Amalfi VEIGA User manual

2
SAFETY INSTRUCTIONS:
The following safety instructions should
always be followed, to reduce the risk of
damage or injury
Retain these instructions for future
reference. Read all the instructions
carefully before using the product
This product must only be used as intended in
accordance with the enclosed operating instructions.
1. The appliance is not to be used by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
the use of the appliance by a person responsible
for their safety. Children being supervised not to
play with the appliance.
2. The appliance must only be supplied at SELV
(safety extra low voltage) and must be used with
the adaptor power supply provided.
3. Do not carry the diffuser by the mains cable or
pull the cable to remove the plug from the socket.
4. If the diffuser stops unexpectedly or appears to
malfunction, switch off the power supply
5. Do not operate the diffuser with damaged cord or
plug or after the diffuser malfunctions or has been
damaged in any manner. If the diffuser is damaged
or broken, do not repair yourself, if the power cord
or the plug is broken or damaged, do not repair or
change yourself, please send the diffuser to qualified
service centre for repair or service.
6. Switch off the power supply when not in use.
Unplug the appliance during filling or cleaning.
7. Avoid positioning the diffuser where the power
cable might be damaged
8. Keep the diffuser and cable away from sources of
heat or anything that may cause damage
9. Ensure the diffuser is switched OFF before
connecting the mains power supply.
10. Be aware that some surfaces may become hot.
Do not touch hot surfaces
11. This product has not been designed to be used
by children.
12. Children should always be closely supervised,
at all times, when they are near any electrical
appliance
13. To protect against electric shock, never allow the
diffuser, the mains cable or plug to come into
contact with water or any other liquid
14. If the diffuser becomes wet outside of the reservoir
DO NOT plug it in until its completely dry
15. Always ensure that hands are dry before
operating or adjusting any switch on the
diffuser or touching the plug and mains supply
connections.
16. To disconnect, first ensure that all controls are in
the OFF position
17. Keep all ventilation slots, filters, etc. uncovered
and clear of debris. Never drop or insert objects
into the openings.
18. Do not use outdoors. This appliance has been
designed for domestic indoor use only.
1. Mist outlet
2. Glass cover
3. Inner cover
4. Base
5. Light button
6. Timer button
7. On/Off button
8. Inlet for Jack
9. DC Jack
10. Adaptor
11. Ceramic disc
12. Air outlet
13. Max water level line
14. Water Tank & Direction
15. Water spout
01
02
03
04
09
10
05060708
11
12
13
14
15
PRODUCT DESCRIPTION

3
INSTRUCTIONS
A detailed diagram can be found below.
1.Place the diffuser on a flat, stable surface, away
from the edge.
2.Carefully remove the glass outer cover.
3.Remove the inner cover
4.Fill the reservoir with distilled water (bottled water
or tap water); do not exceed the maximum water
level – 150 ml (Indicated by the word MAX in
red letters).
5.Then add a few drops of essential oil (5-7 drops) to
the water tank.
6.Replace the inner cover & the glass outer cover on
the diffuser.
7.Plug the connecting cable into the DC-jack located
on the rear of the diffuser.
8.Plug the adaptor into the power supply & push on
the On/Off Button – Turn the rotating button if you
wish to use select the timer function – if not leave
timer button on “0”.
MAINTENANCE
It is recommended to change the water in the
reservoir frequently and to clean the diffuser regularly,
especially if you wish to change the aroma.
1.Turn off and unplug the device.
2.Carefully Remove the glass cover & inner cover and
empty the water from the reservoir. Empty the water
using the water spout, on the opposite side of the
air outlet. Do not empty the water in the air outlet,
this would damage the diffuser.
3.Clean the interior of the diffuser with a soft tissue
and a little water. If necessary, use some heavily
diluted vinegar. Do not use corrosive detergents.
Gently wipe the ceramic disc with a cotton bud,
being careful not to scratch it.
IMPORTANT: DO NOT press heavily or scratch
the ultrasonic mechanism in the water tank during
cleaning.
FUNCTIONS
Left button – On/Off Button
• Press 1: Continuous diffusion
• Press 2: 30sec on/off intermittent diffusion
• Press 3: Off
Middle Turning knob – Timer Button
• Turn on 1st position: Timer 1 hour, than diffusion &
light off
• Turn on 2nd position: Timer 2 hours, than diffusion
& light off
• Turn on 3rd position: Timer 3 hours, than diffusion
& light off
• At <0> position, continuous diffusion and light on,
no timer function
Right button – Light Button
• Press 1: 100 % warm white
• Press 2: 50 % warm white light
• Press 3: Breathing light - 1 minute cycle (light
begins to cycle between bright and dim according
to designed breathing light cycle)
• Press 4: Lights Off
When the water level in the reservoir is insufficient or
empty, the diffuser will stop automatically. When this
happens, fill the reservoir with water following the
instructions to return to normal function.
Precaution
1.Do not use as medical respirator.
2.Do not use the product when there is an abnormal
noise, or the diffuser is overheating abnormally
3.Do not cover or block the mist outlet or air inlet
4.Use only 100% pure essential oils, DO NOT use
inferior essential oils
5.Do not take off the cover while the diffuser is in
operation
6.Do not place on an electronic device
7.Do not use hot water or mineral water, always use
tap water or distilled water
8.Keep out of reach of children or pets
1
3
2

4
Power input /output AC-100-240V 50/60HZ /
DC24V 0.5A
Electric consumption 12 W
Mist Mode Continuous / Intermittent 30 sec on/
30 sec off
Water capacity 150 ml
Fail to turn on
the unit
Is there enough water in the water
tank?
- Add water in the water tank.
Does water amount exceed the
Max line?
- Reduce the water amount and
make sure it is below the MAX line
The diffuser was just unpacked and
is very cold?
- Please wait unit reaches room
temperature
Shut off suddenly
during working
Does water amount exceed the
Max line?
-Reduce the water amount and make
sure it is below the MAX line
Please check if the adaptor is well
connected?
- Unplug the DC socket & plug it
back in. Turn ON he unit.
No mist or
abnormal mist
Not enough water or too much
water?
-Add water to the water tank but
don’t fill over the 150 ml MAX line.
Dirt on the Ultrasonic disc?
-Please refer to the maintenance
instructions of unit & clean the unit.
Too much dirt on the air intake/
mist outlet?
-Please use a small brush to clean
the air intake part / mist outlet.
Different humidity environment
and temperature will affect the mist
density.
Water leakage
from the product
Low temperature or high humidity?
-Under these conditions the mist
may condense quickly into water
droplets.
Please wipe droplets out.
PRODUCT SPECIFICATIONSTROUBLESHOOTING
Please refer to below info when the unit
falls to work properly
OUR 12 MONTH GUARANTEE
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired if the goods fail to be of
acceptable quality and the failure does not amount to
a major failure. We stand by this product. Therefore,
we offer a 12 month guarantee on the motor. The
benefits of this guarantee are in addition to any rights
and remedies imposed by Australian Consumer Law.
Our guarantee excludes normal wear and tear and
instances where care and use instructions have not
been followed.
What IsAlbi will do: During this guarantee period
IsAlbiwill repair, replace or refund any defective
product. If identical product is not available for
replacement, a similar product may be offered. IsAlbi
asks you to cover the cost of postage/transit if the
product needs to be sent back to us for inspection.
If IsAlbi deems the product is defective, we will
reimburse your postage/transit expenses. IsAlbi
will be responsible for the postage/transit of the
repaired/replacement product back to you. What
to do: If a fault/defect is identified cease using the
product immediately.
To make a claim on this guarantee, take the product,
proof of purchase and full details of the alleged defect
to the retailer from whom the product was purchased.
If you cannot access the retailer or areunsatisfied with
the solution offered by the retailer contact Albi via the
details below.
IsAlbi
87 Chifley Drive, Preston, Victoria 3072
P: [phone]
E: [email protected]
isalbi.com.au
