American Megatrends StorTrends User's guide User manual

StorTrends®
iTX Software
CLI (Command Line Interface)
(Version 2.7)
User’s Guide
MAN-STOR-ITX27-CLI
06/07/2010

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
ii
© Copyright 1985-2010 American Megatrends, Inc.
All rights reserved.
American Megatrends, Inc.
5555 Oakbrook Parkway
Norcross, GA 30093
This publication contains proprietary information which is protected by copyright. No part of this publication can be
reproduced, transcribed, stored in a retrieval system, translated into any language or computer language, or
transmitted in any form whatsoever without the prior written consent of the publisher, American Megatrends, Inc.
American Megatrends, Inc. acknowledges the following trademarks:
Intel and Pentium are registered trademarks of the Intel Corporation.
AMD, Athlon, and Athlon XP are trademarks of the Advanced Micro Devices Corporation.
Sun and NFS are trademarks of the Sun Microsystems Corporation.
Microsoft, Windows, Internet Explorer and MS-DOS are registered trademarks of the Microsoft Corporation and
Active Directory is a trademark of the Microsoft Corporation.
Macromedia Flash is a trademark of the Macromedia Corporation.
IBM, AT, VGA, PS/2, and OS/2 are registered trademarks and XT and CGA are trademarks of the International
Business Machines Corporation.
Digital, DEC, and OpenVMS are trademarks of Digital Equipment Corporation.
Compaq is a registered trademark of the Compaq Corporation.
Hewlett-Packard, HP, and HP-UX are registered trademarks of Hewlett-Packard Company.
Novell, NetWare, IPX, NCP, and NetWare Core Protocol are registered trademarks of the Novell Corporation.
UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open
Company Ltd.
Linux is a registered trademark of Linus Torvalds.
Red Hat is a registered trademark of the Red Hat Corporation.
Apple and AppleTalk are registered trademarks of Apple Computer Corporation.
Yellow Pages is a registered trademark in the United Kingdom of British Telecom.
Ethernet is a registered trademark of the Xerox Corporation.
802 is a registered trademark of the Institute of Electrical and Electronic Engineers, Inc. (IEEE).
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks
and names or their products. American Megatrends, Inc. disclaims any proprietary interest in trademarks and trade
names other than its own.
Revision History
02/16/06 Created iTX 2.1 CLI document.
02/16/06 iSCSI Tape command added.
02/16/06 UPS driver config command added.
02/23/06 Synchronous replication commands added.
06/20/06 Volume and Snapshot commands updated.
06/21/06 Synchronous replication, iSCSI configuration updated.
06/23/06 Document is revised and examples are added.
07/14/06 General Server configuration section updated.
07/27/06 Updated for version 2.5.1011 and above.
08/17/06 Added Error Codes section.
04/26/07 Changed the volume chunk size.
04/26/07 Added the SRM commands.
06/28/07 Removed Tape commands.
01/16/09 Updated document and added journal and cdp commands.
12/11/09 Update the network command usage and CLI error text
01/25/10 Updated the OS Agnostic HA related commands and CLI error text
01/25/10 Updated Network Alias commands

Preface
iii
01/25/10 Updated the iSCSI commands and corrected wrong format updation
03/30/10 Corrected the Create Volume usage and Get Eventlog Usage.
04/11/10 Update the create replication commands
06/07/10 Corrected the output of ‘cli main’.
06/07/10 Removed the term apple
06/07/10 Corrected set -t nfs command.
06/07/10 Corrected set raid commands.
06/07/10 Added available cache options for create raid.
06/07/10 Since alarm and cache is supported for set raid; the ‘not supported’ was removed.
06/07/10 Osinfo commands removed.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
iv
Table of Contents
Revision History......................................................................................................................................... ii
Table of Contents ..................................................................................................................................... iv
Table of Contents ..................................................................................................................................... iv
Limited Warranty ....................................................................................................................................... v
Limitations of Liability ................................................................................................................................ v
Technical Support...................................................................................................................................... v
Web Site ................................................................................................................................................ v
Disclaimer................................................................................................................................................. vi
Chapter 1 Overview of CLI ..................................................................................................................... 1
Preface ...................................................................................................................................................... 1
Overview of CLI ......................................................................................................................................... 1
Accessing CLI............................................................................................................................................ 1
Initial Setup ................................................................................................................................................ 2
Network Configuration ........................................................................................................................... 2
Volume Configuration ................................................................................................................................ 3
1. RAID Disk Creation............................................................................................................................ 3
2. Container and Volume Configuration................................................................................................. 4
3. Enabling Share or Target................................................................................................................... 5
Chapter 2 Command Set ........................................................................................................................ 7
Command Set............................................................................................................................................ 7
Alert Configuration..................................................................................................................................... 9
Date/Time Configuration.......................................................................................................................... 10
Domain Configuration .............................................................................................................................. 10
Event log Commands .............................................................................................................................. 11
Firewall Configuration .............................................................................................................................. 12
General Server Configuration.................................................................................................................. 13
Health Configuration ................................................................................................................................ 13
iSCSI Configuration ................................................................................................................................. 14
License configuration............................................................................................................................... 16
Network Controller Configuration ............................................................................................................ 17
NAS Quota Configuration ........................................................................................................................ 18
NAS User / Group Configuration ............................................................................................................. 19
Protocol Configuration ............................................................................................................................. 20
RAID & Disk Management Commands ................................................................................................... 21
Share, Directory & ACL Configuration..................................................................................................... 24
System Control Configuration ................................................................................................................. 26
Volume and Snapshot Commands.......................................................................................................... 26
UPS Configuration ................................................................................................................................... 29
Synchronous replication .......................................................................................................................... 30
Asynchronous Replication ....................................................................................................................... 33
Journal Volume Management ................................................................................................................. 39
Continuous Data Protection..................................................................................................................... 41
Recovery Wizard ..................................................................................................................................... 41
Storage Resource Management ............................................................................................................. 42
Local and Replicated Snapshot validation ..............................................................................................43
Appendix A Error Codes ...................................................................................................................... 45

Preface
v
Limited Warranty
The buyer agrees that if this product proves to be defective, American Megatrends is only obligated to repair
or replace this product at American Megatrends’ discretion according to the terms and conditions of the
warranty registration software that accompanies this product. American Megatrends shall not be liable in
tort or contract for any loss or damage, direct, incidental or consequential resulting from the use of this
product. Please see the Warranty Registration Software shipped with this product for full warranty details.
Limitations of Liability
American Megatrends, Inc. shall in no event be held liable for any loss, expenses, or damages of any kind
whatsoever, whether direct, indirect, incidental, or consequential (whether arising from the design or use of
this product or the support materials provided with the product). No action or proceeding against American
Megatrends may be commenced more than two years after the delivery of product to Licensee of Licensed
Software.
Licensee agrees to defend and indemnify American Megatrends from any and all claims, suits, and liabilities
(including attorney’s fees) arising out of or resulting from any actual or alleged act or omission on the part of
Licensee, its authorized third parties, employees, or agents, in connection with the distribution of Licensed
Software to end-users, including, without limitation, claims, suits, and liability for bodily or other injuries to
end-users resulting from use of Licensee’s product not caused solely by faults in Licensed Software as
provided by American Megatrends to Licensee.
Technical Support
American Megatrends provides technical support for American Megatrends products purchased directly
from American Megatrends or from an American Megatrends-authorized reseller only.
If… Then…
You purchased this product from American Megatrends
or from a certified American Megatrends reseller,
call American Megatrends’ technical support at 770-
246-8645. Please be prepared to specify the serial
number or CD Key of the product (if applicable).
This American Megatrends product was installed as part
of a system manufactured by a company other than
American Megatrends or you purchased an American
Megatrends product from an unauthorized reseller,
call the technical support department of the computer
manufacturer or the unauthorized reseller. American
Megatrends does not provide direct technical support in
this case.
If the American Megatrends StorTrends® iTX Software fails to operate as described or you are in doubt
about a configuration option, please call technical support at 770-246-8645.
Web Site
We invite you to access the American Megatrends’ World Wide Web site at:
http://www.ami.com/

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
vi
Disclaimer
This manual describes the operation of the American Megatrends StorTrends® iTX Software. Although
efforts have been made to assure the accuracy of the information contained here, American Megatrends
expressly disclaims liability for any error in this information, and for damages, whether direct, indirect,
special, exemplary, consequential or otherwise, that may result from such error, including but not limited to
the loss of profits resulting from the use or misuse of the manual or information contained therein (even if
American Megatrends has been advised of the possibility of such damages). Any questions or comments
regarding this document or its contents should be addressed to American Megatrends at the address shown
on the inside of the front cover.
American Megatrends provides this publication “as is” without warranty of any kind, either expressed or
implied, including, but not limited to, the implied warranties of merchantability or fitness for a specific
purpose.
Some states do not allow disclaimer of express or implied warranties or the limitation or exclusion of liability
for indirect, special, exemplary, incidental or consequential damages in certain transactions; therefore, this
statement may not apply to you. Also, you may have other rights which vary from jurisdiction to jurisdiction.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made
to the information herein; these changes will be incorporated in new editions of the publication. American
Megatrends may make improvements and/or revisions in the product(s) and/or the program(s) described in
this publication at any time.
Requests for technical information about American Megatrends products should be made to your American
Megatrends authorized reseller or marketing representative.

Chapter One: Overview of CLI
1
Chapter 1 Overview of CLI
Preface
Our feature rich StorTrends® iTX comes with a built-in command line interface (CLI) that provides
extensive options to monitor and control “managed objects”. Wherever applicable, CLI follows industry
standards and uses extensible ‘tags’ for new features and objects. The command line utility can be accessed
through an in-band special console connected to the StorTrends® iTX system or out-of-band via a SSH or
telnet client. It can also be used with scripting languages to automate a set of operations.
Overview of CLI
Our CLI supports commands in excess of 140 verbs and supports XML output format. The design is very
similar to DMTF SMASH specifications and is being extended to fully comply with SMASH. Every managed
element or object has a SMASH compliant <Target> addressing conforming to the server management
instance addressing specification. The commands implemented are essentially “stateless” in nature. SMASH
compliant <Verbs> is used to select the management actions, which are complemented by extensive <Option>
attributes to control the behavior of the command. <Property> attributes can control the behavior of the
output produced by the <Verb> along with various other mapping actions to the CIM schema.
The output produced can be controlled depending on the need, For example, in automation scripting. Output
can also be made to be in the W3C standard compliant, self-descriptive XML format. The output format
includes new tags pertinent to the object management. Inherent support for multi-lingual documents and
Unicode data, along with content separation from presentation, aids in development of management
applications that have their own data representation format. CLIs used for monitoring of performance
parameters are dished out in XML tags that assist in graphing and charting, and can be right away imported
by spreadsheet applications.
Accessing CLI
The CLI can be accessed either through an in-band console connected directly to the ITX box or through the
out-of-band / remote CLP agents. It can also be accessed through a remote terminal emulation program using
SSH or Telnet. Once connected, the administrator has to login to the system to perform the operations. In a
typical console session, the user will be presented with a login screen such as:
login: cli <Enter>
password: ******* <Enter>
“cli” is the special user that has been provided with CLI access. The password is factory defaulted to
“password”. Once logged in, the system will present the user with a CLI shell as follows:
CLI>
The user can then enter the supported commands in any order. The supported commands are listed in the
next section. To close the session, the user can type the command ‘quit’. This will end the session.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
2
Initial Setup
Network Configuration
Once the StorTrends® iTX is installed in a new system, please ensure that the initial network configuration is
proper. The system factory defaults to DHCP setup. The configured network settings can be verified by the
following CLI commands:
CLI> get –-type or –t port
-–name or –n NIC-1
--info or -i
network <Enter>
Example: get –t port –n nic-1 –i network
This will display the NIC-1 network settings.
To configure static IP to this port:
CLI> set –-type or –t port
–-name or –n NIC-1
–-ip or –i 10.0.0.100
–-mask or –m 255.255.255.0
–-gate or –g 10.0.0.7 (optional)
--pridns or –p 10.0.0.2 (optional)
--secdns or –s 0.0.0.0 (optional)
--dnssuff or –f ami.com (optional)
network <Enter>
Example: set –t port –n nic-1 –i 10.0.0.100 –g 10.0.0.7
-p 10.0.0.2 –s 0.0.0.0 –f ami.com network
Here 10.0.0.100 is the static IP address, 255.255.255.0 is netmask and 10.0.0.7 is the network gateway.

Chapter One: Overview of CLI
3
Volume Configuration
Initial volume configuration can be done in three stages.
1. RAID Disk Creation
At the base level is the RAID CONTROLLER.
CLI> list –-type or –t controller
raid <Enter>
Example: list –t controller raid
This will list the available RAID controllers in the system. By default, Software MD will be shown as a RAID
controller with controller number “0”. If Hardware RAID controllers present, then they will take precedence
over Software MD.
CLI> list –-type or -t PD
--controllerno or -n 0
raid <Enter>
Example: list –t pd –n 0 raid
This will list the PD’s that are available for configuration in controller number zero. PD’s can be grouped
through a RAID level to form a Logical disk – LD.
CLI>create –-type or -t LD
–-stripesize or -p 64
–-diskname or -d /dev/sda (use –d 1 or –d 2…15 on a 3U)
–-diskname or –d /dev/sdb
–-diskname or –d /dev/sdc
–-diskname or –d /dev/sdd
--raidlevel or –r 0
--controllerno or –n 0
--cachemode or –m 3
raid <Enter>
Example: create –t ld –p 64 –d 1 –d 2 –r 1 –n 0 –m 2 raid
This will create a RAID 1 Logical Disk – LD with 64K-chunk size and two disks on a 3U.
Example: create –t ld –p 64 –d /dev/sda –d /dev/sdb –d
/dev/sdc –r 5 –n 0 –m 1 raid
This command will crate a RAID 5 Logical disk – LD with 64 k chunk size and three disks on a 1U box.
CLI> list –-type or –t LD
raid <Enter>
Example: list –t ld raid
This will list the available RAID LD’s present in the system.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
4
2. Container and Volume Configuration
Next step is the AMI DVM container creation. This can be done by the following commands:
CLI>create –-type or -t container
–-containername or -c container1
–-chunksize or –k 64
–-ldname or –l /dev/md0
volume <Enter>
Example: create –t container –c accounting –k 64 –l
/dev/sdb volume (for a 3U)
This command creates a container named “accounting” from the LD /dev/sdb.
On a 1U, LDs are created with names of /dev/mdX, with X as 0, 1, and so on. Therefore the above operation
would be accomplished by entering, for example:
Example: create –t container –c marketing –k 64 –l
/dev/md1 volume
The next step is the creation of volumes.
A NAS volume can be created by the following command:
CLI>create –-type or –t volume
–-containername or -c container1
–-volumename or -v nasvol0
–-volumesize or -z 1000 (in GB)
–-provisiontype or -p 0 (0 is thin-provisioned, 1 is exact)
–-volumetype or -e 0 (type 0 is ROW)
–-voldialect or –f 1 (dialect 1 is NAS, 0 is iSCSI)
--chunksize or –k (8 or 64 for 8KB and 64KB chunk sized volume
respectively.)
volume <Enter>
Example: create –t volume –c container1 –v volume1 –z 1000 –p 0 –
e 0 –f 1 –k 64 volume
This command creates volume “nasvol0” in container “container1” with size of 1000GB, that is thin-
provisioned, Redirect-On-Write, and of NAS type with chunk size as 64KB.
Volume size should be in GBs and currently supported volume type is 0 – ROW.

Chapter One: Overview of CLI
5
Similarly a SAN volume can be created as follows:
CLI>create –-type or –t volume
–-containername or -c container1
–-volumename or -v sanvol0
–-volumesize or -z 1000
–-provisiontype or -p 0
–-volumetype or -e 0
–-voldialect or -f 0
--chunksize or –k (8 or 64 for 8KB and 64KB chunk sized volume
respectively.)
volume <Enter>
Example: create –t volume –c container1 –v volume1 –z 1000 –p 0 –
e 0 –f 1 –k 8 volume
This command creates volume “sanvol0” in container “container1” with size of 1000GB, that is thin-
provisioned, Redirect-On-Write, and of SAN type with chunk size as 8KB.
3. Enabling Share or Target
To enable NAS share, use the following command syntax. Make sure the corresponding share protocol is
enabled in the system.
First, create the directory in the path before creating a share for the path.
CLI>create --path or -p container1_nasvol0/test
dir<Enter>
Example: create –p cont1_nasvol0/test dir
This command creates the subdirectory of “test” within the volume “nasvol0” in the container “cont1”.
Then create the share using the following syntax.
CLI>add –-name or -n NASShare
–-path or -p container1_nasvol0/test
–-prototype or -s cifs
–-prototype or -s nfs
share <Enter>
Example: add –n nasshare –p cont1_nasvol0/test –s cifs –s
nfs share
Note: The path specified should be of format:
“ContainerName_VolumeName/directoryName”.
To create a target, use the following commands.
CLI>add –-type or -t lun
--volumename or -v sanvol0
–-containername or -c container1
–-targetname or -n sanvol0
iscsi <Enter>
Example: add –t lun –v sanvol0 –c cont1 –n sanvol0 iscsi

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
6
Then, to enable the target, use the syntax below:
CLI>enable –-type or –t tgt
–-targetname or -n sanvol0
iscsi <Enter>
Example: enable –t tgt –n sanvol0 iscsi
Next step is to activate a port for iSCSI traffic.
CLI>activate –-type or –t portal
–-ipaddress or -p 10.0.0.100
–-portaltag or -g 1 iscsi
Example: activate –t portal –p 10.0.0.100 –g 2 iscsi
We recommend that you assign different portal tags to the two portals if they are on different subnets.

Chapter Two: Command Set 7
Chapter 2 Command Set
Command Set
The CLI design being similar to the DMTF SMASH specifications follows the standard to a great extent. The
commands supported can be represented grammatically as follows:
<verb> <option> … <property> <target>
The CLI provides a wide range of command sets. These commands are grouped into modules for better
understanding. Each command is non-interactive and state-less. The <options> are supported using switches.
Our CLI accepts both short and long options for each switch to make it user-friendly. If there is any error in
the parameters entered, the CLI will display the usage of that particular command.
CLI also provides extensive online help. Each command supports a help option using ‘-h’ or
‘--help’ that will display the grammar of the command.
To get the main list of targets or modules present in CLI, the user should type the command “main” at the
CLI prompt.
The following targets will get displayed:
*****************************************************************
TARGET LIST
-----------------------------------------------------------------
1. ug 2. ups
3. dir 4. srm
5. dump 6. raid
7. ndmp 8. alert
9. iscsi 10. share
11. quota 12. system
13. volume 14. domain
15. health 16. license
17. network 18. journal
19. eventlog 20. protocol
21. firewall 22. datetime
23. timezone 24. serverinfo
25. sysupgrade 26. syncreplica
27. asyncreplica 28. recoverywizard
29. snapvalidation
For more information on the targets please use the following command
show -t/--target <targetname>
Note : Targetnames are case insensitive
Example :
show -t iscsi
*****************************************************************
The show option can also be used to show commands based on <verb>, and to display the list of targets or
verbs available.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
8
For example: To find out how the show command works, type:
CLI>show -h <Enter>
This will display the many ways the show command can be used.
(this is redundant)
For example: To display the available targets/verbs, the user has to enter:
CLI>show –d targets <Enter>
CLI>show –d verbs <Enter>
The show option can display the functions available for a target or even the functions available for a verb.
For example: To display the functions available for targets/verbs the user has to enter:
CLI>show –t <targetname> <Enter>
Example: show –t ups
CLI>show –v <verbname> <Enter>
Example: show –v list
Note: In the table below, though the <target> is given in the first column together with <verb>, it should
actually be typed at the end of command, complying with SMASH specification. Again, the target
is not case-sensitive.

Chapter Two: Command Set 9
Alert Configuration
These commands configure the way alerts are generated.
Command Argument Description
get alert -t/--type snmp
For example:
get –t snmp alert
Gives the SNMP alert
configuration.
get alert -t/--type email
For example:
get –t email alert
Gives the Email alert
configuration.
delete alert -t/--type snmp
-v/--value <destination>
-x/--xml alert
For example:
delete -t snmp -v 10.0.3.155 -v 10.0.0.203 -x alert
Deletes the SNMP specified
destination from the alert
configuration.
delete alert -t/--type email
-v/--value <emailaddress>
-x/--xml alert
For example:
delete -t email -v [e-mail] -v
[email protected] -x alert
Deletes the specified email address
from the alert configuration.
set alert -t/--type snmp
-e/--enable or
-d/--disable
-v/--value <alertmask:communityname:destination>
-x/--xml
For example: set –t snmp –e –v 1:public:10.10.10.5
-x alert
Configures SNMP alerts.
Note:
<alertmask:communityname:destin
ation>
For example:
<1:public:10.0.0.79>
set alert -t/--type email
-e/--enable or
-d/--disable
-v/--value <alertmask:language:emailaddr>
-s/--emailserver (IP address)
-F <Fully Qualified Domain Name>
-x/--xml
For example: set -t email -e -v
1:1:[email protected] -s 10.0.0.79 -F ami.com -x
alert
Configures Email alerts.
<alertmask:language:emailaddr>
<1:1:[email protected]>
Language
0-Unknown
1-English
2-Japanese
3-Korean
4-Chinese
Alert Mask:
1 - Information
2 - Warning
4 - Fatal
Any combination of the three alert
masks up to a maximum of seven
levels.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
10
Date/Time Configuration
These commands configure the time zone and date.
Command Argument Description
set timezone -z/--zone <zone name>
-x/--xml
For example: set –z America/New_York timezone
Sets the time zone of StorTrends®
iTX to given time zone.
get timezone For example: get timezone Shows the configured time zone.
set datetime -n/--ntp <FQDN of NTP server or ipaddress> Configures the NTP server to be
used for time synchronization.
get timezone -c/--count Gets the number of time zones.
set datetime -d/--date <date in MM/DD/YYYY>
-t/--time <time in HH:MM:SS>
-x/--xml
For example: set –d 12/01/2006 –t 12:11:55
datetime
Sets the date and time to given
values.
list timezone For example: list timezone Lists the time zones supported.
get datetime For example: get datetime Shows the date & time.
Domain Configuration
These commands configure the domain server to be used for authentication.
Command Argument Description
get domain -t/--type {nis/ms}
-x/--xml
For example: get –t nis domain
Displays the domain information of
either NIS or Microsoft (MS)
domains.
set domain -t/--type{ nis }
-b/--broadcast {y/n}
-d/--domain <domainname >
-s/--server <server-1>
-s/--server <server-2>
-x/--xml
For example: set -t nis -b n -d NISSERV -s
10.0.0.215 -s 10.0.0.25 -s 10.0.0.5 domain
Sets the NIS domain to given
domain with broadcast mode OFF
or ON. Servers can be added using
the –s/--server switch.
If broadcast is set to OFF, then no
servers are needed.
set domain -t/--type {ms}
-m/--mtype {wg}
-d/--domain< domainname>
-x/--xml
For example: set -t ms -m wg -d MYGROUP
domain
Sets the Microsoft domain type to
Workgroup.
set domain -t/--type {ms}
-m/--mtype {/nt/ads}
-d/--domain< domainname>
-D/--nbname<netbiosname> (optional)
-i/--ip <serverip>
-I/--secip<secondary serverip> (optional)
-o/--orgname <orgName> (optional)
-u/--user <Adminname >
-p/--passwd <Adminpassword>
-x/--xml
For example: set –t ms –m ads –d domain1.com –D
domain1 –I 10.10.220.1 –u Administrator –p
password domain
Sets the Microsoft domain type to
NT / ADS.

Chapter Two: Command Set 11
Event log Commands
These commands display or clear the event log.
Command Argument Description
get eventlog -s/--section {v/s/o/h}
-o/--offset <record-offset>
-n/--recordcount <record-count>
-i/--info
-f/--fatal
-w/--warning or
-a – all eventlog
-x/--xml
For example: get –s vs –o 2 –n 20 –f –w eventlog
Lists event log content matching
the given criteria.
v-Volume
s-System
o-OS
h-Health
get eventlog -c/--count
-s/--section {v/s/o/h}
-i/--info
-f/--fatal
-w/--warning or
-a/-- all eventlog
-x/--xml
For example: cli get -s vsoh -a -c eventlog
Gets the number of events reported.
clear eventlog Clears the complete event log.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
12
Firewall Configuration
These commands configure the network firewall options.
Command Argument Description
add firewall -a/--allow or
-b/--block
-i/--ip <ipaddress>
-m/--mask <netmask>
-p/--proto {icmp}
-x/--xml
Add allowed or blocked firewall
rule with given parameters for the
ICMP protocol.
add firewall -a/--allow
-b/--block
-i/--ip <ipaddress>
-m/--mask <netmask>
-s/--sport <start-port>
-e/--eport <end-port>
-p/--proto {tcp/udp}
For example: add –a –i 10.10.1.1 –s 1200 –e 5000 –
p tcp firewall
Add allowed or blocked firewall
rule with given parameters for TCP
and UDP protocols.
edit firewall -a/--allow or
-b/--block
-r/--rule<ruleno>
-i/--ip <IP address>
-m/--mask <net mask>
-p/--proto { icmp}
-x/--xml
For example: edit -a -i 10.0.0.218 -r 1 -m
255.255.255.255 -p icmp -x firewall
Modifies specified allowed or
blocked firewall rule with given
rule number to the given values for
ICMP.
delete firewall -a/--allow or
-b/--block
-r/--num <rule number>(obtained when viewing the
list of firewalls via the list command below)
-x/--xml
For example: delete -b -r 1 -x firewall
Deletes allowed or blocked firewall
rule with given rule number.
edit firewall -a/--allow or
-b/--block
-r/--rule<ruleno>
-i/--ip <IP address>
-m/--mask <net mask>
-s/--sport <start port>
-e/--eport <end port>
-p/--proto {tcp/udp}
-x/--xml
For example: edit -a -i 10.0.0.218 -r 1 -m
255.255.255.255 -s 2000 -e 3000 -p udp -x firewall
Modifies specified allowed or
blocked firewall rule with given
rule number to the given values for
TCP or UDP.
list firewall Lists all the blocked and allowed
firewall rules.
get firewall -c/--count
-x/--xml
For example: get -c -x firewall
Retrieves the count of allowed or
blocked firewall rules.

Chapter Two: Command Set 13
General Server Configuration
These commands retrieve the general server information, such as build version, build date and so on. It also
allows configuration of a new server name.
Command Argument Description
get serverinfo For example: get serverinfo Displays the server information
such as server name, build version,
build date and so on.
set serverinfo -n/--name <server name>
-x/--xml
For example: set –n newitx serverinfo
Configures the name of the server.
The length of the servername
should be less than 16 characters
and the first character must be
alphabetical.
set serverinfo -p/--password
–u/--user{root/cli}
-x/--xml
System will prompt you to enter
and confirm the new administrator
(root/cli) password.
Password length should be 32 or
less characters.
create dump Creates a dump of the running
system that is useful for debugging.
The file is placed in /usr/AmiNas.
Health Configuration
These commands get the health information
Command Argument Description
get health -c/--enccount
-x/--xml
For example: get –c health
Gets the number of enclosures
present in the system.
get health -i/--info –n/--enclosure
-x/--xml
For example: get –i –n 0 health
Gets the health information
regarding fan, voltage and
temperatures for the given
enclosure.
get health -s/--encstatus
–n/--enclosure (optional)
-x/--xml
For example: get –s health
get –s –n 0 health
Gets the enclosure status for the
given enclosure or for all the
enclosures.
get health -a/--
-x/--xml
For example: get –x –a health
Gets the enclosure status for all the
enclosures.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide
14
iSCSI Configuration
Note: Targetname input: Only the suffix portion of the targetname is required.
For example: “iqn.1991-10.com.ami:itx001a2b3c4d5e2006:test1” . The user needs to input only “test1”.
Command Argument Description
get iscsi -t/--type {tgtstatus}
-n/--targetname <targetsuffix>
For example: get –t tgtstatus –n target1 iscsi
Gives the status of the target as
enabled or disabled.
get iscsi -t/--type {tgtname} Gets the iSCSI target name. This
value is not configurable and is
unique to the iTX device.
For example:
iqn.1991-
10.com.ami:itx0030482c8d788a7e
activate iscsi -t/--type {portal}
-p/--ipaddress <Ipaddress of the target machine>
-g/--portaltag <portal tag>
For example: activate –t portal –p 10.15.1.1 –g 3
iscsi
Activates the specified iSCSI
portal. You have to specify a portal
tag at the time of activation of the
portal.
deactivate iscsi -t/--type {portal}
-p/--ipaddress <ipaddress of the target machine>
Deactivates the specified iSCSI
portal.
enable iscsi -t /--type {tgt}
-n/--targetname <target suffix>
Enables the specified target.
disable iscsi -t/--type {tgt}
-n/--targetname <target suffix>
For example: cli disable –t tgt –n newtgt iscsi
Disables the specified target.
start iscsi To start the iSCSI service.
stop iscsi For example: stop iscsi To stop the iSCSI service.
set iscsi -t/--type {params}
-o/--choiceno {0-12}
-l/--value <value>
For example: set –t params –o 1 –l 256 iscsi.
Sets specified iSCSI Login
negotiation parameters.
The possible values are:
1. FirstBurstLength (0-256 KB,
default=256)
2. MaxBurstLength (must be less
than #1, default=256)
3. MaxRecvDataSegmentLength
(0-256KB, default=256)
4. MaxConnections (0-4,
default=2)
5. DefaultTime2Retain (0-3600,
default=20 sec)
6. DefaultTime2Wait (0-
3600,default=2 sec)
7. InitialR2T (0-1, default=No,0)
8. MaxOutStandingR2T (1-8,
default=1 sec)
9. ErrorRecoveryLevel (0-2,
default=2)
10. ImmediateData (0-1,
default=1,yes)
11. DataPduInOrder (0-1,
default=1,yes)
12. DataSeqInOrd (0-
1,default=1,yes)
get iscsi -t/--type {lunwritecachemode}
-v/--volumename <volume name>
-c/--containername <containername>
Gets the Write Cache mode for the
specified disk.
set iscsi -t/ --type {lunwritecachemode}
-v/--volumename <volume name>
Sets the Write Cache mode for the
specified disk.
