Anchor Acclaim ACL-6000 User manual

Acclaim Lectern System
Portable Lectern Sound System
Advancing Technology
The Acclaim is versatile enough to meet the needs of the most demanding user
and it’s filled with features and benefits that far out shine all the rest. The lectern
base is also a portable transport case with tilt-n-roll casters for easy movement. If
a school or parks & recreation department need a reliable portable lectern sound
system, the Anchor Audio Acclaim will soon be ready to perform.
Anchor Audio, Inc. 888/444-6077
Portable Sound Systems • Torrance, California www.anchoraudio.com
S-ACC/0707
ACCLAIM FEATURES
6-YEAR WARRANTY!
REACH CROWDS OF 500+
114 DB OF CRYSTAL CLEAR SOUND
TRUE AC/DC – 110/220 POWER SUPPLY
16 CHANNEL UHF DIVERSITY WIRELESS
BY ANCHOR AUDIO
SINGLE BUILT-IN WIRELESS RECEIVER OPTION
RUNS 7+ HOURS ON A CHARGE
HIGH FIDELITY SOUND
FROM HIGH EFFICIENCY AMP &
FULL-RANGE SPEAKER
SEALED, LEAD-ACID BATTERIES
& BUILT-IN CHARGER
UNIVERSAL MICROPHONE INPUT JACK
EXTERNAL SPEAKER OUTPUT JACK
POWERS OPTIONAL UNPOWERED
LIBERTY COMPANION SPEAKER
SENSITIVE 24” REMOVABLE ELECTRET GOOSE-
NECK MICROPHONE
DETACHABLE 12V LED READING LIGHT
MADE IN THE USA!
(FEATURES & SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)
(ACL-6000U1
Lower Panel Shown)
UHF WIRELESS
WH-6000 Wireless Handheld mic/transmitter
WB-6000 Wireless body-pack transmitter
w/ handsfree microphone. Mic options include:
Over-the-Ear/EM-60T, Lapel/LM-60,
Collar/CM-60, Headband/HBM-60
ACCLAIM LECTERN TECHNICAL SPECIFICATIONS
Rated Power Output 50 watts
Max SPL @ Rated Power 114 dB @ 1 meter
Frequency Response 60 Hz – 15 kHz ± 3 dB
AC Power Reqs. 90 – 264 VAC, 50/60 Hz, 50 W max
Dimensions
Base (HWD) 14 x 22.5 x 13.5” / 35.6 x 57 x 34.3 cm
Table Top 22.5 x 19” / 57 x 48 cm
Weight 35 pounds / 15.9 Kg
Inputs
Lectern Mic Lo-Z, balanced, phantom power, XLR
Auxiliary Mic Lo-Z, balanced, phantom power, XLR
Line Hi-Z, unbalanced, 1/4” phone
Sensitivity For Rated Output
Lo-Z Microphone -52 dBV (2.5 mVrms)
Hi-Z Microphone -43 dBV (7.5 mVrms)
Auxiliary (line) -14 dBV (200 mVrms)
Outputs
Line (post fader) Lo-Z (<1k ohm), buffered, 1/4” phone
Microphone Lo-Z, balanced, XLR
Speaker switched – 8ohm, 1/4” phone
unswitched – 4ohm, 1/4” phone
ACL-BASE
Dimensions (HWD) 30.5 x 21.5 x 18.5” / 77.5 x 54.6 x 47 cm
Weight 38 pounds / 17.2 Kg
ACCLAIM ACCESSORIES
ACL-BASE Lectern base & transport case – gray
ACL-BASEBK Lectern base & transport case – black
LM-618 Electret gooseneck microphone
MIC-90 Professional dynamic, cardioid pattern
handheld wired microphone
ACL-RL Removable lectern reading light
LIB-6001 Unpowered companion speaker
SC-50 50’ speaker cable for LIB-6001
SS-550 Heavy-duty speaker stand
ACCLAIM MODELS
ACL-6000 AC/DC portable lectern w/ built-in
sound system – gray
ACL-6000U1 AC/DC portable lectern w/ built-in
sound system & wireless receiver – gray
ACL-6000BK AC/DC portable lectern w/ built-in
sound system – black
ACL-6000U1BK AC/DC portable lectern w/
built-in sound system & wireless receiver – black
DC
SOCKET
(ACL-6000U1 Upper Panel Shown)
