DISHWASHER QUICK START GUIDE: EGSPV 587 910 / ZIM435B
Dear Customer,
This Quick Start Guide is enclosed
with detailed dishwasher Operating
Instructions. Before using the
appliance carefully read the Operating
Instructions, especially guidelines for
safe use.
Before plugging your dishwasher
into the mains power, remove the
safety packaging. Do not start the
dishwasher before it is properly set up.
Turn on the appliance1
Open the dishwasher door, press the on/o󰘯
button. Power indicator will be on
Dispense detergent2
Press the latch to open the detergent dispenser.
Add detergent to the dispenser.
Check the special salt
level
3
Add special salt to the dispenser when the
corresponding indicator on the control panel
comes on.
Load the dishes
4
Remove food leftovers from the dishes
Place the dishes in the baskets according to loading
guidelines.
It is recommended to load the lower basket 󰘰rst, then
the upper basket.
Select the wash programme
5
Open the door, press the Power button
Choose a program, the response light will turn on.
Then close the door, the dishwasher will start its
cycle.
IO-DWS-2468 (EN) 10.2020./1
Start your dishwasher
6
Open the dishwasher door.
The dishwasher will start a wash programme.
Turn o󰘯 the appliance
7
Turn the appliance o󰘯 using the On/O󰘯 button.
Remove dishes from the
appliance
8
When the dishwasher is o󰘯, open the door and wait
about 15 minutes before removing the dishes. This
will also facilitate the drying process. Hot dishes are
more susceptible to cracking.
Features and components
Spray arms
Cutlery basket
Upper basket
Inner tube
Lower basket
Salt container
Detergent dispenser
Mugs and cups shelves
Main 󰘰lter
Water supply hose connection
Water drain hose
Regulator
9
NOTE:
Figures are for illustrative purposes only Individual models may vary.
Lower spray arm
Filter assembly
Inner pipe
Salt container
Dispenser
Cutlery basket Lower basket
Upper basket
Cutlery rack
Cup rack
Upper spray
arm

TABLE OF WASH PROGRAMMES: EGSPV 587 910 / ZIM435B
Standard programme This is a reference program for research institutes. Tests according to EN
50242.
 Thisprogrammeissuitableforwashingnormallysoiledtableware.Thisisthemoste󰀨ectivepro-
gramme taking into account the total energy and water consumption for this kind of tableware.
** Programmeduration,energyandwaterconsumptionvaluegiveninthetablehavebeendeter-
minedunderlaboratoryconditions.Actualvaluescanvary.
*
ITEM Programme name
The
default
tempera-
ture
[°C]
Type of soil Amount of
detergent
Duration
[min.] *
Power
consumption
[kWh] *
Water
consumption
[litres] *
1
2
3**ECO
70°
4
50°
Self-Cleaning 70°
Soil level
With the Sanitize option selected, the water tem-
peratureisincreasedto70˚Cforhightemperature
sanitization.
Intensivesoil 27g
(1 item)
Wash
70°C Dry
Light soil 27g
(1 item)
Wash 45°C Rinse 60°C
Rinse
Lightly soiled glass-ware and porcelain
Light soil 5g / 22g
(1 or 2 items)
Pre-wash
35°C
Rinse Dry
Wash 60°C
Pre-wash Wash 70°C
Type of cycle
45°
A shorter wash for lightly soiled loads that do not need
drying.
Thisprogramprovidesane󰀨ectivecleaningofthe
dishwasher itself. Light soil
Hygiene
Rinse Rinse 70°C
Dry
5g / 22g
(1 or 2 items)
Rinse
1 hour 60° For normally soiled loads that need quick wash.
Rinse 60°C
Rinse 70°C Dry
5Rapid Light soil 15g
Wash
50°C
Rinse Rinse 45°C
Rinse
200 1.310 12.9
235 0.691 9.0
60 0.897 13.3
30 0.611 10.0
145 1.056 13.2

DISHWASHER QUICK START GUIDE: EGSPV 587 910 / ZIM435B
Dear Customer,
This Quick Start Guide is enclosed
with detailed dishwasher Operating
Instructions. Before using the
appliance carefully read the Operating
Instructions, especially guidelines for
safe use.
Before plugging your dishwasher
into the mains power, remove the
safety packaging. Do not start the
dishwasher before it is properly set up.
Turn on the appliance1
Open the dishwasher door, press the on/o󰘯
button. Power indicator will be on
Dispense detergent2
Press the latch to open the detergent dispenser.
Add detergent to the dispenser.
Check the special salt
level
3
Add special salt to the dispenser when the
corresponding indicator on the control panel
comes on.
Load the dishes
4
Remove food leftovers from the dishes
Place the dishes in the baskets according to loading
guidelines.
It is recommended to load the lower basket 󰘰rst, then
the upper basket.
Select the wash programme
5
Open the door, press the Power button
Choose a program, the response light will turn on.
Then close the door, the dishwasher will start its
cycle.
Start your dishwasher
6
Open the dishwasher door.
The dishwasher will start a wash programme.
Turn o󰘯 the appliance
7
Turn the appliance o󰘯 using the On/O󰘯 button.
Remove dishes from the
appliance
8
When the dishwasher is o󰘯, open the door and wait
about 15 minutes before removing the dishes. This
will also facilitate the drying process. Hot dishes are
more susceptible to cracking.
Features and components
Spray arms
Cutlery basket
Upper basket
Inner tube
Lower basket
Salt container
Detergent dispenser
Mugs and cups shelves
Main 󰘰lter
Water supply hose connection
Water drain hose
Regulator
9
NOTE:
Figures are for illustrative purposes only Individual models may vary.
Lower spray arm
Filter assembly
Inner pipe
Salt container
Dispenser
Cutlery basket Lower basket
Upper basket
Cutlery rack
Cup rack
Upper spray
arm

TABLE OF WASH PROGRAMMES: EGSPV 587 910 / ZIM435B
Standard programme This is a reference program for research institutes. Tests according to EN
60436.
 Thisprogrammeissuitableforwashingnormallysoiledtableware.Thisisthemoste󰀨ectivepro-
gramme taking into account the total energy and water consumption for this kind of tableware.
**
Programmeduration,energyandwaterconsumptionvaluegiveninthetablehavebeendeter-
minedunderlaboratoryconditions.Actualvaluescanvary.
*
ITEM Programme name
The
default
tempera-
ture
[°C]
Type of soil Amount of
detergent
Duration
[min.] *
Power
consumption
[kWh] *
Water
consumption
[litres] *
1
2
3**ECO
70°
4
50°
Self-Cleaning 70°
Soil level
With the Sanitize option selected, the water tem-
peratureisincreasedto70˚Cforhightemperature
sanitization.
Intensivesoil 17g
(1 or 2 items)
Wash
70°C Dry
Light soil 17g
(1 or 2 items)
Wash 45°C Rinse 60°C
Rinse
Lightly soiled glass-ware and porcelain
Light soil 4g / 13g
(1 or 2 items)
Pre-wash
35°C
Rinse Dry
Wash 60°C
Pre-wash Wash 70°C
Type of cycle
45°
A shorter wash for lightly soiled loads that do not need
drying.
Thisprogramprovidesane󰀨ectivecleaningofthe
dishwasher itself. Light soil
Hygiene
Rinse Rinse 70°C
Dry
4g / 13g
(1 or 2 items)
Rinse
1 hour 60° For normally soiled loads that need quick wash.
Rinse 60°C
Rinse 70°C Dry
5Rapid Light soil 12g
Wash
50°C
Rinse Rinse 45°C
Rinse
200 1.310 12.9
235 0.704 9.0
60 0.897 13.3
30 0.611 10.0
145 1.056 13.2
