CABINET PARTS
1
For Models: AFB2234WES2
(Stainless Steel)
8−09 Litho In U.S.A. (mat)(bay) Part No. W10289731 Rev.A
REFRIGERATOR

CABINET PARTS
2
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10175445 Use & Care Guide
W10260550 Energy Guide
W10255316 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Cover, Left Hinge
12962301B Black
4 B5759655 Gasket
6
W10141622 Foot, Brake
7
12963204ED Hinge, Left Top
9 12992602 Screw
10 Cover, Right Hinge
12962302B Black
11 12990101 Screw
12 12698403 Block, Pivot
14 12992403 Screw (3)
15 Hinge, Center (LT)
13000007ED Black
16
12963205ED Hinge, Right Top
17 Cover, Corner
12587703B Black
19 Roller Assembly
W10275850 Left
W10275849 Right
20 12991302 Screw (4)
21
W10210979 Cover, Unit
22 Grille, Toe
W10236196 Black
24
W10210988 Tube, Drain
25 12990511 Screw
26 12820505 Fiber, Acoustic
27
W10217701 Cover, Water Valve
28 Shim, Top Hinge
12999501 Left
12999502 Right
29 12990303 Screw, Block
30 Hinge, Center (RT)
13000008ED Black

FREEZER LINER PARTS
3
For Models: AFB2234WES2
(Stainless Steel)
W10289731

FREEZER LINER PARTS
4
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 A3189392 Gasket, Foam
3 12932103 Guide, Fill Tube
4 12804901 Cover, Light
5
W10128551 Motor, Evaporator
6
12570701V Socket, Light
7 12002355 Thermistor
8 12815301 Cover, Thermistor
9
W10194422V Bulb, Light
10
12806601V Housing, Light
11 12226111 Cover, Evaporator
12 12990511 Screw
13
W10121318 Grommet
14 12805001 Module, Light
15 13058002 Clip, Evap. Motor
16 12466105 Switch, Light
17
12991603V Screw
18 D7753903 Funnel, Drain
19 M0500703 Seal
20 A3189395 Gasket, Bottom
21 B8381501 Gasket
22 13024803 Grille, Fz Air
23 13057901 Shroud, Evap.Fan
24 2169142 Blade, Fan
(Evaporator)
25 Bracket, Door
W10122147 Left
W10122148 Right
26 12990521 Screw (8)
27 Cradle, Basket
12812303 Left
12812304 Right
28
W10120018 Slide, Drawer (2)
29 Adapter, Slide
W10149390 Left
W10149391 Right
30 12990501 Screw (6)
31
12812905WD Shaft
32 Gear
W10158749 Left
W10146446 Right
33 Rack, Side
W10216619 Left
W10216620 Right
Following Parts Not Illustrated
13014801 Harness, Lights
(Freezer)

FREEZER DOOR PARTS
5
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION
1 Door, Freezer
12977827SQ Stainless Steel
2 Handle, Door
W10123790 Stainless Steel
3 Gasket, Door
W10164037 Black
4 12991703 Screw, Handle

REFRIGERATOR LINER PARTS
6
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 12806303 Module, Light
3 12816511 Overlay
4 12806407 Module, Control
5 12868513 Board, Control
(Incl Instr Sheet)
6 12466104 Switch, Light (2)
7 12806501 Cover, Light
8
12806601V Housing, Light
9
W10194422V Bulb, Light (2)
10
12570701V Socket, Light (2)
11 12806801 Insert,
Damper Cover
12 12990604 Screw
13 12806701 Cover, Damper
14 13012402 Insulation
15
W10196393 Control, Damper
(Includes Harness)
16 12002355 Thermistor
17 12861601 Switch, Energy
Saver
Following Parts Not Illustrated
W10216622 Harness, Controls
(Refrigerator)

REFRIGERATOR DOOR PARTS
7
For Models: AFB2234WES2
(Stainless Steel)
W10289731

REFRIGERATOR DOOR PARTS
8
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION
1 Door, Left
12978050SQ Stainless Steel
2 Door, Right
12978054SQ Stainless Steel
3
12804701SP Door, Dairy
4
12369502SP Tray, Dairy
5 Bucket, Door
12557211V Small (2)
12918504V 33 Inch
12918204K Gallon
12557214K Medium
6 Mullion, Door
12722803B Black
7 12990204 Screw
8 Gasket, Door
W10163895 Black
9 Handle, Door
W10197305N Stainless (LH&RH)
10 12990504 Screw
11 Stop, Door
12968202B Black
12 12528501 Nameplate
13 13001201 Mount, Handle
15 Closure, Door
12028505B Black

UNIT PARTS
9
For Models: AFB2234WES2
(Stainless Steel)
W10289731

UNIT PARTS
10
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 12992301 Screw
2 12825803 Blade, Fan
3
W10210983 Basepan
4 12990511 Screw
5 2264017 Capacitor
6
W10217748 Tube, Discharge
7
W10224241 Harness, Evap.
Heater
8
W10189185 Pan, Drain
9
W10216919 Screw, Shoulder
10 12729128 Heater, Defrost
11
W10204187 Strap, Bale
12
W10197428 Start Device
13
W10137529 Grommet, Cond.(4)
14
12639324SP Thermostat,
Defrost
15 12477102 Roller (2)
16 12992101 Screw
17 Grommet (4)
10835903SP Service
18
W10135027 Condenser
19 10547003 Clip, Drier
20
12225402WD Tray, Drip
21 12990701 Screw
22 12001919 Evaporator Kit
(Incl. Evaporator
#67003719, Heat
Shield & Instruct.
Sheet)
23 Dam
12225702 Right Side
12225602 Left Side
24 12825101 Motor, Fan
25 10428101 Clip, Heater
26
W10234024 Harness, Unit
with Power Cord
27
W10143759 Drier (service)
28
W10134623 Compressor
(Includes items
5, 12, 17, & 27)
(Also Order
482801
Installation Kit
and 876765
Tube Kit)
29 10623002 Clip, Evaporator
30 12477202 Axle, Roller (2)
31
W10189184 Shroud
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)

SHELF PARTS
11
For Models: AFB2234WES2
(Stainless Steel)
W10289731

SHELF PARTS
12
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION
1 12530701 Rail, Center
Crisper
2
W10231343 Trim, Crisper
3
W10171570 Divider, Basket
(Upper)
4
W10169950 Basket, Freezer
(Upper)
5
W10150038 Basket, Freezer
(Lower)
6 12463509 Shelf (3)
7 12990515 Screw
8
12530805SP Slide, Humidity
Control (2)
9
W10241046 Divider, Basket
(Upper)
10
W10205416 Divider, Basket
(Lower)
11 12990513 Screw
12
W10233898 Mount, LH Gear
13
W10233899 Mount, RH Gear
14 13048801 Extr−Glass Support
16
12530505SP Pan, Crisper
17
12227303WD Brace, Crisper
18
12802302SP Frame, Crisper
19 12204822 Glass, Crisper Cover
20 12435807 Ladder, Center
21 12710602 Ladder, Side
24 12204820 Glass, Pantry
25 12655903 Trim, Pantry Glass
26
12227301WD Brace, Pantry (2)
27 12531901 Track, Pantry
28 12656902 Gasket, Pantry
29 13048301 Housing, Control
30 13048401 Slide, Control
31 Endcap, Pantry
13047701 Right
13047801 Left
32 12990504 Screw (4)
33
13058101V Glide, Pantry (2)
34 12990512 Screw (4)
35 13048201 Bar, Temp Cont.
36
12655204V Knob, Control
37
13048501SP Drawer, Pantry
38 12656820 Lid, Pantry
39
13048601SP Divider, Pantry

OPTIONAL PARTS
13
For Models: AFB2234WES2
(Stainless Steel)
W10289731
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
FIELD INSTALLABLE
ICE MAKER
67001740 IC11B
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350930 White
350939 Black
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799344 Black (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
ACCESSORIES
31462 Cleaner, 10 oz.
Stainless Steel
