AMAZONEN-Werke Amazone Centaya 3000 Super 1600 User manual
Operating manual
az
Pneumatic pack top seed drill
Centaya 3000/3500/4000 Super 1600
Centaya 3000/3500/4000 Super 2000
MG6194
BAH0092-6 10.20
Please read and observe this
operating manual before initial
operation of the implement!
Keep it in a safe place for future use!
en
Centaya Super BAH0092-6 10.20 3
Identification data
Please insert the identification data of the implement.
The identification data can be found on the rating plate.
Machine type:
Implement number, ten digits:
Year of manufacture:
Permissible total weight [kg]:
Manufacturer address
AMAZONEN-WERKE
H. DREYER GmbH & Co. KG
Postfach 51
D-49202 Hasbergen
Tel.: + 49 (0) 5405 501-0
email: [email protected]
Spare Parts Order
Spare parts lists are freely accessible in the spare parts portal at
www.amazone.de.
Please send orders to your AMAZONE dealer.
Formalities of the operating manual
Machine type: Centaya Super
Document number: MG6194
Compilation date: 10.20
Copyright AMAZONEN-WERKE H. DREYER GmbH & Co. KG, 2020
All rights reserved.
Reprinting, even of sections, permitted only with the approval of
AMAZONEN-WERKE H. DREYER GmbH & Co. KG.
4 Centaya Super BAH0092-6 10.20
Foreword
Dear Customer,
You have chosen one of the quality products from the wide product range of AMAZONEN-WERKE,
H. DREYER GmbH & Co. KG. We thank you for your trust in our products.
On receiving the implement, check to see if it has been damaged during transport or if parts are
missing. Check the delivered implement for completeness based on the delivery slip, including the
ordered special equipment. Damage can only be rectified if problems are claimed immediately.
Before initial operation, read and comply with the information in this operating manual, and particularly
the safety instructions. Only after careful reading will you be able to benefit from the full scope of your
newly purchased implement.
Please ensure that all the implement operators have read this operating manual before they put the
implement into operation.
If there are any questions or problems, please read this operating manual or contact your local service
partner.
Regular maintenance and timely replacement of worn or damaged parts increases the service life of
your implement.
Centaya Super BAH0092-6 10.20 5
1User information ........................................................................................ 10
2General Safety Information ....................................................................... 11
2.1Obligations and liability .......................................................................................................... 11
2.2Representation of safety symbols .......................................................................................... 13
2.3Organisational measures ....................................................................................................... 14
2.4Safety and protective equipment ........................................................................................... 14
2.5Informal safety measures ....................................................................................................... 14
2.6User training ........................................................................................................................... 15
2.7Safety measures in normal operation .................................................................................... 16
2.8Danger from residual energy ................................................................................................. 16
2.9Maintenance and repair work, fault elimination ..................................................................... 16
2.10Design changes ..................................................................................................................... 16
2.10.1Spare and wear parts and aids .............................................................................................. 17
2.11Cleaning and disposal ............................................................................................................ 17
2.12Workstation of the operator .................................................................................................... 17
2.13Warning symbols on the implement ....................................................................................... 18
2.13.1Placement of the warning symbols ........................................................................................ 22
2.14Dangers in case of non-compliance with the safety instructions ........................................... 24
2.15Safety-conscious working ...................................................................................................... 24
2.16Safety information for users ................................................................................................... 25
2.16.1General safety instructions and accident prevention instructions .......................................... 25
2.16.2Hydraulic system .................................................................................................................... 29
2.16.3Electrical system .................................................................................................................... 30
2.16.4Mounted implements .............................................................................................................. 31
2.16.5Operation of the seed drill ...................................................................................................... 32
2.16.6Cleaning, maintenance and repair ......................................................................................... 32
3Loading and unloading the implement upon delivery ............................ 33
4Product description ................................................................................... 36
4.1Components of the AMAZONE seeding combination ........................................................... 36
4.2Equipment variations of the Centaya pneumatic pack top seed drill ..................................... 37
4.3Assembly groups of the Centaya pneumatic pack top seed drill ........................................... 38
4.4Safety and protection equipment ........................................................................................... 40
4.5Overview – Supply cable / hydraulic hose lines ..................................................................... 41
4.5.1Supply cable........................................................................................................................... 41
4.5.2Identification of the hydraulic hose lines ................................................................................ 41
4.5.3Type of actuation of the tractor control units .......................................................................... 41
4.5.4Connection and function of the tractor control units without ISOBUS system ....................... 42
4.5.5Connection and function of the tractor control units with ISOBUS system ............................ 43
4.6Traffic safety equipment ......................................................................................................... 44
4.7Proper use .............................................................................................................................. 4 5
4.7.1Approved AMAZONE implement combinations ..................................................................... 46
4.8Danger areas and danger points ........................................................................................... 47
4.9Rating plate and CE mark ...................................................................................................... 48
4.10Technical data ........................................................................................................................ 49
4.11Noise production data ............................................................................................................ 49
4.11.1Technical data for calculating the tractor weight and the tractor axle loads .......................... 50
4.12Required tractor equipment ................................................................................................... 5 1
5Structure and function .............................................................................. 52
5.1AMAZONE AmaDrill 2 control terminal .................................................................................. 55
5.2AMAZONE calibration button ................................................................................................. 55
5.3Control terminal for implements with ISOBUS system .......................................................... 55
5.3.1AMAZONE AmaTron 4 control terminal ................................................................................. 56
6 Centaya Super BAH0092-6 10.20
5.3.2AMAZONE TwinTerminal ...................................................................................................... 56
5.4Implement documentation ..................................................................................................... 57
5.5Central key ............................................................................................................................ 57
5.6Hand wash tank ..................................................................................................................... 57
5.7Distance measurement ......................................................................................................... 58
5.8Seed hopper and loading board ............................................................................................ 59
5.8.1Fill level monitoring ................................................................................................................ 60
5.9Metering ................................................................................................................................ 61
5.9.1Metering roller table - Figures ............................................................................................... 63
5.9.2Table – metering rollers, seed ............................................................................................... 65
5.9.3Calibrating the seed rate ....................................................................................................... 67
5.10Fan ........................................................................................................................................ 70
5.11Distributor head ..................................................................................................................... 72
5.11.1Seed tube monitoring ............................................................................................................ 73
5.11.2Spreading seed with wide row spacing ................................................................................. 73
5.12RoTeC Pro Control coulter .................................................................................................... 74
5.13TwinTeC double disc coulter ................................................................................................. 76
5.13.1Seed placement depth .......................................................................................................... 78
5.14Coulter pressure, seed rate increase, coulter lift (all coulter types) ...................................... 79
5.14.1Coulter pressure .................................................................................................................... 79
5.14.2Seed rate increase ................................................................................................................ 80
5.14.3Coulter lift - Soil tillage without seeding ................................................................................ 81
5.15Min./max. pressure stage (all coulter types) ......................................................................... 82
5.15.1Coulter pressure and seed rate increase .............................................................................. 82
5.15.2Coulter lift - Soil tillage without seeding ................................................................................ 82
5.16Exact following harrow .......................................................................................................... 83
5.16.1Exact following harrow tine position ...................................................................................... 84
5.16.2Exact following harrow pressure ........................................................................................... 85
5.16.3Exact following harrow lifting ................................................................................................. 86
5.17Roller harrow ......................................................................................................................... 87
5.18Seed pre-metering................................................................................................................. 88
5.19Start-up ramp ........................................................................................................................ 88
5.20Tramlines ............................................................................................................................... 89
5.20.1Tramline rhythm, tabular determination ................................................................................ 92
5.20.2Tramline rhythm, graphic determination................................................................................ 92
5.20.3One-sided switching .............................................................................................................. 94
5.20.3.1One-sided switching by installing an insert ........................................................................... 94
5.20.3.2One-sided switching by actuating a lever ............................................................................. 95
5.20.3.3One-sided switching by pressing a button on the control terminal ....................................... 96
5.21Tramline marker .................................................................................................................... 97
5.21.1Tramline marker with implement frame fastening ................................................................. 97
5.21.2Tramline marker with exact following harrow fastening ........................................................ 98
5.22Track marker ......................................................................................................................... 99
5.23Camera system ................................................................................................................... 100
5.24Work floodlights ................................................................................................................... 100
5.25GreenDrill GD200-E ............................................................................................................ 101
6Initial operation ........................................................................................ 102
6.1Checking the suitability of the tractor .................................................................................. 103
6.1.1Calculating the actual values for the total tractor weight, tractor axle loads and tyre
load-bearing capacity, as well as the required minimum ballast weight ............................. 104
6.1.1.1Data required for the calculation (attached implement) ...................................................... 105
6.1.1.2Calculation of the required minimum ballast weight at the front GV min of the tractor
to ensure steering capability ............................................................................................... 106
6.1.1.3Calculation of the actual front axle load of the tractor TV tat ................................................. 106
6.1.1.4Calculation of the actual total weight of the tractor and implement combination ............... 106
6.1.1.5Calculation of the actual rear axle load of the tractor TH tat ................................................. 106
6.1.1.6Load-bearing capacity of the tractor tyres ........................................................................... 106
Centaya Super BAH0092-6 10.20 7
6.1.1.7Table .................................................................................................................................... 107
6.2Secure the tractor / implement against unintentional starting and rolling away ................. 108
6.3Hydraulic connection for the fan drive ................................................................................. 109
7Coupling and uncoupling the implement .............................................. 110
7.1Hydraulic hose lines ............................................................................................................. 112
7.1.1Coupling the hydraulic hose lines ........................................................................................ 112
7.1.2Disconnecting the hydraulic hose lines ................................................................................ 113
7.2Coupling and uncoupling implements .................................................................................. 114
7.2.1Coupling - Tractor and soil tillage implement ....................................................................... 116
7.2.2Coupling - Pack top seed drill and soil tillage implement .................................................... 117
7.2.3Uncoupling – Combination from the tractor ......................................................................... 121
7.2.4Uncoupling – Soil tillage implement and pack top seed drill ................................................ 122
7.3Connecting the FTender on the 2nd distributor head .......................................................... 126
8Settings ..................................................................................................... 128
8.1Folding the steps up and down ............................................................................................ 129
8.2Fill the seed hopper ............................................................................................................. 131
8.3Calibrating the seed rate ...................................................................................................... 134
8.4Adjusting the fan speed ....................................................................................................... 140
8.4.1Setting the fan speed via the flow control valve of the tractor ............................................. 141
8.4.2Setting the fan speed on tractors without flow control valve ................................................ 141
8.4.3Switching on the fan speed monitoring ................................................................................ 141
8.4.4Pressure relief valve with round outer contour .................................................................... 142
8.4.4.1Basic setting of the pressure relief valve ............................................................................. 142
8.4.4.2Fan speed setting ................................................................................................................ 142
8.4.5Pressure relief valve with hexagonal outer contour ............................................................. 143
8.4.5.1Basic setting of the pressure relief valve ............................................................................. 143
8.4.5.2Fan speed setting ................................................................................................................ 143
8.5RoTeC-Pro Control coulter .................................................................................................. 144
8.5.1Adjusting and checking the seed placement depth ............................................................. 144
8.5.1.1Adjusting the depth control discs / wheels ........................................................................... 145
8.6TwinTeC double disc coulter ................................................................................................ 147
8.6.1Adjusting and checking the seed placement depth ............................................................. 147
8.7Coulter pressure, seed rate increase, and coulter lift (all coulter types) ............................. 151
8.7.1Coulter pressure .................................................................................................................. 151
8.7.2Seed rate increase ............................................................................................................... 152
8.7.3Coulter lift - Soil tillage without seeding ............................................................................... 153
8.7.4Min./max. pressure stages: Coulter pressure and seed rate increase ................................ 154
8.7.5Min./max. pressure stages: Coulter lift ................................................................................ 154
8.8Adjusting the exact following harrow ................................................................................... 155
8.8.1Adjusting the exact following harrow tines ........................................................................... 155
8.8.2Adjusting the exact following harrow pressure .................................................................... 156
8.8.3Moving the exact following harrow to the working/transport position .................................. 157
8.8.3.1Move the exact following harrow into working position ........................................................ 157
8.8.3.2Moving the exact following harrow into transport position ................................................... 157
8.8.4Seeding without exact following harrow (exact following harrow lift) ................................... 157
8.9Adjusting the roller harrow ................................................................................................... 158
8.10Moving the track marker to the working / transport position ................................................ 160
8.11One-sided switching ............................................................................................................. 161
8.11.1One-sided switching - Installing an insert ............................................................................ 161
8.11.2One-sided switching - Lever actuation ................................................................................. 162
8.11.3One-sided switching - setting on the control terminal .......................................................... 162
8.12Tramline marker with implement frame fastening ................................................................ 163
8.12.1Moving the tramline marker to working position .................................................................. 163
8.12.2Moving the tramline markers to the transport position ......................................................... 164
8.13Tramline marker with exact following harrow fastening ....................................................... 165
8.13.1Move the tramline marker to working position ..................................................................... 165
8.13.2Move the tramline markers to the transport position............................................................ 166
8 Centaya Super BAH0092-6 10.20
8.14Moving the exact following harrow road safety bar into road transport/parking
position ................................................................................................................................ 167
8.14.1Moving the road safety bar into road transport position ...................................................... 167
8.14.2Moving the road safety bar into parking position ................................................................ 167
9Transportation ......................................................................................... 168
9.1Moving the seeding combination into transport position ..................................................... 168
9.2Legal regulations and safety ............................................................................................... 169
10Use of the implement .............................................................................. 173
10.1Initial operation .................................................................................................................... 174
10.2Work floodlights ................................................................................................................... 174
10.3Coulter array lighting ........................................................................................................... 175
10.4Moving the implement from transport into working position ................................................ 175
10.5Work commencement ......................................................................................................... 175
10.6During operation .................................................................................................................. 177
10.6.1Overview of the inspections ................................................................................................ 177
10.6.2Turning at end of the field ................................................................................................... 178
10.6.3Track marker ....................................................................................................................... 179
10.6.4End of work on the field ....................................................................................................... 180
10.7Emptying the hopper and metering unit and replacing the metering roller ........................ 181
10.7.1Hopper quick emptying ....................................................................................................... 182
10.7.2Emptying the hopper and/or metering unit and replacing the metering roller ..................... 183
11Faults ........................................................................................................ 186
11.1Residual seed quantity display ............................................................................................ 187
11.2Deviations between the set and actual seed rate ............................................................... 187
12Maintenance and repairs ........................................................................ 188
12.1Maintenance schedule ........................................................................................................ 188
12.2Lubrication schedule / lubrication points ............................................................................. 189
12.3Safety .................................................................................................................................. 190
12.3.1Safety when cleaning the implement .................................................................................. 191
12.3.2Safety when working on the distributor head ...................................................................... 193
12.3.3Safety when working on the hydraulic system .................................................................... 193
12.4Repairs ................................................................................................................................ 194
12.4.1Cleaning the fan suction guard screen................................................................................ 194
12.4.2Cleaning the fan rotor .......................................................................................................... 194
12.4.3Clean the distributor head ................................................................................................... 194
12.4.4Visual inspection of the top link and lower link pins ............................................................ 195
12.4.5Visual check of the hydraulic hose lines and couplings ...................................................... 196
12.4.5.1Date of manufacture of the hydraulic hose line ................................................................... 196
12.5Installations ......................................................................................................................... 197
12.5.1Installing plugs to increase the row spacings ...................................................................... 197
12.5.2Checking / readjusting / replacing the TwinTeC roller scraper ........................................... 198
12.5.3Shutdown of the implement over a long period of time ....................................................... 199
12.6Workshop work .................................................................................................................... 200
12.6.1Checking the hydraulic hose lines ....................................................................................... 200
12.6.1.1Safety when working on hydraulic hose lines ..................................................................... 201
12.6.2Checking and readjusting the TwinTeC disc bearings ........................................................ 202
12.6.2.1Checking the TwinTeC disc bearings .................................................................................. 202
12.6.2.2Readjusting the TwinTeC disc bearings ............................................................................. 202
12.6.3Checking / replacing the TwinTeC inner scraper ................................................................ 204
12.6.4Checking / replacing the TwinTeC baffle lip ........................................................................ 205
12.6.5Dismounting the TwinTeC seed line ................................................................................... 206
12.6.6Checking / replacing the TwinTeC press roller ................................................................... 207
12.6.7Adjusting the tramline control .............................................................................................. 208
12.6.7.1Setting the tramline track width ........................................................................................... 209
12.6.7.2Setting the tramline wheelmark width ................................................................................. 209
12.6.7.3Removing and installing the segment in the distributor head ............................................. 210
Centaya Super BAH0092-6 10.20 9
12.6.7.4Electrical connection of the tramline segments ................................................................... 211
12.6.7.5Deactivating tramline segments ........................................................................................... 212
12.6.8Replacing the grid on the RoTeC Pro Control coulter ......................................................... 213
12.7Oils and greases .................................................................................................................. 214
12.7.1Lubricants for grease nipples and grease guns ................................................................... 214
12.8Bolt tightening torques ......................................................................................................... 215
13Hydraulic diagrams .................................................................................. 216
13.1Hydraulic diagram Centaya 3000/3500/4000 Super with RoTeC Pro coulters ................... 216
13.2Hydraulic diagram Centaya 3000/3500/4000 Super with TwinTeC double disc
coulters ................................................................................................................................. 218
User information
10 Centaya Super BAH0092-6 10.20
1 User information
The User information section provides information concerning the operating manual.
This operating manual is valid for all versions of the implement.
Figures serve as a reference and are to be understood as representations of the principle.
All of the equipment is described without indicating it as special equipment. A description may be
provided for equipment that is not fitted on the implement or is only available in certain markets. The
sales documents provide information on the equipment of your implement or consult your service
partner for more detailed information.
All information in this operating manual corresponds to the state of knowledge at the time of
publication. Due to ongoing development of the implement, deviations are possible between the
implement and the information in this operating manual. No claims can be made based on differences
in the specifications, figures or descriptions.
If you want to sell the implement, ensure that the operating manual is supplied with the implement.
The operating manual
describes the operation and maintenance of the implement
provides important information on safe and efficient handling of the implement
is an integral part of the implement and should always be kept with the implement or the towing
vehicle
must be kept in a safe place for future use.
Activities to be carried out by the user are presented as numbered instructions. Always observe the
sequence of the instructions. The reaction to instructions is indicated by an arrow where applicable.
Example:
1. Instruction 1
Reaction of the implement to handling instruction 1
2. Instruction 2
Listings without a mandatory sequence are presented as a listing with bullets.
Example: Point 1
Point 2
Numbers in round brackets refer to the item numbers in the illustrations. The first number refers to the
diagram and the second number to the item.
Example: (Fig. 3/6) = Figure 3 / Item 6.
All the directions specified in the operating manual are always viewed in the direction of travel.
General Safety Information
Centaya Super BAH0092-6 10.20 11
2 General Safety Information
This section contains important information on safe operation of the implement.
2.1 Obligations and liability
Comply with the instructions in the operating manual
Knowledge of the basic safety information and safety regulations is a basic requirement for safe
handling and fault-free implement operation.
Obligations of the operator
The operator is obliged only to let those people work with/on the implement who
are aware of the basic workplace safety information and accident prevention regulations
have been trained in working with/on the implement
have read and understood this operating manual.
The operator is obliged
to keep all the warning symbols on the implement in a legible state
to replace damaged warning symbols.
Obligations of the user
Before starting work, anyone charged with working with/on the machine is obliged
to comply with the basic workplace safety instructions and accident prevention regulations
to read and understand the "General safety information" section of this operating manual
to read the section "Warning symbols and other labels on the implement" in this operating
manual and to follow the safety instructions represented by the warning symbols when operating
the implement
to get to know the implement
to read the sections of this operating manual, important for carrying out your work.
If the user discovers that a function is not working properly, then they must eliminate this fault
immediately. If this is not the task of the user or if the user does not have the appropriate technical
knowledge, they should report this fault to their superior (operator).
General Safety Information
12 Centaya Super BAH0092-6 10.20
Risks in handling the implement
The implement has been constructed to the state-of-the art and the recognised rules of safety.
However, operating the implement may cause risks and restrictions
the health and safety of the user or third persons
the implement itself
other property.
Only use the implement
for the purpose for which it was intended
in a perfect state of repair.
Eliminate any faults immediately which could impair safety.
Guarantee and liability
Our "General conditions of sales and delivery" are always applicable. These shall be available to the
operator, at the latest on conclusion of the contract. Guarantee and liability claims for damage to
people or property will be excluded if they can be traced back to one or more of the following causes:
Improper use of the implement
Improper installation, commissioning, operation and maintenance of the implement
Operation of the implement with defective safety equipment or improperly attached or non-
functioning safety and protective equipment
Non-compliance with the instructions in the operating manual regarding commissioning,
operation and maintenance
Unauthorised design changes to the implement
Insufficient monitoring of implement parts which are subject to wear
Improperly executed repairs
Disasters due to the effects of foreign objects and force majeure.
General Safety Information
Centaya Super BAH0092-6 10.20 13
2.2 Representation of safety symbols
Safety information is indicated by the triangular safety symbol and the highlighted signal word. The
signal word (DANGER, WARNING, CAUTION) describes the severity of the risk, and carries the
following meaning:
DANGER
Indicates an immediate hazard with high risk, which will result in
death or serious bodily harm (loss of limbs or long-term harm), if
it is not avoided.
If the instructions are not followed, then this will result in
immediate death or serious physical injury.
WARNING
Indicates a medium risk, which could result in death or (serious)
physical injury if not avoided.
If the instructions are not followed, then this may result in death
or serious physical injury.
CAUTION
Indicates a low risk which could cause minor or medium level
physical injury or damage to property if not avoided.
IMPORTANT
Indicates an obligation to special behaviour or an activity required for
proper implement handling.
Non-compliance with these instructions can cause faults on the
implement or disturbance to the environment.
NOTE
Indicates handling tips and particularly useful information.
These instructions will help you to use all the functions of your
implement in the best way possible.
General Safety Information
14 Centaya Super BAH0092-6 10.20
2.3 Organisational measures
The operator must provide the necessary personal protective equipment as per the information
provided by the manufacturer of the crop protection agent to be used, such as:
Safety glasses
Protective shoes
Chemical-resistant overalls
Skin protection agents, etc.
The operating manual
must always be kept at the place at which the implement is
operated
must always be easily accessible for the user and maintenance
personnel.
Check all the available safety equipment regularly.
2.4 Safety and protective equipment
Before starting up the implement each time, all the safety and protection equipment must be properly
attached and fully functional. Check all safety and protection equipment regularly.
Faulty safety equipment
Faulty or disassembled safety and protection equipment can lead to dangerous situations.
2.5 Informal safety measures
As well as all the safety information in this operating manual, comply with the general, national
regulations pertaining to accident prevention and environmental protection.
When driving on public roads and routes you should comply with the statutory road traffic regulations.
General Safety Information
Centaya Super BAH0092-6 10.20 15
2.6 User training
Only those people who have been trained and instructed may work with/on the implement. The
operator must clearly specify the responsibilities of the people charged with operation and
maintenance work.
People being trained may only work with/on the implement under the supervision of an experienced
person.
Person
Activity
Person specially
trained for the
activity 1)
Trained
operator 2)
Persons with
specialist
training (specialist
workshop) 3)
Loading/Transport X X X
Initial operation X
Set-up, tool installation X
Operation X
Maintenance X
Troubleshooting and fault
elimination
X X
Disposal X
Key: X..permitted ..not permitted
1) A person who can assume a specific task and who can carry out this task for an appropriately
qualified company.
2) An instructed person is a person who has been instructed regarding the tasks assigned to him
and with regard to possible dangers in the event of improper behaviour and, if required, has been
taught and instructed concerning the necessary protective devices and protective measures.
3) Persons with specialised technical training shall be considered as a specialist. Due to their
specialist training and their knowledge of the appropriate regulations, they can evaluate the work
with which they have been charged and detect possible dangers.
Comment:
A qualification equivalent to specialist training can be obtained from several years' experience in
the relevant field.
Only a specialist workshop may carry out maintenance and repair
work on the implement, if such work is additionally marked "Specialist
workshop". The personnel of a specialist workshop shall possess the
appropriate knowledge and suitable aids (tools, lifting and support
equipment) for carrying out the maintenance and repair work on the
implement in a way which is both appropriate and safe.
General Safety Information
16 Centaya Super BAH0092-6 10.20
2.7 Safety measures in normal operation
Only operate the implement if all the safety and protection equipment is fully functional.
Check the implement at least once a day for visible damage and check the function of the safety and
protection equipment.
2.8 Danger from residual energy
Note that there may be residual mechanical, hydraulic, pneumatic and electrical/electronic energy on the
implement.
Use appropriate measures to inform the operator. You can find detailed information in the relevant
sections of this operating manual.
2.9 Maintenance and repair work, fault elimination
Carry out prescribed setting, maintenance and inspection work in good time.
Secure all media such as compressed air and the hydraulic system against unintentional start-up.
Carefully fix and secure larger assembly groups to lifting units when carrying out replacement work.
Check all the bolted connections for tightness. On completion of the maintenance work, check the
function of the safety and protective devices.
2.10 Design changes
You may make no changes, expansions or modifications to the implement without the authorisation of
AMAZONEN-WERKE. This also applies when welding support parts.
Any extension or conversion work shall require the written approval of AMAZONEN-WERKE. Only use
conversion and special equipment parts approved by AMAZONEN-WERKEN so that the operating
permit, for example, remains valid in accordance with national and international regulations.
Vehicles with an official type approval or with equipment connected to a vehicle with a valid type
approval or approval for road transport according to the German road traffic regulations must be in the
state specified by the approval.
WARNING
Risk of crushing, cutting, being trapped or drawn in, or impact
through the failure of support parts.
It is strictly forbidden to
drill holes in the frame or on the running gear
increase the size of existing holes on the frame or the running gear
weld on load-bearing parts.
General Safety Information
Centaya Super BAH0092-6 10.20 17
2.10.1 Spare and wear parts and aids
Immediately replace any implement parts which are not in a perfect state.
Use only genuine AMAZONE spare and wear parts or the parts cleared by AMAZONEN-WERKE so
that the operating permit retains its validity in accordance with national and international regulations. If
you use wear and spare parts from third parties, there is no guarantee that they have been designed
and manufactured in such a way as to meet the requirements placed on them.
AMAZONEN-WERKE shall accept no liability for damage caused by the use of non-approved spare
and wear parts or aids.
2.11 Cleaning and disposal
Handle and dispose of any materials used carefully, in particular
when carrying out work on lubrication systems and equipment and
when cleaning using solvents.
2.12 Workstation of the operator
The implement may be operated by only one person sitting in the driver's seat of the tractor.
General Safety Information
18 Centaya Super BAH0092-6 10.20
2.13 Warning symbols on the implement
Always keep all the warning symbols of the implement clean and in a
legible state. Replace illegible warning symbols. You can request the
warning symbols from your AMAZONE dealer using the order number
(e.g., MD 075).
Structure
Warning symbols indicate danger areas on the implement and warn against residual dangers. At these
points, there are permanent or unexpected dangers.
A warning symbol consists of two fields.
Field 1
Shows the danger in a triangular safety symbol.
Field 2
Shows instructions for avoiding the danger.
Explanatory text beside the warning symbol
The text beside the warning symbol describes
1. The dangers, e.g.:
Laceration or amputation hazard.
2. The consequence of non-compliance with the risk avoidance instructions, e.g.:
This danger can cause serious injuries to fingers or hands.
3. Instructions for avoiding the risk, e.g.:
Touch machinery parts only when they have come to a complete stop.
General Safety Information
Centaya Super BAH0092-6 10.20 19
MD 078
Risk of crushing of fingers/hand by
accessible, moving parts of the implement!
This hazard can cause extremely serious injuries
resulting in the loss of limbs.
Never reach into the danger area when the
tractor engine is running with the universal joint
shaft or hydraulic / electronic system connected.
MD 082
Risk of falling when riding the implement on
treads or platforms!
Causes serious, potentially fatal injuries
anywhere on the body.
It is forbidden to ride on the implement or climb
the implement when it is running. This prohibition
also applies to implements with step surfaces or
platforms.
Make sure that nobody is riding on the
implement.
MD 095
Before commissioning the machine read and
observe the operating manual and the safety
instructions carefully!
MD 096
Danger from escaping high-pressure
hydraulic fluid due to leaking hydraulic hose
lines!
This danger may cause serious injuries, perhaps
even resulting in death, if escaping high-pressure
hydraulic fluid passes through the skin and into
the body.
Never attempt to plug leaks in hydraulic
hose lines using your hand or fingers.
Read and observe the instructions in the
operating manual before carrying out any
maintenance or repair work on the hydraulic
hose lines.
If you are injured by hydraulic fluid, contact
a doctor immediately.
General Safety Information
20 Centaya Super BAH0092-6 10.20
MD 097
Risk of crushing the entire body when
standing in the lifting area of the 3-point
linkage when the three-point hydraulic
system is being operated!
Causes serious, potentially fatal injuries
anywhere on the body.
It is forbidden to stand in the lifting area of
the 3-point linkage when actuating the
three-point hydraulic system.
Actuate the operator controls for the
tractor's three-point hydraulic system:
only from the designated workstation
under no circumstances if you are in
the lifting area between the tractor and
implement.
MD 102
Danger from intervention in the implement,
e.g. installation, adjusting, troubleshooting,
cleaning, maintaining and repairing, due to
the tractor and the implement being started
unintentionally and rolling away!
These dangers can cause extremely serious and
potentially fatal injuries.
Secure the tractor and the implement
against unintentional start-up and rolling
away before any intervention in the
implement.
Depending on the type of intervention, read
and understand the information in the
relevant sections of the operating manual.
MD 150
Danger of your fingers and hands being cut
or cut off by moving parts involved in the
working process!
This hazard can cause extremely serious injuries
resulting in the loss of limbs.
Never open or remove safety equipment from
moving parts that are involved in the working
process whilst the engine of the tractor is running
with the universal joint shaft/hydraulic
system/electronic system connected.
This manual suits for next models
5
Table of contents
