AMBIENTECH TONE-WS Series User manual

1
Installation Instructions
P/N: TONE-WSx | WARM-WSx
DIMMER
E507432
R
Item Identification
Overview of System Wiring
Tools Needed
Important Notes
Please Read Before Installation!
Wall Switch
Cover Plate
Mounting
Screws Wire
Connectors
x 5
x 2
Wire Stripper VoltmeterScrewdriver
Neutral
120 V~
50/60 Hz
White
Green
Ground
- -
+
LED Driver
Wall Switch
UP to 7
Drivers
Line/Hot Black Red
Green
Ground
- -
+
Black
White Green
Warm White Cool White
RF
1
2
4
3
Automatic RF Pairing using an electrical signal (CCT/Dimming)
Max distance between Wall Switch and Driver 30m/100 ft
1
One wall switch can control up to 7 LED drivers
2
3
4
12/24VDC three wire output
The Driver is compatible with any CV Tunable White/Dim-to-Warm LEDs
• Neutral Wire required. If you don’t have Neutral wire in
the wallbox, please consult an electrician.
• The system is to be installed in accordance with the
National Electrical Code or local code.
• The system is to be installed and serviced by a qualified,
licensed electrician.
• Wall switch must be grounded in accordance
with the NEC or local codes.
Wall Bracket
Bracket Lock ScrewLED Driver
LED Driver

2
Installation Instructions
LED Driver Installation
WARNING
Quick Specs
Input voltage 120VAC
Output voltage 12 / 24VDC (Check Sticker)
Ambient Temp -30°C - + 40°C / -86°F - + 104°F
Enviroment Dry and Damp
Before You Begin
4. Wire Connections
With the power switched off, connect the wires according
to the wiring diagram below.
Note: If you are connecting more than one wire to each
terminal, it is recommended to form a pigtail connection.
To avoid fire, shock, or death, turn the power off
at circuit breaker and test to ensure
the power is off before wiring.
ON
OFF
2. Punch knockouts for wiring
conduit access
1. Open wiring compartment
Wiring
compartment
Strip 1/4”(0.7 cm)
Neutral Ground Line
--
+
LED Driver
Warm White
Cool White
--
+
Black
White
Green
Before You Begin
Determine the location of system parts :
1. Wall Switch
2. LED Driver
Note: Max distance between Wall Switch and LED Driver
30m/100 ft.
Mount the Driver :
Select a suitable location, which can provide
adequate support for the weight of the driver.
Note : Install the LED Driver in a well-ventilated
area free from explosive gases and vapors.
3.
B. Position LED Driver at an angle
over the bracket’s latches
A. Mount the wall bracket
C. Place LED Driver on the
bracket latches
D. Align LED Driver on bracket
E. Install the supplied lock screw

3
Pairing
Button
LED Indicator
Slider
Installation Instructions
Wall Switch Installation
Step 1: Prepare Wall Box Wires
1. Make sure that the ends of the wires from the wall box are straight (cut if needed).
2. Strip the wire insulator for each wire inside the wall box as shown here:
Strip the wire insulation from each wire.
Strip 5/8”(1.6 cm)
Wall box
1. A standard single-gang wall box sized 3 x 2 x 2 ½ cm will service Dimmer
2. Not compatible with multi or double Mud Rings.
3. When using a retrofit gang box (cut in box) you might need to recess the ears.
If you are installing more than one Wall Switch unit, all
others must be switched Off while pairing.
1. Make sure both sliders are set to the top and the
Wall Switch is switched Off.
2. Switch the power ON at the circuit breaker, the
green LED Indicator will light up.
3. Turn ON the Wall Switch, the green LED Indicator
will blink
while pairing.
5. After up to 15 seconds, your LED fixture will be
paired with the Wall Switch.
6. To verify pairing is successful, move the sliders and
ensure that the LEDs respond accordingly.
7. If youre installing a smart wall switch Scan the QR
code to download the app. Follow the instructions
to connect to the SmartAir App.
* If pairing is not successful press the pairing button.
Note: A maximum of 7 LED Drivers can be controlled with each Wall Switch.
Maximum Load
Input Voltage 120VAC
Max Load 700W
Pairing
Step 2: Wire Wall Switch
Wiring Description (Using wire connectors)
1. Connect the green (or bare copper) wire from the wall box
to the green Wall Switch wire.
2. Connect the line/hot wire from the wall box to the black Wall Switch wire.
3. Connect the black LED Driver wire to the red Wall Switch wire.
4. Connect the white wire from the wall box to the white LED Driver wire
and the white Wall Switch wire.
Connect wires according to the wiring diagram below.
Red
Green Ground
Black
Neutral
White
Line / Hot
120 V~
50/60 Hz
Wall Switch
(In-Wall Dimmer)
LED Driver
(Load)
Step 3: Mount the Wall Switch
Mount the Wall Switch into the wall box using the screws
provided.
Step 4: Restore Power
1. Turn the power ON at the circuit breaker.
2. Verify 120V with a Voltmeter
ON
OFF
Before You Begin
To avoid fire, shock, or death, turn the power Off
at circuit breaker and test to ensure
the power is Off before wiring.
ON
OFF
Connect to the SmartAir App
• Scan the QR code to download
the App. Follow the instructions to
connect to the SmartAir App

4
Installation Instructions
Operation - Tunable White Wall Switch
Customer Assistance
Operation - Dim-to-Warm Wall Switch
For more info
For technical questions regarding the installation or operation
of this product, please contact our customer support team:
www.ambientechinc.com
347-334-6368 ext 3
Caution
To Reduce the Risk of Overheating And Possible Damage To
Other Equipment, Do Not Install To Control A Receptacle,
A Motor-Operated Appliance, Or A Transformer-Supplied
Appliance.
"GRADATEURS COMMANDANT UN BALLAST - AFIN DE
REDUIRE LE RISQUE DE SURCHAUFFE ET LA POSSIBILITE
D'ENDOMMAGEMENT A D'AUTRES MATERIELS, NE PAS
INSTALLER POUR COMMANDER UNE PRISE, UN APPAREIL A
MOTEUR,"
FCC/IC Information
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
On/Off
Dimming
Control
Color
Temperature
Control
On/Off
Switch
Dim-to-Warm Control
Troubleshooting
Wall Switch LED
Indicator blinking
RED
The Reset button is
pressed while
the wall switch
is Off
Turn ON the Wall Switch
and press the Pairing
button again
Wall Switch
LED Indicator
steady RED
The Wall Switch is
trying to perform
pairing
Turn On the
Wall Switch until
paring is completed
Lights do not
respond to
Wall Switch
The Breaker is Off
or tripped
Turn power On at
the Circuit breaker
Improper pairing Perform “Pairing”
Improper wiring Make sure all wires
are connected
according to the
wiring diagram
Short circuit at
the LED Driver
output
Check LED Driver
output for short
circuits
Symptoms Cause Possible Solution
The wall switch is
controlling
the wrong lights
(Only if multiple
Wall Switches units are
installed in the
same location)
The Wall Switch was
paired with the
wrong LED Driver
Perform “Pairing”.
Make sure all the other
Wall Switches are turned
Off while pairing
Wall Switch / LED Driver
Replacement
Any reason Perform “Pairing”.
Make sure all the other
Wall Switches are
turned Off while
pairing
