Amana NTW4600VQ1 User manual

TOP AND CABINET PARTS
1
For Model: NTW4600VQ1
(White)
02−09 Litho in U.S.A. (drd) (eeb) Part No. W10253212 Rev. A
AUTOMATIC
WASHER

TOP AND CABINET PARTS
2
For Model: NTW4600VQ1
(White)
W10253212
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
W10200331 English
W10200662 Spanish
Feature Sheet
W10192181 English/French
W10192182 Spanish
Use & Care Guide
W10192187 English/French
W10192188 Spanish
W10183468 Wiring Diagram
W10192184 Energy Guide
2 8318064 Top
3 62750 Spacer, Cabinet To
Top (4)
4 357213 Nut, Push−In (2)
5 63424 Cabinet
6 62780 Clip, Top & Cabinet
& Rear Panel (2)
7 3351614 Screw, Ground
8 3362952 Dispenser, Bleach
9 9724509 Bumper, Lid (2)
10 8318084 Switch, Lid
11
W10119828 Screw, Lid Hinge
Mounting (4)
12
W10225135 Hinge, Lid (L.H.)
13 91770 Hinge, Lid (R.H.)
14 21258 Bearing, Lid
Hinge (2)
15 8541774 Lid
16 3390631 Screw,
10−16 x 3/8 (4)

CONTROLS AND REAR PANEL PARTS
3
For Model: NTW4600VQ1
(White)
W10253212

CONTROLS AND REAR PANEL PARTS
4
For Model: NTW4600VQ1
(White)
W10253212
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 388326 Screw, 8−18 x 1.25
(Panel To Top)
2 9740848 Screw, 8−18 x 1/2
3 3347868 Cable Tie
4 8577378 U−Bend,
Drain Hose
5 8568314 Strap, Console (2)
6
W10194450 Panel, Rear
7 62747 Pad, Rear Panel
8
W10189267 Drain Hose
Assembly
(Includes Item 19)
9
W10175553 Timer, Control
(60 Hz.)
(Motor Not A
Service Part)
10 3351614 Screw, Ground
11 90767 Screw, 8−18 x 3/8
12 8577843 Switch, Water Level
13 3948608 Bracket, Control
14 8578842 Cord, Power
(Includes Item 15)
15 3952821 Strain Relief,
Power Cord
16 8271365 Cap, End (L.H.)
17 8271359 Cap, End (R.H.)
18
W10144820 Valve, Water Inlet
W/Thermistor
& Vacuum Break
19 8541668 Clamp, Hose
20 8318046 Clip, Capacitor
21
W10196505 Knob, Timer
22
W10196506 Dial, Timer
23
W10196503 Knob, Control
24 8536939 Clip, Knob
25 3400073 Screw, Ground
26 8519200 Support, Rear
Panel
27
W10000080 Clip, Push−In
Retainer
28 8572717 Capacitor,
Motor Start
29 8055003 Clip, Harness
& Pressure Hose
30 3363366 Clamp, Hose
31 8317496 Clamp, Hose
32 3951449 Hose, Pump To Tub
(Includes Item 30)
33 3400818 Screw, Timer
Mounting
34
W10184148 Switch, Water
Temperature (ATC)
35 3949187 Switch, Rotary
36
W10192127 Panel, Console
37 62863 Screw, 10−16 x 3/8
38
W10215082 Wiring, Harness
(For Detail See
Pages 9 & 10)

5
AGITATOR, BASKET AND TUB PARTS
For Model: NTW4600VQ1
(White)
W10253212

AGITATOR, BASKET AND TUB PARTS
6
For Model: NTW4600VQ1
(White)
W10253212
Illus. Part
No. No. DESCRIPTION
1 8575076 Dispenser,
Fabric Softener
2 3354733 Cap, Barrier
3
W10072840 Seal, Inner Cap
4 358237 Screw & Washer
(5/16−24 x 1)
5 3949550 Washer
6 3348117 Agitator
(Complete)
7 3363663 Cam, Driven
8 3366877 Dog, Agitator
Clutch (4)
9 3363661 Bearing, Driven
Cam
10 3348752 Clothes Mover
11 3350389 Spacer, Thrust
12 3347288 Agitator
13
W10093698 Tub Ring & Gasket
14 3976308 Gasket, Tub Ring
15 3354845 Clip, Agitator
16 8543666 Washer, Agitator
17 21366 Nut, Spanner
18 8526016 Basket & Balance
Ring
19 387240 Balance Ring
20 63849 Tub
21 389140 Block, Basket
Drive
22 383727 Gasket, Centerpost
23 3347780 Hose, Pressure
Switch
24 2219077 Clip, Pressure
Switch Hose

BRAKE, CLUTCH, GEARCASE, MOTOR AND PUMP PARTS
7
For Model: NTW4600VQ1
(White)
W10253212
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 388952 Brake & Drive
Tube (Complete)
(Refer to Page 11
For Further
Breakdown)
2 63292 Washer, Spin
Tube Thrust
3 62697 Ring, Spin
Tube Support
4 63283 Ring, Retainer
5 3951311 Clutch (Complete)
6 3951308 Band & Lining,
Clutch (Includes
Items 7 & 8)
7 62646 Cap, Clutch
Spring (2)
8 3946792 Spring, Clutch
9 3360630 Gearcase
(Complete)
(Refer To Page 12
For Further
Breakdown)
10 3357334 Screw, Gearcase
To Base (3)
11 62611 Plate, Motor
Mount To
Gearcase
12 62691 Grommet, Motor (4)
13 3364003 Coupling, Motor
& Isolation
14 8577374 Seal
15 3355454 Clip,
Anti−Rattle
16 3400516 Screw
17
W10086010 Retainer, Motor (2)
18 3362089 Shield, Tub
To Motor
19 8528158 Motor, Main
Drive (Spring
P/N 388492 Must
Be Ordered When
Replacing Motor)
20 3952056 Switch, Main
Drive Motor
21 8546127 Retainer, Pump (2)
22 3363394 Pump (Complete)
23 3387485 Screw, 10−16 x 5/8
24 3946532 Shield, Motor

MACHINE BASE PARTS
8
For Model: NTW4600VQ1
(White)
W10253212
Illus. Part
No. No. DESCRIPTION
1 3400076 Screw, Bracket
Mounting
(10−32 x 5/8)
2 64067 Bracket, Spring
Outer (2)
3 63907 Spring
Suspension,(3)
4 8575214 Support & Brake,
Tub
5 64065 Bracket, Spring
Outer (L.F.)
6 63466 Link, Leveling
Mechanism (2)
7 62597 Spring, Leveling
Mechanism
8 62837 Pin, Knurled
9 62596 Foot, Rear (2)
10 8546455 Bearing,
Centerpost (2)
11 357409 Seal, Centerpost (3)
12 8534035 Spring,
Counterweight
(Must Be Ordered
When Replacing
Drive Motor)
13 62568 Pad, Plate
14 3946509 Plate, Suspension
(Includes Item 13)
15 3363660 Pad, Base
16 3946512 Base Assembly
(Includes Items 6,
7, 8, 9, 13, 14,
15 & 22)
17 3359452 Nut, Lock (2)
(3/8−16)
18
W10001130 Foot, Front (2)
19 8577376 Seal, Centerpost
20 285203 Centerpost
Bearing Kit
(Includes Items
10, 11 & 19)
21 63134 Ring, Sound
Deadening
22
W10145155 Retainer,
Suspension Spring

WIRING HARNESS PARTS
9
For Model: NTW4600VQ1
(White)
W10253212

WIRING HARNESS PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3349557 Retainer, Harness
2 388498 Clip, Harness
3 3347812 Clip, Harness
4 3352501 Clip, Harness
(Push−In)
5 90016 Clip, Harness
(Half−Harness)
6 3390496 Clip, Harness
7 389379 Retainer, Harness
8 Timer, Block
Disconnect
3948614 Natural
352089 Black
9 62889 Receptacle,
Terminal
(3−Way)
10 353424 Plug, Terminal
(3−Way)
11 62505 Block, Disconnect
(Motor 2 Speed)
12 3347243 Block, Disconnect
13 63523 Protector
14 717252 Connector
(2−Way)
15 3352944 Clip, Harness
16 3390423 Block, Disconnect
(12−Way)
17 3347730 Receptacle
(6−Way)
18 3948617 Connector (T.P.A.)
(3−Circuit)
19 3360056 Plug (T.P.A)
(3−Circuit)
(Pressure Switch)
20 Block, Connector
3354925 Natural
3354926 Red
FOR COMPLETE WIRING HARNESS REFER TO
CONTROL AND REAR PANEL PARTS PAGE
10
For Model: NTW4600VQ1
(White)
W10253212

Illus. Part
No. No. DESCRIPTION
BRAKE AND DRIVE TUBE PARTS
1 388952 Brake And Drive
Tube (Complete)
2 62658 Ring, Thrust
3 356427 Seal, Drive Tube
4 64027 Tube, Basket
Drive (Includes
Illus. 3, 4, 5 & 9)
5 64035 Ring, Retaining
6 64232 Shoe, Brake (2)
7 62703 "T" Bearing,
Spin Tube
8 3353956 Cap, Brake
Spring (2)
9 387806 Spring, Brake
10 3355360 Sleeve, Brake
Spring
11 661516 Cam, Brake
Release
12 63022 Sleeve, Cam
13 64194 Driver, Brake
Cam
14 90368 Ring, Retaining
FOLLOWING PARTS
NOT ILLUSTRATED
285208 Lubricant
(Use Only In
Brake Shoe
Assembly On
Roller & Pin)
11
For Model: NTW4600VQ1
(White)
W10253212

GEARCASE PARTS
Illus. Part
No. No. DESCRIPTION
1 3360630 Gearcase
(Complete)
2 285202 Cover, Gearcase
3 3349985 Seal, Gearcase
Cover
4 285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
5 63320 Pinion, Spin
(Includes Illus. 25)
6 356427 Seal, Spin
Pinion
7 389387 Shaft, Agitator
(Complete)
8 90369 Ring, Retaining (2)
9 62677 Retainer, Spring
10 62676 Spring, Agitate
11 63273 Gear, Agitate
(Includes 15 and 29)
12 62619 Washer, Agitate
Gear
13 62580 Cam Follower
(Includes 14)
14 62581 Cam, Agitate
(Includes 13)
15 285509 Shaft, Agitator
(Includes 11 and 29)
16 62618 Washer, Cam Thrust
17 16018 Bearing, Thrust
18 85529 Ball, Bearing
19 389230 Bottom and Pinion,
Gearcase
21 285352 Seal, Thrust Plug
22 3351614 Screw, Gearcase
Cover, Mounting (8)
(10−24 x 3/8)
23 3362552 Ring, Retaining
24 285735 Washer Kit,
Thrust
25 62570 Gear, Spin
26 388253 Neutral Assembly
27 3349296 Rack, Connecting
28 62621 Actuator, Shift
29 388815 Washer,
Intermediate
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
For Model: NTW4600VQ1
(White)
W10253212
12

OPTIONAL PARTS (NOT INCLUDED)
13
For Model: NTW4600VQ1
(White)
W10253212
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350938 Primer, Gray
350930 White
PAINT, BULK (1 qt.)
799344 White (Uncut)
OIL
350572 Oil, Gearcase
(16 Oz.)
LUBRICANT
285208 Lubricant (Use
Only in Brake
Shoe Assembly
On Roller and
Pin)
SEALER
285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
ACCESSORY PARTS
63580 Fabric Dispenser
367031 Drain Protector
280129 Siphon Break Kit
280130 Drain Hose
Adapter Kit
280131 Drain Hose
Extension Kit
8212546RP Inlet Hoses, 4 Ft.
(Two Black Hoses
W/Straight Ends &
4 Rubber Washers)
8212641RP Inlet Hoses, 5 Ft.
(Two Black Hoses
W/Straight Ends &
4 Rubber Washers)
8212656RP Inlet Hoses, 10 Ft
(Two Black Hoses
W/Straight Ends &
4 Rubber Washers)
8212545RP Inlet Hoses, 5 Ft.
(One Red Hose
& One Blue Hose
W/Straight Ends &
4 Rubber Washers)
8212487RP Inlet Hoses, 5 Ft.
(Two Braided Hoses
W/Straight Ends &
4 Rubber Washers)
8212637RP Inlet Hoses, 6 Ft.
(Two Black Hoses
W/One Straight
End & One
90 Degree End &
4 Rubber Washers
8212638RP Inlet Hoses, 6 Ft.
(Two Braided Hoses
W/One Straight
End & One
90 Degree End &
4 Rubber Washers)
285448A Hose Washers
(Package of 4)
285452A Hose Screen
(Package of 2)
