Bari 1000
e Bari 1000 is a unique healthcare patient support
system providing dual width capabilities for safe
bed transport. Created specically to accommodate
large and extra tall patients, all in one easy-to-use
design, the Baribed 1000 oers multiple support
functions to both the patient and the caregiver.
2 Patient Surface Widths
in One Frame 39” Width
Extending to 48”
3 Piece Interchangable
Width Mattress with
Detachable Side Bolsters.
Exit / Enter at Foot
of Bed Option to
Exit at the Foot End.
Bari 1000

861 Taylor Rd., Suite “I”
Columbus, Ohio 43230
www.ame-medical.com
Phone: [phone]
Fax: [phone]
[email protected]
PAGE 2
Length adjustable,
reinforced
triangle positioning bar
Great strength, easy
adjustment position
adjustable traction fixtures.
Heavy duty
6” x 1 1/4” steer
and lock casters.
1000 lb. Capacity - Static & Transfer. e Baribed 1000
provides smooth, safe transport of patients up to and including
1000 lbs. Designed specically for the maximum in stability
and safety, providing dependable support to both patient and
sta.
Full Frame Trapeze Option accompanies the patient on the
Baribed 1000 during transfers from one location to another
providing solid, no bend-and-sway support for complete peace
of mind. is unique trapeze system provides an enhanced,
strength enriched frame to ensure condence use, safety and
maximum stability.
State-of-the-art Low Voltage Actuator System. Hospital grade
plug providing low/high eciency and low power consumption
at 1.6 amps.
• Trendelenburg / Reverse Tendelenberg
• Hi-Lo: 28” to 14”
• Cardiac Lounge / Chair Positioning
• Integrated Scale System measures patient weight in lbs. and
kgs. with accuracy of 0.2% +/- 1 digital reading
• Compact “Fold and Roll” 1 person delivery system
• 2 Widths in 1 Frame 39” width extending to 48”
• Full Frame Trapeze fully adjustable, maximum support
• Battery Back-up No hand cranks to lose
• CPR Release Mechanism
• Adjustable, powder coated half side rails telescoping to 6”
• 1 Wand Finger tip Control
• Oak Finish headboard and footboard
• Easy Patient Egress - In and Out of the foot of the bed with
the Dual Passage Assist Option.
key product features

861 Taylor Rd., Suite “I”
Columbus, Ohio 43230
www.ame-medical.com
Phone: [phone]
Fax: [phone]
[email protected]
IMPORTANT SAFETY INFORMATION
PAGE 3
WARNNGS
• All persons with access to the bed must read the Owner’s Manual before using the bed. Failure to do so could
result in improper use which could damage the bed or injure persons.
• 1000 lb. patient use weight limit. Use of bed with persons above this weight may cause damage to bed and
persons.
• To transport a patient to bed, the bed high/low must be in it’s lowest position with the frame resting on the
transverse caster bars. Failure to do so could result in compromising the structural integrity and stability of
the bed which could damage the bed or injure persons.
• Possible re hazard exists when bed is used with oxygen administering equipment other than a nasal mask or
1/2 bed length tent. Oxygen tents should not extend below the mattress support level.
• e electronics are not designed to be used in environments containing ammable anesthetics. Possible re
hazard exists.
• Keep the side rails in a raised position while patient is on the bed to prevent patient from accidentally falling
o the bed.
• If patient restraints are used, they must be attached to some point on the bed that articulates when the
gatches are raised and lowered. Failure to do so could result in the restraints injuring the patient.
HELPFUL HINTS and CAUTIONS
• Keep the power cord plugged into a wall outlet.
• CAUTION: Run the cord under the bed frame and positioned so as to prevent being walked on or rolled
over by the bed casters.
• Elevating the head gatch facilitates easier breathing for heavier patients. Consult a doctor.
• If needed, orthopedic equipment can be attached to the bed.
• CAUTION: hang the hand control pendant on the side rail when not in use. Run the cord under the bed
frame and keep it clear of moving parts to prevent possible damage to the cord.
• CAUTION: When the bed is in use, the casters must be positioned so that the locking tabs are locked and
pointed towards the foot end of the bed. Failure to do so will cause damage to the bed.
• Keep the head of the bed a minimum of 4” from walls to avoid contacting a wall when running the hi-low.
Failure to do so could result in damage in the bed and/or the wall.

861 Taylor Rd., Suite “I”
Columbus, Ohio 43230
www.ame-medical.com
Phone: [phone]
Fax: [phone]
[email protected]
ASSEMBLY / DISASSEMBLY INSTRUCTIONS - UNFOLDING THE BED FOR USE
PAGE 4
NOTE: Move the bed to an open area large enough to unfold the bed. If your bed is not equipped
with the optional scale system, please disregard the information regarding the system.
• Set the head and foot boards aside to be assembled later.
WARNING: Lock the four transport casters to prevent
the bed from moving when you unfold the head and foot
sections as movement can cause injury.
• Remove the “L” shaped foot end transport latch located on
the transport pole.
• Gently lower the foot end section of the bed. WARNING:
If the foot end or head end of the bed is allowed to drop
while being lowered, injury to persons and/or damage to the
bed could occur.
• Make sure that the black woven safety strap located at the
head end of the bed is securing the head gatch patient
support surface to the base. WARNING: Unexpected
movement of the patient support surface and possible injury
could occur if the safety strap is not in place.
• Remove the head end transport latch bracket located on the
transport pole placed vertically in the center of the bed.
• Gently lower the head section of the bed. WARNING: If
the foot end or head end of the bed is allowed to drop while
being lowered, injury to the person and/or damage to the
bed could occur.
• Release the black woven safety strap located at the head end
of the bed and the remove 3/4” wrench.
• Slide a center anti-pivot locking bar into position and pin
it. One end of the bar must be pinned in place and the
opposite end must be anchored through a side bracket by
means of a bolt and square washer. Tighten the bolt rmly
with the 3/4” wrench.
• Repeat the installation process on the opposite side of the bed.
WARNING: Failure to properly install the center anti-pivot
locking bars could result in injury to persons and/or damage
to the bed.
• IMPORTANT: Loosen the four “jack bolts” used to protect
the scale system load cells during storage and transport.
Turn the bolts counterclockwise until they spin freely.
Failure to loosen jack bolts will cause the scale system
measurements to be inconsistent!
• Store the 3/4” wrench in Velcro holder with black safety
strap.
• CAUTION: Position and lock the four casters (located at
the corners o the bed) with locking tabs facing the foot
end of bed. Failure to do so will result in damage to the
casters during hi-low use.
• Plug bed power supply into an AC outlet.
• Raise bed hi-low approx. 5 inches to take weight o of the
center transport wheels.
• Remove the pull pin securing central transport system, pivot
the system inward and up. Lock the transport system “up
out of the way” with the pull pin holder under the head
gatch.
• Raise the head gatch and store the central transport pole in
it’s holder under the head gatch.
• Lower the Hi-low system.
• Position the hinged mattress support tabs as required to
accommodate various mattress widths.
• Install mattress system.
• Install head and foot boards into square tubes at the ends of
the bed.
• Hang the scale readout assembly on the foot board and
connect the cable.

861 Taylor Rd., Suite “I”
Columbus, Ohio 43230
www.ame-medical.com
Phone: [phone]
Fax: [phone]
[email protected]
OPERATIONAL INSTRUCTIONS
e Baribed 1000 operates from a low voltage power supply with a battery back up. If the patient must change position while
being transported or in the event of a power failure, the batter backup will support several position changes to maintain patient
comfort.
Trendelenburg FUNCTION: e Trendelenburg function is controlled by the same buttons in the hand control as the hi-low
function.
To access the Trendelenburg position lower the hi-lo to the lowest position than ip the Trendelenburg switch on the ON position.
Next raise the foot end with the hi-lo button on the hand control.
To access the reverse Trendelenburg position raise the hi-lo to the highest position than ip the Trendelenburg switch to the ON
position. Next lower the foot end with the hi-lo button on the hand control.
BED ELEVATION (HI-LO): Press and hold the bottom UP or Down buttons on the hand pendant to raise or lower the bed as
desired.
FOOT (UP-DOWN): Press and hold the middle UP or Down on the hand pendant to raise or lower the foot as desired.
HEAD ELEVATION: Press and hold the top UP or Down buttons on the hand pendant to raise or lower the head of the bed as
desired. Maximum head elevation is 60 degrees.
I.V. POLES: If needed, I.V. support poles can be attached to each corner of the bed base frame.
PAGE 5
SIDE RAIL WIDTH AND HEIGHT ADJUSTMENTS
• To Attach the Side Rails to the Bed
• You must insert the side rail support frame into the horizontal tube under the bed until it contacts
the stop pin.
• Retract the stop pin by hand until you can pass the arm at least 4” into the bed frame.
• Release the stop in and continue to insert the support frame to the desired width.
• Tighten the adjustable knob until it rmly engages the side rail bracket.
• To adjust the width, loosen the black knob under the bottom of the side rail, slide the horizontal
telescoping tube in or out to the desired position and tighten the knob.

861 Taylor Rd., Suite “I”
Columbus, Ohio 43230
www.ame-medical.com
Phone: [phone]
Fax: [phone]
[email protected]
OPERATIONAL INSTRUCTIONS
PAGE 6
To Remove the Side Rail Support Frame
• Loosen the black knob until the arms moves freely.
• Slowly pull the frame out until fully engages the stop pin.
• Manually retract the stop pin and continue to remove the arm.
• Normally, the side rail support frame should not be completely removed for anything other than setup or maintenance.
• WARNING: Failure to properly insert the arm past the stop pin will cause the arm to be improperly installed possibly
resulting in serious injury or death.
To Lower the Side Rail
• Loosen the black clamp know opposite the spring loaded pull pin.
• Hold the side rail with one hand and pull on the pin to release the side rail.
• Allow the side rail to slide down out of the way until the bottom of the support tube engages the oor.
To Raise the Side rail
• Make sure the black knob opposite the spring loaded pull pin is loose.
• Lift the side rail until the spring loaded pull pin completely re-engages one of the preset hole positions.
• Tighten the black knob located on the opposite side of the spring loaded pull pin. Side rails must be in the up position
to move the bed.
To Remove the Side rails Completely
• Grasp the side rail with one hand while loosening the black clamp knob.
• Retract the spring loaded pull pin and lift out completely vertically to the gatch.
