AMI 26685001 User manual

Page 1of 2
26685050
REV. A
Kit NGX SERIES COIN BLOCKOUT
Kit #26685001
These instructions outline the procedures to install a Blockout for the
Imonex coin accepter into your NGX and NGX MINI jukeboxes.
Tools Required
¼ Nut Driver.
Parts Included with this Kit:
Item # Part Number Description Quantity
1 34105105 Blockout – Imonex Coin Mech 1
2 80713006 #8 – 32 X 3/8 Hex Hd Screw 4
These Instructions
Figure 1
(Partial Rear View Of Currency Panel/Door)
Installation Instructions
Remove &
Replace With
K
it
S
cre
w
Coin Mech

Page 2 of 2
26685050
REV. A
Installing a Coin Blockout requires removal of the Coin Mech. The following procedure
is applicable for any position (side or center) of the Coin Mech. Follow the step by step
instructions to install this kit.
1. Power off and unplug the jukebox. Open the front or currency module door to gain
access to the back of the Coin Mech.
2. Disconnect the wiring to the Coin mech.
3. Referring to Figure 1, remove the four screws fastening the Coin Mech to the door and
remove the Coin Mech.
4. Place the kit supplied Coin Mech Blockout in place of the just removed Coin Mech on
the front of the jukebox door/ currency module and using the kit supplied #8-32 X 3/8
screws, fasten the blockout in place.
