Amana NTW4750YQ1 User manual

TOP-LOADING
HIGH EFFICIENCY
LOW-WATER WASHER
USE AND CARE GUIDE
GUIDE D'UTILISATION
ET D'ENTRETIEN DE
LA LAVEUSE HAUTE
EFFICACIT]_ AFAIBLE
CONSOMMATION D'EAU
AVEC CHARGEMENT
PAR LE DESSUS
Table of Contents Table des mati_res
WASHER SAFETY ............................................................ 2
WHAT'S NEW UNDER THE LiD? .................................... 3
CONTROL PANEL AND FEATURES ............................... 4
CYCLE GUIDE .................................................................. 6
USING YOUR WASHER ................................................... 7
WASHER MAINTENANCE ............................................. 10
TROUBLESHOOTING .................................................... 12
WARRANTY .................................................................... 17
ASSISTANCE OR SERVICE ....................... BACK COVER
S¢:CURIT¢: DE LA LAVEUSE ......................................... 18
QUOI DE NEUF SOUS LE COUVERCLE? .................... 19
TABLEAU DE COMMANDE
ET CARACTg::RISTIQUES .............................................. 20
GUIDE DE PROGRAMMES ........................................... 21
UTILISATION DE LA LAVEUSE ..................................... 23
ENTRETIEN DE LA LAVEUSE ....................................... 26
DF:I:PANNAG E.................................................................. 28
GARANTIE ...................................................................... 34
ASSISTANCE OU SERVICE ..... COUVERTURE ARRI#RE
Para una versi6n de estas instrucciones en espa_ol, visite www.amana.com
Designed to use only HE High Efficiency
detergents.
Congue pour I'utilisation d'un d6tergent haute
efficacit6 seulement
W10420474A
W10420475A =SP

WASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or
"WARNING." These words mean:
You can be killed or seriously injured if you don't
immediately follow instructions.
You can be killed or seriously injured if you don't
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions,
including the following:
[] Read all instructions before using the washer.
[] Do not wash articles that have been previously cleaned
in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, other flammable, or explosive
substances as they give off vapors that could ignite or
explode.
[] Do not add gasoline, dry-cleaning solvents, or other
flammable, or explosive substances to the wash water.
These substances give off vapors that could ignite or
explode.
[] Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been used
for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. Ifthe hot water system has not been
used for such a period, before using the washing
machine, turn on all hot water faucets and let the water
flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame during
Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer is used
near cHdren.
Before the washer is removed from service or discarded,
remove the door or lid.
[] Do not reach into the washer if the drum, tub or agitator is
moving.
[] Do not install or store the washer where it will be exposed to
the weather.
[] Do not tamper with controls.
[] Do not repair or replace any part of the washer or attempt any
servicing unless specifically recommended in this manual or in
published user-repair instructions that you understand and
have the skills to carry out.
[] See "Electrical Requirements" located in the installation
instructions for grounding instructions.
this time. SAVE THESE INSTRUCTIONS
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
2

WHAT'S NEW UNDER THE LID?
Cleaning with Less Water
Traditional agitator-style
washer Washer with low-water washplate wash system
The most striking difference in your new washer is the low-water
washplate wash system. The washer automatically adjusts the
water level to the load size--no water level selector is needed.
Automatic Load Size Sensing
Once you start the cycle, the lid will lock, and the washer will
begin the sensing process to determine the correct water level
for the load. This may take several minutes before water is
added. You will find a step-by-step description in the "Cycle
Status Lights" section.
You will hear the motor turn the basket in short pulses to
thoroughly wet the load. This low-water wash method uses
less water and energy compared to a traditional agitator-style
washer.
Choosing the Right Detergent
Use only High Efficiency detergents. The package will be
marked "HE" or "High Efficiency." Low-water washing creates
excessive sudsing with a regular non-HE detergent. Using
regular detergent will likely result in longer cycle times and
reduced rinsing performance. It may also result in component
failures and noticeable mold or mildew. HE detergents are made
to produce the right amount of suds for the best performance.
Follow the manufacturer's instructions to determine the amount
of detergent to use.
U._e only High Efficiency (HE) detergent.
Load garments in loose heaps evenly around the washplate.
Do not load garments directly over the center of the washplate;
when loaded, the center of the washplate should be visible.
Concentrated Cleaning
Low-water cleaning means concentrated cleaning. Rather
than diluting detergent as done in an agitator-style washer,
this washer delivers the detergent directly to the soils.
Normal Sounds
You Can Expect
At different stages of the wash cycle, you may hear sounds and
noises that are different from those of your previous washer.
For example, you may hear a clicking and hum at the beginning
of the cycle, as the lid lock goes through a self-test. There
will be different kinds of humming and whirring sounds as the
washplate moves the load. And sometimes, you may hear
nothing at all, as the washer determines the correct water level
for your load or allows time for clothes to soak.
As the washer dampens and moves the load, the level of the
garments will settle in the basket. This is normal, and does not
indicate that more garments should be added.
IMPORTANT: You will not see a washer basket full of water as
with your past agitator-style washer. It is normal for some of the
load to be above the water line.

CONTROL PANEL AND FEATURES
\
STAIN TREAT
OWASH TEMPERATURE
Temperature Control senses and maintains uniform water
temperatures by regulating incoming hot and cold water.
Select a wash temperature based on the type of fabric
and soils being washed. For best results and following the
garment label instructions, use the warmest wash water safe
for your fabric.
• Warm and hot water will be cooler than what your previous
washer provided.
• Even in a cool water wash, some warm water may be
added to the washer to maintain a minimum temperature.
OPTIONS
The following options may be added to most cycles.
See "Cycle Guide" for additional details.
EXTRA RINSE
This option can be used to automatically add a second
rinse to most cycles.
FABRIC SOFTENER
This option must be selected if using fabric softener
during a cycle. It ensures that fabric softener is added at
the correct time in the rinse for even distribution.
FABRIC SOFTENER with EXTRA RINSE
This option turns on both the Fabric Softener and the
Extra Rinse options.
STAIN TREAT
This option provides enhanced cleaning action for tough
stains. It will add additional agitation and soak time to the
cycle.
WASH CYCLE KNOB
Use the Wash Cycle knob to select available cycles on your
washer. Turn the knob to select a cycle for your laundry load.
See "Cycle Guide" for detailed descriptions of cycles.
START/PAUSE/UNLOCK LID BUTTON
Press to Start the selected cycle; press again to Pause the
cycle and unlock the lid.
NOTE: If the washer is spinning, it may take several
minutes to unlock the lid. Press and hold 3 seconds
to Cancel a cycle.
CYCLE STATUS LIGHTS
coo o o o
sensing wash rinse final cycle lid
fill spin complete locked
The Cycle Status Lights show the progress of a cycle. At
each stage of the process, you may notice sounds or pauses
that are different from traditional washers.
SENSING FILL
When the START/Pause/Unlock Lid button is pressed,
the washer will first perform a self-test on the lid lock
mechanism. You will hear a click, the basket will make a
slight turn, and the lid will unlock briefly before locking again.
Once the lid has locked the second time, the washer will use
short, slow spins to estimate the load size. These sensing
spins may take 2 to 3 minutes before water is added to the
load and you may hear the hum of these spins. If the sensing
light is on, then washer is working properly. You will hear
the motor turn the basket in short pulses to thoroughly wet
the load. The washer will then move the load briefly, pause
to allow water to soak in to the load, and resume adding
water. This process may repeat until the correct amount of
water has been added for the load. You may also hear water
flowing through the dispenser, adding detergent to the load.
NOTE: Avoid opening lid during sensing. The sensing
process will start over when the washer is restarted. The
sensing light may also come on during the Soak and Wash
portions of the cycle. This is normal.
WASH
You will hear the motor and washplate moving the load.
Unlike traditional washers, the load is not covered with water.
Low-water cleaning means concentrated cleaning. Rather
than diluting detergent as done in an agitator-style washer,
this washer delivers the detergent directly to the soils. The
motor sounds may change at different stages in the cycle.
The wash time is determined by the selected soil level.
4

RINSE
You will hear sounds similar to the wash cycle as the washer
rinses and moves the load. You may hear the motor turning
on briefly (short hum) to move the basket while filling. Fabric
softener will be added if the Fabric Softener option was
selected. Some cycles will use a spray rinse.
FINAL SPiN
The washer spins the load at increasing speeds for proper
water removal, based on the selected cycle and spin speed.
CYCLE COMPLETE
Once the cycle is complete, this light will come on. Remove
the load promptly for best results.
LID LOCKED
To allow for proper load sensing and
spinning, the lid will lock and the Lid
Locked light will turn on. This light
indicates that the lid is locked and
cannot be opened.
If you need to open the lid, press
START/Pause/Unlock Lid. The lid will
unlock once the washer movement has
stopped. This may take several minutes
if the load was spinning at high speed.
Press START/Pause/Unlock Lid again to
resume the cycle. Avoid opening the lid
during sensing. The sensing process
will start over when the washer is restarted.
I{d
locked
START
PAUSE/
UNLOCK LID
©
CANCEL HOLD 3s_c

CYCLE GUIDE
For best fabric care, choose the cycle that best fits the load being washed.
Not all cycles and options are available on all models.
Sturdy fabrics, colorfast
items, towels, jeans
Sturdy fabrics, colorfast
items, towels, jeans
Cottons, linens, and
mixed garment loads
Light-weight cotton
and cotton blends
No-iron fabrics, cottons,
perm. press, synthetics
Large items such as
sheets, sleeping bags,
jackets, and small
washable rugs
Machine-wash silks,
hand-wash fabrics
Small loads, cottons,
polyester, perm. press
Super
Wash
Normal
Heavy
Normal
Regular
Normal
Light
Casual
Bulky
Items
Delicate
Quick
Wash
Hot
Warm
Cool
Cold
Hot
Warm
Cool
Cold
Hot
Warm
Cool
Cold
Hot
Warm
Cool
Cold
Hot
Warm
Cool
Cold
Hot
Warm
Cool
Cold
Hot
Warm
Cool
Cold
Hot
Warm
Cool
Cold
High
High
High
High
Low
High
Low
High
Provides maximum wash time and action for tough stains
and soils. Use this cycle for heavily soiled or sturdy items.
Water-level sensing process may take longer for some
items than for others because they will absorb more water
than other fabric types.
Use this cycle for heavily soiled or sturdy items. Water-level
sensing process may take longer for some items than for
others because they will absorb more water than other
fabric types. This cycle features a spray rinse.
Use this cycle for normally soiled cottons and mixed fabric
loads. This cycle features a spray rinse.
Use this cycle for light weight cottons that are lightly soiled.
This cycle features a spray rinse.
Use this cycle to wash loads of no-iron fabrics such as
sport shirts, blouses, casual business clothes, permanent
press, and blends.
Use this cycle to wash large items such as jackets and
coats. The washer will fill with enough water to wet down
the load before the wash portion of the cycle begins, and
uses a higher water level than other cycles. Do not tightly
pack basket.
Use this cycle to wash lightly soiled garments indicating
"Machine Washable Silks" or "Gentle" cycle on the care
label. Place small items in mesh garment bags before
washing. This cycle uses a higher, preset water level.
Use this cycle to wash small, lightly soiled loads of 2-3 items
that are needed in a hurry. This cycle features a spray rinse.
Heavily soiled fabrics Soak No Spin
Swimsuits and items
requiring rinsing without
detergent
Dripping wet item or
hand-washed items
No clothes in washer
Rinse &
Spin
Drain &
Spin
Clean
Washer
with
affresh ®
*All rinses are cold.
Hot
Warm
Cool
Cold
Cold
N/A
Hot
Warm
Cool
Cold
**Spin speed isintegrated intothe cycle and cannot be selected.
6
High
High
High
Use this cycle to soak small spots of set-in stains on fabrics. The
washer will use intermittent agitation and soaking. After time has
expired, water will drain, but the washer will not spin. Cycle is
complete.
Combines a rinse and high-speed spin for loads requiring
an additional rinse cycle or to complete a load after power
interruption. This cycle uses a higher, preset water level.
Also use for loads that require rinsing only.
This cycle uses a spin to shorten drying times for heavy
fabrics or special-care items washed by hand. Use this
cycle to drain washer after cancelling a cycle or completing
a cycle after a power failure.
Use this cycle every 30 washes to keep the inside of your
washer fresh and clean. This cycle uses a higher water level.
Use with affresh ®washer cleaner tablet or liquid chlorine
bleach to thoroughly clean the inside of your washer. This
cycle should not be interrupted. See "Washer Care" in
Washer Maintenance.
IMPORTANT: Do not place garments or other items in the
washer during the Clean Washer with affresh ®cycle. Use this
cycle with an empty wash tub. J

USING YOUR WASHER
Fire Hazard
Never place items in the washer that are dampened
with gasoline or other flammable fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on
it (including cooking oils).
Doing so can result in death, explosion, or fire.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
1, Sort and prepare your laundry
[] Empty pockets. Loose change, buttons, or any small
object can pass under the washplate and become trapped,
causing unexpected sounds.
[] Sort garments by recommended cycle, water temperature,
and colorfastness.
[] Separate heavily soiled garments from lightly soiled.
[] Separate delicate garments from sturdy fabrics.
[] Do not dry garments if stains remain after washing,
because heat can set stains into fabric.
[] Treat stains promptly.
[] Close zippers, fasten hooks, tie strings and sashes, and
remove non-washable trim and ornaments.
[] Mend rips and tears to avoid further damage to garments
during washing.
Helpful Tips:
[] When washing water-proof or water=resistant items, load
evenly. See "Cycle Guide" for tips and more information on
using the Bulky Items cycle.
[] Use mesh garment bags to help avoid tangling when
washing delicate or small garments.
[] Turn knits inside out to avoid pilling. Separate lint-takers
from lint-givers. Synthetics, knits, and corduroy fabrics will
pick up lint from towels, rugs, and chenille fabrics.
NOTE: Always read and follow fabric care label instructions to
avoid damage to your garments.
Add a measured amount of HE
detergent into the basket.
IMPORTANT: Use only High Efficiency
detergents. The package will be marked "HE" or "High
Efficiency." Low-water washing creates excessive sudsing
with a regular non-HE detergent. Using regular detergent
will likely result in longer cycle times and reduced rinsing
performance. It may also result in component failures and
noticeable mold or mildew. HE detergents are made to
produce the right amount of suds for the best performance.
Follow the manufacturer's instructions to determine the
amount of detergent to use.
Using Oxi or color=safe bleach:
If using an Oxi or color-safe bleach laundry boost product,
add to the bottom of the washer basket before adding
clothes.

Loadgarmentsinlooseheapsevenly
aroundthewashplate.Donotload
garmentsdirectlyoverthecenterofthe
washplate;whenloaded,thecenterof
thewashplateshouldbevisible.Try
mixingdifferentsizedgarmentsto
reducetangling.
IMPORTANT:Garmentsneedtomove
freelyforbestcleaningandtoreducewrinkling
andtangling.
dispenser
Do not overfill, dilute, or use more than 1 cup (250 mL). Do
not use color-safe bleach or Oxi products in the same cycle
with liquid chlorine bleach.
This washer has been designed to allow
the use of the Downy Ball®to dispense
fabric softener in the rinse cycle. Pour a
measured amount of Downy ®liquid fabric softener into the
Downy Ball ®,pull the ring tightly to seal it, and place on top
of load. Always follow manufacturer's directions for correct
amount of fabric softener based on your load size. Then
select Fabric Softener option. The Downy Ball ®will
automatically release the fabric softener during the
rinse cycle. For questions on using the Downy Ball®call
1-800-688-7638 or visit www.downy.com.
IMPORTANT: Fabric Softener option must be selected to
ensure proper distribution at correct time in cycle. Do not
overfill or dilute.
Adding Liquid Fabric Softener Manually to Wash Load
During the final rinse, wait until the washer has completed
filling, press the START/Pause/Unlock Lid button to Pause
the washer. Lift the lid and add the measured recommended
amount of liquid fabric softener. Do not allow liquid fabric
softener to spill, splash, drip, or run into the basket or on load.
Do not use more than the recommended amount. Close the lid
and press the START/Pause/Unlock Lid button again to start
the washer.
IMPORTANT: Fabric Softener option must be selected to
ensure proper distribution of the fabric softener during the
rinse portion of the cycle.
Select cycle
NORMAL
regular
heavy light
super wash casual
bumky itemsdrain & spin
delicate
rinse & spin
soak quick wash
Turn cycle knob to choose your wash cycle.
8

WASH TEMPERATURE
all cold rinses
cool
lights
cool
darks warm
cold hot
Once you select a cycle, select the desired wash temperature
by turning the Wash Temperature knob to the desired setting.
NOTE: Always read and follow fabric care label instructions to
avoid damage to your garments.
Wash Temp
Hot
Some cold water is added to save
energy. This will be cooler than
your hot water heater setting.
Warm
Some cold water will be added, so
this will be cooler than what your
previous washer provided.
Cool Lights
Warm water is added to assist in
soil removal and to help dissolve
detergents.
Cool Darks
Warm water may be added to
assist in soil removal and to help
dissolve detergents.
Cold
This is the temperature from your
faucet. If your tap cold water is
very cold, warm water may be
added to assist in soil removal and
help dissolve detergent.
Suggested Fabrics
Whites and pastels
Durable garments
Heavy soils
Bright colors
Moderate to light soils
Colors that bleed
or fade
Light soils
Colors that bleed
or fade
Light soils
Dark colors that
bleed or fade
Light soils
O, Select cycle options, if desired
OPTIONS STAIN TREAT
extra fabric
rinse softener off
fabric
softener
If you would like to add an Extra Rinse, Fabric Softener,
Fabric Softener with Extra Rinse and/or use the Stain Treat
option, turn the knob for that feature.
9, Press START/Pause/Unlock Lid
to begin wash cycle
START
PAUSE/
UNLOCK UD
©
CANCEL .OLD3sEc
Press the START/Pause/Unlock Lid button to start the wash
cycle. Filling is delayed for several minutes while load balance
is sensed. When the cycle has finished, the Cycle Complete
indicator will light. Promptly remove garments after cycle has
completed to avoid odor, reduce wrinkling, and rusting of
metal hooks, zippers, and snaps.
Unlocking the lid to add garments:
If you need to open the lid to add 1 or 2 missed garments:
Press START/Pause/Unlock Lid; the lid will unlock once
the washer movement has stopped. This may take several
minutes if the load was spinning at high speed. Then close lid
and press START/Pause/Unlock Lid again to restart the cycle.
If lid is left open for more than 10 minutes the water will pump
out automatically.
Delay in water fill
Filling is delayed for 2 to 3 minutes to check for load
unbalance. You will hear the hum of the spin prior to filling.
This is normal operation.

WASHER MAINTENANCE
WATER iNLET HOSES
Replace inlethoses after 5 years of use to reduce the risk
of hose failure. Periodically inspect and replace inlet hoses
if bulges, kinks, cuts, wear, or leaks are found.
When replacing your inlet hoses, mark the date of
replacement on the label with a permanent marker.
NOTE: This washer does not include inlet hoses. See the
"installation Instructions" for more information.
WASHER CARE
Recommendations to Help Keep Your Washer Clean
and Performing at its Best
1. Always use High Efficiency (HE) detergents and follow the
HE detergent manufacturer's instructions regarding the
amount of HE detergent to use. Never use more than the
recommended amount because that may increase the rate
at which detergent and soil residue accumulate inside your
washer, which in turn may result in undesirable odor.
2. Use warm and hot wash water settings sometimes (not
exclusively cold water washes), because they do a better
job of controlling the rate at which soils and detergent
accumulate.
3. Always leave the washer lid open between uses to help dry
out the washer and prevent the buildup of odor-causing
residue.
Cleaning Your Top Loading Washer
Read these instructions completely before beginning the
routine cleaning processes recommended below. This Washer
Maintenance Procedure should be performed, at a minimum,
once per month or every 30 wash cycles, whichever occurs
sooner, to control the rate at which soils and detergent may
otherwise accumulate in your washer.
Cleaning the inside of the Washer
To keep your washer odor-free, follow the usage instructions
provided above, and use this recommended monthly cleaning
procedure:
Clean Washer Cycle
This washer has a special cycle that uses higher water volumes
in combination with affresh ®Washer Cleaner or liquid chlorine
bleach to clean the inside of the washer.
Begin procedure
1. affresh ®Washer Cleaner Cycle Procedure (Recommended
for Best Performance):
a. Open the washer lid and remove any clothing or items.
bo Place an affresh ®Washer Cleaner tablet in the bottom
of the washer basket.
co Do not place an affresh ®Washer Cleaner tablet
in the detergent dispenser.
d. Do not add any detergent or other chemical to the
washer when following this procedure.
eo Close the washer lid.
fo Select the CLEAN WASHER cycle.
FWASHER CARE (cont.)
2=
g. Press the START/Pause/Unlock Lid button to begin
the cycle. The Clean Washer Cycle Operation is
described below.
NOTE: For best results, do not interrupt cycle. If cycle
must be interrupted, press POWER/CANCEL (For models
with no Power/Cancel button, press and hold START/
Pause/Unlock Lid for three seconds). After the Clean
Washer cycle has stopped, run a RINSE & SPIN cycle to
rinse cleaner from washer.
Chlorine Bleach Procedure (Alternative):
a. Open the washer lid and remove any clothing
or items.
b. Add 1 cup (236 mL) of liquid chlorine bleach
to the bleach compartment.
NOTE: Use of more liquid chlorine bleach than is
recommended above could cause washer damage
over time.
co Close the washer lid.
d. Do not add any detergent or other chemical
to the washer when following this procedure.
eo Select the CLEAN WASHER cycle.
f. Press the START/Pause/Unlock Lid button to begin
the cycle. The Clean Washer Cycle Operation is
described below.
NOTE: For best results, do not interrupt cycle. If cycle
must be interrupted, press POWER/CANCEL (For models
with no Power/Cancel button, press and hold START/
Pause/Unlock Lid for three seconds). After the Clean
Washer cycle has stopped, run a RINSE & SPIN cycle to
rinse cleaner from washer.
Description of Clean Washer Cycle Operation:
1. This cycle will fill to a water level higher than in normal
wash cycles to provide rinsing at a level above the water
line for normal wash cycle.
2. During this cycle, there will be some agitation and
spinning to increase the removal of soils.
After this cycle is complete, leave the lid open to allow
for better ventilation and drying of the washer interior.
Cleaning the Dispensers
After a period of using your washer, you may find some
residue buildup in the washer's dispensers. To remove
residue from the dispensers, wipe them with a damp cloth
and towel dry. Do not attempt to remove the dispensers or
trim for cleaning. The dispensers and trim are not removable.
If your model has a dispenser drawer, however, remove the
drawer and clean it before or after you run the Clean Washer
cycle. Use an all-purpose surface cleaner, if needed.
Cleaning the Outside of the Washer
Use a soft, damp cloth or sponge to wipe away any spills.
Use only mild soaps or cleaners when cleaning external
washer surfaces.
IMPORTANT: To avoid damaging the washer's finish, do not
use abrasive products.
10

NON-USE AND VACATION CARE
Operate your washer only when you are home. If moving,
or not using your washer for a period of time, follow these
steps:
1. Unplug or disconnect power to washer.
2. Turn off water supply to washer, to avoid flooding due
to water pressure surge.
WINTER STORAGE CARE
IMPORTANT: To avoid damage, install and store washer
where it will not freeze. Because some water may stay in
hoses, freezing can damage washer. If storing or moving
during freezing weather, winterize your washer.
To winterize washer:
1. Shut off both water faucets; disconnect and drain water
inlet hoses.
2. Put 1 qt. (1 L) of R.V.-type antifreeze in basket and run
washer on RINSE & SPIN cycle for about 30 seconds to
mix antifreeze and remaining water.
3. Unplug washer or disconnect power.
TRANSPORTING YOUR WASHER
1. Shut off both water faucets. Disconnect and drain water
inlet hoses.
2. If washer will be moved during freezing weather, follow
"Winter Storage Care" directions before moving.
3. Disconnect drain from drain system and drain any
remaining water into a pan or bucket. Disconnect drain
hose from back of washer.
4. Unplug power cord.
5. Place inlet hoses and drain hose inside washer basket.
6. Drape power cord over edge and into washer basket.
7. Place packing tray from original shipping materials back
inside washer. If you do not have packing tray, place
heavy blankets or towels into basket opening. Close lid
and place tape over lid and down front of washer. Keep
lid taped until washer is placed in new location.
REINSTALLING/USING WASHER AGAIN
To reinstall washer after non-use, vacation, winter storage,
or moving:
1. Refer to "Installation Instructions" to locate, level, and
connect washer.
2. Before using again, run washer through the following
recommended procedure:
To use washer again:
1. Flush water pipes and hoses. Reconnect water inlet
hoses. Turn on both water faucets.
Electrical Shock Hazard
Plug into agrounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
2. Plug in washer or reconnect power.
3. Run washer through BULKY ITEMS cycle to clean
washer and remove antifreeze, if used. Use only HE
High Efficiency detergent. Use 1/2 the manufacturer's
recommended amount for a medium-size load.
11

TROUBLESHOOTING
fFirst try the solutions suggested here or visit our website at www.amana.comihelp
for assistance and to possibly avoid a service call.
mfyou experience Possible Oauses Solution
Check the following for
proper installation or see
"Using Your Washer"
section.
Clicking or metallic
noises
Gurgling or humming
Humming
Check the following for
proper installation:
Not enough water
in washer
Feet may not be in contact with the
floor and locked.
Washer may not be level.
Load could be unbalanced.
Objects caught in washer
drain system.
Washer may be draining water.
The sensing light is on.
Washer not level.
Fill hoses not attached tightly.
Fill hose washers.
Drain hose connection.
Check household plumbing for leaks
or clogged sink or drain.
Washer not loaded as
recommended.
Load not completely covered
in water.
Front and rear feet must be in firm contact with floor, and washer
must be level to operate properly. Jam nuts must be tight
against the bottom of the cabinet. See "Installation Instructions."
Check floor for flexing or sagging. Ifflooring is uneven, a
3/4" (19 mm) piece of plywood under your washer will reduce
sound.
See "Level the Washer" in Installation Instructions.
Load dry items in loose heaps evenly around basket wall.
Adding wet items to washer or adding more water to basket
could unbalance washer.
Do not tightly pack. Avoid washing single items.
Use Bulky Items cycle for oversized, non-absorbent items such
as comforters or poly-filled jackets.
See "Cycle Guide" and "Using Your Washer" in this Use and
Care Guide.
Empty pockets before washing. Loose items such as coins
could fall between basket and tub or may block pump.
It may be necessary to call for service to remove items.
It is normal to hear metal items on clothing such as metal snaps,
buckles, or zippers touch against the stainless steel basket.
It is normal to hear the pump making a continuous humming
sound with periodic gurgling or surging as final amounts of
water are removed during the spin/drain cycles.
You may hear the hum of the sensing spins after you have
started the washer. This is normal. Sensing spins will take
several minutes before water is added to the washer.
Water may splash off basket if washer is not level. Check that
load is not unbalanced or tightly packed.
Tighten fill-hose connection.
Make sure all four fill hose flat washers are properly seated.
Pull drain hose from washer cabinet and properly secure it to
drainpipe or laundry tub.
Do not place tape over drain opening.
Water can back up out of a clogged sink or drainpipe. Check
all household plumbing for leaks (laundry tubs, drain pipe,
water pipes, and faucets.)
Unbalanced loading can cause basket to be out of alignment
and cause water to splash off tub. See "Using Your Washer"
for loading instructions.
This is normal operation for an HE low-water washer. The load
will not be completely underwater. The washer senses load sizes
and adds correct amount of water for optimal cleaning. See
"What's New Under the Lid."
IMPORTANT: Do not add more water to washer. J
12

TROUBLESHOOTING
Electrical Shock Hazard
Plug into agrounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
First try the solutions suggested here or visit our website at www.amana.comihelp
for assistance and to possibly avoid a service call.
if you experience Possible Causes Solution
Washer won't run or fill,
washer stops working,
or wash light remains
on (indicating that the
washer was unable to
fill appropriately)
Check for proper water supply.
Check proper electrical supply.
Normal washer operation.
Washer may be tightly packed.
Not using HE detergent or using too
much HE detergent.
Both hoses must be attached and have water flowing to inlet
valve.
Both hot and cold water faucets must be turned on.
Check that inlet valve screens have not become clogged.
Check for any kinks in inlet hoses, which can restrict water flow.
Plug power cord into a grounded 3=prong outlet.
Do not use an extension cord.
Ensure there is power to outlet.
Reset a tripped circuit breaker. Replace any blown fuses.
NOTE: If problems continue, contact an electrician.
Lid must be closed for washer to run.
Washer will pause during certain phases of cycle. Do not
interrupt cycle.
Washer may be stopped to reduce suds.
The washer senses the dry load with short spins that may take
2 to 3 minutes before water is added. You may hear the hum of
the spins. This is normal.
Remove several items, rearrange load evenly around the
washplate= Do not load garments directly over the center of the
washplate. Close lid and press START/Pause/Unlock Lid.
Add only 1 or 2 additional garments after washer has started.
Do not add more water to the washer.
Only use HE detergent= Suds from regular detergents can slow
or stop the washer= Always measure detergent and follow
detergent directions based on your load requirements.
To remove suds, cancel cycle. Select RINSE & SPIN. Press
START/Pause/Unlock Lid. Do not add more detergent. J
13

TROUBLESHOOTING
First try the solutions suggested here or visit our website at www.amana.comihelp
for assistance and to possibly avoid a service call.
Washer not draining/
spinning, loads are
still wet, or spin light
remains on (indicating
that the washer was
unable to pump out
water within
10 minutes)
Dry spots on load
after cycle
Incorrect or wrong
wash or rinse
temperatures
Load not rinsed
Empty pockets and use garment
bags for small items.
Using a cycle with a low spin speed.
The washer may be tightly packed or
unbalanced.
Check plumbing for correct
drain hose installation. Drain hose
extends into standpipe farther than
4.5" (114 mm).
Too much detergent causing suds to
slow or stop draining and spinning.
High speed spins extract more
moisture than traditional top-load
washers.
Check for proper water supply.
Energy-saving controlled
wash temperatures.
Check for proper water supply.
Not using HE detergent or using too
much HE detergent.
Washer may be tightly packed.
Small items may have been caught in pump or between basket
and tub, which can slow draining.
Cycles with lower spin speeds remove less water than cycles
with high spin speeds. Use the recommended cycle/speed spin
for your garment. To remove extra water in the load, select
Drain & Spin. Load may need to be rearranged to allow even
distribution of the load in the basket.
Tightly packed or unbalanced loads may not allow the washer
to spin correctly, leaving the load wetter than normal. Evenly
arrange the wet load for balanced spinning. Select the Drain &
Spin cycle to remove excess water. See "Using Your Washer"
for loading recommendations.
Check drain hose for proper installation. Use drain hose form
and securely attach to drainpipe or tub. Do not tape over drain
opening. Lower drain hose if the end is higher than 96" (2.4 m)
above the floor. Remove any clogs from drain hose.
Use only HE detergent. Always measure and follow detergent
directions for your load. To remove extra suds, select RINSE &
SPIN. Do not add detergent.
The high spin speeds combined with airflow during the final
spin can cause items near the top of the load to develop dry
spots during the final spin. This is normal.
Make sure hot and cold inlet hoses are not reversed.
Both hoses must be attached to both washer and faucet, and
have both hot and cold water flowing to inlet valve.
Check that inlet valve screens are not clogged.
Remove any kinks in hoses.
ENERGY STAR_ qualified washers use cooler wash and rinse
water temperatures than traditional topqoad washers. This
includes cooler hot and warm washes.
Make sure hot and cold inlet hoses are not reversed.
Both hoses must be attached and have water flowing to the
inlet valve.
Both hot and cold water faucets must be on.
Inlet valve screens on washer may be clogged.
Remove any kinks in the inlet hose.
The suds from regular detergent can keep washer from
operating correctly.
Use only HE detergent. Be sure to measure correctly.
Always measure detergent and follow detergent directions
based on load size and soil level.
The washer is less efficient at rinsing when tightly packed.
Load garments in loose heaps evenly around the washplate. Do
not load garments directly over the center of the washplate.
Add only 1 or 2 garments after washer has started. J
14

TROUBLESHOOTING
rFirst try the solutions suggested here or visit our website at www.amana.comihelp
for assistance and to possibly avoid a service call.
mfyou experience Possible Oauses Solution
Sand, pet hair, lint, etc.
on load after washing
Load is tangling
Heavy sand, pet hair, lint, and
detergent or bleach residues
may require additional rinsing.
Washer not loaded as recommended.
Not cleaning or Wash load not completely
removing stains covered in water.
Added more water to washer.
Washer not loaded as recommended.
Adding detergent on top of load.
Not washing like colors together.
Not using HE detergent or using too
much HE detergent.
Not using correct cycle for fabric type.
Not using dispenser or Downy Ball@.
Add an Extra Rinse to the selected cycle.
Not selecting Fabric Softener option.
Incorrect dispenser Clogged dispenser.
operation
x, j
See "Using Your Washer" section.
Select a cycle with a slower wash action and spin speed;
however, items will be wetter than those using a higher
speed spin. See the "Cycle Guide" to match your load with the
best cycle.
Load garments in loose heaps evenly around the washplate. Do
not load garments directly over the center of the washplate.
Reduce tangling by mixing types of load items. Use the
recommended cycle for the type of garments being washed.
Washer senses load size and adds correct amount of water.
This is normal and necessary for clothes to move.
Added water lifts the laundry off the washplate, resulting in less
effective cleaning.
Washer is less efficient at cleaning when tightly packed.
Load garments in loose heaps evenly around the washplate.
Load with dry items only.
Add only 1 or 2 garments after washer has started.
Add detergent, oxi products, and color-safe bleach to the
bottom of the basket before adding the load items.
Wash like colors together and remove promptly after the cycle is
complete to avoid dye transfer.
The suds from regular detergent can keep washer from
operating correctly.
Use only HE detergent. Be sure to measure correctly.
Always measure detergent and follow manufacturer's directions
based on load size and soil level.
Use a higher soil level cycle option and warmer wash
temperature to improve cleaning.
If using Quick Wash cycle, wash only a few items.
Use Super Wash and Normal Heavy cycle for tough cleaning.
See the "Cycle Guide" to match your load with the best cycle.
Use dispenser for chlorine bleach and Downy BaIP for fabric
softener to avoid staining.
Load dispenser before starting a cycle.
Do not add products directly onto load.
Always select Fabric Softener option. Cycles that use spray
rinsing will add additional water for proper fabric softener
dispensing when option is selected.
Use only liquid chlorine bleach in the bleach dispenser.
15

TROUBLESHOOTING
mfyou experience
Fabric Damage
Odors
First try the solutions suggested here or visit our website at www.amana.comihelp
for assistance and to possibly avoid a service call.
Sharp items were in pockets during Empty pockets, zip zippers, and snap or hook fasteners before
wash cycle, washing to avoid snags and tears.
Strings and straps could have tangled. Tie all strings and straps before starting wash load.
Items may have been damaged before Mend rips and broken threads in seams before washing.
washing.
Fabric damage can occur if washer is
tightly packed.
Liquid chlorine bleach may have been
added incorrectly.
Garment care instructions may not
have been followed.
Monthly maintenance not done as
recommended.
Using wrong or too much detergent.
Load garments in loose heaps evenly around the washplate.
Load with dry items only.
Use cycle designed for the fabrics being washed.
Add only 1 or 2 garments after washer is started.
Do not pour liquid chlorine bleach directly onto load. Wipe up
bleach spills.
Undiluted bleach will damage fabrics. Do not use more than
recommended by manufacturer.
Do not place load items on top of bleach dispenser when
loading and unloading washer.
Always read and follow garment manufacturer's care label
instructions. See the "Cycle Guide" to match your load with
the best cycle.
Run the Clean Washer with affresW'>cycle monthly.
See "Washer Care" in "Washer Maintenance."
Unload washer as soon as cycle is complete.
Use only HE detergent. Be sure to measure correctly. Always
follow the manufacturer's directions.
See "Washer Care" section.
Lid Locked light is The lid is not closed. Close the lid. The washer will not start or fill with the lid open.
flashing A cycle was stopped or paused using The washer may still be spinning. The lid will not unlock until the
the START/Pause/Unlock Lid button, basket has stopped spinning. This may take several minutes if
washing large loads or heavy fabrics.
16

WHIRLPOOL CORPORATIONLAUNDRYWARRANTY
LiMiTED WARRANTY
For one year from the date of purchase, when this major appliance is installed, operated, and maintained according to instructions
attached to or furnished with the product, Amana, Admiral, Estate, Inglis, or Roper brands of Whirlpool Corporation or Whirlpool
Canada LP (hereafter "Whirlpool") will pay for Factory Specified Replacement Parts and repair labor to correct defects in materials or
workmanship that existed when this major appliance was purchased.
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED
HEREIN. Service must be provided by a company designated by Whirlpool to service Amana, Admiral, Estate, Inglis, or Roper brand
appliances. This limited warranty is valid only in the United States or Canada and applies only when the major appliance is used in
the country in which it was purchased. This limited warranty is effective from the date of original consumer purchase. Proof of original
purchase date is required to obtain service under this limited warranty.
ITEMS EXCLUDED FROM WARRANTY
This limited warranty does not cover:
1. Replacement parts or repair labor if this major appliance is used for other than normal, single-family household use or when it is
used in a manner that is inconsistent to published user or operator instructions and/or installation instructions.
2. Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or
repair house fuses, or to correct house wiring or plumbing.
3. Service calls to repair or replace appliance light bulbs, air filters, or water filters. Consumable parts are excluded from warranty
coverage.
4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in
accordance with electrical or plumbing codes, or use of products not approved by Whirlpool.
5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage
results from defects in materials or workmanship and is reported to Whirlpool within 30 days from the date of purchase.
6. Pick up and delivery. This major appliance is intended to be repaired in your home.
7. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
8. Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an
authorized company designated by Whirlpool to service Amana, Admiral, Estate, Inglis, or Roper brands is not available.
9. The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance
with Whirlpool's published installation instructions.
10. Replacement parts or repair labor on major appliances with original model/serial numbers that have been removed, altered, or
cannot be easily determined.
The cost of repair or replacement under these excluded circumstances shall be borne by the customer.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, iNCLUDING ANY IMPLIED WARRANTY OF MERCHANTABiLiTY OR iMPLiED WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and
provinces do not allow limitations on the duration of implied warranties of merchantability or fitness, so this limitation may not apply
to you. This warranty gives you specific legal rights, and you also may have other rights that vary from state to state or province to
province.
DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY
Whirlpool makes no representations about the quality, durability, or need for service or repair of this major appliance other than the
representations contained in this Warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes
with this major appliance, you should ask Whirlpool or your retailer about buying an extended warranty.
LIMiTATiON OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LiMiTED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
WHIRLPOOL SHALL NOT BE LIABLE FOR iNCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow
the exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This
warranty gives you specific legal rights, and you also may have other rights that vary from state to state or province to province.
If outside the 50 United States and Canada, contact your authorized Whirlpool, Amana, Admiral, Estate, Inglis, or Roper dealer to
determine if another warranty applies.
If you think you need repair service, first see the "Troubleshooting" section of the Use & Care Guide. If you are unable to resolve
the problem after checking "Troubleshooting," additional help can be found by checking the "Assistance or Service" section or by
calling the following numbers for assistance: In the U.S.A., call 800=843=0304 for Amana brand products; 800-688=9920 for Admiral
brand products; 800=253=1301 for Estate brand products, or 800=447=6737 for Roper brand products. For assistance In Canada,
call: 800=807=6777 for Amana, Admiral, Estate, Inglis, or Roper brand products. 1/12
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in=warranty service.
Write down the following information about your major appliance
to better help you obtain assistance or service if you ever need
it. You will need to know your complete model number and serial
number. You can find this information on the model and serial
number label located on the product.
Dealer name
Address
Phone number
Model number
Serial number
Purchase date
17

S] CURIT] DE LA LAVEUSE
Votre s_curit_ et celle des autres est tr_s importante,
Nous donnons de nombreux messages de securit6 importants dans ce manuel et sur votre appareil menager.
Assurez=vous de toujours lire tousles messages de securit6 et de vous y conformer.
Voici le symbole d'alerte de s6curit6.
Ce symbole d'alerte de s6curit6 vous signale les dangers potentiels de deces et de blessures graves
& vous et & d'autres.
Tous les messages de securit6 suivront le symbole d'alerte de securit6 et le mot "DANGER" ou
"AVERTISSEMENT". Ces mots signifient :
Risque possible de d6ces ou de blessure grave si
vous ne suivez pas imm_diatement les instructions,
Risque possible de d_c_s ou de blessure grave
si vous ne suivez pas les instructions.
Tousles messages de s_curit6 vous diront quel est le danger potentiel et vous disent comment r6duire le risque de
blessure et ce qui peut se produire en cas de non-respect des instructions.
IMPORTANTES INSTRUCTIONS DE Si'CURITI_
AVERTISSEMENT :Pour r6duire les risques d'incendie, de choc electrique ou de blessures Iors de I'utilisation de la
laveuse, suivre les precautions fondamentales dont les suivantes :
[] Lire toutes les instructionsavant d'utiliser la laveuse.
[] Ne pas laver des articles qui ont et6 nettoy6s ou
lav6s avec de I'essence ou imbib6s d'essence,
solvants de nettoyage &sec, ou autres substances
inflammables ou explosives; ces substances
peuvent 6mettre des vapeurs susceptibles de
s'enflammer ou d'exploser.
[] Ne pas ajouter d'essence, solvant de nettoyage &
sec ou autre produit inflammable ou explosif dans
I'eau de lavage. Ces substances peuvent emettre
des vapeurs susceptibles de s'enflammer ou
d'exploser.
[] Dans certaines conditions, de I'hydrog_ne gazeux
peut se former dans un circuit d'eau chaude qui n'a
pas 6t6 utilis6 pendant 2 semaines ou plus. LE GAZ
HYDROG#NE EST EXPLOSIBLE. Si le circuit d'eau
chaude n'a pas 6t6 utilis6 pendant une telle p6riode,
avant d'utiliser la laveuse, ouvrir tous les robinets
d'eau chaude et laisser I'eau s'6couler pendant
plusieurs minutes par chaque robinet. Ceci
permettra 1'6vacuation de I'hydrog_ne gazeux
accumul6. Comme ce gaz est inflammable, ne pas
fumer ou utiliser une flamme nue au cours de cette
p6riode.
[] Ne pas laisser des enfants jouer sur ou &I'interieur de la
laveuse. Bien surveiller les enfants Iorsque la laveuse est
utilisee & proximite d'enfants.
[] Avant de mettre la laveuse au rebut ou hors de service,
enlever la porte ou le couvercle.
[] Ne pas tenter d'atteindre un article & I'interieur de la cuve de
la laveuse Iorsque le tambour, la cuve ou I'agitateur est en
mouvement.
[] Ne pas installer ou remiser cette laveuse & un endroit oQ elle
serait exposee aux intemperies.
[] Ne pas modifier les organes de commande.
[] Ne pas reparer ou remplacer un composant quelconque de
la laveuse, ni entreprendre une operation de service, si ce
n'est specifiquement recommande dans ce manuel ou darts
un manuel d'instructions de reparations destine & I'utilisateur;
ilest alors essentiel que la personne concernee comprenne
ces instructions et soit competente pour les executer.
[] Pour les instructionsde liaison &la terre, voir "Specifications
electriques" dans les instructionsd'installation.
CONSERVEZ CES INSTRUCTIONS
Avertissements de la proposition 65 de I'E':-tatde Californie :
AVERTISSEMENT : Ce produit contient au moins un produit chimique connu par I'!_tat de Californie pour 6tre & I'origine de
cancers.
AVERTISSEMENT : Ce produit contient au moins un produit chimique connu par I'#:tat de Californie pour 6tre b,I'origine de
malformations et autres deficiences de naissance.
18

QUOI DE NEUF SOUS LE COUVERCLE?
Nettoyer avec moins d'eau
Laveuse traditionnelle
de type agitateur
'Plateaude "
Laveuse a faible
consommation d'eau avec
plateau de lavage
La nouveaut6 la plus flagrante de cette nouvelle laveuse est son
systeme de lavage a faible consommation d'eau avec plateau
de lavage. La laveuse ajuste automatiquement le niveau d'eau
en fonction de la taille de la charge - nul besoin de s61ecteur de
niveau d'eau.
Charger les v_tements sans les tasser et de fagon uniforme
le long du plateau de lavage. Ne pas placer les v_tements
directement au centre du plateau de lavage - celui-ci doit 6tre
visible.
D6tection automatique
de faille de charge
Une fois que I'on d6marre le programme, le couvercle se
verrouille et la laveuse entame un processus de d6tection pour
d6terminer le niveau d'eau appropri6 a la charge. Cela peut
prendre plusieurs minutes avant que I'eau ne soit ajout6e. Voir
la description pas-a-pas dans la section "T6moins lumineux de
programme".
Vous entendrez le moteur faire tourner le panier par de brefs
mouvements d'impulsion pour bien imbiber la charge. Cette
m6thode de lavage avec faible consommation d'eau utilise
moins d'eau et d'6nergie qu'une laveuse traditionnelle de type
agitateur.
Choix du d6tergent appropri6
Utiliser uniquement des d6tergents Haute efficacit6.
Uemballage portera la mention "HE" ou "High Efficiency" (haute
efficacit6). Un lavage avec faible consommation d'eau produit
un exces de mousse avec un d6tergent non HE ordinaire. IIest
probable que I'utilisation d'un d6tergent ordinaire prolongera la
dur6e des programmes et r6duira la performance de ringage.
Ceci peut aussi entralner des d6faillances des composants et
une moisissure perceptible. Les d6tergents HE sont congus
pour produire la quantit6 de mousse ad6quate pour le meilleur
rendement. Suivre les recommandations du fabricant pour
d6terminer la quantit6 de d6tergent a utiliser.
Utiliser uniquement un detergent Haute efficacite (HE).
Nettoyage concentr6
Le systeme de lavage a faible consommation d'eau signifie un
lavage concentr6. Plut6t que de diluer du d6tergent comme dans
une laveuse de type agitateur, cette laveuse libere le d6tergent
directement sur les endroits souill6s.
Sons normaux pr6visibles
Au cours des diff6rents stades du programme de lavage, vous
entendrez peut-_tre des bruits que votre laveuse pr6c6dente
ne produisait pas. Par exemple, vous entendrez peut-6tre
un cliquetis au d6but du programme Iorsque le systeme de
verrouillage du couvercle effectue un test automatique. On
entendra diff6rents bourdonnements et bruits de frottements
rythmiques a mesure que I'impulseur d6place la charge. Parfois,
il est possible que la laveuse soit completement silencieuse,
Iorsqu'elle d6termine le niveau d'eau ad6quat ou qu'elle laisse
tremper les v_tements.
_,mesure que la laveuse imbibe et d6place la charge, les
v6tements se tassent dans le panier. Ceci est normal et ne
signifie pas que I'on doive rajouter des v_tements.
IMPORTANT : Le panier de la laveuse ne sera pas rempli d'eau,
comme avec votre pr6c6dente laveuse de type agitateur. II est
normal qu'une partie de la charge d6passe du niveau d'eau.
19

TABLEAU DE COMMANDE ET CARACTI RISTIQUES
\
?
STAIN TREAT
OTEMPERATURE (temperature de lavage)
La fonction de contr61e de temp6rature d6tecte et maintient
une temp6rature uniforme de I'eau en r6gulant le d6bit
d'arriv6e d'eau chaude et d'eau froide.
S61ectionner une temp6rature de lavage en fonction du type
de tissu et de salet6 h laver. Pour des r6sultats optimaux,
suivre les instructions sur 1'6tiquette du v_tement et utiliser
la temp6rature d'eau de lavage la plus chaude possible qui
reste sans danger pour le tissu.
. Les temp6ratures de I'eau tiede et de I'eau chaude
seront inf6rieures a celles de votre pr6c6dente laveuse.
. M_me avec un r6glage de lavage a I'eau froide (Cool), il
est possible que de I'eau tiede soit ajout6e a la laveuse
pour maintenir une temp6rature minimale.
OPTIONS DE PROGRAMMES
II est possible d'ajouter les options suivantes & la plupart
des programmes. Voir "Guide de programmes" pour plus
de d6tails.
EXTRA RINSE (ringage suppl_mentaire)
On peut utiliser cette option pour ajouter
automatiquement un second ringage a la plupart
des programmes.
FABRIC SOFTENER (assouplissant pour tissu}
Cette option doit _tre s61ectionn_e si I'on utilise de
I'assouplissant pour tissu durant un programme. EIle
permet que I'assouplissant soit distribu6 de fagon
uniforme au moment ad6quat du ringage.
FABRIC SOFTENER with EXTRA RINSE (assouplissant
pour tissu avec rin£age suppl_mentaire)
Cette option est activ6e & la fois pour les options Fabric
Softener (assouplissant pour tissu) et Extra Rinse (ringage
suppl6mentaire).
STAIN TREAT (nettoyage professionnel)
Cette option fournit une action de nettoyage
am61ior6e pour les taches tenaces. Ceci prolonge
la dur6e d'agitation et de trempage du programme.
BOUTON PROGRAMME DE LAVAGE
Tourner le bouton de programme de lavage pour
s61ectionner un programme correspondant a la charge de
linge. Voir "Guide de programmes" pour des descriptions
de programmes d6taill6es.
OBOUTON START/PAUSE/UNLOCK LID
(raise en marche/pause/d6verrouiller
du couvercle)
Appuyer sur ce bouton pour d6marrer le programme
s61ectionn_, puis appuyer de nouveau pour suspendre
le programme et d6verrouiller le couvercle.
REMAROUE : Si la laveuse tourne, le couvercle peut mettre
quelques minutes a se d6verrouiller. Appuyer pendant
3 secondes pour annuler un programme.
TleMOINS LUMINEUX DES PROGRAMMES
OOO O O O
sensing wash rinse final cycle lid
fill spin complete locked
Les t6moins lumineux indiquent la progression du
programme./_ chaque 6tape du processus, il est possible
que I'on remarque des pauses ou des sons diff6rents de
ceux des laveuses ordinaires.
SENSING FILL (remplissage avec d_tection}
Lorsqu'on appuie sur le bouton START/Pause/Unlock
Lid (mise en marche/pause/d6verrouiller du couvercle), la
laveuse effectue un test automatique sur le m6canisme de
verrouillage du couvercle. On entend un d6clic, le panier
effectue un 16get tour, et le couvercle se d6verrouille
brievement avant de se verrouiller a nouveau.
Une fois que le couvercle a 6t6 verrouill6 une seconde fois,
la laveuse essore lentement la charge s_che pour estimer
la taille de la charge. Ces essorages de d6tection peuvent
prendre 2 a 3 minutes avant que I'eau ne soit ajout6e a la
charge et il est possible que ces essorages 6mettent un bruit
de ronronnement. Si le t6moin de d6tection est allum6, alors
la laveuse fonctionne correctement. On entend le moteur
qui fait tourner le panier par de de courtes impulsions pour
mouiller I'int6gralit6 de la charge. La laveuse d6place ensuite
brievement la charge, fait une pause pour permettre & I'eau
de tremper la charge, et continue h ajouter de I'eau. Ce
processus peut se r6p6ter jusqu'h ce que la quantit6 d'eau
correcte ait 6t6 ajout6e h la charge. II est aussi possible que
I'on entende de I'eau couler dans le distributeur, ajoutant le
d6tergent a la charge.
REMARQUE : l_viter d'ouvrir le couvercle durant la
d6tection. Le processus de d6tection recommencera une
fois la laveuse remise en marche. Le t6moin de d_tection
s'allume _galement Iors des _tapes de trempage et de
lavage du programme. Ceci est normal.
20
