IQ Series Thermometers
i
USER GUIDE
PUBLICATION NO806609
LANGUAGE: ENGLISH
ISSUE: 8
DATE: 01 NOVEMBER 2023
QUALITY CUSTOMER SOLUTIONS
series

Health and Safety Information
Read all of the instructions in this booklet - including all the WARNINGS and CAUTIONS
- before using this product. If there is any instruction which you do not understand, DO
NOT USE THE PRODUCT.
Safety Signs
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or
personal injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, could result in minor or
moderate injury to the user or users, or result in damage to the product or to property.
NOTE
Indicates a potentially hazardous situation which, if not avoided, could result in damage or loss of data.
Signs and Symbols used on equipment and Documentation
Caution, risk of electric shock.
Caution, attention to possibility of risk of damage to the product, process or surroundings. Refer
to instruction manual.
Caution, hot surface.
Protective Conductor Terminal.
Observe precautions for handling electrostatic discharge sensitive devices.
Equipment Operation
Use of this instrument in a manner not specied by AMETEK Land may be hazardous. Read and
understand the user documentation supplied before installing and operating the equipment.
The safety of any system incorporating this equipment is the responsibility of the assembler.
Protective Clothing, Face and Eye Protection
It is possible that this equipment is to be installed on, or near to, machinery or equipment operating at
high temperatures and high pressures. Suitable protective clothing, along with face and eye protection
must be worn. Refer to the health and safety guidelines for the machinery/equipment before installing
this product. If in doubt, contact AMETEK Land.
Wear Protective Gloves Wear Protective Clothing
Wear Eye Protection Wear Ear Protection
Wear Safety Boots Wear Face Protection
Electrical Power Supply
Before working on the electrical connections, all of the electrical power lines to the equipment must
be isolated. All the electrical cables and signal cables must be connected exactly as indicated in these
operating instructions. If in doubt, contact AMETEK Land.
IMPORTANT INFORMATION - PLEASE READ

Health and Safety Information
Read all of the instructions in this booklet - including all the WARNINGS and CAUTIONS
- before using this product. If there is any instruction which you do not understand, DO
NOT USE THE PRODUCT.
Safety Signs
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or
personal injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, could result in minor or
moderate injury to the user or users, or result in damage to the product or to property.
NOTE
Indicates a potentially hazardous situation which, if not avoided, could result in damage or loss of data.
Signs and Symbols used on equipment and Documentation
Caution, risk of electric shock.
Caution, attention to possibility of risk of damage to the product, process or surroundings. Refer
to instruction manual.
Caution, hot surface.
Protective Conductor Terminal.
Observe precautions for handling electrostatic discharge sensitive devices.
Equipment Operation
Use of this instrument in a manner not specied by AMETEK Land may be hazardous. Read and
understand the user documentation supplied before installing and operating the equipment.
The safety of any system incorporating this equipment is the responsibility of the assembler.
Protective Clothing, Face and Eye Protection
It is possible that this equipment is to be installed on, or near to, machinery or equipment operating at
high temperatures and high pressures. Suitable protective clothing, along with face and eye protection
must be worn. Refer to the health and safety guidelines for the machinery/equipment before installing
this product. If in doubt, contact AMETEK Land.
Wear Protective Gloves Wear Protective Clothing
Wear Eye Protection Wear Ear Protection
Wear Safety Boots Wear Face Protection
Electrical Power Supply
Before working on the electrical connections, all of the electrical power lines to the equipment must
be isolated. All the electrical cables and signal cables must be connected exactly as indicated in these
operating instructions. If in doubt, contact AMETEK Land.
IMPORTANT INFORMATION - PLEASE READ
Contact Us
UK - Droneld
Land Instruments International
Tel: [phone]
USA - Pittsburgh
AMETEK Land, Inc.
Tel: [phone]
China
AMETEK Land China Service
Tel: [phone] ext 122
India
AMETEK Land India Service
Tel: +91 - 80 67823240
Email: [email protected]
Web: www.ametek-land.com
For further details on all AMETEK Land oces, distributors and representatives, please visit our website.
Storage
The instrument should be stored in its packaging, in a dry sheltered area.
The maximum storage temperature is 10 °C (18 °F) higher than the maximum operating temperature.
The minimum storage temperature is 10 °C (18 °F) lower than the minimum operating temperature.
Refer to the Technical Specication for details of the operating temperature limits.
Unpacking
Check all packages for external signs of damage. Check the contents against the packing note.
Lifting Instructions
Where items are too heavy to be lifted manually, use suitably rated lifting equipment. Refer to the
Technical Specication for weights. All lifting should be carried out in accordance with local and national
regulations.
Return of Damaged Goods
IMPORTANT If any item has been damaged in transit, this should be reported to the carrier and to the
supplier immediately. Damage caused in transit is the responsibility of the carrier not the supplier.
DO NOT RETURN a damaged instrument to the sender as the carrier will not then consider a claim. Save
the packing with the damaged article for inspection by the carrier.
Return of Goods for Repair
If you need to return goods for repair please contact our Customer Service Department for details of the
correct returns procedure.
Any item returned to AMETEK Land should be adequately packaged to prevent damage during transit.
You must include a written report of the problem together with your own name and contact information,
address, telephone number, email address etc.
Design and Manufacturing Standards
The Quality Management System of Land Instruments International is approved to BS EN ISO 9001 for
the design, manufacture and on-site servicing of combustion, environmental monitoring and non-contact
temperature measuring instrumentation.
Registered ISO 9001 Management System approvals apply in the USA.
UK Calibration Laboratory: UKAS 0034.
USA Calibration Laboratory: ANAB Accredited ISO/IEC 17025.
National Accreditation Board for Testing and Calibration Laboratories approvals apply in India.
Operation of radio transmitters, telephones or other electrical/electronic devices in close proximity
to the equipment while the enclosure doors of the instrument or its peripherals are open, may cause
interference and possible failure where the radiated emissions exceed the EMC directive.
The protection provided by this product may be invalidated if alterations or additions are made to the
structural, electrical, mechanical, pneumatic, software or rmware components of this system. Such
changes may also invalidate the standard terms of warranty.
Copyright
This manual is provided as an aid to owners of AMETEK Land’s products and contains information
proprietary to AMETEK Land. This manual may not, in whole or part, be copied, or reproduced without the
expressed written consent of AMETEK Land.

series
Fixed Spot Thermometer
User Guide
Contents
1 Introduction 1-1
1.1 General Introduction 1-1
1.2 About IQ Series Thermometers 1-1
1.3 Nomenclature 1-2
2 Specications 2-1
3 HardwareConguration 3-1
3.1 ThermometerConguration 3-1
4 LaserAlignment 4-1
5 InstrumentSetup&Conguration 5-1
5.1 IQThermometerLensConguration 5-1
5.2 IQSeriesConguratorSoftware 5-3
6 Thermometer Installation 6-1
6.1 RecommendedInstallationArrangement 6-2
6.2 Enhanced and Premium Variant Thermometers 6-3
6.3 UsingtheBrainboxesUSB/RS485convertor 6-4
7 Time Functions 7-1
7.1 Averager 7-1
7.2 Peak Picker 7-2
7.3 Track and Hold 7-3
8 Emissivity 8-1
8.1 Refractories 8-3
8.2 Alloys 8-3
8.3 Glass 8-3
8.4 Metals 8-4
9 Maintenance,Servicing&Calibration 9-1
9.1 Maintenance 9-1
9.2 Servicing 9-1
9.3 Calibration 9-1
AppendixA-RS485LandProtocol
AppendixB-User Calibration
AppendixC-InstallationDrawings

series
1 - 1
Fixed Spot Thermometer
User Guide
1.1 General Introduction
ThispublicationgivesyoutheinformationrequiredtooperatetheAMETEKLand
IQ Series thermometer.
Itisimportanttocheckallequipmentwithwhichyouhavebeensupplied,and
readalltheliteratureprovidedwiththeAMETEKLand IQ Series thermometer
beforeusingthethermometerforthersttime.Additionally,keepallsupplied
literaturereadilyavailable,forreferencewhentheequipmentisingeneraluse.
Theequipmentmustonlybeusedandmaintainedbysuitablytrained
personnel,capableoffollowingtheproceduresandguidelinesgiveninthisUser
Guide.
1.2 About IQ Series Thermometers
TheAMETEKLandIQseriesarecompact,rugged,industrialthermometers
designedtomeettheneedsofhightemperatureprocesscontrolapplications.
IQseriesthermometersfeatureanallmetaldesignwithintegratedwater
cooling,airpurgeandscrewterminalconnectionstofacilitatesimpleandcost
eectiveoperation.Thermometersareavailablewithfourwavelengthoptions,
includingaratiopyrometer.
Fig.1-1AMETEKLandIQSeriesThermometer
INTRODUCTION
1

series
Fixed Spot Thermometer
User Guide1 - 2
1.3 Nomenclature
TheInstrumentdetaillabelisontherearfaceoftheIQSeriesthermometer.
The instrument Typespeciesthethermometervariantandvariantoptions.
The instrument Serial Numberisauniquenumberincorporatingthe
manufacturedatecode.
Uponreceiptoftheinstrument,checkandmakeanoteoftheinstrumentType
and Serial Number.

series
2 - 1
Fixed Spot Thermometer
User Guide
Model IQ1 IQ2 IQ5 IQR
Operatingrange: 1022to3182°F
550to1750°C
482to2372°F
250to1100°C
392to2012°F
200to1100°C
1292to3182°F
700to1750°C
Speciedrange: 1112to3182°F
600to1750°C
572to2372°F
300to1300°C
482to2012°F
250to1100°C
1382to3182°F
750to1750°C
Spectralresponse: 1 µm 1.6 µm 5 µm 1 µm ratio
Fieldofview
(90%energy):
110:1 110:1 60:1 110:1
Focusing: 250mm/9.8in,500mm/19.7in,1000mm/39.4inandinnity
Output: 0or4to20mAuserselectable(isolated50V)
Response time
(0to90%):
10 ms 10 ms 50 ms 10 ms
Emissivity: 0.10 to 1.00
Nongreyness: 0.80to1.25
Resolution
(midrange):
<1K
Stability: 0.2°/° 0.2°/° 0.02%°/° 0.05%°/°
Accuracy
(absolute):
0.3%+1°C 2°C 0.35%+1°C 0.6%+1.5°C
Timefunctions: Peakpicker,Trackandhold,andAverager
(EnhancedandPremiumvariantsonly)
Alarmoutputs: Processhigh,Processlow,Internaltemperature,
Emissivity/Non-greynesssignallost,Insucientsignal(IQ1only);ratedto50V
d.c.,0.1Anon-inductive,NOorNC-softwareselectable
(EnhancedandPremiumvariantsonly)
Lasersighting: Laserdeningopticalaxis;Class2,1mW,650nm,
120sONduration,Automaticswitch-o
Ambientlimits: 5to60°C/41to140°Fspecied;0to70°C/32to158°Foperating
EMC: EN61326:1999ClassA
Sealing: IP65/NEMA4X
Vibration: 3g(10to300Hz)
Powersupply: 18to30Vd.c.(24Vd.c.nominal-IQ1,2&5currentrequirement:
100mA/IQR:300mA)
Optional
accessories:
1-axisand2-axisadjustablemountingbrackets;Tripodmount;d.c.powersupply
unit;TemperatureindicatorunitLMi
SPECIFICATIONS
2

series
Fixed Spot Thermometer
User Guide2 - 2
Notes for IQR Thermometers
• IQRratiothermometershaveaninternalheaterthatmustbewarmed
upbeforevalidtemperaturereadingscanbeproduced.Thiscantake
typically2to3minutesatroomtemperature,followedbyafurther
stabilisationtimeof2to3minutesbeforeafullyreliablereadingis
available.
• Duringthewarmingupperiod,theinstrumentwillindicate‘Obscuration’
andthetemperatureoutputiseitherheldunderrangeoroverrange,
dependingonyourchosensettingforupscale/downscaledriveunder
conditionsofsignalobscuration.
• Atambienttemperaturesof50°Corabove,theinstrumentwillproduce
avalidoutputimmediately,butwillstillrequire2to3minutessettling
time.
• Inacoldenvironment,atthelowerendoftheambientoperating
temperaturerange,thewarmuptimerequiredmaybeinexcessof10
minutesatthenominal24Vpowersupplyvoltage.Alongerperiodmay
berequiredifthepowersupplyvoltageisbelowthenominalvalue.If
yourapplicationprocessisnotcontinuous(e.g.switchedoovernight),
orifitisinacoldenvironment,itisrecommendedthatanyIQR
installationhasacontinuouspowersupply.Thisisespeciallyrelevantif
yourprocessneedstoberestartedquickly.

series
3 - 1
Fixed Spot Thermometer
User Guide
IQSeriesthermometersoersimpleanalogue‘plug&play’anddigitalmethods
ofcommunication.
3.1 Thermometer configuration
3.1.1 Principal Features
AllIQmodelsincludelasersightingtodenotethecentreofthemeasurement
area.Activatingthelasercanbedoneusingeitherthepush-buttonmounted
onthetopoftheconnectionPCBorbyanexternalvoltfreecontactclosure
acrosstheLSRinandComterminalsontheconnectionPCB.Onceactivatedthe
laserwillremainilluminatedforaperiodof120seconds.
TheyalsohaveRS485digitalcommunications,signalprocessing,2xrelay
alarmsandincludePCcongurationsoftwarewhichisusedtocongureallof
theabove.SeeIQseriesWindowsCongurationSoftwareUserGuideformore
details(partnumber806230).
Fixed,color-codedspacersallowtheusertosetthefocusdistanceastheywish
toanyofthefourpre-denedavailabledistances.Note:Changingthefocus
distancedoesnotaectinstrumentcalibration.
HARDWARE
CONFIGURATION
3

series
Fixed Spot Thermometer
User Guide4 - 1
Warning
CLASS 2 Laser Product.
DONOTstareintolaserbeam(1.0mWmaximumoutputat
650nm).
DONOTlookdirectlytowardsthethermometerwindow,orintothe
laserbeamduringoperation.
Ifthelaserisprojectedontoahighlyreectivesurface,DONOT
lookatthelaserstripefromapositionwhereadirect(‘mirror-
like’)reectionmayentertheeye.
Warning
CLASS 2 Laser Product.
DONOTattempttodisassemblethelaserunitoranyofits
mountingcomponents.
IQSeriesthermometersarettedwithalaseralignmentutility,whichcanbe
usedtoalignthethermometeraccuratelyontherequiredtarget.
Whenthelaserisactivated,alaserbeamisemittedfromthelensinthefront
oftheIQSeriesthermometer.Thelaserbeamdenesthecentrelineofthe
thermometereldofview.Fordetailsofthetargetsizeataparticularpointin
theeldofview,refertothetargetsizetableforyourthermometer.
LASER ALIGNMENT
4

series
4 - 2
Fixed Spot Thermometer
User Guide
TherearefourmethodsofactivatingthelaseralignmentutilityintheIQSeries
thermometer:
• thelaserswitchontherearfaceofthethermometer(SeeFig.4-1);
• a direct connection between pin Com and LSRin on the electrical connector
ontherearfaceofthethermometer.Thisconnectioncanbemadeviaa
user-suppliedexternalswitch;
• Thelaser‘button’intheconguratorsoftware.RefertoSection5.2;
• BysendinganappropriatemessagetothethermometeroveranRS485
digitalcommunicationslink.
Whenthelaserisactivated,itwillremainswitchedonfor2minutes(120
seconds).
Warning
CLASS 2 Laser Product.
Ifthelensisremovedforre-focusingthethermometer,thelaser
energyemittedisincreased.Therefore,ensurethatthelaseris
switchedobeforere-focusingthethermometer
Fig.4-1LocationoflaserwarninglabelsontheIQSeriesThermometer
Laser beam
Laserwarninglabels

series
Fixed Spot Thermometer
User Guide5 - 1
5.1 IQ Thermometer Lens Configuration
ThelocationofthelensoftheIQthermometercanbemanuallycongured
withinthethermometerhousing.This
allowsselectionoffocallengthtosuitthediverserangeofpossibleIQ
thermometerapplications.Thefollowinginformation
detailsthelensandspacercongurationmethod:
Itishighlyrecommendedthatthefollowingprocedureiscarriedoutinaclean
anddryenvironment,eliminatingthe
chanceofthermometercontamination.
1. Unscrew,removeandretainthe4xM2.5retainingscrews(1)fromthe
thermometerwindowholder(2).
2. Removethewindowholderwithsapphirewindow(3)andenvironmentalseal
(4).
3. Removethethreecolouredspacers;red(5),blue(6),yellow(7)andthe
blacklenshousingwithlens(8).Ensurethatthelensisnotmarkedduring
this procedure.
4. Congurethethermometerlensandspacerstomatchtheapplication(see
‘ThermometerSighting’).
5. Placethespacersandlensintothehousingintherelevantorder,ensuring
thattheblacklenshousingisplacedwiththemarkerlinefacingtowardsthe
window.
6. Checkthattheenvironmentalsealisintactandrettothethermometer
housing.
7. Ensurethatthesapphirewindowiscleanandsmearfree.Placethewindow
housingwithsapphirewindowandpositioninthethermometerwindow
recess,ensuringthatthesealisnottrappedanywhere.
8. Retandtightenthe4xwindowhousingretainingscrews.
9. Ensurethatthesapphirewindowiscleanandsmearfree
INSTRUMENT SETUP &
CONFIGURATION
5

series
5 - 2
Fixed Spot Thermometer
User Guide
Window retaining screws x4 (1)
Environmental seal (4)
Window holder (2)
Sapphire window (3)
'Yellow' spacer (7)
'Blue' spacer (6)
'Black' lens housing with lens(8)
'Red' spacer (5)
IQ Thermometer IQ5
IQ Thermometer IQ1, IQ2 and IQR
Focus at 250mm/9.8in
Spot size
mm
Distance
Spot size
inches
Distance
18 2.5 23 64 146 228
250 500 1000 20000 3000
0.7 0.1 0.91 2.52 5.8 9.0
9.8 19.7 39.4 78.80 118.2
Y/BL/R/BK
Focus at 500mm/19.7in
Distance 19.7 39.4 78.80 118.2
Spot size
mm
Spot size
inches
16 5 26 68 110
500 1000 20000 3000
0.63 0.2 1.02 2.7 4.3
Y/BL/BK/R
Focus at 1000mm/39.4in
Y/BK/BL/R
Spot size
mm
Distance
Spot size
inches
Distance
16 13 10 36 74
500 1000 20000 3000
0.63 0.51 0.39 1.4 2.9
19.7 39.4 78.80 118.2
Focus at Innity
BK/Y/BL/R
Spot size
mm
Distance
Spot size
inches
Distance
15 20 25 35 45
500 1000 20000 3000
0.59 0.79 0.99 1.38 1.77
19.7 39.4 78.80 118.2
Focus at 250mm/9.8in
Y/BL/R/BK
Spot size
mm
Distance
Spot size
inches
Distance
20 5 30 80 180
500 1000 15000 2000
0.79 0.20 3.1 5.1 7.1
9.8 19.7 59.1
0 78.8
130
250
1.18
39.4
Focus at 500mm/19.7in
Y/BL/BK/R
Spot size
mm
Distance
Spot size
inches
Distance
18 10 38 94
500 1000 15000 2000
0.71 1.5 2.6 3.7
19.7 59.1
0 78.8
56
0.39
39.4
Focus at 1000mm/39.4in
Y/BK/BL/R
Spot size
mm
Distance
Spot size
inches
Distance
17 19 20 57
500 1000 15000 2000
0.67 0.79 1.5 2.2
19.7 59.1
0 78.8
39
0.75
39.4
Focus at Innity
BK/Y/BL/R
Spot size
mm
Distance
Spot size
inches
Distance
16 26 36 56
500 1000 15000 2000
0.63 1.42 1.81 2.21
19.7 59.1
0 78.8
46
1.02
39.4

series
Fixed Spot Thermometer
User Guide5 - 3
Note
The 1 to 1 (Address 0) mode must notbeusedifmorethanoneIQ
thermometerisconnectedtotheRS485port.
The 1 to 1modeenablescommunicationwiththethermometer,regardlessof
the unreasonable thermometer address.
WheremultiplethermometersaretobeconnectedtoasharedRS485bus,the
instrumentsshouldrstbeconguredseparatelyandgivenauniqueaddress,
sothateachthermometeronthesharedbuswillhaveaseparateaddress.
5.2 IQ Series Configurator Software
Note
The IQ SeriesConguratorSoftwareisprovidedfreeofcharge.This
enableslow-costcongurationofIQSeriesthermometersusinganRS485
physicalconnection.
AMETEKLandrecommendstheuseofUSBtoRS485ConnectionKit(Part
Nº806370)forcomputerswithoutanRS485port.
TheseinstructionsdetailhowtoinstallandusetheIQSeriesCongurator
Software.ThisallowsanIQSeriesthermometertobeconguredfromany
laptoporPChavinganRS485connection.
1) InserttheIQseriesCDintothedriveonyourcomputer.
2) Ifthesoftwaredoesnotrunautomatically,opentheMy Computer
utilityonyourPCanddouble-clickontheSetup.exelelistedintheCD
contents.
3) FollowandconrmtheWizardpromptstoinstallthesoftware.AnIQ
SeriesiconisautomaticallyplacedontheDesktopwheninstallationis
successful.
4) Double-clicktheIQ SeriesiconontheDesktoptostarttheCongurator
software.TheHomepageisdisplayedbydefault.
Note
If‘LiveData’isnotdisplayed(greyedout),checkthatthelaptop/PC
commsandthethermometercommsaresynchronised.Alsocheckthatthe
thermometerisconnectedcorrectly.
If‘LiveData’is‘greyedout’;
1) SelecttheComms menu option.
2) FromtheCommsdrop-downmenu,setthefollowing:
• Serial Port-serialportconnectinglaptop/PCandthermometer,default
set to 1
• Baud Rate-datatransferratebetweenthermometerandlaptop/PC.
Ensure that this is set to 57600(default).
• Address-theconguratoraddress(1to254),defaultsetto1
• 1 to 1 (Address 0)-usedwhenonlyoneIQSeriesthermometeris
connectedtotheRS485port

series
5 - 4
Fixed Spot Thermometer
User Guide
Onceinstalledonthesharedbus,communicationwithaparticularthermometer
isachievedbysettingtheconguratoraddresstomatchthatofthe
thermometer.
Whenallthe‘485Settings’aresynchronisedbetweenlaptop/PCand
thermometer,thedynamic‘LiveData’isthendisplayed.Ifthisdoesnot
happen,checkthatthethermometerconnectionsarecorrect,asshownin
Fig.5-1.

series
Fixed Spot Thermometer
User Guide5 - 5
12 3
4
5
6
8
9
10
11
13
12
15
IMPORTANT: Please note radiation safety warning, where this symbol
appears
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
1mW MAX OUTPUT AT 650nm
IEC 60825-1:2007
Fig.5-1 ConguratorwithIQ1,IQ2orIQ5thermometerconnected

series
5 - 6
Fixed Spot Thermometer
User Guide
Fig.5-2 ConguratorwithIQRthermometerconnected
12 3
4
57 8
910
11
13
12
14
15
IMPORTANT: Please note radiation safety warning, where this symbol
appears
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
1mW MAX OUTPUT AT 650nm
IEC 60825-1:2007

series
Fixed Spot Thermometer
User Guide5 - 7
Item Description User set? Function
1 File Yes New-resetstoadefaultconguration
setting
Open-opensasavedcongurationle
Save-savesthecurrentconguration
le.Note:selectingSavewhenrunning
fromthedefaultcongurationi.e.Default.
snt(Item15)willcreateanewdefault
conguration,whichwillbeappliedwhen
theconguratorisnextopened.
Save As-savesthecurrentconguration
lewithanewlename
Exit-closestheIQSeriesCongurator
2 Thermometer Yes Apply-appliesanychangesmadetothe
thermometer
Read-readsanddisplaystheparameters
set in the thermometer
3 Comms Yes 485 Settings-displaysandallows
changestobemadetotheRS485
settings.SerialPort,BaudRateand
Address(seeFig.5-3).Notethatthis
menuonlysetsthebaudrateofthe
congurator,not the thermometer.
Note:thefactorydefaultbaudrate
settingis57600forboththesoftwareand
forallIQSeriesthermometers.
4 Live Data No Continuouslyupdatedinformation,
includingtargettemperatureinstrument
Label,Internal Ambient Temperature,
selected Time Function and Alarms status
Fig.5-3 ‘485Settings’sub-menu

series
5 - 8
Fixed Spot Thermometer
User Guide
Item Description User set? Function
5 Thermometer
S/N
Address
Type
Label
Units
No
Yes
No
Yes
Yes
Instrument serial number
TheRS485addressofthethermometer.
Tochangetheaddress,typetherequired
addressinthetextbox,thenclickon
Apply(Item13).Notethatinorderto
maintain communication between the
conguratorandthethermometer,either
theconguratoraddressmustbechanged
tomatchthenewthermometeraddress,
orthe1:1modemustbeselected.
Instrumenttype
Label or name allocated to the
instrument,determinedbytheuser
°C or °F,selectablebytheuser
6 Emissivity
(IQ1,2&5)
Setting
Mode
Yes
Yes
Setbytheuser,range0.10 to 1.00
Serialoptionallowstheemissivitytobe
setusingthedigitalSettingfunction.
0-20mAoption,readstheanalog
emissivitysettingdirectlyfromthe
instrument.
7 Non greyness
(IQRonly)
Setting
Mode
Yes
Yes
Setbytheuser,range0.800 to 1.250
Serialoptionallowsthenongreynessto
besetusingthedigitalSettingfunction.
0-20mAoption,readstheanalognon
greynesssettingdirectlyfromthe
instrument.
8 Output
Usesan‘AZAR’system(adjustablezero,adjustablerange).Allowstheuser
tosetthecurrentoutputtooperateoverareducedspanwithintheoperating
rangeoftheinstrument.
Maximum
Temperature
Minimum
Temperature
Mode
Yes
Yes
Yes
Setstheupperlimitofthetemperature
span
Setsthelowerlimitofthetemperature
span
Sets the output mode to 0-20mA or
4-20mA.Minimumspan50°C/90°F

series
Fixed Spot Thermometer
User Guide5 - 9
Item Description User set? Function
9 Time Function Yes None-Notimefunctionselected(see
Section7.0)
Averager-Adjustableresponsespeed,
smoothsthetemperatureoutputsignalin
relation to the temperature input
Time Constant:0,0.05,0.1,0.15,0.25,
1,2,4,8,16,32,64,128,256or512s
Peak Picker-Allowsyoutomonitorthe
highesttemperaturevaluesinarapidly
varyingprocess
Mode:‘ResetorHold’
Threshold:‘Tmin°toTmax°’
Decay Rate:‘512,256,128,64,32,16,
8,4,2,1,0.5or0.25°/s’
On Delay:‘0to10s’in0.1sincrements
O Delay:‘0to10s’in0.1sincrements
Track and Hold - Tracks a temperature
valuewhenenabledandholdsitwhen
disabled
10 Alarms Yes Twocongurablealarmfunctions.Alarm
1and Alarm 2 - each alarm has the
followingoptions:
AL1 Level (°) Set alarm 1 temperature
level
Mode-LowAlarm:indicateswhenthe
processtemperaturefallsbelowtheset
speciedlimit
High Alarm:indicateswhentheprocess
temperatureexceedsthespeciedlimit.
Ambient Alarm:indicateswhenthe
internal thermometer temperature
exceedsthesafeinternalambientlimitof
70°C/158°F
E/NG Lost Alarm:indicateslossofthe
emissivity/non-greynesssignal.Activates
when the input current is <1mA
Obscuration Alarm:indicatesexcessive
obscuration(Ratiothermometersonly)
Contact Mode:‘NC’(NormallyClosed),
‘NO’(NormallyOpen)NOTE:For
‘failsafe’operationusethe‘NC’option
AL2 Level (°)-AsAL1Level(°)above
