Amana W11158492A User manual

TOP-LOADING WASHER
USE AND CARE GUIDE
LAVEUSE À CHARGEMENT PAR LE DESSUS
GUIDE D’UTILISATION ET D’ENTRETIEN
Table of Contents
WASHER SAFETY...................................................................... 2
WHAT’S NEW UNDER THE LID? .............................................. 3
CONTROL PANEL AND FEATURES ......................................... 4
CYCLE GUIDE............................................................................ 6
USING YOUR WASHER............................................................. 7
WASHER MAINTENANCE....................................................... 10
TROUBLESHOOTING.............................................................. 12
WARRANTY.............................................................................. 17
ASSISTANCE OR SERVICE..................................BACK COVER
Table des matières
SÉCURITÉ DE LA LAVEUSE ................................................... 18
QUOI DE NEUF SOUS LE COUVERCLE? .............................. 19
TABLEAU DE COMMANDE ET CARACTÉRISTIQUES.......... 20
GUIDE DE PROGRAMMES ..................................................... 22
UTILISATION DE LA LAVEUSE ............................................... 23
ENTRETIEN DE LA LAVEUSE ................................................. 26
DÉPANNAGE ............................................................................ 28
GARANTIE................................................................................ 35
ASSISTANCE OU SERVICE............... COUVERTURE ARRIÈRE
Para una versión de estas instrucciones en español, visite www.amana.com.
Designed to use only HE High Efciency
detergents.
Conçue pour l’utilisation d’un détergent
haute efcacité seulement.
W11158492A
W11158493A-SP

2
You can be killed or seriously injured if you don't
immediately follow instructions.
You can be killed or seriously injured if you don't
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or
“WARNING.” These words mean:
WASHER SAFETY

3
WHAT’S NEW UNDER THE LID?
Your new washer will operate differently than your past agitator-style washer.
Use only High Efciency (HE) detergent.
Lid Lock
To allow for higher spin speeds, the lid will lock and the Lid
Locked light will turn on. When this light is lit, the lid is locked
and cannot be opened. When this light is blinking, the washer
is paused. When this light is off, the lid can be opened. After
a cycle is started, the washer will ll to the appropriate water
level. When the washer is done lling, it will start to agitate. If
you need to open the lid to add a garment after this point, the
lid will remain unlocked during the entire agitation portion of the
wash phase. The cycle will automatically pause when the lid is
opened, and the cycle will resume once the lid is closed. The
lid will lock before the spin phase begins. If you need to pause
or stop after this point, you must press START/PAUSE/Unlock
Lid and wait for the lid to unlock. The lid will only unlock after
washer movement has stopped. Depending on when in the
cycle you try to pause, it may take several seconds to several
minutes for the lid to unlock. Press START/PAUSE/Unlock Lid
to resume the cycle.
Water Level Options
Set the Water Level knob to the Auto Sensing setting and
the washer will ll to a level that ensures the load engages
the agitator. From this point, the electronic control will sense
the load and determine if additional water is needed.
Set the Water Level knob to the Deep Water Wash setting
and the washer will ll to the maximum water level.
NOTE: Deep Water Wash is not available in the Normal Regular
cycle mode. Selecting the Normal Regular cycle with the Deep
Water Wash setting will result in auto sensing of the water level.
Sensing
This washer will perform a series of spins to check for load
balance. During this time, a series of clicks and a whirring
noise signal that sensing technology is determining if there
is an off-balance load.
Normal Sounds You Can Expect
At different stages of the wash cycle, you may hear sounds
and noises that are different from those of your previous washer.
For example, you may hear a clicking and hum at the beginning
of the spin phase as the lid lock goes through a self-test. There
will be different kinds of humming sounds as the agitator tests
for load balance or moves the load. And sometimes, you may
hear nothing at all as the washer determines the correct water
level for your load or allows time for clothes to soak.
Spray Rinse
Select cycles default to a spray rinse. During these cycles,
you will hear water enter the washer as the tub spins, allowing
the rinse water to penetrate clothes. Check the “Cycle Guide”
for details.
Choosing the Right Detergent
Use only High Efciency detergents. The package will be marked
“HE” or “High Efciency.” Using non-HE detergent will likely
result in longer cycle times and reduced rinsing performance. It
may also result in component malfunction and, over time, buildup
of mold or mildew. HE detergents should be low-sudsing and
quick-dispersing to produce the right amount of suds for the
best performance. They should hold soil in suspension so it
is not redeposited onto clean clothes. Not all detergents labeled
as High Efciency are identical in formulation and their ability to
reduce suds. For example, natural, organic, or homemade HE
detergents may generate a high level of suds. Always follow the
detergent manufacturer’s instructions to determine the amount
of detergent to use.
IMPORTANT: The lid must be closed before the washer basket lls with water and for the wash cycle to start. If the lid is open and
lling stops, close the lid and press START/PAUSE/Unlock Lid to complete the cycle.
Accessories
Enhance your new washer with the following genuine Whirlpool
accessories. For more information on options and ordering, call
1-800-901-2042 or visit us at:
www.whirlpool.com/accessories. In Canada, call
1-800-807-6777 or visit us at www.whirlpoolparts.ca.
Fabric Softener Dispenser
This convenient fabric
softener dispenser connects
to the agitator and saves you
from manually adding fabric
softener during the rinse cycle.

4
CONTROL PANEL AND FEATURES
5
1
4
3
2
Not all features and options are available on all models.
Appearance may vary.
1WATER LEVEL
Set the Water Level knob to an Auto Sensing setting
and the washer will ll to a level that ensures the load
engages the agitator. From this point, the electronic
control will sense the load and determine if additional
water is needed.
Set the Water Level knob to a Deep Water Wash setting
and the washer will ll to the maximum water level.
NOTES:
■Cycle times will be longer due to extended ll times
when using the Deep Water Wash setting.
■Deep Water Wash settings are not available in the
Normal Regular cycle mode. Selecting the Normal
Regular cycle with a Deep Water Wash setting will
result in auto sensing of the water level.
2WASH TEMPERATURE
Wash Temperature senses and maintains uniform water
temperatures by regulating incoming hot and cold water.
Select a wash temperature based on the type of fabric
and soils being washed. For best results and following
the garment label instructions, use the warmest wash
water safe for your fabric.
NOTES:
■On some models and cycles, warm and hot water
may be cooler than your previous washer.
■Even in a cold and cool water wash, some warm
water may be added to the washer to maintain a
minimum temperature. All rinses are cold.
3WASH CYCLE KNOB
Use the Wash Cycle knob to select cycles on your washer.
See the “Cycle Guide” for detailed descriptions of cycles.
4START/PAUSE/UNLOCK LID BUTTON
Press to start the selected cycle; press again to pause
the cycle and unlock the lid.
NOTE: If the washer is spinning, it may take several
minutes to unlock the lid. Press and hold for 3 seconds
to cancel a cycle.
5CYCLE STATUS LIGHTS INDICATOR
The Cycle Status lights show the progress of a cycle.
At each stage of the process, you may notice sounds
or pauses that are different from your previous washer.
SENSING/FILL
When the Start/Pause/Unlock Lid button is pressed,
and the Water Level knob is set to Auto Sensing, the
washer will ll and begin sensing to determine load
size and balance.
Once sensing is complete, the washer will ll to the
appropriate level for the detected load size and then
begin the wash phase of the cycle.
NOTE: Sensing and wash phases will be paused by
opening the unlocked lid. Close the lid to resume the
cycle. If the lid is left open for more than 10 minutes,
the washer will cancel the cycle and pump out the
water. The lid will lock after the wash phase to begin
the initial spinout and remain locked for the remainder
of the cycle.

5
Appearance
may vary.
Appearance
may vary.
WASH
The washer will ll to the correct water level based on
the load size and the Water Level selection. Certain
cycles may agitate during the ll process to boost
cleaning. You will hear the agitator rotate, followed
by a pause lasting several seconds. When the wash
cycle begins, you will hear the agitator increase
speed. The motor sounds may change at different
stages in the wash cycle while the washer performs
different wash actions.
RINSE
Certain cycles use a spray rinse, which adds water
to the tub while the basket spins. You may hear the
motor turning on briey (short hum) to move the
basket while lling.
FINAL SPIN
The washer spins the load at increasing speeds for
proper water removal, based on the selected cycle.
CYCLE COMPLETE
Once the cycle is complete, this light will come on.
Remove the load promptly for best results.
LID LOCKED
The lock feature allows for higher
spin speeds. When the Lid Locked
light is lit, the lid is locked and cannot
be opened without pausing the cycle.
When the light is off, the lid can be
opened.
To open the lid after it has been
locked, press START/PAUSE/Unlock
Lid. The lid will unlock once the
washer movement has stopped.
This may take several minutes if
the load was spinning at a high
speed. Press START/PAUSE/Unlock
Lid again to resume the cycle.

6
CYCLE GUIDE
For best fabric care, choose the cycle that best ts the load being washed. Recommended settings for best performance are shown
in bold. Each cycle listing also includes a performance chart rating its cleaning power, gentleness on items, and resource efciency.
Not all cycles and options are available on all models. Not all settings and options are available on each cycle.
*All rinses are cold.
†Efcient use of resources, such as energy and water.
Items to wash: Cycle: Wash Temperature:* Cycle Details:
Large items such
as sheets, sleeping
bags, small
comforters, jackets,
small washable rugs
Bulky Items
& Sheets Hot Warm
Cool
Cold
Tap Cold
Use this cycle to wash large items such as jackets and small
comforters. The washer will ll with enough water to wet down the load
before the wash portion of the cycle begins, and uses a higher water
level than other cycles.
Sturdy fabrics,
colorfast items,
towels, sheets,
jeans
Normal Heavy Hot
Warm
Cool
Cold
Tap Cold
Use this cycle for heavily soiled or sturdy fabrics.
Cleaning
Gentleness
Efciency†
Good Best
Cottons, linens,
and mixed garment
loads
Normal
Regular Hot Warm
Cool
Cold
Tap Cold
Use this cycle for normally soiled cottons and mixed-fabric loads.
NOTE: Deep Water Wash is not available in the Normal Regular cycle
mode. Selecting the Normal Regular cycle with the Deep Water Wash
setting will result in auto sensing of the water level.
Cleaning
Gentleness
Efciency†
Good Best
No-iron fabrics,
cottons, permanent
press, linens,
synthetics
Casual Hot
Warm
Cool
Cold
Tap Cold
Use this cycle to wash loads of no-iron fabrics such as sport shirts,
blouses, casual business clothes, permanent press, and blends.
Cleaning
Gentleness
Efciency†
Good Best
Machine-wash silks,
lingerie, washable
wools
Delicate Hot
Warm
Cool
Cold
Tap Cold
Use this cycle to wash lightly soiled garments indicating “Machine
Washable Silks” or “Gentle” cycle on the care label. Place small items
in mesh garment bags before washing.
Cleaning
Gentleness
Efciency†
Good Best
Swimsuits and
items requiring
rinsing without
detergent
Rinse/Spin Cold rinse only Combines a rinse and high-speed spin for loads requiring an additional
rinse cycle or to complete a load after power interruption. Also use for
loads that require rinsing only.
No clothes in
washer Clean Washer with affresh®Hot Warm
Cool
Cold
Tap Cold
Use this cycle every 30 washes to keep the inside of your washer
fresh and clean. This cycle uses a higher water level. Use with affresh®
Washer Cleaner tablet or liquid chlorine bleach to thoroughly clean
the inside of your washer. This cycle should not be interrupted. See
“Washer Care” in the “Washer Maintenance” section.
IMPORTANT: Do not place garments or other items in the washer
during the Clean Washer with affresh®cycle. Use this cycle with an
empty washtub.
Hand-wash
garments or
dripping wet items
Drain/Spin N/A This cycle uses a spin to shorten drying times for heavy fabrics or
special-care items washed by hand. Use this cycle to drain washer
after cancelling a cycle or completing a cycle after a power failure.
Cleaning
Gentleness
Efciency†
Good Best

7
■Empty pockets. Loose change, buttons, or any small
object can pass under the agitator and become trapped,
causing unexpected sounds.
■Sort items by recommended cycle, water temperature,
and colorfastness.
■Separate heavily soiled items from lightly soiled.
■Separate delicate items from sturdy fabrics.
■Do not dry garments if stains remain after washing,
because heat can set stains into fabric.
■Treat stains promptly.
■Close zippers, fasten hooks, tie strings and sashes, and
remove non-washable trim and ornaments.
■Mend rips and tears to avoid further damage to items
during washing.
Helpful Tips:
■When washing waterproof or water-resistant items,
load evenly.
■Use mesh garment bags to help avoid tangling when
washing delicate or small items.
■Turn knits inside-out to avoid pilling. Separate lint-takers
from lint-givers. Synthetics, knits, and corduroy fabrics
will pick up lint from towels, rugs, and chenille fabrics.
NOTE: Always read and follow fabric care label instructions
to avoid damage to your garments.
1. Sort and prepare your laundry
Add a measured amount of HE
detergent or single-dose laundry
packet into the basket.
If using Oxi-type boosters, color-safe
bleach,or fabric softener crystals, add
to the bottom of the washer basket before adding clothes.
IMPORTANT: Use only High Efciency detergents. The
package will be marked “HE” or “High Efciency.” Using
non-HE detergent will likely result in longer cycle times and
reduced rinsing performance. It may also result in component
malfunction and, over time, buildup of mold or mildew. HE
detergents should be low-sudsing and quick-dispersing to
produce the right amount of suds for the best performance.
They should hold soil in suspension so it is not redeposited
onto clean clothes. Not all detergents labeled as High
Efciency are identical in formulation and their ability to
reduce suds. For example, natural, organic, or homemade
HE detergents may generate a high level of suds.
NOTE: Follow the manufacturer’s instructions to determine
the amount of laundry products to use.
2. Add laundry products
USING YOUR WASHER

8
On models with a fabric softener
dispenser:
Pour a measured amount of liquid fabric
softener into dispenser; always follow
manufacturer’s directions for the correct
amount of fabric softener based on your
load size. Dilute liquid fabric softener by
lling the dispenser with warm water until
liquid reaches the underside of the rim. See
“Max Fill” line arrows.
IMPORTANT: You must set the Water Level
knob to Auto Sensing + Extra Rinse with
Fabric Softener, or Deep Water Wash +
Extra Rinse with Fabric Softener to ensure
proper distribution of the fabric softener
during the nal rinse portion of the cycle.
On models without a fabric softener dispenser:
You will add fabric softener manually during the nal rinse
portion of the cycle. See step 10 for complete instructions.
Liquid
Chlorine Bleach
4. Add liquid chlorine bleach
to dispenser, if desired
Do not overll, dilute, or use more than 1 cup (236 mL) of liquid
chlorine bleach. Do not use color-safe bleach or Oxi products in
the same cycle with liquid chlorine bleach.
Load garments in loose heaps evenly
around the basket wall. For best results,
do not pack the load tightly. Do not wrap
large items such as sheets around the
agitator; load them in loose piles around
the sides of the basket. Try mixing
different-sized items to reduce tangling.
IMPORTANT: Do not tightly pack or force
items into washer. Items need to move freely
for best cleaning and to reduce wrinkling and tangling.
3. Load laundry into washer
6. Select WATER LEVEL
Set the Water Level knob to an Auto Sensing setting and
the washer will ll to a level that ensures the load engages
the agitator. From this point, the electronic control will sense
the load and determine if additional water is needed. Select a
water level with an extra rinse for enhanced rinsing performance.
Set the Water Level knob to a Deep Water Wash setting and the
washer will ll to the maximum water level. Select a water level
with an extra rinse for enhanced rinsing performance.
Appearance may vary.
5. Add fabric softener, if desired
MAX FILL

9
7. Select WASH TEMPERATURE
Select the wash temperature by turning the Wash Temperature
knob to the desired setting. All rinses are tap cold.
NOTE: Always read and follow fabric care label instructions
to avoid damage to your items.
Wash Temp Suggested Fabrics
Hot
Some cold water is added to save
energy. This may be cooler than
your hot water heater setting.
Whites and pastels
Durable items
Heavy soils
Warm
Some cold water may be added,
so this will be cooler than what
your previous washer provided.
Bright colors
Moderate to light soils
Cool
Warm water may be added to
assist in soil removal and to
help dissolve detergents. Cool
is slightly warmer than cold.
Colors that bleed or fade
Light soils
Cold
This is the temperature from your
faucet. If your tap cold water is
very cold, warm water may be
added to assist in soil removal
and help dissolve detergent.
Dark colors that bleed or fade
Light soils
Tap Cold
This is the temperature from your
faucet.
Dark colors that bleed or fade
Light soils
Appearance may vary.
NOTES:
■Cycle times will be longer due to extended ll times when
using a Deep Water Wash setting.
■Deep Water Wash settings are not available in the Normal
Regular cycle mode. Selecting the Normal Regular cycle
with a Deep Water Wash setting will result in auto sensing of
the water level.
IMPORTANT: Always select a water level setting with an
extra rinse when using fabric softener. The extra rinse options
use additional water and agitation for proper fabric softener
distribution.
Turn cycle knob to choose your wash cycle. For more
information, see the “Cycle Guide.”
8. Select cycle
Appearance may vary.
9. Press START/PAUSE/UNLOCK LID
to begin wash cycle
Press START/PAUSE/Unlock Lid to start the wash cycle.
When the cycle has nished, the Cycle Complete indicator will
light. Promptly remove items after the cycle has completed
to avoid odor, reduce wrinkling, and rusting of metal hooks,
zippers, and snaps.
Unlocking the lid to add garments
If you need to open the lid to add one or two missed
garments:
Press START/PAUSE/Unlock Lid; the lid will unlock once
the washer movement has stopped. This may take several
minutes if the load was spinning at a high speed. Then close
the lid and press START/PAUSE/Unlock Lid again to restart
the cycle.
NOTE: Washer will not ll with the lid open.
IMPORTANT: If lid is left open for more than 10 minutes, the
water will pump out automatically.
Manual soak
If you would like to manually soak your garments at any time
during the wash portion of the cycle, press START/PAUSE/
Unlock Lid and leave the lid closed. Once your desired soak
time has elapsed, press START/PAUSE/Unlock Lid again to
continue the cycle. As long as the lid remains closed, your
soak time can be longer than 10 minutes. However, if the lid
is opened during the soak and remains open for more than
10 minutes, the water will pump out automatically.
Appearance may vary.

10
Replace inlet hoses after ve years of use to reduce the risk
of hose failure. Periodically inspect and replace inlet hoses
if bulges, kinks, cuts, wear, or leaks are found.
When replacing your inlet hoses, mark the date of replacement
on the label with a permanent marker.
NOTE: This washer does not include inlet hoses. See the
Installation Instructions for more information.
WATER INLET HOSES
WASHER MAINTENANCE
WASHER CARE
Recommendations to Help Keep Your Washer Clean
and Performing at its Best
1. Always follow the detergent manufacturer’s instructions
regarding the amount of detergent to use. Never use more
than the recommended amount because that may increase
the rate at which detergent and soil residue accumulate
inside your washer. This may result in undesirable odor.
2. Use warm and hot wash water settings sometimes (not
exclusively cold water washes) because they do a better
job of controlling the rate at which soils and detergent
accumulate.
3. Always leave the washer lid open between uses to help
dry out the washer and prevent the buildup of odor-causing
residue.
Cleaning Your Top-Loading Washer
Read these instructions completely before beginning the
routine cleaning processes recommended below. This washer
maintenance procedure should be performed, at a minimum,
once per month or every 30 wash cycles, whichever occurs
sooner, to control the rate at which soils and detergent may
otherwise accumulate in your washer.
Cleaning the Inside of the Washer
To keep your washer odor-free, follow the usage instructions
provided above, and use this recommended monthly cleaning
procedure:
Clean Washer with affresh® Cycle
This washer has a special cycle that uses higher water
volumes in combination with affresh® Washer Cleaner or liquid
cholorine bleach to clean the inside of the washer.
WASHER CARE (cont.)
Begin Procedure
1. Procedure for using affresh®Washer Cleaner
(recommended for best performance):
a. Open the washer lid and remove any clothing or items.
b.Place an affresh®Washer Cleaner tablet in the bottom of
the washer basket.
c. Do not place an affresh®Washer Cleaner tablet in the
detergent dispenser.
d.Do not add any detergent or other chemical to the washer
when following this procedure.
e. Close the washer lid.
f. Select the CLEAN WASHER with affresh® cycle.
g. Press START/PAUSE/Unlock Lid to start the cycle.
NOTE: For best results, do not interrupt cycle. If cycle must be
interrupted, press START/PAUSE/Unlock Lid once. After the cycle
has stopped, run a Rinse/Spin cycle to rinse cleaner from washer.
2. Procedure for using chlorine bleach (alternative):
a. Open the washer lid and remove any clothing or items.
b. Add 1 cup (236 mL) of liquid chlorine bleach to the
bleach compartment.
NOTE: Use of more liquid chlorine bleach than is
recommended above could cause washer damage over time.
c. Close the washer lid.
d. Do not add any detergent or other chemical to the washer
when following this procedure.
e. Select the CLEAN WASHER with affresh® cycle.
f. Press START/PAUSE/Unlock Lid to start the cycle.
The Clean Washer with affresh® cycle operation is
described below.
NOTE: For best results, do not interrupt cycle. If cycle
must be interrupted, press START/PAUSE /Unlock Lid once.
After the cycle has stopped, run a Rinse/Spin cycle to rinse
cleaner from washer.
Description of Clean Washer with affresh®Cycle Operation
1. This cycle will ll to a water level higher than in normal wash
cycles to provide rinsing at a level above the water line for
normal wash.
2. During this cycle, there will be some agitation and spinning
to increase the removal of soils.
3. After this cycle is complete, leave the lid open to allow for
better ventilation and drying of the washer interior.
10. Manually add fabric softener,
if desired
NOTE: If your washer does not have a fabric softener
dispenser, add fabric softener manually.
During the nal rinse, wait until the washer has completed
lling, then press START/PAUSE/Unlock Lid to pause the
washer. Lift the lid and add the measured recommended
amount of liquid fabric softener to the load. Do not use more
than the recommended amount. Close the lid and press
START/PAUSE/Unlock Lid again to start the washer.
IMPORTANT: You must set the Water Level
knob to Auto Sensing + Extra Rinse or Deep
Water Wash + Extra Rinse when manually
adding fabric softener. These extra rinse
options use additional water and agitation
for proper fabric softener distribution during
the nal rinse portion of the cycle.

11
WASHER CARE (cont.)
Cleaning the Dispensers
After a period of using your washer, you may nd some residue
buildup in the washer’s dispensers. To remove residue from
the dispensers, wipe them with an affresh®Machine Cleaning
Wipe or a damp cloth and towel dry. Do not attempt to remove
the dispensers or trim for cleaning. The dispensers and trim
are not removable. If your model has a dispenser drawer,
however, remove the drawer and clean it with an affresh®
Machine Cleaning Wipe or a damp cloth and towel dry before
or after you run the Clean Washer with affresh®cycle. Use an
all-purpose surface cleaner, if needed.
Cleaning the Outside of the Washer
Use an affresh®Machine Cleaning Wipe, or a soft, damp cloth
or sponge to wipe away any spills. Use an affresh®Machine
Cleaning Wipe or only mild soaps or cleaners when cleaning
external washer surfaces.
IMPORTANT: To avoid damaging the washer’s nish, do not
use abrasive products.
Operate your washer only when you are home. If moving or
not using your washer for a period of time, follow these steps:
1. Unplug or disconnect power to washer.
2. Turn off water supply to washer to avoid ooding due
to water pressure surge.
NON-USE AND VACATION CARE
WINTER STORAGE CARE
IMPORTANT: To avoid damage, install and store your washer
where it will not freeze. Because some water may stay in
hoses, freezing can damage the washer. If storing or moving
during freezing weather, winterize your washer.
To winterize washer:
1. Shut off both water faucets; disconnect and drain water
inlet hoses.
2. Put 1 qt. (1 L) of R.V.-type antifreeze in the basket and run
washer on Rinse/Spin cycle for about 30 seconds to mix
antifreeze and remaining water.
3. Unplug washer or disconnect power.
TRANSPORTING YOUR WASHER
1. Shut off both water faucets. Disconnect and drain water
inlet hoses.
2. If washer will be moved during freezing weather, follow
“Winter Storage Care” directions before moving.
3. Disconnect drain hose from drain system and drain any
remaining water into a pan or bucket. Disconnect drain
hose from the back of the washer.
4. Unplug power cord.
5. Place inlet hoses and drain hose inside the washer basket.
6. Drape power cord over edge and into the washer basket.
7. Place packing tray from original shipping materials back
inside washer. If you do not have a packing tray, place
heavy blankets or towels into basket opening. Close lid
and place tape over lid and down front of washer. Keep
lid taped until washer is placed in new location. Transport
washer in upright position.
REINSTALLING/USING WASHER AGAIN
To reinstall washer after non-use, vacation, winter storage,
or moving:
1. Refer to the Installation Instructions to locate, level, and
connect washer.
2. Before using again, run washer through the following
recommended procedure:
To use washer again:
1. Flush water pipes and hoses. Reconnect water-inlet hoses.
Turn on both water faucets.
2. Plug in washer or reconnect power.
3. Run washer through Bulky Items & Sheets cycle to clean
washer and remove antifreeze if used. Use only HE
High Efciency detergent. Use half the manufacturer’s
recommended amount of detergent for a medium-size load.

12
TROUBLESHOOTING
If you experience Possible Causes Solution
Vibration or Off-Balance
Check the following for
proper installation or
see the “Using Your
Washer” section.
Feet may not be in contact with the
oor and locked. Front and rear feet must be in rm contact with oor, and washer must be level to operate properly.
Washer may not be level. Check oor for exing or sagging. If ooring is uneven, a 3/4"
(19 mm) piece of plywood under your washer will reduce sound.
See the “Level the Washer” section in the Installation Instructions.
Load could be unbalanced. Load dry items in loose heaps evenly around basket wall. Adding
wet items to washer or adding more water to basket could
unbalance washer.
Wash smaller loads to reduce imbalance.
Do not tightly pack. Avoid washing single items.
Use Bulky Items & Sheets cycle for oversized, non-absorbent items
such as jackets and small comforters. See the “Cycle Guide.”
See the “Cycle Guide” and the “Using Your Washer” section.
Noises
Clicking or metallic
noises Objects caught in washer drain system. Empty pockets before washing. Loose items such as coins could fall between basket and tub or may block pump. It may be
necessary to call for service to remove items.
It is normal to hear metal items on clothing such as metal snaps,
buckles, or zippers touch against the basket.
Gurgling or humming Washer may be draining water. It is normal to hear the pump making a continuous humming
sound with periodic gurgling or surging as nal amounts of
water are removed during the Drain/Spin cycle.
Humming Load sensing may be occurring. You may hear the hum of the sensing spins after you have
started the washer. This is normal.
Water Leaks
Check the following for
proper installation: Washer not level. Water may splash off basket if washer is not level. Check that load is not unbalanced or tightly packed.
Fill hoses not attached tightly. Tighten ll-hose connection.
Fill hose washers. Make sure all four ll hose at washers are properly seated.
Drain hose connection. Pull drain hose from washer cabinet and properly secure it to
drainpipe or laundry tub.
Check household plumbing for leaks
or clogged sink or drain. Water can back up out of a clogged sink or drainpipe. Check all household plumbing for leaks (laundry tubs, drain pipe, water
pipes, and faucets).
Washer not loaded as recommended. Improper loading can cause basket to be out of alignment and
cause water to splash off tub. See the “Using Your Washer”
section for loading instructions.
Washer not performing as expected
Not enough water
in washer Load not completely covered in water. This is normal operation for an HE low-water washer. If the Water Level knob is set to the Auto Sensing setting, the load will not be
completely under water. The washer senses load sizes and adds
the correct amount of water for optimal cleaning.
IMPORTANT: Do not add more water to washer. Adding water lifts
the items off the washplate, resulting in less-effective cleaning .
Use the Bulky Items & Sheets cycle or set the Water Level knob
to the Deep Water Wash setting. See the “What’s New under the
Lid” section and the “Cycle Guide” to match your load with the
best cycle.
NOTE: Deep Water Wash settings are not available in the Normal
Regular cycle mode. Selecting the Normal Regular cycle with a
Deep Water Wash setting will result in auto sensing of the water
level.
Run Clean Washer with affresh®cycle to optimize the water level
and wash performance due to soil buildup in washer basket.
First try the solutions suggested here to possibly avoid a service call.

13
TROUBLESHOOTING
If you experience Possible Causes Solution
Washer not performing as expected (cont.)
Washer won’t run or ll,
washer stops working,
or wash light remains
on (indicating that the
washer was unable
to ll appropriately)
Check for proper water supply. Both hoses must be attached and have water owing to
inlet valve.
Both hot and cold water faucets must be turned on.
Check that inlet valve screens have not become clogged.
Check for any kinks in inlet hoses, which can restrict water ow.
First try the solutions suggested here to possibly avoid a service call.
Washer won’t run or ll,
washer stops working,
or wash light remains
on (indicating that the
washer was unable to ll
appropriately) (cont.)
Check proper electrical supply. Plug power cord into a grounded 3 prong outlet.
Do not use an extension cord.
Ensure there is power to outlet.
Reset a tripped circuit breaker. Replace any blown fuses.
NOTE: If problems continue, contact an electrician.
Normal washer operation. Lid must be closed for washer to run.
Washer will pause during certain phases of cycle. Do not
interrupt cycle.
Washer may be tightly packed. Remove several items, rearrange load evenly in basket. Close lid
and press START/PAUSE/Unlock Lid.
Do not add more than one or two additional items after cycle has
started to avoid tightly packing or unbalancing.
Do not add more water to the washer.
Washer not draining/
spinning, loads are still
wet, or spin light remains
on (indicating that the
washer was unable to
pump out water within
10 minutes)
Small items may have been caught
in pump or between basket and tub,
which can slow draining.
Empty pockets and use garment bags for small items.
Use a cycle with a low spin speed. Cycles with lower spin speeds remove less water than cycles
with high spin speeds. Use the recommended cycle/spin speed
for your garment. To remove extra water in the load, select Drain/
Spin. Load may need to be rearranged to allow even distribution
of the load in the basket.
The washer may be tightly packed
or unbalanced. Tightly packed or unbalanced loads may not allow the washer to spin correctly, leaving the load wetter than normal. Evenly
arrange the wet load for balanced spinning. Select the Drain/
Spin cycle to remove excess water. See the “Using Your Washer”
section for loading recommendations.
Check plumbing for correct drain
hose installation. Drain hose
extends into standpipe farther
than 4.5" (114 mm).
Check drain hose for proper installation. Use drain hose form
and securely attach to drainpipe or tub. Do not tape over drain
opening. Lower drain hose if the end is higher than 96" (2.4 m)
above the oor. Remove any clogs from drain hose.
Too much detergent causing suds to
slow or stop draining and spinning. Always measure and follow detergent directions for your load. To remove extra suds, select Rinse/Spin. Do not add detergent.

14
TROUBLESHOOTING
If you experience Possible Causes Solution
Washer not performing as expected (cont.)
Dry spots on load
after cycle High spin speeds extract more moisture than your previous washer. The high spin speeds combined with airow during the nal spin can cause items near the top of the load to develop dry
spots during the nal spin. This is normal.
Washer may be tightly packed. Use the Bulky Items & Sheets cycle or set the Water Level knob
to the Deep Water Wash setting. See the “Cycle Guide” to match
your load with the best cycle.
NOTE: Deep Water Wash is not available in the Normal Regular
cycle mode. Selecting the Normal Regular cycle with the Deep
Water Wash setting will result in auto sensing of the water level.
Added extra garments to the load
after the sensing/ll phase.
Add only one or two additional garments after washer has started.
Incorrect or wrong
wash or rinse
temperatures
Check for proper water supply. Make sure hot and cold inlet hoses are not reversed.
Both hoses must be attached to both washer and faucet, and have
both hot and cold water owing to inlet valve.
Check that inlet valve screens are not clogged.
Remove any kinks in hoses.
Energy-saving controlled
wash temperatures.
This washer uses cooler wash and rinse water temperatures than
your previous washer. This includes cooler hot and warm washes.
Load not rinsed Check for proper water supply. Make sure hot and cold inlet hoses are not reversed.
Both hoses must be attached and have water owing to the
inlet valve.
Both hot and cold water faucets must be on.
Inlet valve screens on washer may be clogged.
Remove any kinks in the inlet hose.
Not using HE detergent or using too
much HE detergent. The suds from too much detergent can keep washer from operating correctly. Always measure detergent and follow
detergent directions based on load size and soil level.
Washer not loaded as recommended. The washer is less efcient at rinsing when tightly packed.
Load garments in loose heaps evenly around the basket wall.
Load with dry items only.
Use cycle designed for the fabrics being washed.
Add only one or two additional garments after washer has
started.
Use the Bulky Items & Sheets cycle or set the Water Level knob
to the Deep Water Wash setting. See the “Cycle Guide” to match
your load with the best cycle.
NOTE: Deep Water Wash is not available in the Normal Regular
cycle mode. Selecting the Normal Regular cycle with the Deep
Water Wash setting will result in auto sensing of the water level.
Sand, pet hair, lint,
etc., on load after
washing
Heavy sand, pet hair, lint, and
detergent or bleach residues may
require additional rinsing.
Select Rinse/Spin.
Load is tangling Washer not loaded as recommended. See the “Using Your Washer” section.
Select a cycle with a slower wash action and spin speed;
however, items will be wetter than those using a higher speed
spin. Use the Bulky Items & Sheets cycle or set the Water Level
knob to the Deep Water Wash setting. See the “Cycle Guide”
to match your load with the best cycle.
NOTE: Deep Water Wash is not available in the Normal Regular
cycle mode. Selecting the Normal Regular cycle with the Deep
Water Wash setting will result in auto sensing of the water level.
Load garments in loose heaps evenly around the basket wall.
Reduce tangling by mixing types of load items. Use the
recommended cycle for the type of garments being washed.
First try the solutions suggested here to possibly avoid a service call.

15
TROUBLESHOOTING
If you experience Possible Causes Solution
Washer not performing as expected (cont.)
Not cleaning or
removing stains Added more water to washer.
Washer senses load size and adds correct amount of water. This
is normal and necessary for clothes to move. It is normal for the
wash load to be not completely covered in water. Added water lifts
the laundry off the washplate, resulting in less effective cleaning.
Washer not loaded as recommended. Washer is less efcient at cleaning when load is tightly packed.
Load garments in loose heaps evenly around the basket wall.
Load with dry items only.
Add only one or two additional garments after washer has started.
Adding detergent on top of load. Add detergent, Oxi products, and color-safe bleach to the
bottom of the basket before adding the load items.
Not using HE detergent or using too
much HE detergent.
The suds from regular detergent can keep washer from operating
correctly.
Use only HE detergent. Be sure to measure correctly.
Always measure detergent and follow manufacturer’s directions
based on load size and soil level.
Not using correct cycle for fabric type. Use a higher soil level cycle option and warmer wash
temperature to improve cleaning.
Use Heavy cycle for tough cleaning. See the “Cycle Guide”
to match your load with the best cycle.
Not using dispenser. Use dispenser to avoid chlorine bleach staining.
Load dispenser before starting a cycle.
Avoid overlling.
Do not add chlorine bleach directly onto load.
Not washing like colors together. Wash like colors together and remove promptly after the cycle
is complete to avoid dye transfer.
Not selecting a water level setting
with an extra rinse when using fabric
softener.
Always select a water level setting with an extra rinse when using
fabric softener. Cycles that have a spray rinse require this option
for proper fabric softener distribution.
Incorrect dispenser
operation Clogged dispenser. Load dispenser before starting a cycle.
Use only liquid chlorine bleach in the bleach dispenser.
Fabric damage Sharp items were in pockets during
wash cycle. Empty pockets, zip zippers, and snap or hook fasteners before washing to avoid snags and tears.
Strings and straps could have tangled. Tie all strings and straps before starting wash load.
Items may have been damaged
before washing. Mend rips and broken threads in seams before washing.
Fabric damage can occur if load is
tightly packed. Load garments in loose heaps evenly around the basket wall. Load with dry items only.
Use cycle designed for the fabrics being washed.
Use the Bulky Items & Sheets cycle or set the Water Level knob
to the Deep Water Wash setting. See the “What’s New under the
Lid” section and the “Cycle Guide” to match your load with the
best cycle.
NOTE: Deep Water Wash settings are not available in the Normal
Regular cycle mode. Selecting the Normal Regular cycle with a
Deep Water Wash setting will result in auto sensing of the water
level.
Add only one or two additional garments after washer has
started.
Liquid chlorine bleach may have
been added incorrectly. Do not pour liquid chlorine bleach directly onto load. Wipe up bleach spills.
Undiluted bleach will damage fabrics. Do not use more than
recommended by manufacturer.
First try the solutions suggested here to possibly avoid a service call.

16
TROUBLESHOOTING
If you experience Possible Causes Solution
Washer not performing as expected (cont.)
Fabric damage (cont.) Liquid chlorine bleach may have
been added incorrectly (cont). Do not place load items on top of bleach dispenser when loading and unloading washer.
Garment care instructions may not
have been followed. Always read and follow garment manufacturer’s care label instructions. See the “Cycle Guide” to match your load with
the best cycle.
Odors Monthly maintenance not done as
recommended. See “Washer Care” in the “Washer Maintenance” section.
Unload washer as soon as cycle is complete.
Using too much detergent. Be sure to measure correctly. Always follow the manufacturer’s
directions.
See “Washer Care” in the “Washer Maintenance” section.
Lid Locked light is
ashing The lid is not closed. Close the lid. The washer will not start or ll with the lid open.
A cycle was stopped or paused
using Start/Pause/Unlock Lid. The washer may still be spinning. The lid will not unlock until the basket has stopped spinning. This may take several minutes
if washing large loads or heavy fabrics.
Single-dose laundry
packet not dissolving Adding laundry packet incorrectly. Be sure laundry packet is added to washer basket before adding clothes. Do not add packet to dispenser. Follow the
manufacturer’s instructions to avoid damage to your garments.
Washer pumps out water
before nishing cycle Lid is left open for more than 10 minutes. Make sure lid is closed before starting a cycle and/or during prewash (soak).
First try the solutions suggested here to possibly avoid a service call.

17
05/17
IF YOU NEED SERVICE:
1. Before contacting us to arrange service, please determine whether your product requires repair. Some questions can be addressed without
service. Please take a few minutes to review the Troubleshooting section of the Use and Care Guide or visit producthelp.amana.com.
2. All warranty service is provided exclusively by our authorized Amana Service Providers. In the U.S. and Canada, direct all requests for warranty
service to:
Amana Customer eXperience Center
In the U.S.A., call 1-800-843-0304. In Canada, call 1-800-807-6777.
If outside the 50 United States or Canada, contact your authorized Amana dealer to determine whether another warranty applies.
AMANA®
MAJOR APPLIANCE
LIMITED WARRANTY
ATTACH YOUR RECEIPT HERE. PROOF OF PURCHASE IS REQUIRED
TO OBTAIN WARRANTY SERVICE.
Please have the following information available when you call the
Customer eXperience Center:
■Name, address, and telephone number
■Model number and serial number
■A clear, detailed description of the problem
■Proof of purchase, including dealer or retailer name and address
ONE YEAR LIMITED WARRANTY
WHAT IS COVERED WHAT IS NOT COVERED
For one year from the date of purchase, when
this major appliance is installed, operated, and
maintained according to instructions attached to
or furnished with the product, Amana brand of
Whirlpool Corporation or Whirlpool Canada LP
(hereafter “Amana”) will pay for factory specified
replacement parts and repair labor to correct
defects in materials or workmanship that existed
when this major appliance was purchased or, at its
sole discretion, replace the product. In the event
of product replacement, your appliance will be
warranted for the remaining term of the original
unit’s warranty period.
YOUR SOLE AND EXCLUSIVE REMEDY UNDER
THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR AS PROVIDED HEREIN. Service must be
provided by a Amana designated service company.
This limited warranty is valid only in the United
States or Canada and applies only when the major
appliance is used in the country in which it was
purchased. This limited warranty is effective from
the date of original consumer purchase. Proof of
original purchase date is required to obtain service
under this limited warranty.
1. Commercial, non-residential, multiple-family use, or use inconsistent with published user,
operator, or installation instructions.
2. In-home instruction on how to use your product.
3. Service to correct improper product maintenance or installation, installation not in
accordance with electrical or plumbing codes, or correction of household electrical or
plumbing (e.g., house wiring, fuses, or water inlet hoses).
4. Consumable parts (e.g., light bulbs, batteries, air or water filters, preservation solutions).
5. Defects or damage caused by the use of non-genuine Amana parts or accessories.
6. Conversion of products from natural gas or propane gas.
7. Damage from accident, misuse, abuse, fire, floods, acts of God, or use with products not
approved by Amana.
8. Repairs to parts or systems to correct product damage or defects caused by unauthorized
service, alteration, or modification of the appliance.
9. Cosmetic damage including scratches, dents, chips, and other damage to the appliance
finishes, unless such damage results from defects in materials and workmanship and is
reported to Amana within 30 days.
10. Discoloration, rust, or oxidation of surfaces resulting from caustic or corrosive environments
including, but not limited to, high salt concentrations, high moisture or humidity, or exposure
to chemicals.
11. Food or medicine loss due to product failure.
12. Pickup or delivery. This product is intended for in-home repair.
13. Travel or transportation expenses for service in remote locations where an authorized
Amana servicer is not available.
14. Removal or reinstallation of inaccessible appliances or built-in fixtures (e.g., trim, decorative
panels, flooring, cabinetry, islands, countertops, drywall) that interfere with servicing,
removal, or replacement of the product.
15. Service or parts for appliances with original model/serial numbers removed, altered, or not
easily determined.
The cost of repair or replacement under these excluded circumstances shall be borne by
the customer.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces do not allow
limitations on the duration of implied warranties of merchantability or fitness, so this limitation may not apply to you. This warranty gives you specific
legal rights, and you also may have other rights that vary from state to state or province to province.
DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY
Amana makes no representations about the quality, durability, or need for service or repair of this major appliance other than the representations
contained in this warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes with this major appliance,
you should ask Amana or your retailer about buying an extended warranty.
LIMITATION OF REMEDIES: EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. AMANA
SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the exclusion or limitation of
incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty gives you specific legal rights, and you
also may have other rights that vary from state to state or province to province.

18
Risque possible de décès ou de blessure grave si
Risque possible de décès ou de blessure grave
si vous ne suivez pas les instructions.
Tous les messages de sécurité vous diront quel est le danger potentiel et vous disent comment réduire le risque de
Votre sécurité et celle des autres est très importante.
Nous donnons de nombreux messages de sécurité importants dans ce manuel et sur votre appareil ménager.
Ce symbole d’alerte de sécurité vous signale les dangers potentiels de décès et de blessures graves
Tous les messages de sécurité suivront le symbole d’alerte de sécurité et le mot “DANGER” ou
“AVERTISSEMENT”. Ces mots signifient :
DANGER
AVERTISSEMENT
Assurez-vous de toujours lire tous les messages de sécurité et de vous y conformer.
à vous et à d’autres.
Voici le symbole d’alerte de sécurité.
vous ne suivez pas immédiatement les instructions.
blessure et ce qui peut se produire en cas de non-respect des instructions.
SÉCURITÉ DE LA LAVEUSE

19
QUOI DE NEUF SOUS LE COUVERCLE?
Votre nouvelle laveuse fonctionne différemment de votre précédente laveuse de type agitateur.
Utiliser uniquement un détergent haute efcacité (HE) .
Verrouillage du couvercle
Pour permettre des essorages à vitesse plus élevée, le
couvercle se verrouille et le témoin de couvercle verrouillé
s’allume. Lorsque ce témoin lumineux s’allume, cela signie
que le couvercle est verrouillé et ne peut être ouvert. Lorsque
ce témoin lumineux clignote, cela signie que la laveuse
effectue une pause. Lorsque ce témoin lumineux est éteint,
cela signie qu’on peut ouvrir le couvercle. Une fois qu’un
programme a commencé, la laveuse se remplit au niveau
d’eau approprié. Quand la laveuse est faite remplir, l’agitation
va commencer. Si l’on doit ouvrir le couvercle pour ajouter
un vêtement après cette étape, le couvercle de la demeurera
déverrouillé pendant toute la partie de l’agitation de l’étape de
lavage. Le programme fait une pause automatiquement quand
le couvercle est ouvert, et le programme recommencera après
la fermeture du couvercle. Le couvercle se verrouille avant
le début de l’étape d’essorage. Si l’on doit pauser ou arrêter
après cette étape, il faut appuyer sur START/PAUSE/UNLOCK
LID (mise en marche/pause/déverrouillage du couvercle)
puis attendre que le couvercle se déverrouille. Le couvercle
se déverrouille uniquement une fois que le mouvement de la
laveuse a cessé. Selon le moment où l’on souhaite suspendre
le programme, le couvercle peut mettre entre quelques
secondes et plusieurs minutes à se déverrouiller. Appuyer
sur START/PAUSE/UNLOCK LID (mise en marche/pause/
déverrouillage du couvercle) pour poursuivre le programme.
Options de niveau d’eau
Régler le bouton de niveau d’eau sur Auto Sensing (détection
automatique) pour que la laveuse se remplisse d’eau à
un niveau qui assure que la charge déclenche l’agitateur.
À ce stade, la commande électronique détecte la charge
et détermine si de l’eau supplémentaire est nécessaire.
Régler le bouton Water Level (niveau d’eau) sur le réglage
Deep Water Wash (lavage à niveau d’eau élevé) et la laveuse
se remplit jusqu’au niveau d’eau maximal.
REMARQUE : L’option Deep Water Wash (lavage à niveau
d’eau élevé) n’est pas disponible avec le programme Normal
Regular (Normal ordinaire). Un programme Normal Regular
(Normal ordinaire) avec option Deep Water Wash (lavage à
niveau d’eau élevé) utilisera la détection automatique du niveau
de l’eau.
Détection
Cette laveuse effectue une série d’essorages pour contrôler
l’équilibre de la charge. Durant cette période, une série de
cliquetis et un bruit de frottements rythmiques indiquent
que la technologie de détection détermine si la charge
est déséquilibrée.
Sons normaux prévisibles
Au cours des différents stades du programme de lavage, vous
entendrez peut-être des bruits que votre laveuse précédente
ne produisait pas. Par exemple, vous entendrez peut-être un
cliquetis et un bourdonnement au début de l’étape d’essorage
lorsque le système de verrouillage du couvercle effectue un
test automatique. Différents bourdonnements et bruits de
frottements rythmiques se produiront à mesure que l’agitateur
évalue l’équilibre de la charge et qu’il la déplace. Parfois, il
est possible que la laveuse soit complètement silencieuse,
lorsqu’elle détermine le niveau d’eau adéquat ou qu’elle laisse
tremper les vêtements.
Rinçage par vaporisation
Certains programmes utilisent l’option rinçage par vaporisation
par défaut. Au cours de ces programmes, on entend l’eau
pénétrer dans la laveuse tandis que la cuve tourne, ce qui
permet à l’eau de rinçage de pénétrer les vêtements. Consulter
le “Guide de programmes” pour plus de détails.
Choix du détergent approprié
Utiliser uniquement des détergents haute efcacité. L’emballage
portera la mention “HE” ou “High Efciency” (haute efcacité). Il
est probable que l’utilisation d’un détergent non HE prolongera
la durée des programmes et réduira la performance de rinçage.
Ceci peut aussi entraîner des malfunctions de composants et,
avec le temps, une accumulation de moisissure. Les détergents
HE devraient produire peu de mousse et se dissoudre
rapidement pour produire une quantité de mousse idéale pour
une performance optimale. Ils devraient retenir les particules de
saleté en suspension an qu’elles ne se redéposent pas sur les
vêtements propres. Les détergents identiés HE ne comportent
pas tous une formule identique et ne produisent pas tous la
même quantité de mousse. Par exemple, les détergents HE
naturels, organiques et faits maison peuvent produire une plus
grande quantité de mousse. Toujours suivre les instructions
du fabricant pour déterminer la quantité de détergent à utiliser.
IMPORTANT : Le couvercle doit être fermé avant que le panier de la laveuse se remplisse et que le programme de lavage se mette
en marche. Si le couvercle est ouvert et que le remplissage s’arrête, fermer le couvercle et appuyer sur START/PAUSE/Unlock Lid
(mise en marche/pause/déverrouillage du couvercle) pour terminer le programme.
Accessoires
Améliorer votre nouvelle laveuse grâce aux authentiques
accessoires Whirlpool suivants. Pour plus d’informations sur
les options et pour commander, composer le 1-800-901-2042,
ou visiter notre site Web à : www.whirlpool.com/accessories.
Au Canada, composer le 1-800-807-6777 ou visiter notre site
Web à www.whirlpoolparts.ca.
Distributeur d’assouplissant
pour tissu
Ce distributeur d’assouplissant
pour tissu pratique est relié
à l’agitateur et vous évite
d’ajouter manuellement
l’assouplissant pour tissu
durant le programme
de rinçage.

20
TABLEAU DE COMMANDE ET CARACTÉRISTIQUES
5
1
4
3
2
Certains programms et options ne sont pas disponibles sur certains modèles.
L’apparence des appareils peut varier.
1WATER LEVEL (NIVEAU D’EAU)
Régler le bouton de niveau d’eau sur Auto Sensing
(détection automatique) pour que la laveuse se remplisse
d’eau à un niveau qui assure que la charge déclenche
l’agitateur. À ce stade, la commande électronique détecte
la charge et détermine si de l’eau supplémentaire est
nécessaire.
Régler le bouton Water Level (niveau d’eau) sur le réglage
Deep Water Wash (lavage à niveau d’eau élevé) et la
laveuse se remplit jusqu’au niveau d’eau maximal.
REMARQUES :
■La durée du programme sera plus grande
en raison du temps de remplissage plus long que
demande le réglage Deep Water Wash (lavage à
niveau d’eau élevé).
■L’option Deep Water Wash (lavage à niveau d’eau
élevé) est disponible avec le programme Normal
Regular (Normal ordinaire). Un programme Normal
Regular (Normal ordinaire) avec option Deep Water
Wash (lavage à niveau d’eau élevé) utilisera la
détection automatique du niveau de l’eau.
2WASH TEMPERATURE (température de lavage)
La fonction Wash Temperature (température de lavage)
détecte et maintient une température uniforme de l’eau en
régulant le débit d’arrivée d’eau chaude et d’eau froide.
Sélectionner une température de lavage en fonction
du type de tissu et de saleté à laver. Pour des résultats
optimaux, suivre les instructions sur l’étiquette du
vêtement et utiliser la température d’eau de lavage la
plus chaude possible qui reste sans danger pour le tissu.
REMARQUES :
■Sur certains modèles et pour certains programmes,
les températures utilisées pour l’eau chaude et l’eau
tiède peuvent être inférieures aux températures
utilisées par votre précédente laveuse.
■Même pour les lavages dont la température a été
réglée sur Cool (frais) ou Cold (froid), il est possible
que de l’eau tiède soit ajoutée à la laveuse pour
maintenir une température minimale. Tous les rinçages
se font à l’eau froide.
3BOUTON DE PROGRAMME DE LAVAGE
Utiliser le bouton du programme de lavage pour
sélectionner les programmes disponibles sur la laveuse.
Voir “Guide de programmes” pour des descriptions de
programmes détaillées.
4BOUTON START/PAUSE/UNLOCK LID
(mise en marche/pause/déverrouillage
du couvercle)
Appuyer sur ce bouton pour démarrer le programme
sélectionné, puis appuyer de nouveau pour suspendre
le programme et déverrouiller le couvercle.
REMARQUE : Si la laveuse tourne, le couvercle peut
mettre quelques minutes à se déverrouiller. Appuyer
pendant 3 secondes pour annuler un programme.
