Ambient weather Ws-108 User manual

Ambient Weather WS-108 Keychain Altimeter, Barometer,

Thermometer & Compass User Manual

Table of Contents

1. Introduction.....................................................................................................................................2

2. Getting Started ................................................................................................................................2

2.1 Parts List.................................................................................................................................2

2.2 Precautions.............................................................................................................................2

2.3 Installing the Battery..............................................................................................................2

3. Display Layout................................................................................................................................3

4. Set Mode.........................................................................................................................................4

4.1 Forecast Mode........................................................................................................................4

4.2 12Hr/ 24Hr Format.................................................................................................................4

4.3 Time........................................................................................................................................4

4.4 Date ........................................................................................................................................5

4.5 Units of Measure....................................................................................................................5

4.6 Magnetic Declination.............................................................................................................5

4.7 Compass Calibration ..............................................................................................................5

5. Normal Mode..................................................................................................................................6

5.1 Time and Date Display...........................................................................................................6

5.2 Altitude and Temperature Display andAltitude Calibration..................................................6

5.3 High Altitude Display.............................................................................................................7

5.4 Barometric Pressure Mode.....................................................................................................8

5.5 Compass Mode.......................................................................................................................8

6. Altimeter Mode...............................................................................................................................8

6.1 Climb Altitude........................................................................................................................9

6.2 Climb Rate..............................................................................................................................9

7. Backlight.......................................................................................................................................10

8. Low Battery Indicator...................................................................................................................10

9. Discussion of Features and Limitations........................................................................................10

9.1 Weather Forecasting.............................................................................................................10

9.2 Magnetic Declination...........................................................................................................10

9.3 Temperature Changes........................................................................................................... 11

9.4 Pressure Altitude vs. True Altitude....................................................................................... 11

9.5 Relative Pressure vs. Sea-level Pressure.............................................................................. 11

9.6 Digital Compass Measurement ............................................................................................ 11

10. Glossary of Terms.....................................................................................................................12

11. Specifications ...........................................................................................................................12

12. Other Specifications .................................................................................................................12

13. Troubleshooting Guide.............................................................................................................12

14. Accessories...............................................................................................................................14

15. Liability Disclaimer..................................................................................................................14

16. Warranty Information...............................................................................................................14

1. Introduction

Thank you for your purchase of the Ambient Weather WS-108 Keychain Altimeter, Barometer,

Thermometer & Compass. The following user guide provides step by step instructions for operation

and troubleshooting. To download the latest manual and additional troubleshooting tips, please visit:

http://ambientweather.wikispaces.com/ws108

2. Getting Started

2.1 Parts List

QTY Item

1 WS-108 Unit

Dimensions: 2.5 x 2.0 x 0.6 inches

1 CR2032 battery

1 Carbineer clip

2.2 Precautions

Caution: This unit is water resistant but not water proof. Do not submerse in water. When

installing the battery, make sure the gasket is properly seated (see battery installation instructions).

Avoid leaving out in the rain.

Caution: Keep away from strong magnetic forces, which can destroy the compass.

Caution: Do not drop or apply excessive force to the LCD display. When replacing the battery,

apply force to the outer ring.

Caution: Do not operate outside of the specified temperature range (14 to 140 °F). Use your

body warmth to keep within the low temperature range.

Note: Do not use a magnetized CR2032 battery, which can corrupt the compass measurement.

Note: Do not use near strong magnetic or EMI forces (TVs, computers, electronics) which can

corrupt the compass measurement.

2.3 Installing the Battery

Rotate the back cover counter clockwise about 20°, gripping the unit with both hands, using your

index fingers and thumbs. Rotate until it stops, then gently pry off the back cover with your fingers,

exposing the battery compartment.

Note: you may have to squeeze on the outer ring (not the display) and apply force in the

clockwise and counterclockwise direction repeatedly (work back and forth) to free the back cover

after extended use, due to sweat and other debris. Make sure your fingers are dry.

Insert the CR2032 battery (+ side up), and close the back cover, insuring the gasket is firmly seated in

the housing trace, as shown in Figure 1.

To remove the battery, use a small pen or paperclip to pry the battery out of the battery compartment.

To close the back cover, rotate the back cover clockwise until the back cover is completely closed.

The display should be powered up in the time and date mode, and ready for use.

Figure 1

3. Display Layout

The display layout is shown in Figure 2.

Figure 2

1. Pressure Altitude

2. Pressure Trend (up, down, steady)

3. Relative Pressure

4. Forecast icon (sunny, partly cloudy,

cloudy, rainy)

5. Temperature degrees

6. Altitude units of measure (Feet)

7. Altitude units of measure (Meters)

8. Pressure units of measure (hectopascals)

9. Pressure units of measure (inHg)

10. Temperature units of measure (degC or

degF)

11. Low battery indicator

12. Compass mode

13. 16 point compass rose

14. Secondary parameter display

15. Sea level pressure

16. Barometric pressure mode

17. AM/PM time indicator (P = PM)

18. Primary parameter display

19. Altitude rate of change units of measure

(ft/min or m/min)

4. Set Mode

To enter the SET Mode, press and hold the MODE button for 3 seconds. To exit the SET mode and

return to the NORMAL mode at any time, press and hold the MODE button again for 3 seconds. The

SET mode will also automatically exit after 30 seconds of inactivity, and return to the NORMAL

mode.

The following sections describe the settings available in the Set Mode. To skip any step, press the

MODE button again.

Set Modes:

Forecast -> 12/24 Hr -> Hour -> Minute -> Month -> Day -> Temperature Units -> Pressure Units ->

Altitude Units -> Compass Magnetic Declination -> Compass Calibration

4.1 Forecast Mode

The current forecast will begin flashing. Press the ALTI button to set the forecast icon to the current

weather conditions, as defined below:

Condition Icon

Sunny

Partly Cloudy

Cloudy

Rainy

Press the MODE button to continue to the next step.

4.2 12Hr/ 24Hr Format

The hour format will begin flashing. Press the ALTI button to toggle between 12 Hour (AM/PM)

and 24 Hour format. Press the MODE button to continue to the next step.

4.3 Time

The hour will begin flashing. Press the ALTI button to advance the hour. Note that in the 12 hour

mode, the Picon will be displayed to designate PM (no icon is present for AM). Press the MODE

button to set the minute.

The minute will begin flashing. Press the ALTI button to advance the minute. Press the MODE

button to continue to the next step.

Note: If 12 hour time is selected, the date format is automatically displayed as Month.Day. If 24

hour time is selected, the date format is automatically displayed as Day.Month.

4.4 Date

The month will begin flashing. Press the ALTI button to advance the month. Press the MODE button

to set the day.

The day of the month will begin flashing. Press the ALTI button to advance the day. Press the

MODE button to continue to the next step.

4.5 Units of Measure

The units of measure icon (UN) will be displayed and the temperature units of measure will begin

flashing. Press the ALTI button to toggle between °F and °C. Press the MODE button to set the

barometric pressure units of measure.

The BARO icon will be displayed and the barometric pressure units of measure will begin flashing.

Press the ALTI button to toggle between inHg and hPa. Press the MODE button to set the altimeter

units of measure.

The ALTI icon will be displayed and the altitude units of measure will begin flashing. Press the ALTI

button to toggle between feet (ft) and meters (m). Press the MODE button to continue to the next step.

4.6 Magnetic Declination

The compass magnetic declination calibration Cb icon will be displayed and the declination

calibration value will begin flashing. Press the MODE button to advance to the next step.

Note: The maximum declination is 30°. To set a negative declination, advance past 30° to “roll

over” to -30°.

4.7 Compass Calibration

The 16 point compass reference points will begin flashing. Press the ALTI button to enter the compass

calibration mode. The compass angle and CAL icon will be displayed.

The following procedure must be carefully and precisely followed or the calibration procedure will

fail.

Note: The compass calibration procedure may exit prematurely if calibration is achieved. This

usually occurs when one of the four calibration points have been passed through to get to 0°.

1. On a flat, level surface, slowly rotate the compass in the clockwise direction. When the

compass reaches exactly 0°, stop for at least 3 seconds. If you overshoot this reading, slowly

rotate counterclockwise until it reads exactly 0°. Proceed to the next step.

2. Rotate the compass clockwise until it reads exactly 90° and stop for at least 3 seconds. If you

overshoot this reading, slowly rotate counterclockwise until it reads exactly 90°. Proceed to

the next step.

3. Rotate the compass clockwise until it reads exactly 180° and stop for at least 3 seconds. If

you overshoot this reading, slowly rotate counterclockwise until it reads exactly 180°.

Proceed to the next step.

4. Rotate the compass clockwise until it reads exactly 270° and stop for at least 3 seconds. If

you overshoot this reading, slowly rotate counterclockwise until it reads exactly 270°.

Proceed to the next step.

5. Rotate the compass clockwise until it reads exactly 0° again, and stop for at least 3 seconds.

6. Once calibrated, the CAL icon will disappear and the unit will return to normal mode. If this

does not occur, please repeat this procedure again. If successful, the unit will return to

normal mode.

5. Normal Mode

The default normal mode display is Time and Date. This mode consumes the least amount of energy,

and will always return to the Time and Date mode after 30 seconds of inactivity to save battery life.

Normal Modes:

Time/Date -> Altitude/Temperature -> High Altitude -> Measured Barometer/Sea-level Barometer ->

Compass/Direction

5.1 Time and Date Display

The default display mode is Time and Date. The time is the primary display and the date is the

secondary display, with the forecast icon and pressure trend at the top of the display, as shown

in Figure 3.

Press the MODE button to continue to the next display mode.

Figure 3

5.2 Altitude and Temperature Display and Altitude

Calibration

The altitude is the primary display and the temperature is the secondary display, with the forecast icon

and pressure trend at the top of the display, as shown in Figure 4.

Since the altimeter measures Pressure Altitude and not True Altitude, the altimeter must be calibrated

at a known altitude, whenever convenient (for example, at the beginning of a hike). Pressure Altitude

vs. True Altitude is discussed in Section 9.

To calibrate the altitude, while in the Altitude and Temperature Display Mode, press and hold the

MODE button for 3 seconds.

The calibrated altitude x 1000 will begin flashing. Press the ALTI button to advance the calibrated

altitude x 1000 setting. Press the MODE button to continue.

The calibrated altitude x 100 will begin flashing. Press the ALTI button to advance the calibrated

altitude x 100 setting. Press the MODE button to continue.

The calibrated altitude x 10 will begin flashing. Press the ALTI button to advance the calibrated

altitude x 10 setting. Press the MODE button to continue.

The calibrated altitude x 1 will begin flashing. Press the ALTI button to advance the calibrated altitude

x 1 setting.

Press and hold the MODE button for 3 seconds to exit the altitude calibration mode.

Press the MODE button to continue to the next display mode.

Figure 4

5.3 High Altitude Display

The high altitude (since reset or calibration) is the primary display and the H (high) icon is the

secondary display, as shown in Figure 5. To reset the high altitude, press and hold the MODE button

for 3 seconds, and the high altitude will reset to the current altitude.

Press the MODE button to continue to the next display mode.

Figure 5

5.4 Barometric Pressure Mode

The measured barometer (relative pressure) is the primary display and the sea-level pressure (absolute

pressure) is the secondary display, with the forecast icon and pressure trend at the top of the display, as

shown in Figure 4.

Press the MODE button to continue to the next display mode.

Figure 6

5.5 Compass Mode

The compass direction (in degrees) is the primary display and the 16-point cardinal direction (N, NNE,

NE, ENE, E, ESE, SE, SSE, S, SSW, SW, WSW, W, WNW, NW, NNW) is the secondary display, as

shown in Figure 7. A four point bearing is indicated at the circumference of the display, with the main

bearing indicator pointing north.

Press the MODE button to return to the time and date display mode.

Figure 7

6. Altimeter Mode

To enter the ALTIMETER mode, while in the NORMAL mode, press the ALTI button. To exit the

ALTIMETER mode and enter the NORMAL mode, press the ALTI button again.

The altimeter mode will return to normal mode time display every hour to conserve battery life.

Altitude Modes:

Climb Altitude/Altitude -> Climb Altitude/Climb Rate

6.1 Climb Altitude

The climb altitude (the change in altitude since the last reset) is the primary display and the current

altitude is the secondary display, as shown in Figure 8.

To rest the climb altitude, press and hold the MODE button for 3 seconds, and the climb altitude will

reset to 0.

Figure 8

Press the MODE button to continue to the next display mode.

6.2 Climb Rate

The climb altitude (the change in altitude since the last reset) is the primary display and the altitude

rate of change in the last minute (ft/min) is the secondary display, as shown in Figure 9. The climb rate

updates once per minute.

Figure 9

7. Backlight

To activate the backlight, press and hold the ALTI button for three seconds. The backlight will remain

on for 30 seconds of inactivity.

8. Low Battery Indicator

When the low battery indicator icon is displayed , it is time to replace the battery.

9. Discussion of Features and Limitations

9.1 Weather Forecasting

The weather forecast or pressure tendency is based on the rate of change of barometric pressure. In

general, when the pressure increases, the weather improves (sunny to partly cloudy) and when the

pressure decreases, the weather degrades (cloudy to rain).

The weather forecast is an estimation or generalization of weather changes in the next 24 to 48 hours,

and varies from location to location. It is not an indication of current conditions. The tendency is

simply a tool for projecting weather conditions and is never to be relied upon as an accurate method to

predict the weather.

Barometric pressure is adversely affected by altitude and to a lesser extent, changes in weather

conditions. The weather forecasting tool is only useful at a fixed position and must be reset to the

current weather conditions if you change altitude. Thus, if you are hiking, climbing or driving, and

continuously changing altitude, the weather forecasting tool must be recalibrated.

9.2 Magnetic Declination

Magnetic declination is defined as the angle between magnetic north (the direction the north end of a

compass needle points) and true north. Only a GPS can determine true north by knowing your exact

orientation on the earth.All digital compasses measure magnetic north.

The declination is positive when the magnetic north is east of true north. The declination is negative

when the magnetic north is west of true north. To determine the declination for your location, visit:

http://www.ngdc.noaa.gov/geomagmodels/Declination.jsp

For example, Phoenix,AZ produces the following result:

Declination = 10° 59' E changing by 0° 6' W/year (or +10 degrees 59 minutes changing –6 minutes

per year). To convert to decimal format:

Declination = 10° + 59’/60 (‘/°) = 10.98° (rounded to the nearest integer, Declination = 11°).

Enter +11 into the display. This will offset magnetic north by +11 degrees (or 11 degrees to the East)

to true north.

Note that the magnetic declination changes as a function of time for your location. In the above

example, the declination changes -6 minutes (or 0.10° per year, or about 1° every 10 years). Thus, the

time function is insignificant.

Table of contents

Popular Compass manuals by other brands

Silva

Silva EXPLORER 203 quick start guide

Quechua

Quechua C Quechua 400 manual

Brunton

Brunton 54lu user guide

Advanced Navigation

Advanced Navigation GNSS Compass Reference manual

Brunton

Brunton Nomad V2 owner's manual

Brunton

Brunton NOMAD V2 PRO user manual

Bushnell

Bushnell 70-0101 instruction manual

Brunton

Brunton OSSl quick start guide

BW SENSING

BW SENSING LEC315M Technical manual

True North

True North Revolution user guide

Furuno

Furuno Sc 50 Operator's manual

Nexus

Nexus NX2 Compass Installation and operation manual

Anschutz

Anschutz 133-811.NG001 Operator's and service manual

SG Brown

SG Brown Meridian System manual

Riviera

Riviera ASTRA 4 user manual

Nexus

Nexus NX Compass Installation and operation manual

Hama

Hama Digital Compas operating instructions

Oregon Scientific

Oregon Scientific RA202 user manual

Ambient Weather WS-108 User manual

Popular Compass manuals by other brands
