0 dB Mobile GlassFix® Antenna for the 450 MHz Band
DESCRIPTION
Shortened half-wave, mobile antenna for the 450 MHz band using the GlassFix®
mounting principle.
Attractive appearance with encapsulated shortening coil.
Mounting on car window glass – no holes required.
Double-adhesion procedure ensures fast and reliable fixing.
Internal matching unit feeds external antenna through window glass.
Half-wave design – no ground plane required.
High positioning gives performance equal to conventionally mounted car roof antenna.
FME FastCabling system (cable to be ordered separately).
Simple tuning procedure by means of tuning screw on matching unit.
Easy removable whip for car wash.
Swivel joint for 180° angle adjustment.
If removal of antenna installation is necessary, a quick dismantling procedure leaves no
trace of the installation.
NOTE
GF antennas are not suitable for car models with windows that have heat reflective
coating.
ORDERING
Type Product No. Frequency
GF 405/s 130000788 380 ... 410 MHz
GF 405/l 130000789 406 ... 440 MHz
GF 405/h 130000790 430 ... 470 MHz
Accessories FME-Cables
1 m FME(f) 130000437
2 m FME(f) 130000447
3 m FME(f) 130000457
4 m FME(f) 130000466
5 m FME(f) 130000474
6 m FME(f) 130000483
4 m FME-white(f) 110000064
6 m FME-white(f) 110000066
12 m FME-white(f) 110000068
18 m FME-white(f) 110000069
Accessories FME-Connectors
FME(f)-FME(f) 130000583
FME(m)-P(m) (Prolongation) 130000565
FME(m)-N(m) 130000571
FME(m)-FSMA (Female-SMA) 130000578
FME(m)-BNC(m) 130000566
FME(m)-TNC(m) 130000569
FME(m)-UHF(m) 130000572
FME(m)-MUHF(m) (Mini-UHF) 130000573
FME(m)-EMUHF(m) (Elbow-MUHF) 130000582
FME(m)-EBNC(m) (Elbow-BNC) 130000580
FME(m)-ETNC(m) (Elbow-TNC) 130000581
FME(m)-SMA(m) 130000577
FME-SYSTEM ACCESSORIES - NOTE
For further information about other types of FME-cables and FME-connectors, please
compare the cable and connector data sheets under accessories in our catalogue.
SPECIFICATIONS
Electrical
Model GF 405/...
Frequency 450 MHz-band covered by three tunable models
Antenna Type Shortened ½ λ mobile GlassFix® Antenna
Max. Input Power 25 W
Polarisation Vertical
Impedance 50 Ω
VSWR ≤ 1.5:1 @ f.res.
Bandwidth ≥ 8 MHz @ SWR ≤ 2.0
≥ 15 MHz @ SWR ≤ 3.0
Gain (EIA RS-329-1) 0 dB
Mechanical
Materials
Whip: Stainless steel and black-chromed brass
Mount and indoor unit: Weather- and shockproof plastics, Corrosion-safe and
corrosion-protected metals
Cable FME-cable to be ordered separately
Colour Black
Height Approx. 240 mm / 9.45 in.
Weight Approx. 0.03 kg / 0.07 lb
Mounting On car windows with silicone glue
(52 mm x 47 mm obstruction-free mounting area required)
Glass
Thickness 2.5 - 7 mm / 0.10 - 0.28 in.
GF 405/...
Page: 1 of 2
Last edited: 2019/07/05
1. BEFORE INSTALLATION
When selecting mounting location take into consideration: positions of back view mirror,
wiper blade paths and defogger wires (when mounting on rear window). The driver’s
view should not be obstructed.
Max. allowed curvature of the glass surface on the mounting spot is 2 mm deflection per
100 mm length.
Environmental- and car temperature must be above 15° C at installation, and surfaces
to be glued must be dry and clean.
2. INSTALLATION
Do not use sealer on rubber gasket or other places.
3. AFTER INSTALLATION
Allow the silicone gluings to dry off 2 hours at a temperature above 15° C. To ensure full
strength of the glue, it is recommended to keep the whip off the mount for 24 hours.
4. TUNING INSTRUCTIONS
Insert a forward/reflection-type wattmeter between the transmitter and the antenna.
Key the transmitter and observe the forward and the reflected power.
Adjust the tuning screw on the matching unit until minimum returned power is obtained.
REINSTALLATION KIT
A reinstallation kit including all necessary parts for transfer of the antenna to another vehicle
is available under order No. »GF-RK«.
WARNING
SAFETY PRECAUTIONS
Antennas mounted on the windscreen may cause relatively high field strengths in the
passenger cabin and near the dashboard.
1. To prevent health hazard due to RF radiation, persons must not be closer than 30 cm
to the antenna whip (transmitter output power to the matching unit: 20 W). (DIN 57 848).
2. The RF signals at the dashboard may cause interference in the car’s electronic
equipment such as broadcast radio, computer automatics, braking systems, electronic
ignition, relays etc. Some cars are more susceptible to disturbances than others. It is the
responsibility of the installer to carry out a thorough check of the proper functioning
under any conditions of such circuits before finishing installation.
The enclosed silicone adhesive contains acetic acid and fungicides. Keep out of reach of
children and dispose properly.
ASSEMBLY DETAILS
GF 405/...
PROCOM A/S reserves the right to
amend specifications without prior notice
Page: 2 of 2
Last edited: 2019/07/05
