AMobile G47 User manual
I
2015.11
G47
Mobile Computing Device
User's Manual
Version 1.0
- II -
This page is intentionally left blank.
- i -
Revision History
Version Release Time Description
1.0 2020.12 Initial release
- ii -
Copyright
Copyright © 2015 AMobile Intelligent Corp. All Rights Reserved.
This document contains proprietary information protected by copyright. No part
of this manual may be reproduced by any mechanical, electronic, or other means
in any form without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
About This Manual
This user’s manual provides the general information and installation instructions
for the product. The manual is meant for the experienced users and integrators
with hardware knowledge of personal computers. If you are not sure about any
description in this manual, consult your vendor before further handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing AMobile
products.
- iii -
Contents
Contents
Preface...........................................................................................................v
Declaration of Conformity.....................................................................................v
Emergency call.............................................................................................x
FCC Warning: ............................................................................................xi
RoHS.......................................................................................................... xii
SVHC / REACH.......................................................................................... xii
Safety Symbols ................................................................................................. xiii
Important Safety Instructions ............................................................................ xiii
Laser Safety...................................................................................................... xiv
Rechargeable Battery Pack Safety ................................................................... xiv
General Cleaning Tips....................................................................................... xvi
Cleaning Tools........................................................................................... xvi
Recommended Cleaning Procedures ...................................................... xvii
Disposing of the Equipment .............................................................................xviii
Additional Information & Technical Support .....................................................xviii
Warranty............................................................................................................ xix
Chapter 1 Introduction................................................................................3
1.1 Product Highlights..........................................................................................4
1.2 Package Contents..........................................................................................5
1.3 Parts of the Device.........................................................................................6
1.4 Parts of the Device.........................................................................................6
1.5 Dimensions ....................................................................................................6
1.6 Specications.................................................................................................6
1.4 Dimensions ....................................................................................................7
1.5 Specications.................................................................................................8
Chapter 2 Installation................................................................................ 11
2.1 Installing microSD and SIM Card.................................................................12
2.2 Charging the Battery ....................................................................................13
2.2.1 Charging the Battery .........................................................................13
2.2.2 Checking the Battery Level ...............................................................13
2.3 Installing/Replacing the Battery....................................................................14
2.4 Optimizing Battery Life.................................................................................14
Chapter 3 Using the Device......................................................................15
3.1 Using Touch Screen.....................................................................................16
3.1.1 Basic Operations...............................................................................16
3.1.2 Text Input...........................................................................................17
- iv -
Contents
3.1.3 Sleep Mode.......................................................................................17
3.2 Home Screen ...............................................................................................18
3.2.1 Using the Quick Settings Panel.........................................................20
3.2.2 Extending Home Screen ...................................................................20
3.3 Using Cellular Network.................................................................................21
3.3.1 Making/Receiving Calls.....................................................................22
3.3.2 Data Connection ...............................................................................22
3.3.3 Data Roaming ...................................................................................23
3.4 Using the Wi-Fi Feature ...............................................................................24
3.4.1 Enabling Wi-Fi and Connecting to a WLAN ......................................25
3.4.2 Adding a Wi-Fi Network.....................................................................26
3.4.3 Connecting to a Wi-Fi Network by WPS ...........................................27
3.4.4 Forgetting/Modifying a Wi-Fi Network...............................................29
3.4.5 Making Your Device a Wi-Fi Hotspot.................................................29
3.5 Using the Bluetooth Feature ........................................................................30
3.5.1 Enabling Bluetooth and Pairing with Bluetooth Device .....................31
3.5.2 Conguring Bluetooth Features to Use.............................................32
3.5.3 Disconnect from a Bluetooth Device.................................................33
3.5.4 Making Your Bluetooth Device Discoverable ....................................33
3.5.5 Additional Bluetooth Settings ............................................................33
3.6 Using the Location Feature..........................................................................34
3.6.1 Enabling/Disabling Location Service.................................................34
3.6.2 Location Mode...................................................................................34
3.7 Using Camera ..............................................................................................35
3.8 Using the NFC Feature ................................................................................37
3.8.1 Enabling/Disabling NFC....................................................................37
3.8.2 Conguring NFC Modes....................................................................37
3.8.3 Exchanging Data with NFC-Enabled Device.....................................38
3.9 Using the Barcode Scanner .........................................................................39
3.9.2 Scanning the Barcode.......................................................................40
3.9.3 Supported Barcode Formats.............................................................41
- v -
Preface
Declaration of Conformity
CE
Environmental Conditions
Device Operating Temperature: -20° C to 55°C
Battery charging temperature: -20° C to 40°C
Working humidity 65+/-20%RH
Hereby, Hong Kong AMobile Intelligent Corp. Limited Taiwan Branch, declares
that this Mobile Computing Device/ G47, is in compliance with the essential
Requirements and other relevant provisions of Radio Equipment Directive
2014/53/EU.
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working
electrical equipment to an appropriate waste disposal center.
A warning that batteries(battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, re or the like.
CAUTION RISK OF EXPLOSION IF BATTERY IS RWPLACED BY AN
INCORRECT TYPE.
DISPOSE OF USED BATTERYS ACCORDING TO THE INSTRUCTINS
Preface
- vi -
Preface
Charge at constant current of 0.2C until voltage reaches 4.25V, then charge at
constant voltage 4.25V till charge current reduce to 0.02C.
The following standards have been applied for the investigation of compliance:
Use careful with the earphone maybe possible excessive sound pressure from
earphones and headphones can cause hearing loss.
The product shall only be connected to a USB interface of version USB2.0 or
higher and that the connection to a power USB is prohibited.
Adapter shall be installed near the equipment and shall be easily accessible.
The AC plug considered as disconnect device of adapter.
Only can use adapter as below: SHEN ZHEN HUAJIN ELECTRONICS CO.,LTD
Adapter model: HJ-FC010K7-EU: I/P AC 100-240V, 50/60Hz, 0.35A, O/P 5.0V,
2.0A / 9V, 2.0A / 12V, 1.5A
The RF distance between body and mobile phone is 5mm.
5G ( if necessary)
For 5150-5250 and 5725-5850 frequency band,
Operations in the 5150-5250 and 5725-5850 band are restricted to indoor usage
only.
- vii -
Preface
Product Name: Mobile Computing Device
Model No.: G47
Brand Name: N/A
Hardware Version: S6_MB_V1.2
Software Version: G47_V02_20181127
Adapter: lanufacturer: SHEN ZHEN HUAJIN
ELECTRONICS CO.,LTD
Model No.: HJ-FC010K7-EU
I/P AC 100-240V, 50/60Hz, 0.35A
O/P 5V, 2.0A / 9V, 2.0A / 12V, 1.5A
Battery: Manufacturer: Hong Kong AMobile In-
telligent Corp. Limited Taiwan Branch
Model No.: G47
DC 3.8V 4000mAh
USB Cable: Manufacturer: Hong Kong AMobile In-
telligent Corp. Limited
Taiwan Branch
Model No.: G47
Length: 1000mm
Draft ETSI EN 301 489-1 V2.2.0 (2017-03)
Final draft ETSI EN 301 489-3 V2.1.1 (2017-03)
Draft ETSI EN 301 489-17 V3.2.0 (2017-03)
Draft ETSI EN 301 489-19 V2.1.0 (2017-03)
Draft ETSI EN 301 489-52 V1.1.0 (2016-11)
- viii -
Preface
ETSI EN 301 511 V9.0.2 (2003-03)
ETSI EN 301 908-1 V11.1.1 (2016-07)
ETSI EN 301 908-2 V11.1.1 (2016-07)
ETSI EN 301 908-13 V11.1.1 (2016-07)
ETSI EN 303 413 V1.1.1 (2017-06)
ETSI EN 300 330 V2.1.1 (2017-02)
ETSI EN 301 893 V2.1.1 (2017-05)
ETSI EN 300 328 V2.1.1 (2016-11)
EN 62479: 2010
EN 50566: 2017
EN 50360: 2017
EN 62209-1: 2016
EN 62209-2: 2010
IEC 62133-2: 2017
EN 62471: 2008
EN 60950-1: 2006 +A11: 2009 +A1: 2010+A12: 2011+A2: 2013
EN 50332-1: 2013
EN 50332-2: 2013
EN 55032:2015
EN 55024: 2010
EN 61000-3-2: 2014
EN 61000-3-3: 2013
- ix -
Preface
Manufacturer Name: Hong Kong AMobile Intelligent Corp. Limited Taiwan Branch
Manufacturer Address: 8F.-1, No.700, Zhongzheng Rd., Zhonghe Dist., New Taipei
City 235, Taiwan
Operation Frequency: GSM/GPRS/EGPRS 900: Tx: 880-915MHz, Rx: 925-960MHz
GSM/GPRS/EGPRS 1800: Tx: 1710-1785MHz, Rx: 1805-
1880MHz
GSM/GPRS/EDGE 850: 824-849MHz (Not used in Europe)
PCS/GPRS/EDGE 1900: 1850-1910MHz (Not used in
Europe)
WCDMA Band I: Tx: 1920-1980MHz, Rx: 2110-2170MHz
WCDMA Band VIII: Tx: 880-915MHz, Rx: 925-960MHz
WCDMA Band II: 1850-1910MHz (Not used in Europe)
WCDMA Band V: 824-849MHz (Not used in Europe)
WCDMA Band IV:1710-1755MHz (Not used in Europe)
LTE Band 1: Tx: 1920-1980MHz, Rx: 2110-2170MHz
LTE Band 3: Tx: 1710-1785MHz, Rx: 1805-1880MHz
LTE Band 7: Tx: 2500-2570MHz, Rx: 2620-2690MHz
LTE Band 8: Tx: 880-915MHz, Rx: 925-960MHz
LTE Band 20: Tx: 832-862MHz, Rx: 791-821MHz
LTE Band 38: Tx: 2570-2620MHz, Rx: 2570-2620MHz
LTE Band 40: Tx: 2300-2400MHz, Rx: 2300-2400MHz
LTE Band 2: 1850-1910MHz (Not used in Europe)
- x -
Preface
Operation Frequency: LTE Band 4: 1710-1755MHz (Not used in Europe)
LTE Band 5: 823-850MHz (Not used in Europe)
LTE Band 7: 2500-2570MHz (Not used in Europe)
LTE Band 12: 699~716MHz (Not used in Europe)
LTE Band 17: 704-716MHz (Not used in Europe)
WiFi: 802.11b/g/n HT20: 2412-2472MHz
802.11n HT40: 2422-2462MHz
802.11a/n/ac: 5150-5250MHz
Bluetooth: 2402-2480MHz
GPS: 1.57GHz
NFC: 13.56MHz
Max. RF output power: GSM900: 33 dBm
GSM1800: 30 dBm
WCDMA FDD Band: 24 dBm
LTE FDD/TDD Band: 23 dBm
WiFi (2.4G): 9.45 dBm EIRP
WiFi (5G): 9.40 dBm EIRP
Bluetooth: 6.48 dBm EIRP
NFC: 15.38 dBμA/m
The RF frequencies can be used in Europe without restriction.
This product is intended for sale and application in a business environment.
Emergency call
If any emergency arises, dial 112/911 (or other emergency call number) for
emergency help.
Due to the nature of cellular networking, the success of emergency call is not
guaranteed.
- xi -
Preface
FCC Warning:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
Any changes or modications not expressly approved by the guarantee of this
device could void the user’s authority to operate the device.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue.
Mobile Computing Device G47 model (FCC ID: 2AQ5W-G47) has also been
tested against this SAR limit. The highest reported SAR values for head, body-
worn accessory, and product specic (Hotspot) are 0.78W/kg, 0.79 W/kg, and
0.79 W/kg respectively. The Max simultaneous SAR is 1.10 W/kg. This device was
tested for typical body-worn operations with the back of the handset kept 10mm
from the body. To maintain compliance with FCC RF exposure requirements,
use accessories that maintain a 10mm separation distance between the user's
- xii -
Preface
body and the back of the handset. The use of belt clips, holsters and similar
accessories should not contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
5G
For 5150-5250 and 5725-5850 frequency band,
Operations in the 5150-5250 and 5725-5850 band are restricted to indoor usage
only.
5G:
Any emission is maintained within the band of operation under all conditions of
normal operation. The max. frequency stability is less than 20ppm.
RoHS
AMobile Intelligent Corporation certies that all components in its products
are in compliance and conform to the European Union’s Restriction of Use of
Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive
2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
AMobile Intelligent Corporation hereby states that the listed products do not
contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB
that exceed a maximum concentration value of 0.1% by weight or for cadmium
exceed 0.01% by weight, per homogenous material. Homogenous material is
dened as a substance or mixture of substances with uniform composition (such
as solders, resins, plating, etc.). Lead-free solder is used for all terminations
(Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth
we live, AMobile hereby conrms all products comply with the restriction of SVHC
(Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration,
- xiii -
Preface
Evaluation, Authorization, and Restriction of Chemicals) regulated by the
European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)
Safety Symbols
This symbol indicates that a potential hazard to personal safety
exists from a laser source. When this symbol is displayed in this
manual, pay special attention to the specic safety information
associated with the symbol
Important Safety Instructions
Read these safety instructions carefully:
1. Read all cautions and warnings on the device.
2. Dropping it or letting it fall may cause damage.
3. Make sure the correct voltage is connected to the device.
4. For pluggable device, the socket outlet should be near the device and should
be easily accessible.
5. Disconnect this device from the A/C outlet before cleaning it. Use a moist
cloth. Do not use liquid or sprayed detergent for cleaning.
6. Do not scratch or rub the screen with a hard object.
7. Never use any of the solvents, such as Thinner Spray-type cleaner, Wax,
Benzene, Abrasive cleaner, Acid or Alkaline solvent, on the display. Harsh
chemicals may cause damage to the cabinet and the touch sensor.
8. Remove dirt with a lightly moistened cloth and a mild solvent detergent.
Then wipe the cabinet with a soft dry cloth.
9. If the device will not be used for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
10. Never pour any liquid into openings. This may cause electrical shock.
11. Never open the device. For safety reasons, the device should be opened
only by qualied service personnel.
- xiv -
Preface
12. If one of the following situations arises, get the device checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the device.
c. The device does not work well, or you cannot get it to work according to
the user’s manual.
d. The device has been damaged.
e. The device has obvious signs of breakage.
13. Keep this User’s Manual for later reference.
14. Do not leave this device in an uncontrolled environment where the storage
temperature is below-20°C (-4°F) or above 55°C (131°F). This may damage
the device.
Do not use the power adapter that isn’t made for the equipment.
Supplying the equipment with inappropriate voltage may cause harm to
or burn the equipment.
To prevent possible hearing damage, do not listen at high volume
levels for long periods
Laser Safety
The device's barcode scanner that uses laser lights is a class 2 laser product.
DO NOT stare into the laser beams or point the laser beam at anyone's eyes
when the barcode scanner is in operation.
Rechargeable Battery Pack Safety
With very little care, you can optimize the battery life and maximize the lifespan
of the battery. Most importantly, use only the device in its ideal operating
temperature (refer to 1.5 Specifications on page 8) – do not leave it in a hot
trunk during the summer.
- xv -
Preface
•Important Terms to Understand
“Battery life” means the time the device will run before it must be recharged
(sometimes this is also called “playtime” or “runtime”).
“Battery lifespan” means the total amount of time your battery will last before it
must be replaced.
•Using the Device for the First Time
Be sure to fully charge (approx. 3 hours) the device when charging the device
for the rst time.
•Long-Term Storage & Maintenance
If you are putting away the device for more than three months, it is recommended
that get recharged every three months. If you store with an uncharged battery, it
could fall into a deep worn-out state which would render it incapable of holding
any charge. Be sure to store the device at the proper temperature (see as 1.5
Specifications on page 8).
•Battery Lifespan
The non-replaceable batteries for the device are designed to retain up to 80%
of their original capacity after 300 charging and recharging cycles when properly
maintained. You may choose to replace new battery with the help of qualied
service personnel when it no longer holds the sucient charge that meets your
needs.
•The lithium-ion battery is currently one of the most popular battery packs.
The best advantage is that it has no memory eect, so users needn’t worry about
that issue. Users can charge the battery anytime whether it is fully drained or not.
However, it’s recommended that users drain the battery until the system shows
power shortage warning and then recharge the battery. Doing so is helpful to the
reliability of your battery.
•Don’t expose the battery to elevated heat situations such as under direct
sunlight in a car or near re.
•Don’t disassemble the battery, or the battery leakage might cause skin or eye
injury. If electrolyte leaking from the battery contacts your skin or clothing,
immediately ush it with running water. If it splashes into eye, rinse the eye
at least 15 minutes with clean water and then seek medical attention.
- xvi -
Preface
•To avoid battery leakage or explosion, don’t discard the battery into water or
re, or put them near a heat source such as a gas stove or an oven.
•If you are putting away the battery for more than three months, it is
recommended that the battery should be fully charged, and get recharged
every three months. If you store the device with an uncharged battery, it
could fall into a deep worn-out state which would render it incapable of
holding any charge. Be sure to store your the device and battery at the
proper temperature (refer to 1.5 Specifications on page 8).
•The battery consists of precise electrical components and cells. Do not drop
or hit the battery.
General Cleaning Tips
You may need the following precautions before you begin to clean the device.
When you clean any single part or component for the device, please thoroughly
read and understand the details below.
1. We strongly recommended that you should shut down the system before
you start to clean any single components.
2. When you need to clean the device, please rub it with a piece of dry cloth.
3. Be cautious of the tiny removable components when you use a vacuum
cleaner to absorb the dirt on the oor.
4. Never drop the components inside the device or get circuit board damp or
wet.
5. Be cautious of all kinds of cleaning solvents or chemicals when you use it
for the sake of cleaning. Some individuals may be allergic to the ingredients.
6. Try not to put any food, drink or cigarette around the device.
Cleaning Tools
Although many companies have created products to help improve the process
of cleaning your devices and peripherals, users can also use household items to
clean their devices and peripherals. Below is a listing of items you may need or
want to use while cleaning your devices or peripherals. Keep in mind that some
components in your device may only be able to be cleaned using a product
- xvii -
Preface
designed for cleaning that component, if this is the case it will be mentioned in
the cleaning.
• Cloth: A piece of cloth is the best tool to use when rubbing up a component.
Although paper towels or tissues can be used on most hardware as well,
we still recommend you to rub it with a piece of cloth.
• Water or rubbing alcohol: You may moisten a piece of cloth a bit with
some water or rubbing alcohol and rub it on the device. Unknown solvents
may be harmful to the plastics parts.
• Vacuum cleaner: Absorb the dust, dirt, hair, cigarette particles, and other
particles out of the device can be one of the best cleaning methods. Over
time, these items can restrict the airow in a device and cause circuitry to
corrode.
• Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are
excellent tools for wiping hard to reach areas in your keyboard, mouse,
and other locations.
• Foam swabs: Whenever possible, it is better to use lint-free swabs such
as foam swabs.
Recommended Cleaning Procedures
1. Close all application programs
2. Close operating software
3. Turn o the equipment
4. Remove all peripherals
5. Disconnect the power cable
6. Proceed to clean.
- xviii -
Preface
Disposing of the Equipment
•Within the European Union
EU-wide legislation, as implemented in each Member State,
requires that waste electrical and electronic products carrying
the mark (left) must be disposed of separately from normal
household waste.
This includes monitors and electrical accessories, such as signal cables or
power cords. When you need to dispose of your display products, please
follow the guidance of your local authority, or ask the shop where you
purchased the product, or if applicable, follow any agreements made between
yourself. The mark on electrical and electronic products only applies to the
current European Union Member States.
•Outside the European Union
If you wish to dispose of used electrical and electronic products outside the
European Union, please contact your local authority so as to comply with the
correct disposal method.
Additional Information & Technical Support
You can download the related technical documents such as datasheet and user’s
manual as well as driver on our website.
Please do not hesitate to call or e-mail our customer service when you still cannot
get the information you need.
http://amobile-solutions.com/web_en/contact.php E-mail: support@amobile.
com.tw
Table of contents
Other AMobile Handheld manuals
