Ambiano Sous Vide Precision User manual

SOUS VIDE PRECISION
IMMERSION COOKER
COCINA POR INMERSIÓN DE
PRECISIÓN SOUS VIDE
English……3
Español….16
User Manual
Manual
del usuario

Contents
Parts list.....................................................................3
Contents ...............................................................3
Before first use .....................................................4
Important safety information ...................................5
User instructions .......................................................9
Helpful hints .......................................................11
Cleaning and maintenance......................................13
Other useful information ........................................15
Technical specifications ......................................15
Storing ................................................................15

Parts list
3
2
7
8
6
5
9
10
Main parts
1. Main unit
2. Clamp
3. Non-slip rubber grip
4. Heating element with cover
5. LED control panel
6. Current temperature
7. Set temperature/time
8. ON/OFF
9. Temperature/time adjustment
10. Set timer
Contents of packaging
Sous Vide
Instruction manual
3
1
4

Before first use
4
Before first use
Please note the Sous Vide may produce an odor and/or smoke when switched on for the
first time, as residue from the production process are eliminated. This is normal and does
not indicate a defect or hazard. This faint smell and/or smoke will eventually go away after
the first few uses.
1. Unpack the Sous Vide from the box.
2. Remove any unwanted packaging materials such as cardboard, plastics or
styrofoam.
3. Check to ensure unit is not damaged.
4. Wipe clean with a soft, damp cloth. DO NOT IMMERSE THE SOUS VIDE
CONTROL PANEL IN WATER OR ANY OTHER LIQUID AT ANY TIME.
5. Only the heating element can be submerged in water: DO NOT IMMERSE the
power cord, control panel or clamp into water. If any parts other than the
heating element become submerged, unplug immediately and allow to dry
thoroughly.
DO NOT USE ANY ABRASIVE MATERIAL TO CLEAN THE SURFACE
DO NOT IMMERSE THE SOUS VIDE CONTROL PANEL IN WATER OR ANY
OTHER LIQUID AT ANY TIME

Important safety instructions
5
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should always be followed.
PLEASE READ AND SAVE ALL
INSTRUCTIONS BEFORE USING THE
SOUS VIDE IMMERSION COOKER.
1. To protect against electrical shock, do not immerse power cord or plug in
water or any other liquid. This is an electrical appliance. To avoid the risk of
electrical shock or serious personal injury, always operate with dry hands.
2. Close supervision is necessary when any appliance is being used by or near
children. This Sous Vide is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning the use of the Sous Vide by a person responsible for their safety.
3. Do not operate the Sous Vide with a damaged power cord or plug or if the
Sous Vide malfunctions or is dropped or damaged in any manner.
4. Do not use outdoors. For household use only. Do not use the appliance for
other than intended use.
5. Use the Sous Vide only as described in this manual. The use of accessory
attachments not recommended by the manufacturer may cause damage to
the Sous Vide or personal injuries.
6. The Sous Vide is not intended to be operated by an external timer or a
separate remote-control system.
7. Never touch the heating element of the Sous Vide during its operation or
before it cools. Use the top handle. DO NOT carry the Sous Vide by the power
cord or the heating element, only by the handle.
8. Unplug this unit from the electrical outlet before removing it from the pot or
food grade container, when not in use and before cleaning.
9. Allow the Sous Vide to cool completely before cleaning. DO NOT immerse the
Sous Vide control panel in water or any other liquid.
10. Do not let the power cord hang over the edge of a table or counter or touch
any hot surface.
11. Do not use the Sous Vide if the power cord or plug is damaged in any way or if
it is cracked, dented or chipped.

Important safety instructions
6
12. Never leave the Sous Vide connected to the power outlet when not in use.
13. Do not place this unit on or near a hot gas or electric burner, or in a heated
oven.
14. Do not touch hot surfaces. Use handles or knobs.
15. To disconnect, always turn to “OFF”first, then unplug from the wall outlet.
16. Do not clean the product with metal scouring pads. Pieces can break off from
the pad and touch electrical parts, creating a risk of electrical shock.
17. Do not turn on the Sous Vide if the pot has no water.
18. Never operate the Sous Vide unless the water level is between “MIN” and
“MAX”levels. Only the heating element can be submerged in water: DO NOT
IMMERSE the power cord, control panel or clamp into water. If any parts
other than the heating element become submerged, unplug product
immediately and allow to dry thoroughly.
19. While cooking, energy can be saved by covering the pot or food grade
container. Note: Do not use plastic wrap as it should never come in contact
with the heating element.
20. After completing the cooking cycle, do not use the water left in the pot for
drinking or for further cooking.
21. Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.
22. All food items must be placed in a re-sealable food grade bag and not placed
directly in the water with the Sous Vide.
23. Do not pre-heat any food items.
24. Do not allow the Sous Vide to stand in sitting water when not in use.
25. The Sous Vide must be in a pot where the water level is between the MIN and
MAX lines for best result.
26. Do not use frozen meat or poultry unless it is thoroughly thawed out first.
1
CAUTION: This unit becomes very hot and extreme caution should be
used during and after cooking and until it has cooled completely, after
unplugging the Sous Vide from the wall outlet.
SAVE ALL INSTRUCTIONS!

Safety instructions
7
Safety instructions
WARNING: Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire or serious personal injury. The
warnings, cautions, and instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood
by the operator that common sense and caution are a factor which cannot be
built into this product, but must be supplied by the operator. Do not abuse the
power cord. Never carry the Sous Vide by the power cord or pull the power cord
to disconnect the outlet plug from an outlet; instead grasp the outlet plug and pull
to disconnect.
CAUTION: A short power supply cord is provided to reduce the risk of personal
injury resulting from becoming entangled in or tripping over a longer cord.
Extension cords are available from local hardware stores and may be used if care
is exercised in their use. If an extension cord is required, special care and caution
is necessary. Also, the cord must be: (1) marked with an electrical rating of 125V,
and at least 13 A., 1625 W., and (2) the cord must be arranged so that it will not
drape over the countertop or tabletop where it can be pulled on by children or
tripped over accidentally.
3 PRONG PLUG
NOTE: This item comes equipped with a 3-prong plug. It is recommended that you
only plug this into an outlet that accepts the 3 prongs and that you do not try to
defeat this feature as it is an important safety feature that protects you from
electric shock if a wire comes loose.
Electric power
If electric circuit is overloaded with other appliances, your appliances may not
operate properly. The appliances should be operated on a separate electrical
circuit from other operating appliances.

Safety instructions
8
Safety warning
Although your Sous Vide is easy to operate, for your safety, the warnings below
must be followed:
1. Do not place the Sous Vide near a heat source.
2. Never leave the Sous Vide unattended while connected to the electrical
outlet. Use the Sous Vide on a stable work surface.
3. Do not unplug from the wall outlet by pulling on the supply cord.
4. The Sous Vide must be unplugged:
A. After each use.
B. If it appears to be faulty.
C. Before cleaning or maintenance.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.
SAVE THESE INSTRUCTIONS!

User instructions
9
User instructions
How to use
1. Always set your Sous Vide on a level and stable, heat resistant surface.
2. Clamp the Sous Vide on the pot or food grade container. Fill with water. Make
sure the water level does not exceed the MAX line or fall below the MIN line. The
Sous Vide will not power on without water.
3. Do not place the pot or food grade container on a heat surface as this item does
not require an additional heat source.
4. Plug the Sous Vide into a wall outlet. When plugged in the power indicator light
will flash indicating it is in STAND BY MODE. The Sous Vide will show the CURRENT
TEMPERATURE of the water. The set temperature defaults to 140 degrees. The
power button needs to be pressed while in STAND BY MODE or the Sous Vide will
turn off after 20 seconds. All lights will illuminate indicating it is ready to be
programmed.
5. Pressing the +/- buttons, set your desired temperature.
6. Place uncooked food in re-sealable food grade bag. Keep the bag slightly open
when immersing in water to allow all the air to be removed. Once all air is
removed, seal the bag completely.
7. Vacuum sealed food may also be used.
8. Once the CURRENT TEMPERATURE displays the same value as the SET
TEMPERATURE, the desired temperature has been achieved.
9. For optimal cooking results, use a clamp to fasten the sealed bag to the inside of
the pot or food grade container to keep the bag from moving around in the
water.
10. After the cooking is complete, use tongs to grab items from within the hot water.
MIN
MAX

User instructions
10
NOTE: The Sous Vide has a water inlet and outlet located on the bottom of the
heating element. Water flowing out of the unit may be hotter than the rest of the
pot and if the food comes into direct contact with this stream of water it may
affect the desired cooking results. For optimal cooking results and to ensure the
food does not come in contact with the water flow, we recommend securing the
bag to the side of the pot that is opposite the Sous Vide.
CAUTION: The water will get hot. Use extreme caution when moving containers
of hot liquid. We recommend placing a trivet under the pot when the water is hot
in order to protect the countertop.
To set the timer:
1. Press the SET button once to set the hours, press the set button twice to set
the minutes. Use the “+” and/or “- “button to add or subtract time. Once
desired time is selected, hit the SET button and the timer will start.
2. The control panel will toggle back and forth showing set temperature and
time remaining.
NOTE: The TIMER will only begin counting down once the CURRENT
TEMPERATURE is the same as the SET TEMPERATURE.
WARNING: Never carry the Sous Vide by the heating element, power cord or
handle. Extreme caution must be used when moving hot liquids.
CAUTION: This unit becomes very hot and extreme caution should be used
during and after cooking and until it has cooled completely, after unplugging the
Sous Vide from the wall outlet.

Helpful hints
11
Helpful hints
Searing is recommended when cooking meat, fish or poultry after cooking
time is completed. Remove the food from the bag and sear by using a pan,
broiler or grill. Searing the food will give it color and texture, and will lock in
the flavors.
All food items must be placed in a re-sealable food grade bag and not placed
directly in the water with the Sous Vide.
Food that is vacuum sealed may be used.
Do not pre-heat any food items.
Do not allow the Sous Vide to stand in sitting water when not in use.
Do not power on the Sous Vide when the pot has no water.
The Sous Vide must be in a pot where the water level is between the MIN and
MAX lines for best result.
Do not use frozen meat or poultry unless it is thoroughly thawed out first.
Many things can affect how quickly a recipe will cook, such as fat content,
initial temperature of the food and the size of the food.
Pieces of food cut into small pieces will cook quicker. A degree of ‘trial and
error’ will be required to fully optimize the potential of your Sous Vide.
After food is cooked, turn the Sous Vide off and unplug.
Troubleshooting
The Sous Vide will not
power on
Make sure that the product is properly plugged
into a working outlet.
Check the power cord for any damage.
Make sure product is submerged in water
between the MIN and MAX line.
The Sous Vide makes a
constant beeping
sound and the display
is not working.
Make sure the product is submerged in water
between the “MIN”and “MAX”line. To reset
press the power indicator symbol and all lights
are illuminated on the control panel.

Helpful hints
12
Cooking guide
TEMP MIN TIME MAX TIME
Eggs
-Poached
-Hard boiled
146°F
165°F
1h
1h
1.5h
1.5h
Poultry
-Light meat
-Dark meat
150°F
167°F
1h
45m
3h
5h
Pork
-Tender cuts
-Tough cuts
150°F
158°F
1h
18h
4h
24h
Beef
-Rare
-Medium rare
-Medium
-Medium-well
-Well
129°F
134°F
140°F
150°F
160°F
1h
1h
1h
1h
1h
3h
3h
3h
3h
3h
Seafood
-Fish
-Shelfish
122°F
131°F
40m
15m
1.5h
45m
Veggies
-Tender
-Tough
180°F
185°F
15m
30m
30m
1h
Note: Times and temperatures are approximate and may vary due to size
and thickness.

Cleaning and maintenance
13
Cleaning and maintenance
CAUTION:
Always be sure that the Sous Vide is unplugged and completely cooled before
cleaning or attempting to store the item. NEVER IMMERSE the Sous Vide control
panel in water or any other liquid. Use a soft, damp cloth to clean the Sous Vide
main unit and control panel.
Cleaning the heating element and cover:
1. Hold the Sous Vide with 2 hands, firmly press the handle, pull down on the
rubber cover to expose the heating element cover lock and turn to the left
(counter clockwise) to unlock.
2. Pull gently, yet firmly, until the heating element is exposed.
3. Wash cover in warm water and dish soap. Do not use abrasive materials.
4. Before replacing and storing, dry thoroughly, replace heating element inside
cover and turn to the right (clockwise) to lock and replace rubber cover.
Note: If the heating element coils need cleaning, use dish soap and a soft tooth
brush and rinse thoroughly before using or storing.
If mineral build up should develop on the heating element of your Sous Vide,
follow these steps:
1. Clamp the Sous Vide to a pot and fill to the MAX level indicated on the heating
element with one-part water and one part distilled white vinegar ratio.

Cleaning and maintenance
14
2. Using the + button; program the SET TEMPERATURE to 158° F. Once the SET
TEMPERATURE is reached, allow the water and vinegar mixture to continue
circulating for 20 minutes.
3. After cleaning for 20 minutes, turn the Sous Vide OFF, unplug and allow to
cool.
4. Allow the Sous Vide to dry thoroughly before to storing for future use.
DO NOT immerse the Sous Vide control panel in water or any other liquid. NEVER
use gasoline, benzene or paint thinner to clean the surface. Do not use abrasive
materials, this will damage the surface of the Sous Vide.
SAVE ALL INSTRUCTIONS!

Other useful information
15
Other useful information
Technical specifications
Model Number H-106
Rating Voltage 120V –60Hz
Nominal Power 800W
Storing
Store the Sous Vide in a dry location.
Do not place heavy items on top of the product as this may damage the Sous
Vide.
Service center
If you have any questions in regard to the operation of this Sous Vide please
contact the service center at:
Tel: [phone]
Business Hours: Mon-Fri 10:00am –5:00pm EST
Email: [email protected]are
Environmental protection
If the Sous Vide should no longer work at all, please make sure that it is disposed
of in an environmentally friendly way.

Other useful information
16
Contenido
Lista de piezas .....................................................17
Contenido .......................................................17
Antes del primer uso.......................................18
Instrucciones de seguridad importantes.............19
Instrucciones para el usuario ..............................23
Consejos útiles................................................25
Limpieza y almacenamiento................................27
Otra información útil ..........................................29
Especificaciones técnicas ................................29
Almacenamiento.............................................29

Lista de piezas
17
2
7
8
6
5
9
10
Piezas principales
1. Unidad principal
2. Pinza
3. Mango de goma antideslizante
4. Elemento calefactor con protección
5. Panel de control LED
6. Temperatura actual
7. Temperatura/temporizador ajustos
8. ENCENDIDO/APAGADO
9. Ajuste de temperatura/temporizador
10. Ajustar el temporizador
Contenido del embalaje
Sous Vide
Manual de instrucciones
3
1
4

Antes del primer uso
18
Antes del primer uso
Tenga en cuenta que el Sous Vide puede producir olor o humo cuando se encienda por
primera vez cuando se eliminan los residuos del proceso de producción. Esto es normal y
no indica defectos o peligros. Este leve olor o humo desaparecerá tras unos usos.
1. Quite el Sous Vide de la caja.
2. Deshágase de materiales de embalaje no deseados como cartones, plásticos
o poliestireno.
3. Verifique que la unidad no esté dañada.
4. Limpie con un paño suave y húmedo. NO SUMERJA EL PANEL DE CONTROL
SOUS VIDE EN AGUA O CUALQUIER OTRO LÍQUIDO.
5. Solo puede sumergir el elemento calefactor en agua: NO SUMERJA el cable de
alimentación, el panel de control o la pinza en agua. Si se sumerge cualquier
parte excepto por el elemento calefactor, desenchufe de inmediato y deje
secar bien.
NO USE MATERIALES ABRASIVOS PARA LIMPIAR LA SUPERFICIE
NO SUMERJA EL PANEL DE CONTROL DEL SOUS VIDE EN AGUA O
CUALQUIER OTRO LÍQUIDO

Instrucciones de seguridad importantes
19
INSTRUCCIONES DE SEGURIDAD
IMPORTANTES
Cuando utilice aparatos eléctricos, se deben tener en cuenta precauciones de seguridad
básicas.
LEA Y GUARDE TODAS LAS
INSTRUCCIONES ANTES DE USAR LA
COCINA DE INMERSIÓN SOUS VIDE.
1. Para protegerse contra una descarga eléctrica, no sumerja el cable de
alimentación o los enchufes en agua u otro líquido. Este es un electrodoméstico.
Para evitar el riesgo de descarga eléctrica o lesiones graves, siempre debe usarlo
con las manos secas.
2. Es necesaria una atenta supervisión cuando el aparato es usado por niños o cerca
de estos. Este Sous Vide no está diseñado para que la utilicen personas (incluidos
niños) con disminución en sus capacidades físicas, sensoriales o mentales; o con
falta de experiencia y conocimiento, a menos de que hayan recibido supervisión o
instrucciones relativas al uso del Sous Vide por una persona responsable de su
seguridad.
3. No utilice el Sous Vide con un cable de alimentación o enchufe dañados o si el
Sous Vide se avería, se deja caer o se daña de cualquier manera.
4. No utilizar al aire libre. Solo para uso doméstico. No utilice el aparato para un uso
que no sea el previsto.
5. Use el Sous Vide solo como se describe en este manual. El uso de accesorios no
recomendados por el fabricante podría causar daños al Sous Vide o lesiones
personales.
6. El Sous Vide no está diseñado para que se lo utilice con un temporizador externo
o un sistema de control remoto independiente.
7. Nunca toque el elemento calefactor del Sous Vide durante su uso o antes de que
se enfríe. Use el mango superior. NO transporte el Sous Vide por el cable de
alimentación o el elemento calefactor, solo el mango.
8. Desconecte la unidad del tomacorriente antes de quitarla de la olla o del
contenedor apto para alimentos, cuando no la utilice y antes de limpiarla.
9. Deje que el Sous Vide se enfríe por complete antes de limpiarlo. NO sumerja el
panel de control del Sous Vide en agua u otro líquido.

Instrucciones de seguridad importantes
20
10. No deje que el cable de alimentación cuelgue sobre el borde de una mesa o
mostrador, ni que toque ninguna superficie caliente.
11. No use el Sous Vide si el cable de alimentación o el enchufe están dañados de
alguna manera o si están quebrados, abollados o mellados.
12. Nunca deje el Sous Vide conectado al tomacorriente cuando no lo use.
13. No coloque la unidad sobre o cerca de una hornilla caliente de gas o eléctrica, ni
adentro de un horno caliente.
14. No toque las superficies calientes. Utilice los mangos o agarraderas.
15. Para desconectarlo, apáguelo siempre primero y luego desenchúfelo del
tomacorriente.
16. No limpie el producto con estropajos de metal. Es posible que se desprendan
pedazos del estropajo, entren en contacto con piezas eléctricas y generen un
riesgo de descarga eléctrica.
17. No encienda el Sous Vide si la olla no tiene agua.
18. Nunca utilice el Sous Vide a menos que el nivel de agua esté entre los niveles
“MIN” y “MAX”. Solo puede sumergir el elemento calefactor en agua: NO
SUMERJA el cable de alimentación, el panel de control o la pinza en agua. Si se
sumerge cualquier parte excepto por el elemento calefactor, desenchufe de
inmediato y deje secar bien.
19. Mientras cocina, se puede ahorrar energía cubriendo la olla o el contenedor apto
para alimentos. Nota: No utilice el envoltorio plástico ya que nunca debe entrar
en contacto con el elemento calefactor.
20. Después de completar el ciclo de cocción, no use el agua que resta en la olla para
beber o para seguir cocinando.
21. Debe tener mucho cuidado al mover cualquier electrodoméstico que contenga
aceite caliente u otros líquidos calientes.
22. Se deben colocar todos los artículos comestibles en una bolsa sellable apta para
alimentos y no directo en el agua con el Sous Vide.
23. No precaliente ningún artículo comestible.
24. No permita que el Sous Vide permanezca en agua cuando no se está utilizando.
25. El Sous Vide debe estar en una olla donde el nivel de agua esté entre las líneas
MIN y MAX para obtener el mejor resultado.
26. No utilice carne o pollo congelado a menos que esté bien descongelado.
2
PRECAUCIÓN: Esta unidad se calienta mucho y se debe tener mucho cuidado
durante y después de la cocción y hasta que se haya enfriado por completo,
después de desenchufar el Sous Vide del tomacorriente.
¡GUARDE TODAS LAS INSTRUCCIONES!
