Amtrol HWBT120-2 Installation instructions

READ CAREFULLY THE PRODUCT
INSTALLATION & OPERATION INSTRUCTIONS.
FAILURE TO FOLLOW THE INSTRUCTIONS AND WARNINGS IN THE
MANUAL MAY RESULT IN SERIOUS OR FATAL INJURY AND/OR
PROPERTY DAMAGE, AND WILL VOID THE PRODUCT WARRANTY.
THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED
PROFESSIONAL. FOLLOW ALL APPLICABLE LOCAL AND STATE
CODES AND REGULATIONS, IN THE ABSENCE OF SUCH CODES,
FOLLOW THE CURRENT EDITIONS OF THE NATIONAL PLUMBING
CODE AND NATIONAL ELECTRIC CODE, AS APPLICABLE
This Product, like most Products under pressure,
may over time corrode, weaken and burst or
explode, causing serious or fatal injury, leaking or flooding and/or property
damage. To minimize risk, a licensed professional must install and
periodically inspect and service the Product. A drip pan connected to an
adequate drain must be installed if leaking or flooding could cause property
damage. Do not locate in an area where leaking could cause property
damage to the area adjacent to the tank or to lower floors of the structure.
EXPLOSION OR RUPTURE HAZARD. A relief
valve must be installed to prevent pressure in
excess of local code requirement or maximum working pressure
designated in the Product Manual, whichever is less. Do not expose
product to freezing temperatures or temperatures in excess of 450°F.
Replace the Product if corroded, damaged or with diminished integrity.
Failure to properly size the product or follow these instructions may result
in excessive strain on the system and may lead to product failure, serious
or fatal personal injury, leakage, and/or property damage.
FOR USE IN CLOSED HYDRONIC SYSTEMS ONLY. Do not install on
domestic water systems, or in open heating systems. Corrosion and tank
failure may result.
HOT WATER BUFFER TANKS
CLOSED LOOP HEATING SYSTEMS HWBT SERIES ASME
INSTALLATION & OPERATION INSTRUCTIONS
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO POTENTIAL PERSONAL INJURY AND OTHER
HAZARDS. OBEY ALL SAFETY MESSAGES THAT FOLLOW THIS SYMBOL TO REDUCE THE RISK OF PERSONAL
INJURY AS WELL AS PROPERTY DAMAGE.
Models HWBT120-2 through HWBT300-4/4
NOTE: Inspect for shipping damage and notify freight carrier or store where purchased immediately if damage is present. To avoid risk of personal
injury and property damage, if the product appears to be malfunctioning or shows signs of corrosion, call a qualified professional immediately. Current
copies of the Product manual can be viewed at www.amtrol.com. Use proper safety equipment when installing.
2 PORT 4 PORT

Pre-Installation
Visually inspect the HWBT for any damage. If damage exists
return product for replacement.
Installation
This product must be installed by a
qualified professional.
Refer to Figure 1 for typical installation of the AMTROL
HWBT Series.
Maintenance
A qualied professional should check the complete system,
including the HWBT, yearly and more frequently as the
system ages.
Operation
1. The HWBT models are designed to add thermal mass to non-
potable, closed, hot water systems helping minimize boiler
cycling that occurs during no/low domestic load conditions.
2. Water temperature not to exceed 450°F.
3. System pressure is not to exceed the maximum working
pressure of the tank.
Warranty
HWBT120-2 through HWBT300-4/4 Models:
One (1) Year Limited Warranty
Visit www.amtrol.com for complete warranty details.
Chlorine & Aggressive Water. The water quality
can significantly influence the life of this product.
You should test for corrosive elements, acidity, total solids and other
relevant contaminants, including chlorine and treat your water appropriately
to insure satisfactory performance and prevent premature failure.
Welding to the pressure vessel boundary will
void the ASME rating.
Leaking, corrosion or indications of damage are
signs of an impending serious failure of the
buffer tank. Periodically inspect for damage and if noted the product
must be serviced or replaced. Failure to follow these instructions
could result in serious personal injury or death and
property damage.
Water temperature above 100°F can be very
hazardous. Allow system water temperature to
cool down below 100°F before blowing down this product. Failure to
follow these instructions could result in serious personal injury or
death and property damage.
EXPLOSION OR RUPTURE HAZARD. A relief
valve must be installed to prevent pressure in
excess of local code requirement or maximum working pressure
designated in the Product Manual, whichever is less. At least once every
3 years or if discharge is present, a licensed contractor should inspect the
temperature and pressure relief valve and replace if corrosion is evident
or the valve does not function. FAILURE TO INSPECT THIS VALVE AS
DIRECTED COULD RESULT IN UNSAFE TEMPERATURE OR
PRESSURE BUILD-UP WHICH CAN RESULT IN PRODUCT FAILURE,
SERIOUS INJURY OR DEATH AND/OR SEVERE PROPERTY
DAMAGE AND VOID THE PRODUCT WARRANTY.
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
IMPORTANT GENERAL SAFETY INFORMATION -
ADDITIONAL SPECIFIC SAFETY ALERTS APPEAR IN THE FOLLOWING INSTRUCTIONS.
© 2015 AMTROL Inc. Part #: 9017-157 (01/15)
Mark of the
Originator
1400 Division Road, West Warwick, RI USA 02893
T: 800.426.8765 F: 800.293.1519
www.amtrol.com
Figure 1
SYSTEM
PUMP
BOILER
2 Port Installation
SYSTEM
PUMP
BOILER
PUMP
4 Port Installation
