Schertler RESOCOIL User manual

Schertler SA
Via Beroldingen 18
6850 Mendrisio
Switzerland
T [phone]
F [phone]
[e-mail]
www.schertler.swiss
Facebook @schertler.sa
Instagram @schertleraudio
Youtube @Schertler SA
#shareyourschertler
QUICK GUIDE V1
RESOCOIL
QUICK GUIDE
THANK YOU
FOR
CHOOSING
SCHERTLER
QUICK START
INSTALLATION
Using double-sided tape, temporarily x the pickup
on the outside of the instrument. See the pictures on
the internal pages for typical positioning on the
most commonly-used instruments.
Test the pickup, trying out different positions to nd
the best sound.
Once you have found the best position, remove the
strings to access the inside of the body and
permanently install the pickup inside the instrument.
Fix in place using contact glue (like the one used for
shoe repair).
Replace the strings. USER GUIDE available at
ww.schertler.com
Scan the QR code
to open
the USER GUIDE

INSTALLATION
RESOCOIL JACK
1. Remove the strings
2. Choose whether you want to install the 1/4
jack connector on the side (Fig. 1) or on the
tailblock (Fig. 2)
3. Drill a 12 mm hole in the guitar side for the jack
connector
4. Install the jack connector by tightening the
inside and outside nuts
5. Follow the “Fitting the Microphone instructions
6. Replace the string set
Fig. 1:
Installation
on the side
Fig. 2:
Installation on the
tailblock

RECOMMENDED
POSITIONING
Acoustic guitar Classical guitar Flamenco/jazz guitar
Mandolin - Lute - Oud - Bouzouki Ukulele Banjo

RELATED PRODUCTS
ARTHUR
Mixer
ACOUSTIC
Amps
YELLOW BLENDER
Preamps
YELLOW SINGLE
Preamps
STAT PRE PS
Preamp
STAT PRE
Preamp
CA JM JM
¼”ja k able CA XF XM XLR able
