Amana ZRRSC8050 User manual

Please Read Manual Before Operating
Range
Installer
Leavethismanualforconsumer’sandlocalelectrical
inspector’s use.
Customer
Keep these instructions for future reference. If appliance
changesownership,besurethismanualaccompanies
range.
English........................................................................2
Français......................................................................30

Convection
Self-Cleaning
Slide-in
Electric Range
Owner's Manual
ZRRSC8050*
ZRTSC8650*
* Additional alphanumeric characters
representing other models in series may
follow each model number.

2
Contents
CookingGuide
OvenRackPlacement ............................................18
PanPlacement .......................................................18
BakingGuide ..........................................................19
ConvectionBakingGuide ........................................20
RoastingGuide .......................................................21
ConvectionRoastingGuide .....................................22
BroilingGuide .........................................................23
DehydrationChart ...................................................24
CareandCleaning
RemovingOvenDoor ...............................................25
ReplacingOvenLight ..............................................25
RemovingStorageDrawer .......................................25
OpeningRangeTop(ZRRSC8050Only) ..................26
RemovingCoil SurfaceElements ............................26
Cleaning..................................................................27
CleaningSmooth TopRange Top.............................28
BeforeCallingforService
AdjustingThermostat ..............................................29
CommonQuestions ................................................29
ServiceTonesand Codes ........................................29
Model Identification
Completeenclosedregistration card and promptly return.
If registration card is missing, call Consumer Affairs
Departmentat 1-800-843-0304 insideU.S.A.
319-622-5511outsideU.S.A.
Whencontacting Amana, provide productinformation.
Findproduct information on range nameplate locatedon
ovenframebehindstorage drawer.Recordfollowing
information:
ModelNumber: ____________________________
ManufacturingNumber: ______________________
SerialorS/NNumber: _______________________
Dateof purchase:___________________________
Dealer’sname and address:
________________________________________
________________________________________
________________________________________
Keepacopyof sales receipt for future reference or in
case warranty service is required. Any questions or to
locatean authorized servicer,call1-800-NAT-LSVC
(1-800-628-5782)inside U.S.A. 319-622-5511 outside
U.S.A.Warranty service must be performed by an
authorizedservicer. Amana also recommends contacting
anauthorized servicer if serviceisrequiredafter warranty
expires.
ModelIdentification .................................................2
ImportantSafety Information
ALLAPPLIANCES..................................................3
SURFACECOOKINGUNITS ..................................3
OVENS...................................................................4
SELF-CLEANINGOVENS ......................................4
GLASS/CERAMICCOOKING SURFACES .............4
VENTILATIONHOODS............................................4
InCaseof Fire ........................................................4
Precautions ............................................................4
Installation
Packing Material .....................................................5
RangeLocation .......................................................5
StandardCabinet andCounterTop
Heightand Depth ....................................................5
CounterTopFront Edge ..........................................5
IrregularCabinet andCounterTopHeights...............5
CounterTopOpening...............................................6
MinimumClearancesto Combustible Surfaces .......7
LineVoltageRequirements .....................................7
PowerSupply Location ...........................................8
Anti-tipBracket Installation .....................................8
LevelRange ............................................................9
RemovalandReplacementof Range .......................9
Operation
SurfaceElements ...................................................9
DualRadiant Element .............................................10
ElectronicOven Control
ElectronicOven Control Pads .................................11
SpecialOven Control Functions ..............................11
QuickReference Instructions ..................................12
Baking ....................................................................12
TimedBaking..........................................................13
DelayedBaking.......................................................13
Broiling ...................................................................14
Convection ..............................................................14
TimedConvection....................................................15
DelayedConvection ................................................15
Self-Cleaning...........................................................16
DelayedSelf-Cleaning .............................................16
Child Lock Out ........................................................17
Utensils
CookingUtensils.....................................................17

3
Important Safety Information
ALL APPLIANCES
1. ProperInstallation—Besureyour appliance is
properlyinstalled and grounded by aqualified
technician.
2. NeverUseYourAppliance for Warming or Heating the
Room.
3. Do NotLeave Children Alone—Children shouldnotbe
aloneorunattended in the area where the appliance
is in use. They should never be allowed to sit or stand
on any part of the appliance.
4. WearAppropriate Apparel—Loose fittingorhanging
garmentsshould never be wornwhileusingappliance.
5. UserServicing—Do not repair or replace any partof
theapplianceunlessspecificallyrecommendedin the
manual.Allotherservicingshould be referred to a
qualifiedtechnician.
6. Storageinor on Appliance—Flammable materials
shouldnot be stored in an oven ornear surface units.
7. DoNot Use WateronGreaseFires—Smotherfireor
flame,orusedry chemical or foam-type extinguisher.
8. UseOnlyDryPotholders—Moistordamppotholders
on hot surfaces may result in burns from steam. Do
not let potholder touch elements. Do not use a towel
or other bulky cloth.
SURFACE COOKING UNITS
1. UseProperPan Size—This appliance is equipped
with one or more surface units of different size. Select
utensilshavingflat bottoms large enough to cover the
surfaceunitheating element. The use of undersized
utensils will expose a portion of the heating element
to direct contact and may result in ignition of clothing.
Properrelationshipofutensiltoburnerwillalso
improveefficiency.
2. NeverLeave SurfaceUnitsUnattended at HighHeat
Settings—Boilovercausessmoking and greasy
spilloversthat may ignite.
3. Make Sure Reflector Pans or Drip Bowls Are in
Place—Absenceofthesepansorbowlsduring
cooking may subject wiring or components
underneathto damage.
4. ProtectiveLiners—Donotusealuminumfoiltoline
dripbowls or oven bottom. Improper installationof
these liners may result in a risk of electrical shock or
fire.
5. Glazed Cooking Utensils—Do not use glass,
ceramic,earthware,orotherglazedutensils.They
candamagesmoothtopandcan break due to sudden
changein temperature.
WARNING
To reduce the risk of the appliance tipping, it
must be secured by a properly installed anti-tip
bracket(s). To make sure bracket has been
installed properly, remove the storage drawer
and look under the range with a flashlight.
Bracket(s) must be engaged in the rear corner
of the range.
• ALL RANGES CAN TIP
• INJURY TO PERSONS
COULD RESULT
• INSTALL ANTI-TIP
BRACKET(S) PACKED
WITH RANGE
• SEE INSTALLATION
INSTRUCTIONS
WARNING
To avoid personal injury, do not sit, stand or lean on
ovendoororovendrawer.
WARNING
To avoid risk of electrical shock, personal injury, or
death,makesureyourrangehasbeen properly
groundedandalwaysdisconnect it from main power
supplybefore any servicing.

4
6. UtensilHandles Should beTurnedInwardand Not
ExtendOver Adjacent Surface Units—Toreducethe
riskofburns,ignitionof flammable materials, and
spillage due to unintentional contact with the utensil,
the handle of a utensil should be positioned so that it
isturnedinward,anddoesnot extend over adjacent
surfaceunits.
7. DoNot Soak RemovableHeatingElements—Heating
elementsshouldnever be immersed in water.
OVENS
1. UseCareWhenOpeningDoor—Lethotairorsteam
escapebefore removingorreplacing food.
2. DoNot HeatUnopenedFood Containers—Buildup of
pressure may cause container to burst and result in
injury.
3. KeepOvenVentDuctsUnobstructed.
4. PlacementofOvenRacks—Always place oven racks
in desired location while oven is cool. If rack is
removedwhileoven is hot, do not let potholder
contacthotheatingelementinoven.
SELF-CLEANING OVENS
1. DoNotCleanDoorGasket—Thedoorgasketis
essential for a good seal. Care should be taken not to
rub,damage,ormovethegasket.
2. DoNot UseOvenCleaners—No commercialoven
cleaner orovenlinerprotectivecoatingofanykind
should be used in or around any part of the liner.
3. Clean Only Parts Listed in Manual.
4. BeforeSelf-Cleaning theOven—Remove broilerpan,
ovenracks,andotherutensils.
5. Removeallitemsfromrangetopandbackguard.
GLASS/CERAMIC COOKING SURFACES
1. DoNotCookonBrokenCooktop-Ifcooktopshould
break,cleaningsolutionsandspilloversmaypenetratethe
brokencooktopandcreateariskofelectricalshock.
Contactaqualifiedtechnicianimmediately.
2. CleanCooktopWithCaution-Ifawetspongeorclothis
usedtowipespillsonahotcookingarea,becarefulto
avoidasteamburn.Somecleanerscanproducenoxious
fumesifappliedtoahotsurface.
VENTILATION HOODS
1. CleanVentilationHoodsFrequently—Greaseshouldnot
beallowedtoaccumulateonhoodorfilter.
2. Whenflaming foods under hood, turnfanoff.The fan,
ifoperating,mayspreadtheflame.
In Case of Fire
Fires can occur as a result of over cooking or excessive
grease. Though a fire is unlikely, if one occurs, proceed
asfollows:
Surface Element Fire
1. Smotherthefirewithanonflammablelidorbaking
soda, or use a Class ABC or BC extinguisher. Not
water. Not salt. Not flour.
2. As soon as it is safe to do so, turn the surface
controls to “OFF”.
Oven Fires
1. Ifyouseesmokefromyour oven, do not open oven
door.
2. Turnoven control to“OFF”.
3. As an added precaution, turn off power at main circuit
breakerorfusebox.
4. Turnon vent toremovesmoke.
5. Allow food or grease to burn itself out in oven. Do not
openovendoor.
6. Ifsmokeand fire persist, call fire department.
7. If there is any damage to components, call an
authorizedservicer beforeusingrange.
Precautions
• Do not cook food directly on range top surface,
alwaysusecookware.
• Donotmixhouseholdcleaningproducts.Chemical
mixturesmayinteractwithobjectionableoreven
hazardousresults.
• Do not put plastic items on warm cooking areas.
They may stick and melt.
• Do not slide rough objects across range top
surface.Scratchingormetalmarkingcanresult.
• Donotusecookwarewithroughbottoms.Theymay
scratch smoothtop surface. Glass and ceramic
cookwareshouldnotbeused.
• Donotusedampspongeordishclothtocleanrange
top.Afilmofsoil-ladendetergentwatermaycollecton
rangetop.Ifthisshouldhappen,AmanaCleaning
ConditioningCreamremovesthistypeofstain.
• Donotleavefatheatingunlessyouremainnearby.Fat
canigniteifoverheatedbyspillingontohotsurfaces.
• Do not allow pots to boil dry as this can cause
damagetocookingsurfaceandpan.
• Do not use range top surface as a cutting board.
• Do not use range for storage or as a display
counter.

5
Installation
Packing Material
Removeprotective packingmaterialsfromrange. Tape
residue can be cleaned with a soft cloth and alcohol.
Range Location
Underwriter’sLaboratoriesInc. specifies that range can be
installed flush against right and left base cabinets, and
rearverticalwall.Rangecanalsobeinstalledflush
againstleftorrightvertical wall extending above 36 inch
standardcountertop height.
Standard Cabinet and Counter Top Height
and Depth
A
C
B
D
E
A—301/8to 30¼ inches (76.5cm to 76.8cm)
B—36inchesstandard (91.4cm)
C—35inches standard (88.9cm)
D—23inches standard (58.4cm)
E—½ inch minimum (1.2cm)
WARNING
To avoid riskofburnsorfire by reaching over heated
surfaceunits,cabinetstoragespacelocated above
rangeshouldbeavoided.Ifcabinetstorageistobe
provided,therisk can be reduced by installing a range
hood that projects horizontally a minimum of 5 inches
beyond the bottom of the cabinets.
Counter Top Front Edge
Counter top front edge may require cutting to fit 31 inch
(78.74cm)widerangetop.Allow for ½ inch (1.2cm)
overlapon each side.
Irregular Cabinet and Counter Top Heights
Counter tops such as ceramic tile tops can cause cabinet
andcountertoptobehigherthan36inches(91.4cm).Follow
instructionsbelowwhencountertopishigherthan36inches
(91.4cm).
1. Raiselevelinglegs to maximum level.
2. Measurefromfloortorangetop. If measurement is
less than height of counter top floor must be
shimmed.
3. Shim floor using a piece of plywood same size as
rangeopening. Secureplywood to floor. Plywood
must be as secure as original flooring.
4. Install anti-tip bracket and slide range into place.
• See “Anti-tip Bracket Installation” section.

6
Counter Top Opening
Island Installation
A
B
A—25inches(63.5cm)
B—301/8to 30¼ inches (76.5cm to 76.8cm)
Counter Top with Backsplash
A
B
B
A—301/8to 30¼ inches (76.5cm to 76.8cm)
B—1/2inch(1.27cm)minimumstartingonhorizontalplane
Counter Top without Backsplash
A
A—301/8to 30¼ inches (76.5cm to 76.8cm)
Backguardkit AXF100W—(white), E—(Ebony), or
L—Almondisavailable. Contact an authorized Amana
dealertopurchasebackguardkit.

7
Minimum Clearances to Combustible
Surfaces
• Minimum clearance to rear wall is 0 inches.
• Minimum clearance to a vertical right or left side
wall is 0 inches.
• Minimumclearancetocounter top/cabinet on each
side is 0 inches.
• Minimumof30inches(76.2cm)betweentopof
cookingsurfaceand bottom of an unprotected wood
or metal cabinet.
• 24inchesbetweencooking surface and protected
woodor metal cabinet above range.Cabinetbottom
must be protected by at least ¼ inch thick
millboard with not less than No. 28 MSG sheet
steel, .015 inch thick stainless steel, .024 inch
thick copper.
A
B
C
A—30inches(76.2cm)minimum
B—30inches(76.2cm) unprotected/24 inches (60.96cm)
protectedminimum
C—13inches(33cm)maximum
Line Voltage Requirements
Line voltage must not exceed rated voltage. Line voltage
less than rated voltage will result in slow heating. Wiring
system must conform to C.S.A standards and Canadian
Electrical Code-latest edition. Installation must conform to
alllocal, municipal andstatebuilding codes, andlocalutility
regulations.Rangemustbeconnectedonlytoasupplycircuit
asspecifiedonrangenameplate.
This range requires 4 wires, 120/240 Volts, 60 Hertz A.C.
Seerating plate attached to range for kilowatt rating.
House wiring and fusing must comply with local wiring
codes.Ifnocodesapply, wire according to Canadian
ElectricalCode-latestedition.

8
Anti-tip Bracket Installation
To reduce risk ofrangetipping,secure range with a
properlyinstalledanti-tipbracket.
1. Removestorage drawerfromrange.
• See“RemovingStorageDrawer”section.
2. Unscrewlevelinglegssowhenrangeismovedinto
positionrangetopclearscountertop.
• Left or right rear leveling leg must extend at least ¼
inch(6mm)toengagebracket.
• Anti-tipbracketcanbeinstalledoneitherrightorleft
rearlevelingleg.
or
3. Moverange towhereitwillbe installed.
4. Position anti-tip bracket.
• Withrangeinposition,reachthroughstorage
draweropeningandslide anti-tip bracket on either
leftorrightrearlevelingleg.SlidelegintoV-shaped
notch in bracket.
5. Mark location of side and front of anti-tip bracket on
floor.
6. Removeanti-tip bracket andrangefrom opening.
7. Position anti-tip bracket according to lines marked on
floor.
8. Mark 2 hole locations in anti-tip bracket.
9. Drill 2 holes.
• If drilling into wood, use a 3/32 inch drill bit.
• If drilling into concrete, use a 3/16 inch masonry drill
bit and insert plastic anchors.
10. Secure bracket to floor using screws supplied.
11. Slide range into position.
• See“Level Range” section ofmanual.
12. Confirm anti-tipbracketisengaged with range leveling
legand replace storagedrawer.
Power Supply Location
Shadedareas show range clearance for electrical
connection.Powercordissuppliedwith range.
A
BC
D
A—3inches (7.6cm)
B—7inches(17.8cm)
C—6inches(15.2cm)
D—301/8to 30¼ inches (76.5cm to 76.8cm)

9
Operation
Surface Elements
• Donotuseapanthatoverhangsburnerbymore
than 1 inch.
1. Push in and turn surface element control to desired
setting.
• Rangeswithcoil elements have two indicator lights,
oneforelementsonright side and one for elements
onleftsideofrange.When either front or rear
elementison,correspondingindicator light glows.
• Smoothtoprangeshave four hot indicator lights,
onelocatedaboveeachknob.Hotindicatorlights
willglowredwhenthecorresponding element is
turnedon.Lightwill remain on until surface element
has cooled to a safe temperature. Element cycles
on and off to maintain desired heat setting.
2. When finished cooking, turn control to “OFF” position.
OFF
LO
HI
MED
Settings
LO
Usetopreparefoodatless than boiling temperatures or
to simmer.
MED
Usetomaintainboilingoflargeramountsoffood,low
temperaturefryingandtomaintaincorrectpressureina
pressurecooker.
HI
Useto bring food to boiling temperatures. Whenfood is
boilingtemperaturesettingshouldbereducedtoMED
throughHI.
Level Range
Carefullylevel range usinglegsprovided.Range must be
leveltocookandbakeuniformly.
• Placea level on top oven rackor on top of range
whenleveling.
• Levelinglegsmustbeextendedaminimumof
¼ inch (6mm) to engage anti-tip bracket.
1. Extendlevelinglegssowhenrangeismovedintoposition
rangetopclearscountertop.
2. Slide range to where it will be installed.
• Positionrange so that rear leveling legs do not
engageanti-tipbracket.
3. Turnleveling legstolevel range.
• Turnlegsclockwisetodecreaserangeheightor
counterclockwiseto increase range height.
• Adjustrearlevelinglegthatengagesanti-tipbracket
first.Leveling leg can not be adjusted while in
bracket.After adjusting leg that engages anti-tip
bracket,sliderange forward until leg engages
bracket, and adjust other legs.
4. Replacestorage drawer.
Removal and Replacement of Range
1. Disconnectpowerto range.
2. Sliderange forward.
3. Unplugrange cord and place range aside.
3. Removeanti-tip bracket.
4. Install anti-tip bracket into new location using
instructionsprovidedwithbracketorsee“Anti-tip
Bracket Installation” section in this manual.
5. To reinstall range, follow instructions in “Installation”
section of this manual.
CAUTION
To avoiddamagingovendoor,do not liftormoverange
byovendoorhandle.Glasscanbreak.
WARNING
Toavoid riskofseriouspersonalinjury,propertydamage,
orfire,donotleavesurfaceelementsunattendedwhilein
operation.Greaseandspilloverscanignitecausingafire.
SurfaceElement Control Knob

10
Dual Radiant Element
DualElementcan be operated using inner 6 inch element
only or both inner and outer 9 inch element.
To use inner element
1. Depress ElementSize switchdownward.Dual
Element switch is located in upper right corner of
controlpanel.
ELEMENT SIZE
LARGE
SMALL
2. Push in and turn surface element control to desired
setting.
• Element will cycle on and off to maintain desired
heat setting.
OFF
LO
HI
MED
3. When finished cooking turn control to OFF position.
To use both inner and outer element
1. Depress ElementSize switch upward.
ELEMENT SIZE
LARGE
SMALL
2. Followsteps 2-3 above.
Settings
LO
Usetopreparefoodatlessthanboilingtemperaturesorto
simmer.
MED
Usetomaintainboilingoflargeramountsoffood,low
temperaturefryingandtomaintaincorrectpressureina
pressurecooker.
HI
Usetobringfoodtoboilingtemperatures.Whenfoodis
boilingtemperaturesettingshouldbereducedtoMED
throughHI.

11
Electronic Oven Control
TIMING TIME / TEMP SET
TIMER
ON/OFF CLOCK
STOP
TIME COOK TIME
OVEN
CANCEL
LIGHTCLEAN BROIL BAKE CONV.
DELAY BAKE CLN STOP TIMER
BROIL CONV
DELAY BAKE
CLEAN LOCKED
Electronic Oven Control Pads
TIMERON/OFF
• Use to time any kitchen function or cancel timer.
• Does not control bake, broil, or clean function.
CLOCK
• Use to set time of day.
STOP TIME
• Use to set delayed bake or delayed self-clean.
COOKTIME
• Use to set delayed or timed bake.
CLEAN
• Use to select self-clean cycle.
BROIL
• Use to select broil.
BAKE
• Use to select bake.
CONV .
• Use to select convection.
or —Used to set temperature or time.
OVENCANCEL
• Cancels any cooking or cleaning function except
timer.
LIGHT
• Usedtoturnonand off light inside oven.
Special Oven Control Functions
Timer Signal—When time elapses timer beeps 3 times
thenonceevery10seconds.
PreheatSignal—Aftersettingoventobake and selecting
atemperature,oven preheats. When oven reaches set
temperature,ovensignalsounds3times.
End of Cycle Signal—When a timed cooking cycle is
complete, three long signals sound. After first 3 signals,
1signalsoundsapproximatelyevery10seconds for 5
minutes or until OVEN CANCEL pad is pressed.
Child Lock Out — This is a safety feature that can be
usedto prevent children from accidently programmingthe
oven.Itdisablesthe electronic oven control. Touchand
hold Bake and Cook Time for 10 seconds. “OFF” will
displaywhere the temperature normally appears.
To reactivate thecontrol, touch and hold Bake and Cook
Time for 10 seconds. Child lockout features must be reset
aftera powerfailure.
12Hour Automatic Cancel—This is a safety feature that
preventsovenfrom continuing to operate if it has been left
onforover12 hours. If a cooking function continues longer
than12hourswithoutanyoptionsonovencontrolbeing
touched, this feature turns oven off. Any time an option is
touched, 12 hour automatic cancel is reset.
Increasing or Pad Speed—When setting time and
temperature, hold pad to accelerate the rate at which the
numbersincrease or decrease.
Self-diagnosticSystem—Electronicrangecontrolhasa
self-diagnostic system. Self-diagnostic system sounds a
series of short, rapid beeps and shows a “F-code” in
displaywhenthereisaproblem.See“ServiceTones and
Codes”section.

12
Quick Reference Instructions
Read “Important Safety Information” before using “Quick
ReferenceInstructions”.If thereareunansweredquestions,
refer to detailed sections of this manual.
Flashing Display
Whenpower is connected to range, numbers flashin
electronic range control. Press OVEN CANCEL pad to
stopflashing.
Setting Clock
12 hour clock does not display am, pm, or military time.
1. PressCLOCKpad.
• “TIME” displays.
2. Press or pad until correct time of day is
displayed.
3. Press OVEN CANCEL pad to set time.
• If OVEN CANCEL pad is not pressed,
approximately5secondsafterlast entry, “TIME”
disappears and time is set.
Setting Minute Timer
Timercan be used while another feature is in use.
1. PressTIMERON/OFF pad.
• “TIMER”displays.
2. Press or pad until desired amount of time is
displayed.
• Timer can be set from 5 seconds to 9 hours and 55
minutes.
• Timerbeginscountingdownautomatically.
3. When time elapses timer beeps 3 times then
approximatelyonceevery 10 seconds.
• Press TIMER ON/OFF to cancel beep but remain in
timermode.
Canceling Minute Timer
PressTIMERON/OFF pad.
• When canceling minute timer do not press OVEN
CANCELpad.PressingOVENCANCELpadcancels
cookingfunction.
Baking or Broiling
1. Press BAKE or BROIL pad.
2. Press or pad until desired temperature or
broiler setting is displayed.
3. Ovenbeginsbakingorbroilingautomatically.
Canceling Bake or Broil
PressOVENCANCELpad.
Self-Cleaning
1. Removeoven racks and allutensilsfromoven and
rangetop.Cleanexcessspills from oven.
2. PressCLEANpad.
3. Press or pad to adjust clean time. Clean can
be set from 2 to 4 hours.
4. Ovenbegins cleaning automatically.
Canceling Self-Cleaning Cycle
1. PressOVEN CANCELpad.
2. Whenovenhascooledto a safe temperature, door
will unlock.
• When“LOCKED” no longer displays,oven
temperatureissafe.Donotforcedoorwhile
“LOCKED”displays.
Baking
Bottomelementoperates during bake. Upper element
operates10% of the time to provideadditionalbrowning
and to lower preheat times. Bake can be used to cook
foodswhichare normally baked. Open oven door to
confirm nothing is stored in oven cavity and set racks to
properheightbefore baking. For most recipes, preheat
ovenbefore placing food inside oven.Pansmustbe
staggeredforevenbrowning.
Top elementand
bottomelement
operating
1. Press BAKE pad.
• “BAKE”and“---°”display.
2. Press or pad until desired temperature is
displayed.
• Time of day,oven temperature, “BAKE”, and “ O
N”
display.
• Temperature begins at 350°F and can be set from
170°Fto550°Fin5degree increments.
• Temperature starts at 100°Fandincreasesin5°
incrementsuntilreachingsettemperature.Some
minorsmokingisnormalwhenusingovenforfirst
time.Whencooktemperatureisreached preheat
signalsounds.
3. PressOVENCANCEL pad when finished.
• Removefood from ovenwhencooking timehas
elapsed.Food left in oven can overcook.

13
Delayed Baking
1. Placefood in oven.
2. Press BAKE pad.
• “BAKE”and“---°”display.
3. Press or pad until desired temperature is
displayed.
• Time of day, oven temperature, “BAKE”, and “ O
N”
display.
• Temperature begins at 350°F and can be set from
170°Fto550°Fin5degree increments.
4. PressSTOPTIMEpad.
• Currenttimeofday,“BAKE”,“STOP”,“TIME”,
“BAKE”, and display.
5. Press or paduntildesiredstoptimedisplays.
• Stop time can be set up to 11 hours 55 minutes
aheadofcurrenttime of day.
6. PressCOOKTIMEpad.
• “BAKE”, “TIME”, and “BAKE” display.
• To view cook timelater,pressandhold COOK TIME
pad.
7. Press or pad until desired time cooking
displays.
• Maximum cooking time, “DELAY”, “BAKE”,
“STOP”,“TIME”, “DELAY”,and “BAKE”display.
When start time is reached “DELAY” no longer
displays and “ O
N” displays.
• 10 minutes minimum cooking time.
• Electronic range control calculates start time.
• To view cook time,pressandholdCOOK TIME
pad.
• When cooking time has elapsed, end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day.
To Cancel Remaining Cooking Time
PressOVENCANCELpad.
Timed Baking
1. Placefood in oven.
2. PressCOOKTIMEpad.
• “TIME”,“BAKE”,and“--:--” display.
3. Press or pad until cooking time is displayed.
• “TIME”,“BAKE”,and“HR”display. “HR” does not
display if less than an hour of time is set.
• Cook time can be set up to 11 hours and 59
minutes.
• 5 minutes minimum cooking time.
• Ifcooktimeisenteredandtemperaturenot entered
“BAKE”flashesandoven signals.
4. Press BAKE pad.
• “BAKE”and“---°”display.
5. Press or pad until desired temperature is
displayed.
• “TIME”,“BAKE”,“O
N”,and“HR”display.“HR”does
not display if less than a hour of time is set.
• Cooking time begins to count down.
• Temperature begins at 350°F and can be set from
170°F to 550°F in 5°F increments.
• Temperature display increases in 5°F increments
startingat100°Funtil reaching set temperature.
Someminorsmokingisnormalwhen using oven for
firsttime.Whencooktemperature is reached oven
signals.
• Preheatsignal sounds when oven cavityreaches
temperature.
• When cooking time has elapsed, an end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day.
6. PressOVENCANCEL pad when finished.
• Removefood from ovenwhencooking timehas
elapsed.Food left in oven can overcook.
To Cancel Remaining Cooking Time
PressOVENCANCELpad.

14
Broiling
Top elementoperates during broil. Broil can beused to
cookfoodswhich are normally broiled. Preheating is not
requiredwhen using broil.
Top
element
operating
• Ovendoormustbe closed while broiling.
• Removeexcessfat from meat before broiling. Cut
edgesofmeat to prevent curling.
• Placefoodonacoldungreasedbroilingpan. If pan
is hot, food sticks.
• Seasonmeatafterithasbrowned.
• Begin cooking using suggested rack levels in
Broiling Guide section to test broiler results. If food
is not browned enough, cook on a higher rack
position. If food is too browned, cook on a lower
rack position.
• All foods should be turned at least once except
fish, which does not need to be turned.
1. Centerfoodonbroilinggrid and pan, and place in
oven.
• Ovendoormustbe closed while broiling.
2. PressBROILpad.
• “BROIL”and “---” displays.
3. Press or to set from “HI”, “5” thru “2”, or “LO”.
• Ovenbeginstobroilautomatically.“BROIL”,“O
N”
and“HI”,“5”thru“2”,or“LO”display.
Broiler Setting Use
HI Cookin
g
red meats
5 Cooking pork
4 Cookin
g
poultr
y
3 Cookin
g
seafood
2 Cooking fruits and vegetables
LO Toastin
g
breads
4. PressOVENCANCEL pad when finished.
WARNING
•To avoid risk of fire, do not line the broiler grid with
foil. Foil may trap grease on top of grid close to
elementcausingafire.
• Neverleaveovenunattendedwhilebroiling.
Overcookingmayresultinafire.
Convection
Rearelement and fanoperateduringconvection. Use
convectionforcookingpastries,souffles,yeastbread,
cakesand cookies. Preheat oven for best results when
usingconvection. Pans do not need to be staggered.
Cooksapproximately 25% quicker than bake.
Rearelement
andfan
operating
1. Press CONV. pad.
• “CONV”and “---°” display.
2. Press or pad until desired temperature is
displayed.
• Time of day,oven temperature, “CONV”,and“O
N”
display.
• Temperature begins at 350°F and can be set from
170°Fto550°Fin5degree increments.
• Temperature starts at 100°Fandincreasesin5°
incrementsuntilreachingsettemperature.Some
minorsmokingisnormalwhenusingovenforfirst
time.Whencooktemperatureisreached preheat
signalsounds
3. PressOVENCANCEL pad when finished.
• Removefood from ovenwhencooking timehas
elapsed.Food left in oven can overcook.

15
Delayed Convection
1. Placefood in oven.
2. Press CONV. pad.
• “CONV”and “---°” display.
3. Press or pad until desired temperature is
displayed.
• Time of day,oven temperature, “CONV”,and“O
N”
display.
• Temperature begins at 350°F and can be set from
170°Fto550°Fin5degree increments.
4. PressSTOPTIMEpad.
• Currenttimeofday,“BAKE”,“STOP”,“TIME”,
“CONV”,anddisplay.
5. Press or paduntildesiredstoptimedisplays.
• Stop time can be set 11 hours 55 minutes ahead of
current time of day.
6. PressCOOKTIMEpad.
• “BAKE”,“TIME”,and “CONV” display.
7. Press or pad until desired cooking time
displays.
• Maximum cooking time, “DELAY”, “BAKE”,
“STOP”,“TIME”, “DELAY”, and “CONV” display.
When start time is reached “DELAY” no longer
displays and “ O
N” displays.
• 10 minutes minimum cooking time.
• Electronic range control calculates start time.
• To view cook time,pressandholdCOOK TIME
pad.
• When cooking time has elapsed, end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day.
To Cancel Remaining Cooking Time
PressOVENCANCELpad.
Timed Convection
1. Placefood in oven.
2. PressCOOKTIMEpad.
• “TIME”,“CONV”, and “--:--” display.
3. Press or pad until cooking time is displayed.
• “TIME”,“CONV”, and “HR” display.“HR” does not
display if less than a hour of time is set.
• Cook time can be set up to 11 hours and 59
minutes.
• 5 minutes minimum cooking time.
• Ifcooktimeisenteredandtemperaturenot entered
“BAKE”flashesandoven signals.
4. Press CONV. pad.
• “CONV”and “---°” display.
5. Press or pad until desired temperature is
displayed.
• “TIME”,“CONV”,“ O
N”,and “HR” display. “HR” does
not display if less than a hour of time is set.
• Cooking time begins to count down.
• Temperature begins at 350°F and can be set from
170°F to 550°F in 5°F increments.
• Temperature display increases in 5°F increments
startingat100°Funtil reaching set temperature.
Someminorsmokingisnormalwhen using oven for
firsttime.Whencooktemperature is reached oven
signals.
• Preheatsignal sounds when oven cavityreaches
temperature.
• When cooking time has elapsed, an end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day.
6. PressOVENCANCEL pad when finished.
• Removefood from ovenwhencooking timehas
elapsed.Food left in oven can overcook.
To Cancel Remaining Cooking Time
PressOVENCANCELpad.

16
WARNING
To avoid risk of fire, clean excess spills from oven
interior.
CAUTION
To avoid risk of personal injury, do not touch oven vents
orareas around ventsduringself-cleaning. These areas
can become hot enough to cause burns.
Delayed Self-Cleaning
• A small amount of smoke is normal when cleaning.
Excessive smoke may indicate there is a faulty
gasket or too much food residue has been left in
oven.
• Cleanoven before it gets too dirty.Wipe up large
spillsbefore self-cleaning.
• Do not use cleaning cycle if oven light cover is not
properlyinplace.
1. Prepareoven forself-cleaning.
• Removeovenracks and all cooking utensils from
oven.
• Cleanexcessspillsfromoveninterior.
• Removeitems from range topandbackguard.
Theseareas can become hot during self-cleaning
cycle.
2. PressCLEANpad.
• “CLN”,“TIME”, and “--:--”display.
3. Press or pad until desired amount of cleaning
time is displayed.
• “3:00” displays when or is pressed.
• Increaseor decrease cleaning time in 5 minute
increments.
• Clean can be set from 2 to 4 hours. Minimum
recommendedcleaningtimeis 3 hours.
4. PressSTOPTIMEpad.
Self-Cleaning
• A small amount of smoke is normal when cleaning.
Excessive smoke may indicate a failed gasket or
toomuchfoodresiduehasbeenleftinoven.
• Cleanoven before it gets too dirty. Wipe up large
spillsbefore self-cleaning.
• Do not use cleaning cycle if oven light cover is not
properlyinplace.
1. Prepareoven forself-cleaning.
• Removeovenracks and all cooking utensils from
oven.
• Cleanexcessspillsfromoveninterior.
• Removeitems from range topandbackguard.
Theseareas can become hot during self-cleaning
cycle.
2. PressCLEANpad.
• “CLN”,“TIME”, and “--:--”display.
3. Press or pad to adjust cleaning time.
• “3:00” displays when or is pressed.
• Increase or decrease cleaning time by 5 minute
increments.
• Clean can be set from 2 to 4 hours. Minimum
recommendedcleaningtimeis 3 hours.
• Ovenbegins to clean. “HR”,“CLN,“TIME”,
“CLEAN”,“LOCKED”,and “ O
N”lights. “LOCKED”
flashes in display when automatic door latch is
locking.
• When cleaning time has elapsed, end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day. End of cycle signal
sounds.
4. PressOVENCANCEL padwhenfinished.
• Whenovenhascooledto a safe temperature, door
latchopensand“LOCKED”lightflasheswhile
opening.When oven has cooled enoughtoopen
door“LOCKED”light no longer displays and door
canbe opened.
Interrupt Self-Clean Cycle
1. PressOVEN CANCELpad.
2. Whenovenhascooledto a safe temperature, door
will unlock and can be opened.
WARNING
To avoid risk of fire, clean excess spills from oven
interior.
CAUTION
To avoid risk of personal injury, do not touch oven vents
orareas around ventsduringself-cleaning. These areas
can become hot enough to cause burns.

17
Cooking Utensils
• Use proper pan size. Do not use utensils that
overhangelementby more than 1 inch.
More than 1" overhang
2"
Less than 1" overhang
1"
• Use care when using glazed cooking utensils.
Someglass,earthenware,orotherglazedutensils
breakdueto sudden temperature changes.
• Select utensils without broken or loose handles.
Handlesshouldnotbeheavy enough to tilt pan.
• Select utensils with flat bottoms.
• Do not use a wok with a ring stand.
Donotuse a wokwith
a ring stand.
Use a flat
bottom wok.
For best cooking results, use a pan with a flat bottom.
Determine if pan has a flat bottom.
1. Rotate a ruler along bottom of pan. If pan is not flat,
gapsbetweenbottomofpanand edge of ruler occur.
2. A small groove or mark on a pan does not effect
cookingtimes.However,ifapanhas a gap, formed
rings, or an uneven bottom, it does not cook
efficiently and in some cases may not boil liquid.
Utensils
5. Press or pad until desired stopping time
appears in display.
• Starting time is automatically calculated based on
amount of cleaning time and stop time.
• “DELAY”,“CLN,“STOP”, “TIME”, :DELAY”,
“CLEAN”,and “LOCKED” display.“LOCKED”
flashes in display when automatic door latch is
locking.
• To view remaining cleaningtime,pressandhold
CLEANpad.
• To view calculated stop time, press and hold STOP
TIMEpad.
• When cleaning time has elapsed, end of cycle
signalsounds,ovenautomaticallyturns off and
display returns to time of day. End of cycle signal
sounds.
6. PressOVENCANCEL padwhenfinished.
• Whenovenhascooledto a safe temperature, door
latchopensand“LOCKED”lightflasheswhile
opening.When oven has cooled enoughtoopen
door“LOCKED”light no longer displays and door
canbe opened.
Interrupt Self-Clean Cycle
1. PressOVEN CANCELpad.
2. Whenovenhascooledto a safe temperature, door
will unlock and can be opened.
Child Lock Out
Thisfeaturedisables oven control. Surface elements will
heatwhenchildlockoutison.
1. Press and hold BAKE and CLOCK pads
simultaneously.
• “OFF”displays.
2. Repeat step 1 to cancel child lock.

18
Follow these recommendations only as a guide for times
andtemperature.Times,rack position, and temperatures
mayvarydependingonconditionsandfoodtype.Forbest
results, always check food at minimum time. When
roasting, choose rack position based on size of food item.
Oven Rack Placement
Positionovenrackbeforeturningovenon.
1. Pullrackforwardtostopposition.
2. Raisefrontedgeofrackandpulluntilrackisoutofoven.
3. Placerackinnewrackposition.
• Curvededgeofrackmustbetowardrearofoven.
Pan Placement
• Keeppans and cookie sheets 2 inches from oven
walls.
• Staggerpansplacedondifferentrackssooneisnot
directlyovertheother.
Cooking Guide
Utensil Material Charateristics
Type Temperature
Response Uses
Aluminum Heats and Cools
Quickly Frying, Braising,
Roasting
Cast Iron Heats and Cools
Slowly Low Heat Cooking,
Frying
Copper
Tin Lined Heats and Cools Quickly Gourmet Cooking, Wine
Sauces, Egg
Dishes
Enamelware Depends on Base
Metal Low Heat Cooking
Ceramic (Glass) Heats and Cools
Slowly Low Heat Cooking
Stainless Steel Heats and Cools at
Moderate Rate Soups, Sauces,
Vegetables,
General
Cooking

19
Followtheserecommendationsonly as a guide for times and temperature. Times, rack position, and temperatures
may vary depending on conditions and food type. For best results, always check food at minimum time.
Baking Guide
Rack Position Oven Temperature Cooking Time
1=Highest Fahrenheit Minutes
5=Lowest
AngelFood Cake 5 350 28-50
Biscuits 3 or 4 375-400 8-16
Muffins 3 or 4 400-425 17-23
Cookies 3 or 4 350-400 8-20
Cupcakes 3 or 4 350-400 18-30
Brownies 3 or 4 350 25-38
Layer cakes 3 or 4 350-375 27-40
PoundCake 3 or 4 325-350 45-70
Fresh Pies 3 or 4 400-450 35-60
Frozenpies 3 400 40-65

20
Convection Baking Guide
Followtheserecommendationsonlyasaguidefortimesandtemperature.Times,rackposition,andtemperaturesmayvary
depending on conditions and food type. For best results, always check food at minimum time.
Food Oven Temperature Cooking Time
Fahrenheit Minutes
An
g
el Food Cake 325 28-40
Biscuits 350-375 8-16
Muffins 375-400 15-23
Cookies 325-350 7-18
Cupcakes 325-375 15-20
Brownies 325-350 25-35
Layer cakes 325-350 20-30
Pound Cake 325 40-60
Fresh Pies 375-425 40-60
Nut Bread 350 45-55
