 25 22172625211724232016

1180 KW 2.39 2.44 2.53 2.62 2.59 2.65 2.75 2.84 2.77 2.84 2.94 3.04 2.93 3.00 3.10 3.22 3.06 3.14 3.25 3.37 3.18 3.25 3.37 3.49

AMPS 9.2 9.4 9.8 10.1 10.0 10.2 10.6 11.0 10.9 11.2 11.6 12.0 11.7 12.0 12.4 12.9 13.7 14.0 14.5 15.1 14.5 14.8 15.4 16.0

HI PR 222 238 242 247 243 262 265 271 285 306 311 318 325 349 354 362 365 393 398 407 422 454 460 470

LO PR 116 119 130 139 119 123 134 143 123 127 138 147 126 130 142 151 129 133 145 154 132 136 149 158

MBh 44.6 45.5 47.6 50.8 43.6 44.4 46.5 49.6 42.5 43.4 45.4 48.4 41.5 42.3 44.3 47.3 39.4 40.2 42.1 44.9 36.5 37.2 39.0 41.6

S/T 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.70 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77

DeltaT26252421262624212626242125 26 24212424242122232219

1520 KW 2.43 2.49 2.57 2.67 2.64 2.70 2.79 2.89 2.82 2.89 2.99 3.10 2.98 3.05 3.16 3.28 3.12 3.19 3.31 3.43 3.24 3.31 3.43 3.56

AMPS 9.4 9.6 10.0 10.3 10.2 10.4 10.8 11.2 11.1 11.4 11.8 12.2 11.9 12.2 12.6 13.1 14.0 14.3 14.8 15.4 14.8 15.1 15.7 16.3

HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 372 400 406 415 430 463 469 480

LO PR 118 122 133 141 121 125 137 146 125 129 141 150 129 133 145 154 131 136 148 158 135 139 152 161

MBh 43.3 44.1 46.2 49.3 42.3 43.1 45.2 48.2 41.3 42.1 44.1 47.0 40.3 41.1 43.0 45.9 38.3 39.0 40.9 43.6 35.4 36.1 37.8 40.4

S/T 0.91 0.87 0.79 0.64 0.94 0.91 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.73

DeltaT27262522272725222727252227 27 25222626252224252320

85 1350 KW 2.41 2.47 2.55 2.64 2.61 2.68 2.77 2.87 2.80 2.86 2.96 3.07 2.95 3.03 3.13 3.25 3.09 3.16 3.28 3.40 3.21 3.28 3.40 3.53

AMPS 9.3 9.5 9.9 10.2 10.1 10.3 10.7 11.1 11.0 11.3 11.7 12.1 11.8 12.1 12.5 13.0 13.8 14.2 14.7 15.3 14.6 15.0 15.5 16.1

HI PR 224 241 244 250 246 264 268 274 288 309 314 321 328 352 357 365 369 397 402 411 426 458 465 475

LO PR 117 120 131 140 120 124 135 144 124 128 140 149 128 132 144 153 130 134 146 156 133 137 150 160

MBh 40.0 40.7 42.7 45.5 39.0 39.8 41.7 44.5 38.1 38.8 40.7 43.4 37.2 37.9 39.7 42.3 35.3 36.0 37.7 40.2 32.7 33.4 34.9 37.3

S/T 0.87 0.84 0.76 0.62 0.91 0.87 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.96 0.87 0.70 1.00 0.97 0.87 0.71

DeltaT27.2272522282726222827262228 27 26222727252225252421

1180 KW 2.39 2.44 2.53 2.62 2.59 2.65 2.75 2.84 2.77 2.84 2.94 3.04 2.93 3.00 3.10 3.22 3.06 3.14 3.25 3.37 3.18 3.25 3.37 3.49

AMPS 9.2 9.4 9.8 10.1 10.0 10.2 10.6 11.0 10.9 11.2 11.6 12.0 11.7 12.0 12.4 12.9 13.7 14.0 14.5 15.1 14.5 14.8 15.4 16.0

HI PR 222 238 242 247 243 262 265 271 285 306 311 318 325 349 354 362 365 393 398 407 422 454 460 470

LO PR 116 119 130 139 119 123 134 143 123 127 138 147 126 130 142 151 129 133 145 154 132 136 149 158

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

COOLINGPERFORMANCEDATA ASX180361*-HIGHSTAGE

EXPANDED PERFORMANCE DATA

MODEL: ASX180361A* / CA*F4961*6** + TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. High Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59 63 6771 59 6367 71 59 63 677159 63 67 715963677159636771

MBh 36.7 38.1 41.7 - 35.9 37.2 40.7 - 35.0 36.3 39.8 - 34.2 35.4 38.8 - 32.4 33.6 36.8 - 30.1 31.2 34.1 -

S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -

Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -

1330 KW 2.09 2.14 2.21 - 2.26 2.31 2.39 - 2.41 2.47 2.56 - 2.55 2.61 2.70 - 2.66 2.73 2.82 - 2.76 2.83 2.93 -

AMPS 8.2 8.4 8.7 - 8.9 9.1 9.4 - 9.7 9.9 10.3 - 10.4 10.7 11.0 - 11.1 11.4 11.8 - 11.8 12.1 12.5 -

HIPR 220 237 240 - 249 268 271 - 283 304 309 - 322 347 352 - 348 374 380 - 413 444 450 -

LOPR 118 122 133 - 122 126 137 - 126 130 142 - 129 134 146 - 132 136 149 - 135 140 152 -

MBh 35.6 36.9 40.5 - 34.8 36.1 39.5 - 34.0 35.2 38.6 - 33.2 34.4 37.7 - 31.5 32.7 35.8 - 29.2 30.2 33.1 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -

Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

70 1175 KW 2.07 2.12 2.19 - 2.24 2.29 2.37 - 2.39 2.45 2.53 - 2.53 2.59 2.68 - 2.64 2.70 2.80 - 2.74 2.80 2.90 -

AMPS 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.6 9.9 10.2 - 10.3 10.6 10.9 - 11.0 11.3 11.7 - 11.7 12.0 12.4 -

HIPR 218 234 238 - 246 265 269 - 280 301 306 - 319 343 348 - 345 371 376 - 409 439 446 -

LOPR 117 121 132 - 121 125 136 - 125 129 141 - 128 132 144 - 131 135 147 - 134 138 151 -

MBh 32.9 34.1 37.4 - 32.1 33.3 36.5 - 31.4 32.5 35.6 - 30.6 31.7 34.8 - 29.1 30.1 33.0 - 26.9 27.9 30.6 -

S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -

Delta T 20 17 13 - 20 18 13 - 20 18 13 - 20 18 13 - 20 17 13 - 19 16 12 -

1025 KW 2.05 2.10 2.17 - 2.22 2.27 2.35 - 2.37 2.43 2.51 - 2.50 2.56 2.65 - 2.62 2.68 2.77 - 2.71 2.78 2.88 -

AMPS 8.1 8.3 8.5 - 8.7 9.0 9.3 - 9.5 9.8 10.1 - 10.2 10.5 10.8 - 10.9 11.2 11.5 - 11.6 11.8 12.3 -

HIPR 216 232 235 - 244 262 266 - 278 298 303 - 316 340 345 - 341 367 372 - 405 435 441 -

LOPR 116 120 131 - 120 123 135 - 124 127 139 - 127 131 143 - 129 134 146 - 133 137 149 -

MBh 37.3 38.4 41.6 44.7 36.5 37.5 40.6 43.6 35.6 36.7 39.7 42.6 34.7 35.8 38.7 41.5 33.0 34.0 36.8 39.5 30.6 31.5 34.1 36.6

S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42

DeltaT222016112220171122 2017112220 17 12 22 20 16 11 20 19 15 11

1330 KW 2.09 2.14 2.21 2.28 2.26 2.31 2.39 2.48 2.41 2.47 2.56 2.65 2.55 2.61 2.70 2.80 2.66 2.73 2.82 2.92 2.76 2.83 2.93 3.03

AMPS 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.7 9.9 10.3 10.7 10.4 10.7 11.0 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 13.0

HI PR 220 237 240 245 249 268 271 277 283 304 309 316 322 347 352 359 348 374 380 388 413 444 450 460

LO PR 118 122 133 142 122 126 137 146 126 130 142 151 129 134 146 155 132 136 149 158 135 140 152 162

MBh 36.3 37.3 40.4 43.4 35.4 36.5 39.5 42.4 34.6 35.6 38.5 41.3 33.7 34.7 37.6 40.3 32.0 33.0 35.7 38.3 29.7 30.6 33.1 35.5

S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40

DeltaT232117122321171223 2117122321 17 12 23 21 17 12 21 20 16 11

75 1175 KW 2.07 2.12 2.19 2.26 2.24 2.29 2.37 2.45 2.39 2.45 2.53 2.62 2.53 2.59 2.68 2.77 2.64 2.70 2.80 2.90 2.74 2.80 2.90 3.01

AMPS 8.1 8.3 8.6 9.0 8.8 9.0 9.3 9.7 9.6 9.9 10.2 10.6 10.3 10.6 10.9 11.4 11.0 11.3 11.7 12.1 11.7 12.0 12.4 12.9

HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455

LO PR 117 121 132 141 121 125 136 145 125 129 141 150 128 132 144 154 131 135 147 157 134 138 151 161

MBh 33.5 34.5 37.3 40.0 32.7 33.6 36.4 39.1 31.9 32.8 35.6 38.2 31.1 32.0 34.7 37.2 29.6 30.4 33.0 35.4 27.4 28.2 30.5 32.8

S/T 0.77 0.69 0.52 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.88 0.79 0.59 0.38 0.89 0.79 0.60 0.39

DeltaT232117122322181223 2218122422 18 12 23 21 18 12 22 20 16 11

1025 KW 2.05 2.10 2.17 2.24 2.22 2.27 2.35 2.43 2.37 2.43 2.51 2.60 2.50 2.56 2.65 2.75 2.62 2.68 2.77 2.87 2.71 2.78 2.88 2.98

AMPS 8.1 8.3 8.5 8.9 8.7 9.0 9.3 9.6 9.5 9.8 10.1 10.5 10.2 10.5 10.8 11.2 10.9 11.2 11.5 12.0 11.6 11.8 12.3 12.7

HI PR 216 232 235 241 244 262 266 272 278 298 303 309 316 340 345 352 341 367 372 380 405 435 441 451

LO PR 116 120 131 139 120 123 135 143 124 127 139 148 127 131 143 152 129 134 146 155 133 137 149 159

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

COOLINGPERFORMANCEDATA ASX180361*-HIGHSTAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180361A* / CA*F4961*6** + TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. High Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59 63 6771 59 6367 71 59 63 677159 63 67 715963677159636771

MBh 38.0 38.8 41.5 44.4 37.1 37.9 40.5 43.3 36.2 37.0 39.6 42.3 35.4 36.1 38.6 41.3 33.6 34.3 36.7 39.2 31.1 31.8 34.0 36.3

S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.81 0.60

DeltaT24 23 201624 2320 16 25 23 201624 24 21 162324201622221915

1330 KW 2.09 2.14 2.21 2.28 2.26 2.31 2.39 2.48 2.41 2.47 2.56 2.65 2.55 2.61 2.70 2.80 2.66 2.73 2.82 2.92 2.76 2.83 2.93 3.03

AMPS 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.7 9.9 10.3 10.7 10.4 10.7 11.0 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 13.0

HI PR 220 237 240 245 249 268 271 277 283 304 309 316 322 347 352 359 348 374 380 388 413 444 450 460

LO PR 118 122 133 142 122 126 137 146 126 130 142 151 129 134 146 155 132 136 149 158 135 140 152 162

MBh 36.9 37.7 40.3 43.1 36.0 36.8 39.3 42.1 35.2 35.9 38.4 41.1 34.3 35.1 37.5 40.1 32.6 33.3 35.6 38.1 30.2 30.9 33.0 35.2

S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.94 0.76 0.57 1.00 0.94 0.77 0.57

DeltaT252421172625211726 2521172625 22 17 25 24 21 17 24 23 20 16

80 1175 KW 2.07 2.12 2.19 2.26 2.24 2.29 2.37 2.45 2.39 2.45 2.53 2.62 2.53 2.59 2.68 2.77 2.64 2.70 2.80 2.90 2.74 2.80 2.90 3.01

AMPS 8.1 8.3 8.6 9.0 8.8 9.0 9.3 9.7 9.6 9.9 10.2 10.6 10.3 10.6 10.9 11.4 11.0 11.3 11.7 12.1 11.7 12.0 12.4 12.9

HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455

LO PR 117 121 132 141 121 125 136 145 125 129 141 150 128 132 144 154 131 135 147 157 134 138 151 161

MBh 34.1 34.8 37.2 39.7 33.3 34.0 36.3 38.8 32.5 33.2 35.4 37.9 31.7 32.4 34.6 37.0 30.1 30.8 32.9 35.1 27.9 28.5 30.4 32.5

S/T 0.85 0.79 0.65 0.48 0.88 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.74 0.55 0.97 0.91 0.74 0.55

DeltaT26 25 221726 2522 17 26 25 221726 25 22 182625221724232016

1025 KW 2.05 2.10 2.17 2.24 2.22 2.27 2.35 2.43 2.37 2.43 2.51 2.60 2.50 2.56 2.65 2.75 2.62 2.68 2.77 2.87 2.71 2.78 2.88 2.98

AMPS 8.1 8.3 8.5 8.9 8.7 9.0 9.3 9.6 9.5 9.8 10.1 10.5 10.2 10.5 10.8 11.2 10.9 11.2 11.5 12.0 11.6 11.8 12.3 12.7

HI PR 216 232 235 241 244 262 266 272 278 298 303 309 316 340 345 352 341 367 372 380 405 435 441 451

LO PR 116 120 131 139 120 123 135 143 124 127 139 148 127 131 143 152 129 134 146 155 133 137 149 159

MBh 38.7 39.4 41.3 44.0 37.8 38.5 40.3 43.0 36.9 37.6 39.4 42.0 36.0 36.7 38.4 41.0 34.2 34.8 36.5 38.9 31.7 32.3 33.8 36.1

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.96 0.78

DeltaT26 25 242126 2624 21 25 26 242125 25 24 212424242122222319

1330 KW 2.09 2.14 2.21 2.28 2.26 2.31 2.39 2.48 2.41 2.47 2.56 2.65 2.55 2.61 2.70 2.80 2.66 2.73 2.82 2.92 2.76 2.83 2.93 3.03

AMPS 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.7 9.9 10.3 10.7 10.4 10.7 11.0 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 13.0

HI PR 220 237 240 245 249 268 271 277 283 304 309 316 322 347 352 359 348 374 380 388 413 444 450 460

LO PR 118 122 133 142 122 126 137 146 126 130 142 151 129 134 146 155 132 136 149 158 135 140 152 162

MBh 37.5 38.3 40.1 42.8 36.7 37.4 39.1 41.8 35.8 36.5 38.2 40.8 34.9 35.6 37.3 39.8 33.2 33.8 35.4 37.8 30.7 31.3 32.8 35.0

S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.75

DeltaT27 27 252227 2725 22 27 27 252227 27 26 222626252224252420

85 1175 KW 2.07 2.12 2.19 2.26 2.24 2.29 2.37 2.45 2.39 2.45 2.53 2.62 2.53 2.59 2.68 2.77 2.64 2.70 2.80 2.90 2.74 2.80 2.90 3.01

AMPS 8.1 8.3 8.6 9.0 8.8 9.0 9.3 9.7 9.6 9.9 10.2 10.6 10.3 10.6 10.9 11.4 11.0 11.3 11.7 12.1 11.7 12.0 12.4 12.9

HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455

LO PR 117 121 132 141 121 125 136 145 125 129 141 150 128 132 144 154 131 135 147 157 134 138 151 161

MBh 34.6 35.3 37.0 39.5 33.8 34.5 36.1 38.5 33.0 33.7 35.3 37.6 32.2 32.9 34.4 36.7 30.6 31.2 32.7 34.9 28.4 28.9 30.3 32.3

S/T 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 0.98 0.89 0.72

DeltaT28 27 262228 2726 22 28 27 262228 28 26 232727262225252421

1025 KW 2.05 2.10 2.17 2.24 2.22 2.27 2.35 2.43 2.37 2.43 2.51 2.60 2.50 2.56 2.65 2.75 2.62 2.68 2.77 2.87 2.71 2.78 2.88 2.98

AMPS 8.1 8.3 8.5 8.9 8.7 9.0 9.3 9.6 9.5 9.8 10.1 10.5 10.2 10.5 10.8 11.2 10.9 11.2 11.5 12.0 11.6 11.8 12.3 12.7

HI PR 216 232 235 241 244 262 266 272 278 298 303 309 316 340 345 352 341 367 372 380 405 435 441 451

LO PR 116 120 131 139 120 123 135 143 124 127 139 148 127 131 143 152 129 134 146 155 133 137 149 159

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

COOLINGPERFORMANCEDATA ASX180481*-HIGHSTAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180481A* / CA*F4961*6** + TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. High Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 596367715963677159 63 677159 63 67 715963677159636771

MBh 48.2 50.0 54.8 - 47.1 48.8 53.5 - 46.0 47.7 52.2 - 44.9 46.5 50.9 - 42.6 44.2 48.4 - 39.5 40.9 44.8 -

S/T 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -

Delta T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -

1970 KW 2.87 2.94 3.03 - 3.10 3.17 3.27 - 3.30 3.37 3.48 - 3.47 3.55 3.67 - 3.62 3.70 3.83 - 3.75 3.84 3.97 -

AMPS 10.2 10.5 10.8 - 11.1 11.4 11.7 - 12.1 12.4 12.8 - 13.0 13.3 13.7 - 13.8 14.2 14.7 - 14.7 15.1 15.6 -

HI PR 228 245 248 - 257 277 280 - 292 315 319 - 333 358 363 - 375 403 409 - 420 451 458 -

LO PR 121 124 136 - 124 128 140 - 128 132 145 - 132 136 148 - 134 139 151 - 138 142 155 -

MBh 46.8 48.5 53.2 - 45.7 47.4 51.9 - 44.6 46.3 50.7 - 43.5 45.1 49.5 - 41.4 42.9 47.0 - 38.3 39.7 43.5 -

S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -

Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

70 1750 KW 2.85 2.91 3.01 - 3.07 3.14 3.24 - 3.27 3.34 3.45 - 3.44 3.52 3.64 - 3.59 3.67 3.80 - 3.72 3.80 3.93 -

AMPS 10.1 10.4 10.7 - 11.0 11.2 11.6 - 12.0 12.3 12.7 - 12.8 13.2 13.6 - 13.7 14.0 14.5 - 14.5 14.9 15.4 -

HI PR 225 242 246 - 255 274 278 - 290 311 316 - 330 355 360 - 371 399 405 - 416 447 453 -

LO PR 119 123 134 - 123 127 138 - 127 131 143 - 130 135 147 - 133 137 150 - 136 141 154 -

MBh 43.2 44.8 49.1 - 42.2 43.7 47.9 - 41.2 42.7 46.8 - 40.2 41.7 45.6 - 38.2 39.6 43.4 - 35.4 36.7 40.2 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -

Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

1530 KW 2.83 2.89 2.98 - 3.05 3.12 3.22 - 3.24 3.32 3.43 - 3.42 3.49 3.61 - 3.56 3.64 3.76 - 3.69 3.77 3.90 -

AMPS 10.0 10.3 10.6 - 10.9 11.1 11.5 - 11.9 12.2 12.6 - 12.7 13.0 13.5 - 13.6 13.9 14.4 - 14.4 14.8 15.3 -

HI PR 223 240 243 - 252 271 275 - 287 308 313 - 327 351 356 - 367 395 401 - 411 442 449 -

LO PR 118 122 133 - 122 125 137 - 126 130 142 - 129 133 145 - 132 136 148 - 135 139 152 -

MBh 49.0 50.5 54.6 58.7 47.9 49.3 53.4 57.3 46.8 48.1 52.1 55.9 45.6 47.0 50.8 54.6 43.3 44.6 48.3 51.8 40.1 41.3 44.7 48.0

S/T 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.92 0.83 0.63 0.40 0.95 0.85 0.65 0.42 0.99 0.89 0.67 0.43 1.00 0.89 0.68 0.44

DeltaT201815102019151020 19 15112019 15 11 20 18 15 10 19 17 14 10

1970 KW 2.87 2.94 3.03 3.13 3.10 3.17 3.27 3.38 3.30 3.37 3.48 3.60 3.47 3.55 3.67 3.80 3.62 3.70 3.83 3.96 3.75 3.84 3.97 4.10

AMPS 10.2 10.5 10.8 11.2 11.1 11.4 11.7 12.2 12.1 12.4 12.8 13.3 13.0 13.3 13.7 14.3 13.8 14.2 14.7 15.3 14.7 15.1 15.6 16.2

HI PR 228 245 248 254 257 277 280 287 292 315 319 326 333 358 363 371 375 403 409 418 420 451 458 468

LO PR 121 124 136 145 124 128 140 149 128 132 145 154 132 136 148 158 134 139 151 161 138 142 155 165

MBh 47.6 49.0 53.1 56.9 46.5 47.9 51.8 55.6 45.4 46.7 50.6 54.3 44.3 45.6 49.4 53.0 42.1 43.3 46.9 50.3 39.0 40.1 43.4 46.6

S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

DeltaT211916112119161121 19 16112120 16 11 21 19 16 11 20 18 15 10

75 1750 KW 2.85 2.91 3.01 3.10 3.07 3.14 3.24 3.35 3.27 3.34 3.45 3.57 3.44 3.52 3.64 3.76 3.59 3.67 3.80 3.93 3.72 3.80 3.93 4.07

AMPS 10.1 10.4 10.7 11.1 11.0 11.2 11.6 12.1 12.0 12.3 12.7 13.2 12.8 13.2 13.6 14.2 13.7 14.0 14.5 15.1 14.5 14.9 15.4 16.0

HI PR 225 242 246 251 255 274 278 284 290 311 316 323 330 355 360 368 371 399 405 414 416 447 453 463

LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 154 163

MBh 43.9 45.2 49.0 52.6 42.9 44.2 47.8 51.3 41.9 43.1 46.7 50.1 40.9 42.1 45.6 48.9 38.8 40.0 43.3 46.4 36.0 37.0 40.1 43.0

S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40

DeltaT211916112120161121 20 16112220 16 11 21 20 16 11 20 18 15 10

1530 KW 2.83 2.89 2.98 3.08 3.05 3.12 3.22 3.32 3.24 3.32 3.43 3.54 3.42 3.49 3.61 3.73 3.56 3.64 3.76 3.89 3.69 3.77 3.90 4.03

AMPS 10.0 10.3 10.6 11.0 10.9 11.1 11.5 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.6 13.9 14.4 15.0 14.4 14.8 15.3 15.9

HI PR 223 240 243 249 252 271 275 281 287 308 313 320 327 351 356 364 367 395 401 409 411 442 449 459

LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

COOLINGPERFORMANCEDATA ASX180481*-HIGHSTAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180481A* / CA*F4961*6** + TXV / MBE2000**-1**, Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. High Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 596367715963677159 63 677159 63 67 715963677159636771

MBh 49.9 51.0 54.5 58.2 48.7 49.8 53.2 56.9 47.6 48.6 52.0 55.5 46.4 47.4 50.7 54.2 44.1 45.1 48.1 51.5 40.9 41.7 44.6 47.7

S/T 0.95 0.89 0.73 0.54 1.00 0.93 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.63

DeltaT222119152322191522 22 19152222 19 152121191519191714

1970 KW 2.87 2.94 3.03 3.13 3.10 3.17 3.27 3.38 3.30 3.37 3.48 3.60 3.47 3.55 3.67 3.80 3.62 3.70 3.83 3.96 3.75 3.84 3.97 4.10

AMPS 10.2 10.5 10.8 11.2 11.1 11.4 11.7 12.2 12.1 12.4 12.8 13.3 13.0 13.3 13.7 14.3 13.8 14.2 14.7 15.3 14.7 15.1 15.6 16.2

HI PR 228 245 248 254 257 277 280 287 292 315 319 326 333 358 363 371 375 403 409 418 420 451 458 468

LO PR 121 124 136 145 124 128 140 149 128 132 145 154 132 136 148 158 134 139 151 161 138 142 155 165

MBh 48.5 49.5 52.9 56.5 47.3 48.4 51.7 55.2 46.2 47.2 50.4 53.9 45.1 46.1 49.2 52.6 42.8 43.8 46.7 50.0 39.7 40.5 43.3 46.3

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 0.98 0.80 0.60

DeltaT232219152322201623 22 20162423 20 16 22 22 19 16 21 21 18 14

80 1750 KW 2.85 2.91 3.01 3.10 3.07 3.14 3.24 3.35 3.27 3.34 3.45 3.57 3.44 3.52 3.64 3.76 3.59 3.67 3.80 3.93 3.72 3.80 3.93 4.07

AMPS 10.1 10.4 10.7 11.1 11.0 11.2 11.6 12.1 12.0 12.3 12.7 13.2 12.8 13.2 13.6 14.2 13.7 14.0 14.5 15.1 14.5 14.9 15.4 16.0

HI PR 225 242 246 251 255 274 278 284 290 311 316 323 330 355 360 368 371 399 405 414 416 447 453 463

LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 154 163

MBh 44.7 45.7 48.8 52.2 43.7 44.6 47.7 51.0 42.6 43.6 46.6 49.8 41.6 42.5 45.4 48.6 39.5 40.4 43.1 46.1 36.6 37.4 40.0 42.7

S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.94 0.76 0.57 1.01 0.94 0.77 0.57

DeltaT242320162423201624 23 20162423 20 162423201622211815

1530 KW 2.83 2.89 2.98 3.08 3.05 3.12 3.22 3.32 3.24 3.32 3.43 3.54 3.42 3.49 3.61 3.73 3.56 3.64 3.76 3.89 3.69 3.77 3.90 4.03

AMPS 10.0 10.3 10.6 11.0 10.9 11.1 11.5 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.6 13.9 14.4 15.0 14.4 14.8 15.3 15.9

HI PR 223 240 243 249 252 271 275 281 287 308 313 320 327 351 356 364 367 395 401 409 411 442 449 459

LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162

MBh 50.8 51.8 54.2 57.8 49.6 50.6 53.0 56.5 48.4 49.4 51.7 55.1 47.2 48.2 50.4 53.8 44.9 45.7 47.9 51.1 41.6 42.4 44.4 47.3

S/T 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.81

DeltaT242322192324221923 23 22192222 22 192121221919202118

1970 KW 2.87 2.94 3.03 3.13 3.10 3.17 3.27 3.38 3.30 3.37 3.48 3.60 3.47 3.55 3.67 3.80 3.62 3.70 3.83 3.96 3.75 3.84 3.97 4.10

AMPS 10.2 10.5 10.8 11.2 11.1 11.4 11.7 12.2 12.1 12.4 12.8 13.3 13.0 13.3 13.7 14.3 13.8 14.2 14.7 15.3 14.7 15.1 15.6 16.2

HI PR 228 245 248 254 257 277 280 287 292 315 319 326 333 358 363 371 375 403 409 418 420 451 458 468

LO PR 121 124 136 145 124 128 140 149 128 132 145 154 132 136 148 158 134 139 151 161 138 142 155 165

MBh 49.3 50.3 52.6 56.2 48.2 49.1 51.4 54.8 47.0 47.9 50.2 53.5 45.9 46.7 49.0 52.2 43.6 44.4 46.5 49.6 40.4 41.1 43.1 46.0

S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.95 0.77

DeltaT252423202525232025 25 23202425 23 202323232021222219

85 1750 KW 2.85 2.91 3.01 3.10 3.07 3.14 3.24 3.35 3.27 3.34 3.45 3.57 3.44 3.52 3.64 3.76 3.59 3.67 3.80 3.93 3.72 3.80 3.93 4.07

AMPS 10.1 10.4 10.7 11.1 11.0 11.2 11.6 12.1 12.0 12.3 12.7 13.2 12.8 13.2 13.6 14.2 13.7 14.0 14.5 15.1 14.5 14.9 15.4 16.0

HI PR 225 242 246 251 255 274 278 284 290 311 316 323 330 355 360 368 371 399 405 414 416 447 453 463

LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 154 163

MBh 45.5 46.4 48.6 51.8 44.4 45.3 47.5 50.6 43.4 44.2 46.3 49.4 42.3 43.1 45.2 48.2 40.2 41.0 42.9 45.8 37.3 38.0 39.8 42.4

S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.75

DeltaT252523202525242025 25 24212525 24 212425242022232219

1530 KW 2.83 2.89 2.98 3.08 3.05 3.12 3.22 3.32 3.24 3.32 3.43 3.54 3.42 3.49 3.61 3.73 3.56 3.64 3.76 3.89 3.69 3.77 3.90 4.03

AMPS 10.0 10.3 10.6 11.0 10.9 11.1 11.5 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.6 13.9 14.4 15.0 14.4 14.8 15.3 15.9

HI PR 223 240 243 249 252 271 275 281 287 308 313 320 327 351 356 364 367 395 401 409 411 442 449 459

LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

COOLINGPERFORMANCEDATA ASX180601*-HIGHSTAGE

EXPANDED PERFORMANCE DATA COOLING OPERATION

MODEL: ASX180601A* / CA*F4961*6** / TXV / MBE2000**1**, Design Subcooling @ AHRI 95°F Conditions, 5- 7°F @ the Serv. Vlv. High Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67 715963677159636771

MBh 58.5 60.6 66.4 - 57.1 59.2 64.9 - 55.8 57.8 63.3 - 54.4 56.4 61.8 - 51.7 53.6 58.7 - 47.9 49.6 54.4 -

S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -

DeltaT181512 - 181512 - 181512 - 18 15 12 - 181512 - 161411 -

2250 KW 3.87 3.96 4.09 - 4.18 4.27 4.41 - 4.45 4.55 4.70 - 4.69 4.80 4.96 - 4.89 5.00 5.17 - 5.07 5.18 5.36 -

AMPS 13.8 14.2 14.7 - 15.0 15.4 15.9 - 16.4 16.8 17.4 - 17.6 18.0 18.7 - 20.6 21.2 21.9 - 21.8 22.4 23.2 -

HI PR 241 259 263 - 265 285 289 - 310 333 338 - 353 380 385 - 397 427 433 - 459 493 500 -

LO PR 115 119 130 - 118 122 133 - 123 126 138 - 126 130 142 - 128 132 144 - 131 136 148 -

MBh 56.8 58.9 64.5 - 55.5 57.5 63.0 - 54.2 56.1 61.5 - 52.8 54.8 60.0 - 50.2 52.0 57.0 - 46.5 48.2 52.8 -

S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.66 0.46 - 0.80 0.67 0.46 -

DeltaT181612 - 181612 - 181612 - 19 16 12 - 181612 - 171511 -

70 2000 KW 3.84 3.93 4.05 - 4.15 4.24 4.38 - 4.41 4.51 4.66 - 4.65 4.75 4.91 - 4.85 4.96 5.13 - 5.02 5.14 5.31 -

AMPS 13.7 14.0 14.5 - 14.9 15.2 15.8 - 16.2 16.6 17.2 - 17.4 17.8 18.5 - 20.4 21.0 21.7 - 21.6 22.2 23.0 -

HI PR 239 257 260 - 262 282 286 - 307 330 335 - 349 376 381 - 393 423 429 - 454 488 495 -

LO PR 114 118 128 - 117 121 132 - 121 125 137 - 125 128 140 - 127 131 143 - 130 134 147 -

MBh 52.4 54.3 59.5 - 51.2 53.1 58.1 - 50.0 51.8 56.8 - 48.8 50.5 55.4 - 46.3 48.0 52.6 - 42.9 44.5 48.7 -

S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -

DeltaT191612 - 191612 - 191612 - 19 16 12 - 191612 - 171511 -

1750 KW 3.81 3.89 4.02 - 4.11 4.20 4.34 - 4.38 4.47 4.62 - 4.61 4.71 4.87 - 4.81 4.92 5.08 - 4.98 5.09 5.27 -

AMPS 13.5 13.9 14.4 - 14.7 15.1 15.6 - 16.1 16.5 17.1 - 17.2 17.7 18.3 - 20.2 20.8 21.5 - 21.4 22.0 22.7 -

HI PR 236 254 258 - 259 279 283 - 304 327 331 - 346 372 377 - 389 419 424 - 450 484 490 -

LO PR 113 116 127 - 116 120 131 - 120 124 135 - 123 127 139 - 126 130 142 - 129 133 145 -

MBh 59.561.366.371.258.159.864.869.556.758.463.267.855.3 57.0 61.7 66.2 52.6 54.1 58.6 62.9 48.7 50.1 54.3 58.3

S/T 0.830.750.560.360.860.770.580.380.890.790.600.390.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42

DeltaT20191511201915112119151121 19 16 11 20 19 15 11 19 18 14 10

2250 KW 3.873.964.094.224.184.274.414.564.454.554.704.864.69 4.80 4.96 5.13 4.89 5.00 5.17 5.35 5.07 5.18 5.36 5.55

AMPS13.814.214.715.215.015.415.916.616.416.817.418.117.6 18.0 18.7 19.4 20.6 21.2 21.9 22.8 21.8 22.4 23.2 24.1

HI PR 241 259 263 269 265 285 289 295 310 333 338 345 353 380 385 393 397 427 433 443 459 493 500 511

LO PR 115 119 130 138 118 122 133 142 123 126 138 147 126 130 142 151 128 132 144 154 131 136 148 158

MBh 57.859.564.469.156.458.162.967.555.156.761.465.953.7 55.3 59.9 64.3 51.0 52.6 56.9 61.1 47.3 48.7 52.7 56.6

S/T 0.790.710.540.350.820.740.560.360.840.760.570.370.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.82 0.62 0.40

DeltaT21191611212016112120161122 20 16 11 21 20 16 11 20 18 15 10

75 2000 KW 3.843.934.054.194.154.244.384.524.414.514.664.824.65 4.75 4.91 5.08 4.85 4.96 5.13 5.31 5.02 5.14 5.31 5.50

AMPS13.714.014.515.114.915.215.816.416.216.617.217.917.4 17.8 18.5 19.2 20.4 21.0 21.7 22.6 21.6 22.2 23.0 23.9

HI PR 239 257 260 266 262 282 286 292 307 330 335 342 349 376 381 389 393 423 429 438 454 488 495 506

LO PR 114 118 128 137 117 121 132 141 121 125 137 145 125 128 140 149 127 131 143 152 130 134 147 156

MBh 53.354.959.463.852.153.658.062.350.852.356.760.849.6 51.1 55.3 59.3 47.1 48.5 52.5 56.4 43.6 44.9 48.6 52.2

S/T 0.770.690.520.330.790.710.540.350.810.730.550.350.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38

DeltaT21201611222016112220161122 20 17 11 22 20 16 11 20 19 15 11

1750 KW 3.813.894.024.154.114.204.344.494.384.474.624.784.61 4.71 4.87 5.04 4.81 4.92 5.08 5.26 4.98 5.09 5.27 5.45

AMPS13.513.914.414.914.715.115.616.216.116.517.117.717.2 17.7 18.3 19.0 20.2 20.8 21.5 22.3 21.4 22.0 22.7 23.6

HI PR 236 254 258 263 259 279 283 289 304 327 331 339 346 372 377 386 389 419 424 434 450 484 490 501

LO PR 113 116 127 135 116 120 131 139 120 124 135 144 123 127 139 148 126 130 142 151 129 133 145 155

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

COOLINGPERFORMANCEDATA ASX180601*-HIGHSTAGE

EXPANDED PERFORMANCE DAT

COOLING OPERATION

MODEL: ASX180601A* / CA*F4961*6** / TXV / MBE2000**1**, Design Subcooling @ AHRI 95°F Conditions, 5- 7°F @ the Serv. Vlv. High Stage

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB*Airflow 59636771596367715963677159 63 67 715963677159636771

MBh 60.661.966.170.759.160.464.669.057.759.063.067.456.3 57.6 61.5 65.753.554.758.462.449.650.654.157.8

S/T 0.910.860.700.520.950.890.720.541.000.910.740.551.00 0.94 0.77 0.571.001.000.790.591.001.000.800.60

DeltaT23221915232219152422191523 22 19 152222191520211814

2250 KW 3.873.964.094.224.184.274.414.564.454.554.704.864.69 4.80 4.96 5.134.895.005.175.355.075.185.365.55

AMPS13.814.214.715.215.015.415.916.616.416.817.418.117.6 18.0 18.7 19.420.621.221.922.821.822.423.224.1

HI PR 241 259 263 269 265 285 289 295 310 333 338 345 353 380 385 393 397 427 433 443 459 493 500 511

LO PR 115 119 130 138 118 122 133 142 123 126 138 147 126 130 142 151 128 132 144 154 131 136 148 158

MBh 58.860.164.268.657.458.762.767.056.157.361.265.454.7 55.9 59.7 63.8 52.0 53.1 56.7 60.6 48.1 49.2 52.5 56.2

S/T 0.870.820.670.500.900.850.690.520.930.870.710.530.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57

DeltaT24232016242320162423201624 23 20 16 24 23 20 16 22 21 18 15

80 2000 KW 3.843.934.054.194.154.244.384.524.414.514.664.824.65 4.75 4.91 5.08 4.85 4.96 5.13 5.31 5.02 5.14 5.31 5.50

AMPS13.714.014.515.114.915.215.816.416.216.617.217.917.4 17.8 18.5 19.2 20.4 21.0 21.7 22.6 21.6 22.2 23.0 23.9

HI PR 239 257 260 266 262 282 286 292 307 330 335 342 349 376 381 389 393 423 429 438 454 488 495 506

LO PR 114 118 128 137 117 121 132 141 121 125 137 145 125 128 140 149 127 131 143 152 130 134 147 156

MBh 54.355.459.263.353.054.257.961.951.752.956.560.450.5 51.6 55.1 58.948.049.052.356.044.445.448.551.8

S/T 0.840.790.640.480.870.820.660.500.890.840.680.510.92 0.86 0.70 0.530.960.900.730.550.960.900.740.55

DeltaT24232016242320162423201624 23 20 162423201623221915

1750 KW 3.813.894.024.154.114.204.344.494.384.474.624.784.61 4.71 4.87 5.044.814.925.085.264.985.095.275.45

AMPS13.513.914.414.914.715.115.616.216.116.517.117.717.2 17.7 18.3 19.020.220.821.522.321.422.022.723.6

HI PR 236 254 258 263 259 279 283 289 304 327 331 339 346 372 377 386 389 419 424 434 450 484 490 501

LO PR 113 116 127 135 116 120 131 139 120 124 135 144 123 127 139 148 126 130 142 151 129 133 145 155

MBh 61.662.865.870.260.261.364.268.558.759.962.766.957.3 58.4 61.2 65.354.455.558.162.050.451.453.857.4

S/T 0.960.920.830.680.990.960.860.701.000.980.890.721.00 1.00 0.91 0.741.001.000.950.771.001.000.960.78

DeltaT24242219242423202424232023 24 23 202223232021212118

2250 KW 3.873.964.094.224.184.274.414.564.454.554.704.864.69 4.80 4.96 5.134.895.005.175.355.075.185.365.55

AMPS13.814.214.715.215.015.415.916.616.416.817.418.117.6 18.0 18.7 19.420.621.221.922.821.822.423.224.1

HI PR 241 259 263 269 265 285 289 295 310 333 338 345 353 380 385 393 397 427 433 443 459 493 500 511

LO PR 115 119 130 138 118 122 133 142 123 126 138 147 126 130 142 151 128 132 144 154 131 136 148 158

MBh 59.861.063.968.158.459.662.466.557.058.160.965.055.6 56.7 59.4 63.452.953.956.460.249.049.952.355.8

S/T 0.910.880.800.650.950.910.820.670.970.940.850.691.00 0.97 0.87 0.711.001.000.910.731.001.000.910.74

DeltaT25252320252524202525242026 25 24 212425232023232219

85 2000 KW 3.843.934.054.194.154.244.384.524.414.514.664.824.65 4.75 4.91 5.084.854.965.135.315.025.145.315.50

AMPS13.714.014.515.114.915.215.816.416.216.617.217.917.4 17.8 18.5 19.220.421.021.722.621.622.223.023.9

HI PR 239 257 260 266 262 282 286 292 307 330 335 342 349 376 381 389 393 423 429 438 454 488 495 506

LO PR 114 118 128 137 117 121 132 141 121 125 137 145 125 128 140 149 127 131 143 152 130 134 147 156

MBh 55.256.358.962.953.955.057.661.452.653.756.260.051.4 52.4 54.8 58.548.849.752.155.645.246.148.251.5

S/T 0.880.850.770.620.910.880.790.640.940.900.820.660.97 0.93 0.84 0.681.000.970.870.711.000.980.880.71

DeltaT26252421262524212625242126 26 24 212625242124242219

1750 KW 3.813.894.024.154.114.204.344.494.384.474.624.784.61 4.71 4.87 5.044.814.925.085.264.985.095.275.45

AMPS13.513.914.414.914.715.115.616.216.116.517.117.717.2 17.7 18.3 19.020.220.821.522.321.422.022.723.6

HI PR 236 254 258 263 259 279 283 289 304 327 331 339 346 372 377 386 389 419 424 434 450 484 490 501

LO PR 113 116 127 135 116 120 131 139 120 124 135 144 123 127 139 148 126 130 142 151 129 133 145 155

*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

PERFORMANCE DATA LOW STAGE

Outdoor

Temp. ° F. Total

Btuh Sensible

Btuh Latent

Btuh Total

Watts

75° 37,040 26,508 10,532 2,122

80° 36,599 26,526 10,073 2,195

85° 36,158 26,535 9,623 2,268

90° 35,717 26,634 9,083 2,333

95° 35,276 26,722 8,554 2,397

100° 34,394 26,548 7,846 2,452

105° 33,512 26,348 7,164 2,506

110° 32,278 25,483 6,794 2,554

115° 31,043 24,611 6,432 2,601

95° 32,688 26,455 6,233 2,315

TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB

ASX180481A* / CA*F4961*6** + TXV / MBE2000**-1**, Design Subcooling

@ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv.-

Low Stage

Outdoor

Temp. ° F. Total

Btuh Sensible

Btuh Latent

Btuh Total

Watts

75° 45,384 31,027 14,356 2,770

80° 44,843 31,047 13,796 2,867

85° 44,303 31,058 13,245 2,963

90° 43,763 31,174 12,589 3,048

95° 43,223 31,277 11,945 3,133

100° 42,142 31,073 11,069 3,205

105° 41,061 30,839 10,222 3,278

110° 39,549 29,828 9,721 3,340

115° 38,036 28,806 9,229 3,402

95° 40,052 30,965 9,087 3,025

TVAConditions @95° OD DB,75° ID DB,63° ID WB

ASX180601A* / CA*F4961*6** + TXV / MBE2000**-1**, Design Subcooling

@ AHRI 95°F Conditions, 5-7°F@ the Serv. Vlv. -

Low Stage

Outdoor

Temp. ° F. Total

Btuh Sensible

Btuh Latent

Btuh Total

Watts

75° 26,692 17,980 8,712 1,689

80° 26,374 17,991 8,383 1,743

85° 26,057 17,998 8,059 1,797

90° 25,950 18,762 7,188 1,737

95° 25,844 19,520 6,324 1,676

100° 25,198 19,392 5,806 1,714

105° 24,552 19,246 5,305 1,753

110° 23,647 18,615 5,032 1,786

115° 22,743 17,978 4,765 1,819

95° 23,948 19,324 4,624 1,619

TVAConditions @95° OD DB,75° ID DB,63° ID WB

ASX180361A* / CA*F4961*6** + TXV / MBE2000**-1**,

Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. -

Low Stage

ASX180361* - ASX180601*

PERFORMANCE DATA

PERFORMANCETEST

Alldatabaseduponlistedindoordrybulbtem-

perature. .00 inches external static pressure

oncoilofoutdoorsection. Indooraircubicfeet

perminute(CFM)aslistedinthe Performance

DataSheets:

Ifconditionsvary from this, resultswill change

asfollows:

1. As indoor dry bulb temperatures in-

crease, a slight increase will occur in

indoor air temperature drop (Delta T).

Lowandhighside pressuresandpower

willnot change.

2. As indoor CFM decreases, a slight in-

creasewilloccurinindoortemperature

drop (Delta T). A slight decrease will

occur in low and high side pressures

andpower.

A properly operating unit should be within the

subcoolingvalue shown in theAirConditioning

Specifications.

Aproperlyoperatingunit should be within plus

orminus3 degrees ofthetypical(DeltaT)value

shown.

Aproperlyoperatingunit should be within plus

or minus 7 PSIG of the HI PR shown.

Aproperlyoperatingunit should be within plus

or minus 3 PSIG of the LO PR shown.

Aproperlyoperatingunit should be within plus

or minus 3 Amps of the typical value shown.

NOTE: Pressures are measured at the liquid

andsuction service valve ports.

HIGH STAGE

Outdoor

Temp. ° F. Total

Bt uh Sensible

Btuh Latent

Btuh Total

Watts

75° 39,342 27,300 12,043 2,372

80° 38,874 27,318 11,556 2,453

85° 38,406 27,327 11,078 2,534

90° 37,937 27,429 10,508 2,605

95° 37,469 27,520 9,949 2,677

100° 36,532 27,340 9,192 2,737

105° 35,596 27,135 8,461 2,798

110° 34,284 26,244 8,040 2,850

115° 32,973 25,346 7,627 2,903

95° 34,720 27,245 7,476 2,586

TVAConditions @95° ODDB, 75°ID DB, 63°ID WB

ASX180361A* / CA*F4961*6** + TXV / MBE2000**-1**,

Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. -

High Stage

Outdoor

Temp. ° F. Total

Bt uh Sensible

Btuh Latent

Btuh Total

Watts

75° 51,668 37,197 14,471 3,244

80° 51,053 37,221 13,831 3,349

85° 50,438 37,234 13,203 3,454

90° 49,823 37,373 12,450 3,547

95° 49,208 37,497 11,711 3,640

100° 47,977 37,252 10,725 3,718

105° 46,747 36,972 9,775 3,797

110° 45,025 35,759 9,266 3,865

115° 43,303 34,535 8,768 3,933

95° 45,598 37,122 8,476 2,586

TVAConditions @95° ODDB, 75°ID DB, 63°ID WB

ASX180481A* / CA*F4961*6** + TXV / MBE2000**-1**,

Design Subcooling @ AHRI 95°F Conditions, 5- 7°F @ the Serv. Vlv. -

High Stage

Outdoor

Temp. ° F. Total

Bt uh Sensible

Btuh Latent

Btuh Total

Watts

75° 62,686 43,209 19,476 4,377

80° 61,939 43,238 18,702 4,520

85° 61,193 43,253 17,940 4,662

90° 60,447 43,414 17,033 4,788

95° 59,701 43,558 16,143 4,915

100° 58,208 43,274 14,934 5,022

105° 56,715 42,948 13,767 5,129

110° 54,626 41,539 13,087 5,221

115° 52,536 40,117 12,420 5,314

95° 55,321 43,122 12,199 4,755

TVAConditions @95° ODDB, 75°ID DB, 63°ID WB

ASX180601A* / CA*F4961*6** + TXV / MBE2000**-1**,

Design Subcooling @ AHRI 95°F Conditions, 5-7°F @ the Serv. Vlv. -

High Stage

ASX180361* - ASX180601*

WIRING DIAGRAMS

HIGH VOLTAGE!

DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS

UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO

DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.

ASX180[36-60]1A*

USE N.E.C. CLASS 2 WIRE

NOTES:

1) TO INDOOR UNIT LOW VOLTAGE

TERMINAL BLOCK & INDOOR

THERMOSTAT.

2) START ASSIST FACTORY

EQUIPPED WHEN REQUIRED.

COMP

AIN

CADM

L1 L2

(IF USED)

CADM

SOL

INDOOR POWER

SUPPLY

LPS HPS

Y1Y2 CR

0140R00106

RD Y1

LVJB

NOTE 1

COLOR CODE

BK --------------- BLACK

BL --------------- BLUE

BL/PK ---------- BLUE/PINK STRIPE

BR --------------- BROWN

GR --------------- GREEN

PU --------------- PURPLE

RD --------------- RED

WH -------------- WHITE

YL --------------- YELLOW

YL/PK ---------- YELLOW/PINK STRIPE

GR/YL ---------- GREEN/YELLOW STRIPE

COMPONENT CODE

C --------------- CONTACTOR

CADM -------- COMFORT ALERT MODULE

CM ------------ OUTDOOR FAN MOTOR

COMP -------- COMPRESSOR

CS ------------- COMPRESSOR SOLENOID

HPS ----------- HIGH PRESSURE SWITCH

IO -------------- INTERNAL OVERLOAD

LPS ------------ LOW PRESSURE SWITCH

LVJB ---------- LOW VOLTAGE JUNCTION BOX

RC ------------ COMPRESSOR RUN CAPACITOR

SA ------------- START ASSIST

SC ------------- START CAPACITOR FOR COMPRESSOR (OPTIONAL)

SR ------------- START RELAY FOR COMPRESSOR (OPTIONAL)

CONTROLS SHOWN WITH THERMOSTAT IN 'OFF' POSITION.

OUTDOOR POWER SUPPLY

SEE RATING PLATE

WIRING CODE

FACTORY WIRING

HIGH VOLTAGE

LOW VOLTAGE

OPTIONAL HIGH VOLTAGE

FIELD WIRING

HIGH VOLTAGE

LOW VOLTAGE

(IF USED)

NOTE 2

LVJB

CONTROL BOX

RD BL

BK RD

YL/PK

YLYL

BR RD YL

(HIGH)

GR/YL

(LOW)

RD BK AUX

MAIN

COMP

BL/PK

BL/PK HPS

LPS

SOL

YL PURD BL

CADM

Y2 R C Y1

YLRD BK

R C S

EQUIPMENT GROUND

USE COPPER

CONDUCTORS ONLY

ALTERNATE DOUBLE

POLE CONTACTOR ONLY

YL/PK YL/PK

YL/PK BL/PK BL/PK PU

GND

(COM)

ALTERNATE DOUBLE

POLE CONTACTOR

T1 T2

CHERM

This manual suits for next models

Table of contents

Popular Heat Pump manuals by other brands

Robur

Robur K18 Simplygas Installation, use and maintenance manual

Amana

Amana RHF36A2A Specification sheet

Gorenje

Gorenje TC200SGNE Instructions for use

EDG

EDG 101204 User and installation manual

Madimack

Madimack Elite Series user manual

Carrier

Carrier COMFORT 25HCS installation instructions

CIAT

CIAT COADIS LINE 600 instruction manual

ClimateMaster

ClimateMaster TRM Series Installation, operation & maintenance instructions

M&C

M&C CSS Series instruction manual

Bryant

Bryant 574A LEGACY 13 SEER Owner's information manual

AERMEC

AERMEC HRS-HRS W Installation, use and maintenance manual

Raypak

Raypak RHP 5100ti Technical data

Amana

Amana PHB**C User's information manual

Valeo

Valeo REVO-E Workshop manual

Daikin

Daikin RZQ71KAVLT Service manual

RDZ

RDZ PDC-GTM-RES Installation and owner's manual

swimmax

swimmax 07 User and service manual

Trane

Trane BAYVALV001 installation guide

Amada ASX 18 Series User manual

Popular Heat Pump manuals by other brands
