AnB TAI-TC-X4DB-A1 User manual

Instruction Manual of Wifi Doorbell
1
User Manual of Video Doorbell

Instruction Manual of Wifi Doorbell
2
1. Introduction:
With mobile apps, two way audio and WiFi connection, WiFi video doorbell can make
the user to have video conversation with the visitors and also control the lock
whenever wherever they are. When the visitors press the doorbell, the camera will
notify the app on user’s smart phone, then user can have video conversation with the
visitors and decide whether to open the door or not. The doorbell can also record the
motion detection photos in front of the door, which make the user know what has
happened in front of door.
The features of the device are in below,
1.1 No matter where you are, you could answer your visitors’ calls, control the lock,
and see the circumstances in front of the door at anytime via mobile apps.
1.2 Support both Android and iOS operating system.
1.3 With the function of infrared night vision，the device can works even in the night.
1.4 With the function of motion detection，the device can take the photos whenever
whatever unusual happened in front of the door.
1.5 Several cellphones could connect with one doorbell at the same time.
1.6 Power by DC 12V/1A—12V/2A(Electronically controlled lock, mute lock use DC12V /
1.5A --- DC12V / 2A power supply).

Instruction Manual of Wifi Doorbell
3
2. Overview of the device

Instruction Manual of Wifi Doorbell
4
3 .In the box
WiFi door intercom*1 pcs
12V/1A Power Adapter*1 pcs
Mounting Bracket*1 pcs
Quick Installation Guide*1 pcs
（Premium Edition contains an indoor dingdong doorbell, customers are free to
choose whether or not need to be equipped）
4. Before using the device
If the product is found cracked, deformed, or has other anomalies when the
package is received, please stop using it immediately and contact the seller or
manufacturer.
Don’t place the product in fire, water, high temperature (<60 ℃) or low
temperature (>-20 ℃) environment.
Don’t disassemble or modify the product, to avoid damage to the product.
Use a dry and soft cloth to clean the surface, don’t use chemicals, soap or
detergent.
If the product is damaged as a result of breach of the warnings above, we will
not bear any legal responsibility.

Instruction Manual of Wifi Doorbell
5
5. Download and Install the app
The device can support iOS device and android device both ways of remote viewing:
1. iOS app can be searched and acquired from Apple “APP Store”by typing “Kdoor
Pro”;
2. Android apk can be acquired from Android “Play Store”by typing “Kdoor Pro”;
User can also scan the QR code below to download and install the app.

Instruction Manual of Wifi Doorbell
6
6. Start Using The Device
Android Configuration
Step 1
Using one of the homeowners’ Android
phones, search for “Kdoor Pro” app
on the Google Play store. Look for the
icon shown. Then download and install to
the users phone.
Step 2
Step 2
Locate the intercom on a bench or table beside the home router, along
with the user phone. Connect the power supply provided to the
intercom, and power on.

Instruction Manual of Wifi Doorbell
7
Step 3
Wait a full 60 seconds for the intercom to fully
boot up.
Step 4
Press and hold the call button for more
than 3 seconds. A loud tone will be
heard. The intercom will now be in
configuration mode for 5 minutes.

Instruction Manual of Wifi Doorbell
8
Step 5 Step 6
Enter settings on the phone, select Enter the following password…
WiFi and scan for networks. The 123456789
phone should detect the intercom.
The network name will be BELL- XXXXX
.
Step 7 Step 8
Now open the Kdoor Pro App on On the next screen, select search as
the phone and select as shown to add shown
intercom.

Instruction Manual of Wifi Doorbell
9
Step 9 Step 10
The phone should then find the On the next screen the intercom should
device. Select it as shown. be showing online status. Select the
settings button.
Step 11 Step 12
Enter WiFi settings as shown. Select option to manage wifi networks
and the intercom will now scan networks
in the area.

Instruction Manual of Wifi Doorbell
10
Step 13 Step 14
Select the network which the home Enter the home owner’s WiFi password
owner is normally using. and press DONE. The intercom should
now re-boot and the phone should then
re-connect to the normal wifi network
.

Instruction Manual of Wifi Doorbell
11
Step 15 Step 16
Wait 2 minutes for the intercom to You may now press the call button and
come back online, and then open the check that the intercom calls the phone
app. The intercom should be showing successfully.
status online.
You are now ready to range test the intercom in the
location which it will be used!

Instruction Manual of Wifi Doorbell
12
I-phone Configuration
Step 1 Using one of the homeowners’
iphones, search for “KdoorPro”
app on the Apple Store. Look for the
icon shown. Then download and
install to the users phone.
Step 2
Locate the intercom on a bench or table beside the home router, along
with the user phone. Connect the antenna & power supply provided to the
intercom, red to +12v dc and black to 0v dc, and power on.

Instruction Manual of Wifi Doorbell
13
Step 3
Wait a full 60 seconds for the
intercom to fully boot up.
Step 4
Press and hold the call button for
more than 3 seconds. The intercom
will sound a long tone, and now be in
configuration mode for 5 minutes.

Instruction Manual of Wifi Doorbell
14
Step 5 Step 6
Enter settings on the phone, select Enter the following password
WiFi and scan for networks. The 123456789. Now the iphone is
phone should detect the intercom. directly connected to the intercom.
The network name will be BELL-
XXXXX)
Step 7 Step 8
Now open the KdoorPro App on Press search. The phone should now
the phone and select as shown to add detect the intercom
intercom.

Instruction Manual of Wifi Doorbell
15
Step 9 Step 10
The intercom should now have been Now the app should show the bell ID,
detected. Select as shown. Default usename & password details.
Press DONE as shown.
Step 11 Step 12
Enter Settings as shown. Select option to manage wifi networks
and the intercom will now scan
networks in the area

Instruction Manual of Wifi Doorbell
16
Step 13 Step 14
Select the network which the home Enter the home owner’s WiFi
owner is normally using. Note the password and press JOIN. The
scan button at top if the iphone does intercom should now re-boot.
not automatically scan for networks.
Step 15 Step 16
Wait 2 minutes for the intercom to You may now press the call button
come back online, and then open the and check that the intercom calls the
app. The intercom should be showing phone sucessfully. Note: It may take
status online several minutes for the operation to

Instruction Manual of Wifi Doorbell
17
fully stabalise
Using the Intercom on iPhone
Note: Because of restrictions by Apple, your iphone will
receive a notification message first. If your screen is
locked, you must swipe the notification banner, then
unlock the screen before the intercom app can begin
calling the phone in full as shown…
1. Swipe & unlock 2. App screen appears. 3. Ringing screen appear
Note: If the phone does not receive a notification
message when the app is running in background mode
or when the screen is locked, please follow the steps
below and try again…

Instruction Manual of Wifi Doorbell
18
Please take note at the end of the process, the phone should show the success
message as shown. If it shows a fail message, please repeat the process.

Instruction Manual of Wifi Doorbell
19
Range Test
Before fully installing this product, it is strongly recommended to temporarily
power the
intercom at the gate and position the antenna to check that it is within range of
the WiFi
router. The manufacturer will not give a full refund for a product which is not
returned in brand new condition.
Once the antenna is in position and the unit has been powered up for more
than 2
minutes, use the users phone inside the house to check for range as follows..
Check that the network which it is connected to is showing at least 20%
strength. If it is
not connecting, or is lower than 20%, then corrective action must be taken at
this stage.
Suggestions are as follows..

Instruction Manual of Wifi Doorbell
20
1. For longer range applications, check if the router is, or can be located at the
front of
the building, preferably near a window or glass, as this will greatly extend range
as
2. If it is not possible to have the WiFi router at the front of the building, then
consider installing a standard “on the market” WiFi repeater or ranger extender.
These can be purchased as a plug in device and are sold in DIY and consumer
electronics stores
3. For even greater range, you can alternatively connect home plug power line
adaptors to the LAN socket on the intercom and on the home router.
