SF60
Water Heater
Technical Documentation
This manual must be kept with the appliance November 2013

Technical data
SF61 SF62 SF63 SF64 SF65 SF66 SF67
Maximum set point ºC 75 75 75 75 75 75 75
Nominal heat output at 75-60ºC max/min* kW 142.2/23.5 190.3/39.5 237.4/39.5 285.5/39.5 380.6/76.6 475.8/76.6 539.6/76.6
Nominal heat output at 40/30ºC max/min* kW 150.7/26.7 201.6/45.2 251.4/45.1 302.3/45.2 403.1/87.7 503.9/87.7 571.5/87.7
Nominal heat input Hi max/min* kW 145.0/24.5 194.0/41.5 242.0/41.5 291.0/41.5 388.0/80.5 485.0/80.5 550.0/80.5
Efficiency at 40/30ºC % 103.9
Annual efficiency (NNG 75/60ºC) % 106.8
Annual efficiency (NNG 40/30ºC) % 110.4
Standstill losses (Twater = 70ºC) % 0.21 0.18 0.17 0.16 0.15 0.14 0.13
Max. condensate flow l/h 11 15 19 22 30 37 42
Gas consumption H-gas max/min (10,9 kWh/m
3
) m
3
/h 13.3/2.3 17.8/3.8 22.2/3.8 26.7/3.8 35.6/7.4 44.5/7.4 50.5/7.4
Gas consumption L-gas max/min (8,34 kWh/m
3
)m
3
/h 17.4/2.9 23.2/5.0 29.0/5.0 34.9/5.0 46.5/9.7 58.2/9.7 66.0/9.7
Gas consumption LL-gas max/min (8,34 kWh/m
3
) m
3
/h 17.4/2.9 23.2/5.8 29.0/5.8 34.9/5.8 46.5/11.2 58.2/11.2 66.0/11.2
Gas consumption LPG max/min (12,8 kWh/kg) kg/h 11.3/1.9 15.2/3.2 18.9/3.2 22.7/3.2 30.3/6.3 37.9/6.3 43.0/6.3
Gas pressure H-gas mbar 20
Gas pressure L/LL-gas mbar 25
Gas pressure LPG mbar 30/50
Maximum gas pressure mbar 100
Fluegas temperature at 80/60ºC max/min ºC 78/61
Fluegas temperature at 40/30ºC max/min ºC 56/30
Fluegas quantity max/min* m
3
/h 238/40 318/69 397/69 477/69 636/134 795/134 901/134
CO2level natural gas max/min % 10.2/9.4
CO2level LPG max/min % 11.9/10.0
NOx level max/min mg/kWh 35/15
CO level max/min mg/kWh 14/8
Max. permissible flue resistance max/min Pa 160/10 160/10 200/10 200/10 200/10 250/10 250/10
Water volume l 27 31 35 61 68 75 82
Water pressure max/min bar 8/1
Electrical connection V 230/400
Frequency Hz 50
Mains connection fuse A 10
IP class - IP20
Power consumption boiler max/min (excl. pump) W 158/43 200/35 230/35 260/35 470/61 650/61 770/61
Power consumption DHW pump (optional) W 245 340 470 470 720 1150 1550
Power consumption DHW bypass pump W 245 245 245 245 380 460 530
Power consumption swimming pool pump (optional) W 550 900 1500 1100 2200 3000 3000
Weight (empty) kg 295 345 400 465 535 590 650
Noise level at 1 meter distance dB(A) 59
Ionisation current minimum µA 6
PH value condensate - 3.2
CE certification code - CE-0063BS3840
Water connections - R2" DN65 PN16
Gas connection - R3/4" R1" R1.1/2"
Flue gas connection mm 150 200 250
Air intake connection (for room sealed use) mm 130 150 200
Condensate connection mm 22
* min load on gasses H/L/LPG. For type R602-R607 on LL-gas min value is 15% higher.
2

Dimensions (water heater)
Top view
Rear view Side view Front view
Dimensions SF61 SF62 SF63 SF64 SF65 SF66 SF67
Lmm 1105 1260 1470 1220 1435 1585 1735
L2 mm 127.5 127.5 137.5 137.5 187.5 187.5 187.5
Hmm 1480 1480 1500 1500 1500 1500 1500
H2 mm 1120 1130 1130 1150 1245 1245 1245
Bmm 670 670 670 770 770 770 770
B2 mm 225 235 235 235 260 260 260
B3 mm 260 260 260 310 310 310 310
B4 mm 130 130 130 245 245 245 245
D1 mm 130 150 150 150 200 200 200
D2 mm 150 150 200 200 250 250 250
W1 R” / DN R2” R2” R2” DN65 PN16
W2 R” / DN R2” R2” R2” DN65 PN16
GR R3/4” R1” R1” R1” R1 1/2”
1 Electrical connections
2 Gas supply
3 Water supply
4 Water return
5 Air intake
6 Boiler water drain valve 1/2”
7 Flue gas outlet
8 Condensate drain
flexible hose 25mm diam.
7(D2)
1
2(G)
3(W1)
4(W2)
5(D1)
6
8
B3 B2
B4
B
413490
1175
H2
73 L2
L
H
115
1440
3

General
This document is meant to be used in addition to the SUPAheat SH60 (R600) heating
boiler documentation, in case of having a SUPAflo SF60 (R600) water heater version.
This documentation only contains the difference in construction and application to the
heating boiler version. General information on the boiler (transport, commissioning,
maintenance, etc.) can be found in the heating boiler documentation.
Technical Description
The SF60 water heater are applicable for direct heating of sanitary hot water without
using an hydraulic separation (i.e. plate heat exchanger) in the system.
This special version of the SF60 boiler series is mainly identical to the heating boiler version,
except for the manifolds on the heat exchanger. These are made from stainless steel instead
of cast iron, assuring the hydraulic side of the boiler being fully made of stainless steel and
allowing the boiler to be flushed with the sanitary hot water directly.
4

Water quality
Water heater
As a water heater is constantly flushed with fresh water, there are restrictions to the
maximum flow temperature related to the hardness of the water. The following table indicates
the maximum flow temperatures for different water hardness values. Not respecting these
values can lead to damage of the heat exchanger.
Maximum flow temperature related to water hardness
Water hardness Max. setpoint (P1) Temp. limiter setting High limit setting
[ºdH] [ºf] [ºC] [ºC] [ºC]
15 - 20 27 - 36 80 87 90
20 - 28 36 - 50 60 67 70
Hot water production (water heater only)
The following table shows the sanitary hot water tapping volumes which can be achieved
with an SF60 water heater, based on a cold water inlet temperature of 10ºC.
Hot water tapping volumes (cold water = 10ºC)
Output flow @50ºC flow @60ºC flow @65ºC flow @70ºC
[kW] [l/min] [l/min] [l/min] [l/min]
SF61 142 51.1 40.8 37.1 34.0
SF62 190 68.3 54.7 49.7 45.5
SF63 237 85.2 68.2 62.0 56.8
SF64 285 102.5 82.0 74.5 68.3
SF65 380 136.6 109.3 99.4 91.1
SF66 475 170.8 136.6 124.2 113.9
SF67 539 193.8 155.0 141.0 129.2
5

Hydraulic connection
Water heater
The SF60 water heater must be installed in such a way, that a minimum water flow rate of
30% of the nominal flow rate can be assured at all times when the burner is switched on. The
SF60 water heater can increase the water temperature by maximum 17K at once. This
means that the water has to cycle through the boiler several times when f.e. cold water of
10ºC has to be heated up to 60ºC (3 times).
This is normally done by installing the SF60 water heater in combination with a buffer tank.
The flow rate from the tank to the water heater and back can then be secured by the
(primary) water heater pump.
The table below shows the nominal water flow data a
(optional) pump kit for each type of water heater.
Water flow data water heater
flow rate
Boiler
resistance
Pump type Voltage Curve
setting
Pump
head
Residual
pump head
[K] [m3/h] [kPa] [-] [V] [-] [kPa] [kPa]
SF61 7.2 14 UPS 32-80B 230 3
-
34
-
20
-
SF62 9.5 25 UPS 32-120FB 230 3
2
61
30
36
5
SF63 12.0 39 UPS 40-120FB 230 3
2
64
48
25
9
SF64 14.4 21 UPS 40-120FB 230 3
2
50
30
29
9
SF65 19.2 37 UPS 50-120FB 400 3
2
64
47
27
10
SF66 24.0 58 UPS 65-120FB 400 3
-
76
-
18
-
SF67
17
27.2 76 UPS 65-180FB 400 3
-
104
-
28
-
6

7
System examples
The following examples are only meant to give an indication of the possibilities available with
the SF60 water heater and swimming pool boilers. These examples can not be used in a
project without any further analysis of the project situation by an authorized company.
System 1:water heater with buffer tank (1)
Water heater connected to a buffer tank, with the cold water feed connected to the return
connection of the buffer tank. This is the most common way to connect a water heater.
Having the cold water feed on the return connection of the tank results in less start/stop
sequences of the water heater and creates a stable temperature control in a normal hot
water installation.
System 2: water heater with buffer tank (2)
Water heater connected to a buffer tank, with the cold water feed connected to the return
connection of the water heater. This system is only applicable when there’s a constant hot
water demand of hot water, peak loads can cause a high number of start and stop
sequences.

8
System 3:water heater with big buffer tank
When having temporary peak demand, it’s useful to have a big buffer tank (or multiple
smaller tanks in series) in combination with a small water heater capacity. The capacity of
the water heater is determined by the maximum loading time of the buffer tank.
System 4: water heater cascade
When having a constant high demand of hot water, it’s useful to install a high capacity water
heater (or even a cascade of multiple water heaters) in combination with a small buffer tank.
The Buffer tank is only covering the starting delay of the boilers, after that the boilers
completely cover the hot water demand constantly.

9
System 5:bypass water heater
This system is mainly used in industrial processes with a constant demand of hot water.
The bypass water heater can be used without a buffer tank, as the internal bypass covers the
minimum flow rate through the water heater. The Bypass water heater can heat up the hot
System 6:bypass water heater with buffer tank
This system is mainly used in industrial processes,where there is a requirement for direct
increase of the water temperature with more than 17K, without having a constant demand.
Without the buffer tank the bypass water heater would generate many startsand stops and
have a restive regulation.
