CABINET PARTS
1
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
11−08 Litho In U.S.A. (mat) (eeb) Part No. W10207767 Rev. A
REFRIGERATOR

CABINET PARTS
2
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10175445 Use & Care Guide
W10184250 Energy Guide
W10165418 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
M0310731 Black
4 B5759649 Gasket
5 67006118 Roller Assembly
6 67003868 Foot, Brake
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Front Roller)
9 67006521 Screw
10 Cover, Hinge
67001012 Black
11 67005822 Screw
12 67006473 Screw
13 67005064 Label, Fl Tb
Plug
14 67006303 Screw
15 Hinge, Center
67007043 Black
16
12566604ED Hinge, Top
17 Cover, Corner
67003485 Black
18
W10157973 Clip, Drain
19
12906303WD Hinge Bottom
20 67006564 Screw
21 67006101 Cover, Unit
22 Grille Assembly
67006954 Black
23 67001098 Cover, Fl Tb
24
W10164397 Tube, Drain
25 67006425 Screw (9)
27 67001097 Cover, Water Valve
28 A3076901 Plug Button
29 12479901 Plate, Cover
30 67006662 Screw

FREEZER LINER PARTS
3
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767

FREEZER LINER PARTS
4
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 12002497 Gear (2)
4 67003905 Cover, Light
5 67004261 Shaft
6
Y12570701 Socket, Light
7 67006530 Screw
8 67006473 Screw
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005872 Cover, Evaporator
12 67006425 Screw
13 Bracket, Door
W10122147 Left
W10122148 Right
14 67003906 Housing, Light
15 10623002 Clip, Evap Motor
16 67005653 Switch, Light
17 67006406 Screw
18 Bracket, Basket
W10187668 Left
W10187667 Right
19
W10120018 Slide, Drawer (2)
20 67003731 Gasket, Bottom
21 Bracket, Slide
W10128118 Left
W10128119 Right
22
W10175909 Grille, Fan Shroud
23
W10167023 Shroud, Evaporator
24 2169142 Blade, Fan
25
W10121318 Grommet
26 67003636 Motor, Evaporator
27 D7753903 Funnel
28 M0500703 seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)

FREEZER DOOR PARTS
5
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Freezer Door
(w/ Insulation)
13092210SQ Stainless Steel
2 Handle
W10136873 Stainless
3 Door Gasket,
Magnetic
W10130587 Black
4 67002935 Screw
5 Plug, Button (2)
W10153326 Black
6 67006113 Mount, Handle

REFRIGERATOR LINER PARTS
6
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2
Y67003896 Module, Light
3 67004279 Overlay
4
W10185244 Housing, Control
5
W10165748 Board, Control
6 C3680310 Switch, Light
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701 Socket, Light (2)
11 67003900 Insert
Damper Cover
12 67006602 Screw
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429 Control, Damper
16 12002355 Thermistor
17 M0310731 Plug Button
Following Parts Not Illustrated
67004033 Harness, Controls
(Refrigerator)

REFRIGERATOR DOOR PARTS
7
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767

REFRIGERATOR DOOR PARTS
8
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(w/Liner)
13023840SQ Left
13023839SQ Right
2 67002935 Screw
3 67003819 Door, Dairy
4 67001279 Tray, Dairy
5 67001021 Bucket, Medium (4)
6 67006113 Mount, Handle
7 Plug, Button
W10153326 Black
8 Door Gasket,
Magnetic
W10131327 Black
9 Door Handle
W10136873 Black
10 12528501 Nameplate
11 67001280 Retainer, Ref Door
12 67006287 Screw
13 Bushing
67004978 Black
14 Stop, Door
67003780 Black
15 Closure, Door
67003639 Black

UNIT PARTS
9
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767

UNIT PARTS
10
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2
W10162928 Blade, Fan
3 67005744 Basepan
4 67006425 Screw
5 67005491 Block, Condenser
6
W10167036 Tube, Discharge
7
W10119856 Harness, Evap.
Heater
8 67004713 Drain Pan
9 61004743 Grommet (3)
10 67001794 Evaporator Heater
11
W10136415 Clip, Capacitor
12
W10136414 Overload
(Includes Relay)
13 61003210 Gasket
14
W10165425 Thermostat
15
W10137529 Grommet
16 67006573 Screw
17
W10169124 Grommet (4)
18 67006132 Condenser
19 67006432 Screw
20 67001080 Tray, Drip
21 67006737 Screw
22 67003719 Evaporator
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060301 Harness, MC
(Includes
Power Cord)
27
W10143759 Drier (Service)
28
W10130129 Compressor
29 2264017 Capacitor
30 67006434 Axle, Roller
31
W10158508 Shroud
32 67004953 Bracket, Fan Motor
33 67004954 Screw
34 10547003 Clip, Drier
35 67005149 Roller
36 10623002 Clip, Evap
37 67005680 Grommet
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.00 Ozs.
(R−134A)

SHELF PARTS
11
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767

SHELF PARTS
12
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION
1 67001057 Rail, Center
Crisper
2 67004420 Trim, Crisper
3 67005864 Slide, Humidity
Control
4 67004986 Basket, Upper
5
W10143561 Basket, Freezer
(Lower)
6 67006626 Screw
7 67006360 Screw
8 67006608 Screw
9 67001314 Pan, Deli
10 10459927 Trim, Front (4)
11 67006400 Screw (6)
12 67004127 Divider, Top
13 67001054 Glide LH
67001053 Glide RH
15 10370099 Glass, Shelf
16 67002633 Pan, Crisper (2)
17 67001059 Brace, Crisper (2)
18 67001056 Frame, Crisper
19 67006878 Glass, Crisper (2)
20 67001073 Ladder, Center
21 67001317 Ladder, Side
22 67006644 Divider, Basket
Lower
23 10460107 Shelf (4)
24 10946008 Trim, Rear (4)

ICEMAKER PARTS
13
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767

ICEMAKER PARTS
14
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION
1 Mold & Heater
Assembly
(Not Available
Order D7824706Q)
2 67004028 Arm, Shutoff
3 628356 Cup, Fill
4 627843 Ejector
5 2182124 Ice Stripper
6 2195914 Support & Motor
Assembly
7 2315522 Retainer,
Thermostat
8 Thermostat
(Not Available
Order D7824706Q)
9 681249 Screw (2)
10 67001255 Pan, Ice
11 67004101 Bracket, Tube
Support
12 67006531 Valve, Water
Inlet
13 A3223101 Insert, Tube
14 B5705307 Tubing, Plastic
15
W10146389 Harness, Icemaker
16 625910 Bracket
17 67006662 Screw
18 67004710 Cover
19 Module Assembly
(Not Available
Order D7824706Q)
20 67006287 Screw
21 67005603 Funnel, Fill
Tube
100 67001740 Complete Ice Maker

OPTIONAL PARTS (NOT INCLUDED)
15
For Models: ABL2222FES12, ABR2222FES12
(Stainless Steel) (Stainless Steel)
W10207767
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350930 White
350939 Black
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799344 Black (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
ACCESSORIES
2217192 Cleaner,
Stainless Steel
