Addendum to the directions for use,
software versions 1.0X–1.7X
This addendum supplements the following documents:
•Welch Allyn Connex®Vital Signs Monitor 6000 Series™ directions for use (part number 103730)
•Welch Allyn Connex®Integrated Wall System directions for use (part number 104066)
Before using the product, you must familiarize yourself with the sections of the directions for use
and this addendum that pertain to your use of the product.
Advanced settings
Specify patient ID settings
Patient identification appears on the Home tab in the Patient frame, and it is listed in various tabs,
such as the Patients tab and the Review tab.
1. Access the Advanced Settings.
a. Touch the Settings tab.
b. Touch the Advanced tab.
c. Enter the Advanced settings code.
d. Touch OK.
The General tab appears.
2. Touch the Data Management tab.
3. Touch the Patient IDs tab.
4. Specify settings.
Setting Action/Description
Name format Select a format for all displayed patient names:
Full name or Abbreviation.
Primary label Select the primary identification label for all
displayed patients.
Secondary label Select a secondary identification label for patients.
A secondary label displays only on the Home tab,
after the primary label.
Require patient ID to save readings Make entering a patient ID a prerequisite for saving
measurements. If they fail to enter an identifier, the
monitor prompts them when they try to save.
1

Clear patient information on manual save Specify that the monitor clears the selected patient
after a clinician manually saves measurements
from the Home tab. Patient information clears from
the Patient frame and the Summary tab.
Note This setting does not take effect when
intervals are in progress.
Retrieve list Enable the monitor to retrieve the patient list from
the network. When this option is selected, a
Retrieve list button replaces the Add button
on the List tab. Information from the network
populates the List tab when clinicians touch the
Retrieve list button. Since the Add button is
not available, clinicians cannot add a patient to the
patient list.
Search by patient ID Enable clinicians to enter a patient ID to query for
the patient's information. If clinicians scan the ID
onto the Home tab or the Summary tab, the monitor
queries the patient list and the network. Returned
patient information populates the Patient frame on
the Home tab and fields on the Summary tab.
Require patient ID match to save measurements Enable clinicians to save measurements only after
they have entered a patient ID that matches an ID
in the patient list or network.
5. Do one of the following:
• To continue in the Advanced Settings, touch another tab.
• To exit the Advanced Settings and return to the Home tab, touch Exit.
Specify clinician ID settings
Clinician identification appears next to the medicine symbol in the Device Status area on the Home
tab.
1. Access the Advanced Settings.
a. Touch the Settings tab.
b. Touch the Advanced tab.
c. Enter the Advanced settings code.
d. Touch OK.
The General tab appears.
2. Touch the Data Management tab.
3. Touch the Clinician IDs tab.
4. Specify settings.
Setting Action/Description
Label Select a type of clinician identification label for
display on the Home tab: Full name,
Abbreviation, Clinician ID, or Symbol only.
Require clinician ID to save readings Make entering a clinician ID a prerequisite for
saving measurements. If they fail to enter
identification, the monitor prompts them when they
try to save measurements. Clinicians can enter
clinician identification on the Clinician tab.
Clear clinician information on manual save Specify that the monitor clears the selected
clinician after a clinician manually saves
2Addendum to the directions for use, software versions 1.0X–1.7X

measurements from the Home tab. Clinician
information clears from the Clinician tab and the
Device Status area.
Note This setting does not take effect when
intervals are in progress.
Search by clinician ID Enable the monitor to query the network for
clinician information based on ID. The monitor
initiates the search when the clinician enters or
scans the ID from the Clinician tab. Returned
clinician information populates the Device Status
area and fields on the Clinician tab.
Require password Require clinicians to enter their password, in
addition to ID, on the Clinician tab. The monitor
uses the ID and password combination to query the
network for clinician information.
Require clinician ID match to save measurements Enable clinicians to save measurements only after
they have entered a clinician ID that matches an ID
in the network.
5. Do one of the following:
• To continue in the Advanced Settings, touch another tab.
• To exit the Advanced Settings and return to the Home tab, touch Exit.
Troubleshooting
Patient data management messages
Message Possible cause Suggested action
Unable to identify patient.
Touch Clear to delete all data. The patient ID does not match an ID in the patient list or network Re-enter the patient ID.
To delete all unsaved data,
touch Clear.
Unable to identify clinician.
Touch Clear to delete all data. The clinician ID does not match an ID in the network Re-enter the clinician ID.
To delete all unsaved data,
touch Clear.
Problems and solutions
The problems addressed in this table do not generate alarm or information messages on the
monitor.
Problem Possible cause Suggested action
• Save button is disabled
• Start intervals button is
disabled
No patient ID Enter the patient ID.
Patient search is in progress (the Patient
frame displays a process indicator) Wait until the search is complete.
The patient ID does not match an ID in the
patient list or network Re-enter the patient ID.
Addendum to the directions for use, software versions 1.0X–1.7X 3

Problem Possible cause Suggested action
No clinician ID Enter the clinician ID.
Clinician search is in progress (the Clinician
ID section of the Device Status area displays
a process indicator)
Wait until the search is
complete.
The clinician ID does not match an ID in the
network Re-enter the clinician ID.
4Addendum to the directions for use, software versions 1.0X–1.7X

Addenda au mode d'emploi, versions
logicielles 1.0X–1.7X
Le présent addenda complète les documents suivants :
•Mode d'emploi du Vital Signs Monitor 6000 Series™ Welch Allyn Connex®(référence 103730)
•Mode d'emploi du système mural intégré Welch Allyn Connex®(référence 104066)
Avant de commencer à utiliser le produit, parcourez les différentes sections de ce mode d'emploi
et de cet addenda pour savoir comment utiliser le produit.
Paramètres avancés
Spécification des paramètres d’identification du patient
L’identification du patient s’affiche dans l’onglet Menu Principal, sous le volet Patient, mais aussi
dans différents onglets dont les onglets Patients et Revue.
1. Accédez aux paramètres avancés.
a. Effleurez l’onglet Paramètres.
b. Effleurez l’onglet Avancé.
c. Entrez le Code des paramètres avancés.
d. Effleurez le bouton OK.
L’onglet Général s’affiche.
2. Effleurez l’onglet Gestion des données.
3. Effleurez l’onglet ID du patient.
4. Spécifiez les paramètres.
Paramètre Action/Description
Format du nom Choisissez un format pour tous les noms de patient
affichés : Nom complet ou Abréviation.
Étiquette principale Sélectionnez l’étiquette d’identification principale
pour tous les patients affichés.
Étiquette secondaire Sélectionnez une étiquette d’identification
secondaire pour les patients. L’étiquette
secondaire s’affiche uniquement dans l’onglet
Menu Principal après l’étiquette principale.
Demander l’ID du patient pour enregistrer les
lectures Rendez la saisie de l’ID du patient obligatoire lors de l’enregistrement des relevés. Si aucun
5

identifiant n’est entré, le moniteur affiche une invite
à l’utilisateur lors de l’enregistrement.
Effacer les informations du patient en cas
d’enregistrement manuel Indiquez que le moniteur efface le patient sélectionné après qu’un médecin a enregistré
manuellement des relevés depuis l’onglet Menu
Principal. Les informations du patient sont effacées
du volet Patient et de l’onglet Résumé.
Remarque Ce paramètre n'a aucun effet lorsque
des intervalles sont en cours.
Extraire la liste Autorisez le moniteur à récupérer la liste de
patients sur le réseau. Lorsque cette option est
sélectionnée, le bouton Extraire la liste
remplace le bouton Ajouter dans l’onglet Liste.
Les informations issues du réseau sont
renseignées dans l’onglet Liste lorsqu’un médecin
effleure le bouton Extraire la liste. Le bouton
Ajouter n’étant pas disponible, le médecin ne
peut pas ajouter de patient à la liste de patients.
Rechercher par ID de patient Permettez aux médecins d’entrer un ID de patient
pour rechercher les informations du patient. Si un
médecin scanne l’ID dans l’onglet Menu Principal
ou Résumé, le moniteur effectue une recherche
dans la liste des patients et sur le réseau. Les
informations du patient renvoyées sont utilisées
pour renseigner le volet Patient de l’onglet Menu
Principal et les champs de l’onglet Résumé.
Demander l’ID du patient pour enregistrer les
lectures Permettez aux médecins d'enregistrer des lectures uniquement après avoir saisi un ID de patient
correspondant à un ID de la liste de patients ou du
réseau.
5. Effectuez l’une des opérations suivantes :
• Pour continuer avec les paramètres avancés, effleurez un autre onglet.
• Pour quitter les paramètres avancés et revenir à l’onglet Menu Principal, effleurez le
bouton Quitter.
Spécification des paramètres d’identification du médecin
L’identification du médecin s’affiche en regard du symbole de médecine dans la zone État du
périphérique de l’onglet Menu Principal.
1. Accédez aux paramètres avancés.
a. Effleurez l’onglet Paramètres.
b. Effleurez l’onglet Avancé.
c. Entrez le Code des paramètres avancés.
d. Effleurez le bouton OK.
L’onglet Général s’affiche.
2. Effleurez l’onglet Gestion des données.
3. Effleurez l’onglet ID du médecin.
4. Spécifiez les paramètres.
Paramètre Action/Description
Etiquette Sélectionnez le type d’étiquette d’identification du
médecin devant s’afficher dans l’onglet Menu
6Addenda au mode d'emploi, versions logicielles 1.0X–1.7X
