Ametrix 36W User manual

29.97
13
16 "
1"
25.40
Side ViewTop View
(Mounting screws and wire connection box not included)
16 "
11
11
16
16
32
29.97
"
415.04
1
"
3
16
424.18
13
16 "
29.97
other special installation requirements. See ballast manufacturer's installation instructions or
ADY071486 REV A(ECN080361)
Mounting of Compact Fluorescent
Ballasts
contact the factory for remote mounting distance and installation requirements.
Ballast Dimensions for Remote
Remote Ballast Mounting Instructions
Attention:
Maximum remote distance for an electronic ballast depends upon the ballast manufacturer
and may require use of special low capacitance wire, separate conduit runs for lead wires, or
Remote ballast mounting is not outdoor rated. All remote ballasts must be
mounted indoor, unless special ordered.
Supplementary Installation Instructions
mount fixtures vertically.
Warning : Before starting any work ensure
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician.
Do not
Sheet 1 of 1
Lamp
Description
# of
Lamps Wattage Voltage
Remote
Ballast
Distance
Lamp
Description
# of
Lamps Wattage Voltage
Remote
Ballast
Distance
Twin tube 1 36W UNV 20ft. Twin tube 2 36W UNV 20ft.
Twin tube 1 36W 347V 20ft. Twin tube 2 36W 347V 20ft.
Twin tube 1 50W UNV 20ft. Twin tube 2 50W UNV 20ft.
Twin tube 1 50W 347V 20ft. Twin tube 2 50W 347V 20ft.
Twin tube 1 55W UNV 20ft. Twin tube 2 55W UNV 20ft.
Twin tube 1 55W 347V 20ft. Twin tube 2 55W 347V 20ft.
