Ancona WPRO 30 User manual

18/09/20171303

IMPORTANT SAFETY INSTRUCTIONS
Carefully read the following important information regarding
installation safety and maintenance.
Keep these instructions for future reference.
WPR 30
W  R 
R R
W       
       


2
Important Safety Notice
Read all Instructions before Installing and operating this appliance
•The installation in this manual is intended for qualied installers, service technicians or persons with
similar qualied background. Installation and electrical wiring must be done by qualied profession-
als and in accordance with all applicable codes and standards, including re-rated construction.
•DO NOT attempt to install this appliance yourself. Injury could result from installing the unit due to
lack of appropriate electrical and technical background.
• Range hood may have very sharp edges please wear protective gloves if it is necessary to remove any
parts for installing, cleaning or servicing.
•Activating any switch ON before completing installation may cause ignition or an explosion.
•Due to the size and weight of this range hood, two people installation is recommended.
To reduce the risk of fire, electric shock, or injury to persons:
•For general ventilating use only. DO NOT use to exhaust hazardous or explosive materials and va-
pors.
•The combustion air ow needed for safe operation of fuel-burning equipment may be affected by this
unit’s operation. Follow the heating equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association (NFPA), and the American Society of
Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.
• Before servicing or cleaning unit, switch power OFF at service panel and lock service panel to pre-
vent power from being switched ON accidentally.
• Clean grease laden surfaces frequently. To reduce the risk of re and to disperse air properly, make
sure to vent air outside. DO NOT vent exhaust into spaces between walls, crawl spaces, ceiling, attics
or garages.
•Ducted fans MUST always be vented to the outdoors.
• Use only metal ductwork and this unit MUST be grounded.
• Sufcient air is needed for proper combustion and exhausting of gases through the duct to prevent
back drafting.
• When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hid-
den utilities.
•All electrical wiring must be properly installed, insulated and grounded.
•Old duct work should be cleaned or replaced if necessary to avoid the possibility of a grease re.
• Check all joints on duct work to insure proper connection and all joints should be properly taped.
•Use this unit only in the manner intended by the manufacturer. If you have questions, contact the
vendor.
To reduce the risk of a stove top grease fire:
•Keep all fan, bafe, spaces, lter, oil container and grease-laden surfaces clean. Grease should not be
allowed to accumulate on fan, bafe, spaces, lter and oil container.
• Always turn range hood ON when cooking at high heat or when cooking aming foods.
•Use high settings on cooking range only when necessary.
•Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers
that may ignite. Heat oils slowly on low or medium settings.


                 
• Clean ventilating fan frequently.
• Always use appropriate cookware and utensils size.
• Always use cookware appropriate for the size of the surface element.
3


To reduce the risk of injury to persons in the event of a stove top grease fire:
• SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn OFF the burner.
BE CAREFUL TO PREVENT BURNS. NEVER PICK UP A FLAMING PAN—you may be burned. KEEP
FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames DO NOT go out
immediately, EVACUATE AND CALL THE FIRE DEPARTMENT or 911.
• DO NOT USE WATER, including wet dishcloths or towels — a violent steam explosion will result.
• Use an extinguisher ONLY if:
• You know you have a Class A, B, C extinguisher, and you already know how to operate it.
• The fire is small and contained in the area where it is started.
• The fire department is being called.
• You can fight the fire with your back to an exit.
To reduce the risk of injury to persons in the event of a gas leaks:
• Extinguish any open flame.
• DO NOT turn on the lights or any type of appliance.
• Open all doors and windows to disperse the gas. If you still smell gas, call the gas company and fire department, or
911 immediately.
Yo u r s a f et y a nd t he s a f et y o f o t h er s a r e v e r y i m p o r tant. We have provided many important safety messages in this manual
and on your appliance. Always read and obey all safety messages. All safety messages will tell you what the potential
hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.
This is the safety alert symbol. This symbol alerts you to potential hazards that can hurt you and others. All safety
messages will follow the safety alert symbol and the word “WARNING”.

Upper Chimney
Lower Chimney
Range hood
Hood-mounting bracket
Qty: 6 + 1 pcs
Hood mounting
bracket
Qty: 8 + 1 pcs
Chimney screw
Qty: 4 + 1 pcs
Mounting hood
to wall &
upper chimney
bracket to wall
Qty: 4 + 1 pcs
Mounting hood
to wall &
upper chimney
bracket to wall
Baffle filters
Chimney-mounting Bracket
Qty: 8 + 1 pcs
Handle screw
Grease Tunnel
Parts Supplied :
4
Flexible duct tube
4 Baffle filter handle

    
•Vent system must terminate to the outside
(roof or side wall).
• DO NOT terminate the vent system in an
attic or other enclosed area.
• DO NOT use 4” (10.2 cm) laundry-type wall
caps.
• Use metal/aluminum vent only. Rigid metal/
aluminum vent is recommended.
• DO NOT use plastic vent.
•
Always keep the duct clean to ensure proper
airflow.
•
Calculate the following figures before instal-
lation:
1. Distance from the floor to the ceiling.
2. Distance between the floor to the coun-
tertop/stove
3. Distance between the cooking surface
to the range hood (recommend 24” to
30”) minimum of 30” is required for
gas stove top
4. Height of hood and duct cover.
Lower
Chimney
For the most efficient & quiet operation:
Range hood
• A distance of 24” to 30” is recommended
between stove top and the bottom of range
hood. 30” minimum is required for gas stove
tops
•
It is recommended that the range hood be
vented vertically through the roof through
   or bigger round metal/
aluminum vent work.
• The size of the vent should be uniform.
• Use no more than three 90° elbows.
•Make sure there is a minimum of 24” (61
cm) of straight vent between the elbows if
more than one elbow is used.
• DO NOT install two elbows together.
•
The length of vent system and number of
elbows should be kept to a minimum to pro-
vide efficient performance.
• The vent system must have a damper. If
roof or wall cap has a damper, DO NOT
use damper (if supplied) on top of the range
hood.
•Use silver tape or duct tape to seal all joints
in the vent system.
•Use caulking to seal exterior wall or roof
opening around the cap.
Height
Min: 24”
Max: 30”
Ceiling
36”
Counter
Top
Countertop/Stove
Upper
Chimney
Chimney-
mounting
bracket
Max: 110”
Maximum ceiling
clearance 110" at
30" hood mounting
height above
countertop/stove
(may vary with
different model.
5

6
Duct Run Calculation:
Recommended maximum run
6” or 3-1/4 x 10” duct 50 ft
Vent piece deduction
Each 90 elbow used 9 ft
Each 45 elbow used 5 ft
Each 6” to 3/14 x 10” transition used 7 ft
Side wall cap with damper 0 ft
Roof cap 0 ft
IMPORTANT:
• A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate-
ly) must be used to maintain maximum airow efciency.
• Always use rigid type metal/aluminum ducts if available to maximize airow when connecting to provided
duct.
• Please use Duct Run Calculation below to compute total available duct run when using elbows, transitions
and caps.
• ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is required, increase
duct size from 6” to 7” or 8”. If a reducer is used, install a long reducer instead of a pancake reducer. Reduc-
ing duct size will restrict airow and decrease airow, thus reduce duct size as far away from opening as
possible.
• If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible.
• Minimum mount height between stove top to hood bottom should be no less than 24-inch for electric cook
tops and minimum of 30” for gas stove tops and no higher than 30 inch for electric cook tops.
• It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat
damage and re hazard while hoods mounted too high will be hard to reach and will loose its performance
and efciency.
• If available, also refer to stove top manufacturer’s height clearance requirements and recommended hood
mounting height above range.
Minimum Duct Size:
• Round - 6” minimum
• Rectangular - 3-1/4 x 10” minimum (requires a 6” to 3-1/4x10” adaptor, not supplied)
To calculate the length of the system you need, deduct the equivalent feet for each vent piece used in the system
from the recommended maximum duct run.
Duct Run Calculation example:
One roof cap, two 90º elbow, and one 45º elbow used:
0ft + 9ft + 9ft + 5ft = 23ft used.
Deduct 23ft from 50ft, 27ft maximum available for
straight duct run.
Calculating Vent System Length :

7
Venting methods:
• This range hood is factory set for venting through the roof or wall.
• Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed.
IMPORTANT:
• NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or
garages. All exhaust must be ducted to the outside.
• Use metal/aluminum duct work only.
• Fasten all connections with sheet metal screws and tape all joints with certied Silver Tape or Duct Tape.
• Use caulking to seal exterior wall or roof opening around the cap.
Option 1:
Horizontal wall venting
Option 2:
Side wall cap
Vertical roof venting
Roof cap

IMPORTANT: Observe all governing codes and
ordinances.
It is the customer’s responsibility:
    lii lil isll
 s i   s  i is s i is    lii lii i 
   is 
 l   l s lil sl is i   s  ii s  
sis   li
     s i
 i  lii lii i    s     is l 
    s i  l   ii
IMPORTANT: Save this Installation Guide for electrical inspector’s use.
Electrical Requirements :
The range hood must be connected with copper wire/plug only.
The range hood should be connected directly to the fused disconnect (or circuit breaker) box through flexible
armored or non-metallic sheathed copper cable. ETL: listed strain relief must be provided at each
end of the
power supply cable.
8

Preparation:
Advanced Preparations:
•Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 12.
• Place the range hood on a at, stable surface. Connect the range hood to a designated standard outlet (120-Volt,
60Hz, AC only) and turn on the range hood. Verify all operations of the range hood by referring to Range
Hood Operations, Page 12.
• Place all supplied parts and required hardware on a at, stable surface and verify the existence of all supplied
parts listed on Page 4.
• Carefully remove the white plastic protective coat from the range hood.
Preparations:
NOTE: To avoid damage to your hood, prevent debris from entering the vent opening.
• Determine and mark the center line on the ceiling where the range hood will be installed. Make sure there is
proper clearance within the ceiling or wall for exhaust vent.
• Due to the weight and size of this unit, please make sure that the support system or framework being used is
stable and secure in the wall.
• Put a thick, protective covering over counter top, cook top or range to protect from damage or dirt. Remove
any hazardous objects around the area when installing.
• Mark the locations of the support mounting bracket holes, vent cutout (if used) and power supply cable cutout
on the ceiling. Use drill and saber saw or keyhole saw to cut openings for power supply cable and vent (see
Venting requirements and Electrical requirements, Pages 6-8).
•If venting to the outside install vent system (see Venting Requirements, Page 5). Use caulking to seal exterior
wall or roof openings.
• Disconnect main electrical supply, prepare and run electrical wiring through ceiling or wall. Leave approxi-
mately 12” of electrical cord hanging from the ceiling. Do not restore power until wiring is completed.
• Disconnect power cord, remove the bafe lter by sliding the knob toward the metal lter handle.
• Set aside the bafe lters until the range hood is properly installed.
CAUTION: If moving the cooking range is necessary to install the hood, turn OFF the power on an
electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE.
9

Installation:
Installations (refer to Page 4 for parts):
1. Measure the distance between stove top and the bottom of range hood. A distance of 24” to 30” is
recommended with a minimum of 30” for gas stove tops.
2. Using references in Height & Clearance on Page 5 and
Measurements and Diagrams on Page 16, mark the leveling point of the hood. Position two mounting
screws on the wall, leaving 1/8” space away from the wall.
3. Position the chimney-mounting bracket directly above the hood-mounting bracket, mark the leveling
points and secure it using two mounting screws.
NOTE: Use threaded drywall anchors only when mounting the hood on sheet rock. Mounting the hood
on wall studs or lumbers is highly recommended.
4. Attach the hood-mounting bracket to the back of the hood with six screws as shown in Figure 3.
5. Align hood-mounting bracket to the screws on the wall and hook hood into place as shown in Figure 4 and
Figure 5. Tighten screws to secure hood to the wall.
CAUTION: Make certain the range hood is secure before
releasing!
6. For safety purpose, pre-drilled mounting holes are provided through the back of the hood. For a more
secure installation, use as many mounting holes as needed to secure from the inside of hood.
7. Use 6” round steel pipe (follow building codes in your area) to connect the exhaust on the hood to the
duct- work above. Use silver tape or duct tape to make all joints secure and air tight. Refer to Figure 7.
SAFETY WARNING: Risk of electrical shock. This range hood must be properly grounded. Make sure
this is done by qualified electrician in accordance with all applicable national and local electrical codes.
Before connecting wires, switch power off at service panel and lock service panel to prevent power
from being switched on accidentally.
Figure 7
Figure 3 Figure 4
Figure 5 Figure 6
10

11
Installation (Continued):
8. Connect the range hood to a designated standard outlet (120-Volt,
60Hz, AC only) or cut off the plug and connect three wires (black,
white and green) to house wires and cap with wire connectors. Con-
nect according to colors (i.e. black to black, white to white, and
green to green)
9. Store excess wires in the wiring box.
F
Fi
ig
gu ur
re
e 8
8
10. Install both chimneys and tighten screws to secure the lower chim-
ney to the range hood as shown in Figure 8.
11. To avoid scratching the chimney, extend the upper chimney slowly
and carefully to the chimney-mounting bracket and tigten screws
as shown in Figure 9.
12. To install bafe lters, refer to Figure 10 for the following three
steps:
Angle bafe lter toward back of hood.
Slide the knob toward the metal lter handle and push up.
Release the knob until it ts into resting positions.
13. Repeat Step 12 to install all bafe lters.
14. Turn powe ON in control panel. Check all lights and fan operations.
15. Make sure to leave this Installation Guide for the homeowner.
Figure 9 Figure 10

12
Range Hood Operations:
LED Light
Indicator
LED Speed
Indicators
Light Control Speed Control Power Control
(On/Off)
This range hood is equipped with six electronic controls, oversized powerful centrifugal squirrel cage
motor with stainless steel bafe lters and spacers, two bright 3 W LED lights.
The six electronic buttons control the intensity of the Lights, Speeds (uiet, Low, Medium and High) and Power
(On/Off). The Power Control (On/Off) offers startup, 3-minute delay or immediate power-off. The Light
Control operates independently from the Power Control (On/Off) and is not affected by the delay shutoff.
Turning Fan ON:
Always turn fans ON before cooking to establish air ow and allow fans to run for a few minutes after cooking
for cleaner air in the kitchen. The Power Control (On/Off) button must be pressed before a Speed Control button
can be activated. NOTE: The light setting will not be affected by the Power Control (On/Off) button.
• Press the Power Control (On/Off) button once. The four LED Speed Indicators above the Speed Control will
ash, if a Speed Control button is not pressed within 10-seconds, power will be turn OFF automatically.
•While the LED Speed Indicators are ashing, press a Speed Control button to activate the desired speed
• To change the fan speed, press another Speed Control button.
Turning Fan OFF:
The 3-minute power-off delay function will only turn OFF fans. The light settings will not be affected by the delay
function.
Three-Minute Delay
• While the fans are operating, press Power Control (On/Off) button once, the LED Speed Indicator for the
active speed will ash and fans will turn OFF after 3-minutes.
Control Panel Layout and Buttons Configurations:

13
uiet
Speed
Low
Speed
Medium
Speed
High
Speed
LED Light
Indicator
LED Speed
Indicators
Light Control Power Control
(On/Off)
• During this 3-minutes delay, changing speeds will not affect the countdown.
eiate oer-o
• While the fans are in 3-minute power-off delay mode, press the Power Control (On/Off) button once to
turn OFF the fans immediately.
• When the fans are operating in normal mode (LED Speed Indicator not ashing), press the Power Control
(On/Off) twice to turn OFF the fans.
Light Control:
Light Control button operates independently from the Power Control (On/Off) and power-off delay function.
Pressing the Power Control (On/Off) button or activating the delay function will not turn LED lights ON or
OFF. CAUTION: DO NOT touch the lights until switched OFF.
• While the LED lights are OFF, press the Light Control button once to turn LED lights ON at High
intensity. LED Light Indicator will light up.
• Touch the Light Control button again will change the light to 
Range Hood Operations (Continued):
Control Panel Layout and Buttons Configurations:

14
Troubleshooting
1. If the range hood or LED light does not operate •
after installation:
Check if the range hood has been plugged in, make
sure that all power has been turned back ON, fused
not blown and all electrical wiring are properly con-
nected.
Swap out light assembly to working ones to deter-
mine whether it is caused by defective bulbs. See
Replacing the light bulbs on Page 22.
2. The range hood vibrates when the blower is on: • The range hood might not have been secured prop-
erly on to the ceiling or wall.
3. The blower or fan seems weak: • Check that the duct sized used is at least 6” or 3-1/4
x 10”. Range hood WILL NOT function efciently
with insufcient duct size. For example: 7” duct
over 6” hole and loosely secured.
• Check if duct is clogged or if damper unit (half-cir-
cular apper) is not installed correctly or opening
properly. A tight mesh on a side wall cap unit might
also cause restriction to the air ow.
4. The lights work but the blower is not spinning at all, •
is stuck or is rattling.
The blower might be jammed or scraping the bot-
tom due to shipping damage. Please contact us im-
mediately.
5. The hood is not venting out properly: • Make sure the distance between the stove top and
the bottom of the hood is within 24” and 30” in
distance with minimum 30” for  stove top.
• Reduce the number of elbows and length of duct
work. Check if all joints are properly connected,
sealed, and taped.
• Make sure the power is on high speed for heavy
cooking.

Use and Care Information:
Operations:
• Read and understand all instructions and warnings in this manual before operating the appliance. Save these
instructions for future reference.
• Always leave safety grills and lters in place. Without these components, operating blowers could catch on to
hair, ngers and loose clothing.
• NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers.
• NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch re. The risk of
self combustion is higher when the oil has been used several times.
• NEVER cook on “open” ames under the range hood. Check deep-fryers during use: Superheated oil may be
ammable.
Cleaning:
• The saturation of greasy residue in the blower and lters may cause increased inammability. Keep unit clean
and free of grease and residue build-up at all times to prevent possible res.
• Filters must be cleaned periodically and free from accumulation of cooking residue (see cleaning instructions
on Page 22). Old and worn lters must be replaced immediately.
•DO NOT operate blowers when lters are removed. Never disassemble parts to clean without proper instruc-
tions. Disassembly is recommended to be performed by qualied personnel only. Read and understand all
instructions and warnings in this manual before proceeding.
Specifications3:
Body Design Seamless Stainless Steel, Satin Finish / Glossy Piano Black Finish
Power Rating 120V / 60Hz (USA  Canada standard)
General Input Power  W ( W  2 x  W)
Motor Input Power 8 W
Ampere 2. A
Levels Of Speed Control 4 Levels
Number Of Motors Single Motor
Motor Type Single Chamber Ultra uiet
Fan Type Centrifugal Squirrel Cage
Control Type Electronic Button Control
Filtration Type Stainless Steel Bafe Filter
Illumination     LED
Venting Size Top, 6 inches Round
Interference Protection Radio Frequency Interference Protected
15
Specifications:

Instlltion erie
6
Measurements and diagrams:

•
•
All measurements in parenthesis are in i.
All inch measurements are converted from is, thus inch measurements are estimated.
Overall:
17


•
•
All measurements in parenthesis are in is.
All inch measurements are converted from is, thus inch measurements are estimated.
Overall without Chimney:

19
Hood-mounting Bracket:
Circuit Diagram:

20
Range Hood Assembly:
No. Description No. Description
 il l
 i l
1  i
1  il l
1  il s
1 l ll l
1  si
2  
3 i 
4  l
5 l
6 i
7 l 
 l
1   ssl
1 i 
